CHAPTER 1 RÉGLAGES GÉNÉRAUX
CONSIGNES DE SECURITEÉ
WARNING: BEFORE SERVICING THIS CHASSIS, READ THE “X-RAY RADIATION PRECAUTION”, “SAFETY PRECAU-
TION” AND “PRODUCT SAFETY NOTICE” INSTRUCTIONS BELOW.
X-RAY RADIATION PRECAUTION
1. Excessive high voltage can produce potentially hazardous X-RAY RADIATION. To avoid such hazards, the high
voltage must not be above the specified limit. The nominal
value of the high voltage of this receiver is (A) kV at zero
beam current (minimum brightness) under a (C) V AC power
source. The high voltage must not, under any circumstances, exceed (B) kV.
Refer to table-1 for high voltage (A), (B) & AC voltage (C).
(See SETTING & ADJUSTING DATA on page 32)
Each time a receiver requires servicing, the high voltage
should be checked following the HIGH VOLTAGE CHECK
procedure in this manual. It is recommended that the reading of the high voltage be recorded as a part of the service
record. It is important to use an accurate and reliable high
voltage meter.
SAFETY PRECAUTION
WARNING : Service should not be attempted by anyone unfamiliar with the necessary precautions on this receiver. The following
are the necessary precautions to be observed before servicing this chassis.
1. An isolation transformer should be connected in the power line between the receiver and the AC line before any service is
performed on the receiver.
2. Always discharge the picture tube anode to the CRT conductive coating before handling the picture tube. The picture tube
is highly evacuated and if broken, glass fragments will be violently expelled. Use shatter proof goggles and keep picture tube
away from the unprotected body while handling.
3. When replacing a chassis in the cabinet, always be certain that all the protective devices are put back in place, such as; nonmetallic control knobs, insulating covers, shields, isolation resistor-capacitor network etc.
2. The only source of X-RAY RADIATION in this TV receiver
is the picture tube. For continued X-RAY RADIATION protection, the replacement tube must be exactly the same
type tube as specified in the parts list.
3. Some part in this receiver have special safety-related characteristics for X-RAY RADIATION protection. For continued safety, parts replacement should be undertaken only
after referring to the PRODUCT SAFETY NOTICE below.
GENERAL ADJUSTMENTS
SPECIFIC INFORMATIONS
PRODUCT SAFETY NOTICE
Many electrical and mechanical parts in this chassis have special safety-related characteristics. These characteristics are
often passed unnoticed by a visual inspection and the protection afforded by them cannot necessarily be obtained by using
replacement components rated for higher voltage, wattage, etc. Replacement parts which have these special safety characteristics are identified in this manual and its supplements; electrical components having such features are identified by
the international hazard symbols on the schematic diagram and the parts list.
Before replacing any of these components, read the parts list in this manual carefully. The use of substitute replacement
parts which do not have the same safety characteristics as specified in the parts list may create shock, fire, X-ray
radiation or other hazards.
– 3 –
Page 4
CAUTION : DO NOT LOOSEN THE HEX HEAD BOLTS WITH SPRINGS (12 PCS), BECAUSE THOSE ARE FOR
SEALING OF CRT COOLANT.
GENERAL ADJUSTMENTS
CRT ASSEMBLY REPLACEMENT AND MOUNTING
Attention Serviceman
The Hex Head
Bolts with
Springs. (see
sketch) used on
CRT assembly,
are “NOT”
Adjustment Screws
DO NOT LOOSEN-FLUID
LEAKAGE WILL OCCUR.
SPECIFIC INFORMATIONS
Lens Assembly
CRT Assembly
CRT Anode Cap Assembly
S.V.M. Coil
4 Screws
4 Screws
CRT DRIVE Board
CRT Mounting
Deflection Yoke and Conver Yoke
Lens and Neck Components View
– 4 –
Page 5
TO REMOVE CRT (Same procedure for R, G, B)
1. Remove CRT DRIVE Board, S. V. M. COIL and
DEF. YOKE from CRT.
2. Remove Lens Assembly.
3. Detach CRT Anode Cap from CRT.
4. Remove CRT Assembly from CRT Mounting.
CRT REPLACEMENT (Same procedure for R, G, B)
Reverse the removal procedures except the followings.
1. Anode Cable should be replaced with new one.
See "SERVICING PRECAUTIONS" shown below.
2. Install silicon (T461B) to the CRT, replace the Anode
cable and put enough silicon again on around the Anode Cap as illustrated.
CAUTION: Align the Anode cable as illustrated on page
4.
ADJUSTING PROCEDURE IN REPLACING CRT
1. R.G.B. CUTOFF (SCREEN VR) ADJUSTMENT (page 6.)
2. R.G.B. FOCUS ADJUSTMENT (page 6.)
3. PICTURE TILT ADJUSTMENT (page 7.)
4. USER CONVERGENCE CENTER CHECK
(Refer to owner's manual.)
5. CENTERING ADJUSTMENT (page 7.)
6. CONVERGENCE ADJUSTMENT (page 21.)
7. WHITE BALANCE ADJUSTMENT (page 14.)
Adjustments are complete.
Silicon
(On shaded area)
TSE3843W #23960136
Anode Cap
2 ~ 5 mm
GENERAL ADJUSTMENTS
SPECIFIC INFORMATIONS
SERVICING PRECAUTIONS
■ Do not use a magnetized screw driver for screws
of Deflection Yoke and Velocity Modulation Coil to
avoid magnetization of electron gun.
Magnetization of electron gun will degrade basic
function and result in unbalance of right and left
shift of user static convergence, and result in no
variable quantity.
Screw
for D.Y
15 ~ 25 mm
■ When replacing the anode cap assembly (CRT) or
anode lead assembly (F.B.T.), remove the anode
lead holder from old one and attach the holder
again to new anode lead.
■ Check the point of anode lead in a straight
line, if it is winding, please revise it.
Anode lead holder
Screw for SVM coil
– 5 –
Page 6
WARNING: BEFORE SERVICING THIS CHASSIS, READ THE "X-RAY RADIATION PRECAUTION", "SAFETY PRE-
CAUTION" AND "PRODUCT SAFETY NOTICE" ON PAGE 3 OF THIS MANUAL.
PICTURE TUBE COMPONENTS ADJUSTMENT
ADJUSTING PROCEDURE IN REPLACING CRT
Cutoff
Lens focus
Electrical focus
GENERAL ADJUSTMENTS
Yoke horizontal
DESCRIPTION OF NECK COMPONENTS
SPECIFIC INFORMATIONS
S.V.M. COIL
1 Deflection yoke and convergence yoke.
The position on the neck is required most front (CRT funnel side) and the screw is fastened after rotating yoke
adjusting picture tilt.
2 Centering magnet
After adjusting picture tilt, picture position is finally fixed
by this magnet.
In order to get maximum margin of user convergence control for center of screen, this magnet have to be used for
center convergence adjustment.
2
User convergence center check
Centering (PAL)
Convergence adjustment
(PAL/NTSC)
White balance
Sub bright adjustment
End
1
RGB FOCUS ADJUSTMENT
1. Call-up the adjustment mode (see page 10)
2. Press a button on the remote controller in order to display
the internally-generated cross-hatch (See TEST SIGNAL
SELECTION on page 11.)
3. Expose only RED by covering the GREEN and BLUE
lenses with caps.
4. Loosen the RED lens fixing screws (refer to Fig. a), and
adjust the RED lens focus to obtain the sharpest point
while observing the middle and peripheral sections of the
screen.
Fig. a
5. Use the focus VR of “R” of the focus pack in order to adjust
the electric focus in the middle and peripheral sections of
the screen to its sharpest level.
6. Check the RED focus of the whole screen and if necessary
repeat steps 4 and 5.
7. Fix the RED lens by tightening its fixing screws.
8. Expose only GREEN by covering the RED and BLUE
lenses with caps.
9. Display the internally-generated cross-hatch signal.
10. Adjust the GREEN lens focus on the left border of the
screen to its sharpest level, then check the focus on the
right border, and if it is at its sharpest level, fix it in that
position by tightening the lens screws.
PREPARATION
Operate the receiver for at least 5 minutes.
R, G, B CUTOFF (SCREEN VR) ADJUSTMENT
1. Adjust before replace the screen assembly.
2. Set user control to reset position.
CONTRAST → Max
(
BRIGHTNESS, COLOR, TINT → Center.
3. Call up the adjustment mode display, then select the
item RCUT.
4. Adjust the data of items RCUT, GCUT, and BCUT to
"40H".
5. Press the
6. Gradually rotate R, G and B screen volume of FOCUS
PAC clockwise or counterclockwise until the raster
appears slightly on the CRT through the each lens, and
leave them.
(Lookin to the lens in order to check the raster.)
7. Press the
Picture)
button on Remote. (Y-MUTE : ON)
button on Remote. (Return to Normal
(1) If the horizontal line toward the right border is red-
flared, turn the lens screw slightly right in order to
balance it with the left border. (After adjustment, the
left border tends to be slightly green-flared, and the
right border tends to be slightly red-flared.)
(2) If the horizontal line toward the right border is green-
)
Note: The aim of the above-described adjustment procedure
– 6 –
flared, turn the lens screw slightly left in order to
balance it with the left border. (After adjustment, the
left border tends to be slightly red-flared, and the
right border tends to be slightly green-flared.)
for the Green lens focus is to obtain the best lens focus
after 2 - 3 hours of warming up taking into account the
focus drift; it applies if the warming up time before the
adjustment is less than 30 minutes. (The horizontal line
in the screen middle section tends to be slightly redflared.)
Page 7
In case of warming up of more than 2 hours under a condition
that the large anode current is running through the projection
tube so that for example the all-white pattern appears, adjust
to obtain the sharpest focus while observing the whole screen
like in the RED case.
11. Press a button on the remote controller in order to display
the internally-generated black cross-hatch. (See TEST
SIGNAL SELECTION on page 11.)
12. Use the focus VR of “G” of the focus pack in order to ad-
just the electric focus in the middle section of the screen
to its sharpest level.
Note: Keep in mind that only the BLUE electric focus is ad-
justed with the black cross-hatch.
20. Check the BLUE focus of the whole screen and if necessary repeat steps 17 and 19.
21. Fix the BLUE lens by tightening its fixing screws.
TILT ADJUSTMENT
Rotate R, G, B deflection yoke so that picture becomes horizon, then fasten screw.
CENTERING ADJUSTMENT
1. Stretch a thread between two center of screen edge (top
and bottom, left and right).
GENERAL ADJUSTMENTS
Note: Normally the most clearly visible point of the scanning
line is the sharpest point of the Green focus, however as
the characteristics vary depending on the projection tube,
the sharpest focus points of the vertical and horizontal
lines may not match each other, thus when you turn the
focus VR, if the picture tends to be tremendously unstable
(rolls horizontally or vertically), adjust the balance of the
vertical and horizontal lines to its best position.
13. Check the GREEN focus of the whole screen and if
necessary repeat steps 10 and 11.
14. Fix the GREEN lens by tightening up its fixing screws.
15. Expose only BLUE by covering the RED and GREEN
lenses with caps.
16. Press a button on the remote controller in order to display
the internally-generated cross-hatch (See TEST SIGNAL
SELECTION on page 11.)
17. Loosen the BLUE lens fixing screws (refer to Fig. a), and
adjust the BLUE lens focus while observing the middle
and peripheral screen sections.
