Toshiba 46RF350, 40RF350 User Manual

Download

Integrated High Definition

DRAFT2

LCD Television

HIGH-DEFINITION TELEVISION

40RF350U 46RF350U

For an overview of steps for setting up your new TV, see page 10.

Note: To display a High Definition picture, the TV must be receiving a High Definition signal (such as an over-the-air High Definition TV broadcast, a High Definition digital cable program, or a High Definition digital satellite program). For details, please contact your TV antenna installer, cable provider, or satellite provider.

Owner’s Record

The model number and serial number are on the back of your TV. Record these numbers in the spaces below. Refer to these numbers whenever you communicate with your Toshiba dealer about this TV.

Model number:

Serial number:

YC/M

VX1A00065000

Dear Customer,

Thank you for purchasing this Toshiba LCD TV. This manual will help you use the many exciting features of your new LCD TV. Before operating your LCD TV, please read this manual completely, and keep it nearby for future reference.

Child Safety

It Makes A Difference

Safety Precautions

WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

WARNING

RISK OF ELECTRIC SHOCK

DO NOT OPEN.

WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

WARNING

To prevent injury, this apparatus must be securely attached to the floor/wall in accordance with the installation instructions. See item 20 on page 3.

WARNING: If you decide to wall mount this television,

always use a UL Listed wall bracket appropriate for the size and weight of this television. The use of any wall bracket other than a UL Listed wall bracket appropriate for the size and weight of this television for wall mounting this television could result in serious bodily injury and/or property damage. See “Removing the Pedestal Stand” (- page 5).

NOTE TO CATV INSTALLERS

This is a reminder to call the CATV system installer’s attention to Article 820-40 of the U.S. NEC, which provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of cable entry as practical. For additional antenna grounding information, see items 27 and 28 on page 4.

Where Your TV Stands

Congratulations on your purchase! As you enjoy your new TV, keep these safety tips in mind:

The Issue

a If you are like most consumers, you have a TV in your

home. Many homes, in fact, have more than one TV.

a The home theater entertainment experience is a growing

trend, and larger TVs are popular purchases; however, they are not always supported on the proper TV stands.

Sometimes TVs are improperly secured or inappropriately

situated on dressers, bookcases, shelves, desks, audio speakers, chests, or carts. As a result, TVs may fall over,

causing unnecessary injury.

Toshiba Cares!

a The consumer electronics

industry is committed to

making home entertainment

enjoyable and safe.

The Consumer Electronics Association formed the Home Entertainment Support Safety Committee, comprised of TV and

consumer electronics

furniture manufacturers, to

advocate children’s safety and

educate consumers and their

families about television safety.

Tune Into Safety

a One size does NOT fit all! Use appropriate

furniture large enough to support the weight of your TV (and other electronic components).

a Use appropriate angle braces, straps, and anchors to

secure your furniture to the wall (but never screw anything directly into the TV).

a Carefully read and understand the other enclosed

instructions for proper use of this product.

a Do not allow children to climb on or play with furniture

and TVs.

a Avoid placing any item on top of your TV (such as a VCR,

remote control, or toy) that a curious child may reach for. Remember that children can become excited while watching

a program and can potentially push or pull a TV over.

a Share our safety message about this hidden hazard of

the home with your family and friends. Thank you!

2500 Wilson Blvd. Arlington, VA 22201 U.S.A. www.CE.org

CEA is the Sponsor, Producer and

Manager of the International CES

Important Safety Instructions

1) Read these instructions.

2) Keep these instructions.

3) Heed all warnings.

4) Follow all instructions.

5) Do not use this apparatus near water.

6) Clean only with dry cloth.

7) Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.

8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.

9) Do not defeat the safety purpose of

the polarized or grounding type plug. A polarized plug has two blades

with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.

10) Protect the power cord from being walked on or pinched, particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

11) Only use attachments/accessories specified by the

manufacturer.

12) Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use

caution when moving the cart/apparatus combination to avoid injury from tip-over.

13) Unplug this apparatus during lightning storms or

when unused for long periods of time.

14) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

Additional Safety Precautions

14a) CAUTION: If the TV is dropped and the cabinet or

enclosure surface has been damaged or the TV does not operate normally, take the following precautions:

• ALWAYS turn off the TV and unplug the power cord to

avoid possible electric shock or fire.

• NEVER allow your body to come in contact with any

broken glass or liquid from the damaged television. The LCD panel inside the TV contains glass and a toxic liquid. If the liquid comes in contact with your mouth or eyes, or your skin is cut by broken glass, rinse the affected area thoroughly with water and consult your doctor.

• ALWAYS contact a service technician to inspect the TV

any time it has been damaged or dropped.

Wide blade

15) CAUTION:

• To reduce the risk of electric shock, do not use the polarized plug with an extension cord, receptacle, or other outlet unless the blades can be inserted completely to prevent blade exposure.

• To prevent electric shock, match wide blade of plug to wide slot; fully insert.

16) WARNING: To prevent the spread of fire, keep candles or other open flames away from this product at all times.

Installation, Care, and Service

Installation

Follow these recommendations and precautions and heed all warnings when installing your TV:

17) Never modify this equipment. Changes or modifications may void: a) the warranty, and b) the user’s authority to operate this equipment under the rules of the Federal Communications Commission.

18) DANGER: RISK OF

SERIOUS PERSONAL INJURY, DEATH, OR EQUIPMENT DAMAGE!

Never place the TV on an unstable cart, stand, or table. The TV may fall, causing serious personal injury, death, or serious damage to the TV.

19) To avoid damage to this product, never place or store the TV in direct sunlight; hot, humid areas; or areas subject to excessive dust or vibration.

20) Always place the TV on the floor or a sturdy, level, stable surface that can support the weight of the unit. To secure the TV, use a sturdy tie from the hooks on the rear of the TV pedestal to a wall, pillar, or other immovable structure. Make sure the tie is tight, secure, and parallel to the floor.

Sturdy tie (as short as possible)

min.

Clip

TV side TV top

21) The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such as vases, shall be placed on the apparatus.

22) Never block or cover the slots or openings in the TV cabinet back, bottom, and sides. Never place the TV:

• on a bed, sofa, rug, or similar

surface;

• too close to drapes, curtains, or

walls; or

• in a confined space such as a

bookcase, built-in cabinet, or any other place with poor

ventilation. The slots and openings are provided to protect the TV from overheating and to help maintain reliable operation of the TV. Leave a space of at least 4 (four) inches around the TV.

Hooks

Clip

(continued)

23) Always place the back of the television at least four (4) inches away from any vertical surface (such as a wall) to allow proper ventilation.

24) Never allow anything to rest on or roll over the power cord, and never place the TV where the power cord is subject to wear or abuse.

25) Never overload wall outlets and extension cords.

26) Always operate this equipment from a 120 VAC, 60 Hz power source only.

27) Always make sure the antenna system is properly grounded to provide adequate protection against voltage surges and built-up static charges (see Section 810 of the National Electric Code).

Antenna lead-in wire

Antenna discharge unit

Ground clamp

Electric service equipment

(NEC Section 810-20)

Grounding conductors (NEC Section 810-21)

31)

WARNING:

RISK OF ELECTRIC SHOCK!

Never spill liquids or push objects of any kind into the TV cabinet slots.

32) While it is thundering, do not touch the connecting cables or apparatus.

33) For added protection of your TV from lightning and power surges, always unplug the power cord and disconnect the antenna from the TV if you leave the TV unattended or unused for long periods of time.

34) During normal use, the TV may make occasional snapping or popping sounds. This is normal, especially when the unit is being turned on or off. If these sounds become frequent or continuous, unplug the power cord and contact a Toshiba Authorized Service Center.

35)

WARNING: RISK OF SERIOUS PERSONAL INJURY OR EQUIPMENT DAMAGE!

Never strike the screen with a sharp or heavy object.

Power service grounding electrode system (NEC Art 250 Part-H)

28)

Ground clamps

DANGER: RISK OF SERIOUS

PERSONAL INJURY OR DEATH!

• Use extreme care to make sure you are never in a position where your body (or any item you are in contact with, such as a ladder or screwdriver) can accidentally touch overhead power lines. Never locate the antenna near overhead power lines or other electrical circuits.

• Never attempt to install any of the following during lightning activity: a) an antenna system; or b) cables, wires, or any home theater component connected to an antenna or phone system.

Care

For better performance and safer operation of your TOSHIBA TV, follow these recommendations and precautions:

29) If you use the TV in a room whose temperature is 32 ºF (0 ºC) or below, the picture brightness may vary until the LCD warms up. This is not a sign of malfunction.

30) Always unplug the TV before cleaning. Gently wipe the display panel surface (the TV screen) using a dry, soft cloth only (cotton, flannel, etc.). A hard cloth may damage the surface of the panel. Avoid contact with alcohol, thinner, benzene, acidic or alkaline solvent cleaners, abrasive cleaners, or chemical cloths, which may damage the surface. Never spray volatile compounds such as insecticide on the cabinet. Such products may damage or discolor the cabinet.

36) • The LCD screen of this product can be damaged by ultraviolet radiation from the sun. When selecting a location for the television, avoid locations where the screen may be exposed to direct sunlight, such as in front of a window.

• Never touch, press, or place anything on the LCD screen. These actions will damage the LCD screen. If you need to clean the LCD screen, follow the instructions in item 30 on this page.

Service

37)

RISK OF ELECTRIC SHOCK!

Never attempt to service the TV yourself. Opening and removing the covers may expose you to dangerous voltage or other hazards. Failure to follow this WARNING may result in death or serious injury. Refer all servicing not specified in this manual to a Toshiba Authorized Service Center.

38) If you have the TV serviced:

• Ask the service technician to use only replacement parts specified by the manufacturer.

• Upon completion of service, ask the service technician to perform routine safety checks to determine that the TV is in safe operating condition.

39) The cold cathode fluorescent lamp in the LCD panel contains a small amount of mercury.

When the TV reaches the end of its useful life, dispose of the used TV by the approved method for your area, or ask a qualified service technician to properly dispose of the TV.

Note: The lamp(s) inside this product contain mercury. Disposal may be regulated due to

environmental considerations. For disposal or recycling information, contact your local authorities or the Electronics Industries Alliance (www.eiae.org).

WARNING:

Choosing a location for your LCD TV

To Display your LCD TV on the included Pedestal Stand:

Observe the following safety precautions:

1) Read and Follow the pedestal assembly instructions included with the pedestal.

CAUTION: Before beginning pedestal assembly, carefully lay the front of the LCD Panel face down on a flat, cushioned surface such as a quilt or blanket. Leave the bottom of the unit protruding over the edge of the surface and assemble the pedestal as indicated below.

Note: Extreme care should always be used when attaching the pedestal stand to avoid damage to the LCD panel.

2) Place the TV on a sturdy, level surface that can support the weight of the TV.

3) Be sure to secure the TV to a wall, pillar, surface, or other immovable structure. To secure the TV in this manner, use the included strap located at the rear of the pedestal stand. (- item 20, page 3).

To Display your LCD TV using a Wall Bracket:

If you decide to wall mount your LCD TV, always use a ULlisted wall bracket appropriate for the size and weight of the LCD TV (- page 2) :

1) CAUTION: Two people are required for installation.

2) Unplug and remove any cables and/or other component connectors from the rear of the TV.

3) Follow the instructions provided with your wall bracket. Before proceeding, make sure the appropriate bracket(s) are attached to the wall and the back of the TV as described in the instructions provided with the wall bracket.

4) After attaching the appropriate bracket(s) to the wall and the back of the TV, remove the pedestal stand from the TV as described below.

Removing the Pedestal Stand

1) Carefully lay the front of the unit face down on a flat, cushioned surface such as a quilt or blanket. Leave the stand protruding over the edge of the surface.

Note: Extreme care should always be used when removing the pedestal stand to avoid damage to the LCD panel.

2) Remove the jack pack cover on the back of the TV to expose the pedestal stand screws. The jack pack cover can be removed without tools.

3) Remove the five screws shown in the diagram below. This will allow removal of the pedestal stand.

4) Once you have removed all five screws holding the pedestal stand in place, remove the pedestal stand from the TV by sliding the pedestal stand away from the TV.

Five screws

FCC Declaration of Conformity

Important notes about your LCD Compliance Statement (Part 15):

The Toshiba 40RF350U and 46RF350U Televisions comply with Part 15 of the FCC rules.

Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

The party responsible for compliance to these rules is: Toshiba America Consumer Products, L.L.C. 82 Totowa Rd. Wayne, NJ 07470. Ph: 1-800-631-3811

Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by removing and applying power to the equipment, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and the

receiver.

• Connect the equipment into an outlet on a circuit different

from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for

help.

Caution: Changes or modifications to this equipment not expressly approved by Toshiba could void the user’s authority to operate this equipment.

The following symptoms are technical limitations of LCD

Display technology and are not an indication of malfunction;

therefore, Toshiba is not responsible for perceived issues

resulting from these symptoms.

1) An afterimage (ghost) may appear on the screen if a fixed, nonmoving image is displayed for a long period of time. The afterimage is not permanent and will disappear in a short period of time.

2) The LCD panel contained in this TV is manufactured using an extremely high level of precision technology; however, there may be an occasional pixel (dot of light) that does not operate properly (does not light, remains constantly lit, etc.). This is a structural property of LCD technology, is not a sign of malfunction, and is not covered under your warranty. Such pixels are not visible when the picture is viewed from a normal viewing distance.

Note: Interactive video games that involve shooting a “gun” type of joystick at an on-screen target may not work with this TV.

Trademark Information

• WOW, SRS and l symbol are trademarks of SRS Labs, Inc.

WOW technology is incorporated under license from SRS Labs, Inc.

• Manufactured under license from Dolby Laboratories.

Dolby and the double-D symbol are registered trademarks of Dolby Laboratories.

• HDMI, the HDMI logo and High-Definition Multimedia Interface are

trademarks or registered trademarks of HDMI Licensing LLC.

Contents

Important Safety Instructions .......................................... 3

Installation, Care, and Service ........................................ 3

Chapter 1: Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Welcome to Toshiba . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Features of your new TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Overview of steps for installing, setting up, and using

your new TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

TV front and side panel controls and connections . . . . . . . . 11

TV back panel connections. . . . . . . . . . . . . . . . . . . . . . . . . . 12

Chapter 2: Connecting your TV . . . . . . . . . . . . . . . . . . . . . . .13

Overview of cable types . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

About the connection illustrations . . . . . . . . . . . . . . . . . . . . 13

Connecting a VCR and antenna or Cable TV

(no Cable box) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Connecting a VCR with S-video and a cable box . . . . . . . . 15

Connecting a DVD player with ColorStream

(component video), a VCR, and a satellite receiver. . . . 16

Connecting a device to the IR OUT infrared terminal

using the IR blaster cable for IR pass-through device

control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Connecting a camcorder . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Connecting an HDMI

™

or DVI device to the HDMI

input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

CE-Link connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Connecting a digital audio system . . . . . . . . . . . . . . . . . . . . 21

Connecting an audio system . . . . . . . . . . . . . . . . . . . . . . . . . 21

Connecting a personal computer (PC) . . . . . . . . . . . . . . . . . 22

Chapter 3: Using the remote control . . . . . . . . . . . . . . . . . . .23

Installing the remote control batteries . . . . . . . . . . . . . . . . . 23

Remote control effective range. . . . . . . . . . . . . . . . . . . . . . . 23

Learning about the remote control . . . . . . . . . . . . . . . . . . . . 24

Remote Control functional key chart . . . . . . . . . . . . . . . . . . 25

Using the remote control to operate your other devices . . . . 27

Programming the remote control to operate your other

devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Device code setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Searching and sampling the code of a device

(8500) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Using the volume lock feature (8000) . . . . . . . . . . . . . . 28

Operational feature reset (8900). . . . . . . . . . . . . . . . . . . 28

Multi-brand remote control device codes . . . . . . . . . . . . . . . 29

Chapter 4: Menu layout and navigation . . . . . . . . . . . . . . . . .36

Main menu layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Setup/Installation menu layout . . . . . . . . . . . . . . . . . . . . . . . 37

™

THINC

menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Navigating the menu system. . . . . . . . . . . . . . . . . . . . . . . . . 38

Chapter 5: Setting up your TV. . . . . . . . . . . . . . . . . . . . . . . .39

Selecting the menu language . . . . . . . . . . . . . . . . . . . . . . . . 39

Configuring the antenna input source for the ANT

terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Programming channels into the TV’s channel memory . . . . 40

Programming channels automatically . . . . . . . . . . . . . . 40

Manually adding and deleting channels in the channel

memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Setting the Auto Input feature. . . . . . . . . . . . . . . . . . . . . . . . 41

Labeling channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Setting the HDMI

™

audio mode . . . . . . . . . . . . . . . . . . . . . . 43

Viewing the digital signal meter. . . . . . . . . . . . . . . . . . . . . . 44

Viewing the system status. . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Selecting the Blue LED Illumination level. . . . . . . . . . . . . . 45

Selecting the Power-On Mode . . . . . . . . . . . . . . . . . . . . . . . 45

Chapter 6: Using the TV’s features . . . . . . . . . . . . . . . . . . . .46

Selecting the video input source to view . . . . . . . . . . . . . . . 46

Labeling the video input sources . . . . . . . . . . . . . . . . . . . . . 47

Tuning channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Tuning channels using the Channel Browser

™

. . . . . . . 48

Setting the Antenna Tuning Mode. . . . . . . . . . . . . . . . . 49

Tuning to the next programmed channel . . . . . . . . . . . . 50

Tuning to a specific channel (programmed or

unprogrammed) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Switching between two channels using Channel

Return . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Switching between two channels using SurfLock

Selecting the picture size . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

Scrolling the TheaterWide


™

. . . . 50

(TheaterWide 2 and 3 only) . . . . . . . . . . . . . . . . . . . . . . 53

Using the auto aspect ratio feature . . . . . . . . . . . . . . . . . . . . 53

Selecting the cinema mode

(480i and 1080i signals). . . . . . . . . . . . . . . . . . . . . . . . . 54

Using the FREEZE feature . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Adjusting the picture. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Selecting the picture mode. . . . . . . . . . . . . . . . . . . . . . . 54

Adjusting the picture quality . . . . . . . . . . . . . . . . . . . . . 55

Using the TheaterLock

™

feature. . . . . . . . . . . . . . . . . . . . . . 55

Using the closed caption mode. . . . . . . . . . . . . . . . . . . . . . . 56

Base closed captions . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

Digital CC Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

CC Selector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Using the Closed Caption button on the remote

control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Adjusting the audio. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Muting the sound . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Using the digital audio selector . . . . . . . . . . . . . . . . . . . 57

Selecting stereo/SAP broadcasts . . . . . . . . . . . . . . . . . . 58

Adjusting the audio quality . . . . . . . . . . . . . . . . . . . . . . 58

Using the StableSound

Selecting the optical audio output format . . . . . . . . . . . 59

Using the Dolby

feature. . . . . . . . . . . . . . . . . . . 59

Digital Dynamic Range Control

feature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Using the Locks menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

Entering the PIN code . . . . . . . . . . . . . . . . . . . . . . . . . . 60

If you cannot remember your PIN code. . . . . . . . . . . . . 60

Changing your PIN code . . . . . . . . . . . . . . . . . . . . . . . . 60

Blocking TV programs and movies by rating

(V-Chip) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Downloading an additional rating system for blocking

TV programs and movies . . . . . . . . . . . . . . . . . . . . 61

Blocking channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

Unlocking programs temporarily. . . . . . . . . . . . . . . . . . 63

Using the input lock feature. . . . . . . . . . . . . . . . . . . . . . 63

Using the GameTimer

. . . . . . . . . . . . . . . . . . . . . . . . . 64

Using the control panel lock feature . . . . . . . . . . . . . . . 64

Using the PC settings feature . . . . . . . . . . . . . . . . . . . . . . . . 65

Setting the PC Audio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

Setting the sleep timer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

Using CE-Link . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

CE-Link playback device (HD DVD player, etc.)

control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

CE-Link input source selection . . . . . . . . . . . . . . . . . . . 67

Audio Receiver VOLUME and MUTE control. . . . . . . 67

Other CE-Link functions . . . . . . . . . . . . . . . . . . . . . . . . 67

Using the HDMI settings feature . . . . . . . . . . . . . . . . . . . . . 68

Displaying TV status information. . . . . . . . . . . . . . . . . . . . . 69

Understanding the auto power off feature . . . . . . . . . . . . . . 69

Understanding the last mode memory feature . . . . . . . . . . . 69

(continued)

Chapter 7: Using the TV’s advanced features . . . . . . . . . . . . .70

Using the advanced picture settings features . . . . . . . . . . . . 70

Using dynamic contrast . . . . . . . . . . . . . . . . . . . . . . . . . 70

Using the static gamma feature . . . . . . . . . . . . . . . . . . . 70

Selecting the color temperature . . . . . . . . . . . . . . . . . . . 71

Using CableClear

Using MPEG noise reduction. . . . . . . . . . . . . . . . . . . . . 72

Using the ColorMaster

digital noise reduction . . . . . . . . . . 71

™

feature . . . . . . . . . . . . . . . . . . 72

Using the xvYCC Selection feature. . . . . . . . . . . . . . . . 73

Using the Game Mode feature . . . . . . . . . . . . . . . . . . . . 74

Using the advanced audio settings features . . . . . . . . . . . . . 74

Using the SRS WOW

™

surround sound feature . . . . . . 74

Chapter 8: Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . .75

General troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

LED indications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77

Chapter 9: Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .78

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78

Acceptable signal formats

for PC IN and HDMI terminals . . . . . . . . . . . . . . . . . . . 79

Limited United States Warranty

for LCD Televisions 26” and Larger . . . . . . . . . . . . . . . 80

Limited Canadian Warranty

for Toshiba Brand Flat Panel Televisions . . . . . . . . . . . 81

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .84

Chapter 1: Introduction

Welcome to Toshiba

Thank you for purchasing this Toshiba LCD TV, one of the most innovative LCD TVs on the market. This digital television is capable of receiving analog basic, digital basic and digital premium cable television programming by direct connection to a cable system providing such programming. A security card provided by your cable operator is required to view encrypted digital programming. Certain advanced and interactive digital cable services such as video-on-demand, a cable operator’s enhanced program guide and data-enhanced television services may require the use of a set-top box. For more information call your local cable operator.

Features of your new TV

The following are just a few of the many exciting features of your new Toshiba widescreen, integrated HD, LCD TV:

• Super narrow and piano black finish bezel.

• Integrated digital tuning (8VSB ATSC and QAM)

eliminates the need for a separate digital converter set-top box (in most cases).

• 1080p output resolution.

• Three HDMI

interfaces capable of supporting up to 1080p sources (- page 19).

