Toshiba 32W301PS Schematic

(*1) GREEN PRODUCT PROCUREMENT

The EC is actively promoting the WEEE & RoHS Directives that define standards for recycling and reuse of Waste Electrical and Electronic Equipment and for the Restriction of the use of certain Hazardous Substances. From July 1, 2006, the RoHS Directive will prohibit any marketing of new products containing the restricted substances.

Increasing attention is given to issues related to the global environmental. Toshiba Corporation recognizes environmental protection as a key management tasks, and is doing its utmost to enhance and improve the quality and scope of its environmental activities. In line with this, Toshiba proactively promotes Green Procurement, and seeks to purchase and use products, parts and materials that have low environmental impacts.

Green procurement of parts is not only confined to manufacture. The same green parts used in manufacture must also be used as replacement parts.

(*2) LEAD-FREE SOLDER

This product is manufactured using lead-free solder as a part of a movement within the consumer products industry at large to be environmentally responsible. Lead-free solder must be used in the servicing and repair of this product.

WARNING

This product is manufactured using lead free solder .

DO NOT USE LEAD BASED SOLDER TO REPAIR THIS PRODUCT !

The melting temperature of lead-free solder is higher than that of leaded solder by 86°F to 104°F (30°C to 40°C). Use of a soldering iron designed for lead-based solders to repair product made with lead-free solder may result in damage to the component and or PCB being soldered. Great care should be made to ensure high-quality soldering when servicing this product  especially when soldering large components, through-hole pins, and on PCBs  as the level of heat required to melt lead-free solder is high.

A1-1

SERVICING NOTICES ON CHECKING

1. KEEP THE NOTICES

As for the places which need special attentions, they are indicated with the labels or seals on the cabinet, chassis and parts. Make sure to keep the indications and notices in the operation manual.

2. AVOID AN ELECTRIC SHOCK

There is a high voltage part inside. Avoid an electric shock while the electric current is flowing.

3. USE THE DESIGNATED PARTS

The parts in this equipment have the specific characters of incombustibility and withstand voltage for safety. Therefore, the part which is replaced should be used the part which has the same character. Especially as to the important parts for safety which is indicated in the circuit diagram or the table of parts as a mark, the designated parts must be used.

4. PUT PARTS AND WIRES IN THE ORIGINAL POSITION AFTER ASSEMBLING OR WIRING

There are parts which use the insulation material such as a tube or tape for safety, or which are assembled in the condition that these do not contact with the printed board. The inside wiring is designed not to get closer to the pyrogenic parts and high voltage parts. Therefore, put these parts in the original positions.

5. TAKE CARE TO DEAL WITH THE CATHODE-RAY TUBE

In the condition that an explosion-proof cathoderay tube is set in this equipment, safety is secured against implosion. However, when removing it or serving from backward, it is dangerous to give a shock. Take enough care to deal with it.

PERFORM A SAFETY CHECK AFTER

6. SERVICING

Confirm that the screws, parts and wiring which were removed in order to service are put in the original positions, or whether there are the portions which are deteriorated around the serviced places serviced or not. Check the insulation between the antenna terminal or external metal and the AC cord plug blades. And be sure the safety of that.

(INSULATION CHECK PROCEDURE)

Unplug the plug from the AC outlet.

Remove the antenna terminal on TV and turn on the TV.

Insulation resistance between the cord plug terminals and the eternal exposure metal [Note 2] should be more than 1M ohm by using the 500V insulation resistance meter [Note 1].

If the insulation resistance is less than 1M ohm, the inspection repair should be required.

[Note 1]

If you have not the 500V insulation resistance meter, use a Tester.

[Note 2]

External exposure metal:

Antenna terminal Headphone jack

HOW TO ORDER PARTS

Please include the following informations when you order parts. (Particularly the VERSION LETTER.)

1. MODEL NUMBER and VERSION LETTER The MODEL NUMBER can be found on the back of each product and the VERSION LETTER can be

found at the end of the SERIAL NUMBER.

2. PART NO. and DESCRIPTION You can find it in your SERVICE MANUAL.

IMPORTANT

When you exchange IC and Transistor with a heat sink, apply silicon grease on the contact section of the heat sink. Befor applying new silicon grease, remove all the old silicon grease. (Old grease may cause damages to the IC and Transistor.)

A1-2

TABLE OF CONTENTS

GREEN PRODUCT PROCUREMENT ........................................................................................

LEAD-FREE SOLDER ................................................................................................................

SERVICING NOTICES ON CHECKING.....................................................................................

HOW TO ORDER PARTS ..........................................................................................................

IMPORTANT ...............................................................................................................................

TABLE OF CONTENTS..............................................................................................................

GENERAL SPECIFICATIONS ...................................................................................................

DISASSEMBLY INSTRUCTIONS ............................................................................................

SERVICE MODE LIST ................................................................................................................

WHEN REPLACING EEPROM (MEMORY) IC ..........................................................................

ELECTRICAL ADJUSTMENTS..................................................................................................

BLOCK DIAGRAMS

MAIN ........................................................................................................................................

POWER ...................................................................................................................................

PRINTED CIRCUIT BOARDS

MAIN ........................................................................................................................................

POWER/OPERATION/REMOCON .........................................................................................

SCHEMATIC DIAGRAMS

21 PIN ......................................................................................................................................

POWER 3 ................................................................................................................................

REGULATOR...........................................................................................................................

AV JACK/SWITCH...................................................................................................................

SOUND AMP/HEADPHONE AMP ..........................................................................................

TUNER.....................................................................................................................................

SCALER...................................................................................................................................

SUB MICON/RS-232C ............................................................................................................

JACK ........................................................................................................................................

PANEL INTERFACE................................................................................................................

INTERFACE_HDMI IC ............................................................................................................

POWER 1 ................................................................................................................................

POWER 2 ................................................................................................................................

