Integrated High Definition

DRAFT1

LCD TV/DVD Combination

HIGH-DEFINITION TELEVISION

26LV47

For an overview of steps for setting up your new TV, see page 12.

Note: To display a High Definition picture, the TV must be receiving a High Definition signal (such as an over-the-air High Definition TV broadcast, a High Definition digital cable program, or a High Definition digital satellite program). For details, please contact your TV antenna installer, cable provider, or satellite provider.

Owner’s Record

The model number and serial number are on the back of your TV. Record these numbers in the spaces below. Refer to these numbers whenever you communicate with your Toshiba dealer about this TV.

Model number: 26LV47

Serial number:

YC/M

VX1A00068600

Dear Customer,

Thank you for purchasing this Toshiba LCD TV or TV/DVD Combination. This manual will help you use the many exciting features of your new LCD TV. Before operating your TV/DVD Combination, please read this manual completely, and keep it nearby for future reference.

Safety Precautions

WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

WARNING

RISK OF ELECTRIC SHOCK

DO NOT OPEN.

NOTE TO CATV INSTALLERS

This is a reminder to call the CATV system installer’s attention to Article 820-40 of the U.S. NEC, which provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of cable entry as practical. For additional antenna grounding information, see items 27 and 28 on page 4.

Child Safety

It Makes A Difference Where Your TV Stands

Congratulations on your purchase! As you enjoy your new TV, keep these safety tips in mind:

WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

WARNING

To prevent injury, this apparatus must be securely attached to the floor/wall in accordance with the installation instructions. See item 20 on page 3.

WARNING: If you decide to wall mount this television,

always use a UL Listed wall bracket appropriate for the size and weight of this television. The use of any wall bracket other than a UL Listed wall bracket appropriate for the size and weight of this television for wall mounting this television could result in serious bodily injury and/or property damage. See “Removing the Pedestal Stand” (- page 5).

TV/DVD Combination Precautions

The DVD player contained in this TV contains a laser beam. Do not attempt to stare at the beam through the TV disc tray or the ventilation openings. Staring directly at the beam may cause permanent damage to your eyesight.

The DVD player contained in this TV contains a Laser System. To ensure proper use of this TV and the DVD player contained therein, please read this owner’s manual carefully and retain it for future reference. Should the unit require maintenance, contact an authorized service location. Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure. To prevent direct exposure to the laser beam, do not try to open the enclosure. Visible and invisible laser radiation may be present when open and interlocks defeated. DO NOT STARE INTO the BEAM.

The Issue

a If you are like most consumers, you have a TV in your home.

Many homes, in fact, have more than one TV. The home theater entertainment experience is a growing trend,

and larger TVs are popular purchases; however, they are not always supported on the proper TV stands.

a Sometimes TVs are improperly secured or inappropriately

situated on dressers, bookcases, shelves, desks, audio

speakers, chests, or carts. As a result, TVs may fall over,

causing unnecessary injury.

Toshiba Cares!

a The consumer electronics industry

is committed to making home entertainment

enjoyable and safe.

The Consumer Electronics Association

formed the Home Entertainment Support Safety Committee, comprised of TV and

consumer electronics furniture

manufacturers, to advocate children’s safety

and educate consumers and their families

about television safety.

Tune Into Safety

a One size does NOT fit all! Use appropriate furniture large enough to support the weight of your TV (and other electronic components).

Use appropriate angle braces, straps, and anchors to secure your

furniture to the wall (but never screw anything directly into the TV).

a Carefully read and understand the other enclosed

instructions for proper use of this product.

a Do not allow children to climb on or play with furniture and TVs. a Avoid placing any item on top of your TV (such as a VCR, remote

control, or toy) that a curious child may reach for.

a Remember that children can become excited while watching

a program and can potentially push or pull a TV over.

a Share our safety message about this hidden hazard of the home

with your family and friends. Thank you!

2500 Wilson Blvd. Arlington, VA 22201 U.S.A. www.CE.org

CEA is the Sponsor, Producer and

Manager of the International CES

Important Safety Instructions

1) Read these instructions.

2) Keep these instructions.

3) Heed all warnings.

4) Follow all instructions.

5) Do not use this apparatus near water.

6) Clean only with dry cloth.

7) Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.

8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.

9) Do not defeat the safety purpose of

the polarized or grounding type plug. A polarized plug has two blades

with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.

10) Protect the power cord from being walked on or pinched, particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

11) Only use attachments/accessories specified by the

manufacturer.

12) Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use

caution when moving the cart/apparatus combination to avoid injury from tip-over.

13) Unplug this apparatus during lightning storms or

when unused for long periods of time.

14) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

Additional Safety Precautions

14a) CAUTION: If the TV is dropped and the cabinet or

enclosure surface has been damaged or the TV does not operate normally, take the following precautions:

• ALWAYS turn off the TV and unplug the power cord to

avoid possible electric shock or fire.

• NEVER allow your body to come in contact with any

broken glass or liquid from the damaged television. The LCD panel inside the TV contains glass and a toxic liquid. If the liquid comes in contact with your mouth or eyes, or your skin is cut by broken glass, rinse the affected area thoroughly with water and consult your doctor.

• ALWAYS contact a service technician to inspect the TV

any time it has been damaged or dropped.

Wide blade

15) CAUTION:

• To reduce the risk of electric shock, do not use the polarized plug with an extension cord, receptacle, or other outlet unless the blades can be inserted completely to prevent blade exposure.

• To prevent electric shock, match wide blade of plug to wide slot; fully insert.

16) WARNING: To prevent the spread of fire, keep candles or other open flames away from this product at all times.

Installation, Care, and Service

Installation

Follow these recommendations and precautions and heed all warnings when installing your TV:

17) Never modify this equipment. Changes or modifications may void: a) the warranty, and b) the user’s authority to operate this equipment under the rules of the Federal Communications Commission.

18) DANGER: RISK OF

SERIOUS PERSONAL INJURY, DEATH, OR EQUIPMENT DAMAGE!

Never place the TV on an unstable cart, stand, or table. The TV may fall, causing serious personal injury, death, or serious damage to the TV.

19) To avoid damage to this product, never place or store the TV in direct sunlight; hot, humid areas; or areas subject to excessive dust or vibration.

20) Always place the TV on the floor or a sturdy, level, stable surface that can support the weight of the unit. To secure the TV, use a sturdy tie from the hooks on the rear of the TV pedestal to a wall, pillar, or other immovable structure. Make sure the tie is tight, secure, and parallel to the floor.

Sturdy tie (as short as possible)

min.