• HDMI new capabilities

Lip-Sync Latency activates an audio/video display timing adjustment function that allows HDMI source devices to accurately perform synchronization automatically.

xvYCC expands the color range (limits) of HDMI signals, allowing input of wider color signals from HDMI sources.

• Two sets of ColorStream

video inputs (- page 16).

• SRS WOW

• Digital Audio Out optical audio connection with Dolby

Digital optical output format (- page 59).

• CableClear

(- page 71).

• PC IN (Analog RGB) computer terminal (- page 22).

• Channel Labeling allows you to put the Call Letters (e.g.

ABC, HBO, etc.) on the screen along with the station numbers, so you always know what you’re watching (- page 42).

• IR OUT infrared terminal using the IR blaster cable for IR

pass-through device control (- pages 13 and 17).

• ColorMaster

colors. The menu for this feature has a unique “black” design to enhance contrast while you’re adjusting the color (- page 72).

• CE-Link allows control of external devices from the TV via

HDMI connection (- page 66).

™

digital, high-definition multimedia

HD high-resolution component

™

audio technologies (- page 74).

digital picture noise reduction

™

allows you to adjust the TV’s standard

Chapter 1: Introduction

Overview of steps for installing, setting up, and using your new TV

Follow these steps to set up your TV and begin using its many exciting features.

1 Carefully read the important safety, installation, care, and

service information. Keep this manual for future reference.

2 Observe the following when choosing a location for the

TV:

• Read “Important notes about your LCD TV”

(- page 6).

• Place the TV on the floor or a sturdy, level, stable

surface that can support the weight of the unit. Secure the TV to a wall, pillar, or other immovable structure (- page 3).

• Place the TV in a location where light does not reflect

on the screen.

• Place the TV far enough from walls and other objects to

allow proper ventilation. Inadequate ventilation may cause overheating, which will damage the TV. THIS TYPE OF DAMAGE IS NOT COVERED UNDER THE TOSHIBA WARRANTY.

3 Do not plug in any power cords until AFTER you have

connected all cables and devices to your TV.

4 BEFORE connecting cables or devices to the TV, learn

the functions of the TV’s connections and controls (

- pages 11–12).

5 Connect your other electronic device(s) to the TV

(

- pages 13–22).

6 Install the batteries in the remote control (- page 23). 7 See “Learning about the remote control” (- page 24) for

an overview of the buttons on the remote control.

8 Program the remote control to operate your other

device(s) (

9 AFTER connecting all cables and devices, plug in the

power cords for your TV and other devices. The yellow LED will blink until the TV goes into standby mode. When the TV is in standby mode, press POWER on the TV control panel or remote control to turn on the TV. If the TV stops responding to the controls on the remote control or TV control panel and you cannot turn the TV off or on, press and hold the POWER button for 5 seconds to reset the TV.

- pages 27–35).

10 See “Menu layout and navigation” for a quick overview of

navigating the TV’s menu system (

- page 36).

11 Programming channels into the TV’s channel memory

(

- page 40).

12 For details on using the TV’s features, see Chapters 6

and 7.

13 For help, refer to the Troubleshooting Guide, Chapter 8. 14 For technical specifications and warranty information, see

Chapter 9.

15 Enjoy your new TV!

Chapter 1: Introduction

TV front and side panel controls and connections

TV front

1 Illumination — Power indicator

This slit will be illuminated by the blue LED back light. See “Selecting the Blue LED Illumination level” on page 45 for additional information.

2 Green and Yellow LEDs

Green = Power indicator (when the Illumination Off mode)

Yellow = Power-On Mode indicator (- “Selecting the Power-On Mode” on page 45)

See “LED indications” on page 77 for additional information.

3 Remote sensor — Point the remote control toward this

remote sensor (- “Remote control effective range” on page 23).

4 VIDEO-2 IN — The side panel A/V connections are

referred to as “VIDEO 2” and include standard A/V connections.

5 POWER — Press to turn the TV on and off.

If the TV stops responding to the controls on the remote control or TV control panel and you cannot turn off the TV, press and hold the POWER button on the TV control panel for 5 or more seconds to reset the TV.

6 ARROWS BbC c — When a menu is on-screen, these

buttons function as up/down/left/right menu navigation buttons.

Right side panel

Control panel

7 MENU (ENTER) — Press to access the menu system

(- pages 36–37). When a menu is on-screen, the MENU button on the TV’s control panel functions as the ENTER button.

8 EXIT — Press to instantly close an on-screen menu.

9 CHANNEL Bb — When no menu is on-screen, these

buttons change the channel (programmed channels only;

- page 40).

10 VOLUME C c — These buttons adjust the volume level.

11 INPUT — Repeatedly press to change the source you are

viewing (ANT, VIDEO 1, VIDEO 2, ColorStream HD1, ColorStream HD2, HDMI 1, HDMI 2, HDMI 3, PC) (- page 46).

Chapter 1: Introduction

TV back panel connections

For an explanation of cable types and connections, see pages 13–22.

TV back

4 52 3

Power cord

Cable Clamper

1 IR OUT — For controlling infrared remote-controlled

devices through the TV. You can connect up to two devices with an optical IR blaster cable (- page 13), and then control the devices using the TV’s IR pass-through features.

2 ColorStream

Two sets of ColorStream video inputs (with standard stereo audio inputs) for connecting devices with component video output, such as a Toshiba DVD player with ColorStream

Note: Component video cables carry only video information; separate audio cables are required for a complete connection.

3 VIDEO-1 IN — Standard (composite) video and standard

audio inputs plus optional S-video inputs for connecting devices with composite video or S-video output.

Note: Standard (composite) video and S-video cables carry only video information; separate audio cables are required for a complete connection.

4 Fixed Audio OUT — Analog audio outputs for

connecting an audio amplifier.

5 PC/HDMI-1 (AUDIO) IN — PC audio input terminals

are shared with HDMI-1 analog audio input terminals, and their use can be configured in the Audio Setup menu (- page 65).

HD-1 and ColorStream® HD-2 —

high-definition component

7 ANT — Antenna input that supports analog (NTSC) and

digital (ATSC) off-air antenna signals and analog and digital Cable TV (QAM) signals.

8 Digital Audio OUT — Optical audio output in Dolby

Digital or PCM (pulse-code modulation) format for connecting an external Dolby Digital decoder, amplifier, A/V receiver, or home theater system with optical audio input.

9 HDMI

™

IN — High-Definition Multimedia Interface

input receives digital audio and uncompressed digital video from an HDMI device or uncompressed digital video from a DVI device. Also see item 5. HDMI connection is necessary to receive 1080p signals.

10 Service port — For service use only. Used for updating

the television’s firmware.

HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC. Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are registered trademarks of Dolby Laboratories.

6 PC IN — For use when connecting a personal computer.

Chapter 2: Connecting your TV

Overview of cable types

Cables can be purchased from most stores that sell audio/video devices. Before purchasing any cables, be sure of connector types required by your devices and the length of each cable.

Coaxial (F-type) cable

Coaxial (F-type) cable is used for connecting your antenna, cable TV service, and/or cable converter box to the ANT input on your TV.

Standard A/V cables (red/white/yellow)

Standard A/V cables (composite video) usually come in sets of three, and are for use with video devices with analog audio and composite video output. These cables (and the related inputs on your TV) are typically color-coded according to use: yellow for video, red for stereo right audio, and white for stereo left (or mono) audio.

HDMI™ cable (with HDMI Logo “ ”)

HDMI (High-Definition Multimedia Interface) cable is for use with devices with an HDMI output. An HDMI cable delivers digital audio and video in its native format. This cable carries both video and audio information; therefore, separate audio cables are not required for a complete HDMI device connection (- page 19 and page 22).

Note: HDMI cable provides better picture performance than a standard (composite) video or S-video cable.

Dual-wand IR blaster cable

Dual-wand IR blaster cable is for use with video devices with IR (infrared) remote control. This cable can be used with the TV’s IR pass-through feature (- page 17).

To obtain IR blaster cable:

Visit www.ceaccessories.toshiba.com.

Optical audio cable

S-video cable

S-video cable is for use with video devices with S-video output. Separate audio cables are required for a complete connection.

Note: An S-video cable provides better picture performance than a composite video cable. If you connect an S-video cable, be sure to disconnect the standard (composite) video cable or the picture performance will be unacceptable.

Component video cables (red/green/blue)

Component video cables come in sets of three and are for use with video devices with component video output. (ColorStream cables are typically color-coded red, green, and blue. Separate audio cables are required for a complete connection.

Note: Component video cables provide better picture performance than a standard (composite) video or S-video cable.

is Toshiba’s brand of component video.) These

Optical audio cable is for connecting receivers with Dolby Digital or PCM (pulse-code modulation) optical audio input to the TV’s DIGITAL AUDIO OUT terminal (- page 21).

Analog RGB (15-pin) computer cable

Analog RGB (15-pin) computer cable is for connecting a PC to the TV’s PC IN terminal (- page 22).

About the connection illustrations

You can connect different types and brands of devices to your TV in several different configurations. The connection illustrations in this manual are representative of typical device connections only. The input/output terminals on your devices may differ from those illustrated herein. For details on connecting and using your specific devices, refer to each device’s owner’s manual.

Chapter 2: Connecting your TV

Connecting a VCR and antenna or Cable TV (no Cable box)

TV upper back panel

From Cable TV or antenn

Stereo VCR

VIDEO AUDIO

CH 3 CH 4

OUT

TV lower back panel

IN from ANT

OUT to TV

You will need:

• coaxial cables

• standard A/V cables

– For better picture performance, if your VCR has S-video,

use an S-video cable (plus the audio cables) instead of the standard video cable. Do not connect both types of video cable to VIDEO 1 at the same time or the picture performance will be unacceptable.

– If you have a mono VCR, connect L/MONO on the TV to

your VCR’s audio out terminal using the white audio cable only.

To view the antenna or Cable signal:

Select the ANT video input source on the TV.*

To view the VCR:

Turn ON the VCR. Select the VIDEO 1 video input source on the TV.*

* To select the video input source, press INPUT on the remote control

(- page 24). To program the TV remote control to operate other devices, see Chapter 3.

The unauthorized recording, use, distribution, or revision of television programs, videotapes, DVDs, and other materials is prohibited under the Copyright Laws of the United States and other countries, and may subject you to civil and criminal liability.

Chapter 2: Connecting your TV

Connecting a VCR with S-video and a cable box

An S-video connection will provide better picture performance than a standard (composite) video cable.

TV upper back panel

Cable box

CH 3 CH 4

stereo VCR

VIDEO AUDIO

CH 3 CH 4

OUT

TV lower back panel

From Cable T

OUT

IN from ANT

OUT to TV

You will need:

• coaxial cables

• S-video cable

– Do not connect both types of video cable to VIDEO 1 at

the same time or the picture performance will be unacceptable.

•

standard audio cables

– If you have a mono VCR, connect L/MONO on the TV to

your VCR’s audio out terminal using the white audio cable only.

Note: When you use a Cable box, you may not be able to use the remote control to program or access certain features on the TV.

To view basic and premium Cable channels:

Turn OFF the VCR. Select the ANT video input source on the TV.* Tune the TV to channel 3 or 4 (whichever channel the Cable box output is set to). Use the Cable box controls to change channels.

To view the VCR:

Turn ON the VCR. Select the VIDEO 1 video input source on the TV.*

* To select the video input source, press INPUT on the remote control

(- page 24). To program the TV remote control to operate other devices, see Chapter 3.

Chapter 2: Connecting your TV

Connecting a DVD player with ColorStream® (component video), a VCR, and a satellite receiver

Your TV has two sets of ColorStream® (component video) inputs.

TV upper back panel

From antenn

AUDIO

OUT

COMPONENT VIDEO

VIDEO

S-VIDEO

OUT

DVD player with component video

From satellite dish

AUDIO

OUT

Satellite

COMPONENT VIDEO

S-VIDEO

OUT

VIDEO

OUT

Satellite receiver with component video

TV lower back panel

You will need:

• coaxial cables

• standard A/V cables

– For better picture performance, if your VCR has S-video,

use an S-video cable (plus the audio cables) instead of the standard video cable. Do not connect both types of video cable to VIDEO 1 at the same time or the picture performance will be unacceptable.

– If you have a mono VCR, connect L/MONO on the TV to

your VCR’s audio out terminal using the white audio cable only.

•

standard audio cables

• component video cables

– You can connect the component video cables (plus audio

cables) from the DVD player or satellite receiver to either set of ColorStream terminals on the TV (HD-1 or HD-2). The ColorStream HD-1 and HD-2 terminals can be used with Progressive (480p, 720p) and Interlaced (480i, 1080i) scan systems. A 1080i signal will provide the best picture performance (1080p is not supported).

– If your DVD player or satellite receiver does not have

component video, connect a standard A/V cable to VIDEO 2 on the side panel. If your DVD player has HDMI video, see page 19.

Stereo VCR

VIDEO AUDIO

IN from ANT

CH 3 CH 4

OUT

OUT to TV

To view satellite programs using the component video connections:

Turn on the satellite receiver. Select the ColorStream HD-2 video input source on the TV.*

To view the VCR or view and record antenna channels:

Turn ON the VCR. Tune the VCR to the channel you want to watch. Select the VIDEO 1 video input source on the TV.*

To record a TV program while watching a DVD:

Turn ON the VCR. Tune the VCR to the channel to record. Select the ColorStream HD-1 video input source on the TV* to view the DVD.

* To select the video input source, press INPUT on the remote control

(- page 24). To program the TV remote control to operate other devices, see Chapter 3.

To view antenna or Cable channels:

Select the ANT video input source on the TV.*

To view the DVD player:

Turn ON the DVD player. Select the ColorStream HD-1 video input source on the TV.*

Chapter 2: Connecting your TV

Connecting a device to the IR OUT infrared terminal using the IR blaster cable for IR pass-through device control

You can use the TV’s IR OUT terminal (infrared passthrough) to remotely operate (through the TV) many infrared remote-controlled devices (such as Toshiba infrared remotecontrolled VCRs or DVD players) enclosed within an entertainment center or similar cabinet. Without the IR OUT connection, the device typically would need to be visible to operate it remotely.

You will need:

• dual-wand IR blaster cable (- page 13)

• other audio/video cables as required to connect the device(s)

to the TV (- pages 14–19)

Front of IR-controlled DVD player (for example)

To connect the IR blaster cable:

1 Locate the infrared sensor on the front of your device.

This sensor is marked on some devices.*

2 Align one of the IR blaster cable’s wands about 1 inch

away from the infrared sensor on the front of the device and attach it using double-sided mounting tape. If you have a second device, attach the second wand in a similar manner. (See illustration.)

Note: If you do not have a second device, coil the second wand with a rubber band and leave it behind the TV.

3 Plug the IR blaster cable’s plug into the TV’s IR OUT

terminal.

To control the device(s):

Point either the device’s remote control or the TV remote control (that you previously programmed to operate the device; - Chapter 3) toward the front of the TV and press the button for the desired function. The signal passes from the remote control through the TV to the device via the IR blaster cable.

Front of IR-controlled audio device (for example)

Infrared sensor

IR blaster cable wand (approx.1 inch from device)

TV upper back panel

Note:

• If you use the device’s remote control to operate the device, you also will need to use the TV’s remote control to operate the TV.

• The IR pass-through feature does not support all IR-controlled devices; satisfactory performance may not be attainable with certain devices.

*If you cannot locate the device’s infrared sensor:

1 Turn OFF the device. 2 Starting at the lower left corner of the device, place the

end of the device’s remote control (with the infrared emitter) so it touches the front of the device and press POWER. (Do not use the TV’s remote control for this step.)

3 If the device turns on, the point at which the remote

control touched the device is the location of the sensor.

4 If the device does not turn on, move the remote control

slightly to the right and press POWER again.

5 Repeat step 4 until you locate the device’s infrared

sensor.

Chapter 2: Connecting your TV

Connecting a camcorder

You will need:

• standard A/V cables

– For better picture performance, if your camcorder has

S-video, connect an S-video cable (plus the audio cables) to VIDEO 1 on the TV back instead of the VIDEO 2 on the TV right side panel.

Camcorder

VIDEO

AUDIO

OUT

VIDEO 2 inputs on TV right side panel

To view the camcorder video:

Select the VIDEO 2 video input source on the TV.*

* To select the video input source, press INPUT on the remote control

(- page 24). To program the TV remote control to operate other devices, see Chapter 3.

Chapter 2: Connecting your TV

Connecting an HDMI™ or DVI device to the HDMI input

The HDMI input on your TV receives digital audio and uncompressed digital video from an HDMI source device, or uncompressed digital video from a DVI (Digital Visual Interface) source device.

This input is designed to accept HDCP (High-Bandwidth Digital-Content Protection) program material in digital form from EIA/CEA-861-D–compliant devices (such as a set-top box or DVD player with HDMI or DVI output).

The HDMI input can accept and display VGA, SVGA, XGA, WXGA, SXGA, 480i (60Hz), 480p (60Hz), 720p (60Hz), 1080i (60Hz), and 1080p (24Hz/30Hz/60Hz) signal formats. For detailed signal specifications, see page 79.

Supported Audio format: Linear PCM, sampling rate 32/44.1/ 48 kHz

Note:

• Some of legacy HDMI sources may not work properly with your latest HDMI TV, due to new standard adoption. Please try to set Off the following two options (Lip-Sync Latency, xvYCC). Your legacy HDMI source should operate properly with your TV. See page 68.

• To connect a PC to the HDMI input, see page 22.

To connect an HDMI device, you will need:

• one HDMI cable (type A connector) per HDMI device

– For proper operation, it is recommended that you use an

HDMI cable with the HDMI Logo ( ).

– If your HDMI connection is capable of 1080p and/or your

TV is capable of refresh rates greater than 60Hz, you will need a Category 2 cable. Conventional HDMI/DVI cable may not work properly with this mode.

– HDMI cable transfers both video and audio. Separate

analog audio cables are not required (see illustration).

– See “Setting the HDMI™ audio mode” (- page 43).

TV lower back panel

[1]

consumer electronic

To connect a DVI device, you will need:

• one HDMI-to-DVI adapter cable (HDMI type A connector)

per DVI device

– For proper operation, the length of an HDMI-to-DVI

adapter cable should not exceed 9.8 ft (3m). The recommended length is 6.6 ft (2m).

•

one pair of standard analog audio cables per DVI device

– An HDMI-to-DVI adapter cable transfers video only.

Separate analog audio cables are required (see illustration).

™

– See “Setting the HDMI

TV upper back panel

DVI device

VIDEO AUDIO

OUT

Note: To ensure that the HDMI or DVI device is reset properly, it is recommended that you follow these procedures:

• When turning on your electronic components, turn on the TV first, and then the HDMI or DVI device.

• When turning off your electronic components, turn off the HDMI or DVI device first, and then the TV.

[1] EIA/CEA-861-D compliance covers the transmission of

uncompressed digital video with high-bandwidth digital content protection, which is being standardized for reception of highdefinition video signals. Because this is an evolving technology, it is possible that some devices may not operate properly with the TV.

audio mode” (- page 43).

TV lower back panel

DVI/ HDCP

OUT

HDMI device

VIDEO AUDIO

OUT

HDMI OUT

To view the HDMI device video:

Select the HDMI 1, HDMI 2, or HDMI 3 video input source on the TV.*

* To select the video input source, press INPUT on the remote control

(- page 24). To program the TV remote control to operate other devices, see Chapter 3.

HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC.

Chapter 2: Connecting your TV

CE-Link connection

You can control the basic functions of connected audio/video devices using the TV’s remote control if you connect a CE-Link compatible audio receiver or playback device. For an explanation of setup and operations, see pages 66 and 67.

TV lower back panel

Playback device (CE-Link HD DVD player,etc.)

VIDEO

AUDIO

OUT

HDMI OUT

VIDEO

AUDIO

OUT

Audio receiver

Playback device (CE-Link HD DVD player,etc.)

VIDEO

AUDIO

OUT

HDMI OUTHDMI

HDMI OUT

To connect an Audio Receiver and Playback Device, you will need:

• three HDMI cables (- page 19)

Note:

• If several devices are connected, the CE-Link feature may not operate properly.

• For proper operation, it is recommended that you use HDMI cables with the HDMI Logo ( ).

Before controlling the device(s):

• After completing the above connections, set the CE-Link

Setup menu as you desire (- page 67).

• The connected devices must also be set. For details, see the

operation manual for each device.

• The CE-Link feature uses the CEC technology as regulated

by the HDMI standard.

• This feature is limited to models incorporating Toshiba’s

CE-Link. However, Toshiba is not liable for those operations. Refer to individual instruction manuals for compatibility information.

Chapter 2: Connecting your TV

Connecting a digital audio system

The TV’s DIGITAL AUDIO OUT terminal outputs a Dolby®* Digital g or 2-channel down-mixed PCM (pulse-code modulation) signal for use with an external Dolby decoder or other external audio system with optical audio input.

You will need:

• optical audio cable (Use an optical audio cable that has the

larger “TosLink” connector and not the smaller “minioptical” connector.)

Dolby Digital decoder or other digital audio system

Optical

Audio IN

LINE IN LR

Digital

Note:

• Some audio systems may not be compatible with Dolby Digital bitstream signals. Older audio systems that are not compatible with standard optical out signals may not work properly, creating a high noise level that may damage speakers or headphones. THIS DAMAGE IS NOT COVERED BY YOUR WARRANTY.

• The DIGITAL AUDIO OUT terminal may not output some digital audio sources because of copy restrictions.

* Manufactured under license from Dolby Laboratories.

Dolby and the double-D symbol are registered trademarks of Dolby Laboratories.

Connecting an audio system

This connection allows you to use external speakers with an external analog audio amplifier to adjust the sound level.

TV lower back panel

To control the audio:

1 Turn on the TV and the digital audio device. 2 Press Y on the TV’s remote control and open the

Audio menu.

3 Highlight Audio Setup and press T.

Audio

Digital Audio Selector

Audio Settings

Advanced Audio Settings

Audio Setup

4 In the Optical Output Format field, select either

Dolby Digital or PCM, depending on your device

(

- “Selecting the optical audio output format” on

page 59).

Audio Setup

PC Audio No

HDMI 1 Audio

MTS Stereo

Language

Optical Output Format

Dolby Digital Dynamic Range Control

Reset

Auto

English

Dolby Digital

Compressed

Done

You will need:

• standard audio cables

Analog audio amplifier

LINE IN LR

TV upper back panel

To control the audio:

1 Turn on the TV and the stereo amplifier. 2 Minimize the sound volume from the TV’s built-in

speakers and control the volume level using the amplifier’s remote control.

Chapter 2: Connecting your TV

Connecting a personal computer (PC)

With either the PC IN or HDMI connection, you can watch your computer’s display on the TV and hear the sound from the TV’s speakers.