OPERATION/REMOCON ........................................................................................................

INTERCONNECTION..................................................................................................................

WAVEFORMS .............................................................................................................................

MECHANICAL EXPLODED VIEWS...........................................................................................

MECHANICAL REPLACEMENT PARTS LIST .........................................................................

ELECTRICAL REPLACEMENT PARTS LIST...........................................................................

A1-1 A1-1 A1-2 A1-2 A1-2 A2-1 A3-1~A3-5 B-1, B-2 C-1 C-2 D-1~D-7

E-1, E-2 E-3, E-4

F-1~F-4 F-5~F-8

G-1, G-2 G-3, G-4 G-5, G-6 G-7, G-8 G-9, G-10 G-11, G-12 G-13, G-14 G-15, G-16 G-17, G-18 G-19, G-20 G-21, G-22 G-23, G-24 G-25, G-26 G-27, G-28 G-29, G-30 H-1, H-2 I-1~I-3 J1-1, J1-2 J2-1~J2-17

A2-1

GENERAL SPECIFICATIONS

5oC

0oC

60oC

G-1 TV LCD LCD Size / Visual Size 31.51 inch / 800.4mmV

G-2 Tuning Broadcasting System

G-3 Power Power Source AC 220-240V AC 50Hz/60Hz

G-4 Regulation Safety CE(EN60065:2002)

G-5 Temperature Operation

G-6 Operating Humidity Less than 80% RH G-7 OSD Language English, Spanish, German, French, Italian,

G-8 Clock and Sleep Timer Max Time 120 Min

System LCD Type Color TFT LCD

Color System PAL / SECAM Speaker 2 Speaker

Sound Output MAX 10W + 10W

NTSC3.58+4.43 /PAL60Hz Yes

System Tuner and System 1Tuner

Receive CH Destination UK, I.R., CCIR Hyper+France CATV

Intermediate Frequency Picture(FP) 38.9 / 38.9 / 38.9 / 33.9MHz

Auto Tuning Method Preset CH 99 Stereo/Dual TV Sound Nicam/A2 Dual Tuner Sound Muting Yes

Power Consumption at AC 150 W at AC 230 V 50 Hz

Protector Power Fuse Yes

Timer Step 10 Min

On/Off Timer Program(On Timer / Off Timer) -- Program Wake Up Timer No Timer Back-up (at Power Off Mode) more than -- Min Sec

Number of Pixels 1366(H) x 768(V)

View Range Left/Right 89/89 degree

Position Front Size 2.2 x 5.0 inch Impedance 4 ohm

10%(Typical) ---

CH Coverage IreE2~E4, X~Z+2, S1~S10, E5~E12,S11~S41,E21~E69

Sound(FS) FP-FS

DC ---

Stand by (at AC) 1 W at 230V 50Hz Per Year -- kWh/Year

Radiation CE X-Radiation ---

Storage

Up/Down 89/89 degree

U.K., I.R., CCIR, FRENCH System B/G, D/K, I/I, L

BG / II / DK, L / L' (SECAM VL)

33.4 / 32.9 / 32.4 / 40.4MHz

5.5 / 6.0 / 6.5 / 6.5MHz ALL Band (Not C.C.I.R. CH Plan)

at DC --

~ +4

-2

~ +

Swedish, Dutch, Russian, Portuguese, Turkish, Greek, Finnish, Polish

A3-1

GENERAL SPECIFICATIONS

G-9 Remote Unit RC-NZ

Control Glow in Dark Remocon Yes

Remocon Format TOSHIBA Format NEC Custom Code 40-BF h Power Source Voltage(D.C) 3V

Total Keys 33 Keys Keys Power (Stand By) Yes

T'TEXT Keys TEXT / TAP / TV Yes

UM size x pcs UM-3 x 2 pcs

Display / (Status) Yes Input Select Yes Picture Size Yes 1 Yes 2 Yes 3 Yes 4 Yes 5 Yes 6 Yes 7 Yes 8 Yes 9 Yes 0 Yes Sleep Yes Mute Yes Volume Up / Right Volume Down / Left CH Down No CH Up No Menu Yes

Up Down Left Right

Enter Yes Exit Yes Freeze frame No

Reveal / Skip No Reveal Yes Display Cancel No HOLD / Freeze Yes Red Yes Green Yes Yellow Yes Cyan Yes Normal No F/T/B(Expand) Yes F/T/B(Expand) / Normal No Quick View No Sub Page / Quick View Yes Up/CH Up No Up / CH Up / Page Up Down / CH Down No Down / CH Down / Page Down Reset No Audio 1/2 Yes Reset / Audio 1/2 No

Yes Yes

Yes

No No No No

A3-2

GENERAL SPECIFICATIONS

G-10 Features Power On Memory Yes

Auto Shut Off Yes Just Clock Function No Game Position No DNR Yes

Comb Filter Yes

Auto Set Up (Fast installation) Auto tuning (Analog tuner) Yes

Auto clock (Analog tuner) No

Picture Setting(TV) Picture Preference Yes

Picture Setting(PC) BRIGHTNESS , CONTRAST Yes

Audio Nicam Yes

Tuning Auto Tuning Yes

Lock (Analog) Panel Lock No

Screen Saver

Black Side Panel No CH Label Yes T'Text Yes

Wide Mode (AUTO/4:3/FULL SCREEN/16:9/CINEMA/14:9) Yes HD Zoom Picture Scroll (Vertical Position) Yes PFC(Power Factor circuit) Yes Freeze frame Yes (w/o720p, 1080i) HD-Ready Yes Plug and Play No Reset TV Setting Yes Scart Spec Scart1 AV in Yes

Scart2 AV in Yes

Plug in start Yes

Brightness , Contrast , Color Yes Tint Yes Sharpness Yes DNR Yes Color Temperature Yes Blue Back Yes Backlight Control Yes Film Mode No