18. Press a button on the remote controller in order to display
the internally-generated black cross-hatch (See TEST SIGNAL SELECTION on page 11.)
19. Use the focus VR of “B” of the focus pack in order to adjust
the focus in the middle section of the screen to its sharpest
level.
(The point of the Blue focus becomes sharpest when the
brightness level of BLUE is lowest, the cross-hatch is
clearly visible.)
2. Select the adjustment mode. (See page 10.)
3. Press a button on the Remote Control to display the black
cross-hatch.
4. Adjust G centering magnet so that the cross-hatch pattern center comes to screen center.
5. Perform HEIGHT adjustment . (See page 14.)
6. Perform WIDTH adjustment. (See page 14.)
7. Check whole quality of green line.
8. Adjust R, B centering magnet so that the cross-hatch pattern center comes to screen center.
SPECIFIC INFORMATIONS
– 7 –
Page 8
LOCATION OF SCREEN AND FOCUS VR'S
To remove the Speaker grille and Front panel.
GENERAL ADJUSTMENTS
SPECIFIC INFORMATIONS
REPLACEMENT OF HIGH VOLTAGE CABLE
ANODE LEAD
RUBBER BOOT
LEAD HOLDER
Speaker grille
B
1. When replacing Anode Lead or Anode Cap with new
one, remove Lead Holder from old lead as shown in
figure below, and put it on new lead. Do not throw away
Lead Holder.
NOTE : THE LEAD HOLDER IS ATTACHED TO
TPA5007 (Z450), BUT IS NOT ATTACHED TO
ANODE LEAD AND ANODE CAP. RUBBER
BOOT IS ATTACHED TO ANODE LEAD AND
ANODE CAP.
RG
FOCUS VR's
SCREEN VR's
Fig. a
Z450 TPA5007
– 8 –
2. Detaching Lead Holder
LOCK
LEAD HOLDER
RUBBER BOOT
Fig. b
OLD
ANODE LEAD
or
ANODE CAP
Cut here rubber boot
and lead together to
detach Lead Holder.
Page 9
WARNING: BEFORE SERVICING THIS CHASSIS, READ THE "X-RAY RADIATION PRECAUTION", "SAFETY PRE-
CAUTION" AND "PRODUCT SAFETY NOTICE" ON PAGE 3 OF THIS MANUAL.
SERVICE POSITION
In order to assure the performance, processed wires shall be replaced after the repair work.
Work procedures are as follows:
1. Remove the back board.
2. Remove lead wires.
3. Draw out the chassis.
4. Rest the chassis against the back cabinet, chassis as shown bellow.
After repair work finished, replace it in the opposite procedure.
GENERAL ADJUSTMENTS
SPECIFIC INFORMATIONS
– 9 –
Page 10
1. ENTERING TO SERVICE MODE
1) Press o button once on
Remote Control.
SERVICE MODE
2) Press o button again to
keep pressing.
3) While pressing the o button,
press MENU button on TV set.
or Sound Mute
GENERAL ADJUSTMENTS
2. DISPLAYING THE ADJUSTMENT MENU
1)Press MENU button on TV.
Service mode
3. KEY FUNCTION IN THE SERVICE MODE
The following key entry during display of adjustment menu provides special functions.
SPECIFIC INFORMATIONS
Screen adjustment mode ON/OFF:-/-- () button (on Remote)
Test signal selection :a button (on Remote)
Selection of the adjustment items :Channel s/t (on TV or Remote)
Change of the data value :Volume ; +/– (on TV or Remote)
Adjustment menu mode ON/OFF :MENU button (on TV)
Initialization of the memory (QA02) :CALL + Channel button on TV (s)
Reset the count of operating protect
Color thickness correction
note: Displayed differently as shown below, de-
pending on the setting of the receiving color
system.
COLP (PAL)
COLC (NTSC)
COLS (SECAM)
CAUTION : Never try to perform initialization unless you have changed the memory IC.
– 10 –
Page 11
4. SELECTING THE ADJUSTING ITEMS
1) Every pressing of CHANNEL s button in the service mode changes the adjustment items in the order of table-2.
(t button for reverse order)
Refer to table-2 for preset data of adjustment mode.
(See SETTING & ADJUSTING DATA on page 32)
5. ADJUSTING THE DATA
1) Pressing of VOLUME ; +/– button will change the value of data in the range from 00H to FFH. The variable
range depends on the adjusting item.
6. EXIT FROM SERVICE MODE
1) Pressing POWER button to turn off the TV once.
■ INITIALIZATION OF MEMORY DATA OF QA02
After replacing QA02, the following initialization is required.
1. Enter the service mode, then select any register item.
2. Press and hold the CALL button on the Remote, then press the CHANNEL s button on the TV. The initialization of QA02 has
been complated.
3. Check the picture carefully. If necessary, adjust any adjustment item above.
Perform “Auto search Memory” on the owner’s manual.
CAUTION: Never attempt to initialize the data unless QA02 has been replaced.
7. TEST SIGNAL SELECTION
1) Every pressing of a button on the Remote Control changes the built-in test patterns on screen as described below
in SERVICE MODE.
Signal off
NTSC signals (5 patterns)
PAL signals (5 patterns)
SignalsPicture
• Red raster
• Green raster
• Blue raster
• All White
• Black cross-hatch
GENERAL ADJUSTMENTS
SPECIFIC INFORMATIONS
The signals marked with are not usable to display in the Test signal for some model.
*
– 11 –
Page 12
8. SELF DIAGNOSTIC FUNCTION
1) Press “9” button on Remote Control during display of adjustment menu in the service mode.
The diagnosis will begin to check if interface among IC’s are executed properly.
2) During diagnosis, the following displays are shown.
Indicated color of mode now selected : Green and Red
<SELF CHECK>
2300****
TIME : 000000
POWER : 00
BUS CONT : OK
BLOCK : UV V1 V2 V3 V4
Indicated color of other modes: Black
Green : Normal
Red : The microcomputer operates to provide judgement
of no video signal. The red color is still indicated
though the signal is input, failure may exist in input
signal line including QV01.
GENERAL ADJUSTMENTS
Part number of microcomputer (QA01)
Total hour of turn the TV on. (Unit: H)
Operation number of protecting circuit ----“00” is nor-
mal.
When indication is other than “00”, overcurrent apts to
flow, and circuit parts may possibly be damaged.
BUS CONT ----“OK” is normal.
When indication shows “Q uuu NG”, the device with
SPECIFIC INFORMATIONS
the number may possibly be damaged.
BLOCK
UV : TV reception mode
V1 : VIDEO 1 input mode (a1)
V2 : VIDEO 2 input mode (a2)
V3 : VIDEO 3 input mode
V4 : VIDEO 4 input mode
The items marked with are not usable to display in the SELF DIAGNOSTIC FUCTION for some model.
*
NOTE: (1) In case that "on timer" indicator is blinking with
interval of 0.5 seconds; it means protecting
circuit (Current limiter) is operating, and circuit components may possibly be damaged.
Check related components.
(2) In case that "on timer" indicator is blinking with
interval of 1 second; Protecting circuit does
not operate, but a part of Bus line does not
operate normally. Check Bus line.
– 12 –
Page 13
1. ENTERING TO DESIGN MODE
1) Select the Service mode.
DESIGN MODE
2) While pressing CALL button on Remote
and press MENU button on TV.
3) Press MENU button on TV.
SD
(Design mode)(Adjustment mode)
When QA02 is initialized, items “OPT0”, “OPT1” and "OPT2" of DESIGN MODE are set to the data of the representative model
of this chassis family.
Therefore, because ON-SCREEN specification remains in the state of the representative of model. This model is required to
reset the data of items “OPT0”, “OPT1” and "OPT2".
2. SELECTING THE ADJUSTING ITEMS
Every pressing of CHANNEL t button in the design mode changes the adjustment items in the order of table-3.
(s button for reverse order)
Refer to table-3 for data of design mode.
(See SETTING & ADJUSTING DATA on page 32)
3. ADJUSTING THE DATA
Pressing of VOLUME s or t button will change the value of data.
Press
Press
ITEM
DATA
GENERAL ADJUSTMENTS
SPECIFIC INFORMATIONS
– 13 –
Page 14
ELECTRICAL ADJUSTMENT
ITEMADJUSTMENT PROCEDURE
WIDTH
(WID)
(Picture size wide)
HEIGHT
(HIT)
GENERAL ADJUSTMENTS
(Picture size wide)
WHITE BALANCE
(RCUT)
(GCUT)
(BCUT)
(RDRV)
(BDRV)
SPECIFIC INFORMATIONS
1. Call up the adjustment mode display, then select the item WID.
2. Press the VOLUME t button to get the picture so the left
or right edges of raster begins to lack.
3. Press the VOLUME s button to advance the data by 11
steps.
Note : Check the horizontal picture position is correct.
1. Call up the adjustment mode display, then select the item HIT.
2. Press the VOLUME t button to get the picture so the top or bottom of
raster begins to lack.
3. Press the VOLUME s button to advance the data by 9 steps.
Note : Check the vertical picture position is correct.
Black and White pattern
High light area
Adjust "RDRV" or "BDRV" to be white.
Low light area
Fine adjust "RCUT", "GCUT" or "BCUT" to be black.
1. Set user control to reset position.
CONTRAST → Max
(
BRIGHTNESS, COLOR, TINT → Center.
2. Call up the adjustment mode display, then select the item RCUT.
3. Adjust the data of items RCUT, GCUT, and BCUT to "40H".
4. Press the -/-- () button on Remote. (Y-MUTE : ON)
5. Gradually rotate R, G and B screen volume of FOCUS PAC clockwise or counterclockwise until the raster appears slightly on the CRT through the each lens,
and leave them.
(Lookin to the lens in order to check the raster.)
6. Press the -/-- (
7. Press the a button on Remote, and select the Black and White pattern.
8. Adjust the data of items RCUT, GCUT and BCUT for proper white-balanced
picture in low light area.
9. Adjust the data of items RDRV and BDRV for proper white-balanced picture in
high light area.
10. Check the white balance in both low and high light areas.
If necessary, perform again steps from 8 to 9.
) button on Remote. (Return to Normal Picture)
)
– 14 –
Page 15
C01P: Series (Reference factory adjustment)
TP-V
TP-G
Adjusting
standards
For details,
refer to [focus
adjusting
method]
introduced in
the next page.
8750k-0.002uv
8750k-0.002uv
).
2
)
2
Digital
voltmeter
GENERAL ADJUSTMENTS
(PAL-I signal)SIGNAL unitwhite peak
Audio system: I
Wide mode
2) Adjust after adjusting W/B, SCNT
(Y mute, DRV.CUT=40H)
adjust the screen VR to the point that starts lighting
3) Directly observe the surface of Cathode Ray Tube and
4) Make above-mentioned adjustments for each tube of G, R,
and B.
Crosshatch2) Use the jig and shade the CRT except the axes under
.3) Make above-mentioned adjustments for each tube of G, R,
RDRVBright partScreen1) Adjust the color temperature of the bright part (103cd/m
BDRVW/Badjustment
RCUTDark part W/BScreen1) Adjust the color temperature of the dark part (17cd/m
MidpointDynamic mode Phillips PatternBetween TP-V1) Connect a digital voltmeter between TP-V10 ± 10mV
voltageWide modeand TP-Gand TP-G and adjust it to 10 ± 10mV by VCEN data
Voltage
measure-
BCUTadjustment
ment at
vertical
midpoint
Page 16
Adjustment itemsAdjusting methods
Focus adjustment
GENERAL ADJUSTMENTS
The items of G lens adjust-
SPECIFIC INFORMATIONS
ment mentioned in 4) are
applicable to 50PH, 61PH,
50W, and 57W, and regarding
the G lens adjustment for
43PH and 42W, apply the
methods mentioned in the
next page.