To connect a PC to the PC IN terminal on the TV:

When connecting a PC to the PC IN terminal on the TV, use an analog RGB (15-pin) computer cable and a PC audio cable.

TV upper back panel

TV lower back panel

•

Signal names for mini D-sub 15-pin connector

Pin No.

1R 6Ground11NC

2G 7Ground12NC

3 B 8 Ground 13 H-sync

4 NC * 9 NC 14 V-sync

5 NC 10Ground15NC

*NC=Not connected

Signal name

Pin No.

Signal name

Pin No.

Signal name

To connect a PC to the HDMI terminal on the TV:

When connecting a PC to the HDMI terminal on the TV, use an HDMI-to DVI adapter cable and analog audio cables.

If connecting a PC with an HDMI terminal, use an HDMI cable (type A connector). Separate analog cables are not necessary (- page 19).

PC audio

Computer

PC audio output

Conversion adapter (if necessary)

• To use a PC, set the monitor output resolution on the PC

cable

before connecting it to the TV. The PC IN terminal can accept and display VGA, SVGA, XGA, WXGA, and SXGA signal formats. For detailed signal specifications, see page

79. “Unsupported Video Signal” will be displayed when the

input signal is of unsupported.

• To display the optimum picture, use the PC setting feature

(

- “Using the PC settings feature” on page 65).

Note:

• The PC audio input terminals on the TV are shared with the

HDMI-1 analog audio input terminals (- page 65).

• Some PC models cannot be connected to this TV.

• An adapter is not needed for computers with a compatible

mini D-sub15-pin terminal.

• Depending on the DVD’s title and the specifications of the PC on which you are playing the DVD-Video, some scenes may be skipped or you may not be able to pause during multi-angle scenes.

TV upper back panel

Computer

PC audio cable

PC audio output

TV lower back panel

Note:

• The edges of the images may be hidden.

• If receiving a 720p, 1080i, or 1080p signal program, Native

mode scales the video to display the entire picture within the borders of the screen (i.e. no overscanning).

Chapter 3: Using the remote control

Installing the remote control batteries

To install the remote control batteries:

1 Slide the battery cover off the back of the remote control.

2 Install two “AA” size alkaline batteries. Match the + and

– symbols on the batteries to the symbols on the battery compartment.

3 Slide the battery cover on to the remote control until the

lock snaps.

Caution: Never throw batteries into a fire.

Note:

• Be sure to use AA size alkaline batteries.

• Dispose of batteries in a designated disposal area.

• Batteries should always be disposed of with the

environment in mind. Always dispose of batteries in accordance with applicable laws and regulations.

• If the remote control does not operate correctly, or if the operating range becomes reduced, replace batteries with new ones.

• When necessary to replace batteries in the remote control, always replace both batteries with new ones. Never mix battery types or use new and used batteries in combination.

• Always remove the batteries from the remote control if they are dead or if the remote control is not to be used for an extended period of time. This will prevent battery acid from leaking into the battery compartment.

Remote control effective range

For optimum performance, aim the remote control directly at the TV remote sensor. Make sure there are no obstructions between the remote control and the TV.

Point remote control toward remote sensor on front of TV.

16.4 ft (5m)

Chapter 3: Using the remote control

Learning about the remote control

The buttons used for operating the TV only are described here. For the CE-Link remote control functions, see the section “Using CE-Link” (- page 66). For a complete list of the remote control’s functions, see the remote control functional key chart (- pages 25–26).

6 8

5 7

3 MODE SELECT sets the four remote control device

modes: TV, CABLE/SAT, DVD, and VCR/PVR. Press TV until the keypad blinks 3 times to control the TV. The selected MODE key blinks each time any key is pressed. ( these keys can also be used to change inputs on the TV (- page 41).

4 Channel Numbers (0–9, –/100) directly tune

channels. The = button is used to tune digital channels

(

- page 50) or to edit the Favorite List (- page 48).

5 INPUT selects the video input source (

6 FAV BROWSER accesses the Favorites List in the

Channel Browser

7 MENU accesses the main TV menu system (

and 37).

8 ENTER activates highlighted items in the main menu

system.

9 THINC accesses the THINC menu (

10 3 C / # c While watching TV, these buttons open the

Channel Browser in the channel history (- page 49). (Also see “Arrow buttons.”)

- page 27). When the Auto Input feature is set,

- page 46).

™

(- page 48).

- pages 36

- page 37).

™

and tune to the previous/next channel

10 11

15 16

14 17

20 21

Note: The error message “Not Available” may appear if you press a key for a function that is not available.

1 SLEEP accesses the sleep timer (- page 66).

2 POWER turns the TV on and off. When the TV is on, the

green LED indicator on the TV front will be illuminated.

11 Arrow buttons (BbC c) When a menu is on-screen,

these buttons select or adjust programming menus. (Also see 3 C / # c.)

12 VOL + - adjusts the volume level.

13 CH Bb cycles through programmed channels when no

menu is on-screen (

14 EXIT closes on-screen menus.

15 INFO displays TV status information as well as program

details, when available (- page 69).

16 MUTE reduces or turns off the sound (- page 57).

17 CH RTN returns to the last viewed channel or source (-

page 50).

18 RECALL displays TV status information (- page 69).

19 C.CAPTION (TV/VCR) opens the closed caption/audio

selector screen. (The audio selector is not available for analog channels.) (- page 57.) By using this button, it is also possible to select TV mode and view one program while another is being recorded.

20 PIC MODE selects the picture mode (- page 54).

21 FREEZE freezes the picture. Press again to restore the

moving picture.

22 PIC SIZE cycles through the picture sizes: Natural,

TheaterWide 1/2/3, Full, 4:3 HD, and Native

(

- page 54).

- page 40).

Chapter 3: Using the remote control

Remote Control functional key chart

•

DVD/VCR REMOTE CONTROL KEY

Toshiba TV (TV)

CABLE

SAT (satellite)

VCR

combo

• DVD/ DVD-R

MODE SELECT

SLEEP Sleep timer s TV s TV s TV s TV s TV s TV s TV

POWER Power Power Power Power Power Power Power Power

1 Digit 1 Digit 1 Digit 1 Digit 1 Digit 1 AV input 1 Digit 1 Digit 1

2 Digit 2 Digit 2 Digit 2 Digit 2 Digit 2 AV input 2 Digit 2 Digit 2

3 Digit 3 Digit 3 Digit 3 Digit 3 Digit 3 AV input 3 Digit 3 Digit 3

4 Digit 4 Digit 4 Digit 4 Digit 4 Digit 4 AV input 4 Digit 4 Digit 4

5 Digit 5 Digit 5 Digit 5 Digit 5 Digit 5 CD Digit 5 Digit 5

6 Digit 6 Digit 6 Digit 6 Digit 6 Digit 6 Tuner Digit 6 Digit 6

7 Digit 7 Digit 7 Digit 7 Digit 7 Digit 7 Phono Digit 7 Digit 7

8 Digit 8 Digit 8 Digit 8 Digit 8 Digit 8 Cassette Digit 8 Digit 8

9 Digit 9 Digit 9 Digit 9 Digit 9 Digit 9 Aux Digit 9 Digit 9

0 Digit 0 Digit 0 Digit 0 Digit 0 Digit 0 --- Digit 0, 10 Digit 0

100/–/+10

INPUT

PIC SIZE

FAV BROWSER/ SET UP

THINC/ TOP MENU

GUIDE Guide* Guide Guide --- Guide --- --- Guide

INFO Guide Info Info Info --- Display --- --- Info

ENTER Enter Select Select --- Select --- --- Select

C 3 # c

EXIT/ DVD CLEAR

PAGE +/–

VOL +/–

Remote control device mode selection

– (digital separator)

TV/Video select

Selects the image shape

Menu/Guide Menu

FAV BROWSER

THINC s TV s TV s TV Top menu s TV s TV s TV

Menu select up

Menu select down

Menu select left/right

3 Back # Next

Exit Exit Exit --- DVD clear --- --- Exit

Page up/ down*

Volume up/

down

---

s TV s TV s TV s TV Input s TV s TV

s TV s TV s TV s TV s TV s TV s TV

Menu Menu --- Menu Menu Menu Menu

--- --- --- Setup --- --- ---

Cursor up Cursor up --- Cursor up --- --- Cursor up

Cursor down

Cursor left/ right

Page up/ down

Volume up/

down

–/--, +10, +100

Cursor down

Cursor left/ right

Page up/ down

Volume up/

down

+100

---

Volume up/

down

–/--, +10, +100

Cursor down

Cursor left/ right

Page up/ down

Volume up/ down

Receiver/ AMP

--- --- ---

--- ---

--- --- ---

Volume up/ down

CD (AUDIO)

Volume up/down

PVR

Cursor down

Cursor left/ right

Volume up/down

(continued)

Chapter 3: Using the remote control

•

REMOTE CONTROL KEY

Toshiba TV (TV)

CABLE

SAT (satellite)

VCR

DVD/VCR

combo

• DVD/

Receiver/ AMP

CD (AUDIO)

PVR

DVD-R

CH RTN/ DVD RTN

RECALL

MUTE Sound mute

SLOW

SKIP z SKIP Z

REW Rewind* Rewind Rewind Rewind Rewind --- Rewind Rewind

PAUSE/STEP Pause* Pause Pause Pause Pause --- Pause Pause

PLAY Play* Play Play Play Play --- Play Play

FF Fast FWD* Fast FWD Fast FWD Fast FWD Fast FWD --- Fast FWD Fast FWD

C.CAPTION TV/VCR

DISC/AM/FM --- --- --- --- ---

STOP Stop* Stop Stop Stop Stop --- Stop Stop

REC

CH B b

PIC MODE PIC MODE s TV s TV s TV s TV s TV s TV s TV FREEZE Freeze s TV s TV s TV s TV s TV s TV s TV

Previous channel

On-screen display

Slow FWD* Slow REW*

DAY+ DAY–

Previous channel

--- DVD RTN --- --- ---

s TV s TV s TV s TV s TV s TV s TV

Sound

mute

--- ---

--- --- ---

Sound mute

mute

Slow FWD Slow REW

Sound

Sound mute

Slow FWD Slow REW

Skip FWD Skip REW

C.Caption --- TV/SAT TV/VCR ---

REC Menu* (Single click)

Channel up/ down

Record (Double click)

Channel up/ down

Record (Double click)

Channel up/ down

Record (Double click)

Channel up/down

Record (Double click)

Channel up/down

Sound mute

--- ---

---

--- --- ---

AM/FM

Skip FWD Skip REW

Disc SKIP Disc select

Sound

mute

Slow FWD Slow REW

---

Instant replay

Record

--- ---

Channel up/down

---

(Double click)

Channel up/down

Note:

• “---” = key does not send a signal in that remote control mode.

• “s TV” = key will affect the TV, even though the remote control is in another mode.

• * Not available for your TV. However, you can use the certain remote buttons to control the CE-Link devices (- page 66).

Volume will affect the TV by default. When the volume is unlocked, all the devices will have their own volume if their ID has volume data. The AUDIO modes (receiver, CD) will have their own volume if volume lock is set on TV, CABLE/SAT, VCR/PVR, or DVD mode. See “Using the volume lock feature” (- page 28).

DVD/DVD-R : RECORD is only for DVD-R, no function is picked for DVD.

DVD/VCR combo : TV/VCR

DVD/VCR combo : DVD/VCR

Chapter 3: Using the remote control

Using the remote control to operate your other devices

Your TV remote control has one dedicated TV mode and three programmable multi-brand modes: CABLE/SAT, DVD, and VCR/PVR. The default device modes and programmable device modes are listed below.

Note: The TV remote control is preprogrammed to operate most Toshiba devices. To operate a non-Toshiba device or a Toshiba device that the remote control is not preprogrammed to operate, you will need to program the remote control. See “Programming the remote control to operate your other devices” (at right).

MODE SELECT

TV Toshiba TV

CABLE/SAT Toshiba Satellite receiver

DVD Orion DVD

VCR/PVR Toshiba VCR

MODE SELECT Device mode control after programming

TV Toshiba TV

CABLE/SAT

VCR/PVR

Note: Although your new TV’s remote control includes codes for many devices, it may not include codes for some or all of the features on certain devices you wish to control. If you are unable to program the TV’s remote control to operate your device or some of the features on that device, use the device’s remote control or the controls on the device.

Default device mode control (before programming)

Multi-brand video/audio devicesDVD

Programming the remote control to operate your other devices

Device code setup

Find the code for your device brand in the remote control device code table on pages 29–35.

If more than one code is listed, try each one separately until you find one that works.

2 Press the applicable mode select button (CABLE/SAT,

DVD, or VCR/PVR), until the mode select button blinks

3 times.

3 While holding down E, press the five-digit device code

for your device.

• If a valid code is entered, the mode select button will

blink twice.

• If an invalid code is entered, the mode select button will

blink one long blink.

4 Point the remote control at the device and press p to test

the code.

• If the device responds to the remote control, you have

entered the correct code.

• If the device does not respond to the remote control,

repeat steps 3 and 4 using another code.

Note: After programming the remote control, make sure all necessary keys on the TV remote control (in addition to

p) operate your device. If some keys are not

operational, repeat the device code setup using another code (if other codes are listed for your device). If, after trying all listed codes, the necessary keys do not operate your device, use the device’s original remote control.

5 To control the TV, press the “TV” mode select button.

Note:

• Although the TV remote control includes codes for many devices, it may not include codes for some or all of the features on certain devices you want to control. If you are unable to program the TV remote control to operate your device or some of the features on that device, use the device’s original remote control (or the control buttons on the device).

• Every time you change the batteries you will need to reprogram the remote control.

• Some newer VCRs respond to either of two codes. These VCRs have a switch labeled “VCR1/VCR2.” If your VCR has this kind of switch and does not respond to the codes for your VCR brand, set the switch to the other position (“VCR1” or “VCR2”) and reprogram the remote control.

(continued)

Chapter 3: Using the remote control

Searching and sampling the code of a device (8500)

If you do not know the device code for a particular device, you can cycle the remote control through the available codes for that device mode and sample the functions to find the code that operates the target device. The keys available to be sampled,

provided they are applicable to that mode, are p, 1, z, <, and S. Invalid keys will be ignored while in program mode.

To cycle through each available device code and sample its functions:

1 Press the appropriate mode select button on the remote

control.

2 While holding down E, press 8, 5, 0, 0. The remote

control will enter program mode.

3 Point the remote control at the target device and press p

(or other function buttons that are available to be sampled).

4 If the device responds to the remote control:

Press E to store the device code. The mode select

button will blink two times and the remote control will exit the program mode.

If the device does not respond to the remote control:

Press B, and then press p. Repeat this step until the

device responds to the remote control, and then press

Note: When a search cycle is completed, the mode select button will blink three times. The remote control will begin to cycle through the available codes again. If no key is pressed within 10 seconds during programming, the remote control will exit the program mode and return to the previous code.

Using the volume lock feature (8000)

By default (factory setting), the remote control’s volume keys

(z Z and W) are locked to the “TV” device mode.

The remote control will operate the TV’s volume, even when “TV” is not the current device mode.

If you unlock the remote control’s volume keys, each device mode will have its own volume (if the device ID has volume data). The remote control will operate the volume of the device associated with the current device mode.

If you lock the remote control’s volume keys to a specific device mode, the remote control will operate the volume of the device associated with the locked mode, even when the locked mode is not the current device mode.

See “Using the remote control to operate your other devices” on page 27.

To lock the remote control’s volume keys to a specific mode (CABLE/SAT in this example):

1 Press CABLE/SAT. 2 While holding down the E button, press 8, 0, 0, 0. 3 Press z. The CABLE/SAT mode select button will blink

two times (locked). The remote control’s volume keys will now operate the

volume of the device associated with the CABLE/SAT mode, even when CABLE/SAT is not the current device mode.

To unlock the remote control’s volume keys:

1 While holding down E, press 8, 0, 0, 0. 2 Press Z. The CABLE/SAT mode select button will blink

four times (unlocked).

Operational feature reset (8900)

This feature clears all programmed remote control features not related to “Device code setup” and resets the volume lock to the “TV” device mode.

To reset the remote control:

While holding down E, press 8, 9, 0, 0. The mode select

button will respond with four blinks.

Chapter 3: Using the remote control

Multi-brand remote control device codes

TVs

Brand Code

Toshiba 01524

Cable boxes

Brand Code

A-Mark 10008, 10144 ABC 10237, 10003,

10008, 10014, 10017

Accuphase 10003, 10014,

10017 Acorn 10237 Action 10237 Active 10237 Americast 10899 Amino 11822 Archer 10237 BCC 10276 Bell & Howell 10014 Bell South 10899 British Telecom 10003 Century 10008 Citation 10017 Clearmaster 10883 ClearMax 10883 Cool Box 10883 Coolmax 10883 Digeo 11187 Digi 10637 Director 10476 Dumont 10637 Emerson 10014 Fosgate 10276 GE 10144 Motorola/GI/Jerrold 10014, 10276,

10476, 10810 GI/Jerrold 10003, 10012 Motorola 11106, 11187,

11376 Gibralter 10003 GMI 10883 GoldStar 10144 Hamlin 10009, 10273 Hitachi 10003, 10008,

10009 Insight 10476, 10810 Jebsee 10014 Memorex 10000 Mitsubishi 10003 Multitech 10883 Myrio 11822 Nova Vision 10008 Novaplex 10008, 10017 NSC 10012, 10637 Oak 10017 Pace 11877, 10877,

10237, 10008

Panasonic 10000, 10008,

10144, 10107 Panther 10637 Paragon 10000, 10008,

10525 Penney 10000, 10637 Philips 11305, 10317 Pioneer 11877, 10877,

10144, 10533 Prism 10012 Pulsar 10000 Quasar 10000 RadioShack 10883 RCA 11256 Regal 10276, 10279,

10273 Runco 10000 Samsung 10003, 10144 Scientific Atlanta 11877, 10877,

10477, 10237,

10003, 10000,

10008, 10012,

10017 Sony 11006 Sprucer 10144 Starcom 10003, 10014 Stargate 10014 Storm 10637 Supercable 10276 Supermax 10883 Thomson 11256 Tocom 10012 Torx 10003 Toshiba 10000 Tristar 10883 United Cable 10276, 10003,

10014 US Electronics 10276, 10003,

10008, 10017 V2 10883 Videoway 10000 Viewmaster 10883 Vision 10883 Vortex View 10883 Zenith 10000, 10525,

10899, 10017

Satellite receivers

Brand Code

AlphaStar 10772 Bell ExpressVu 10775 Chaparral 10216 Coolsat1 1806 Crossdigital1 1109 DirecTV 11377, 10392,

10566, 10639,

11639, 11142,

10247, 10749,

11749, 10724,

10819, 11856,

11076, 11108,

10099, 11109,

11414, 11442,

11609, 11392,

11640

Dish Network System 11505, 11005,

Dishpro 11505, 11005,

Echostar 11505, 11005,

Expressvu 10775, 11775 Fortec Star 11821 Funai 11377 GE 10392, 10566 General Instrument 10869 GOI 10775, 11775 Hitachi 10749, 10819 Houston 10775 HTS 10775, 11775 Hughes Network Systems Humax 11790 Innova 10099 Jerrold 10869 JVC 10775, 11170,

LG 11226, 11414 Magnavox 10724, 10722 McIntosh 10869 Memorex 10724 Mitsubishi 10749 Motorola 10869 Netsat 10099 Next Level 10869 Optimus 10724 Panasonic 10247, 10701 Pansat 11807 Paysat 10724 Philips 11142, 10749,

Pioneer 11142, 11442 Primestar 10869 Proscan 10392, 10566 RadioShack 10566, 10775,

RCA 10392, 10566,

Samsung 11377, 11142,

SKY 10099 Sony 10639, 11639,

Star Choice 10869 Star Trak 10772, 10869 Thomson 10392, 10566 Tivo 11142, 11442 Toshiba 10749, 11749,

UltimateTV 11392, 11640

10775, 11170, 11775

10775, 11775

10775, 11170, 11775

11142, 10749, 11749, 11442

11775

11749, 10775, 10724, 10819, 11076, 10722, 10099, 11442

10869

11142, 10775, 10855, 10143, 11392, 11442

11276, 11108, 11109, 11442, 11609

11640

10790, 10819, 11285, 11286, 11287, 11289, 11857, 11858

(continued)

Chapter 3: Using the remote control

Ultrasat 11806 Uniden 10724, 10722 Voom 10869 Zenith 11856

DVDs

Brand Code

3D LAB 20503, 20539 Accurian 21072, 21416 Advent 21016 Afreey 20698 Aiwa 20641 Akai 20695, 20705,

20770, 20899,

21089 Alba 20672, 20717 Alco 20790 Allegro 20869 Apex Digital 20533, 20672,

20717, 20755,

20794, 20796,

20797, 20830,

21004, 21020,

21056, 21061,

21100 Arrgo 21023 Aspire Digital 21168, 21407 Audiovox 20717, 20790,

21041, 21071,

21072, 21121,

21122 Axion 21071, 21072 Blaupunkt 20717 Blue Parade 20571 Blue Sky 20695 Bose 21895 Brandt 20651 Broksonic 20695, 20868 California Audio Labs 20490 Celestial 21020 Centrex 20672, 21004 Cinea 20831 CineVision 20876, 20833,

20869 Citizen 21003, 21277 Clairtone 20571 Coby 20778, 21086,

21107, 21177 Craig 20831 Creative 20503, 20539 Curtis Mathes 21087 CyberHome 20816, 20874,

21023, 21024,

21117, 21129,

21502 Cytron 20705 Daewoo 20784, 20705,

20770, 20833,

20869, 21169,

21172, 21234,

21242 Dansai 20770 Decca 20770 Denon 20490, 20634 Denver 20778 Desay 21407

Digitrex 20672 Disney 20675, 21270 DiViDo 20705 Dual 20675, 21068 Durabrand 21127 DVD2000 20521 Electrohome 21003 Emerson 20591, 20675,

20821, 21268 Enterprise 20591 Entivo 20503, 20539 Enzer 20770 ESA 20821, 21268 Firstline 20651 Fisher 20670 Funai 20675, 21268,

21334 Gateway 21073, 21158 GE 20522, 20815,

20717 Go Video 20573, 20744,

20717, 20715,

20741, 20783,

20833, 20869,

21044, 21075,

21099, 21158,

21304, 21730 Go Vision 21071, 21072 GoldStar 20741, 20801,

20869 Goodmans 20790 Gradiente 20490, 20651 Greenhill 20717 Grundig 20539, 20705 Harman/Kardon 20582, 20702 Hitachi 20573, 20664,