Clip

TV side TV top

21) The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such as vases, shall be placed on the apparatus.

22) Never block or cover the slots or openings in the TV cabinet back, bottom, and sides. Never place the TV:

• on a bed, sofa, rug, or similar

surface;

• too close to drapes, curtains, or

walls; or

• in a confined space such as a

bookcase, built-in cabinet, or any other place with poor

ventilation. The slots and openings are provided to protect the TV from overheating and to help maintain reliable operation of the TV. Leave a space of at least 4 (four) inches around the TV. (5 inches away from the TV slot side).

Hooks

Clip

(continued)

23) Always place the back of the television at least four (4) inches away from any vertical surface (such as a wall) to allow proper ventilation.

24) Never allow anything to rest on or roll over the power cord, and never place the TV where the power cord is subject to wear or abuse.

25) Never overload wall outlets and extension cords.

26) Always operate this equipment from a 120 VAC, 60 Hz power source only.

27) Always make sure the antenna system is properly grounded to provide adequate protection against voltage surges and built-up static charges (see Section 810 of the National Electric Code).

Antenna lead-in wire

Antenna discharge unit

Ground clamp

Electric service equipment

(NEC Section 810-20)

Grounding conductors (NEC Section 810-21)

31)

WARNING:

RISK OF ELECTRIC SHOCK!

Never spill liquids or push objects of any kind into the TV cabinet slots.

32) While it is thundering, do not touch the connecting cables or apparatus.

33) For added protection of your TV from lightning and power surges, always unplug the power cord and disconnect the antenna from the TV if you leave the TV unattended or unused for long periods of time.

34) During normal use, the TV may make occasional snapping or popping sounds. This is normal, especially when the unit is being turned on or off. If these sounds become frequent or continuous, unplug the power cord and contact a Toshiba Authorized Service Center.

35)

WARNING: RISK OF SERIOUS PERSONAL INJURY OR EQUIPMENT DAMAGE!

Never strike the screen with a sharp or heavy object.

Power service grounding electrode system (NEC Art 250 Part-H)

28)

Ground clamps

DANGER: RISK OF SERIOUS

PERSONAL INJURY OR DEATH!

• Use extreme care to make sure you are never in a position where your body (or any item you are in contact with, such as a ladder or screwdriver) can accidentally touch overhead power lines. Never locate the antenna near overhead power lines or other electrical circuits.

• Never attempt to install any of the following during lightning activity: a) an antenna system; or b) cables, wires, or any home theater component connected to an antenna or phone system.

Care

For better performance and safer operation of your TOSHIBA TV, follow these recommendations and precautions:

29) If you use the TV in a room whose temperature is 32 ºF (0 ºC) or below, the picture brightness may vary until the LCD warms up. This is not a sign of malfunction.

30) Always unplug the TV before cleaning. Gently wipe the display panel surface (the TV screen) using a dry, soft cloth only (cotton, flannel, etc.). A hard cloth may damage the surface of the panel. Avoid contact with alcohol, thinner, benzene, acidic or alkaline solvent cleaners, abrasive cleaners, or chemical cloths, which may damage the surface. Never spray volatile compounds such as insecticide on the cabinet. Such products may damage or discolor the cabinet.

36) • The LCD screen of this product can be damaged by ultraviolet radiation from the sun. When selecting a location for the television, avoid locations where the screen may be exposed to direct sunlight, such as in front of a window.

• Never touch, press, or place anything on the LCD screen. These actions will damage the LCD screen. If you need to clean the LCD screen, follow the instructions in item 30 on this page.

Service

37)

RISK OF ELECTRIC SHOCK!

Never attempt to service the TV yourself. Opening and removing the covers may expose you to dangerous voltage or other hazards. Failure to follow this WARNING may result in death or serious injury. Refer all servicing not specified in this manual to a Toshiba Authorized Service Center.

38) If you have the TV serviced:

• Ask the service technician to use only replacement parts specified by the manufacturer.

• Upon completion of service, ask the service technician to perform routine safety checks to determine that the TV is in safe operating condition.

39) The cold cathode fluorescent lamp in the LCD panel contains a small amount of mercury.

When the TV reaches the end of its useful life, dispose of the used TV by the approved method for your area, or ask a qualified service technician to properly dispose of the TV.

Note: The lamp(s) inside this product contain mercury. Disposal may be regulated due to

environmental considerations. For disposal or recycling information, contact your local authorities or the Electronics Industries Alliance (www.eiae.org).

WARNING:

Choosing a location for your LCD TV

To Display your LCD TV on the included Pedestal Stand:

Observe the following safety precautions:

1) Read and Follow the pedestal assembly instructions included with the pedestal.

CAUTION: Before beginning pedestal assembly, carefully lay the front of the LCD Panel face down on a flat, cushioned surface such as a quilt or blanket. Leave the bottom of the unit protruding over the edge of the surface and assemble the pedestal as indicated below.

Note: Extreme care should always be used when attaching the pedestal stand to avoid damage to the LCD panel.

2) Place the TV on a sturdy, level surface that can support the weight of the TV.

3) Be sure to secure the TV to a wall, pillar, surface, or other immovable structure. To secure the TV in this manner, use the included strap located at the rear of pedestal stand. (- item 20, page 3).

To Display your LCD TV using a Wall Bracket:

If you decide to wall mount your LCD TV, always use a ULlisted wall bracket appropriate for the size and weight of the LCD TV (- page 2) :

1) CAUTION: Two people are required for installation.

2) Unplug and remove any cables and/or other component connectors from the rear of the TV.

3) Follow the instructions provided with your wall bracket. Before proceeding, make sure the appropriate bracket(s) are attached to the wall and the back of the TV as described in the instructions provided with the wall bracket.

4) After attaching the appropriate bracket(s) to the wall and the back of the TV, remove the pedestal stand from the TV as described below.

Removing the Pedestal Stand

1) Carefully lay the front of the unit face down on a flat, cushioned surface such as a quilt or blanket. Leave the stand protruding over the edge of the surface.

Note: Extreme care should always be used when removing the pedestal stand to avoid damage to the LCD panel.

2) Remove the jack pack cover on the back of the TV to expose the pedestal stand screws. The jack pack cover can be removed without tools.

3) Remove the five screws shown in the diagram below. This will allow removal of the pedestal stand.

4) Once you have removed all five screws holding the pedestal stand in place, remove the pedestal stand from the TV by sliding the pedestal stand away from the TV.

Safety and Care Information for TV/DVD Combination Models

DISC SLOT

• Keep your fingers well clear of the disc slot when the disc is loading or unloading. Neglecting to do so may cause personal injury.