(Conditions)
- User adjustment: Dynamic mode, Cinema mode
- To be performed after centering magnet adjustment.
- Signal :Lens: R .... Retma Pattern (PAL)
G.... Crosshatch (PAL)
B .... Crosshatch (PAL)
Electrical focus :
R .... Retma Pattern (PAL)
G.... Crosshatch (PAL)
B .... RetmaPattern (PAL)
(Adjustment)
1. Common item
1) Make coarse adjustments in advance on the lens focus and electrical
focus of each R, G, and B tube.
2. G adjustment
1) Set to the G monochrome by lens cap.
2) Receive the image of crosshatch.
3) Adjust the G electric focus.
Adjust the G electrical focus by the focus volume of focus block (Z410)
so that the screen center will come to optimum focus. (Although the G
electrical focus is to be adjusted to allow the scanning lines in the center
of the screen to be seen most clealy, if G alignment and astigmatism are
inferior with the appearance of vertical and horizontal flares in the center
of and around the screen and if the lines become thicker, adjust to the
best point observing the entire screen.)
4) Adjust the G lens focus. (Details on43PH and 42W are mentioned in the
next page)
Keep an eye on the center of the crosshatch pattern and adjust so that
the screen center will become clear.
As a rough guide to decrease unevenness, adjust so that red flares on
both sides of the crosshatch line will come to 1mm in thickness.
5) Repeat 3, 4, and attempt to further improve the focus quality.
– 16 –
Page 17
Adjustment itemsAdjusting methods
Point to be noted during
G lens focus adjustment
(To be adjusted within
circles of 100mm diameter
contacting the left and
right of the bezel)
Focus adjustment
The method mentioned left is
applied to the focus adjustment
on the G lens adjustment of
43PH, 42W.The details of G
lens adjustment for 50PH,61PH,
50W, and 57W are described in
the previous page.
4) Adjust the G lens focus. (Applicable only to 43PH, 42W)
Watch the horizon of the left and right both ends of the screen (the range of
circle with 100mm diameter shown in the following sketch), make optimum
adjustments on the G lens focus, and check that the focus balance on the
right and left is satisfactory.
(Balance check of left-and-right G lens focus)
(1) Adjust the G lens focus best by crosshatch of the left end (or the right end).
(2) Check the focus of the right end (or the left end).
If the balance of the left and right lens focus (flare) is different, part it and
adjust to the medium quality.
Check the environment and confirm that the focus quality (including flare) is
within a tolerable range.
GENERAL ADJUSTMENTS
SPECIFIC INFORMATIONS
Concerning items 1), 2), 3), and 5) of G adjustment, these are common to the ones
on the previous page.
3. R adjustment
1) Set to the R monochrome by lens cap.
2) Receive the image of Retma pattern.
3) Adjust the R electrical focus.
Adjust by focus volume of the focus block (Z410) so that the screen center will
come to optimum focus.
4) Adjust the R lens focus.
Adjust so that the screen center will become the best.
5) Repeat 3, 4, and attempt to further improve the focus quality.
– 17 –
Page 18
Adjustment itemsAdjusting methods
Focus adjustment4. B adjustment
GENERAL ADJUSTMENTS
1) Set to the B monochrome by lens cap.
2) Receive the image of Retma pattern.
3) Adjust the B electrical focus.
Adjust by focus volume of the focus block (Z410) so that the screen center will
come to optimum focus (point where the brightness gets minimized)
4) Receive the image of crosshatch pattern.
5) Adjust the B lens focus.
Pay attention to the border of the blue line and the black (background) in the vicinity of the screen center.
First of all, make coarse adjustments of the lens, and move the lens adjusting
screw to the right at the point being considered as the best focus. Then, the lines
of the border become clear. Check and confirm under the circumstance that a
flare appears. On the contrary, if the lens adjusting screw is moved to the left from
the situation, the flare will disappear, and at this point you will find a point from
which the borderline itself begins to go out of focus. Adjust to the very point where
the focus begins to go out.
SPECIFIC INFORMATIONS
– 18 –
Page 19
Adjusting
standards
GENERAL ADJUSTMENTS
(Overlap the vertical center of the pattern with the centercome in
can overlap precisely.
This will be carried out individually for the tubes of R, G, and B.
NHITVerticalDynamic mode MonoscopeScreen1) Set the screen size to WIDE.
NVLIamplitudeWIDE modesignaladjustment2) The upper first one on the screen is to be hidden by the
NHITVerticalDynamic mode MonoscopeScreen1) Set the screen size to SUPERLIVE mode.
adjustmentmodeNTSC in contact with the screen end
NTSCLEADER-435B3) Do not adjust NVLI.
SUPERLIVE
amplitudeCINEMAsignalsadjustment2) Adjust so that the 30 characters on the up-and-down and
adjustmentmodeNTSCleft-and-right ends can come in contact with the screen end.
NTSCLEADER-435B
CINEMA
amplitudemodesignaladjustment2) Adjust so that the upper fifth one on the screen will come
adjustmentSUBTITLENTSCin contact with the screen end.
NHITVerticalDynamic mode MonoscopeScreen1) Set the screen size to CINEMA.
NHITVerticalDynamicMonoscopeScreen1) Set the screen size to SUBTITLE.
– 20 –
amplitudemodesignaladjustment2) Adjust the 25th left register mark to the left screen end.
adjustmentWIDENTSC
NTSCmodeLEADER-435B3) Do not adjust NVLI.
SUBTITLE
NWIDHorizontalDynamicMonoscopeScreen1) Set the screen size to WIDE.
NTSCmodeLEADER-435B
WIDE
Page 21
1. SCREEN ADJUSTMENT
CONVERGENCE ADJUSTMENT
The adjustment is carried out on four screens; 4 : 3 and 16 : 9
screens in both PAL and NTSC modes. When making the adjustments, feed an external signal to make an synchronization.
Note:
The convergence circuit is a circuit to eliminate screen distortion and can not make a drastic correction such as to correct
entire screen size. An excessive correction may actuate the
protection circuit. So a care will be necessary.
1-1. Entering the Adjustment Menu
7 key
CONVER ADJUST MENU
1 Adjust PAL wide
2 PAL Wide to Others
3 Adjust PAL S.Live
4 Adjust PAL Cinema
5 Adjust PAL S.title
6 PAL to NTSC(Wide)
7 PAL to NTSC(ALL)
8 Adjust NTSC Wide
9 NTSC Wide to Others
10 Adjust NTSC S. Live
11 Adjust NTSC Cinema
12 Adjust NTSC S.title
Before proceeding to the adjustment for each screen, always
perform the adjustments for vertical size (HIT) and horizontal
size (WID) with the main deflection data changed.
Order of the adjusting screens is PAL 4 : 3 → PAL 16 : 9 →
NTSC 4 : 3 → NTSC 16 : 9.
The menu order is 1~7 .... when the vertical sync is 50 Hz. (In
this case, item 8~12 are not displayed)
The menu order is 8~12 .... when the vertical sync is 60 Hz. (In
this case, item 1~7 are not displayed)
GENERAL ADJUSTMENTS
SPECIFIC INFORMATIONS
7 key
Fig. 1
– 21 –
Page 22
1-2. Remote Control Key
p
CALL
1
GENERAL ADJUSTMENTS
i
456
g
b
7
j
NexT View
MENU
SPECIFIC INFORMATIONS
DVD
MENU
n
NexT
-View
h
2
3
l
k
8
9
0
I
EXIT
a o key ............... Push this key twice and the set con-
sole menu key to enter the service
mode.
b 7 key ................. Push 7 key to enter and cancel the
convergence menu.
g 5 key ................. Cursor shift / data change mode
change-over.
h 2 key ................. Cursor up / adjusting point up.
i 4 key ................. Cursor left / adjusting point left
j 8 key ................. Cursor down / adjusting point down
k 6 key ................. Cursor right / adjusting point right
l 3 key ................. Cursor colour change (Adjusting
colour selection).
m S key ................ Execution key on convergence menu.
n s key ................ Up key on convergence menu.
o t key ................ Down key on convergence menu.
m
o
R
TV
VCR
DVD
G
C
Y
a
Fig. 2
– 22 –
Page 23
1-3. Adjusting Screen
1) Adjusting menu
NODescription
1Adjust PAL WideUsed for manual adjustment of the Wide/4:3 screen in the PAL mode.
2PAL Wide to othersAutomatically saves approximate supplementary data for the other PAL screens based
3Adjust PAL S.LiveUsed for manual adjustment of the PAL Super Live screen.
4Adjust PAL CinemaUsed for manual adjustment of the PAL Cinema screen.
5Adjust PAL S.titleUsed for manual adjustment of the PAL S.title screen.
Item
Returns to the original screen data screen before data conversion, explained below.
on the PAL Wide/4:3 screen data.
First, the PAL Wide/4:3 screen data are converted to Super Live and the values are
saved. Next, the data are converted to Cinema and the values are saved. Finally, the
data are converted to Subtitle and the values are saved, and then the operation ends.
Manually check the other screen modes as described below and make corrections if
distortion, etc., is present.
Please be aware that all PAL screens are re-adjusted when this menu is selected and
executed.
Select this mode for Super Live screen color matching and distortion adjustment.
Use the specified dimensions when adjusting.
Select this mode for Cinema screen color matching and distortion adjustment.
Use the specified dimensions when adjusting.
Select this mode for S.title screen color matching and distortion adjustment.
Use the specified dimensions when adjusting.
GENERAL ADJUSTMENTS
SPECIFIC INFORMATIONS
6PAL to NTSC (Wide)PAL Wide/4:3 screen data is calculated, converted to NTSC Wide/4:3 approximate
data and saved.
To assure accurate adjustments, select the manual mode explained below and check,
then apply color matching and distortion adjustments.
7PAL to NTSC (All)Data for all PAL screens is converted to approximate data for the NTSC screens and
saved.
To assure accurate adjustments, select the manual mode explained below and check,
then apply color matching and distortion adjustments.
8Adjust NTSC WideUsed for manual adjustment of the NTSC Wide/4:3 screen.
Select this mode for Wide/4:3 screen color matching and distortion adjustment.
Use the specified dimensions when adjusting.
9NTSC Wide to othersApproximate supplementary data for the other NTSC screens is automatically saved
based on the NTSC Wide/4:3 screen data.
First, the NTSC Wide/4:3 screen data are converted to Super Live and the values are
saved. Next, the data are converted to Cinema and the values are saved. Finally, the
data are converted to Subtitle and the values are saved, and then the operation ends.
Manually check the other screen modes as described below and make corrections if
distortion, etc., is present.
Please be aware that all NTSC screens are re-adjusted when this menu is selected
and executed.
– 23 –
Page 24
NODescription
10Adjust NTSC S.LiveUsed for manual adjustment of the NTSC Super Live screen.
11Adjust NTSC CinemaUsed for manual adjustment of the NTSC Cinema screen.
12Adjust NTSC S.titleUsed for manual adjustment of the NTSC Subtitle screen.