21247 Hiteker 20672 Humax 21588 iLo 21348 Initial 20717 Insignia 21268 Integra 20571, 20627 IRT 20783 JBL 20702 Jensen 21016 JMB 20695 JVC 20558, 20623,

20867, 21164 Kawasaki 20790 Kenwood 20490, 20534 KLH 20717, 20790,

21020, 21149 Kloss 20533 Koss 20651, 21061 Lasonic 20627, 20798 Lecson 21533 Lenoxx 21127 LG 20591, 20741,

20801, 20869 LiteOn 21058, 21158,

21416, 21440 Loewe 20511, 20741 Logix 20783 Magnasonic 20651, 20675

Magnavox 20503, 20539,

20646, 20675, 20821, 21268

Marantz 20503, 20539,

20675 McIntosh 21533 Medion 20651 Memorex 20695, 20831,

21270 Microsoft 20522, 21708 Minato 20752 Mintek 20839, 20717 Mitsubishi 21521, 20521 NAD 20591, 20741 Naiko 20770 NEC 20785, 20869 Nesa 20717 NexxTech 21402 Norcent 21003, 21107,

21265 Onkyo 20503, 20627,

20792 Optimus 20571 Orion 21854 Oritron 20651 Palsonic 20672 Panasonic 20503, 20490,

20571, 20703,

21362, 21462,

21490, 21762 Philips 20503, 20539,

20646, 20675,

20854, 21260,

21267, 21354 PianoDisc 21024 Pioneer 20525, 20571,

20631 Polaroid 21020, 21061,

21086 PolkAudio 20539 Portland 20770 Presidian 20675, 21072 Prima 21016 Proceed 20672 Proscan 20522 ProVision 20778 Qwestar 20651 Radionette 20741 RadioShack 20571 RCA 20522, 20571,

20717, 20790,

20822, 21022,

21132 Realistic 20571 Reoc 20752 Rio 20869 Rotel 20623 Rowa 21004 Saba 20651 Sampo 20698, 20752 Samsung 20490, 20573,

20744, 20820,

20899, 21044,

21075 Sansui 20695 Sanyo 20670, 20675,

20695, 20873,

21334

Chapter 3: Using the remote control

Schneider 20783 Schwaiger 20752 Sensory Science 21158 Sharp 20630, 20675,

20752, 21256 Sharper Image 21117 Sherwood 20770, 21043 Shinsonic 20533, 20839 Slim Art 20784 Sonic Blue 20573, 20715,

20783, 20869,

21099 Sony 20533, 21533,

20864, 21033,

21070, 21431 Sova 21122 Superscan 20821 SVA 20717 Sylvania 20675, 20821,

21268 Symphonic 20675, 20821,

21268, 21334 Tatung 20770 Teac 20571, 20717,

20790 Technics 20490, 20703 Technika 20770 Tevion 20651 Theta Digital 20571 Thomson 20522, 20511 Tivo 21503, 21588 Toshiba 20503, 20573,

20539, 20695,

21045, 21154,

21503, 21588,

21854 Unimax 20770 Universum 20591 Urban Concepts 20503, 20539 US Logic 20839 V 21064, 21226 Venturer 20790 Visio 21064, 21226 Vizio 21064, 21226 Xbox 20522, 21708 Yamaha 20490, 20539,

20545 Zenith 20503, 20591,

20741, 20869 Zeus 20784 Zoece 21265

DVD-R

Brand Code

Accurian 21416 Apex Digital 21056 Aspire Digital 21168 Coby 21086 CyberHome 21129, 21502 Funai 20675, 21334 Gateway 21073, 21158 Go Video 20741, 21158,

21304, 21730 iLo 21348 JVC 21164 LG 20741

LiteOn 21158, 21416,

21440 Magnavox 20646, 20675 Panasonic 20490 Philips 20646 Pioneer 20631 Polaroid 21086 RCA 20522 Samsung 20490 Sensory Science 21158 Sharp 20675 Sony 21033, 21070,

21431 Sylvania 20675 Zenith 20741

DVD/VCR Combo

Brand Code

Allegro 20869 Apex Digital 21061 Broksonic 20695 CineVision 20833, 20869 Daewoo 20833, 20869 Emerson 20675 Funai 20675 Go Video 20744, 20715,

20741, 20833,

20869, 21044,

21075 GoldStar 20741 Hitachi 20664 JVC 20867, 21164 LG 20741 Magnavox 20675 Memorex 20695 Panasonic 21762 Philips 20675, 21267 Polaroid 21061 Presidian 20675 RCA 20522, 20822 Samsung 20820, 21044,

21075 Sansui 20695 Sanyo 20670, 20873 Sharp 20630 Sony 20864, 21033,

21070, 21431 Sylvania 20675 Symphonic 20675 Toshiba 20503, 21854 Zenith 20741, 20869 Emerson 31593 Funai 31593 Hitachi 30000 Magnavox 31593 Presidian 31593 RCA 30060 Sanyo 30104 Sharp 30848 Sylvania 30000, 30593,

31593 Symphonic 30000, 31593 Toshiba 41788

VCRs

Brand Code

A-Mark 30037, 30240,

30000, 30278,

30046 ABS 31972 Admiral 30060, 30048,

30039, 30047,

30104, 30209,

30020, 30062,

30479 Adventura 30037, 30240,

30000 Adyson 30072 Aiko 30278 Aiwa 30037, 30000,

30124, 30307 Akai 30041, 30061,

30106, 30175 Alba 30209, 30072,

30278 Alienware 31972 Allegro 30039 America Action 30278 American High 30035, 30081 Amstrad 30000 Asha 30240 Astra 30035, 30240 Audiovox 30037, 30278,

30038 Avis 30000, 30072 Beaumark 30240 Bell & Howell 30035, 30048,

30039, 30000,

30104, 30046,

30479 Broksonic 30184, 30121,

30209, 30002,

30208, 30479,

31479 Calix 30037 Candle 30037, 30038 Canon 30035 Capehart 30002, 30020,

30062 Carrera 30240 Carver 30035, 30081 CCE 30072, 30278 Cineral 30278 Citizen 30035, 30037,

30240, 30000,

30209, 30278,

30479, 31278 Classic 30037 Colortyme 30060, 30035,

30045, 30278 Colt 30000, 30072 Craig 30037, 30047,

30240, 30072,

30271 Criterion 30000, 30072 Crosley 30035, 30081,

30000, 30149 Crown 30072, 30278

(continued)

Chapter 3: Using the remote control

Curtis Mathes 30060, 30035,

30162, 30240, 30000, 30041, 30278, 30432,

30760, 31035 Cybernex 30240 CyberPower 31972 Daewoo 30037, 30045,

30278, 30020,

30046, 30561,

31278 Daytron 30037, 30278,

30020 Dell 31972 Denon 30081, 30042 Derwent 30041 DirecTV 30739 Dual 30000 Durabrand 30039, 30038 Dynatech 30240, 30000 Electrohome 30060, 30037,

30240, 30000,

30043, 30209,

30061 Electrophonic 30037 Emerald 30184, 30121 Emerex 30032 Emerson 30037, 30184,

30240, 30000,

30121, 30043,

30209, 30002,

30278, 30202,

30208, 30061,

30479, 30561,

30593, 31278,

31479, 31593 Fisher 30039, 30047,

30000, 30104,

30046 Fuji 30035, 30033 Fujitsu 30000 Funai 30037, 30000,

30072, 30278,

30593, 31593 Garrard 30000 Gateway 31972 GE 30060, 30035,

30048, 30240,

30000, 30149,

30202, 30760,

30807, 31035,

31060 Gemini 30060 Genexxa 30037, 30000,

30278 Go Video 30240, 30432,

30526, 30614 GoldStar 30035, 30037,

30039, 30000,

30278, 30038,

31237 Goodmans 30037, 30081,

30000, 30072,

30278, 30020,

30062 Gradiente 30000, 30008 Granada 30081, 30042 Grundig 30081 Harley Davidson 30000

Harman/Kardon 30081, 30038 Harvard 30072 Harwood 30072 Headquarter 30046 Hewlett Packard 31972 HI-Q 30035, 30047,

30000

Hitachi 30035, 30037,

30045, 30000, 30042, 30041,

30089, 30105 Howard Computers 31972 HP 31972 Hughes Network Systems 30042, 30739 Humax 30739 Hush 31972 Hytek 30047, 30000,

30072 iBUYPOWER 31972 ITT Nokia 30240, 30041 Janeil 30240 Jensen 30067, 30041 JVC 30067, 30041,

30008, 30061,

31162 KEC 30037, 30278 Kenwood 30067, 30041,

30038, 30046 KLH 30072 Kodak 30035, 30037 KTV 30000 LG 30037, 30240,

30038, 31037 Linksys 31972 Lloyd’s 30240, 30000,

30072, 30038,

30208 Loewe 30081 Logik 30240, 30000,

30072 Lumatron 30278 Luxor 30046, 30106 LXI 30037, 30000,

30042, 30067 M Electronic 30240 Magnasonic 30037, 30240,

30000, 30072,

30278, 30020,

30593, 31278 Magnavox 30035, 30037,

30048, 30039,

30081, 30240,

30000, 30149,

30563, 30593,

30618, 31593,

31781 Magnin 30240 Marantz 30035, 30081,

30038, 30062 Marta 30037 Matsui 30037, 30209 Matsushita 30035, 30162,

30081, 31162 Media Center PC 31972 MEI 30035

Memorex 30035, 30162,

30037, 30048, 30039, 30047, 30240, 30000, 30104, 30209, 30072, 30278, 30062, 30046, 30307, 30479, 31037, 31162,

31237, 31262 Metz 30037 MGA 30060, 30240,

30043, 30061 MGN Technology 30240 Microsoft 31972 Midland 30240 Mind 31972 Minolta 30042, 30105 Mitsubishi 30060, 30048,

30047, 30000,

30042, 30067,

30043, 30041,

30061, 30807 Motorola 30035, 30048 Movie Walker 30072 MTC 30240, 30000,

30072 MTX 30000 Multitech 30039, 30000,

30072 NAD 30240, 30104 NEC 30104, 30067,

30041, 30038 New Tech 30072 Nikko 30037, 30278 Nikkodo 30037, 30278 Nishi 30240 Niveus Media 31972 Noblex 30240 Northgate 31972 Olympus 30035, 30162,

30104 Onkyo 30222 Optimus 31062, 30035,

30162, 30037,

30048, 30047,

30240, 30000,

30104, 30062,

30432, 30593,

31048, 31162,

31262 Optonica 30062 Orion 30184, 30240,

30000, 30104,

30121, 30209,

30002, 30278,

30208, 30479,

31479 Panama 30035 Panasonic 31062, 30035,

30162, 30000,

30020, 30225,

30614, 30616,

31035, 31162,

31262

Chapter 3: Using the remote control

Penney 30035, 30162,

30037, 30047, 30081, 30240, 30000, 30042, 30067, 30038,

31035, 31237 Pentax 30042, 30105 Philco 30035, 30081,

30000, 30209,

30479 Philips 30035, 30162,

30048, 30081,

30045, 30000,

30209, 30062,

30616, 30618,

30739, 31081,

31181 Pilot 30037 Pioneer 30162, 30081,

30042, 30067 Polk Audio 30081 Portland 30278, 30020 Presidian 31593 Profitronic 30240 Proscan 30060, 30202,

30760, 31060 Protec 30000, 30072 Protech 30072 Pulsar 30039, 30240,

30278 Pulser 30240 Quarter 30046 Quartz 30035, 30047,

30046 Quasar 30035, 30162,

30002, 31035,

31162 RadioShack 30035, 30162,

30037, 30048,

30047, 30240,

30000, 30104,

30046, 30062,

31037, 31162 Radix 30037 Randex 30037 RCA 30060, 30035,

30048, 30240,

30045, 30000,

30042, 30149,

30105, 30106,

30202, 30760,

30807, 30880,

31035, 31060 Realistic 30035, 30162,

30037, 30048,

30047, 30240,

30000, 30104,

30121, 30278,

30046, 30062,

31162 ReplayTV 30614, 30616 Ricavision 31972 Runco 30039 Samsung 30060, 30240,

30045, 30000,

30038, 30432,

30739, 31014 Samtron 30240 Sanky 30048, 30039

Sansui 30240, 30000,

30067, 30209, 30041, 30072, 30002, 30271, 30479, 31479

Sanyo 30047, 30240,

30000, 30104, 30046, 30159,

30479 Scientific Atlanta 30008 Scott 30184, 30045,

30121, 30043,

30208, 30210 Sears 30060, 30035,

30162, 30037,

30048, 30039,

30047, 30033,

30045, 30000,

30042, 30104,

30067, 30043,

30209, 30041,

30072, 30046,

30105, 31237 Sharp 30048, 30047,

30032, 30000,

30062, 30807,

30848 Shintom 30039, 30240,

30000, 30072,

30208 Shogun 30240 Siemens 30037, 30104 Signature 30060, 30035,

30037, 30048,

30000, 30149,

30046, 30479 Singer 30037, 30240,

30072 Sonic Blue 30614, 30616 Sonographe 30046 Sony 30035, 30047,

30032, 30033,

30000, 30067,

30046, 30636,

31032, 31232,

31972 Soundmaster 30000 Stack 9 31972 STS 30042, 30105 SV2000 30000, 30072 SVA 30000 Sylvania 30035, 30081,

30000, 30043,

30593, 31593,

31781 Symphonic 30240, 30000,

30002, 30593,

31593 Systemax 31972 Tagar Systems 31972 Tandy 30000, 30104 Tatung 30048, 30081,

30000, 30067,

30041, 30008 Teac 30000, 30067,

30041 Technics 30035, 30162,

30037, 30000 Teknika 30035, 30037,

30000

Telecorder 30240 Telefunken 30041, 30208 Tevion 30479 Thomas 30000, 30002 Thomson 30060, 30041,

30202 Tisonic 30278 Tivo 30618, 30636,

30739, 31996 TMK 30240, 30000,

30208 TNIX 30037 Tocom 30240 Toshiba 30240, 30045,

30000, 30043,

30209, 30041,

30062, 30210,

30845, 31008,

31145, 31972,

31996 Tosonic 30278 Totevision 30037, 30240 Touch 31972 Trix 30037 Ultra 30045, 30278,

30020 Unitech 30240 Vector 30045 Vector Research 30184, 30038 Vextra 30072 Victor 30067, 30041,

30008 Video Concepts 30045, 30061,

30210 Videomagic 30037 Videosonic 30240, 30000,

30072 Viewsonic 31972 Villain 30000 Voodoo 31972 Wards 30060, 30035,

30037, 30048,

30047, 30081,

30033, 30240,

30045, 30000,

30042, 30043,

30041, 30072,

30038, 30149,

30046, 30062,

30479, 30760 Wharfedale 30593 White Westinghouse 30000, 30209,

30072, 30278,

30479 World 30209, 30002,

30479 XR-1000 30035, 30240,

30000, 30072,

30208 Yamaha 30041, 30038 Zenith 30037, 30039,

30033, 30000,

30209, 30041,

30278, 30479,

31139, 31479 ZT Group 31972

(continued)

Chapter 3: Using the remote control

PVRs

Brand Code

ABS 31972 Alienware 31972 CyberPower 31972 Dell 31972 DirecTV 30739 Gateway 31972 Hewlett Packard 31972 Howard Computers 31972 HP 31972 Hughes Network Systems 30739 Humax 30739 Hush 31972 iBUYPOWER 31972 Linksys 31972 Media Center PC 31972 Microsoft 31972 Mind 31972 Niveus Media 31972 Northgate 31972 Panasonic 30616 Philips 30618, 30739 RCA 30880 ReplayTV 30614, 30616 Samsung 30739 Sonic Blue 30614, 30616 Sony 30636, 31972 Stack 9 31972 Systemax 31972 Tagar Systems 31972 Tivo 30618, 30636,

30739

Toshiba 31008, 31972,

31996 Touch 31972 Viewsonic 31972 Voodoo 31972 ZT Group 31972

Cable/PVR Combo

Brand Code

Americast 10899 Amino 11822 Digeo 11187 Motorola/GI/Jerrold 10810 Motorola 11106, 11187,

11376 Myrio 11822 Pace 11877, 10237 Pioneer 11877, 10877 RCA 11256 Scientific Atlanta 11877, 10877 Sony 11006 Supercable 10276 Thomson 11256 Zenith 10899

DBS/PVR Combo

Brand Code

DirecTV 11377, 10392,

10639, 11142, 11076, 10099, 11392, 11442,

11640 Dish Network System 11505, 10775 Dishpro 11505, 10775 Echostar 11505, 10775,

11170 Expressvu 10775 Hughes Network Systems 11142, 11442 JVC 11170 Motorola 10869 Philips 11142, 11442 Proscan 10392 RCA 11392 Samsung 11442 Sony 10639, 11640 Star Choice 10869 Hughes Network Systems 30739 Philips 30739 Samsung 30739

Audio Amp

Brand Code

Adcom 40577 Bose 40674 Carver 40892 Curtis Mathes 40300 GE 40078 Harman/Kardon 40892 JVC 40331 Left Coast 40892 Marantz 40892 NEC 40264 Optimus 40013, 40300,

40823 Philips 40892 Pioneer 40013, 40300,

40823 Polk Audio 40892 RCA 40013, 40300,

40823 Realistic 40013 Shure 40264 Sony 40689, 40815 Soundesign 40078 Victor 40331 Wards 40078, 40013 Yamaha 40354, 40133

CD players

Brand Code

Acoustic Research 50420 Aiwa 50157 Arcam 50157 Audio Research 50157 Burmester 50420 Cairn 50157 California Audio Labs 50029, 50303

Cambridge Soundworks Carver 50157, 50179

Curtis Mathes 50032 Denon 50003, 50034 DKK 50000 DMX Electronics 50157 Fisher 50000, 50179 Garrard 50420 Genexxa 50032 Grundig 50157 Hafler 50173 Harman/Kardon 50100, 50157,

Hitachi 50032 Inkel 50157, 50180 Integra 50101 Jerrold 50003 JVC 50032, 50072 Kenwood 50626, 50000,

KLH 51711 Krell 50157 Linn 50157 LXI 50179 Magnavox 50157, 50274 Marantz 50626, 50029,

Matsui 50157 McIntosh 50256 MCS 50029 Memorex 50000, 50032,

Micromega 50157 Miro 50000 Mission 50157 Modulaire 50000, 50032,

MTC 50420 NSM 50157 Onkyo 51327, 50101 Optimus 50000, 50032,

Panasonic 50029, 50303,

Parasound 50420 Penney 50029 Philips 50626, 50157,

Pioneer 51062, 50032,

PolkAudio 50157 Proceed 50420 Proton 50157 QED 50157 Quad 50157 Quasar 50029 RadioShack 50000, 50032,

50157

50173

50029, 50028, 50037, 50190

50157, 50180

50179, 50420, 50468

50087, 50179, 50180, 50420, 50468

50037, 50087, 50179, 50420, 50468

50388, 50752

50274

51087, 50468

50179, 50180, 50420, 50468

Chapter 3: Using the remote control

RCA 51062, 50032,

50053, 50179, 50420, 50468

Realistic 50000, 50032,

50087, 50179, 50180, 50420,

50468 Revox 50157 Rotel 50157, 50420 SAE 50157 Sansui 50000, 50157 Sanyo 50000, 50087,

50179 Sears 50179 Sharp 50037, 50180 Sherwood 50180 Sonic Frontiers 50157 Sony 50490, 50000,

50100, 51364,

50185 Sugden 50157 Sylvania 50157 Symphonic 50180 TAG McLaren 50157 Tandy 50032 Tascam 50420 Teac 50490, 50180,

50420 Technics 50029, 50303 Techwood 50303 Thule Audio 50157 Victor 50072 Wards 50032, 50157,

50053, 50087,

50179 Yamaha 50490, 50036,

51292 Yorx 50000

Audio Amp/Tuners

Brand Code

ADC 40531 Aiwa 41405, 40189,

40121, 41388,

41641 Alco 41390 AMC 41077 Anam 41609, 41074 Apex Digital 41774 Arcam 41189 Audiotronic 41189 Audiovox 41390 B&K 40701, 40820 Bose 41229, 40639,

41253, 41933 Cairn 40189 Capetronic 40531 Carver 41189, 40189,

40121, 41289 Curtis Mathes 40014 Denon 41360, 40121,

40771, 41142,

41306 Emerson 40531 Fisher 41801 Grundig 40189

Harman/Kardon 40110, 40189,

40891, 41289,

41304, 41306 Hitachi 41273, 41801 Integra 40135, 40842,

41298, 41320 JBL 40110, 41306 JVC 41058, 40074,

41374, 41495,

41811 Kawasaki 41390 Kenwood 41313, 41570,

41569, 40186 KLH 41390, 41428 Koss 41366, 41497 LG 41293 Linn 40189 Liquid Video 41497 Magnavox 41189, 41269,

40189, 40531,

41266, 41514 Marantz 41189, 41269,

40189, 40891,

41289 McIntosh 41289 Micromega 41189, 40189 Mitsubishi 41393 Myryad 41189 Nakamichi 41313 Onkyo 40135, 40842,

41298, 41320,

41531 Optimus 41023, 40074,

40014, 40121,

40186, 40531,

41074 Oritron 41366, 41497 Panasonic 41308, 41518,

40309, 41288,

41316, 41548,

41633, 41763,

41764 Philips 41189, 41269,

40189, 40891,

41266 Pioneer 41023, 40014,

40150, 40531,

40630, 41384 Polaroid 41508 Polk Audio 40189, 41289 Proscan 41254 RadioShack 41609 RCA 41023, 41609,

41254, 40531,

41074, 41390,

41511 Realistic 41609, 40121,

40186 Revox 40189 Samsung 41295, 41304,

41500 Sansui 41189, 40189 Sanyo 41251, 41469,

41801 Sharp 40186 Sherwood 41077 Sirius 41811

Sony 41058, 41441,

41258, 41622, 41658, 41758,

41858 Stereophonics 41023 Sunfire 41313 Teac 41074, 41390 Technics 41308, 41518,

40309, 41633 Thorens 41189 Toshiba 40135, 40842,

41788 Venturer 41390 Victor 40074 Wards 40189, 40014 Yamaha 41023, 40176,

40186, 41176,

41276, 41331,

41375 Zenith 41293

Chapter 4: Menu layout and navigation

Main menu layout

The tables below and on the next page provide a quick overview of your TV’s menu system.

To open the main menus (illustrated below), press Y on the remote control or TV control panel.

