Toshiba 32D1333B Instruction manual

ON-LINE MANUAL

32D1333B 32D1334B

LED Backlight LCD TV

During the life of your TV firmware updates will be made available

to ensure that your TV maintains optimum performance. You can

download the latest version of firmware from

www.toshiba-om.net/firmware.php

*Some features listed in this document are limited due to local

legislation and may not be available in all countries.

"Register your TV online at: www.toshiba.co.uk/registration”

Get started with Freeview

Freeview gives you over 50 TV channels to play with, not to mention 25 radio stations.

Start watching all your favourite TV content today, just connect your aerial and tune in.

Keep up-to-date

New channels are launched on Freeview from time to time along with other updates to the service. So it pays to retune your digital TV periodically to make sure your Digital TV/Radio channels are up to date. To retune your Toshiba Digital TV, please refer to the Re-tune section for guidance.

English

Alternatively nd out more on the dedicated Freeview website:

www.freeview.co.uk/retune

Freeview service is subject to availability. Aerial upgrade may be required.

English - 1 -

Contents

English

Safety Precautions ................................................. 4

Air Circulation ..................................................... 4

Heat Damage...................................................... 4

Mains Supply ...................................................... 4

Warning ............................................................. 4

Do ....................................................................... 4

Do not ................................................................. 4

Installation and Important Information .................... 5

EXCLUSION CLAUSE........................................ 5

Important safety information .................................. 6

Removing the pedestal stand ................................. 7

The Remote Control (TV - DVD) ............................ 8

Inserting Batteries and Effective Range of the

Remote Control................................................... 8

Connecting External Equipment ............................. 9

Connecting an HDMI® or DVI Device to the HDMI

Input...................................................................... 10

To Connect an HDMI Device ............................ 10

To Connect a DVI Device.................................. 10

To Connect a Computer ..................................... 11

Connecting a USB Memory ...................................11

To Connect a USB Flash Drive .......................... 11

Connecting a Computer.........................................11

Power Save Mode ................................................ 12

Environmental Information ............................... 12

Controlling the TV ................................................. 13

Switching on ..................................................... 13

Using the Remote Control ................................ 13

Using the Controls on the TV ............................ 13

Initial Installation .................................................. 14

Auto Tuning....................................................... 15

Auto Tuning .......................................................... 15

Manual Tuning, Analogue Fine Tuning ................. 16

Digital Aerial Manual Search............................. 16

Digital Cable Manual Search ............................ 16

Analogue Manual Search ................................. 16

Analogue Fine Tune.......................................... 16

Re-tune Section .................................................... 17

Re-tuning: TOSHIBA Freeview Products .............. 17

General Operation ................................................ 18

Stereo and Bilingual Transmissions.................. 18

Displaying Subtitles .......................................... 18

Viewing Main Menu .......................................... 18

Controlling Volume and Muting Sound ............. 18

Selecting Programme Positions........................ 18

Standby Notications ........................................ 18

Channel List, Sorting Programmes, Programme

Locking ................................................................. 19

Viewing Channel List ........................................ 19

Moving a Channel ............................................. 19

Deleting a Channel ........................................... 19

Renaming a Channel ........................................ 19

Locking a Channel ............................................ 19

Viewing Info Banner, Electronic Programme

Guide .................................................................... 20

Viewing Info Banner .......................................... 20

Electronic Programme Guide............................ 20

Language Selection .............................................. 21

Language Settings ............................................ 21

Preferred ....................................................... 21

Current .......................................................... 21

Digital Settings - Parental Control, Menu Lock, Set

PIN........................................................................ 22

Viewing Parental Control Menu ........................ 22

Menu Lock ........................................................ 22

Maturity Lock (*)................................................ 22

Child Lock ......................................................... 22

Set PIN ............................................................. 22

Conguring Picture Settings ................................. 23

Conguring Picture Settings ............................. 23

Picture Mode..................................................... 23

Contrast ............................................................ 23

Brightness ......................................................... 23

Sharpness......................................................... 23

Colour ............................................................... 23

Power Save Mode ............................................ 23

Backlight (optional) ........................................... 23

Noise Reduction ............................................... 23

Advanced Settings ........................................ 23

Reset ................................................................ 24

Changing Picture Format...................................... 25

Conguring PC Picture Settings ........................... 26

PC Picture Settings (*) ...................................... 26

PC Position ....................................................... 26

Autoposition ...................................................... 26

H Position ......................................................... 26