GENERAL ADJUSTMENTS
2) Adjustment Screen
SPECIFIC INFORMATIONS
Item
Select this mode for Super Live screen color matching and distortion adjustment.
Use the specified dimensions when adjusting.
Select this mode for Cinema screen color matching and distortion adjustment.
Use the specified dimensions when adjusting.
Select this mode for Subtitle screen color matching and distortion adjustment.
Use the specified dimensions when adjusting.
X : 1
Y : 1
C : R
S : 08
Wide
Displayed when the cursor blinks and cleared
when the cursor lights steady.
X Cursor horizontal position display
Displayed when the cursor blinks and
cleared when the cursor lights steady.
Displays the current screen mode.
Y Cursor vertical position display
C Cursor color select display
S Menu select display
3) Adjustment Sequence
When the initial screen opens, X = 1, Y = 1, C = R and S = [Select Menu] are displayed as the defaults. The cursor can
now be moved up, down, left and right using the (2), (8), (4) and (6) keys of the remote control. Select the desired
adjustment and press the (5) key; the cursor will light steady and the screen display will be cleared. Again press the (2),
(8), (4) and (6) keys of the remote control to adjust the shape of the screen. When adjustment has been completed, press
the (+) key to return to the Adjustment Menu. When all of the screen adjustments have been completed, turn off the main
power supply of the set to reset the menu.
– 24 –
Page 25
2. Case Study
In many cases, color matching problems can be solved by returning the HIT and WID data for main deflection to the
initial adjustment values. Convergence cannot be re-adjusted in the following cases.
2-1 When the CRT has been replaced
Main deflection re-adjustment and color matching are necessary when the CRT has been replaced. Use the following
procedure.
1. Replace the blue and red CRTs.
2. Perform the blue and red yoke horizontal adjustments in relation to the green CRT. Press the yokes and speed
modulation coils + alignments onto the CRTs and fasten after making sure that there are no gaps.
3. Adjust the blue and red alignments (refer to the detailed alignment adjustment item).
4. Use centering magnets to center the blue and red CRTs in relation to the green CRT.
5. Adjust the main deflection HIT and WID data, using the most accurate location in relation to the green as data.
6. Use convergence to match the colors for each screen. Green will not work at this time.
7. When the convergence adjustments have been completed for all screens, then replace the green CRT.
Repeat the procedures in steps 2 - 5 for the green CRT but this time use convergence to match the colors using red and
blue as reference.
2-2 When replacing the convergence unit
Generally, all of the screens must be re-adjusted when the convergence unit is replaced, but the process can be greatly
shortened by using the following method.
1. Replace the memory (Q711, Q712, Q713) of the new unit with the memory (Q711, Q712, Q713) of the defective unit.
This makes it possible to quickly reproduce the previous screen status when installed in the set.
2. Install the new unit with the old memory in the set and turn on the power. The entire screen will move linearly in either
the vertical or horizontal direction.
3. Use centering magnets to re-adjust the green, red and blue centers.
4. There is possibility of color mismatching or differences in screen size when the various screens are checked. In such
case, adjust the main deflection and apply a slight amount of convergence color matching.
2-3 When none of the above cases apply (rare case)
An unexpected situation or major operational error, etc., could be considered but it is recommended that all screens be
matched starting from the beginning. If the initial positions of the centering magnets are unknown, disconnect the
connectors for the convergence sub-yoke outputs one at a time, adjust the CRT centering and then start the following
adjustments.
1. Make sure that there is plenty of room for the static cross convergence to be moved left, right, up and down. If
sufficient space is not available, move to an appropriate location and then re-adjust the centering.
2. Enter the convergence adjustment mode and call out the menu. (Leave the PAL signal connected.)
3. Select 1. Adjust PAL Wide and adjust the PAL mode Wide/4:3 screen manually in accordance with the dimension
diagram.
4. When the Wide/4:3 screen adjustment has been completed, return to the Main Menu and select 2. PAL Wide to
others.
The screen will change automatically and the Wide, Cinema and Subtitle screens will be created automatically.
5. Next, select 3. Adjust PAL S.Live and mainly adjust in the horizontal direction in accordance with the dimension
diagram.
6. Next, select 4. Adjust PAL Cinema and fine adjust to remove any Cinema screen distortion.
7. Next, select 5. Adjust PAL Subtitle and fine adjust to remove any Subtitle screen distortion.
8. Next, select 7. PAL to NTSC (ALL), then calculate and copy the data for all PAL screens in the NTSC mode. At this
time, the calculations and screen shape changes will be performed automatically and the NTSC screen data
corresponding to the PAL screens will be transferred.
9. Select in sequence 8. Adjust NTSC Wide, 10. Adjust NTSC S.Live, 11. Adjust NTSC Cinema and 12. Adjust NTSC
Subtitle, check the respective NTSC screen modes and, if necessary, adjust for any distortion.
GENERAL ADJUSTMENTS
SPECIFIC INFORMATIONS
All of the screens can be adjusted with the above process but make every effort not to change the factory data unless
absolutely necessary. Try not to change the convergence data any more than necessary.
– 25 –
Page 26
3 Screen adjustment dimensions
3-1 WIDE/4:3 (PAL mode)
GENERAL ADJUSTMENTS
454.1
399.0
239.4
79.8
246.8
217.9
130.7
43.6
0
(screen center)
43.6
130.7
217.9
246.8
0
79.8
239.4
399.0
454.1
SPECIFIC INFORMATIONS
3-2 Super Wide (PAL mode)
449.4
390.6
229.4
76.1
261.5
231.0
137.0
42
0
(pattern center)
-5.3
52.0
143.3
232.1
261.5
0
76.1
229.4
390.6
449.4
Caution: Do not perform the VLIN adjustment.
– 26 –
Page 27
3-3 Cinema (PAL mode)
Note: The cursor will move outside the screen limits in the Cinema mode; therefore, be careful to consider the position
of the cursor displayed on the screen when making adjustments.
275.6
238.9
165.4
55.1
0
55.1
165.4
238.9
275.6
0
454.1
399.0
239.4
79.8
79.8
239.4
399.0
454.1
3-4 Subtitle (PAL mode)
Note: The cursor will move outside the screen limits in the Subtitle mode; therefore, be careful to consider the position
of the cursor displayed on the screen when making adjustments.
Note: Please be aware that the Subtitle screen convergence pattern center is located at the center of the screen but the
image center is located approximately 13mm above that.
285.6
252.0
GENERAL ADJUSTMENTS
SPECIFIC INFORMATIONS
Screen limit changed
454.1
399.0
239.4
79.8
0
– 27 –
79.8
239.4
399.0
151.2
50.4
0
50.4
151.2
252.0
285.6
454.1
Page 28
3-5 WIDE/4:3 (NTSC mode)
GENERAL ADJUSTMENTS
454.1
399.0
239.4
79.8
242.6
207.9
104.0
(screen center)
0
104.0
207.9
242.6
0
79.8
239.4
399.4
454.1
SPECIFIC INFORMATIONS
3-6 Super Live (NTSC mode)
Caution: Do not perform the VLIN adjustment.
449.4
390.6
229.4
76.1
261.5
223.7
110.3
0
(pattern center)
-5.3
117.6
226.8
261.5
0
76.1
229.4
390.6
449.4
– 28 –
Page 29
3-7 Cinema (NTSC mode)
Note: The cursor will move outside the screen limits in the Cinema mode; therefore, be careful to consider the position
of the cursor displayed on the screen when making adjustments.
Note: Please be aware that the Cinema screen convergence pattern center is located at the center of the screen but
the image center is located approximately 13mm above that.
301.4
258.3
129.2
0
129.2
258.3
301.4
GENERAL ADJUSTMENTS
0
454.1
399.0
239.4
79.8
79.8
239.4
399.0
454.1
3-8 Subtitle (NTSC mode)
Note: The cursor will move outside the screen limits in the Subtitle mode; therefore, be careful to consider the position
of the cursor displayed on the screen when making adjustments.
Note: Please be aware that the Subtitle screen convergence pattern center is located at the center of the screen but
the image center is located approximately 32mm above that.
279.3
239.4
119.7
0
119.7
239.4
279.3
SPECIFIC INFORMATIONS
454.1
399.0
239.4
79.8
0
79.8
239.4
399.0
454.1
– 29 –
Page 30
SCREEN AND MIRROR ALIGNMENTS
ASSEMBLING OF
FRONT SCREEN
GENERAL ADJUSTMENTS
FRONT
FRONT
SPECIFIC INFORMATIONS
Label with part
number
Lenticular
shield
Lenticular sheet
Fresnel sheet
Stick cotton
cloth tape
Label with part
number
MOUNTING OF
FRONT SCREEN
Fresnel sheet
5 CLIPS
3 CLIPS
5 CLIPS
3 CLIPS
2 screws
2 screws
CAUTION : Do not hold the optical system parts (lens and
mirror) with bare hand to avoid finger-prints on
the surface of those parts.
HOW TO CLEAN LENS AND MIRROR
1. Be sure to remove sand dust with an air brush, etc.
2. When it is stained slightly, breathe upon it and wipe away
with the specified cleaning cloth.
For other stains than the above, wipe the stains away
with the specified cloth into which a cleaning liquid has
been soaked.
42", 50"
HIGH VOLTAGE AT ZERO BEAM:(A)33.0 kV
MAX HIGH VOLTAGE:
AC VOLTAGE
Table-1
(B)34.5 kV
(C) 220~240 V
Item
RCUT
GCUT
BCUT
RDRV
BDRV
BRTC
COLP
SPECIFIC INFORMATIONS
COLS
SCNT
SRY
SBY
HPOS
DESIGN MODE
ADJUSTING ITEMS AND DATAS IN THE DESIGN MODE:
R CUTOFF (B/W)
G CUTOFF (B/W)
B CUTOFF (B/W)
R DRIVE
B DRIVE
SUB BRIGHT CEN
SUB COLOR CEN PAL
SUB COLOR CEN SECAM
SUB CONTRAST
SECAM R-Y
SECAM B-Y
50Hz H-POSITION
ItemName of adjustmentPreset Data42", 50"Remarks
OPT0OPTION 0B0HB0H
OPT1OPTION 17EH7EH
OPT2OPTION 2A0HA0H
OPT4OPTION 401H01H
Adjustment
Reference data
40H
40H
40H
40H
40H
80H
05H
08H
08H
07H
04H
0EH
Table-2
Item
VPOS
HIT
VLIN
VSC
VPS
WID
PARA
CNR
TRAP
VFC
VCEN
OPT3
WARNING: BEFORE SERVICING THIS CHASSIS, READ THE “X-RAY RADIATION PRECAUTION”, “SAFETY
PRECAUTION” AND “PRODUCT SAFETY NOTICE” ON PAGE 3 OF THIS MANUAL.
CAUTION: The international hazard symbols “” in the schematic diagram and the parts list designate com-
ponents which have special characteristics important for safety and should be replaced only with types identical to
those in the original circuit or specified in the parts list. The mounting position of replacements is to be identical with
originals. Before replacing any of these components, read carefully the PRODUCT SAFETY NOTICE . Do not
degrade the safety of the receiver through improper servicing.
NOTICE:
•
The part number must be used when ordering parts, in order to assist in processing, be sure to include the Model
number and Description.
•
The PC board assembly with * mark is no longer available after the end of the production.