LASER BEAM

• Never look into the opening of the disc slot or ventilation opening of the product to see the source of the laser beam. Staring directly at the beam may cause permanent damage to your eyesight.

DISC

• Do not use a cracked, deformed, or repaired disc. These discs are easily broken and may cause serious personal injury and product malfunction.

Precautions

VIBRATION

• Vibration or shock may disrupt DVD playback or cause scratches on the disc. Do not move or tilt or otherwise jolt the TV when a disc is loaded. The playback sound may skip if the TV is dropped from a height of 1.58 inch (4 cm) or more or if the TV is installed at a greater angle than recommended.

Notes on moisture condensation

Moisture condensation occurs, for example, when you pour a cold drink into a glass on a warm day. Drops of water form on the outside of the glass. In the same way, moisture may condense on the optical pick-up lens inside the DVD player, one of the most crucial internal parts of the DVD player.

Moisture condensation can occur in the following conditions:

• When the TV is moved directly from a cold or air conditioned area to a warm or humid area.

• When the TV is placed in an area in which the heat has just been turned on, or where cold air from an air conditioner falls directly on the TV.

Optical pick-up

lens

Five screws

(continued)

Do not use the DVD player when moisture condensation may be present.

If you use the DVD player in such a situation, the DVD player and/or discs may become damaged. Connect the power cord of the TV to the wall outlet, turn on the TV, remove the disc, and leave the TV on for two or three hours. After two or three hours, the TV will have warmed up and evaporated any moisture. Leaving the TV connected to the wall outlet will help prevent moisture condensation in the TV or DVD player.

On storing discs

• Never store discs near heat sources or in an area subject to direct sunlight.

• Never store discs in places subject to moisture and dust (such as near a humidifier or in a bathroom).

• Store discs vertically in a case. Stacking or placing objects on discs outside of their case may cause warping.

Wait!

Notes on discs

On handling discs

• Do not touch the playback side of the disc. For example, handle the disc as shown below.

Playback side

• Do not attach paper or tape to discs.

Wall outlet

Structure of disc contents

Normally, DVD video discs are divided into titles, and the titles are sub-divided into chapters. Video CDs and Audio CDs are divided into tracks.

DVD video disc

Title 1 Title 2

Chapter 1 Chapter 2 Chapter 1 Chapter 2 Chapter 3

Video CD/Audio CD

Track 1 Track 2 Track 3 Track 4 Track 5

Each title, chapter or track is assigned a number (the “title number,” “chapter number,” and “track number,” respectively).

Some discs do not have these numbers.

Notes on copyright

DO NOT

On cleaning discs

• Fingerprints and dust on discs cause picture and sound deterioration. Wipe discs from the center outward with a soft cloth. Always keep discs clean.

DO DO NOT

• Never use any type of solvent (such as thinner, benzine, commercially available cleaners or antistatic spray for vinyl LPs). Using such solvents may damage the discs.

The unauthorized recording, use, distribution, or revision of television programs, videotapes, DVDs, and other materials is prohibited under the Copyright Laws of the United States and other countries, and may subject you to civil and criminal liability.

This product incorporates copyright protection technology that is protected by U.S. patents and other intellectual property rights. Use of this copyright protection technology must be authorized by Macrovision, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision. Reverse engineering or disassembly is prohibited.

Notes on region numbers

The region number of this DVD player of the TV is 1. If region numbers, which stand for their playable area, are printed on your DVD video disc and you do not find or , disc playback will not be allowed by the DVD player. (In this case, the TV will display a message on-screen.)

Some DVDs that have no region code label may still be subject to area restrictions and are therefore not playable.

ALL

Playable discs

This DVD player can play the following discs with the corresponding logo.

Disc Mark

DVD video discs

Video CDs

Audio CDs

The following discs may also be compatible:

DIGITAL VIDEO

DVD-R/RW discs in DVD video format. CD-R/CD-RW discs in CD-DA, Video CD, MP3, or JPEG format. Kodak Picture CD and FUJICOLOR CD format.

Contents

Audio

Video

(moving

pictures)

Audio

Video

(moving

pictures)

Audio

Disc Size

12 cm

8 cm

12 cm

8 cm

Maximum

playback time

Approx. 4 hours

(single-sided disc)

Approx. 8 hours

(double-sided disc)

Approx. 30 minutes

(single-sided disc)

Approx. 60 minutes

(double-sided disc)

Approx. 74 minutes

Approx. 22 minutes

CAUTION:

THIS DIGITAL VIDEO PLAYER EMPLOYS A LASER SYSTEM.

TO ENSURE PROPER USE OF THIS PRODUCT, PLEASE READ THIS OWNER’S MANUAL CAREFULLY AND RETAIN FOR FUTURE REFERENCE. SHOULD THE UNIT REQUIRE MAINTENANCE, CONTACT AN AUTHORIZED SERVICE LOCATION.

USE OF CONTROLS OR ADJUSTMENTS, OR THE PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN, MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.

TO PREVENT DIRECT EXPOSURE TO THE LASER BEAM, NEVER TRY TO OPEN THE ENCLOSURE. VISIBLE LASER RADIATION MAY BE PRESENT WHEN THE ENCLOSURE IS OPENED. NEVER STARE INTO THE BEAM.

Location of required label

HONG KONG TOHEI E.M.C. CO.,LTD.

CLASS 1 LASER PRODUCT

CAUTION:VISIBLE AND INVISIBLE

LASER RADIATION WHEN OPEN

AVOID EXPOSURE TO BEAM

Unit No.D,9th Floor, Spectrum Tower, 53 Hung To Road,Kwun Tong,Kowloon, Hong Kong

COMPLIES WITH 21 CFR

1040.10 AND 1040.11 EXCEPT FOR DEVIATIONS PURSUANT TO LASER NOTICE NO.50, DATED (JULY 26, 2001 ).

• You cannot play discs other than those listed above. You cannot play discs in formats such as DVD-RAM, DVD-ROM, Photo CD, Super Audio CD (SACD™), etc., or non standardized discs even if they may be labeled as above. The damage depending on the use of those discs is NOT covered under your Toshiba warranty.

• Some CD-R/RWs cannot be played back depending on the recording conditions.

• This TV uses the NTSC color system, and cannot play DVD video discs recorded in any other color system (for example, PAL or SECAM).

• Do not use the CD single adapter since it may not play properly.

Because of problems and errors that can occur during the creation of DVD and CD software and/or the manufacture of DVD and CD discs, Toshiba cannot assure that the DVD player contained in your TV/DVD Combination will successfully play every disc bearing the DVD and CD logos. If you happen to experience any difficulty playing a DVD and/or CD disc on the DVD player contained in your TV/DVD Combination, please contact Toshiba Customer Service.