V Position.......................................................... 26

Dot Clock .......................................................... 26

Phase................................................................ 26

Conguring Sound Settings .................................. 27

Conguring Sound Settings .............................. 27

Operating Sound Settings Menu Items ............. 27

Volume .............................................................. 27

Equalizer (Only for speaker) ............................. 27

Balance (Only for speaker) ............................... 27

Headphone ....................................................... 27

Sound Mode ..................................................... 27

AVL ................................................................... 27

Dynamic Bass ................................................... 27

Surround Sound................................................ 27

Digital Out ......................................................... 27

Settings Menu Operation, Conditional Access ..... 28

Conguring Your TV’s Settings ......................... 28

Viewing Settings Menu ..................................... 28

Conditional Access ........................................... 28

Language .......................................................... 28

Parental ............................................................ 28

English - 2 -

Timers ............................................................... 28

Date/Time ......................................................... 28

Sources............................................................. 28

Other Settings ................................................... 28

Using a Conditional Access Module ................. 28

Setting Timers, Setting Date/Time ........................ 29

Timers ............................................................... 29

Setting Sleep Timer .......................................... 29

Setting Programme Timers ............................... 29

Conguring Date/Time Settings ........................ 29

Source Settings, Other Controls ........................... 30

Conguring Source Settings ............................. 30

Input Selection .................................................. 30

Conguring Other Settings - General ............... 30

Operation .......................................................... 30

Menu Timeout ................................................... 30

Scan Encrypted Channels ............................... 30

Blue Background .............................................. 31

Software Upgrade ............................................. 31

Application Version ........................................... 31

Hard of Hearing ................................................ 31

Audio Description.............................................. 31

Auto TV Off ....................................................... 31

Broadcast Type (optional) ................................. 31

Standby Search (*) .......................................... 31

Store Mode ....................................................... 31

Power Up Mode ................................................ 31

DVD Mode ............................................................ 32

Handling Discs .................................................. 32

Cleaning Discs .................................................. 32

DVD - Features ................................................ 32

DVD - Control buttons on the TV ...................... 33

How to watch a DVD ............................................ 35

Notes on DVD Playback ................................... 35

DVD Mode Conguration .................................. 36

TV Type ......................................................... 36

Language Setup ........................................... 36

OSD LANG ................................................... 36

AUDIO .......................................................... 36

DISC MENU .................................................. 36

SUBTITLE ..................................................... 36

DEFAULT ...................................................... 36

DOWNMIX .................................................... 36

SURROUND ................................................. 36

STEREO ....................................................... 36

PARENTAL .................................................... 36

PASSWORD ................................................. 36

SPDIF OUTPUT ............................................ 36

The DVD picture quality is poor ........................ 37

Appendix A: DVD Mode Supported le formats.... 38

Appendix B: Compatible disc types ...................... 38

Manual Start ..................................................... 39

Auto Start .......................................................... 39

USB Media Browser ............................................. 39

Playing MP3 Files ............................................. 40

Viewing JPEG Files .......................................... 40

Slideshow Feature ............................................ 41

English - 3 -

Video Playback ................................................. 41

Media Browser Settings .................................... 42

Using MENU button in Media Browser Mode ... 42

To Close the Media Player ................................ 42

Analogue Only Text Services ................................ 43

Using Text Button -TXT ..................................... 43

Acessing Sub-Pages ........................................ 43

Revealing Concealed Text ................................ 43

Holding a Page ................................................. 43

To display an initial page................................... 43

Appendix C: PC Input Typical Display Modes ...... 44

Appendix D: AV and HDMI Signal Compatibility

(Input Signal Types) .............................................. 45

Appendix E: PIN Information ............................... 46

Appendix F: Supported File Formats for USB

Mode..................................................................... 47

Specications and Accessories ............................ 48

License Information .............................................. 49

Q & A Section ....................................................... 50

English

Safety Precautions

This equipment has been designed and manufactured to meet international safety standards but, like any electrical equip-

English

ment, care must be taken to obtain the best results and for safety to be assured. Please read the points below for your own safety. They are of a general nature, intended to help with all electronic consumer products and some points may not apply to the goods you have just purchased.