Resistors ............... CF: Carbon FilmCC : Carbon CompositionMF: Metal Film
OMF : Oxide Metal FilmVR : Variable ResistorFR: Fusible Resistor
(All CD and PF capacitors are ±5%, 50V and all resistors, ±5%, 1/6W unless otherwise noted.)
Models : 42WH18P/50WH18P
LocationLocation
Location
LocationLocation
No.No.
No.
No.No.
Parts No.Parts No.
Parts No.
Parts No.Parts No.
DescriptionDescription
Description
DescriptionDescription
CAPACITORS
C10224793221ELECTROLYTIC CE04G 10V 220UF M
C10524109102CERAMIC CHIP CK73B 50V 1000PF K
C10624797100ELECTROLYTIC, 50V 10UF M
C10824793221ELECTROLYTIC CE04G 10V 220UF M
C10924109103CERAMIC CHIP CK73B 50V 10000PF K
C11524109103CERAMIC CHIP CK73B 50V 10000PF K
C16024567224PLASTIC FILM, 50V 0.22UF J
C17024567104PLASTIC FILM, 50V 0.1UF J
C20524797229ELECTROLYTIC, 50V 2.2UF M
C20624794100ELECTROLYTIC, 16V 10UF M
C21524105101CERAMIC CHIP, 50V CH 100PF J
C30124092730CERAMIC CHIP, 16V 0.1UF K
C30224092753CERAMIC CHIP CK73B 10V 220NF K
C30324503049MT PLA CAP 63V 0.47UF J
C30424092730CERAMIC CHIP, 16V 0.1UF K
C30524092730CERAMIC CHIP, 16V 0.1UF K
C30624105102CERAMIC CHIP CC73CH 25V 1000PF J
C30724567105PLASTIC FILM, 50V 1 UF J
C30824092733CERAMIC CHIP CK73B 50V 22000PF K
C30924105102CERAMIC CHIP CC73CH 25V 1000PF J
C31024669101ELECTROLYTIC, 50V 100UF M 3A
C31124109103CERAMIC CHIP CK73B 50V 10000PF K
C31224105102CERAMIC CHIP CC73CH 25V 1000PF J
C31324666101ELECTROLYTIC, 16V 100UF M 3A
C31424092730CERAMIC CHIP, 16V 0.1UF K
C31524666102ELECTROLYTIC, 16V 1000UF M 3A
C31624666102ELECTROLYTIC, 16V 1000UF M 3A
C31724109222CERAMIC CHIP CK73B 50V 2200PF K
C31824109222CERAMIC CHIP CK73B 50V 2200PF K
C31924503049MT PLA CAP 63V 0.47UF J
C32024669101ELECTROLYTIC, 50V 100UF M 3A
C32124669101ELECTROLYTIC, 50V 100UF M 3A
C32224109473CERAMIC CHIP CK73B 25V 47000PFK
C32324109473CERAMIC CHIP CK73B 25V 47000PFK
C32424669101ELECTROLYTIC, 50V 100UF M 3A
C32524503045MT PLA CAP 63V 0.22UF J
C32624092730CERAMIC CHIP, 16V 0.1UF K
C32724092753CERAMIC CHIP CK73B 10V 220NF K
LocationLocation
Location
LocationLocation
Parts No.Parts No.
Parts No.
Parts No.Parts No.
No.No.
No.
No.No.
C32824082260PLASTIC FILM, 100V 4700PF J
C32924669100ELECTROLYTIC, 50V 10UF M 3A
C33024085946ELEC. NONPOLAR CE04R 16V 10UF M
C33224669221ELECTROLYTIC CE04Q 50V 220UF M 3A
C33324693473PLASTIC FILM CQ921 M 100V 0.047MF J
C33424109471CERAMIC CHIP CK73B 50V 470PF K
C33524092730CERAMIC CHIP, 16V 0.1UF K
C33824666330ELECTROLYTIC, 16V 33UF M 3A
C33924667101ELECTROLYTIC, 25V 100UF M 3A
C34024666330ELECTROLYTIC, 16V 33UF M 3A
C37024669229ELECTROLYTIC, 50V 2.2UF M 3A
C37124092730CERAMIC CHIP, 16V 0.1UF K
C40124214332CERAMIC DISK, 500V 3300PF K
C40224214391CERAMIC DISC, 500V B 390PF K
C40324667220ELECTROLYTIC, 25V 22UF M 3A
C40524503042MT PLA CAP 63V 0.12UF J
C41224829823PLASTIC FILM, 400V 82000PF J
C41524092478CERAMIC DISK, 2KV 470PF K
C41624676220ELECTROLYTIC, 100V 22UF M 3A
C41724095716PLASTIC FILM, 250V 1.5UF K
C42324082756PLASTIC FILM CF92 T 400V R33UF J
C42324082649CF92T2G334J (50WH18P)
C42524082647PLASTIC FILM CF92 T 400V R27UF J
C42624211222CERAMIC DISC CK45B 2KV 2200PFK
C43224567333PLASTIC FILM, 50V 33000PF J
C44024082938PLASTIC FILM CF92 T 1500VH 2200PF H
C44324082946PLASTIC FILM, 1500VH 4700PF H
C44424082961PLASTIC FILM, 1500VH 8200PF H
C44524828473PLASTIC FILM, 200V 47000PF J
C44624679330ELECTROLYTIC, 250V 33UF M 3A
C44824640908ELECTROLYTIC, 160V 33UF M 3A LI
C44924214221CERAMIC DISK, 500V 220PF K
C46024679330ELECTROLYTIC, 250V 33UF M 3A
C46424095900PLASTIC FILM, 100V 3.3UF K
C46524109103CERAMIC CHIP CK73B 50V 10000PF K
C46624109103CERAMIC CHIP CK73B 50V 10000PF K
C46724820123PLASTIC FILM, 630V 0.012UF J
DescriptionDescription
Description
DescriptionDescription
NP 3A
(42WH18P)
SPECIFIC INFORMATIONS
– 41 –
Page 40
LocationLocation
Location
LocationLocation
SPECIFIC INFORMATIONS
Parts No.Parts No.
Parts No.
Parts No.Parts No.
No.No.
No.
No.No.
C46824820123PLASTIC FILM, 630V 0.012UF J
C47024095900PLASTIC FILM, 100V 3.3UF K
C48124666101ELECTROLYTIC, 16V 100UF M 3A
C48224092733CERAMIC CHIP CK73B 50V 22000PF K
C48324092733CERAMIC CHIP CK73B 50V 22000PF K
C48424109102CERAMIC CHIP CK73B 50V 1000PF K
C50124100104CERAMIC CHIP, 25V 100000PF Z
C50224100104CERAMIC CHIP, 25V 100000PF Z
C50324794470ELECTORLYTIC, 16V 47UF M
C50424109103CERAMIC CHIP CK73B 50V 10000PF K
C50524794470ELECTORLYTIC, 16V 47UF M
C50624109103CERAMIC CHIP CK73B 50V 10000PF K
C50724100104CERAMIC CHIP, 25V 100000PF Z
C50824100104CERAMIC CHIP, 25V 100000PF Z
C50924100104CERAMIC CHIP, 25V 100000PF Z
C51024763221ELECTROLYTIC, 16V 220UF M
C51124100104CERAMIC CHIP, 25V 100000PF Z
C51224100104CERAMIC CHIP, 25V 100000PF Z
C51324109103CERAMIC CHIP CK73B 50V 10000PF K
C51424762221ELECTROLYTIC, 10V 220UF M
C51624105110CERAMIC CHIP CC73CH 50V 11pF J
C51724206478ELECTROLYTIC, 50V 0.47UF M 7L 3A
C51824105101CERAMIC CHIP, 50V CH 100PF J
C51924797479ELECTROLYTIC, 50V 4.7UF M
C52024503047MT PLA CAP 63V 0.33UF J
C52124092733CERAMIC CHIP CK73B 50V 22000PF K
C52224109103CERAMIC CHIP CK73B 50V 10000PF K
C52324100104CERAMIC CHIP, 25V 100000PF Z
C52424109103CERAMIC CHIP CK73B 50V 10000PF K
C52524503041PLASTIC FILM , 63V 0.1UF J
C52624109103CERAMIC CHIP CK73B 50V 10000PF K
C52724797229ELECTROLYTIC, 50V 2.2UF M
C53024206010ELECTROLYTIC, 50V 1.0UF M 7L 3A
C53124100104CERAMIC CHIP, 25V 100000PF Z
C53224100104CERAMIC CHIP, 25V 100000PF Z
C53324100104CERAMIC CHIP, 25V 100000PF Z
C53424100104CERAMIC CHIP, 25V 100000PF Z
C53624100104CERAMIC CHIP, 25V 100000PF Z
C53724100104CERAMIC CHIP, 25V 100000PF Z
C54024100104CERAMIC CHIP, 25V 100000PF Z
C54124100104CERAMIC CHIP, 25V 100000PF Z
C54224100104CERAMIC CHIP, 25V 100000PF Z
C54324109103CERAMIC CHIP CK73B 50V 10000PF K
C54424109103CERAMIC CHIP CK73B 50V 10000PF K
C54524109103CERAMIC CHIP CK73B 50V 10000PF K
C54724109103CERAMIC CHIP CK73B 50V 10000PF K
C54824763101ELECTROLYTIC, 16V 100UF M
C56324206010ELECTROLYTIC, 50V 1.0UF M 7L 3A
C56424797229ELECTROLYTIC, 50V 2.2UF M
C57124100104CERAMIC CHIP, 25V 100000PF Z
C58124100104CERAMIC CHIP, 25V 100000PF Z
C58224100104CERAMIC CHIP, 25V 100000PF Z
C58324794470ELECTORLYTIC, 16V 47UF M
C58424100104CERAMIC CHIP, 25V 100000PF Z
C58524100104CERAMIC CHIP, 25V 100000PF Z
C59924794100ELECTROLYTIC, 16V 10UF M
C60124797229ELECTROLYTIC, 50V 2.2UF M
C60224797229ELECTROLYTIC, 50V 2.2UF M
C60324591102PLASTIC FILM, 50V 1000PF J
C60424591102PLASTIC FILM, 50V 1000PF J
C60524669100ELECTROLYTIC, 50V 10UF M 3A
C60624669100ELECTROLYTIC, 50V 10UF M 3A
C60724667470ELECTROLYTIC, 25V 47UF M 3A
C60824667470ELECTROLYTIC, 25V 47UF M 3A
C60924667470ELECTROLYTIC, 25V 47UF M 3A
DescriptionDescription
Description
DescriptionDescription
LocationLocation
Location
LocationLocation
Parts No.Parts No.
Parts No.
Parts No.Parts No.
No.No.
No.
No.No.