Slot - in DVD / CD player module DVC - 303S - TO

No.XXXXX

FCC Declaration of Conformity

Important notes about your LCD Compliance Statement (Part 15):

The Toshiba 26LV47 Television complies with Part 15 of the FCC rules.

Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

The party responsible for compliance to these rules is: Toshiba America Consumer Products, L.L.C. 82 Totowa Rd. Wayne, NJ 07470. Ph: 1-800-631-3811

Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by removing and applying power to the equipment, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and the

receiver.

• Connect the equipment into an outlet on a circuit different

from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for

help.

Caution: Changes or modifications to this equipment not expressly approved by Toshiba could void the user’s authority to operate this equipment.

TV/DVD combination

The following symptoms are technical limitations of LCD

Display technology and are not an indication of malfunction;

therefore, Toshiba is not responsible for perceived issues

resulting from these symptoms.

1) An afterimage (ghost) may appear on the screen if a fixed, nonmoving image is displayed for a long period of time. The afterimage is not permanent and will disappear in a short period of time.

2) The LCD panel contained in this TV is manufactured using an extremely high level of precision technology; however, there may be an occasional pixel (dot of light) that does not operate properly (does not light, remains constantly lit, etc.). This is a structural property of LCD technology, is not a sign of malfunction, and is not covered under your warranty. Such pixels are not visible when the picture is viewed from a normal viewing distance.

Note: Interactive video games that involve shooting a “gun” type of joystick at an on-screen target may not work with this TV.

About this owner’s manual (DVD player section)

This owner’s manual explains the basic instructions for using the internal DVD player. Some DVDs are produced in a manner that allows specific or limited operation during playback. As such, the DVD player may not respond to all operating commands. This is not a defect in the DVD player.

Refer to the instructions provided with your DVDs. If the symbol “ ” appears on-screen during DVD operation, it

means that the operation or feature is not permitted or available for the DVD player or disc.

For example, sometimes the DVD player is unable to stop playback of the DVD’s copyright message when the D button is pressed.

Trademark Information

• WOW, SRS and l symbol are trademarks of SRS Labs, Inc.

WOW technology is incorporated under license from SRS Labs, Inc.

• Manufactured under license from Dolby Laboratories.

Dolby and the double-D symbol are registered trademarks of Dolby Laboratories.

• HDMI, the HDMI logo and High-Definition Multimedia Interface are

trademarks or registered trademarks of HDMI Licensing LLC.

• is a trademark of DVD Format/Logo Licensing Corporation.

Contents

Important Safety Instructions .......................................... 3

Installation, Care, and Service ........................................ 3

Safety and Care Information for

TV/DVD Combination Models .......................................... 5

Chapter 1: Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

Welcome to Toshiba . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Features of your new TV . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Overview of steps for installing, setting up, and using

your new TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

TV front and side panel controls and connections . . . . . . . . 13

TV back panel connections . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Chapter 2: Connecting your TV . . . . . . . . . . . . . . . . . . . . . . .15

Overview of cable types . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

About the connection illustrations . . . . . . . . . . . . . . . . . . . . 15

Connecting a VCR and antenna or Cable TV

(no Cable box) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Connecting a VCR with S-video and a cable box . . . . . . . . 17

Connecting a DVD player with ColorStream

(component video), a VCR, and a satellite receiver. . . . 18

Connecting a camcorder . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Connecting an HDMI

™

or DVI device to the HDMI

input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Connecting a digital audio system . . . . . . . . . . . . . . . . . . . . 21

Connecting an audio system . . . . . . . . . . . . . . . . . . . . . . . . . 21

Connecting a personal computer (PC) . . . . . . . . . . . . . . . . . 22

Chapter 3: Using the remote control . . . . . . . . . . . . . . . . . . .23

Preparing the remote control for use. . . . . . . . . . . . . . . . . . . 23

Installing the remote control batteries . . . . . . . . . . . . . . . . . 23

Remote control effective range . . . . . . . . . . . . . . . . . . . . . . . 23

Learning about the remote control . . . . . . . . . . . . . . . . . . . . 24

Using the remote control to control your other devices . . . . 25

Remote Control functional key chart . . . . . . . . . . . . . . . . . . 26

Programming the remote control to control your other

devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Remote control codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Chapter 4: Menu layout and navigation . . . . . . . . . . . . . . . . .30

Main menu layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Setup/Installation menu layout . . . . . . . . . . . . . . . . . . . . . . . 31

Navigating the menu system . . . . . . . . . . . . . . . . . . . . . . . . . 31

Chapter 5: Setting up your TV. . . . . . . . . . . . . . . . . . . . . . . .32

Selecting the menu language . . . . . . . . . . . . . . . . . . . . . . . . 32

Configuring the antenna input source for the ANT

terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Programming channels into the TV’s channel memory . . . . 33

Programming channels automatically . . . . . . . . . . . . . . 33

Manually adding and deleting channels in the channel

memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Labeling channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Setting the HDMI

™

audio mode . . . . . . . . . . . . . . . . . . . . . . 35

Viewing the digital signal meter . . . . . . . . . . . . . . . . . . . . . . 36

Viewing the system status. . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Chapter 6: Using the TV’s features . . . . . . . . . . . . . . . . . . . .38

Selecting the video input source to view . . . . . . . . . . . . . . . 38

Labeling the video input sources . . . . . . . . . . . . . . . . . . . . . 38

Tuning channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Tuning channels using the Channel Browser

™

. . . . . . . 39

Tuning to the next programmed channel . . . . . . . . . . . . 41

Tuning to a specific channel (programmed or

unprogrammed) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Switching between two channels using Channel

Return . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Switching between two channels using SurfLock

Selecting the picture size . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Scrolling the TheaterWide


™

. . . . 41

(TheaterWide 2 and 3 only) . . . . . . . . . . . . . . . . . . . . . . 43

Using the auto aspect ratio feature . . . . . . . . . . . . . . . . . . . . 44

Selecting the cinema mode (480i and 1080i signals) . . . . . . 44

Adjusting the picture. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Selecting the picture mode . . . . . . . . . . . . . . . . . . . . . . . 45

Adjusting the picture quality . . . . . . . . . . . . . . . . . . . . . 45

Using the closed caption mode . . . . . . . . . . . . . . . . . . . . . . . 46

Base closed captions . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Digital CC Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

CC Selector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Adjusting the audio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Muting the sound . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Using the digital audio selector . . . . . . . . . . . . . . . . . . . 47