HOR POSITION , VER POSITION Yes PHASE , CLOCK Yes AUTO ADJUST No RED , GREEN , BLUE Yes Backlight Yes WXGA INPUT Yes WVGA INPUT No

Tone Control (Bass/Treble/Balance) Yes Surround Yes BBE No SRS WOW (SRS 3D/Focus/Tru Bass) No Variable Audio Out Yes

Manual Tuning Yes CH Allocation Yes

Channel Lock No Hotel Lock No Inversion No Full White No Screen Saver No Static Image No

Text type Fastext / Toptext Text Language English , French, Swedish, Hungarian

AV out Yes (Tuner) S-Video in Yes RGB in Yes

AV out Yes (Monitor) S-Video in Yes RGB in Yes

CH sort Yes

ATS Yes

Turkish, German, Portuguese, Spanish, Italian, Greek, Slovakian, Russian, Polish, Czech, Rumanian, Estonian, Lettish, Lithuanian, Ukrainian, Croatian, Slovenian, Latvian

A3-3

GENERAL SPECIFICATIONS

PC Monitor Input Yes

HDMI Input Yes (Ver. 1.2)

Component Input Yes

G-11 Accessories Owner's Manual Language English/French/Italy/Spanish/German/

Remote Control Unit Yes Rod Antenna

Loop Antenna (W/ Antenna Change Plug)

U/V Mixer DC Car Cord (Center+) Guarantee Card Warning Sheet Circuit Diagram Antenna Change Plug Service Facility List Important Safeguard Quick Set-up Sheet Battery Yes

AC Adapter AC Cord (for AC Adapter) AC Cord Yes AV Cord (2Pin-1Pin) HDMI-DVI Cable Registration Card 300 ohm to 75 ohm Antenna Adapter

VGA (640x480) Yes (60Hz) VGA (720x400) Yes (70Hz) WVGA (848x480) No SVGA (800x600) Yes (60Hz) XGA (1024x768) Yes (60Hz) WXGA (1280x768) Yes (60Hz) WXGA (1280x720) Yes (60Hz) WXGA (1360x768) Yes (60Hz) SXGA (1280x1024) No

VGA (640x480) 720x480i (4:3) 720x480i (16:9) 720x480p (4:3) 720x480p (16:9) 720x576i (4:3) 720x576i (16:9) 720x576p (4:3) 720x576p (16:9) 1280x720p 1920x1080i

720x480i (4:3) 720x480i (16:9) 720x480p (4:3) 720x480p (16:9) 720x576i (4:3) 720x576i (16:9) 720x576p (4:3) 720x576p (16:9) 1280x720p 1920x1080i

w/Guarantee Card

Poles Terminal -

Terminal -

UM size x pcs UM-3 x 2 pcs OEM Brand No

Yes (60Hz) Yes (60Hz) Yes (60Hz) Yes (60Hz) Yes (60Hz) Yes (50Hz) Yes (50Hz) Yes (50Hz) Yes (50Hz) Yes (50/60Hz) Yes (50/60Hz)

Yes (60Hz) Yes (60Hz) Yes (60Hz) Yes (60Hz) Yes (50Hz) Yes (50Hz) Yes (50Hz) Yes (50Hz) Yes (50/60Hz) Yes (50/60Hz)

Polish/Turkish/Greek/Dutch

No No No No No No No No No

No No

No No No No

A3-4

GENERAL SPECIFICATIONS

G-12 Interface Switch Power (Tact) Yes

Indicator Power/Stand-by Yes(GREEN / RED)

Terminals Side Video Input 1

G-13 Set Size Approx. W x D x H (mm) 822 x 332.5 x 604

G-14 Weight Net Approx. 18.5kg (40.8 lbs)

G-15 Carton Master Carton

Gift Box Yes

Drop Test Natural Dropping At 2 Corner / 2 Edges / 1 Surfaces

Container Stuffing 201

G-16 Material Cabinet Cabinet Front PS 94V0 NON-DECABROM

PCB Non-Halogen

G-17 Environment Environmental standard requirement Green procurement of TOSHIBA

Pb- Free Phase3(PHASE3A)

WEEE Yes

System Select No Main Power SW No Channel Up/Menu Up Yes Channel Down/Menu Down Yes Volume Up/Menu > Yes Volume Down/Menu < Yes Input Select/Enter Yes Menu Yes

On Timer No

Audio Input 1 S- Input 1 Yes Video Input 2 No Audio Input 2 No S- Input 2 No Video Output No Audio Output Other Terminal No Euro Scart (21Pin) Component In Audio Input (Component In use) PC Monitor Input (D-Sub) Audio Input HDMI Input 1 Audio Input (HDMI/DVI In use) PC Monitor Audio Input Alternative HDMI Input 2 Audio Input (HDMI/DVI In use) Sub Woofer Output No Diversity No Ext Speaker No DC Jack 12V(Center +) No VHF/UHF Antenna Input AC Inlet Other Terminal Headphone

w/o Stand,Handle Approx. W x D x H (mm)

Net w/o Stand,Handle Approx. 16.0kg (35.3 lbs) Gross Approx. 22.5kg (49.6 lbs)

Content ---Material -- Dimensions W x D x H(mm) -- x -- x -- Description of Origin

Material Double/Brown Dimensions W x D x H(mm) 917 x 441 x 720 Design As per Buyer's Description of Origin Yes

Height (cm) 50

Cabinet Rear PS 94V0 NON-DECABROM

Eyelet Yes

Measures for Whisker Yes

RCA x 1

RCA x 2(L/MONO, R)

RCA x 2(Variable) (L, R)

2Scart Yes RCA x 2(L/MONO, R) Yes Mini Pin Jack(o3.5), STEREO Yes

Yes Mini Pin Jack(o3.5), STEREO

DIN Type Yes

822 x 129 x 556.5

3 Sets /--

Sets/40' container

A3-5

DISASSEMBLY INSTRUCTIONS

REMOVAL AND INSTALLATION OF FLAT PACKAGE IC

REMOVAL

Put Masking Tape (cotton tape) around the Flat Pack-

1. age IC to protect other parts from any damage.