C61024669479ELECTROLYTIC, 50V 4.7UF M 3A
C61224669102ELECTROLYTIC CE04Q 50V 1000UF M 3A
C61324503042MT PLA CAP 63V 0.12UF J
C61424503042MT PLA CAP 63V 0.12UF J
C61524669102ELECTROLYTIC CE04Q 50V 1000UF M 3A
C61624669102ELECTROLYTIC CE04Q 50V 1000UF M 3A
C61724669220ELECTROLYTIC, 50V 22UF M 3A
C61824797478ELECTROLYTIC, 50V 0.47UF M
C61924794471ELECTROLYTIC, 16V 470UF M
C62124797220ELECTROLYTIC CE04G 50V 22UF M
C62224591103PLASTIC FILM, 50V 0.01MF J
C62424797100ELECTROLYTIC, 50V 10UF M
C62624797478ELECTROLYTIC, 50V 0.47UF M
C62724797220ELECTROLYTIC CE04G 50V 22UF M
C62824797100ELECTROLYTIC, 50V 10UF M
C62924503039MT PLA CAP 63V 0.068UF J
C63124797220ELECTROLYTIC CE04G 50V 22UF M
C63324795221ELECTROLYTIC, 25V 220UF M
C63424765101ELECTROLYITC CE04G 35V 100UF M
C63524797100ELECTROLYTIC, 50V 10UF M
C63624797100ELECTROLYTIC, 50V 10UF M
C63924793222ELECTROLYTIC CE04G 10V 2200UF M
C64124797479ELECTROLYTIC, 50V 4.7UF M
C64224797479ELECTROLYTIC, 50V 4.7UF M
C64324591102PLASTIC FILM, 50V 1000PF J
C64424591102PLASTIC FILM, 50V 1000PF J
C64524797010ELECTROLYTIC CE04G 50V 1.0UF M
C64624667470ELECTROLYTIC, 25V 47UF M 3A
C64724669100ELECTROLYTIC, 50V 10UF M 3A
C64824669100ELECTROLYTIC, 50V 10UF M 3A
C64924667470ELECTROLYTIC, 25V 47UF M 3A
C65024667470ELECTROLYTIC, 25V 47UF M 3A
C65124503042MT PLA CAP 63V 0.12UF J
C65224503042MT PLA CAP 63V 0.12UF J
C65324668102ELECTROLYTIC, 35V 1000UF M 3A
C65424668102ELECTROLYTIC, 35V 1000UF M 3A
C65524797479ELECTROLYTIC, 50V 4.7UF M
C65624591122PLASTIC FILM, 50V 1200PF J
C65724503040MT PLA CAP 63V 0.082UF J
C65824591102PLASTIC FILM, 50V 1000PF J
C65924797010ELECTROLYTIC CE04G 50V 1.0UF M
C66024667470ELECTROLYTIC, 25V 47UF M 3A
C66124669100ELECTROLYTIC, 50V 10UF M 3A
C66224669100ELECTROLYTIC, 50V 10UF M 3A
C66324667470ELECTROLYTIC, 25V 47UF M 3A
C66424667470ELECTROLYTIC, 25V 47UF M 3A
C66524503042MT PLA CAP 63V 0.12UF J
C66624503042MT PLA CAP 63V 0.12UF J
C66724668102ELECTROLYTIC, 35V 1000UF M 3A
C66824668102ELECTROLYTIC, 35V 1000UF M 3A
C66924668102ELECTROLYTIC, 35V 1000UF M 3A
C70124105471CERAMIC CHIP CC73CH 50V 470pF J
C70224591222PLASTIC FILM, 50V 2200PF J
C70324591822PLASTIC FILM, 50V 8200PF J
C70424105150CERAMIC CHIP, 50V CH 15PF J
C70524206479ELECTROLYTIC, 50V 4.7UF M 7L 3A
C70724797470ELECTROLYTIC, 50V 47UF M
C70824591272PLASTIC FILM, 50V 2700PF J
C71124105471CERAMIC CHIP CC73CH 50V 470pF J
C71224797470ELECTROLYTIC, 50V 47UF M
C71224591222PLASTIC FILM, 50V 2200PF J
C71324790470ELECTROLYTIC, 160V 47UF M
C71324591822PLASTIC FILM, 50V 8200PF J
C71424105150CERAMIC CHIP, 50V CH 15PF J
C71524214472CERAMIC DISK CK45 B 500V 4700PF K
DescriptionDescription
Description
DescriptionDescription
– 42 –
Page 41
LocationLocation
Location
LocationLocation
* C80124503055MT PLA AC275V 0.22UF M
* C80224503055MT PLA AC275V 0.22UF M
* C81124092555CERAMIC DISC CK45B AC250V 1000PF M
* C81224092555CERAMIC DISC CK45B AC250V 1000PF M
Parts No.Parts No.
Parts No.
Parts No.Parts No.
No.No.
No.
No.No.
C71724109103CERAMIC CHIP CK73B 50V 10000PF K
C71724214472CERAMIC DISK CK45 B 500V 4700PF K
C71824666470ELECTORLYTIC, 16V 47UF M 3A
C71824591272PLASTIC FILM, 50V 2700PF J
C71924435560CERAMIC DISC, 500V SL 56PF J
C72024790100ELECTROLYTIC CE04G 160V 10UF M
C72124105471CERAMIC CHIP CC73CH 50V 470pF J
C72124666470ELECTORLYTIC, 16V 47UF M 3A
C72224591222PLASTIC FILM, 50V 2200PF J
C72324591822PLASTIC FILM, 50V 8200PF J
C72424105150CERAMIC CHIP, 50V CH 15PF J
C72624212102CERAMIC DISK CK45 B 50V 1000PF K
C72824591272PLASTIC FILM, 50V 2700PF J
C73124105471CERAMIC CHIP CC73CH 50V 470pF J
C73224591222PLASTIC FILM, 50V 2200PF J
C73324591822PLASTIC FILM, 50V 8200PF J
C73424105150CERAMIC CHIP, 50V CH 15PF J
C73724109103CERAMIC CHIP CK73B 50V 10000PF K
C73824591272PLASTIC FILM, 50V 2700PF J
C74124105471CERAMIC CHIP CC73CH 50V 470pF J
C74224591222PLASTIC FILM, 50V 2200PF J
C74324591822PLASTIC FILM, 50V 8200PF J
C74424105150CERAMIC CHIP, 50V CH 15PF J
C74824591272PLASTIC FILM, 50V 2700PF J
C75124105471CERAMIC CHIP CC73CH 50V 470pF J
C75224591222PLASTIC FILM, 50V 2200PF J
C75324591822PLASTIC FILM, 50V 8200PF J
C75424105150CERAMIC CHIP, 50V CH 15PF J
C75724109103CERAMIC CHIP CK73B 50V 10000PF K
C75824591272PLASTIC FILM, 50V 2700PF J
C76024797470ELECTROLYTIC, 50V 47UF M
C76124212102CERAMIC DISK CK45 B 50V 1000PF K
C76124667331ELECTROLYTIC, 25V 330UF M 3A
C76224797470ELECTROLYTIC, 50V 47UF M
C76524109103CERAMIC CHIP CK73B 50V 10000PF K
C76524214472CERAMIC DISK CK45 B 500V 4700PF K
C76624214472CERAMIC DISK CK45 B 500V 4700PF K
C76624669331ELECTROLYTIC, 50V 330UF M 3A
C76724790470ELECTROLYTIC, 160V 47UF M
C76724567104PLASTIC FILM, 50V 0.1UF J
C76824666470ELECTORLYTIC, 16V 47UF M 3A
C76824567104PLASTIC FILM, 50V 0.1UF J
C76924666470ELECTORLYTIC, 16V 47UF M 3A
C76924567104PLASTIC FILM, 50V 0.1UF J
C77024435560CERAMIC DISC, 500V SL 56PF J
C77124790100ELECTROLYTIC CE04G 160V 10UF M
C78024797470ELECTROLYTIC, 50V 47UF M
C78124212102CERAMIC DISK CK45 B 50V 1000PF K
C78224797470ELECTROLYTIC, 50V 47UF M
C78424214472CERAMIC DISK CK45 B 500V 4700PF K
C78624214472CERAMIC DISK CK45 B 500V 4700PF K
C78724790470ELECTROLYTIC, 160V 47UF M
C78824666470ELECTORLYTIC, 16V 47UF M 3A
C78924666470ELECTORLYTIC, 16V 47UF M 3A
C79024435560CERAMIC DISC, 500V SL 56PF J
C79124790100ELECTROLYTIC CE04G 160V 10UF M
C80524092281CERAMIC DISC CK45E AC 250V 4700PF
C80624092281CERAMIC DISC CK45E AC 250V 4700PF
C81024086935400V 560M35F 400V 560UF M 35F
C81724503041PLASTIC FILM , 63V 0.1UF J
C81824669010ELECTROLYTIC, 50V 1.0UF M 3A
DescriptionDescription
Description
DescriptionDescription
LocationLocation
Location
LocationLocation
Parts No.Parts No.
Parts No.
Parts No.Parts No.
No.No.
No.
No.No.
C81924073076ELECTROLYTIC, 35V 6800UF M 3A
C82024086072ELECROLYTIC CE692R 450V 100UF M 3D
C82124082926PLASTIC FILM, AC275V 0.1UF M
C82224092553CERAMIC DISC, AC250V B 470PF K
C82424095887PLASTIC FILM, 630V 11000PF H
C82524669331ELECTROLYTIC, 50V 330UF M 3A
C82724436221CERAMIC DISC CC45 SL 50V 220PF J
C82824503041PLASTIC FILM , 63V 0.1UF J
C82924214471CERAMIC DISK CK45 B 500V 470PF K
C83024503047MT PLA CAP 63V 0.33UF J
C83124666101ELECTROLYTIC, 16V 100UF M 3A
C83224503047MT PLA CAP 63V 0.33UF J
C83324666470ELECTORLYTIC, 16V 47UF M 3A
C83424503047MT PLA CAP 63V 0.33UF J
C83524665101ELECTROLYTIC, 10V 100UF M 3A
C83624503047MT PLA CAP 63V 0.33UF J
C83724665470ELECTROLYTIC, 10V 47UF M 3A
C84124503053MT PLA CAP 63V 1.0UF J
C84224666101ELECTROLYTIC, 16V 100UF M 3A
C84324503041PLASTIC FILM , 63V 0.1UF J
C84824666100ELECTROLYTIC, 10V 10UF M 3A
C84924666100ELECTROLYTIC, 10V 10UF M 3A
C85024667222ELECTROLYTIC, 25V 2200UF M 3A
C85124667102ELECTROLYTIC CE04Q 25V 1000UF M 3A
C85224667472ELECTROLYTIC, 25V 4700UF M 3A
C85324667472ELECTROLYTIC, 25V 4700UF M 3A
C85424669102ELECTROLYTIC CE04Q 50V 1000UF M 3A
C85524669331ELECTROLYTIC, 50V 330UF M 3A
C85624667102ELECTROLYTIC CE04Q 25V 1000UF M 3A
C86024214103CERAMIC DISC, 500V B 10000PF K
C86324503045MT PLA CAP 63V 0.22UF J
C86424092474CERAMIC DISC, 2KV B 220PF K
C86624503053MT PLA CAP 63V 1.0UF J
C86724591472PLASTIC FILM, 50V 4700PF J
C86824668101ELECTROLYTIC, 35V 100UF M 3A
C86924678229ELECTROLYTIC, 200V 2.2UF M 3A
C87024082890PLASTIC FILM CQ92 T 800V 82000PF J
C87124092481CERAMIC DISK, 2KV 820PF K
C87224092478CERAMIC DISK, 2KV 470PF K
C87324503045MT PLA CAP 63V 0.22UF J
C87424214102CERAMIC DISC, 500V B 1000PF K
C87624503049MT PLA CAP 63V 0.47UF J
C87724092480CERAMIC DISK, 2KV 680PF K
C88024503049MT PLA CAP 63V 0.47UF J
C88124092475CERAMIC DISC, 2KV B 270PF K
C88224092475CERAMIC DISC, 2KV B 270PF K
C88324666220ELECTROLYTIC, 16V 22UF M 3A
C88424086916ELECTROLYTIC CE692R 160V 330UF M 3D
C88524666100ELECTROLYTIC, 10V 10UF M 3A
C88624669229ELECTROLYTIC, 50V 2.2UF M 3A
C89024669222ELECTROLYTIC, 50V 2200UF M 3A
C89124082229PLASTIC FILM, 250V 0.1MF D
C89224678478ELECTROLYTIC, 200V 0.47UF M 3A
C89424667222ELECTROLYTIC, 25V 2200UF M 3A
C89524666332ELECTROLYTIC CE04Q 16V 3300UF M 3A
C89824092398CERAMIC DISC, 25V 0.1UF Z, 24092398A
C90124211102CERAMIC DISC, 2KV B 1000PF K
C90224794100ELECTROLYTIC, 16V 10UF M
C90424436561CERAMIC DISC CC45 SL 50V560PF J
C90724214101CERAMIC DISK, 500V B 100PF K
C90824436390CERAMIC DISC, 50V SL 39PFJ
C91124211102CERAMIC DISC, 2KV B 1000PF K
C91224794100ELECTROLYTIC, 16V 10UF M
C91424436471CERAMIC DISC, 50V SL 470PF J
DescriptionDescription
Description
DescriptionDescription
NI TOOITSU
SPECIFIC INFORMATIONS
– 43 –
Page 42
LocationLocation
Location
LocationLocation
SPECIFIC INFORMATIONS
Parts No.Parts No.