Air Circulation

Leave more than 10cm around all edges when wall mounting the television to allow adequate ventilation. This will prevent overheating and possible damage to the television. Dusty places should also be avoided.

Heat Damage

Damage may occur if the television is left in direct sunlight or near a heater. Avoid places subject to extremely high temperatures or humidity, or locations where the temperature is likely to fall below 5°C (41°F).

Mains Supply

The set should be operated only from a 220-240 V AC 50 Hz outlet. DO ensure that the television is not standing on the mains lead. DO NOT cut off the mains plug from this equipment, this incorporates a special Radio Interference Filter, the removal of which will impair its performance. In the UK, the

fuse tted in this plug is approved by ASTA or BSI to BS1362.

It should only be replaced by a correctly rated and approved type. IF IN DOUBT PLEASE CONSULT A COMPETENT ELECTRICIAN.

Warning

To prevent the spread of re, keep candles or other open

ames away from this product at all times.

DO read the operating instructions before you attempt to

use the equipment.

DO ensure that all electrical connections (including the mains plug, extension leads and inter connections between pieces of equipment) are properly made and in accordance with

the manufacturers’ instructions. Switch off and withdraw the

mains plug before making or changing connections.

DO consult your dealer if you are ever in doubt about the installation, operation or safety of your equipment.

DO be careful with glass panels or doors on equipment.

Do not

DON’T remove any xed cover as this may expose danger- ous voltages.

DON’T obstruct the ventilation openings of the equipment with items such as newspapers, tablecloths, curtains, etc. Overheating will cause damage and shorten the life of the equipment.

DON’T allow electrical equipment to be exposed to dripping

or splashing or objects lled with liquids, such as vases, to

be placed on the equipment.

DON’T place hot objects or naked ame sources, such as

lighted candles or nightlights on, or close to equipment. High

temperatures can melt plastic and lead to res.

DON’T use makeshift stands and NEVER x with wood

screws. Use only the manufacturers supplied screws.

DON’T leave equipment switched on when it is unattended, unless it is specically stated that it is designed for unattended operation or has a standby mode. Switch off by withdrawing the plug, make sure your family know how to do this. Special arrangements may need to be made for people with disabilities.

DON’T continue to operate the equipment if you are in any doubt about it working normally, or it is damaged in any way

- switch off, withdraw the mains plug and consult your dealer.

WARNING - excessive sound pressure from earphones or headphones can cause hearing loss.

ABOVE ALL - NEVER let anyone, especially children, push or hit the screen, push anything into holes, slots or any other openings in the case.

NEVER guess or take chances with electrical equipment of any kind - it is better to be safe than sorry.

THE MAINS PLUG IS USED AS A DISCONNECTING DEVICE AND THEREFORE SHOULD BE READILY OPERABLE.

Note : Interactive video games that involve shooting a “gun” type of joystick at the on-screen target may not work with this TV.

English - 4 -

Installation and Important Information

Where to install

Sturdy tie

(as short

as possible)

* Button and stand style is dependent on model.

“P” Clip position on TV is dependent on model.

Locate the television away from direct sunlight and strong lights. Soft, indirect lighting is recommended for comfortable viewing. Use curtains or blinds to prevent direct sunlight falling on the screen.

Place the TV on a stable, level surface that can support the weight of the TV. In order to maintain stability and prevent it falling over, secure the TV to a wall using a sturdy tie on the back of the stand. The LCD display panels are manufactured using an extremely high level of precision technology; however, sometimes some parts of the screen may be missing picture elements or have luminous spots. This is not a sign of a malfunction. Make sure the television is located in a position where it cannot be pushed or hit by objects, as pressure will break

Please take note

The digital reception function of this television is only effective in the countries listed in the “Country” section

during the rst time installation menu. Depending on country/area, some of this television’s functions may not be available. Reception of future additional or modied services cannot be guaranteed with this television.