(Refer to Fig. 1-1.) NOTE

Masking is carried out on all the parts located within 10 mm distance from IC leads.

When IC starts moving back and forth easily after

3. desoldering completely, pickup the corner of the IC using a tweezers and remove the IC by moving with the IC desoldering machine. (Refer to Fig. 1-3.)

NOTE

Some ICs on the PCB are affixed with glue, so be careful not to break or damage the foil of each IC leads or solder lands under the IC when removing it.

Blower type IC desoldering machine

Masking Tape (Cotton Tape)

Heat the IC leads using a blower type IC desoldering

machine. (Refer to Fig. 1-2.)

NOTE

Do not rotate or move the IC back and forth until IC can move back and forth easily after desoldering the leads completely.

Blower type IC desoldering machine

Fig. 1-1

Tweezers

Peel off the Masking Tape.4. Absorb the solder left on the pattern using the Braided

5. Shield Wire. (Refer to Fig. 1-4.)

NOTE

Do not move the Braided Shield Wire in the vertical direction towards the IC pattern.

Fig. 1-3

Braided Shield Wire

Soldering Iron

Fig. 1-2

IC pattern

Fig. 1-4

B-1

DISASSEMBLY INSTRUCTIONS

INSTALLATION

Take care of the polarity of new IC and then install the

1. new IC fitting on the printed circuit pattern. Then solder each lead on the diagonal positions of IC temporarily.

(Refer to Fig. 1-5.)

Soldering Iron

Solder temporarily

Supply the solder from the upper position of IC leads

Solder temporarily

sliding to the lower position of the IC leads.

(Refer to Fig. 1-6.)

Fig. 1-5

When bridge-soldering between terminals and/or the

4. soldering amount are not enough, resolder using a Thintip Soldering Iron. (Refer to Fig. 1-8.)

Thin-tip Soldering Iron

Fig. 1-8

Finally, confirm the soldering status on four sides of the

5. IC using a magnifying glass. Confirm that no abnormality is found on the soldering position and installation position of the parts around the IC. If some abnormality is found, correct by resoldering.

NOTE

When the IC leads are bent during soldering and/or repairing, do not repair the bending of leads. If the bending of leads are repaired, the pattern may be damaged. So, be always sure to replace the IC in this case.

Soldering IronSolder

Absorb the solder left on the lead using the Braided

Supply soldering from upper position to lower position

Shield Wire. (Refer to Fig. 1-7.)

NOTE

Do not absorb the solder to excess.

Soldering Iron

Braided Shield Wire

Fig. 1-6

Fig. 1-7

B-2

SERVICE MODE LIST

This unit is provided with the following SERVICE MODES so you can repair, examine and adjust easily. To enter to the SERVICE MODE function, press and hold both buttons simultaneously on the main unit and on the remote

control for more than the standard time in the appropriate condition. (See below chart.)

Set

Condition

POWER ON

ALL mode

POWER ON

ALL mode

Set Key Operations

VOL. DOWN

(Minimum)

VOL. DOWN

(Minimum)

VOL. DOWN

(Minimum)

VOL. DOWN

(Minimum)

Remocon

Key

1 2 sec.

6 2 sec.

9 2 sec.

Standard

Time

2 sec.

Initialization of factory TV data. NOTE:

Check of the SUM DATA, POWER ON total hours and MICON VERSION on the screen. Refer to the "WHEN REPLACING EEPROM (MEMORY) IC".

Can be checked of the INITIAL DATA of MEMORY IC. Refer to the "WHEN REPLACING EEPROM (MEMORY) IC".

If you set factory initialization, the memories are reset such as the channel setting, and the POWER ON total hours.

Display of the Adjustment MENU on the screen. Refer to the "ELECTRICAL ADJUSTMENT" (On-Screen Display Adjustment).

C-1

WHEN REPLACING EEPROM (MEMORY) IC

CONFIRMATION OF CHECK SUM, POWER ON TOTAL HOURS AND MICON VERSION.

Initial total of MEMORY IC, POWER ON total hours and MICON VERSION can be checked on the screen. Total hours are displayed in 16 system of notation.

NOTE:

4. NOTE:The each item value might be different according to each set.

If you set a factory initialization, the total hours is reset to "0". Please refer to "CONFIRMATION OF INITIAL DATA" when SUM DATA is not corresponding.

Turn on the POWER, and set to the TV mode. Set the VOLUME to minimum. Press both VOL. DOWN button on the set and Channel button (2) on the remote control for more than 2 seconds. After the confirmation of each check sum, POWER ON total hours and MICON VERSION , turn off the power.

Initial setting data check sum.

SCALER data check sum.

Main Micon check sum.

INIT : 5BE3 VCT-P : B8AD LCD ON : 0000

ANALOG M : DB070_70509A

POWER ON total hours.

= (16 x 16 x 16 x thousands digit value) + (16 x 16 x hundreds digit value) + (16 x tens digit value) + (ones digit value)

FIG. 1

CONFIRMATION OF INITIAL DATA

If a service repair is undertaken where it has been required to change the MEMORY IC, the following steps should be taken to ensure correct data settings while making reference to INITIAL SETTING TABLE (Attached "INITIAL DATA").

Turn on the POWER, and set to the TV mode.

1. Set the VOLUME to minimum.

2. Press both VOL. DOWN button on the set and Channel button (6) on the remote control for more than 2 seconds.

3. ADDRESS and DATA should appear as FIG 2.

ADDRESS DATA

INIT 0000 00

ANALOG M : DB070_70509A

FIG. 2

ADDRESS is now selected and should "blink". Using the UP/DOWN buton on the remote, step through

4. the ADDRESS until required ADDRESS to be changed is reached. Press VOL. UP/DOWN button to select DATA. When DATA is selected, it will "blink".