Parts No.
Parts No.Parts No.
No.No.
No.
No.No.
C91524679330ELECTROLYTIC, 250V 33UF M 3A
C91724214101CERAMIC DISK, 500V B 100PF K
C91824503041PLASTIC FILM , 63V 0.1UF J
C92124211102CERAMIC DISC, 2KV B 1000PF K
C92224794100ELECTROLYTIC, 16V 10UF M
C92324436561CERAMIC DISC CC45 SL 50V560PF J
C92624214101CERAMIC DISK, 500V B 100PF K
C92724503041PLASTIC FILM , 63V 0.1UF J
C92824794100ELECTROLYTIC, 16V 10UF M
C96124794100ELECTROLYTIC, 16V 10UF M
C96224794100ELECTROLYTIC, 16V 10UF M
C96324503041PLASTIC FILM , 63V 0.1UF J
C96424503041PLASTIC FILM , 63V 0.1UF J
C4401 24763221ELECTROLYTIC, 16V 220UF M
C4402 24109103CERAMIC CHIP CK73B 50V 10000PF K
C4403 24797010ELECTROLYTIC CE04G 50V 1.0UF M
C4404 24109103CERAMIC CHIP CK73B 50V 10000PF K
C4405 24100104CERAMIC CHIP, 25V 100000PF Z
C4406 24109103CERAMIC CHIP CK73B 50V 10000PF K
C4451 24763101ELECTROLYTIC, 16V 100UF M
C5020 24109103CERAMIC CHIP CK73B 50V 10000PF K
C5030 24763101ELECTROLYTIC, 16V 100UF M
C5080 24206010ELECTROLYTIC, 50V 1.0UF M 7L 3A
C5090 24763101ELECTROLYTIC, 16V 100UF M
C7702 24105101CERAMIC CHIP, 50V CH 100PF J
C7747 24667101ELECTROLYTIC, 25V 100UF M 3A
C7749 24567334PLASTIC FILM, 50V 0.33UF J
C7750 24667101ELECTROLYTIC, 25V 100UF M 3A
C7755 24667101ELECTROLYTIC, 25V 100UF M 3A
C7757 24567334PLASTIC FILM, 50V 0.33UF J
C7758 24667101ELECTROLYTIC, 25V 100UF M 3A
C7767 24667101ELECTROLYTIC, 25V 100UF M 3A
C7769 24109103CERAMIC CHIP CK73B 50V 10000PF K
C7774 24105331CERAMIC CHIP CC73CH 50V 330pF J
C7776 24667101ELECTROLYTIC, 25V 100UF M 3A
C7779 24669479ELECTROLYTIC, 50V 4.7UF M 3A
C7782 24669221ELECTROLYTIC CE04Q 50V 220UF M 3A
C7785 24667221ELECTROLYTIC, 25V 220UF M 3A
C7788 24669221ELECTROLYTIC CE04Q 50V 220UF M 3A
C7791 24667221ELECTROLYTIC, 25V 220UF M 3A
C7792 24109472CERAMIC CHIP, 50V B 4700PF K
C7793 24567104PLASTIC FILM, 50V 0.1UF J
C7794 24567104PLASTIC FILM, 50V 0.1UF J
C7795 24109472CERAMIC CHIP, 50V B 4700PF K
C7796 24666100ELECTROLYTIC, 10V 10UF M 3A
C7798 24109102CERAMIC CHIP CK73B 50V 1000PF K
C7810 24105471CERAMIC CHIP CC73CH 50V 470pF J
C7811 24105471CERAMIC CHIP CC73CH 50V 470pF J
C7812 24105331CERAMIC CHIP CC73CH 50V 330pF J
C7813 24669221ELECTROLYTIC CE04Q 50V 220UF M 3A
C7814 24669221ELECTROLYTIC CE04Q 50V 220UF M 3A
CA0324105180CERAMIC CHIP CC73CH 50V 18PF J
CA0424105180CERAMIC CHIP CC73CH 50V 18PF J
CA0924105101CERAMIC CHIP, 50V CH 100PF J
CA1024105101CERAMIC CHIP, 50V CH 100PF J
CA1224105101CERAMIC CHIP, 50V CH 100PF J
CA1524105101CERAMIC CHIP, 50V CH 100PF J
CA1624105101CERAMIC CHIP, 50V CH 100PF J
CA1724105101CERAMIC CHIP, 50V CH 100PF J
CA2024212101CERAMIC DISK, 50V B 100PF K
CA3324100103CERAMIC CHIP, 50V 10000PF Z
CA4224794101ELECTROLYTIC, 16V 100UF M
CA4324109103CERAMIC CHIP CK73B 50V 10000PF K
CA4524109103CERAMIC CHIP CK73B 50V 10000PF K
CA4624109103CERAMIC CHIP CK73B 50V 10000PF K
DescriptionDescription
Description
DescriptionDescription
LocationLocation
Location
LocationLocation
Parts No.Parts No.
Parts No.
Parts No.Parts No.
No.No.
No.
No.No.
CA5824794330ELECTROLYTIC CE04G 16V 33UF M
CA6724100103CERAMIC CHIP, 50V 10000PF Z
CA6824794100ELECTROLYTIC, 16V 10UF M
CA6924100103CERAMIC CHIP, 50V 10000PF Z
CA7024794100ELECTROLYTIC, 16V 10UF M
CA8024794470ELECTORLYTIC, 16V 47UF M
CA8124100104CERAMIC CHIP, 25V 100000PF Z
CA8324092538CERAMIC CHIP, 10V F 1UF Z
CB0124794470ELECTORLYTIC, 16V 47UF M
CB0424092538CERAMIC CHIP, 10V F 1UF Z
CB0524109222CERAMIC CHIP CK73B 50V 2200PF K
CB0624105561CERAMIC CHIP, 50V CH 560PF J
CB0724109332CERAMIC CHIP CK73B 50V 3300PF K
CB4024092538CERAMIC CHIP, 10V F 1UF Z
CB4124109222CERAMIC CHIP CK73B 50V 2200PF K
CB4224105561CERAMIC CHIP, 50V CH 560PF J
CB4324109332CERAMIC CHIP CK73B 50V 3300PF K
CB9024100103CERAMIC CHIP, 50V 10000PF Z
CC0124109103CERAMIC CHIP CK73B 50V 10000PF K
CC0124100103CERAMIC CHIP, 50V 10000PF Z
CC0224100103CERAMIC CHIP, 50V 10000PF Z
CC0324100103CERAMIC CHIP, 50V 10000PF Z
CC0424100103CERAMIC CHIP, 50V 10000PF Z
CC0424105220CERAMIC CHIP, 50V CH 22PF J
CC0524109102CERAMIC CHIP CK73B 50V 1000PF K
CC0524105101CERAMIC CHIP, 50V CH 100PF J
CC0624109102CERAMIC CHIP CK73B 50V 1000PF K
CC0624105101CERAMIC CHIP, 50V CH 100PF J
CC0724105101CERAMIC CHIP, 50V CH 100PF J
CC0824109103CERAMIC CHIP CK73B 50V 10000PF K
CC0924105470CERAMIC CHIP, 50V CH 47PF J
CC1024105470CERAMIC CHIP, 50V CH 47PF J
CC1124105470CERAMIC CHIP, 50V CH 47PF J
CC1224109102CERAMIC CHIP CK73B 50V 1000PF K
CC1324109102CERAMIC CHIP CK73B 50V 1000PF K
CC1324100104CERAMIC CHIP, 25V 100000PF Z
CC1424100104CERAMIC CHIP, 25V 100000PF Z
CC1524100104CERAMIC CHIP, 25V 100000PF Z
CC1624109103CERAMIC CHIP CK73B 50V 10000PF K
CC2024105220CERAMIC CHIP, 50V CH 22PF J
CC2624109103CERAMIC CHIP CK73B 50V 10000PF K
CC2724109103CERAMIC CHIP CK73B 50V 10000PF K
CC3024100103CERAMIC CHIP, 50V 10000PF Z
CC3124109102CERAMIC CHIP CK73B 50V 1000PF K
CC3224100103CERAMIC CHIP, 50V 10000PF Z
CC3324105101CERAMIC CHIP, 50V CH 100PF J
CC4124105470CERAMIC CHIP, 50V CH 47PF J
CC4224105470CERAMIC CHIP, 50V CH 47PF J
CC4724212332CERAMIC DISC, 50V B 3300PF K
CC4824212332CERAMIC DISC, 50V B 3300PF K
CC6024109102CERAMIC CHIP CK73B 50V 1000PF K
CC6124109102CERAMIC CHIP CK73B 50V 1000PF K
CC6224109102CERAMIC CHIP CK73B 50V 1000PF K
CC6324109102CERAMIC CHIP CK73B 50V 1000PF K
CC6424109102CERAMIC CHIP CK73B 50V 1000PF K
CC6524109102CERAMIC CHIP CK73B 50V 1000PF K
CC6624109102CERAMIC CHIP CK73B 50V 1000PF K
CC6724109102CERAMIC CHIP CK73B 50V 1000PF K
CC6824109102CERAMIC CHIP CK73B 50V 1000PF K
CC6924109102CERAMIC CHIP CK73B 50V 1000PF K
CC7024109102CERAMIC CHIP CK73B 50V 1000PF K
CC7124109102CERAMIC CHIP CK73B 50V 1000PF K
CC7224109102CERAMIC CHIP CK73B 50V 1000PF K
CC7324109102CERAMIC CHIP CK73B 50V 1000PF K
CC7424109102CERAMIC CHIP CK73B 50V 1000PF K
DescriptionDescription
Description
DescriptionDescription
– 44 –
Page 43
LocationLocation
Location
LocationLocation
Parts No.Parts No.
Parts No.
Parts No.Parts No.
No.No.
No.
No.No.