Selecting stereo/SAP broadcasts . . . . . . . . . . . . . . . . . . 48

Adjusting the audio quality . . . . . . . . . . . . . . . . . . . . . . 48

Using the StableSound

Selecting the optical audio output format . . . . . . . . . . . 49

Using the Dolby

feature . . . . . . . . . . . . . . . . . . . 49

Digital Dynamic Range

Control feature. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

Using the Locks menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Entering the PIN code . . . . . . . . . . . . . . . . . . . . . . . . . . 50

If you cannot remember your PIN code. . . . . . . . . . . . . 50

Changing your PIN code . . . . . . . . . . . . . . . . . . . . . . . . 50

Blocking TV programs and movies by rating

(V-Chip) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

Downloading an additional rating system for blocking

TV programs and movies . . . . . . . . . . . . . . . . . . . . 51

Blocking channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

Unlocking programs temporarily . . . . . . . . . . . . . . . . . . 53

Using the input lock feature. . . . . . . . . . . . . . . . . . . . . . 53

Using the control panel lock feature . . . . . . . . . . . . . . . 54

Using the PC settings feature . . . . . . . . . . . . . . . . . . . . . . . . 54

Setting the PC Audio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Setting the sleep timer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Displaying TV status information. . . . . . . . . . . . . . . . . . . . . 56

Understanding the auto power off feature . . . . . . . . . . . . . . 56

Understanding the last mode memory feature . . . . . . . . . . . 56

Chapter 7: Using the TV’s advanced features . . . . . . . . . . . . .57

Using the advanced picture settings features . . . . . . . . . . . . 57

Using dynamic contrast . . . . . . . . . . . . . . . . . . . . . . . . . 57

Using the static gamma feature . . . . . . . . . . . . . . . . . . . 57

Selecting the color temperature . . . . . . . . . . . . . . . . . . . 58

Using CableClear

digital noise reduction . . . . . . . . . . 58

Using MPEG noise reduction. . . . . . . . . . . . . . . . . . . . . 59

Using the Game Mode feature . . . . . . . . . . . . . . . . . . . . 59

Using the advanced audio settings features . . . . . . . . . . . . . 60

Using the SRS WOW

™

surround sound feature . . . . . . 60

Chapter 8: DVD Playback. . . . . . . . . . . . . . . . . . . . . . . . . . .61

Playing a disc . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Basic playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Using the DVD aspect ratio feature . . . . . . . . . . . . . . . . . . . 63

Playing in fast reverse or fast forward . . . . . . . . . . . . . . . . . 63

To pause playback (still playback) . . . . . . . . . . . . . . . . . . . 63

Playing frame by frame . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

Playing in slow motion . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

Locating a chapter or track . . . . . . . . . . . . . . . . . . . . . . . . . 64

Changing angles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

Title selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

Changing soundtrack language . . . . . . . . . . . . . . . . . . . . . . 65

Subtitles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

Disc status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

(continued)

MP3/JPEG CD operation . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

MP3/JPEG CD information . . . . . . . . . . . . . . . . . . . . . 66

MP3 CD playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

JPEG CD playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

Chapter 9: Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . .69

General troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

DVD Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

LED indications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

Chapter 10: Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . .72

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

Limited United States Warranty

for LCD TV/DVD Combinations 26” and Larger . . . . . 73

Limited Canadian Warranty

for Toshiba Brand Flat Panel Televisions . . . . . . . . . . . 74

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .77

Chapter 1: Introduction

Welcome to Toshiba

Thank you for purchasing this Toshiba LCD TV/DVD combination, one of the most innovative LCD TVs on the market. This digital television is capable of receiving analog basic, digital basic and digital premium cable television programming by direct connection to a cable system providing such programming. A security card provided by your cable operator is required to view encrypted digital programming. Certain advanced and interactive digital cable services such as video-on-demand, a cable operator's enhanced program guide and data-enhanced television services may require the use of a set-top box. For more information call your local cable operator.

Features of your new TV

The following are just a few of the many exciting features of your new Toshiba widescreen, integrated HD, LCD TV:

• Integrated digital tuning (8VSB ATSC and QAM)

eliminates the need for a separate digital converter set-top box (in most cases).

• Three HDMI

interfaces 1080p input support (- page 20).

• Two sets of ColorStream

video inputs (- page 18).

• SRS WOW

• Digital Audio Out optical audio connection with Dolby

Digital optical output format (- page 49).

• CableClear

(- page 58).

• PC IN (Analog RGB) computer terminal (- page 22).

• DVD video (and Video CD, Audio CD) player

(- page 61).

• Channel Labeling allows you to put the Call Letters (e.g.

ABC, HBO, etc.) on the screen along with the station numbers, so you always know what you’re watching (- page 34).

™

digital, high-definition multimedia

HD high-resolution component

™

audio technologies (- page 60).

digital picture noise reduction

Chapter 1: Introduction

Overview of steps for installing, setting up, and using your new TV

Follow these steps to set up your TV and begin using its many exciting features.

1 Carefully read the important safety, installation, care, and

service information. Keep this manual for future reference.

2 Observe the following when choosing a location for the

TV:

• Read “Important notes about your LCD TV/DVD

combination” (- page 8).

• Place the TV on the floor or a sturdy, level, stable

surface that can support the weight of the unit. Secure the TV to a wall, pillar, or other immovable structure (- page 3).

• Place the TV in a location where light does not reflect

on the screen.

• Place the TV far enough from walls and other objects to

allow proper ventilation. Inadequate ventilation may cause overheating, which will damage the TV. THIS TYPE OF DAMAGE IS NOT COVERED UNDER THE TOSHIBA WARRANTY.

3 Do not plug in any power cords until AFTER you have

connected all cables and devices to your TV.

4 BEFORE connecting cables or devices to the TV, learn

the functions of the TV’s connections and controls (

- pages 13–14).

5 Connect your other electronic device(s) to the TV

(

- pages 15–22).

6 Install the batteries in the remote control (- page 23). 7 See “Learning about the remote control” (- page 24) for

an overview of the buttons on the remote control.

8 Program the remote control to operate your other

device(s) (

9 AFTER connecting all cables and devices, plug in the

power cords for your TV and other devices. The yellow LED will blink until the TV goes into standby mode. When the TV is in standby mode, press POWER on the TV control panel or remote control to turn on the TV. If the TV stops responding to the controls on the remote control or TV control panel and you cannot turn the TV off or on, press and hold the POWER button for 5 seconds to reset the TV.

- pages 25–29).

10 See “Menu layout and navigation” for a quick overview of

navigating the TV’s menu system (

- page 30).