5. Again, step through the DATA using UP/DOWN button until required DATA value has been selected.

6. Pressing LEFT/RIGHT button will take you back to ADDRESS for further selection if necessary.

7. Repeat steps 4 to 6 until all data has been checked.

8. When satisfied correct DATA has been entered, turn POWER off (return to STANDBY MODE) to finish DATA input.

After the data input, set to the initializing of shipping.

Turn POWER on.

10. Press both VOL. DOWN button on the set and Channel button (1) on the remote control for more than 2 seconds.

11. After the finishing of the initializing of shipping, the unit will turn off automatically.

12.

The unit will now have the correct DATA for the new MEMORY IC.

C-2

ELECTRICAL ADJUSTMENTS

1. ADJUSTMENT PROCEDURE

Read and perform these adjustments when repairing the circuits or replacing electrical parts or PCB assemblies.

CAUTION

•

Use an isolation transformer when performing any service on this chassis.

•

When removing a PCB or related component, after unfastening or changing a wire, be sure to put the wire back in its original position.

•

When you exchange IC and Transistor with a heat sink, apply silicon grease on the contact section of the heat sink. Before applying new silicon grease, remove all the old silicon grease. (Old grease may cause damage to the IC and Transistor).

Prepare the following measurement tools for electrical adjustments.

1. Pattern Generator

2. BASIC ADJUSTMENTS

On-Screen Display Adjustment

1.2.Set the VOLUME to minimum.

Press the VOL. DOWN button on the set and the channel button (9) on the remote control for more than 2 seconds to display adjustment mode on the screen as shown in Fig. 2-1.

PAL

01 OSD H POSI

Use the UP/DOWN button or Channel button (0-9) on the remote control to select the options shown in Fig. 2-2.

Press the ANALOG MENU button on the remote control to end the adjustments.

To display the adjustment screen for TUNER, AV, COMPONENT, HDMI and PC mode, press the INPUT SELECT button on the remote control to set to the TUNER, AV, HDMI and PC mode.

Press the VOL.DOWN button on the set and the channel (9) on the remote control for more than 2 seconds.

TUNER

16:9

Fig. 2-1

NO.

FUNCTION

NO.

OSD H POSI

OSD V POSI

R DRIVE (N)

R CUT OFF (N)

G DRIVE (N)

G CUT OFF (N)

B DRIVE (N)

B CUT OFF (N)

R DRIVE (C)

R CUT OFF (C)

G DRIVE (C)

G CUT OFF (C)

B DRIVE (C)

B CUT OFF (C)

R DRIVE (W)

R CUT OFF (W)

G DRIVE (W)

G CUT OFF (W)

B DRIVE (W)

B CUT OFF (W)

H POSI

H POSI MAX

FUNCTION

H POSI MIN

V POSI

V POSI MAX

V POSI MIN

BACKLIGHT CENTER

BACKLIGHT MAX

BACKLIGHT MIN

BRIGHT CENTER

BRIGHT MAX

BRIGHT MIN

TINT CENTER

CONTRAST CENTER

CONTRAST MAX

CONTRAST MIN

CONTRAST 40

COLOR CENTER

COLOR MAX

COLOR MIN

TEXT H POIS

TEXT V POIS

FLICKER ADJ

Fig. 2-2

2-1: WHITE BALANCE

Place the set in Aging Test for more than 15 minutes.

Receive the gray scale pattern from the Pattern Generator.

Press the INPUT SELECT button on the remote control to set to the AV mode.

Using the remote control, set the brightness and contrast to normal position.

Activate the adjustment mode display of Fig. 2-1 and press the channel button (03) on the remote control to select "R DRIVE (N)".

Press the CH. UP/DOWN button on the remote control to select the "R CUT OFF(N)", "G DRIVE(N)", "G CUT OFF(N)", "B DRIVE(N)", "B CUT OFF(N)", "R DRIVE(C)", "R CUT OFF(C)", "G DRIVE(C)", "G CUT OFF(C)", "B DRIVE(C)", "B CUT OFF(C)", "R DRIVE(W)", "R CUT OFF(W)", "G DRIVE(W)", "G CUT OFF(W)", "B DRIVE(W)" or "B CUT OFF(W)".

Adjust the VOL. UP/DOWN button on the remote control to whiten the R CUT OFF(N), G DRIVE(N), G CUT OFF(N), B DRIVE(N), B CUT OFF(N), R DRIVE(C), R CUT OFF(C)", G DRIVE(C), G CUT OFF(C), B DRIVE(C), B CUT OFF(C), R DRIVE(W), R CUT OFF(W), G DRIVE(W), G CUT OFF(W), B DRIVE(W) and B CUT OFF(W) at each step tone sections equally.

Perform the above adjustments 6 and 7 until the white color is achieved.

D-1

ELECTRICAL ADJUSTMENTS

2-2: CONTRAST MAX

Receive the monoscope pattern. (RF Input)

Using the remote control, set the brightness and contrast to normal position.

Activate the adjustment mode display of Fig. 2-1 and press the channel button (35) on the remote control to select "CONTRAST MAX".

Press the LEFT/RIGHT button on the remote control until the contrast step No. becomes "53"

Check if the picture is normal.

Receive the monoscope pattern. (VIDEO Input)

Press the INPUT SELECT button on the remote control to set to the AV mode.

Using the remote control, set the brightness and contrast to normal position.

Activate the adjustment mode display of Fig. 2-1 and press the channel button (35) on the remote control to select "CONTRAST MAX".

10.

Press the LEFT/RIGHT button on the remote control until the contrast step No. becomes "53".

11.