Icon Item Option Page

Video

Audio

Preferences

Locks

Setup

Mode S Sports/Standard/Movie/Document/Preference 54 Picture Settings S [Opens the Picture Settings menu] 55 Noise Reduction S [Opens the Noise Reduction menu] 71 ColorMaster S [Opens the ColorMaster menu] 72 xvYCC Selection S Auto/On/Off 73 Game Mode S On/Off 74 Theater Settings S [Opens the Theater Settings menu] 51

TheaterLock Digital Audio Selector S [Launches the temporary Audio Selector] 57 Audio Settings S [Opens the Audio Settings menu] 58 Advanced Audio Settings S [Opens the Advanced Audio Settings menu] 74 Audio Setup S [Opens the Audio Setup menu] 58 CC Selector S [Launches the temporary CC Selector] 57 Base CC Mode S Off/CC1/CC2/CC3/CC4/T1/T2/T3/T4 56 Digital CC Settings S [Opens the Digital CC Setup menu] 56 Auto Input S [Opens the Auto Input Setup menu] 41 Input Labeling S [Opens the Input Labeling menu] 47 Channel Labeling S [Opens the Channel Labeling menu] 42 Menu Language S English/French/Spanish 39 Channel Browser Setup S [Opens the Channel Browser Setup menu] 48 Enable Rating Blocking S Off/On 61 Edit Rating Limits S [Opens the Edit Rating Limits menu] 61 Channels Block S [Opens the Channels block menu] 62 Input Lock S Off/Video/Video+ 63 Front Panel Lock S Off/On 64

GameTimer New PIN Code S [Opens the New PIN Code entry screen] 60 Installation S [Opens the Installation menu] 39 CE-Link Setup S [Opens the CE-Link Setup menu] 67 Sleep Timer S [Opens the Sleep Timer menu] 66 HDMI Settings S [Opens the HDMI Settings menu] 68 PC Settings S [Opens the PC Settings menu] 65 Blue LED Illumination S High/Middle/Low/Off 45 Power-On Mode S Power-Saving/Fast 45

™

S On/Off 55

S Off/30 Min/60 Min/90 Min/120 Min 64

Chapter 4: Menu layout and navigation

Setup/Installation menu layout

The Installation menu contains the Terrestrial and System Status menus.

To open the Installation menu (illustrated below), press Y on the remote control or TV control panel, open the Setup menu, select Installation, and press T.

Icon Item Option Page

Press Y,

open the Setup menu, and then open the Installation sub-menu.

Terrestrial

System Status

Input Configuration S [Opens the Input Configuration menu] 39 Antenna Tuning Mode S Standard/Auto/Digital 49 Channel Program S [Start] S [Scans for new channels on ANT] 40 Channel Add/Delete S [Opens the Channel Add/Delete menu] 40 Signal Meter S [Opens the Signal Meter menu] 44

System Information S [Opens the System Information screen] 44

THINC™ menu

The THINC* menu provides access to the CE-Link Player Control, Channel Browser, and Favorites Browser

features. The THINC menu is not part of the main menu system. You

can only view the THINC menu by pressing C on the

remote control.

THINC Applications

CE-Link Player Control

Channel Browser

Favorites Browser

* Toshiba Home Interactive Network Connection.

Chapter 4: Menu layout and navigation

Navigating the menu system

You can use the buttons on the remote control or TV control panel to access and navigate your TV’s on-screen menu system.

• Press Y to open the menu system.

• When a menu is open, use the up/down/left/right arrow

buttons (BbC c) on the remote control or TV control panel to move in the corresponding direction in the menu.

• Press T to save your menu settings or select a highlighted

item. (A highlighted menu item appears in a different color in the menu.)

• All menus close automatically if you do not make a selection

within 60 seconds, except the signal meter menu, which closes automatically after about 5 minutes.

• To close a menu instantly, press O.

Note:

• The menu background may sometimes appear black, depending on the signal the TV is receiving. This is not a sign of malfunction.

Video

Mode Sports

Picture Settings

Noise Reduction

ColorMaster

xvYCC Selection Auto

Game Mode

Theater Settings

TheaterLock

Navigate

Select

Off

Back Exit

CH RTNENTER

EXIT

• The Video sub-menu appears with a black background, which looks different from other menus.

Picture Settings

Contrast 100

Back Light 100

DynaLight

Brightness

Color

Tint

Advanced Picture Settings

Reset

50Sharpness

Mode: Sports

Done

Chapter 5: Setting up your TV

Selecting the menu language

You can choose from three different languages (English, French and Spanish) for the on-screen display of menus and messages.

To select the menu language:

1 Press Y and open the Preferences menu. 2 Highlight Menu Language and press c. 3 Press B or b to select your preferred menu language and

press T.

Preferences

CC Selector

Base CC Mode

Digital CC Settings

Auto Input

Input Labeling

Channel Labeling

Menu Language

Channel Browser Setup

4 Press O to close the Preferences menu.

Off

English

Français

Español

Configuring the antenna input source for the ANT terminal

To configure the ANT input source:

1 Press Y and open the Setup menu. 2 Highlight Installation and press T.

Setup

Installation

CE-Link Setup

Sleep Timer

HDMI Settings

PC Settings Blue LED Illumination High

Power-On Mode Power-Saving

3 (A new set of Installation menu icons will appear, as

shown below.) Open the Terrestrial menu, highlight

Input Configuration, and press T.

Installation

Terrestrial

Input Configuration

Antenna Tuning Mode

Channel Program

Channel Add/Delete

Signal Meter

4 Press C or c to select the input source (Cable or

Antenna) for the ANT input on the TV.

Input Configuration

Antenna In Cable

Cancel Done

5 To save your new settings, highlight Done and press T.

To revert to your original settings, highlight Cancel and

press T.

Chapter 5: Setting up your TV

Programming channels into the TV’s channel memory

4 (A new set of Installation menu icons will appear, as

shown below.) Open the Terrestrial menu, highlight

Channel Program to bring up the Start, and press T

again to begin channel programming.

When you press < or , on the remote control or TV control

panel, your TV will stop only on the channels you programmed into the TV’s channel memory.

Follow the steps below to program channels into the TV’s channel memory.

Programming channels automatically

Your TV can automatically detect all active channels in your area and store them in its memory. After the channels are programmed automatically, you can manually add or erase individual channels in the channel memory.

Note:

• You must configure the antenna input source before programming channels (- page 39).

• If the Antenna input signal type is set to Cable, the automatic channel programming process erases channels that were previously programmed into the TV’s memory.

• If the Antenna input signal type is set to Antenna, the automatic channel programming process adds newly found channels to the existing set of programmed channels (and does NOT erase channels that were previously programmed into the TV’s memory.) To remove an Antenna source channel from the memory, you must manually delete it.

• To tune the TV to a channel not programmed in the channel memory, you must use the Channel Number buttons on the remote control.

• Programming channels when the antenna input is configured for Cable will take substantially longer than when the antenna input is configured for Antenna. This is normal; however, once channel programming is finished, you should not have to repeat the programming process again unless your Cable TV service lineup changes significantly.

To program channels automatically:

1 Configure the antenna input source, if you have not

already done so (

- page 39).

2 Press Y and open the Setup menu. 3 Highlight Installation and press T.

Setup

Installation

CE-Link Setup

Sleep Timer

HDMI Settings

PC Settings Blue LED Illumination High

Power-On Mode Power-Saving

Installation

Terrestrial

Input Configuration

Antenna Tuning Mode

Channel Program

Channel Add/Delete

Signal Meter

ANT Cable Scanning channels, please wait ...

Number of Channels Found - 73 Scanning Digital Channels Found Channel - 118

Abort

Start

52%

The TV will automatically cycle through all the antenna channels, and store all active channels in the channel memory. While the TV is cycling through the channels, the message “Scanning channels, please wait” appears (as shown above).

5 To cancel channel programming, press O on the remote

control (or highlight Abort in the on-screen display and

press T). When channel programming is finished, press < or , to

view the programmed channels.

Manually adding and deleting channels in the channel memory

After automatically programming channels into the channel memory, you can manually add or delete individual channels.

To add or delete channels in the channel memory:

1 Press Y and open the Setup menu. 2 Highlight Installation and press T. 3 (A new set of Installation menu icons will appear, as

shown below.) Open the Terrestrial menu, highlight

Channel Add/Delete, and then press T.

Installation

Terrestrial

Input Configuration

Antenna Tuning Mode

Channel Program

Channel Add/Delete

Signal Meter

Chapter 5: Setting up your TV

To add a channel to the channel memory:

Highlight the unchecked box next to the channel number you

want to add, and then press T to check the box.

To manually add digital subchannels on a physical channel:

Use the Channel Numbers and the Dash (=) on the remote

control to enter the channel number (for example, 56–1). If the channel is found, the number will be added to the list and

the box will be checked. If the channel is not found, a message will appear.

To remove a channel from the channel memory:

Highlight the checked box next to the channel number you

want to remove, and then press T to uncheck the box.

To save your new settings:

Highlight Done and press T.

To revert to your original settings:

Highlight Cancel and press T before saving.

To remove all channels from the channel memory:

Highlight Reset and press T, and then highlight Done and press T.

Setting the Auto Input feature

This feature allows you to change TV inputs using the mode select buttons—TV, CABLE/SAT, DVD, VCR/PVR—on the remote control. Once an input has been set for a specific mode select button, the TV will automatically switch to that input when that mode select button is pressed.

Auto Input settings options for each mode select button are shown below.

• TV: ANT

• CABLE/SAT: ANT, Video 1, Video 2, ColorStream HD1,

ColorStream HD2, HDMI 1, HDMI 2, HDMI 3, PC

• DVD: Video 1, Video 2, ColorStream HD1,

ColorStream HD2, HDMI 1, HDMI 2, HDMI 3, PC

• VCR/PVR: ANT, Video 1, Video 2, ColorStream HD1,

ColorStream HD2, HDMI 1, HDMI 2, HDMI 3, PC

Note: The TV mode select button will be restricted to the ANT input.

To set the Auto Input:

1 Press Y and open the Preferences menu. 2 Highlight Auto Input and press T.

Channel Add/Delete

2 - 1

2 - 2

7 - 1

Analog

Digital

Analog

Digital

Analog

Digital

Analog

Reset

Cancel

Done

To remove encrypted channels from the channel memory:

If an encrypted channel is accidentally added to the channel list by programming channels, you can remove the unwanted encrypted (non-viewable) channel while you are channel surfing. When you tunes to an encrypted channel, the following message will appear.

Digital Channel Is Encrypted - Press 1 on remote to remove channel

Press “1” button while the message is on the screen to

remove the unnecessary channel from the channel list.

Preferences

CC Selector

Base CC Mode

Digital CC Settings

Auto Input

Input Labeling

Channel Labeling

Menu Language

Channel Browser Setup

Off

English

3 Press B or b to highlight Enable Auto Input and then

press C or c to select On.

Auto Input

Use this menu to enable your TV's automatic input switching feature when changing modes on your remote control.

SLEEP

MODE SELECT

CABLE/SAT

Enable Auto Input

POWER

DVD

VCR/PVR

CABLE/SAT ColorStream HD1

DVD

VCR/PVR Video 1

Reset

Done

HDMI 1

(continued)

Chapter 5: Setting up your TV

4 Press B or b to select the mode field you want to set.

Auto Input

Use this menu to enable your TV's automatic input switching feature when changing modes on your remote control.

SLEEP

MODE SELECT

CABLE/SAT

Enable Auto Input

POWER

DVD

VCR/PVR

CABLE/SAT ColorStream HD1

DVD

VCR/PVR Video 1

HDMI 1

Labeling channels

A list of common channel labels (logos) for various channels (ABC, CBS, etc.) will be programmed into the TV. You will be able to view and assign these logos from the Channel Labeling window. If the desired channel label is not provided in the list, you will be able to manually enter/edit labels using the software keyboard.

Reset

Done

5 Press C or c to select the desired input source for that

mode.

6 Repeat steps 4 and 5 for other modes. 7 To save your settings, highlight Done and press T.

To turn off the Auto Input:

Select Off in step 3 on the previous page.

Note: Setting the feature to Off will not cancel any settings; however, all items will be grayed out.

To reset Auto Input:

1 Press Y and open the Preferences menu. 2 Highlight Auto Input and press T. 3 Highlight Reset and press T.

To assign channel labels:

1 Press Y and open the Preferences menu. 2 Highlight Channel Labeling and press T.

The Channel Labeling window opens.

Preferences

CC Selector

Base CC Mode

Digital CC Settings

Auto Input

Input Labeling

Channel Labeling

Menu Language

Channel Browser Setup

Channel Labeling

{No Label}

A&E

ABC

ABCFAM

ABCHD

AMAX

AMAXW

AMC

ANIMAL

Off

English

ANT

A&E

Press CH UP/DOWN to change channels.

Custom

Clear All

Done

3 Press < or , to select the channel you want to label. 4 Press BbC c to highlight the desired channel label and

press T.

5 Repeat steps 3 and 4 for other channels. 6 To save your settings, highlight Done and press T.

Channel Labeling

{No Label}

A&E

ABC

ABCFAM

ABCHD

AMAX

AMAXW

AMC

ANIMAL

ANT

A&E

Press CH UP/DOWN to change channels.

Custom

Clear All

Done

The maximum number of labels that can be stored is 128.

Chapter 5: Setting up your TV

To remove channel labels:

1 Open the Channel Labeling window. 2 Press < or , to select the channel for which you want to

remove the label.

3 Press BbC c to highlight No Label and press T.

Channel Labeling

{No Label}

A&E

ABC

ABCFAM

ABCHD

AMAX

AMAXW

AMC

ANIMAL

ANT

Press CH UP/DOWN to change channels.

Custom

Clear All

Done

4 Repeat steps 2 and 3 for other channels. 5 To save your settings, highlight Done and press T.

If the desired channel label is not available from the list of presets, you can create a custom label.

To create and assign a custom label:

1 Open the Channel Labeling window. 2 Press < or , to select a channel you want to label. 3 Press Bb c to highlight Custom and press T.

The software keyboard will appear.

Channel Labeling

{No Label}

A&E

1 A B C a b c 2

ABC

G H I g h i 4

ABCFAM

P Q R S p q r s 7

ABCHD

Backspace

100

AMAX

AMAXW

AMC

ANIMAL

ANT

A&E

Edit

Press CH UP/DOWN to

J K L j k l 5

change channels.

T U V t u v 8

Clear All

Done

CH RTN

Cancel

Send

Exit

EXIT

D E F d e f 3

M N O m n o 6

W X Y Z w x y z 9

INPUT

Space

4 Repeatedly press the corresponding key on the remote

control to highlight the desired character on the on-screen software keyboard.

5 The highlighted character is entered after you either press

a different key, press c key, or after a two-second pause.

6 Repeat steps 4 and 5 until you have entered all desired

text.

7 When finished, press T. 8 (New labels will be added to the list in alphabetical order

and marked with an icon to indicate that they are

custom.) Highlight the new custom label and press T to

assign. Assigned channel labels will be displayed in the banner,

Channel Add/Delete window, and Channels Block window.

To delete the custom label:

1 Open the Channel Labeling window. 2 Highlight the label to be deleted and press =. 3 Highlight Yes from the deletion confirmation window

and press T.

Channel Labeling

TIMES

TLC

TMC

TMCX

TMCXw

TMCw

TNT

TNTHD

TOCDEFG

ANT

Delete the selected custom label?

Press CH UP/DOWN to change channels.

Custom

Clear All

Done

YesNo

4 Highlight Done and press T to save changes, and go

back to the Channel Labeling window.

Setting the HDMI™ audio mode

To set the HDMI audio mode:

1 Press Y and open the Audio menu. 2 Highlight Audio Setup and press T. 3 Press B or b to select HDMI 1 Audio and then press

C or c to select the HDMI 1 audio mode (Auto, Digital, or Analog). (Auto is the recommended mode.) See “Connecting an HDMI or DVI device to the HDMI input” (- page 19).

Audio Setup

PC Audio No

HDMI 1 Audio

MTS Stereo

Language

Optical Output Format

Dolby Digital Dynamic Range Control

Reset

Note: Because the PC and HDMI-1 inputs share the same set of analog audio inputs, the PC Audio menu setting influences the HDMI 1 Audio menu setting. If PC Audio is set to “No,” the HDMI 1 Audio setting changes to “Auto.” If PC Audio is set to “Yes,” the HDMI 1 Audio setting is set to “Digital” and is grayed out in the menu. (Also see item 5 on page 12 and “Setting the PC Audio” on page 65.)

Auto

English

Dolby Digital

Compressed

Done

Chapter 5: Setting up your TV

Viewing the digital signal meter

You can view the digital signal meter in the ANT digital TV input source only.

To view the digital signal meter:

1 Press Y and open the Setup menu. 2 Highlight Installation and press T. 3 A new set of Installation menu icons will appear, as shown

below. Open the Terrestrial menu, highlight Signal

Meter, and press T.

Installation

Terrestrial

Input Configuration

Antenna Tuning Mode

Channel Program

Channel Add/Delete

Signal Meter

4 Press BbC c to select the antenna input and digital

channel whose signal you want to check.

Note: The physical digital channel number listed in the Signal Meter screen may not correspond to a virtual TV channel number. Contact your local broadcasters to obtain the RF channel numbers for your local digital stations.

Signal Meter

Signal Locked

Physical Digital Channel 4

Virtual Digital Channel

Peak

4-1

DoneAdvanced

Viewing the system status

To view the system status:

1 Press Y and open the Setup menu. 2 Highlight Installation and press T. 3 A new set of Installation menu icons will appear, as shown

below. Open the System Status menu, highlight

System Information, and press T.

Installation

System Status

System Information

4 Press C c to scroll through the menu bar to select the

Software Version and view the related information.

System Information

Software Version

RF350U

3.3.55.0

Jun 28 2007 - 01:10:27

FW: 31

Done

To close the screen and return to the Installation menu:

Highlight Done and press T.

To return to normal viewing:

Press O.

Reset Factory Defaults

To close the screen and return to the Terrestrial menu:

Highlight Done and press T.

To return to normal viewing:

Press O.

To reset all settings and channels to their factory default values:

1 Press Y and open the Setup menu. 2 Highlight Installation and press T. A new set of

Installation menu icons will appear.

3 Open the System Status menu, highlight System

Information, and press T.

4 Press C c to scroll through the menu bar to select

Factory Defaults.

System Information

Factory Defaults

This window provides the ability to reset the TV settings.Type in your PIN now (or "0000" if no PIN has been set) to restore settings to their factory default values.

Done

5 Enter your PIN code (or 0000 if no PIN code has been set).

Chapter 5: Setting up your TV

6 Highlight Yes and press T. The TV will turn off

automatically after a few seconds. After the TV turns off, unplug the TV power cord and then plug it in again to complete the reset process.

System Information

Press YES to confirm. After the TV turns off, unplug it and plug it back in to complete the reset.

YesNo

Selecting the Power-On Mode

You can select either Power-Saving or Fast mode.

• Power-Saving mode keeps power consumption in standby

mode to below 3W. As a result, it takes a bit longer for the TV to turn on.

• Fast mode increases power consumption in standby mode.

As a result, the TV will turn on more quickly. While in Fast mode, the yellow LED on the front of the TV will be lit.

To cancel the reset:

Highlight No and press T.

Selecting the Blue LED Illumination level

You can adjust the brightness of the blue LED located on the front panel (High, Middle, Low, or Off).

To set the Blue LED Illumination level:

1 Press Y, and open the Setup menu. 2 Highlight Blue LED Illumination and press c. 3 Press B or b to select your desired illumination level.

Setup

Installation

CE-Link Setup

Sleep Timer

HDMI Settings

PC Settings

Blue LED Illumination High

Power-On Mode Power-Saving

Off

Low

Middle

High

To set the Power-On Mode feature:

1 Press Y, and open the Setup menu. 2 Highlight Power-On Mode and press c. 3 Press B or b to select either Power-Saving or Fast.

Setup

Installation

CE-Link Setup

Sleep Timer

HDMI Settings

PC Settings Blue LED Illumination High

Power-On Mode Power-Saving

Power-Saving

Fast

Chapter 6: Using the TV’s features

Selecting the video input source to view

To select the video input source to view:

1 Press + on the remote control or TV control panel. 2 And then either:

a) Press 0–8; or b) Repeatedly press Bb on the remote control and then

press T to change the input; or

c) Repeatedly press + on the remote control or TV

control panel to change the input.

The current signal source displays in the top right corner of the Input Selection screen.

Input Selection ANT

ANT ANT

Video 1

Video 2

ColorStream HD1

ColorStream HD2

CE-Link

CE-LINK

HDMI 1

5 6

HDMI 2

HDMI 3

INPUT

- / to Select

Note:

• You can label the video input sources according to the specific devices you have connected to the TV (- “Labeling the video input sources” at right).

• Sources can also be “hidden” (- “Labeling the video input sources” at right).

• “No Video Signal” will appear randomly on the screen if no signal is received in video input mode.

• If a CEC device is connected to an HDMI input, the CE-Link icon will appear.

Navigate

Note:

• When selecting CE-Link input sources from the popup

window using +, some CE-Link devices may automatically

turn on.

• When selecting input sources using B b, you will have to

press T to actually select a particular device from the

popup window.

To switch the video input source using the mode select buttons:

Press CABLE/SAT, DVD, or VCR/PVR.

Note: To use this function, you must set up the Auto Input feature (- page 41).

If a CE-Link device with HDMI switching capability (e.g. Audio Receiver) is connected to the HDMI input:

Press + on the remote or TV control panel repeatedly to

highlight HDMI 1, HDMI 2, or HDMI 3. If the connected CEC device has any connected devices, a

separate device selection popup window will appear.

Input Selection

ANT ANT

Video 1

Video 2

ColorStream HD1

ColorStream HD2

CE-Link

HDMI 1

5 6

HDMI 2

HDMI 3

- / to Select

INPUT

HDMI 1

Navigate

HDMI 1 - 1 Audio Receiver

HDMI 1 - 2 Player HDMI 1 - 3 Recorder

Press + repeatedly to highlight the desired input source, and then press O.

Chapter 6: Using the TV’s features

Labeling the video input sources

You can label each video input source according to the type of device you connected to each source, from the following preset list of labels:

• – – (default label)

• Audio Receiver

• Cable

• Compact Disc

• DTV

• DVD

• Game Console

• HD DVD

• HDMI Switch

• Laser Disk

• Satellite/DSS

• VCR

• Video Recorder

•

Hide (to hide an unused input in the and in the Channel Browser Inputs list)

Note: If you select PC in the Input Selection screen, you can choose only “– –” or “Hide” as the label.

To label the video input sources:

1 Press Y and open the Preferences menu. 2 Highlight Input Labeling and press T.

Input Selection

screen

4 Press C or c to select the desired label for that input

source. If a particular input is not used, you can select Hide as the label, which will cause that input to be “grayed out” in the Input Selection screen and skipped

over when you press + on the remote control.