If stationary images generated by 4:3 broadcasts, text services, channel identication logos, computer displays,

video games, on screen menus, etc. are left on the television screen for any length of time, they could become conspicuous. It is always advisable to reduce both the brightness and contrast settings.

Very long, continuous use of the 4:3 picture on a 16:9 screen may result in some retention of the image at the 4:3 outlines. This is not a defect of the LCD TV and is not covered under the manufacturer’s warranty.

Regular use of other size modes will prevent permanent retention.

EXCLUSION CLAUSE

Toshiba shall under no circumstances be liable for loss and/or damage to the product caused by:

i) re;

ii) earthquake;

iii) accidental damage;

iv) intentional misuse of the product;

v) use of the product in improper conditions;

vi) loss and/or damage caused to the product whilst in the possession of a third party;

vii) any damage or loss caused as a result of the owner’s failure and/or neglect to follow the instructions set out in the

owner’s manual;

viii) any loss or damage caused directly as a result of misuse or malfunction of the product when used simultaneously with

associated equipment;

Furthermore, under no circumstances shall Toshiba be liable for any consequential loss and/or damage including but not limited to the following, loss of prot, interruption of business, the loss of recorded data whether caused during normal operation or misuse of the product.

or damage the screen. Also, please be certain that small items cannot be inserted into slots or openings in the case.

Avoid using chemicals (such as air refreshers, cleaning agents, etc.) on or near the TV pedestal. Studies

indicate that plastics may weaken and crack over time from the combination effects of chemical agents and mechanical stress (such as weight of TV). Failure to follow these instructions could result in serious injury and/or permanent damage to TV and TV pedestal. Cleaning the screen and cabinet… Turn off the power, and clean the screen and cabinet with a soft, dry cloth. We recommend that you do not use any proprietary polishes or solvents on the screen or cabinet as this may cause damage.

English

English - 5 -

Important safety information

• Any function relative to the digital television (with the DVB logo) is available only within the country or area

English

where such signals are transmitted. Verify with the salesperson if it is possible to receive a DVB-T signal in the zone where you live.

• Even if the television conforms to the DVB-T specications, the compatibility to future digital DVB-T

transmissions is not guaranteed.

• Some digital television functions may not be available in some countries.

• The DVB-T system present in this device is FTA (Free to air).

• DVB is a registered trademark of the DVB Project. This logo indicates that the product is compliant with

European Digital Broadcasting.

IMPORTANT INFORMATION

TV Installation

• Not standing the televisions on cloth or other materials placed between the television and supporting furniture.

• Educating children about the dangers of climbing on furniture to reach the television or its controls.

• Always hold the plug when disconnecting the unit from the socket outlet. Do not pull on ex. The ex can

become damaged and cause a short circuit.

• Use a soft, dry cloth to clean the unit.

• Set up unit so that no one will trip over the ex.

• If you intend to wall mount the unit, contact the shop where you purchased the unit for advice, and leave the

installation work to professionals. Improper installation can cause damage and/or injuries.

• To protect the unit during a thunder storm, unplug the AC power cord and disconnect the aerial, cable and

satellite decoder/systems etc.

Caution: Do not touch the aerial connector.

• The unit becomes warm when in operation. Do not place any covers or blankets on the unit in order to

prevent overheating.

The ventilation holes should not be blocked. Do not set up near radiators. Do not place in direct sunshine.

• Moisture condensation occurs in the following situations:

- When you move the unit from a cold place to a warm place.

- When you use the unit in a room where the heater was just turned on.

- When you use the unit in an area where cold air from an air conditioner directly hits the unit.

- When you use the unit in a humid place.

• Never use the unit when moisture condensation could occur.

• Using the unit when moisture condensation exists may damage its own internal parts. After two or three

hours, the unit will warm up and moisture will be evaporated.