Check if the picture is normal.

12.

Playback the DVD(480i) disc. (COMPONENT Input)

13.

Press the INPUT SELECT button on the remote control to set to the COMPONENT mode.

14.

Using the remote control, set the brightness and contrast to normal position.

15.

Activate the adjustment mode display of Fig. 2-1 and press the channel button (35) on the remote control to select "CONTRAST MAX".

16.

Press the LEFT/RIGHT button on the remote control until the contrast step No. becomes "56".

17.

Playback the DVD(480i) disc. (HDMI Input)

18.

Press the INPUT SELECT button on the remote control to set to the HDMI mode.

19.

Using the remote control, set the brightness and contrast to normal position.

20.

Activate the adjustment mode display of Fig. 2-1 and press the channel button (35) on the remote control to select "CONTRAST MAX".

21.

Press the LEFT/RIGHT button on the remote control until the contrast step No. becomes "56".

22.

Check if the picture is normal.

D-2

2-3: Confirmation of Fixed Value (Step No.)

ELECTRICAL ADJUSTMENTS

Please check if the fixed values of each of the adjustment item is set correctly referring below. (TUNER/AV/CS/HDMI/PC)

NO. FUNCTION CVBS S(Y/C) RGB 480i 480p 720p 1080i 576i 576p 720p 1080i 480i 480p VGA 720p 1080i 576i 576p 720p 1080i 640x480 720x400 800x600 1024x768 1280x720 1280x768 1360x768

Step No. Step No. Step No. Step No. Step No. Step No. Step No. Step No. Step No. Step No. Step No. Step No. Step No. Step No. Step No. Step No. Step No. Step No. Step No. Step No. Step No. Step No. Step No. Step No. Step No. Step No. Step No. Step No.

1 OSD H POSI 21 21 21 21 21 21 21 21 21 21 21 21 21 21 21 21 21 21 21 21 21 21 21 21 21 21 21 21 2 OSD V POSI 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 00000 0 0 3 R DRIVE(N) 736 736 736 736 736 736 736 736 736 736 736 736 736 736 736 736 736 736 736 736 736 736 736 736 736 736 736 736 4 R CUT OFF(N) 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 ----- - 5 G DRIVE(N) *714 *714 *714 *714 *714 *714 *714 *714 *714 *714 *714 *714 *714 *714 *714 *714 *714 *714 *714 *714 *714 714 714 714 714 714 714 714 6 G CUT OFF(N) *-5 *-5 *-5 *-5 *-5 *-5 *-5 *-5 *-5 *-5 *-5 *-5 *-5 *-5 *-5 *-5 *-5 *-5 *-5 *-5 *-5 ----- - 7 B DRIVE(N) *635 *635 *635 *635 *635 *635 *635 *635 *635 *635 *635 *635 *635 *635 *635 *635 *635 *635 *635 *635 *635 635 635 635 635 635 635 635 8 B CUTOFF(N) *-2 *-2 *-2 *-2 *-2 *-2 *-2 *-2 *-2 *-2 *-2 *-2 *-2 *-2 *-2 *-2 *-2 *-2 *-2 *-2 *-2 ----- - -

9 R DRIVE(C) 736 736 736 736 736 736 736 736 736 736 736 736 736 736 736 736 736 736 736 736 736 ----- - 10 R CUT OFF(C) 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 ----- - 11 G DRIVE(C) *712 *712 *712 *712 *712 *712 *712 *712 *712 *712 *712 *712 *712 *712 *712 *712 *712 *712 *712 *712 *712 ----- - 12 G CUT OFF(C) *-5 *-5 *-5 *-5 *-5 *-5 *-5 *-5 *-5 *-5 *-5 *-5 *-5 *-5 *-5 *-5 *-5 *-5 *-5 *-5 *-5 ---- - - 13 B DRIVE(C) *654 *654 *654 *654 *654 *654 *654 *654 *654 *654 *654 *654 *654 *654 *654 *654 *654 *654 *654 *654 *654 ----- - 14 B CUTOFF(C) *-3 *-3 *-3 *-3 *-3 *-3 *-3 *-3 *-3 *-3 *-3 *-3 *-3 *-3 *-3 *-3 *-3 *-3 -3 -3 -3 ----- - 15 R DRIVE(W) 736 736 736 736 736 736 736 736 736 736 736 736 736 736 736 736 736 736 736 736 736 ----- - 16 R CUT OFF(W) 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 ----- - 17 G DRIVE(W) *692 *692 *692 *692 *692 *692 *692 *692 *692 *692 *692 *692 *692 *692 *692 *692 *692 *692 *692 *692 *692 ----- - 18 G CUT OFF(W) *0 *0 *0 *0 *0 *0 *0 *0 *0 *0 *0 *0 *0 *0 *0 *0 *0 *0 *0 *0 *0 ----- - 19 B DRIVE(W) *599 *599 *599 *599 *599 *599 *599 *599 *599 *599 *599 *599 *599 *599 *599 *599 *599 *599 *599 *599 *599 ----- - 20 B CUTOFF(W) *-4 *-4 *-4 *-4 *-4 *-4 *-4 *-4 *-4 *-4 *-4 *-4 *-4 *-4 *-4 *-4 *-4 *-4 *-4 *-4 *-4 ---- - - 21

H POSI 50Hz 4:3 H POSI 50Hz 4:3 OTHER 643 643 643 640 - - - - 597 284 307 256 - - - - - 76 3 146 94 ----- - -

H POSI 60Hz 4:3 H POSI CENTER (PC) H POSI 60Hz 4:3 OTHER 584 584 584 592 553 266 306 256 - - - - 52 2 2 92 33 - - - - 130 146 192 280 - - -

22 H POSI MAX (PC) - - - - - - - - - - - - - - - - - - - - - 181 197 242 330 254 352 394 23 H POSI MIN (PC) - - - - - - - - - - - - - - - - - - - - - 81 97 142 230 154 252 294 24