5 To save the new input labels, highlight Done and

press T.

To revert to the factory default labels, highlight Reset

and press T.

Input labeling example:

The screen below left shows the default Input Selection screen (with none of the inputs labeled as a specific device). The screen below right is an example of how you could label the inputs if you connected a VCR to VIDEO 1, Cable TV to VIDEO 2, a video recorder to ColorStream HD1, a DTV settop box to HDMI 1, a satellite/DSS set-top box to HDMI 2, and a DVD player to HDMI 3. Also note that the ColorStream HD2 input is labeled “Hidden,” which means that input will be

skipped over when + is pressed.

Input Selection ANT

ANT ANT

Video 1

Video 2

2 3

ColorStream HD1

ColorStream HD2

CE-Link CE-Link

HDMI 1

5 6

HDMI 2 HDMI 3

INPUT

to Select

Navigate

Input Selection screen with no inputs labeled.

Input Selection ANT

ANT ANT

VCR

Cable

2 3

Video Recorder

ColorStream HD2 (Hidden)

DTV

5 6

Satellite/DSS DVD

INPUT

to Select

Navigate

Input Selection screen with all inputs labeled except input 4, which has been hidden.

Preferences

CC Selector

Base CC Mode

Digital CC Settings

Auto Input

Input Labeling

Channel Labeling

Menu Language

Channel Browser Setup

Off

English

3 Press B or b to highlight the video source you want to

label.

Input Labeling

Video 1 VCR

Video 2 Cable

ColorStream HD 1 Video Recorder

ColorStream HD 2 Hide

HDMI 1 DTV

HDMI 2

HDMI 3 DVD

Reset

Satellite/DSS

Done

To clear the input labels:

1 Press Y and open the Preferences menu. 2 Highlight Input Labeling and press T. 3 Highlight Reset and press T.

Chapter 6: Using the TV’s features

Tuning channels

Tuning channels using the Channel Browser

The Channel Browser™ provides an easy navigation interface for all your channels and inputs. This feature allows you to:

• Navigate the contents of all of your inputs.

• Keep a list of your favorite channels (see “Favorites

Browser,” below).

• Keep a history of the last 32 channels or inputs viewed.

• Quickly surf and tune your recently viewed channels/inputs

from the Channel Browser next page).

• Surf via Browse mode (to immediately tune channels as you

highlight them in the Channel Browser surf over channels in the Channel Browser select one to tune).

• Quickly change inputs from the Inputs List.

• Quickly select CE-Link devices from the CE-Link List.

Favorites Browser

The Favorites Browser allows you to quickly set up a favorite channels/inputs list that is integrated into the Channel Browser

To add a favorite channel/input:

1 Tune to the channel or input. 2 Press and hold n for 3 seconds.

Note: Additions are added to the beginning of the Favorites list on the left side of the Channel Browser

To delete a favorite channel/input:

1 Press n to open the Favorites browser list. 2 Highlight the channel or input to delete by pressing

3 C or # c.

3 Press and hold = for 3 seconds. The channel/input will

be removed from the Favorites list.

To set up the Channel Browser™:

™

History List (illustrated on the

™

) or Select mode (to

™

before you

™

3 Press B to highlight Navigation, and then press C or c

to select either Browse Mode or Select Mode.

Channel Browser Setup

Navigation

History List

ANT List On

Inputs List On

Favorites List On

CE-Link List

Reset

Select Mode

Power Off Clear (On)

Off

Done

4 Press b to highlight History List, and then press C or c

to select the setting you prefer: either Power Off Clear (On), On, or Off.

Note: When History List is set to On and the Power-On Mode (- page 45) is in Fast mode, the channels and

inputs stored in the list will be saved every power on/off cycle. When History List is set to Power Off Clear (On), the channels and inputs stored in the list will be cleared with every power on/off cycle of the TV.

5 Press b to highlight ANT List, and then press C or c to

select On or Off.

6 Press b to highlight Inputs List, and then press C or c

to select On or Off.

7 Press b to highlight Favorites List, and then press C or

c to select On or Off.

8 Press b to highlight CE-Link List, and then press C or c

to select On or Off.

Note: This item will be automatically grayed out and set to Off when Enable CE-Link is switched to Off. (See “To set

the CE-Link Setup” on page 68 for more information.)

9 To save your entries, highlight Done and press T.

To return to factory defaults, highlight Reset and

press T.

To open the Channel Browser™:

• Press 3 C or # c on the remote control.

• Press 3 C to surf backward through the previously tuned 32

channels in the History list, the channels in the ANT channel list, the inputs in the Inputs list, the CE-Link devices in the CE-Link list, or the favorite channels/inputs in the Favorites list.

• Press # c to surf forward through the channel History, the

ANT channel list, the Inputs list, the CE-Link list, or the favorite channels/inputs in the Favorites list.

1 Press Y and open the Preferences menu. 2 Highlight Channel Browser Setup and press T.

Chapter 6: Using the TV’s features

Elements of the Channel Browser

™

1 2 43

History

10 32 11 8

TVLAND ABCHD WEATHER

1 Current list (History, ANT, Inputs, CE-Link, or

Favorites)

2 Input type

3 Channel or input currently being viewed

4 Channel or input that is currently highlighted in the

browser

5 Channels stored in the History List

6 Channel labels

To toggle among the available lists:

After opening the Channel Browser™, press B or b to toggle among History, ANT, Inputs, CE-Link, and Favorites.

Note:

• The Channel Browser™ opens in History List by default. Once another list has been selected, the Channel Browser will open in the last selected list.

• If all lists are turned off, pressing display the Channel Browser™. If Favorites List is turned

off, n will have no effect.

• Pressing n will bring up the Channel Browser

list regardless of the last selected list in the Channel Browser

™

3 C, # c, or n will not

™

Favorites

Adding and clearing channels and inputs in the History List

Adding channels and inputs to the History List:

As a channel or input is tuned, the Channel Browser™ adds it to the History List and displays it on the “right side” of the Channel Browser

™

. Previously tuned channels/inputs are

“shifted” to the left, eventually moving off the left side. Press 3 C to surf backward through the previously tuned channels/ inputs. Any channel or input that is tuned repeatedly will not be repeated in the History List, but instead is moved to the end of the list on the right side of the Channel Browser

The Channel Browser

• All channels that are tuned using the numeric buttons on the

™

will store the following channels:

remote control.

• All channels that are tuned using < or , on the remote

control.

Note: Whenever an item is selected that cannot be tuned (for various reasons), the TV will automatically tune to the previously viewed channel or input.

Clearing channels from the History List:

• Reconfiguring the ANT input will clear the History List.

™

Note: See page 39 for details on configuring the antenna input.

• Once 32 channels or inputs are stored in the History List, the

oldest item will be removed from the list when a new channel or input is tuned.

• If History List in the Channel Browser Setup is set to

“Power Off Clear (On),” turning off the TV will clear the History List.

™

To tune to a channel or input in Browse mode:

1 While watching TV, press 3 C or # c to open the

Channel Browser surf forward to the next item in the list.

In Browse mode, when you stop on an item in the Channel Browser automatically tune to the channel or input.

2 Press O to close the Channel Browser

To tune to a channel or input in Select mode:

™

and surf back to a previous item or

™

, it will be highlighted and the TV will

™

1 While watching TV, press 3 C or # c to open the

Channel Browser forward to the next item in the list.

In Select mode, when you stop on an item in the Channel Browser

™

tune the TV to the highlighted item.

™

and surf back to a previous item or

, it will be highlighted but you must press T to

2 Press T to tune the TV to the highlighted item. 3 Press O to close the Channel Browser

™

Setting the Antenna Tuning Mode

This feature allows you to choose how tuning will be handled for analog and digital channels when the TV is in Antenna mode.

Note: To use this feature, the Input Configuration must be set to Antenna (- page 39).

The antenna tuning mode has three options.

• Standard: both analog and digital channels can be tuned

normally (default)

• Auto: digital channels will have priority when manually

entering a channel number using the Channel Number (0-9) on the remote control, analog channels can still be tuned by

< / , if available

• Digital: only digital channels can be tuned

Note: This mode will be most useful after analog channels are shut down by the government in 2009.

(continued)

Chapter 6: Using the TV’s features

To set the Antenna Tuning Mode:

1 Press Y and open the Setup menu. 2 Highlight Installation and press T. 3 (A new set of Installation menu icons will appear, as

shown below.) Open the Terrestrial menu, highlight Antenna Tuning Mode, and then press B b to select

your desired mode.

Installation

Terrestrial

Input Configuration

Antenna Tuning Mode

Channel Program

Channel Add/Delete

Signal Meter

Note:

• The Channel Add/Delete & Channels Block windows as well as the Channel Browser ANT list will be updated automatically when you change the mode. Also, the History List will be cleared, but the Favorites List will be saved.

• Even if the Antenna Tuning Mode is set to Digital, analog channel 3 will still be the default channel to prevent the initial case where no digital channels have been found in prior channel scans. (Channel Add/Delete will not have anything listed until a scan is done.)

Standard

Auto

Digital

Tuning to the next programmed channel

To tune to the next programmed channel:

Press < or , on the remote control or TV control panel.

Note:This feature will not work unless you program channels into the TV’s channel memory (- page 40).

Tuning to a specific channel (programmed or unprogrammed)

Press the Channel Number (0–9) on the remote control. For example, to select channel 125 (or channel 125-1), press 1, 2, 5. Your TV will tune to the analog or digital channel according to the Antenna Tuning Mode setting:

• If the Antenna Tuning Mode is set to Standard, the TV will

tune to analog channel 125. To tune to digital channels, press the Channel Number (0–9) on the remote control,

followed by the dash (=) button and then the sub-channel

number. For example, to select digital channel 125-1, press 1, 2, 5, -, 1.

• If the Antenna Tuning Mode is set to Auto, the TV will tune

to digital channel 125-1 if it exists, if not then analog channel 125.

• If the Antenna Tuning Mode is set to Digital, the TV will

tune to digital channel 125-1. (It is not possible to tune analog channels by pressing the Channel Number (0–9).)

Note: If a digital channel is not programmed—either through the automatic channel scan (- page 40) or the channel add/ delete function (- page 40)—you will have to tune the RF channel using the Channel Number and dash ( remote control.

=) on the

Switching between two channels using Channel Return

The Channel Return feature allows you to switch between two channels without entering an actual channel number each time.

1 Select the first channel you want to view. 2 Select a second channel using the Channel Number

buttons (and the dash (=) button if selecting a digital

channel).

3 Press R on the remote control. The previous channel

will display. Each time you press R, the TV will switch

back and forth between the last two channels that were tuned.

Note:

• If you press R from a non-antenna input, the TV will return

to the last-viewed input.

• If the previous channel or memorized channel was an analog channel and you change the Channel Tuning Mode to Digital, “NOT AVAILABLE” will be displayed if pressed.

R is

Switching between two channels using SurfLock

The SurfLock™ feature temporarily “memorizes” one channel

to the R button, so you can return to that channel quickly from any other channel by pressing R. To memorize a channel to the R button:

™

1 Tune the TV to the channel you want to program into the

R button.

2 Press and hold R for about 2 seconds until the message

“Channel Memorized” appears on-screen. The channel

has been programmed to the R button.

3 You can then change channels repeatedly, and when you

press R, the memorized channel will be tuned.

The TV will return to the memorized channel one time only.

Once you press R and then change channels again, the CH

RTN memory will be cleared and the button will function as Channel Return, by switching back and forth between the last two channels that are tuned.This feature also works for external inputs.

Chapter 6: Using the TV’s features

Selecting the picture size

You can view many program formats in a variety of picture sizes—Natural, TheaterWide 1, TheaterWide 2, TheaterWide 3, Full, 4:3 HD and Native.

Note: The “picture size” illustrations are examples only. The format of the image (in any of the picture sizes) will vary depending on the format of the signal you are currently watching. Select the picture size that displays the current program the way that looks best to you.

You can save separate picture size preferences for each input on your TV.

To select the picture size using the remote control:

Note: If you select one of the TheaterWide® picture sizes, the top and bottom edges of the picture (including subtitles or captions) may be hidden. To view the hidden edges, either scroll the picture (TheaterWide 2 and 3 only) or try viewing the program in Full or Natural picture size.

Natural picture size

• The image is displayed close to its originally formatted

proportion. Some program formats will display with sidebars and/or bars at the top and bottom.

1 Press I on the remote control. 2 While the Picture Size screen is open, you can do one of

the following to select the desired picture size:

• Repeatedly press I.

• Press the corresponding Number button (0–6) while the

Picture Size screen is open.

• Press B or b while the Picture Size screen is open.

Picture Size

Natural

TheaterWide 1

TheaterWide 2

TheaterWide 3

Full

4:3 HD

Native

PIC SIZE

- / to Select

To select the picture size using the menus:

1 Select Picture Size in the Theater Settings menu. 2 Press C or c to select the desired picture size setting. 3 Highlight Done and press T.

Theater Settings

Picture Size Full

Picture Scroll

Cinema Mode Film

Auto Aspect Ratio On

Reset

Mode: Sports

Done

Natural picture size example

TheaterWide 1 picture size (for 4:3 format programs)

• The center of the picture remains close to its original

proportion, but the left and right edges are stretched wider to fill the screen.

TheaterWide 1 picture size example

TheaterWide 2 picture size (for letter box programs)

• The picture is stretched wider to fill the width of the screen,

but only slightly stretched taller.

• The top and bottom edges of the picture may be hidden. To

view the hidden areas, see “Scrolling the TheaterWide picture” (- page 53).

A B C D E F G - - - - - - - - - - - - - - - -

TheaterWide 2 picture size example

Note: Some of the picture sizes may not be available depending on the receiving signal format (those will be “grayed out” in the Picture Size screen).

Using these functions to change the picture size (i.e., changing the height/ width ratio) for any purpose other than your private viewing may be prohibited under the Copyright Laws of the United States and other countries, and may subject you to civil and criminal liability.

(continued)

Chapter 6: Using the TV’s features

TheaterWide 3 picture size (for letter box programs with subtitles)

• The picture is stretched wider to fill the width of the screen,

but only slightly stretched taller.

• The top and bottom edges are hidden. To view the hidden

areas (such as subtitles or captions), see “Scrolling the TheaterWide

A B C D E F G - - - - - - - - - - - - - - - -

picture.”

A B C D E F G - - - - - - - - - - - - - - - - - - - - - - - - - -

TheaterWide 3 picture size example

Full picture size (for 16:9 [480i, 480p] source programs only)

• If receiving a squeezed 4:3 format program, the picture is

stretched wider to fill the width of the screen, but not stretched taller.

• None of the picture is hidden.

Native picture size (for 720p, 1080i, and 1080p signal programs)

• If receiving a 720p, 1080i, or 1080p signal program, Native

mode scales the video to display the entire picture within the borders of the screen (i.e. no overscanning).

• This is especially useful for external HD sources such as

HD-DVD, DVHS movies, or PC graphics.

Note:

• Native picture size is available for 720p, 1080i, and 1080p signals only. If the signal being received is other than 1080i, 1080p, or 720p, “Native” will be grayed out in the Picture Size screen.

• This mode is supported only for HDMI, ColorStream, and antenna inputs.

• Depending on the input signals, the border of the picture may be hidden, displayed in black, or noisy.

Native picture size example

Full picture size example

4:3 HD picture size (for 720p, 1080i, and 1080p program sources only)

• Sidebars fill the empty vertical spaces.

• Picture is not distorted from original size.

4:3 HD picture size example

Chapter 6: Using the TV’s features

Scrolling the TheaterWide® picture (TheaterWide 2 and 3 only)

You can set separate scroll settings for the TheaterWide 2 and TheaterWide 3 modes for each input.

To set the scroll settings:

1 Press Y and open the Video menu. 2 Highlight Theater Settings and press T.

Video

Mode

Picture Settings

Noise Reduction

ColorMaster

xvYCC Selection

Game Mode

Theater Settings

TheaterLock

3 In the Picture Size field, select either TheaterWide 2

or TheaterWide 3 (you cannot scroll in any other mode).

4 Press b to highlight the Picture Scroll field. 5 Press C or c to scroll the picture up and down as needed,

from –10 to +20.

Theater Settings

Picture Size TheaterWide 2

Picture Scroll -5

Cinema Mode Film

Auto Aspect Ratio On

6 To save the new settings, highlight Done and press T.

To revert to the factory defaults, highlight Reset and

press T.

Sports

Auto

Off

Mode: Sports

DoneReset

Using the auto aspect ratio feature

When the auto aspect ratio feature is set to On, the TV will automatically select the picture size when one of the following input sources is received:

• A 480i signal from the VIDEO 1, VIDEO 2, ColorStream

HD-1, or ColorStream HD-2 input.

• A 480i, 480p, 720p, 1080i, 1080p, or VGA signal from the

HDMI input.

Aspect ratio of signal source

4:3 normal Natural (with sidebars)

4:3 letter box TheaterWide 2

16:9 full Full

Not defined (no ID-1 data or HDMI aspect data)

Note: The auto aspect ratio feature is not applicable to antenna or cable input sources.

To turn on the auto aspect ratio feature:

1 Press Y and open the Video menu. 2 Highlight Theater Settings and press T. 3 In the Auto Aspect Ratio field, select On.

4 To save the new settings, highlight Done and press T.

To revert to the factory defaults, highlight Reset and

press T.

Automatic aspect size (automatically selected when Auto Aspect is On)

The current picture size you set under “Selecting the picture size” on page 51.

Theater Settings

Picture Size Natural

Picture Scroll --

Cinema Mode Film

Auto Aspect Ratio On

DoneReset

Mode: Sports

To turn off the auto aspect ratio feature:

Select Off in step 3 above.

Chapter 6: Using the TV’s features

Selecting the cinema mode (480i and 1080i signals)

When you view a DVD (3:2 pulldown processed) from a DVD player connected to the VIDEO 1, VIDEO 2, ColorStream HD-1, ColorStream HD-2 (component video), or HDMI inputs on the TV, smoother motion can be obtained by setting the Cinema Mode to Film.

To set the Cinema Mode to Film:

1 Press Y and open the Video menu. 2 Highlight Theater Settings and press T. 3 In the Cinema Mode field, select Film.

Theater Settings

Picture Size Natural

Picture Scroll --

Cinema Mode Film

Auto Aspect Ratio On

4 To save the new settings, highlight Done and press T.

To revert to the factory defaults, highlight Reset and

press T.

To set the Cinema Mode to Video:

Select Video in step 3 above.

Mode: Sports

DoneReset

Adjusting the picture

Selecting the picture mode

You can select your desired picture settings from five different modes, as described below.

Mode Picture Quality

Sports Bright and dynamic picture (factory setting)

Standard Standard picture settings (factory setting)

Movie

Document

Preference Your personal preferences

Note:The Document mode is available for HDMI input sources only (grayed out for other input sources).

To select the picture mode:

Press u on the remote control.

The following popup menu appears on-screen.

Lower contrast for darkened room (factory setting)

Designed for viewing of tables/documents from a PC (factory setting)

Sports

Standard

Movie

Document

Preference

Using the FREEZE feature

To use the FREEZE feature:

1 When viewing the TV, press B to make the picture a

still picture.

2 To return to the moving picture, press B again (or any

other button).

Note: If the TV is left in FREEZE mode for more than 15 minutes, the FREEZE mode will automatically be released and the TV will return to moving picture.

Still pictureMoving picture

Using the FREEZE function for any purpose other than your private viewing may be prohibited under the Copyright Laws of the United States and other countries, and may subject you to civil and criminal liability.

Press B or b to select the picture mode you prefer and press T.

To select the picture mode using the menu system:

1 Press Y and open the Video menu. 2 Highlight Mode and press T.

Video

Mode

Picture Settings

Noise Reduction

ColorMaster

xvYCC Selection

Game Mode Theater Settings

TheaterLock

Sports

Auto

Off

3 Press B or b to select the picture mode you prefer and

press T.

Sports

Standard

Movie

Document

Preference

Note: The picture mode you select affects the current input only. You can select a different picture mode for each input.

Chapter 6: Using the TV’s features

Adjusting the picture quality

You can adjust the picture quality (Contrast, Back Light, DynaLight™, Brightness, Color, Tint, and Sharpness) to your personal preferences.

Selection Pressing C Pressing c

Contrast lower higher

Back Light* darker lighter

DynaLight** On/Off On/Off

Brightness darker lighter

Color paler deeper

Tint reddish greenish

Sharpness softer sharper

* Back Light

This feature adjusts the brightness of the entire screen. When in video mode and no signal is input, this will automatically be set to 0. (Settings are stored in memory.)

**DynaLight

This function automatically strengthens the black coloring of dark areas in the video according to the level of darkness.

To adjust the picture quality:

1 Press Y and open the Video menu. 2 Highlight Picture Settings and press T. 3 Press B or b to select the picture quality you want to

adjust (Contrast, Back Light, DynaLight, Brightness, Color, Tint, or Sharpness), and then

press C or c to adjust the setting, as described in the table above.

Picture Settings

Contrast 100

Back Light 100

DynaLight

Brightness

Color

Tint

Advanced Picture Settings

Reset

50Sharpness

Mode: Sports

Done

Using the TheaterLock™ feature

The TheaterLock™ feature allows you to “lock” all items that affect the picture mode setting. In other words, those settings that when adjusted cause the Mode setting to automatically change to “Preference” will be grayed out and unavailable when the TheaterLock setting is set to “On”. Items that do not influence Mode status will not be affected e.g., Noise Reduction, xvYCC Selection, Game Mode, etc.

To turn on TheaterLock™:

1 Press Y and open the Video menu. 2 Press B or b to highlight the TheaterLock field, and

then press C or c to select On.

Video

Mode

Picture Settings

Noise Reduction

ColorMaster

xvYCC Selection

Game Mode Theater Settings

TheaterLock

To turn off TheaterLock™:

Select Off in step 2 above.

Note: When TheaterLock is set to On, a lock icon ( ) will also be displayed in all Video menu windows where items are disabled.

Picture Settings

Contrast 100

Back Light 100

DynaLight

Brightness

Color

Tint

Advanced Picture Settings

Reset

Sports

Auto

Off

50Sharpness

Off

Mode: Sports

Done

Picture Settings Mode: Preference

Contrast 70

4 To save the new settings, highlight Done and press T.

You can use any of the picture modes (- “Selecting the picture mode,” above left) as a starting point for adjusting the picture settings.

To revert back to the base mode that you began adjusting

the picture settings from, highlight Reset and press T.

The picture qualities you adjusted are automatically saved in the Preference mode (- “Selecting the picture mode,” above left) until Reset is selected.

Chapter 6: Using the TV’s features

Using the closed caption mode

Base closed captions

The closed caption mode has two options:

• Captions—An on-screen display of the dialogue, narration,

and sound effects of TV programs and videos that are closed captioned (usually marked “CC” in program guides).