English - 6 -

Removing the pedestal stand

When using a Wall Bracket

Please use a wall bracket appropriate for the size and weight of the LCD TV.

• Two people are required for installation.

• To install a wall-mount from another manufacturer.

(1) Unplug and remove any cables and/or other component connectors from the rear of the TV.

(2) Carefully lay the front of the unit face down on a at, cushioned surface such as a quilt or blanket.

(3) Follow the instructions provided with your wall bracket. Before proceeding, make sure the appropriate bracket(s) are attached to the wall and the back of the TV as described in the instructions provided with the wall bracket.

(4) Always use the screws supplied or recommended by the wall mount manufacturer.

Note :

• The bracket shown above is a sample image. The bracket and xings are not supplied with the TV.

Removing the pedestal stand

(1) Carefully lay the front of the unit face down on a at, cushioned surface with the stand hanging over the edge. (2) Remove the screws. (3) After the screws are removed, hold the pedestal stand in place,then remove the pedestal stand and the

plastic moulding from the TV by removing away from the TV.

NOTE: Extreme care should always be used when removing the pedestal stand to avoid damage to the LCD

panel.

English

For 32D1333B and 32D1334B models

English - 7 -

English

The Remote Control (TV - DVD)

Simple at-a-glance reference of your remote control.

1. Standby

20. Green button

Standby

2. Image size

PRESETS

SCREEN

SLEEP

FAV

LANG.

3. Sleep Timer

4. Mono/Stereo - Dual I-II / Currrent

Language (in DVB channels)

Language selection (Set language)

5. No function

EPG

SWAP

SOURCE

6. Numeric buttons

Numeric buttons

7. Electronic programme guide(in

DVB channels)

21. Picture mode selecion

22. No function

23. Teletext / Mix (in TXT mode)

24. Subtitle on-off (in DVB channels)

25. Previous programme

26. AV / Source selection

27. Menu on-off

28. Okay (Conrm) / Hold (in TXT

8. No function

9. Media Browser

Angle

29. Exit / Return / Index page (in TXT

10. Navigation buttons

DISP.

MODE

INFO

(Up/Down/Left/Right)

Navigation buttons (Up/Down/ Left/Right)

11. No function

12. No function

Clear

13. Programme Down /

Page up - Programme Up / Page down

Display time / DVD menu

14. Mute

Mute

15. No function

16. Pause

Pause

17. Rapid reverse

Rapid reverse

18. Play

30. No function

31. Info / Reveal (in TXT mode)

32. Volume Up / Down

33. No function

34. No function

35. Rapid advance

36. Stop

37. Blue button

38. Yellow button

Play

19. Red button

Zoom

Note: The references in Bold are when in

DVD mode.

Inserting Batteries and Effective Range of the Remote Control

Repeat

Subtitle

AV / Source selection

mode) / Channel List

mode)

Return

Search Mode

Info

Volume Up / Down

Skip Previous

Skip Next

Rapid advance

Stop

Title

Root

Remove the back cover to reveal the battery compartment and make sure the batteries are inserted the right way round. Suitable battery types for this remote are AAA, IEC R03 1.5V.

Do not combine a used, old battery with a new one or mix battery types. Remove exhausted batteries immediately to prevent acid from leaking into the battery compartment. Dispose of them in a designated disposal area.

Warning: Batteries must not be exposed to excessive heat such as sunshine, re or the like.

The performance of the remote control will deteriorate beyond a distance

of ve metres or outside an angle of 30 degrees from the IR receiver. If the

operating range becomes reduced the batteries may need replacing.

English - 8 -

Connecting External Equipment

Before connecting any external equipment, remove the mains plug from the wall socket.

Side View

COMMON INTERFACE

The Common Interface is for a Conditional Access Module (CAM).

HDMI Input

D IH M 2

D IH M 1

Sockets

Max:500mA

5Vdc

USB Input

English

DIGITAL AUDIO

* a decoder could be Digital Satellite, Free to Air or any other compatible decoder.