V POSI 50Hz FULL SCREEN/ Cinema OTHER

V POSI 50Hz FULL SCREEN V POSI 50Hz Cinema

V POSI 60Hz FULL SCREEN/Cinema OTHER /V POSI CENTER(PC)

V POSI 60Hz FULL SCREEN

V POSI 60Hz Cinema 25 V POSI MAX - - - - - - - - - - - - - - - - - - - - - 53 51 51 50 57 50 42 26 V POSI MIN - - - - - - - - - - - - - - - - - - - - - 31107 0 0 27 BACKLIGHT CENTER 128 128 128 128 128 128 128 128 128 128 128 128 128 128 128 128 128 128 128 128 128 128 128 128 128 128 128 128 28 BACKLIGHT MAX 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 255 29 BACKLIGHT MIN 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 00000 0 0 30 BRIGHT CENTER + + + + -1 -1 -1 -1 -1 -1 -1 -1 -1 -1 -1 -1 -1 -1 -1 -1 -1 88888 8 8 31 BRIGHT MAX + + + + 40 40 40 40 40 40 40 40 40 40 40 40 40 40 40 40 40 40 40 40 40 40 40 40 32 BRIGHT MIN + + + + -64 -64 -64 -64 -64 -64 -64 -64 -64 -64 -64 -64 -64 -64 -64 -64 -64 -64 -64 -64 -64 -64 -64 -64 33 TINT CENTER + + + + -6 -6 -6 -6 -6 -6 -6 -6 -6 -6 -6 -6 -6 -6 -6 -6 -6 -7 -7 -7 -7 -7 -7 -7 34 CONTRAST CENTER *+ *+ *+ *+ *41 *40 *39 *39 *41 *40 *39 *39 *40 *40 *40 *40 *35 *40 *40 *40 *40 39 39 39 39 39 39 39 35 CONTRAST MAX *+ *+ *+ *+ *59 *59 *55 *55 *56 *56 *55 *55 *56 *56 *56 *56 *56 *56 *56 *56 *56 53 53 53 53 53 53 53 36 CONTRAST MIN + + + + 18 18 18 18 18 18 18 18 18 18 18 18 18 18 18 18 18 18 18 18 18 18 18 18 37 CONTRAST 50 *+ *+ *+ *+ *54 *52 *51 *51 *54 *52 *51 *51 *52 *52 *52 *52 *52 *52 *52 *52 *52 50 50 50 50 50 50 50 38 COLOR CENTER + + + + 45 45 45 45 45 45 45 45 45 45 45 45 45 45 45 45 45 45 45 45 45 45 45 45 39 COLOR MAX + + + + 63 63 63 63 63 63 63 63 63 63 63 63 63 63 63 63 63 63 63 63 63 63 63 63 40 COLOR MIN + + + + 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 00000 0 0 41 TEXT H POSI 150 150 150 150 150 150 150 150 150 150 150 150 150 150 150 150 150 150 150 150 150 150 150 150 150 150 150 150 42 TEXT V POSI 7 7 7 7 7 7 7 7 7 7 7 7 7 7 7 7 7 7 7 7 7 77777 7 7 43 DAC VCOM 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0000 00000 0 0

643643643637----597284-------763------- - -

583 583 583 590 553 266 - - - - - - 52 2 2 - - - - - - 131 147 192 280 204 302 344

27272726----27542218-----16421219----- - -

-------------------------- - -

21 21 21 20 21 44 20 18 - - - - 10 31 34 22 19 - - - - 28 26 26 25 32 25 17

-------------------------- - -

CS(NTSC) CS(PAL) HDMI(NTSC)TUNER AV

PCHDMI(PAL)

NOTE: For the step no. with * mark, please adjust it according to the situation of the set.

For the step no. with + mark, please adjust it according to the 2-4.

D-3 D-4

2-4: Confirmation of Fixed Value (Step No.)

Please check if the fixed values of each of the ad

NO. FUNCTION

PAL50 PAL60 SECAM PAL50 PAL60 SECAM NTSC3.58 NTSC4.43 PAL50 PAL60 SECAM NTSC3.58 NTSC4.43 PAL50 PAL60 SECAM NTSC3.58 NTSC4.43 PAL50 PAL60 SECAM NTSC3.58 NTSC4.43 PAL50 PAL60 SECAM NTSC3.58 NTSC4.43

30 BRIGHT CENTER 31 BRIGHT MAX 32 BRIGHT MIN 33 TINT CENTER 34 CONTRAST CENTER 35 CONTRAST MAX 36 CONTRAST MIN 37 CONTRAST 40 38 COLOR CENTER 39 COLOR MAX 40 COLOR MIN

A-TU

-1 -1 -1 -1 -1 -1 -1 -1 -1 -1 -1 -1 -1 -1 -1 -1 -1 -1 40 40 40 40 40 40 40 40 40 40 40 40 40 40 40 40 40 40

-64 -64 -64 -64 -64 -64 -64 -64 -64 -64 -64 -64 -64 -64 -64 -64 -64 -64 -64 -64 -64 -64 -64 -64 -64 -64 -64 -64

-4 -4 -4 -4 -4 -4 -4 -4 -4 -4 -4 -4 -4 -4 -4 -4 -4 -4 -4 -4 -4 -4 -4 -4 -4 -4 -4 -4 *39 *39 *39 *39 *39 *39 *39 *39 *39 *39 *39 *39 *39 *39 *39 *39 *39 *39 *39 *39 *39 *39 *39 *39 *39 *39 *39 *39 *53 *53 *53 *53 *53 *53 *53 *53 *53 *53 *53 *53 *53 *53 *53 *53 *53 *53 *53 *53 *53 *53 *53 *53 *53 *53 *53 *53