• Text—An on-screen display of information not related to

the current program, such as weather or stock data (when provided by individual stations).

To view captions or text:

1 Press Y and open the Preferences menu. 2 Highlight Base CC Mode and press c. 3 Press B or b to select the desired closed caption mode and

press T.

Preferences

CC Selector

Base CC Mode

Digital CC Settings

Auto Input

Input Labeling

Channel Labeling

Menu Language

Channel Browser Setup

• To view captions:

Highlight CC1, CC2, CC3, or CC4. (CC1 displays translation of the primary language in your area.)

Off

English

Off

CC1

CC2

CC3

CC4

Note: A closed caption signal may not display in the following situations:

• When a videotape has been dubbed

• When the signal reception is weak

• When the signal reception is non-standard

Digital CC Settings

You can customize the closed caption display characteristics by changing the background color, opacity, text size, type, edge, and color.

Note:

• This feature is available for digital channels only.

• You cannot set the Caption Text and Background as the

same color.

To customize the closed captions:

1 Press Y and open the Preferences menu. 2 Highlight Digital CC Settings and press T. 3 Press B or b to highlight the characteristic you want to

change, and then press C or c to select the format for that characteristic (see table below).

Digital CC Settings

Caption Size Auto

Caption Text Edge

Caption Text Color

Text Foreground Opacity

Background Color

Text Background Opacity

Caption Text Edge Color

Reset

ABC123

Done

AutoCaption Text Type

Auto

Preview window

Giant pandas eat leaves.

Note: If the program or video you selected is not closed captioned, no captions will display on-screen.

• To view text:

Highlight T1, T2, T3, or T4.

WORLD WEATHER

Temps Current F C Weather LONDON 51 11 MOSCOW PARIS ROME TOKYO

57 14 53 12 66 19 65 18

Clear Cloudy Clear Cloudy Rain

Note: If text is not available in your area, a black rectangle may appear on screen. If this happens, set the Base CC Mode to Off.

•

To turn off the closed caption mode:

Select Off in step 3 above.

4 To save the new settings, highlight Done and press T.

To revert to the factory defaults, highlight Reset and

press T.

Caption Size Auto, Small, Standard, Large

Caption Text Type

Caption Text Edge

Caption Text Color

Text Foreground Opacity

Background Color

Text Background Opacity

Caption Text Edge Color

Auto, Default, Mono w. Serif, Prop. w. Serif, Mono w/o Serif, Prop. w/o Serif, Casual, Cursive, Small Capitals

Auto, None, Raised, Depressed, Uniform, Left Drop Shadow, Right Drop shadow

Auto, Black, White, Red, Green, Blue, Yellow, Magenta, Cyan

Auto, Transparent, Translucent, Flashing, Solid

Auto, Black, White, Red, Green, Blue, Yellow, Magenta, Cyan

Auto, Transparent, Translucent, Flashing, Solid

Auto, Black, White, Red, Green, Blue, Yellow, Magenta, Cyan

Chapter 6: Using the TV’s features

CC Selector

You can use the CC Selector to temporarily override the default analog caption mode (set in Base CC Mode) for a particular channel. However, once you change to another analog channel, the closed caption setting will automatically change back to the current Base CC Mode setting.

You can also use the CC Selector to select digital closed caption services (if available). When such services are not available, the CC Selector presents a default list of services. If the selected service is not available, the next best service will be used instead.

To select closed captions:

1 Press Y and open the Preferences menu. 2 Highlight CC Selector and press T.

Preferences

CC Selector

Base CC Mode

Digital CC Settings

Auto Input

Input Labeling

Channel Labeling

Menu Language

Channel Browser Setup

Off

English

Adjusting the audio

Muting the sound

Press W to partially reduce (1/2 MUTE) or turn off (MUTE) the sound. Each time you press W, the mute mode will

change in the following order:

Volume1/2 Mute Mute

If the closed caption mode is set to Off when you select “MUTE” mode, the closed caption feature is automatically activated. To mute the audio without automatically activating

the closed caption feature, use Z to set the volume to 0. See “Using the closed caption mode” (- page 56) for more

information on closed caption modes.

Using the digital audio selector

You can use the Digital Audio Selector to conveniently switch between audio tracks on a digital channel (for those channels that have multiple audio tracks). This temporarily overrides the audio track chosen by the language option under Audio Setup (- “Selecting stereo/SAP broadcasts” on page 58).

3 Press B or b to select Closed Caption, and then press

C or c to select the desired service.

Closed Caption

Audio

CC 1

None

4 Press O.

Using the Closed Caption button on the remote control

If you press ; when an analog channel is tuned:

• The CC selector will be active and will display CC1-4 and

T1-4 as the options.

• The audio selector will be disabled.

If you press ; when a digital channel is tuned:

• The CC selector will be active and will display the possible

caption options (available languages) for that channel or service. For example, in addition to English, a channel might offer closed captions in Spanish and/or French.

• The audio selector will be active and will offer different

audio choices for the digital channel (Dolby or AC3, for example).

To use the digital audio selector:

1 Press Y and open the Audio menu. 2 Highlight Digital Audio Selector and press T.

Audio

Digital Audio Selector

Audio Settings

Advanced Audio Settings

Audio Setup

3 Press B or b to select Audio, and then press C or c to

select the desired service.

CC 1Closed Caption

Audio

None

4 Press O.

Chapter 6: Using the TV’s features

Selecting stereo/SAP broadcasts

The multi-channel TV sound (MTS) feature allows you to output high-fidelity stereo sound. MTS also can transmit a second audio program (SAP) containing a second language, music, or other audio information (when provided by individual stations).

When the TV receives a stereo or SAP broadcast, the word

“STEREO” or “SAP” appears on-screen when E is pressed.

The MTS feature is not available when the TV is in VIDEO mode.

To listen to stereo sound:

1 Press Y and open the Audio menu. 2 Highlight Audio Setup and press T.

Audio

Digital Audio Selector

Audio Settings

Advanced Audio Settings

Audio Setup

3 In the MTS field, select Stereo.

Audio Setup

PC Audio No

HDMI 1 Audio

MTS Stereo

Language

Optical Output Format

Dolby Digital Dynamic Range Control

Reset

Auto

English

Dolby Digital

Compressed

Done

4 To save the new settings, highlight Done and press T.

To reset the settings to the factory defaults, highlight

Reset and press T.

Note:

• You can typically leave the TV in Stereo mode because it will automatically output the type of sound being broadcast (stereo or monaural).

• If the stereo sound is noisy, select Mono to reduce the noise.

To listen to an alternate language on an ATSC digital station (if available):

Highlight the Language field in step 3 above, and then press C or c to select the language you prefer.

To listen to a second audio program on an analog station (if available):

Select SAP in step 3 at left.

Note:

• A second audio program (SAP) can be heard only on those TV stations that offer it. For example, a station might broadcast another language as a second audio program. If you have SAP on, you will see the current program on the screen but hear the other language instead of the program’s normal audio.

• If you have SAP on and the station you are watching is not broadcasting a second audio program, the station’s normal audio will be output. However, occasionally there is no sound at all in SAP mode. If this happens, set the MTS feature to Stereo mode.

Adjusting the audio quality

You can adjust the audio quality by adjusting the bass, treble, and balance.

To adjust the audio quality:

1 Press Y and open the Audio menu. 2 Highlight Audio Settings and press T. 3 Press b or B to highlight the item you want to adjust

(Bass, Treble, or Balance).

Audio Settings

Bass 100

Treble

Balance

StableSound Off

Reset

100

Done

4 Press C or c to adjust the level.

• C makes the bass or treble weaker or increases the

balance in the left channel (depending on the item selected).

• c makes the bass or treble stronger or increases the

balance in the right channel (depending on the item selected).

5 To save the new settings, highlight Done and press T.

To reset the settings to the factory defaults, highlight

Reset and press T.

Chapter 6: Using the TV’s features

Using the StableSound® feature

The StableSound® feature limits the highest volume level to prevent extreme changes in volume when the signal source changes (for example, to prevent the sudden increase in volume that often happens when a TV program switches to a commercial).

To turn on the StableSound® feature:

1 Press Y and open the Audio menu. 2 Highlight Audio Settings and press T. 3 In the StableSound field, select On.

Audio Settings

Bass 100

Treble

Balance

StableSound On

Reset

100

Done

4 To save the new settings, highlight Done and press T.

To revert to the factory defaults, highlight Reset and

press T.

Note: The RESET function returns your audio adjustments to the following factory settings:

Bass . . . . . . . . center (50)

Treble . . . . . . . center (50)

Balance . . . . . . center (0)

StableSound . . Off

To turn off the StableSound feature:

Select Off in step 3 above.

Selecting the optical audio output format

You can use this feature to select the optical audio output format when you connect a Dolby Digital decoder or other digital audio system to the Optical Audio Out terminal on the TV (see “Connecting a digital audio system” on page 21).

3 In the Optical Output Format field, select either

Dolby Digital or PCM, depending on your device.

Audio Setup

PC Audio No

HDMI 1 Audio

MTS Stereo

Language

Optical Output Format

Dolby Digital Dynamic Range Control

Reset

Auto

English

Dolby Digital

Compressed

Done

4 To save the new settings, highlight Done and press T.

To revert to the factory defaults, highlight Reset and

press T.

Using the Dolby® Digital Dynamic Range Control feature

This dynamic range control feature causes the ATSC dynamic range to be further compressed, allowing you to switch from ATSC to analog broadcasts at the same dynamic range.

To use the Dolby Digital Dynamic Range Control:

1 Press Y and open the Audio menu. 2 Highlight Audio Setup and press T. 3 In the Dolby Digital Dynamic Range Control field,

select Compressed. When Standard is selected, the audio is output with minimal compression.

Audio Setup

PC Audio No

HDMI 1 Audio

MTS Stereo

Language

Optical Output Format

Dolby Digital Dynamic Range Control

Reset

Auto

English

Dolby Digital

Compressed

Done

To select the optical audio output format:

1 Press Y and open the Audio menu. 2 Highlight Audio Setup and press T.

4 To save the new settings, highlight Done and press T.

To revert to the factory defaults, highlight Reset and

press T.

Note:

• This item will be grayed out for NTSC signals, Video, ColorStream, and PC inputs.

• The Dolby Digital Dynamic Range Control will function in relation to Optical Output Format (PCM mode).

Using the Locks menu

Chapter 6: Using the TV’s features

When the correct PIN code is entered, the Locks menu opens.

The Locks menu includes the Enable Rating Blocking, Edit Rating Limits, Channels Block, Input Lock, Front (control) Panel Lock, Game Timer, and New PIN Code features. You can use these features after entering the correct PIN code.

Entering the PIN code

Press Y and highlight the Locks menu icon.

Locks

Enable Rating Blocking

Edit Rating Limits

Channels Block

Input Lock

Front Panel Lock

Game Timer

New PIN Code

Off

2 Press b, which displays the PIN code entry screen.

• The Lock System screen (below) appears if a PIN

code has not been stored. Press the Channel Number buttons to enter a new four-digit code, enter the code a

second time to confirm, and press T.

Lock System

Please enter a 4 digit PIN code

Confirm PIN code

Cancel Done

• The Locks/Active screen (below) appears if the PIN

code is already stored. Use the Number buttons to enter

your four-digit code and press T.

Locks Active

Please enter the 4 digit PIN code

****

Cancel

Done

Locks

Enable Rating Blocking

Edit Rating Limits

Channels Block

Input Lock

Front Panel Lock

Game Timer

New PIN Code

Off

If you cannot remember your PIN code

While the PIN code entering screen is displayed, press E four

times within five seconds. The PIN code will be cleared and you can enter a new PIN code.

Changing your PIN code

Press Y and highlight the Locks menu icon.

2 Press b to display the PIN code entering screen. 3 Enter your four-digit PIN code and press T. 4 Press b to highlight New PIN Code and press T.

Locks

Enable Rating Blocking

Edit Rating Limits

Channels Block

Input Lock

Front Panel Lock

Game Timer

New PIN Code

Off

5 Press the Number buttons to enter a new four-digit code.

Reenter the PIN code to confirm it.

6 Press T. The new PIN code is now active.

New PIN Code

Please enter a 4 digit PIN code

****

Confirm PIN code

****

If the wrong PIN code is entered, the message “Incorrect PIN code, please try again!” appears. Highlight Retry and press

T. Enter the code again and press T.

Cancel Done

Chapter 6: Using the TV’s features

Blocking TV programs and movies by rating (V-Chip)

Some TV programs and movies include signals that classify the content of the program (violence, sex, dialog, language). The V-Chip feature in this TV detects the signals and blocks the programs according to the ratings you select. (For rating descriptions, see the tables on the next page.)

Note: Rating blocking is a function of the V-Chip feature in this TV, which supports the U.S. V-Chip system only.

To block and unblock TV programs and movies:

1 Press Y and highlight the Locks menu icon. 2 Press b to display the PIN code entering screen. 3 Enter your four-digit PIN code and press T. 4 Press b to highlight Enable Rating Blocking. 5 Press c and b to select On, and then press T.

Locks

Enable Rating Blocking

Edit Rating Limits

Channels Block

Input Lock

Front Panel Lock

Game Timer

New PIN Code

Off

6 Press b to highlight Edit Rating Limits and press T.

The Edit Rating Limits screen (below) appears.

7 Press BbC c and then press T to select the level of

blocking you prefer. A box with an “5” is a rating that will be blocked. As you highlight a rating, a definition for the rating appears at the bottom of the screen.

8 When done selecting the ratings you want to block,

highlight Done and press T.

Edit Rating Limits

(V-CHIP) FV

D L S V

TV-Y

TV-Y7

TV-G

TV-PG

TV-14

TV-MA

"None" Rated

Movies

PG-13

NC-17

Children

Youth

Alt RS

Cancel

Done

Downloading an additional rating system for blocking TV programs and movies

In the future, an additional rating system may become available for use in selectively blocking programs.

Note: The currently tuned station must be receiving a digital signal before an additional rating system can be downloaded.

To download the additional rating system (if available):

The Edit Rating Limits screen appears.

7 Highlight Alt RS and press T. The Edit Alternate

Ratings screen will appear.

Note:

• The Alt RS button will only be available if an additional rating system is currently available.

• It may take several minutes for the TV to download the additional rating system.

• The information displayed in the Alternate Ratings screen will depend on the configuration of the additional rating system available at the time of download.

8 Press B b C c and then press T to select the level of

blocking you prefer. A box with an “5” is a rating that will be blocked.

9 When you are finished selecting the ratings you want to

block, highlight Done and press T.

10 In the Edit Rating Limits screen, highlight Done and

press T.

Note:

• The additional rating system can only be downloaded one time. You will not be able to download any updates to the rating system should such updates become available.

• The additional rating system is not designed, transmitted, or controlled by the TV or Toshiba, nor is the availability of an additional rating system determined or controlled by Toshiba. Similarly, the rating of programs in an additional rating system is not determined, transmitted, or controlled by the TV or Toshiba.

• The additional rating system is an evolving technology; therefore, availability, content, and format may vary.

Chapter 6: Using the TV’s features

Independent rating system for broadcasters Ratings Description and Content themes

Mature Audience Only (This program is specifically designed to be viewed by adults and therefore may

TV-MA

TV-14

TV-PG

TV-G

TV-Y7, TV-Y7FV

TV-Y

be unsuitable for children under 17.) L) Crude or indecent language S) Explicit sexual activity V) Graphic violence

Parents Strongly Cautioned (This program contains some material that many parents would find unsuitable for children under 14 years of age.)

Intensely suggestive dialog L) Strong, coarse

language violence

Parental Guidance Suggested (This program contains material parents may find unsuitable for younger children.)

language violence

General Audience (Most parents would find this program suitable for all ages.)

Directed to Older Children (This program is designed for children age 7 and above. Note: Programs in which fantasy violence may be more intense or more combative than other programs in this category are designated TV-Y7FV.)

All Children (This program is designed to be appropriate for all children.)

S) Intense sexual situations V) Intense

Some suggestive dialog L) Infrequent coarse

S) Some sexual situations V) Moderate

Independent rating system for movies Ratings Description and Content themes

X NC-17

PG-13

Note:

• If you place an “5” in the box next to “ ‘None’ Rated,”

programs rated “None” will be blocked; however, programs that do not provide any rating information will not be blocked.

• To display the rating of the program you are watching, press

X-rated (For adults only)

Not intended for anyone 17 and under

Restricted (Under 17 requires accompanying parent or adult)

Parents Strongly Cautioned (Some material may be inappropriate for children under 13)

Parental Guidance Suggested (Some material may not be suitable for children)

General Audience (Appropriate for all ages)

E on the remote control. If it is rated “None,” the word

“NONE” appears in the RECALL screen (as shown below right). If rating information is not provided, no rating will appear in the RECALL screen.

Blocking channels

With the Channels Block feature, you can block specific channels. You will not be able to tune blocked channels unless you unlock them.

To block channels:

1 Press Y and highlight the Locks menu icon. 2 Press b to display the PIN code entering screen. 3 Enter your four-digit PIN code and press T

(- page 60).

4 Press b to highlight Channels Block and then press T.

A list of the channels available for that input will be displayed along with the call letters for each channel, if available.

Locks

Enable Rating Blocking

Edit Rating Limits

Channels Block

Input Lock

Front Panel Lock

Game Timer

New PIN Code

Off

5 Press Bb to highlight the channel you want to block and

press T, which puts an “5” in the box next to that

channel.

Channels Block

Allow All

Block All

Cancel

Done

6 Repeat step 5 for other channels you want to block. 7 Highlight Done and press T.

To unblock individual channels:

In step 5 above, press Bb to highlight the channel you want to unblock, press T to remove the “5” from the box, highlight Done and press T.

TV - PG L V NONE

Chapter 6: Using the TV’s features

To block all channels at once:

Highlight Block All in step 5 on previous page and then

highlight Done and press T.

To unblock all locked channels at once:

Highlight Allow All in step 5 on previous page and then

highlight Done and press T.

Channels Block

Allow All

Block All

Cancel

Done

Unlocking programs temporarily

If you try to tune the TV to a program that exceeds the rating limits you set, the TV will enter program lock mode and the following message will appear on-screen:

This program exceeds the rating limit you set.

Push 'mute' to enter PIN.

Using the input lock feature

You can use the Input Lock feature to lock the video inputs (VIDEO 1, VIDEO 2, ColorStream HD-1, ColorStream HD-2, HDMI 1, HDMI 2, HDMI 3 and PC) and channels 3 and

4. You will not be able to view the input sources or channels

until you unlock the inputs.

To lock/unlock the video inputs:

1 Press Y and highlight the Locks menu icon. 2 Press b to display the PIN code entering screen. 3 Enter your four-digit PIN code and press T. 4 Press b to highlight Input Lock and press c. 5 Press B or b to select the level of video input locking you

prefer, as described below. Video: Locks VIDEO 1, VIDEO 2, ColorStream HD1/

HD2, HDMI 1, HDMI 2, HDMI 3, and PC. Video+: Locks VIDEO 1, VIDEO 2, ColorStream HD1/

HD2, HDMI 1, HDMI 2, HDMI 3, PC and channels 3 and

• Select Video+ if you play video tapes via an ANT

input.

You can either temporarily unlock the program or select an unlocked program to watch.

To temporarily unlock the program:

1 Press W. 2 Enter your four-digit PIN code and press T. If the correct

code is entered, the program lock mode is released and the normal picture appears. All locking is disabled until the TV is turned off, and will be enabled when the TV is turned on again.

Locks Active

Enter PIN code to temporarily unblock.

****

Cancel

Done

Locks

Enable Rating Blocking

Edit Rating Limits

Channels Block

Input Lock

Front Panel Lock

Game Timer

New PIN Code

Off

Video

Off

Video +

Off

Off: Unlocks all video inputs and channels 3 and 4.

6 Press T.

Chapter 6: Using the TV’s features

Using the GameTimer

You can use the GameTimer to set a time limit for playing a video game (30–120 minutes). When the GameTimer expires, the TV enters Input Lock mode and locks out the input source for the video game device.

To set the GameTimer®:

1 Press Y and highlight the Locks menu icon. 2 Press b to display the PIN code entering screen. 3 Enter your four-digit PIN code and press T. 4 Press b to highlight Game Timer and press c. 5 Press B or b to select the length of time until the Input

Lock is activated (30, 60, 90, or 120 minutes) and press

Locks

Enable Rating Blocking

Edit Rating Limits

Channels Block

Input Lock

Front Panel Lock

Game Timer

New PIN Code

To cancel the GameTimer®:

Select Off in step 5 above.

To deactivate the Input Lock once the GameTimer has activated it:

Set the Input Lock to Off (- “Using the input lock feature” on the previous page).

Note:

• A message will appear when 10 minutes, 3 minutes, and 1 minute remain on the GameTimer.

• If the TV loses power with time remaining on the GameTimer, when power is restored the TV will enter Input Lock mode (as if the GameTimer had been activated) and you will have to deactivate the Input Lock (as described above).

Off

30 min

60 min

90 min

120 min

Using the control panel lock feature

You can lock the control panel to prevent your settings from being changed accidentally (by children, for example). When the control panel lock is On, none of the controls on the TV control panel will operate except POWER.

To lock the control panel:

1 Press Y and highlight the Locks menu icon. 2 Press b to display the PIN code entering screen. 3 Enter your four-digit PIN code and press T. 4 Press b to highlight Front Panel Lock. 5 Press c and C or c to highlight On and press T. When

the control panel is locked and any button on the control panel (except POWER) is pressed, the message “Not Available” appears.

Locks

Enable Rating Blocking

Edit Rating Limits

Channels Block

Input Lock

Front Panel Lock

Game Timer

New PIN Code

To unlock the control panel:

Highlight Off in step 5 above, or press and hold the VOLUME – button on the TV control panel for about 10

seconds until the volume icon appears.

Off

Chapter 6: Using the TV’s features

Using the PC settings feature

You can view an image from a PC on the TV screen. When a PC is connected to the TV's PC IN terminal, you can

use the PC Settings feature to make adjustments to the image. If the edges of the picture are cut off, readjust the Horizontal

Position and Vertical Position. If the picture is affected by interference, readjust the Clock Phase and Sampling Clock.

To adjust the PC settings:

1 Repeatedly press + to select PC input mode

(- “Selecting the video input source to view” page 46).

2 Press Y and open the Setup menu. 3 Highlight PC Settings and press T.

Setup

Installation

CE-Link Setup

Sleep Timer

HDMI Settings

PC Settings

Blue LED Illumination High

Power-On Mode Power-Saving

Note: If a PC is not connected or there is no pc input signal, this feature will be grayed out in the Setup menu.