Socket

decoder*

SPDIF

Coax.OUT

SCART Socket

Aerial cable:...........................................................

Connect the aerial to the ANT. socket on the rear of the TV.

SCART lead:..........................................................

If you use a decoder* or a media recorder, it is essential that the scart cable is connected to the TV.

Before running rst time installation, any connected devices need to be set to standby mode.

The DIGITAL AUDIO socket enables the connection of a suitable surround sound system.

HDMI® (High-Denition Multimedia Interface) is for using with a DVD decoder or other equipment with digital audio and video output. It is designed for best performance with 1080i

and 1080p high-denition video signals but will also accept

and display VGA, 480i, 480p, 576i, 576p and 720p signals. PC format signals will also be displayed.

NOTE: Although this TV is able to connect to HDMI equipment,

it is possible that some equipment may not operate correctly.

RGB/PC Input

Aerial Input

Max:500mA

5Vdc

USB Input

SIDE AV

Headphone

YPbPr

When connecting a device via the Side AV input, you must use the supplied connection cable to enable connection.

When connecting a device via YPbPr input, you must use the

supplied connection cable to enable connection.

A wide variety of external equipment can be connected to the TV; therefore, the relevant owner’s manuals for all additional equipment must be referred to for exact instructions.

If the TV automatically switches over to monitor external equipment, return to normal TV by pressing the desired programme position button. To recall external equipment, press SOURCE button repeatedly to switch between sources.

Regardless of source’s property, audio output from the

DIGITAL AUDIO socket cannot be copied.from the DIGITAL AUDIO socket cannot be copied.

English - 9 -

Connecting an HDMI® or DVI Device to the HDMI Input

English

The HDMI inputs on your TV receive digital audio and uncompressed digital video from an HDMI source device or uncompressed digital video from a DVI (Digital Visual Interface) source device.

These inputs are designed to accept HDCP (High-Bandwidth Digital-Content Protection) programme material in digital form from EIA/CEA-861-D–compliant [1] consumer electronic devices (such as a set-top box or DVD player with HDMI or DVI output).

NOTE:

• Some early HDMI equipment may not work properly with

your latest HDMI TV.

• Supported Audio format: Linear PCM, sampling rate 32/44.1/48kHz.

To Connect an HDMI Device

Connect an HDMI cable (type A connector) to the HDMI ter-

minal. For proper operation, it is recommended that you use an HDMI cable with the HDMI Logo ( ).

• If your HDMI connection is capable of 1080p and/or your TV is capable of refresh rates greater than 50Hz, you

will need a Category 2 cable. Conventional HDMI/DVI cable

may not work properly with this mode.

• HDMI cable transfers both video and audio. Separate analogue audio cables are not required (see illustration).

• To view the HDMI device video, press SOURCE button to

select HDMI1 or HDMI2.

To Connect a DVI Device

Connect an HDMI-to-DVI adaptor cable (HDMI type A con-

nector) to the HDMI input socket and audio cables to the RED and WHITE SIDE AV AUDIO inputs on the Audio/Video

connection cable supplied (see illustration).

• The maximum HDMI-to-DVI adaptor cable length is 6.6 ft (2m).

• An HDMI-to-DVI adaptor cable transfers video only. Separate analogue audio cables are required.

D IH M 1

D IH M 2

HDMI Input Socket (Back)

NOTE:

D IH M 1

D IH M 2

To ensure that the HDMI or DVI device is reset properly, it is recommended that you follow these procedures:

• When turning on your electronic components, turn on the TV rst, and then the HDMI or DVI device.

• When turning off your electronic components, turn off the HDMI or DVI device rst, and then the TV.

HDMI device

English - 10 -

Connecting a Computer

Connecting a USB Memory

English

To Connect a Computer

With either an RGB/PC or an HDMI connection, you can watch

your computer’s display on the TV and hear the sound from the TV’s speakers.

When connecting a PC to the RGB/PC input on TV, use an analogue RGB (15-pin) computer cable and use the SIDE AV socket with a PC audio cable (not supplied) for audio

connection, using the supplied Side AV connection cable’s

RED and WHITE inputs (see illustration).