11 Program channels into the TV’s channel memory

(

- page 33).

12 For details on using the TV’s features, see Chapters 6

and 7.

13 For details on using the DVD’s features, see Chapter 8. 14 For help, refer to the Troubleshooting Guide, Chapter 9. 15 For technical specifications and warranty information, see

Chapter 10.

16 Enjoy your new TV/DVD!

Chapter 1: Introduction

TV front and side panel controls and connections

Left side panel

TV front

TV top

DISC POWER

1 Green and Yellow LEDs

Green = Power indicator Yellow = Disc indicator See “LED indications” on page 71 for additional

information.

2 Remote sensor — Point the remote control toward this

remote sensor (- “Remote control effective range” on page 23).

3 VIDEO-2 IN — The side panel A/V connections are

referred to as “VIDEO 2” and include standard A/V connections.

4 POWER — Press to turn the TV on and off.

If the TV stops responding to the controls on the remote control or TV control panel and you cannot turn off the TV, press and hold the POWER button on the TV control panel for 5 or more seconds to reset the TV.

5 ARROWS BbC c — When a menu is on-screen, these

buttons function as up/down/left/right menu navigation buttons.

Right side panel

Control panel

8 CHANNEL Bb — When no menu is on-screen, these

buttons change the channel (programmed channels only;

- page 33).

9 VOLUME C c — These buttons adjust the volume level.

10 INPUT — Repeatedly press to change the source you are

viewing (ANT, Built-In DVD, VIDEO 1, VIDEO 2, ColorStream HD1, ColorStream HD2, HDMI 1, HDMI 2, HDMI 3, PC).

11 PLAY — Press to play a DVD video disc, or other

playable disc.

12 STOP — Press to stop a DVD video disc, or other

playable disc.

13 SKIP — Press to skip DVD chapter, or CD track.

14 OPEN/CLOSE — Press to eject a disc.

15 DVD disc slot — Insert a playable disc to play.

6 MENU (ENTER) — Press to access the menu system

(- pages 30–31). When a menu is on-screen, the MENU button on the TV’s control panel functions as the ENTER button.

7 EXIT — Press to instantly close an on-screen menu.

Chapter 1: Introduction

TV back panel connections

For an explanation of cable types and connections, see pages 15–22.

3 4

1 ColorStream® HD-1 and ColorStream® HD-2 —

Two sets of ColorStream video inputs (with standard stereo audio inputs) for connecting devices with component video output, such as a Toshiba DVD player with ColorStream

Note: Component video cables carry only video information; separate audio cables are required for a complete connection.

2 VIDEO-1 IN — Standard (composite) video and standard

audio inputs plus optional S-video inputs for connecting devices with composite video or S-video output.

Note: Standard (composite) video and S-video cables carry only video information; separate audio cables are required for a complete connection.

3 Fixed Audio OUT — Analog audio outputs for

connecting an audio amplifier.

4 PC/HDMI-1 (AUDIO) IN — PC audio input terminals

are shared with HDMI-1 analog audio input terminals, and their use can be configured in the Audio Setup menu (- page 55).

5 PC IN — For use when connecting a personal computer.

6 ANT — Antenna input that supports analog (NTSC) and

digital (ATSC) off-air antenna signals and analog and digital Cable TV (QAM) signals.

high-definition component

TV back

Power cord

Cable Clamper

7 Digital Audio OUT — Optical audio output in Dolby

Digital or PCM (pulse-code modulation) format for connecting an external Dolby Digital decoder, amplifier, A/V receiver, or home theater system with optical audio input.

8 HDMI

™

IN — High-Definition Multimedia Interface

input receives digital audio and uncompressed digital video from an HDMI device or uncompressed digital video from a DVI device. Also see item 4. HDMI connection is necessary to receive 1080p signals.

9 Service port — For service use only. Used for updating

the television’s firmware.

HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC. Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are registered trademarks of Dolby Laboratories.

Chapter 2: Connecting your TV

Overview of cable types

Cables can be purchased from most stores that sell audio/video devices. Before purchasing any cables, be sure of connector types required by your devices and the length of each cable.

Coaxial (F-type) cable

Coaxial (F-type) cable is used for connecting your antenna, cable TV service, and/or cable converter box to the ANT input on your TV.

Standard A/V cables (red/white/yellow)

Standard A/V cables (composite video) usually come in sets of three, and are for use with video devices with analog audio and composite video output. These cables (and the related inputs on your TV) are typically color-coded according to use: yellow for video, red for stereo right audio, and white for stereo left (or mono) audio.

HDMI™ cable cable (with HDMI Logo “ ”)

HDMI (High-Definition Multimedia Interface) cable is for use with devices with an HDMI output. An HDMI cable delivers digital audio and video in its native format. This cable carries both video and audio information; therefore, separate audio cables are not required for a complete HDMI device connection (- page 20 and page 22).

Note: HDMI cable provides better picture performance than a standard (composite) video or S-video cable.

Optical audio cable

Optical audio cable is for connecting receivers with Dolby Digital or PCM (pulse-code modulation) optical audio input to the TV’s DIGITAL AUDIO OUT terminal (- page 21).

Analog RGB (15-pin) computer cable

S-video cable

S-video cable is for use with video devices with S-video output. Separate audio cables are required for a complete connection.

Note: An S-video cable provides better picture performance than a composite video cable. If you connect an S-video cable, be sure to disconnect the standard (composite) video cable or the picture performance will be unacceptable.

Component video cables (red/green/blue)

Component video cables come in sets of three and are for use with video devices with component video output. (ColorStream cables are typically color-coded red, green, and blue. Separate audio cables are required for a complete connection.

Note: Component video cables provide better picture performance than a standard (composite) video or S-video cable.

is Toshiba’s brand of component video.) These

Analog RGB (15-pin) computer cable is for connecting a PC to the TV’s PC IN terminal (- page 22).

About the connection illustrations

You can connect different types and brands of devices to your TV in several different configurations. The connection illustrations in this manual are representative of typical device connections only. The input/output terminals on your devices may differ from those illustrated herein. For details on connecting and using your specific devices, refer to each device’s owner’s manual.

Chapter 2: Connecting your TV

Connecting a VCR and antenna or Cable TV (no Cable box)

TV upper back panel

TV lower back panel

You will need:

• coaxial cables

• standard A/V cables

– For better picture performance, if your VCR has S-video,

use an S-video cable (plus the audio cables) instead of the standard video cable. Do not connect both types of video cable to VIDEO 1 at the same time or the picture performance will be unacceptable.