CC7524109102CERAMIC CHIP CK73B 50V 1000PF K
CC7624109102CERAMIC CHIP CK73B 50V 1000PF K
CC7724109102CERAMIC CHIP CK73B 50V 1000PF K
CC7824109102CERAMIC CHIP CK73B 50V 1000PF K
CC8224105151CERAMIC CHIP CC73CH 50V 150PF J
CD8124100104CERAMIC CHIP, 25V 100000PF Z
CD8224794100ELECTROLYTIC, 16V 10UF M
CD8324092733CERAMIC CHIP CK73B 50V 22000PF K
CD8424092733CERAMIC CHIP CK73B 50V 22000PF K
CD8524100104CERAMIC CHIP, 25V 100000PF Z
CD8624092733CERAMIC CHIP CK73B 50V 22000PF K
CD8724793221ELECTROLYTIC CE04G 10V 220UF M
CD8824109222CERAMIC CHIP CK73B 50V 2200PF K
CD8924794100ELECTROLYTIC, 16V 10UF M
CF0124793101ELECTROLYTIC, 10V 100UF M
CF0224100104CERAMIC CHIP, 25V 100000PF Z
CF0324100104CERAMIC CHIP, 25V 100000PF Z
CF0424100104CERAMIC CHIP, 25V 100000PF Z
CF0524100104CERAMIC CHIP, 25V 100000PF Z
CF0624793101ELECTROLYTIC, 10V 100UF M
CF0724100104CERAMIC CHIP, 25V 100000PF Z
CF0824794100ELECTROLYTIC, 16V 10UF M
CF0924109102CERAMIC CHIP CK73B 50V 1000PF K
CF1024794100ELECTROLYTIC, 16V 10UF M
CF1124109102CERAMIC CHIP CK73B 50V 1000PF K
CF1224100104CERAMIC CHIP, 25V 100000PF Z
CF1324100104CERAMIC CHIP, 25V 100000PF Z
CF1424100104CERAMIC CHIP, 25V 100000PF Z
CF1524100104CERAMIC CHIP, 25V 100000PF Z
CF1624793101ELECTROLYTIC, 10V 100UF M
CF1724100104CERAMIC CHIP, 25V 100000PF Z
CF1824794100ELECTROLYTIC, 16V 10UF M
CF1924109102CERAMIC CHIP CK73B 50V 1000PF K
CF2024105220CERAMIC CHIP, 50V CH 22PF J
CF2024105330CERAMIC CHIP, 50V CH 33PF J
CF2124105220CERAMIC CHIP, 50V CH 22PF J
CF2124105330CERAMIC CHIP, 50V CH 33PF J
CF2224100104CERAMIC CHIP, 25V 100000PF Z
CF2324100104CERAMIC CHIP, 25V 100000PF Z
CF2424100104CERAMIC CHIP, 25V 100000PF Z
CF2524794100ELECTROLYTIC, 16V 10UF M
CF2624109102CERAMIC CHIP CK73B 50V 1000PF K
CF2724100104CERAMIC CHIP, 25V 100000PF Z
CF2824100104CERAMIC CHIP, 25V 100000PF Z
CF2924100104CERAMIC CHIP, 25V 100000PF Z
CF3024100104CERAMIC CHIP, 25V 100000PF Z
CF3124100104CERAMIC CHIP, 25V 100000PF Z
CF3224794100ELECTROLYTIC, 16V 10UF M
CF3324105330CERAMIC CHIP, 50V CH 33PF J
CF3424092538CERAMIC CHIP, 10V F 1UF Z
CF3524105100CERAMIC CHIP CC73CH 50V 10PF D
CF3624105220CERAMIC CHIP, 50V CH 22PF J
CF3724105151CERAMIC CHIP CC73CH 50V 150PF J
CF3824794100ELECTROLYTIC, 16V 10UF M
CF3924109103CERAMIC CHIP CK73B 50V 10000PF K
CF4024100104CERAMIC CHIP, 25V 100000PF Z
CF4124100104CERAMIC CHIP, 25V 100000PF Z
CF4224100104CERAMIC CHIP, 25V 100000PF Z
CF4324100104CERAMIC CHIP, 25V 100000PF Z
CF4424100104CERAMIC CHIP, 25V 100000PF Z
CF4524100104CERAMIC CHIP, 25V 100000PF Z
CF4624100104CERAMIC CHIP, 25V 100000PF Z
CF4724100104CERAMIC CHIP, 25V 100000PF Z
CF4824100104CERAMIC CHIP, 25V 100000PF Z
CF4924100104CERAMIC CHIP, 25V 100000PF Z
DescriptionDescription
Description
DescriptionDescription
LocationLocation
Location
LocationLocation
Parts No.Parts No.
Parts No.
Parts No.Parts No.
No.No.
No.
No.No.
CF5024794100ELECTROLYTIC, 16V 10UF M
CF5124109102CERAMIC CHIP CK73B 50V 1000PF K
CF5224100104CERAMIC CHIP, 25V 100000PF Z
CF5524100104CERAMIC CHIP, 25V 100000PF Z
CF7124100104CERAMIC CHIP, 25V 100000PF Z
CG0124082926PLASTIC FILM, AC275V 0.1UF M
CG0524092553CERAMIC DISC, AC250V B 470PF K
CG0624073101ELECTROLYTIC CE04Q 400V 47UF M 3A
CG0724503049MT PLA CAP 63V 0.47UF J
CG0824214471CERAMIC DISK CK45 B 500V 470PF K
CG1024667331ELECTROLYTIC, 25V 330UF M 3A
CG1124667470ELECTROLYTIC, 25V 47UF M 3A
CG1224212681CERAMIC DISK CK45 B 50V 680PF K
CG1324092333CERAMIC DISC CK45R 2KV 100PF K
CG2024676470ELECTROLYTIC, 100V 47UF M 3A
CG2724666222ELECTROLYTIC, 16V 2200UF M 3A
CG3424666101ELECTROLYTIC, 16V 100UF M 3A
CG3524665470ELECTROLYTIC, 10V 47UF M 3A
CG6224214471CERAMIC DISK CK45 B 500V 470PF K
CG6524214471CERAMIC DISK CK45 B 500V 470PF K
CH001 24100104CERAMIC CHIP, 25V 100000PF Z
CH004 24100104CERAMIC CHIP, 25V 100000PF Z
CH005 24100104CERAMIC CHIP, 25V 100000PF Z
CH006 24100104CERAMIC CHIP, 25V 100000PF Z
CH007 24100104CERAMIC CHIP, 25V 100000PF Z
CH008 24100104CERAMIC CHIP, 25V 100000PF Z
CH009 24100104CERAMIC CHIP, 25V 100000PF Z
CH010 24092538CERAMIC CHIP, 10V F 1UF Z
CH011 24762221ELECTROLYTIC, 10V 220UF M
CH012 24763101ELECTROLYTIC, 16V 100UF M
CH013 24763101ELECTROLYTIC, 16V 100UF M
CH014 24108101CERAMIC CHIP, 50V SL 100PF J
CH015 24108330CERAMIC CHIP, 50V SL 33PF J
CH016 24108330CERAMIC CHIP, 50V SL 33PF J
CH017 24108330CERAMIC CHIP, 50V SL 33PF J
CH018 24108330CERAMIC CHIP, 50V SL 33PF J
CH019 24108330CERAMIC CHIP, 50V SL 33PF J
CH020 24108330CERAMIC CHIP, 50V SL 33PF J
CH040 24100104CERAMIC CHIP, 25V 100000PF Z
CH041 24108101CERAMIC CHIP, 50V SL 100PF J
CH042 24108101CERAMIC CHIP, 50V SL 100PF J
CH043 24108101CERAMIC CHIP, 50V SL 100PF J
CH044 24108101CERAMIC CHIP, 50V SL 100PF J
CH045 24108101CERAMIC CHIP, 50V SL 100PF J
CH046 24108101CERAMIC CHIP, 50V SL 100PF J
CH047 24108101CERAMIC CHIP, 50V SL 100PF J
CH048 24108101CERAMIC CHIP, 50V SL 100PF J
CH051 24100104CERAMIC CHIP, 25V 100000PF Z
CH052 24100104CERAMIC CHIP, 25V 100000PF Z
CH053 24105070CERAMIC CHIP CC73CH 50V 7PF D
CH061 24109103CERAMIC CHIP CK73B 50V 10000PF K
CH062 24092730CERAMIC CHIP, 16V 0.1UF K
CH063 24100104CERAMIC CHIP, 25V 100000PF Z
CH101 24105070CERAMIC CHIP CC73CH 50V 7PF D
CH102 24105070CERAMIC CHIP CC73CH 50V 7PF D
CH120 24100104CERAMIC CHIP, 25V 100000PF Z
CH121 24100104CERAMIC CHIP, 25V 100000PF Z
CH122 24100104CERAMIC CHIP, 25V 100000PF Z
CH123 24100104CERAMIC CHIP, 25V 100000PF Z
CH124 24100104CERAMIC CHIP, 25V 100000PF Z
CH125 24100104CERAMIC CHIP, 25V 100000PF Z
CH126 24100104CERAMIC CHIP, 25V 100000PF Z
CH127 24100104CERAMIC CHIP, 25V 100000PF Z
CH128 24108221CERAMIC CHIP, 50V SL 220PF J
CH129 24108221CERAMIC CHIP, 50V SL 220PF J
T80123211717COIL, LINE FILTER, TRF3164AM
T82123211661COIL, LINE FILTER, TRF3192
T82223211661COIL, LINE FILTER, TRF3192
T82423217438TRANSFORMER, CONVERTER TPW3431AR
TG0123217466TRANSFORMER, CONVERTER TPW3449AM
TG0223211661COIL, LINE FILTER, TRF3192
WARNING: BEFORE SERVICING THIS CHASSIS, READ THE "X-RAY RADIATION PRECAUTION", "SAFETY
PRECAUTION" AND "PRODUCT SAFETY NOTICE" ON THE MANUAL FOR THIS MODEL.
CAUTION: The international hazard symbols "*" in the schematic diagram and the parts list designate components
which have special characteristics important for safety and should be replaced only with types identical to those in the
original circuit or specified in the parts list. The mounting position of replacements is to be identical with originals.
Before replacing any of these components, read carefully the PRODUCT SAFETY NOTICE on the MANUAL for this
model. Do not degrade the safety of the receiver through improper servicing.
NOTE:
1. RESISTORResistance is shown in ohm [K = 1.000, M = 1.000.000]. All resistors are 1/6W and 5%
tolerance carbon resistor, unless otherwise noted as the following marks.
1/2R = Metal or Metal oxide of 1/2 watt1/2S = Carbon compsistion of 1/2 watt
1RF = Fuse resistor of 1 watt10W = Cement of 10 watt
K = ±10% G = ±2% F = ±1%
2. CAPACITOR Unless otherwise noted in schematic, all capacitor values less than 1 are expressed in
?F, and the values more than 1 in pF.
All capacitors are ceramic 50V, unless otherwise noted as the following marks.
Electolytic capacitorMylar capacitor
3. The parts indicated with " * " have special characteristics, and should be replaced with identical parts only.
4. Voltages read with DIGITAL MULTI-METER from point indicated to chassing ground, using a color bar signal with all
controls at normal, line voltage 220 volts.
5. Waveforms are taken receiving color bar signal with enough sensitivity.
6. Voltage reading shown are nominal values and may vary ±20% except H.V.
SCHEMATIC DIAGRAM STRUCTURE:
SIGNAL Circuit
MAIN POWER Circuit
DEF / CONVER Circuit(1/2) Circuit