PC VGA Cable (not supplied)

RGB/PC Input

(back)

SIDE AV Input

To use a PC, set the monitor output resolution on the PC before connecting it to the TV. To display the optimum picture, use the PC setting feature.

NOTE:

SIDE AV

Side Audio/Video Connection Cable

(supplied)

PC Audio Cable

(not supplied)

• Some PC models cannot be connected to this TV. An adaptor is not needed for computers with a compatible mini D-sub15-pin terminal.

• Depending on the DVD’s title and the specications

of the PC on which you are playing the DVD-Video, some scenes may be skipped or you may not be able to pause during multiangle scenes.

To Connect a USB Flash Drive

• You can connect a USB Flash Drive to your TV by

using the USB input of the TV. This feature allows

you to display/play music, photo or video les stored

in a USB stick.

• It is possible that certain types of USB devices (e.g. MP3 Players) may not be compatible with this TV.

• You may back up your les before making any

connections to the TV set in order to avoid any possible data loss. Note that manufacturer will not

be responsible for any le damage or data loss.

• Do not pull out USB module while playing a le.

CAUTION: Quickly plugging and unplugging USB devices. This may cause damage to the USB device

itself.

English - 11 -

Power Save Mode

English

Environmental Information

This television is designed to consume less energy to save environment. You not only help to save the environment but also you can save money by reducing electricity bills thanks to the energy efciency feauture of this TV. To reduce energy consumption, you should take the following steps:

You can use Power Save Mode setting, located in the Picture Settings menu. If you set Power Save Mode as

Eco, the TV will switch to energy-saving mode and luminance level of TV set will be decreased to optimum level. Note that some picture settings will be unavailable to be changed when the TV is in Power Save Mode.

If Picture Off is selected, “Screen will be off in 3 seconds.” message will be displayed on the screen. Select PROCEED and press OK to continue. The screen will be off in 15 seconds. If you disable Power Save Mode, Picture mode will be automatically set to Dynamic.

When the TV is not in use, please switch off or disconnect the TV from the mains plug. This will also reduce energy consumption.

Disconnect power when going away for longer time.

It is highly recommended to activate Power Save Mode setting to reduce your annual power consumption. And also it is recommended to disconnect the TV from the mains plug to save energy more when you do not use.

Please helps us to save environment by following these steps.

Repair Information

Please refer all servicing to qualied personnel. Only qualied personnel must repair the TV. Please contact

your local dealer, where you have purchased this TV for further information.

English - 12 -

Controlling the TV

A wide variety of external equipment can be connected via the sockets located on the side and back of the

TV. Whilst all the necessary adjustments and controls for the TV are made using the remote control, the

buttons on the Back of the TV may be used for some functions.

English

Switching on

If the standby LED is unlit, check that the mains plug is connected to the power and press the / I button on the back

side of the television to switch the television on.

To put the television into Standby, press button on the remote control or on the TV. To view the television, press button again. The picture may take a few seconds to appear.

Note: The active Standby LED colour will turn to red in a few moments when the TV is switched off.

For energy saving:

Turning the TV off at its mains supply, or un-plugging it, will cut energy use to nearly zero for all TV’s. This is recommended when the TV is not being used for a long time, e.g. when on holiday.

Reducing the brightness of the screen will reduce energy use.

Energy efciency cuts energy consumption and thus saves

money by reducing electricity bills.

NOTE: Putting the TV into standby mode, will reduce energy consumption, but will still draw some power.

Using the Remote Control

Press the MENU button on the remote control to see the menus.

The main menu appears as a group of icons each for a menu option. Press the Left or Right button to select a topic.

In sub menu screen mode the menu appears as a list. Press the Up or Down button to select a topic.

To use the options press the Up and Down buttons on the remote control to move up and down through them and OK, Left or Right buttons to select the required choice. Follow the on screen instructions. The functions of each menu are described in detail throughout the manual.

Using the Controls on the TV

Using the control buttons on the Back of the TV:

• To alter the volume press + or - .