18 18 18 18 18 18 18 18 18 18 18 18 18 18 18 18 18 18 18 18 18 18 18 18 18 18 18 18

*50 *50 *50 *50 *50 *50 *50 *50 *50 *50 *50 *50 *50 *50 *50 *50 *50 *50 *50 *50 *50 *50 *50 *50 *50 *50 *50 *50

45 45 45 45 45 45 45 45 45 45 45 45 45 45 45 45 45 45 45 45 45 45 45 45 45 45 45 45 63 63 63 63 63 63 63 63 63 63 63 63 63 63 63 63 63 63 63 63 63 63 63 63 63 63 63 63

000000 0 0 000 0 0 0 00 0 0 000 0 0 000 0 0

ustment item is set correctly referring below. (TUNER/AV)

AV1(SCART1),AV2(SCART2) AV3(RCA)

CVBS CVBS

ELECTRICAL ADJUSTMENTS

AV2(SCART2) AV3(RCA) AV1(SCART1)

S(Y/C) S(Y/C)

480i

576i 480i

RGB

480i 576i 480i 576i576i 576i 480i 576i

-1 -1 -1 -1 -1 40 40 40 40 40

-1 -1 -1 -1 -1

40 40 40 40 40

NOTE: For the step no. with * mark, please ad

ust it according to the situation of the set.

D-5 D-6

ELECTRICAL ADJUSTMENTS

3. ELECTRICAL ADJUSTMENT PARTS LOCATION GUIDE (WIRING CONNECTION)

LCD PANEL

CP406

CD403

CD404

OPERATION PCB

CP2202

POWER PCB

CP411

CD7204

CD4302

CP7201

CP3801

CP4305

MAIN PCB

CP3603

CP3601

J4301

CP4302

TU6001

J4202 J4203

J4204

J4205

AC IN CD3810

CP407

J401

CP412

D-7

SPEAKER

CP3802

CP301

CP4301

CD4301

CP2201

J4206

OS2201

REMOCON PCB

MAIN BLOCK DIAGRAM

PC/HDMI AUDIO IN J4301 MSJ-035-39D_B_PC_LF(087)

COMPONENT AUDIO IN J4202 AV2-57A03-01

PC IN CP4302 D229FD015G107BY

DECORDER/PERITEL J4206 MRC-021V-27_PC

PC/DVI1_A_N_L

DVI2 AUDIO_L

DVI2 AUDIO_R PC/DVI1_A_IN_R

YUV AUDIO L

YUV AUDIO R

VGA_R

VGA_G

VGA_B

SCART1_V_IN

SCART2_V_IN

SCART1_R/C1_IN SCART1_G_IN SCART1_B_IN

SCART2_R/C2_IN SCART2_G_IN SCART2_B_IN

SC1_A_IN_L SC2_A_IN_L

YUV/DVI/PC Lch SW IC4303 NJM2534V(TE2)

YUV/DVI/PC Rch SW IC4304 NJM2534V(TE2)

COMPONENT V IN J4203 RCA-349-00D-01

SCART1/2_VIDEO_SW IC4206 MM1501XNRE

SCART1/2_RGB_SW IC4204 NJM2584AM(TE1)

AUDIO_SCART1/2_LCH_SW IC4203 MM1501XNRE

SW_A1_L

SW_A1_R

SW_Y/D_Y

SW_PB/D_PB

SW_PR/D_PR

SW_SCART_CVBS/Y

SW_SCART_R/C

SW_SCART_G

SW_SCART_B

SW_A_L

MICON/SCALER IC803 VCT6973G‑FA‑B3‑000

RGB

SPEAKER AUDIO OUT L

SPEAKER AUDIO OUT R

CP7201 20389-Y30E

AUDIO AMP IC301 TDA8932T

HEADPHON AMP IC300 NJM2151AV (TE1)

RGB

HEADPHON

PANEL V2301 LC320W01-SL22

AMP L/R

L/R

SPEAKER SP301,SP302 FB136N4-A1

HEADPHON JACK J4205 MSJ-03508D_PC(087)

TUNER TU6001 TAFV-W623D

AV/AUDIO OUT/S-TERMINAL J4204 RCA/DIN-501A-00B-03

YC IN

AUDIO_OUT_LR

VIDEO_AUDIO LR IN

SC1_A_IN_R SC2_A_IN_R

SC1_A_OUT_L SC1_A_OUT_R SC2_A_OUT_L

SC2_A_OUT_R MONITOR

TUNER_VIDEO_OUT SIF

S_JACK_Y S_JACK_C

AUDIO JACK OUT L AUDIO JACK OUT R

CVBS IN

VIDEO A L VIDEO A R

AUDIO_SCART1/2_RCH_SW IC4202 MM1501XNRE

SW_A_R

HDMI CONNECTOR CP3601

HDMI CONNECTOR CP3603

HDMI1 IN

HDMI2 IN

HDMI I/F IC3605 SII9025CTU

DVI DATA8〜23 Y,Cb,Cr 16Bit

E-1 E-2

POWER BLOCK DIAGRAM

10188

Vcc

1324132

413

J401

314589245

1+431

273

181714131013

Q416

F401

L401

L402

AC IN

RELAY RY401

AT+5V

RELAY_H

D408

POWER SW CTL IC401 MP2A5060

P-GND

L403

D427

SW REG CTL IC402 MIP2F4

D430D425

D431

TRANSFORMER

T402

FEED BACK IC410 PS2561AL1-1-V(W)

TRANSFORMER T401

CP412_7.AT+34

CP411_14,15.AT+5V

CP411_16.PWOER FAIL

REGULATOR IC404 KIA431A-AT

CP411_1,2.SOUND+B CP411_8,9.SW+12V

Q413,Q419 CP412_8,9.LCD+B

CP406_1,2,3,4,5.INV_SW+24V

E-3 E-4

+ 42 hidden pages