– If you have a mono VCR, connect L/MONO on the TV to

your VCR’s audio out terminal using the white audio cable only.

From Cable TV or antenn

Stereo VCR

VIDEO AUDIO

IN from ANT

CH 3 CH 4

OUT

OUT to TV

To view the antenna or Cable signal:

Select the ANT video input source on the TV.*

To view the VCR:

Turn ON the VCR. Select the VIDEO 1 video input source on the TV.*

* To select the video input source, press INPUT on the remote control

(- page 24). To program the TV remote control to operate other devices, see Chapter 3.

Chapter 2: Connecting your TV

Connecting a VCR with S-video and a cable box

An S-video connection will provide better picture performance than a standard (composite) video cable.

TV upper back panel

TV lower back panel

You will need:

• coaxial cables

• S-video cable

– Do not connect both types of video cable to VIDEO 1 at

the same time or the picture performance will be unacceptable.

standard audio cables

•

– If you have a mono VCR, connect L/MONO on the TV to

your VCR’s audio out terminal using the white audio cable only.

Note: When you use a Cable box, you may not be able to use the remote control to program or access certain features on the TV.

From Cable T

Cable box

CH 3

stereo VCR

VIDEO AUDIO

OUT

CH 4

CH 3 CH 4

OUT

IN from ANT

OUT to TV

To view basic and premium Cable channels:

Turn OFF the VCR. Select the ANT video input source on the TV.* Tune the TV to channel 3 or 4 (whichever channel the Cable box output is set to). Use the Cable box controls to change channels.

To view the VCR:

Turn ON the VCR. Select the VIDEO 1 video input source on the TV.*

* To select the video input source, press INPUT on the remote control

(- page 24). To program the TV remote control to operate other devices, see Chapter 3.

Chapter 2: Connecting your TV

Connecting a DVD player with ColorStream® (component video), a VCR, and a satellite receiver

Your TV has two sets of ColorStream® (component video) inputs.

TV upper back panel

From antenn

AUDIO

OUT

COMPONENT VIDEO

VIDEO

S-VIDEO

OUT

DVD player with component video

From satellite dish

AUDIO

OUT

Satellite

COMPONENT VIDEO

S-VIDEO

OUT

VIDEO

OUT

Satellite receiver with component video

TV lower back panel

You will need:

• coaxial cables

• standard A/V cables

– For better picture performance, if your VCR has S-video,

use an S-video cable (plus the audio cables) instead of the standard video cable. Do not connect both types of video cable to VIDEO 1 at the same time or the picture performance will be unacceptable.

– If you have a mono VCR, connect L/MONO on the TV to

your VCR’s audio out terminal using the white audio cable only.

standard audio cables

•

• component video cables

– You can connect the component video cables (plus audio

cables) from the DVD player or satellite receiver to either set of ColorStream terminals on the TV (HD-1 or HD-2). The ColorStream HD-1 and HD-2 terminals can be used with Progressive (480p, 720p) and Interlaced (480i, 1080i) scan systems. A 1080i signal will provide the best picture performance (1080p is not supported).

– If your DVD player or satellite receiver does not have

component video, connect a standard A/V cable to VIDEO 2 on the side panel. If your DVD player has HDMI video, see page 20.

Stereo VCR

VIDEO AUDIO

IN from ANT

CH 3 CH 4

OUT

OUT to TV

To view satellite programs using the component video connections:

Turn on the satellite receiver. Select the ColorStream HD-2 video input source on the TV.*

To view the VCR or view and record antenna channels:

Turn ON the VCR. Tune the VCR to the channel you want to watch. Select the VIDEO 1 video input source on the TV.*

To record a TV program while watching a DVD:

Turn ON the VCR. Tune the VCR to the channel to record. Select the ColorStream HD-1 video input source on the TV* to view the DVD.

* To select the video input source, press INPUT on the remote control

(- page 24). To program the TV remote control to operate other devices, see Chapter 3.

To view antenna or Cable channels:

Select the ANT video input source on the TV.*

To view the DVD player:

Turn ON the DVD player. Select the ColorStream HD-1 video input source on the TV.*

Chapter 2: Connecting your TV

Connecting a camcorder

You will need:

• standard A/V cables

– For better picture performance, if your camcorder has

S-video, connect an S-video cable (plus the audio cables) to VIDEO 1 on the TV back instead of the VIDEO 2 on the TV right side panel.

Camcorder

VIDEO

AUDIO

OUT

VIDEO 2 inputs on TV right side panel

To view the camcorder video:

Select the VIDEO 2 video input source on the TV.*

* To select the video input source, press INPUT on the remote control

(- page 24). To program the TV remote control to operate other devices, see Chapter 3.

Chapter 2: Connecting your TV

Connecting an HDMI™ or DVI device to the HDMI input

The HDMI input on your TV receives digital audio and uncompressed digital video from an HDMI source device, or uncompressed digital video from a DVI (Digital Visual Interface) source device.

This input is designed to accept HDCP (High-Bandwidth Digital-Content Protection) program material in digital form from EIA/CEA-861-D–compliant devices (such as a set-top box or DVD player with HDMI or DVI output).

The HDMI input can accept and display VGA, 480i (60Hz), 480p (60Hz), 720p (60Hz), 1080i (60Hz), and 1080p (24Hz/ 60Hz) signal formats. For detailed signal specifications, see page 72.

Supported Audio format: Linear PCM, sampling rate 32/44.1/ 48 kHz

Note: To connect a PC to the HDMI input, see page 22.

To connect an HDMI device, you will need:

• one HDMI cable (type A connector) per HDMI device

– For proper operation, it is recommended that you use an

HDMI cable with the HDMI Logo ( ).

– To display an 1080p/60Hz signal format, you will need a

Category 2 cable. Conventional HDMI/DVI cable may not work properly.

– HDMI cable transfers both video and audio. Separate

analog audio cables are not required (see illustration).

– See “Setting the HDMI

TV lower back panel

[1]

consumer electronic

™

audio mode” (- page 35).

To connect a DVI device, you will need:

• one HDMI-to-DVI adapter cable (HDMI type A connector)

per DVI device

– For proper operation, the length of an HDMI-to-DVI

adapter cable should not exceed 9.8 ft (3m). The recommended length is 6.6 ft (2m).

one pair of standard analog audio cables per DVI device

•

– An HDMI-to-DVI adapter cable transfers video only.

Separate analog audio cables are required (see illustration).

™

– See “Setting the HDMI

TV upper back panel

DVI device

VIDEO AUDIO

OUT

Note: To ensure that the HDMI or DVI device is reset properly, it is recommended that you follow these procedures:

• When turning on your electronic components, turn on the TV first, and then the HDMI or DVI device.