• To alter the programme position press

Back of the TV.

• Press + - buttons at the same to view main menu and

To select an external input, press until the appropriate input source is selected.

Please always refer to the owner’s manual of the equipment to be connected for full details..

use

to navigate and + - to change value.

on the

English - 13 -

Initial Installation

Before switching on the TV, put your decoder and media recorder to Standby if they are connected and

English

ensure the aerial is connected to your TV. To set up the TV, use the buttons on the remote control as

detailed on page 8.

IMPORTANT: Ensure that the aerial is connected and a Common Interface module is not inserted before

switching on the TV for the rst time installation.

1. Connect the mains plug and switch the TV to

on on using the / I button. If the TV does not switch on, press any numbered or button on the remote control, then the language selection menu will be displayed. This screen will appear

the rst time that the TV is switched on and each

time the TV is reset.

2. By pressing Up or Down button, highlight the language you want to set and press OK button.

The following message will be displayed next:

5. Press OK button on the remote control to continue

and the following message will be displayed on

the screen:

6. Select Yes button by using Left or Right button and press OK button to continue. Afterwards, the

following OSD will be displayed on the screen:

7. If you select Cable option, the following screen

will be displayed:

Note: Although this cable feature can be selected,

it is not fully supported in the UK. If cable signals are input to this TV from a Cable Network Provider some may be displayed.

3. By pressing Left or Right button, select the country you want to set and press Down button to highlight the Search Type option. Use Left or Right to set the desired search type. Available

search types are digital only, analog TV only and full.

4. When set, Down buton to select Teletext Language. Use Left or Right button to select desired Teletext Language.

English - 14 -

8. You can select frequency ranges from this screen. For highlighting lines you see, use Up or Down button. You can enter the frequency range

manually by using the numeric buttons on the remote control. Set Start and Stop Frequency as desired by using numeric buttons on the remote control. After this operation, you can set Search Step as 8000 kHz or 1000 kHz. If you select 1000 kHz, the TV will perform search process in a detailed way. Searching duration will thus

increase accordingly. When nished, press OK

button to start automatic search.

Auto TuningInitial Installation - continued

English

9. If you select Aerial option from the Search Type

screen, the television will search for broadcasts.

10. The Auto tuning screen will appear and the

television will start to search for available stations.

The progress bar will move along the line. You

must allow the television to complete the search. The following OSD will be displayed on the screen and the television will search for the selected

broadcasts:

Note: You can press MENU button to cancel.

After the available stations are stored, Channel List will be displayed on the screen.

• Press OK button to quit channel list and watch TV.

Note:

Do not turn off the TV while initializing rst time

installation.

Keep the menu of Store Mode Disabled and do not change it, when using at home.

• Press the Left or Right button to choose the required

language region.

• After the Teletext language is selected, press MENU

button to exit.

Auto Tuning

As new services are broadcast, it will be necessary to retune the television in order to view them.

• Auto Tuning will completely retune the television and can be used to update the channel list. It is recommended that Auto Tuning is run periodically to ensure that all new services are added. All current channels and settings, i.e. locked channels, will be lost.

• Press MENU button on the remote control and select Install and Retune by using Left or Right button.

Press OK button and the following menu screen will be displayed.

• Select Automatic Channel Scan (Retune) by using Up or Down button and press OK button. Automatic

Channel Scan options will be displayed. You can select

options by using Up or Down and OK buttons.

Auto Channel Scan Menu Operation

Digital: Searches and stores aerial DVB stations.

Analogue: Searches and stores analogue stations.

Full: Searches and stores both analogue and aerial

DVB stationsres both analogue and cable DVB stations.

• Whenever you select an automatic search type and press OK button, a conrmation screen will appear on the screen. To start installation process, select Yes, to cancel select No by using Left or Right and OK button.

• After auto channel scan type is set and selected and conrmed, installation process will start and

progress bar will move along. Press MENU button to cancel process. In such a case, located channels are not stored. The television will start to search for

all available stations. You must allow the television

to complete the search.

English - 15 -

+ 37 hidden pages