4 Press B or b to highlight the item you want to adjust. 5 Press C or c to make the appropriate adjustments.

PC Settings

Horizontal Position 0

Vertical Position

Clock Phase

Sampling Clock

Reset

Done

Setting the PC Audio

This function allows you to output the sound from your PC (if connected) or mute the sound from your PC and output the sound from your HDMI (DVI) connection. (- page 22)

To set the PC Audio:

1 Press Y and open the Audio menu. 2 Highlight Audio Setup and press T. 3 Press B or b to select PC Audio and then press C or c

to select No or Yes.

Yes: Outputs the sound from your PC. No: Mutes the sound from your PC, and outputs the

sound from the HDMI-1 connection.

Audio Setup

PC Audio No

HDMI 1 Audio

MTS Stereo

Language

Optical Output Format

Dolby Digital Dynamic Range Control

Reset

Auto

English

Dolby Digital

Compressed

Done

™

Audio mode”

Note: The screen is disrupted momentarily when adjusting the PC settings. This is not a sign of malfunction.

•

Horizontal Position:

Moves the picture left/right. The adjustment range is within ±10 from center.*

• Vertical Position:

Moves the picture up/down. The adjustment range is within ±10 from center.*

• Clock Phase:

Helps to reduce noise and sharpen the picture. The adjustment range is within ±4 from center.*

• Sampling Clock:

Helps to reduce noise and minimize periodic vertical stripes on the screen. The adjustment range is within ±5 from center.*

* The default settings may vary depending on the input signal format.

Chapter 6: Using the TV’s features

Setting the sleep timer

You can set the sleep timer to turn off the TV after a set length of time (maximum of 180 minutes).

To set the sleep timer using the remote control:

Press [ on the remote control to set the length of time until the TV turns off. Repeatedly press [ to increase the time in 10-minute increments, or press B or b to increase or decrease

the time in 10-minute increments, to a maximum of 180 minutes.

To set the sleep timer using the on-screen menus:

1 Press Y and open the Setup menu. 2 Highlight Sleep Timer and press T.

Setup

Installation

CE-Link Setup

Sleep Timer

HDMI Settings

PC Settings Blue LED Illumination High

Power-On Mode Power-Saving

3 Press the Number buttons to enter the length of time in

10-minute increments.

Sleep Timer

Enter total minutes until the TV

turns off automatically (Maximum

180 minutes)

120

Cancel Done

Using CE-Link

This is a new feature that uses CEC technology and allows you to control Toshiba CE-Link compatible devices from the TV remote via HDMI connection (- page 20).

When the Enable CE-Link item in the CE-Link setup menu (- page 68) is set to On, individual CE-Link functions also set to On will be activated.

CE-Link playback device (HD DVD player, etc.) control

With your TV’s remote control, or using the CE-Link Control menu, you can control the connected CE-Link playback device you are watching.

Available remote control key functions:

Before using the following key functions, first select the TV mode by pressing the TV mode select button until the keypad blinks 3 times.

• S begins playback.

• D stops playback.

• A pauses the picture during play or record mode.

• G skips forward.

• F skips backward.

• J fast-forwards.

• H rewinds/reverses.

• B b C c navigate the Contents Menu, etc.

• T enters the Contents Menu, etc.

• O returns to the previous menu.

Note: These functions depend on the devices connected.

4 Highlight Done and press T.

Note: When a power failure occurs, the sleep timer setting may be cleared.

To display the remaining sleep time:

Press [.

Sleep Timer

120 minutes

Note: A message will display on-screen when there is one minute remaining on the sleep timer.

To cancel the sleep timer:

Repeatedly press [ until it is set to 0 minute.

Chapter 6: Using the TV’s features

CE-Link Player Control menu functions:

1 Press C and open the THINC Applications menu. 2 Press B or b to highlight CE-Link Player Control and

press T.

THINC Applications

CE-Link Player Control

Channel Browser

Favorites Browser

3 Press B or b to select the item you want to control and

press T.

CE-Link Player Control

Recorder

Top Menu

Contents Menu

Navigate Select Exit

ENTER

Power

EXIT

– POWER turns the selected device on and off. – Top Menu accesses the top menu of a DVD. – Menu accesses the menu of a DVD. – Contents Menu accesses the contents list when you

press T. At this time, the CE-Link Player Control

menu will disappear.

Note:

• These functions depend on the devices that are connected.

• The CE-Link Player Control item will be grayed out in the

following conditions:

- A non-HDMI input is currently selected.

- The Enable CE-Link item is set to Off.

- The connected device is not a playback or recording

device.

CE-Link input source selection

If a CE-Link device with HDMI switching capability (e.g. Audio Receiver) is connected to the HDMI input, you can select another CE-Link device that is connected to the master HDMI device using the TV’s INPUT button. See page 46 for details.

Audio Receiver VOLUME and MUTE control

With your TV’s remote control, you can adjust or mute the sound volume of the speakers connected to the TV via an audio receiver. First, select TV mode by pressing MODE SELECT on the remote control.

• z Z adjust the volume level.

• W turns off the sound.

Note:

• To use this function:

- Set Speakers preference to Audio Receiver in the

CE-Link Setup menu.

- Confirm that a connected CE-Link device (such as HD DVD player, etc) is selected for the Audio Receiver input source.

• You can also use this function when the audio receiver is connected to the TV’s DIGITAL AUDIO OUT terminal (not HDMI connection). In this case, select a digital audio input mode on the Audio Receiver.

• These functions depend on the device connected.

Other CE-Link functions

When the Enable CE-Link is set to On, the following functions can be enabled by setting them to On.

• TV Auto Input Switch

If a connected HDMI device starts playing video or audio, the TV will automatically switch to the appropriate HDMI input.

• TV Auto Power

If a CE-Link device is turned on or off, the TV turns on or off automatically.

• Device Auto Standby

If the TV is turned off the TV will send a message to turn off all of the CE-Link devices connected to the TV.

• Speaker Preference

From this item, you can set your audio output preference to the TV speakers or the audio receiver speakers. When this item is set to Audio Receiver, the TV remote can be used to adjust or mute the volume of the audio. This item will be grayed out unless a CE-Link compatible audio receiver is connected.

Note: When you turn on the Audio Receiver, change its input source, or adjust the sound volume, the sound will be output from the audio receiver’s speakers even if the TV Speakers has been selected. Turn the TV off and on again to output the sound from the TV Speakers.

(continued)

Chapter 6: Using the TV’s features

To set the CE-Link Setup:

1 Press Y and open the Setup menu. 2 Highlight CE-Link Setup and press T.

Setup

Installation

CE-Link Setup

Sleep Timer

HDMI Settings

PC Settings Blue LED Illumination High

Power-On Mode Power-Saving

3 Press B or b to highlight Enable CE-Link.

CE-Link Setup

Enable CE-Link On

TV Auto Input Switch

TV Auto Power Off

Device Auto Standby

Speaker Preference

Reset

TV Speakers

Done

4 Press C or c to select On.

Note: If you set Enable CE-Link to Off, the all other items will be grayed out.

5 Press B or b to highlight the CE-Link setup item you

want to use, and press C or c to select On/Off or the desired speakers mode.

• TV Auto Input Switch: On/Off

• TV Auto Power: On/Off

• Device Auto Standby: On/Off

• Speaker Preference: TV Speakers/Audio Receiver (See

details on the previous page.)

CE-Link Setup

Enable CE-Link On

TV Auto Input Switch

TV Auto Power Off

Device Auto Standby

Speaker Preference

Reset

TV Speakers

Done

Using the HDMI settings feature

This menu consists of the 2 items shown below (new HDMI capabilities) and will be grayed out on non-HDMI inputs.

Some HDMI legacy sources may not work properly with your HDMI TV. If you experience any problems, please try setting the following options (Lip-Sync Latency and xvYCC) to Off. Adjusting these settings should allow your HDMI legacy source to operate properly with your TV.

• Lip-Sync Latency: On

This option activates an audio/video display timing adjustment function that allows HDMI source devices to accurately perform synchronization automatically.

• xvYCC: On

This feature expands the color range of HDMI signals, allowing input of wider color signals from an HDMI sources.

The HDMI features require proper HDMI source devices. If your HDMI source device does not support these features, activating them on the TV will not have any effect.

Note: If your HDMI connection is capable of 1080p and/or your TV is capable of refresh rates greater than 60Hz, you will need a Category 2 cable. A conventional HDMI/DVI cable may not work properly with these settings.

To set the HDMI Settings:

1 Select the appropriate HDMI input (HDMI 1, HDMI 2, or

HDMI 3).

2 Press Y and open the Setup menu. 3 Highlight HDMI Settings and press T. 4 Press B or b to highlight the item you want to set.

HDMI Settings HDMI 1

Lip-Sync Latency On

xvYCC On

Please unplug your HDMI cable first! Once you have changed On/Off settings, please press Done and wait for changes completed message.

Warning: DO NOT TURN OFF OR UNPLUG THE TV UNTIL COMPLETED MESSAGE IS DISPLAYED!!

6 To save the new settings, highlight Done and press T.

To revert to the factory defaults, highlight Reset and

press T.

Reset

Done

5 Press C or c to select On or Off . 6 To save the new settings, highlight Done and press T.

To revert to the factory defaults, highlight Reset and

press T.

Chapter 6: Using the TV’s features

Displaying TV status information

To display TV status information using RECALL:

Press E on the remote control.

The following information will display (if applicable):

• Current input (ANT, VIDEO 1, etc.)

• If ANT is the current input, either “CABLE” (for cable TV)

or “ANT” (for over-the-air broadcasts).

• Channel number (if in ANT mode)

• Channel label (if set)

• Digital signal strength indicator (bar graph in lower right

corner of box; for ATSC signal only)

• Stereo, Mono or SAP audio status (when HDMI input mode,

Dolby Digital or PCM)

• Video resolution

• Aspect ratio of incoming video signal (4:3 or 16:9)

• V-Chip rating status

• GameTimer (if set)

• xvYCC status of incoming signal

ANT

123-456

ABCHD

: 120min

Stereo SAP

16:9

xvYCC TV-PG L V1080i

9:00pm

Understanding the auto power off feature

The TV will automatically turn itself off after approximately 15 minutes if it is tuned to a vacant channel or a station that completes its broadcast for the day. This feature functions in ANT mode only.

Understanding the last mode memory feature

If the power is cut off while you are viewing the TV, the Last Mode Memory feature automatically turns on the TV when the power is resupplied.

Note: You should unplug the TV’s power cord if it is possible that you will be away from the TV for an extended period of time after the power is restored.

To close the RECALL screen:

Press E again.

To display TV status information using INFO:

Press Q on the remote control.

The following additional information will display for off air digital channels (if applicable):

• Title

• Duration

• Detailed description

ANT

123-456

ABCHD

: 120min

Stereo SAP

MLB Young,s XXX...

Today,s Major League Baseball.

Note: The location of the banner can be moved to the top or bottom of the screen by pressing B or b while the RECALL or INFO display is on-screen. (The last position will be stored to memory.)

1080i

16:9

xvYCC TV-PG L V

East 9:00pm -11:00pm

Chapter 7: Using the TV’s advanced features

Using the advanced picture settings features

Using dynamic contrast

When dynamic contrast is set to Low, Middle, or High, the TV will detect changes in the picture quality that affect the appearance of your contrast settings and then automatically adjust the video.

To select dynamic contrast preferences:

1 Press Y and open the Video menu. 2 Highlight Picture Settings and press T.

Video

Mode

Picture Settings

Noise Reduction

ColorMaster

xvYCC Selection

Game Mode Theater Settings

TheaterLock

3 Highlight Advanced Picture Settings and press T.

Picture Settings

Contrast 100

Back Light 100

DynaLight

Brightness

Color

Tint

Advanced Picture Settings

4 In the Dynamic Contrast field, select either Off, Low,

Middle or High.

Advanced Picture Settings Mode: Preference

Dynamic Contrast

Static Gamma

Color Temperature

5 To save the new settings, highlight Done and press T.

To revert to the factory defaults, highlight Reset and

press T.

Note: If you select one of the factory-set picture modes (Sports, Standard, Movie, or Document) and then change the dynamic contrast setting, the picture mode automatically changes to Preference.

Reset

Sports

Auto

Off

50Sharpness

Mode: Sports

Done

Off

Cool

Done

Using the static gamma feature

The static gamma feature allows you to adjust the levels of black in the picture.

To adjust the static gamma settings:

1 Press Y and open the Video menu. 2 Highlight Picture Settings and press T.

Video

Mode

Picture Settings

Noise Reduction

ColorMaster

xvYCC Selection

Game Mode Theater Settings

TheaterLock

Sports

Auto

Off

3 Highlight Advanced Picture Settings and press T.

Picture Settings

Contrast 100

Back Light 100

DynaLight

Brightness

Color

Tint

Advanced Picture Settings

Reset

50Sharpness

Mode: Sports

Done

4 In the Static Gamma field, press C or c to adjust the

static gamma. The adjustment range is within ±5 from center.

Advanced Picture Settings Mode: Preference

Dynamic Contrast

Static Gamma

Color Temperature

Reset

High

Cool

Done

• If the setting is moved in the minus direction, the detail

of black colors will be decreased.

• If the setting is moved in the plus direction, the detail of

black colors will be increased.

5 To save the new settings, highlight Done and press T.

To revert the factory defaults, highlight Reset and

press T.

Note: If you select one of the factory-set picture modes (Sports, Standard, Movie, or Document) and then change the static gamma setting, the picture mode automatically changes to Preference.

Chapter 7: Using the TV’s advanced features

Selecting the color temperature

You can change the quality of the picture by selecting from three preset color temperatures (Cool, Medium, and Warm), as described below.

Mode Picture Quality

Cool blueish

Medium neutral

Warm reddish

To select the color temperature:

1 Press Y and open the Video menu. 2 Highlight Picture Settings and press T. 3 Highlight Advanced Picture Settings and press T. 4 Highlight Color Temperature and press T.

Advanced Picture Settings Mode: Preference

Dynamic Contrast

Static Gamma

Color Temperature

Reset

High

Cool

Done

5 In the Color Temperature field, select the mode you

prefer (Cool, Medium, or Warm).

Color Temperature Mode: Preference

Color Temperature

B Drive

G Drive

Reset

Cool

Done

6 Press B or b to select either B Drive or G Drive, and

then press C or c to adjust the settings.

B Drive

G Drive

• B Drive: c makes the picture blueish.

• G Drive: c makes the picture greenish.

Note: The B Drive and G Drive settings are connected to the Color Temperature settings and will change based on which setting is selected in step 5 above.

7 To save the new settings, highlight Done and press T.

To revert to the factory defaults, highlight Reset and

press T.

Note: If you select one of the factory-set picture modes (Sports, Standard, Movie, or Document) and then change the color temperature mode, the picture mode automatically changes to Preference.

Using CableClear® digital noise reduction

The CableClear® digital noise reduction feature allows you to reduce visible interference in your TV picture. This may be useful when receiving a broadcast with a weak signal (especially a Cable channel) or playing a noisy video cassette or disc.

To change the CableClear settings:

1 Press Y and open the Video menu. 2 Highlight Noise Reduction and press T.

Video

Mode

Picture Settings

Noise Reduction

ColorMaster

xvYCC Selection

Game Mode Theater Settings

TheaterLock

Sports

Auto

Off

3 In the CableClear field, select your desired setting.

Noise Reduction ANT

CableClear

MPEG Noise Reduction

Reset

Done

Auto

Low

Note:

• If the current input is ANT, VIDEO 1, or VIDEO 2, the menu will display the text “CableClear.” The available selections are Off, Auto, Low, Middle, and High.

• If the current input is ColorStream HD1, ColorStream HD2, HDMI 1, HDMI 2, or HDMI 3, the menu will display the text “DNR.” The available selections are Off, Auto, Low, Middle, and High. Auto will react proportionally

to the strength of the noise. Low, Middle, and High will reduce the noise in varying degrees, from lowest to highest, respectively.

4 To save the new settings, highlight Done and press T.

To revert to the factory defaults, highlight Reset and

press T.

Chapter 7: Using the TV’s advanced features

Using MPEG noise reduction

The MPEG noise reduction feature allows you to reduce visible interference caused by MPEG compression. Choices for MPEG noise reduction are Off, Low, Middle, and High. Off is automatically selected when this feature is disabled (“grayed out”).

To select the MPEG noise reduction level:

1 Press Y and open the Video menu. 2 Highlight Noise Reduction and press T. 3 Press B or b to highlight the MPEG Noise Reduction

field, and then press C or c to select either Off, Low, Middle or High.

Noise Reduction ANT

CableClear

MPEG Noise Reduction

Reset

Done

Auto

Low

4 To save the new settings, highlight Done and press T.

To revert to the factory defaults, highlight Reset and

press T.

Using the ColorMaster™ feature

The ColorMaster feature allows you to adjust standard colors. The menu will consist of 3 items: ColorMaster, Color Palette Adjustment, and Reset.

To turn on ColorMaster:

1 Press Y and open the Video menu. 2 Highlight ColorMaster and press T.

Video

Mode

Picture Settings

Noise Reduction

ColorMaster

xvYCC Selection

Game Mode Theater Settings

TheaterLock

Sports

Auto

Off

3 In the ColorMaster field, select On.

ColorMaster

Color Palette Adjustment

Reset

Note: If you select one of the factory-set picture modes (Sports, Standard, Movie, or Document) and then change the ColorMaster setting, the picture mode automatically changes to Preference.

ANT

To turn off ColorMaster:

Select Off in Step 3 above.

Using Color Palette Adjustment

When color palette adjustment is selected, the list of base colors will be displayed. You can select a base color to adjust.

Note: To use Color Palette Adjustment, ColorMaster must be set to On.

To adjust the Base Colors:

1 From the ColorMaster menu, highlight Color Palette

Adjustment and press T.

ColorMaster

Color Palette Adjustment

Reset

ANT

Chapter 7: Using the TV’s advanced features

2 The Select Standard Color window will be displayed.

Press B or b to highlight the color you want to adjust, and then press T.

Select Standard Color

Base Colors

Red

Green

Blue

Yellow

Magenta

Cyan

3 The Color Adjustment window will be displayed.

Press B to freeze the picture. To return to moving picture, press B again.

Color Adjustment

Red

Hue

Saturation

Brightness

Reset

4 Press B or b to select either Hue, Saturation, or

Brightness, and then press C and c to adjust the setting.

Note: To revert to the factory settings of the Hue, Saturation, and Brightness for the selected color,

Highlight Reset and press T.

5 Press R to return to the previous menu. 6 Repeat steps 2 through 5 to adjust any other color.

Using the xvYCC Selection feature

The color range “xvYCC” is an international standard and enables a wider color range than conventional video applications.

If the xvYCC Selection is set to Auto, your TV will automatically detect images supported by xvYCC.

Note: If a non-HDMI input is selected or the xvYCC setting in the HDMI Settings menu is set to Off, this feature will appear grayed out in the Video menu.

To change the xvYCC Selection:

1 Press Y, and open the Video menu. 2 Press B or b to highlight xvYCC Selection, and then

press C or c to select the settings you prefer (Auto, On or Off).

Video

Mode

Picture Settings

Noise Reduction

ColorMaster

xvYCC Selection

Game Mode Theater Settings

TheaterLock

Sports

Auto

Off

To reset ColorMaster to its factory settings:

1 From the ColorMaster menu, highlight Reset, and then

press T.

ColorMaster

Color Palette Adjustment

Reset

ANT

2 A confirmation message will appear. Highlight OK, and

then press T.

Are you sure?

OKCancel

3 Press O.

Chapter 7: Using the TV’s advanced features

Using the Game Mode feature

You can use the Game Mode feature for shorter frame delays when playing a video game requiring split-second timing between the on-screen display and input from the controller (such as music creation and high-action games).

This feature is more effective for 480i and 1080i input signals.

Note: To use the Game Mode feature, the current video input must be Video 1, Video 2, ColorStream HD1, ColorStream HD2, HDMI 1, HDMI 2, HDMI 3 or PC. The Game Mode cannot be turned on when any other video input is selected.

To turn on Game Mode:

1 Press Y and open the Video menu. 2 Press B or b to highlight the Game Mode field, and then

press C or c to select On.

Video

Mode

Picture Settings

Noise Reduction

ColorMaster

xvYCC Selection

Game Mode

Theater Settings

TheaterLock

To turn off Game Mode:

Select Off in step 2 above, change the video input, or turn the TV off and then on again.

Note:

• You can change the video input by pressing + on the

remote control (- page 46).

• The Game Mode feature does not function if the following signals are received.

– PC IN terminal: VGA 72Hz/75Hz

SVGA 72Hz/75Hz XGA 70Hz/75Hz WXGA 75Hz

– HDMI terminal: 1080p 24Hz/30Hz

VGA 72Hz/75Hz SVGA 72Hz/75Hz XGA 70Hz/75Hz WXGA 75Hz

Sports

Auto

Off

Using the advanced audio settings features

Using the SRS WOW™ surround sound feature

SRS WOW™ is a special combination of SRS Labs audio technologies (SRS 3D, SRS Focus, and SRS TruBass) that creates a thrilling surround sound experience with deep, rich bass from stereo sound sources. Your TV’s audio will sound fuller, richer, and wider.

To adjust the WOW™ settings:

1 Put the TV in STEREO mode (- “Selecting stereo/SAP

broadcasts” on page 58).

2 Press Y and open the Audio menu. 3 Highlight Advanced Audio Settings and press T. 4 Press b or B to highlight the WOW feature you want to

adjust, and then press C or c to adjust the item.

Advanced Audio Settings

WOW: SRS 3D

WOW: SRS Focus

WOW: SRS TruBass Low

Reset

• WOW: SRS 3D — To turn the surround sound effect

On or Off.

Note: If the broadcast is monaural, the SRS 3D effect will not work.

•

WOW: SRS Focus — To turn the vocal emphasis effect On or Off.

• WOW: SRS TruBass — To select the desired bass

expansion level (Off, Low, or High).

5 To save the new settings, highlight Done and press T.

To revert to the factory defaults, highlight Reset and

press T.

WOW, SRS and l symbol are trademarks of SRS Labs, Inc. WOW technology is incorporated under license from SRS Labs, Inc.

Off

Done

Chapter 8: Troubleshooting

General troubleshooting

Before calling a service technician, please check this chapter for a possible cause of the problem and some solutions you can try.

Black box on-screen

• The closed caption feature is set to one of the Text modes

(T1, T2, T3, or T4). Set the closed caption feature to Off (- page 56).

TV stops responding to controls

• If the TV stops responding to the controls on the remote

control or TV control panel and you cannot turn off the TV, press and hold the POWER button on the TV control panel for 5 or more seconds to reset the TV.

Toshiba 46RF350, 40RF350 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