• When turning off your electronic components, turn off the HDMI or DVI device first, and then the TV.

audio mode” (- page 35).

TV lower back panel

DVI/ HDCP

OUT

HDMI device

VIDEO AUDIO

OUT

HDMI OUT

To view the HDMI device video:

Select the HDMI 1, HDMI 2, or HDMI 3 video input source on the TV.*

* To select the video input source, press INPUT on the remote control

(- page 24). To program the TV remote control to operate other devices, see Chapter 3.

[1] EIA/CEA-861-D compliance covers the transmission of

uncompressed digital video with high-bandwidth digital content protection, which is being standardized for reception of highdefinition video signals. Because this is an evolving technology, it is possible that some devices may not operate properly with the TV.

HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC.

Chapter 2: Connecting your TV

Connecting a digital audio system

The TV’s DIGITAL AUDIO OUT terminal outputs a Dolby®* Digital g or 2-channel down-mixed PCM (pulse-code modulation) signal for use with an external Dolby decoder or other external audio system with optical audio input.

You will need:

• optical audio cable (Use an optical audio cable that has the

larger “TosLink” connector and not the smaller “minioptical” connector.)

Dolby Digital decoder or other digital audio system

Optical Audio IN

LINE IN LR

Digital

Note:

• Some audio systems may not be compatible with Dolby Digital bitstream signals. Older audio systems that are not compatible with standard optical out signals may not work properly, creating a high noise level that may damage speakers or headphones. THIS DAMAGE IS NOT COVERED BY YOUR WARRANTY.

• The DIGITAL AUDIO OUT terminal may not output some digital audio sources because of copy restrictions.

* Manufactured under license from Dolby Laboratories.

Dolby, and the double-D symbol are registered trademarks of Dolby Laboratories.

Connecting an audio system

This connection allows you to use external speakers with an external analog audio amplifier to adjust the sound level.

TV lower back panel

To control the audio:

1 Turn on the TV and the digital audio device. 2 Press Y on the TV’s remote control and open the Audio

menu.

3 Highlight Audio Setup and press T.

Audio

Digital Audio Selector

Audio Settings

Advanced Audio Settings

Audio Setup

4 In the Optical Output Format field, select either

Dolby Digital/Surround or PCM, depending on your

device (

- “Selecting the optical audio output format” on

page 49).

Audio Setup

PC Audio No

HDMI 1 Audio

MTS Stereo

Language

Optical Output Format

Dolby Digital Dynamic Range Control

DVD Audio

Reset

Auto

English

Dolby Digital/Surround

Compressed

Stereo

Done

You will need:

• standard audio cables

Analog audio amplifier

LINE IN LR

TV upper back panel

To control the audio:

1 Turn on the TV and the stereo amplifier. 2 Minimize the sound volume from the TV’s built-in

speakers and control the volume level using the amplifier’s remote control.

Chapter 2: Connecting your TV

Connecting a personal computer (PC)

With either the PC IN or HDMI connection, you can watch your computer’s display on the TV and hear the sound from the TV’s speakers.

To connect a PC to the PC IN terminal on the TV:

When connecting a PC to the PC IN terminal on the TV, use an analog RGB (15-pin) computer cable and a PC audio cable.

TV upper back panel

TV lower back panel

PC audio cable

• Depending on the DVD’s title and the specifications of the PC on which you are playing the DVD-Video, some scenes may be skipped or you may not be able to pause during multi-angle scenes.

Signal names for mini D-sub 15-pin connector

•

Pin No.

1 R 6 Ground 11 NC

2 G 7 Ground 12 NC

3 B 8 Ground 13 H-sync

4 NC * 9 NC 14 V-sync

5 NC 10 Ground 15 NC

*NC=Not connected

Signal name

Pin No.

Signal name

Pin No.

Signal name

To connect a PC to the HDMI terminal on the TV:

When connecting a PC to the HDMI terminal on the TV, use an HDMI-to DVI adapter cable and analog audio cables.

If connecting a PC with an HDMI terminal, use an HDMI cable (type A connector). Separate analog cables are not necessary (- page 20).

TV upper back panel

TV lower back panel

Computer

PC audio output

Conversion adapter (if necessary)

• To use a PC, set the monitor output resolution on the PC

before connecting it to the TV. The following signals can be displayed:

Format Resolution V. Frequency

VGA 640 × 480 60Hz

SVGA 800 × 600 60Hz

XGA 1024 × 768 60Hz

Other formats or non-standard signals will not be displayed correctly.

• To display the optimum picture, use the PC setting feature

(

- “Using the PC settings feature” on page 54).

Note:

• The PC audio input terminals on the TV are shared with the

HDMI-1 analog audio input terminals (- page 55).

• Some PC models cannot be connected to this TV.

• An adapter is not needed for computers with a compatible

mini D-sub15-pin terminal.

PC audio cable

Computer

PC audio output

The HDMI input can accept and display VGA, 480i (60Hz), 480p (60Hz), 720p (60Hz), 1080i (60Hz), and 1080p (24Hz/ 60Hz) signal formats. For detailed signal specifications, see page 72.

Note:

• The edges of the images may be hidden.

• If receiving a 720p, 1080i, or 1080p signal program, Native

mode scales the video to display the entire picture within the borders of the screen (i.e. no overscanning).

Chapter 3: Using the remote control

Preparing the remote control for use

Your TV remote control can operate your TV and many other devices such as cable converter boxes, satellite receivers, VCRs, DVD players, and HTIBs (home theater in a box), even if they are different brands.

If you have a Toshiba device:

Your TV remote control is preprogrammed to operate most Toshiba devices (- page 27).

• Always remove batteries from the remote control if they are dead or if the remote control is not to be used for an extended period of time. This will prevent battery acid from leaking into the battery compartment.

Remote control effective range

For optimum performance, aim the remote control directly at the TV and make sure there is no obstruction between the remote control and the TV.

If you have a non-Toshiba device or a Toshiba device that the remote control is not preprogrammed to operate:

You can program the TV remote control so it will operate the other device (- pages 25–29).

Installing the remote control batteries

1 Remove the battery cover from the back of the remote

control.

Squeeze tab and lift cover.

2 Install two “AAA” size batteries, making sure to match

the + and – signs on the batteries to the signs on the battery compartment.

Point remote control toward remote sensor on front of TV.

16.4 ft (5m)

3 Reinsert the battery cover in the remote control until the

tab snaps.

Caution: Never throw batteries into a fire.

Note:

• Be sure to use AAA size batteries.

• Dispose of batteries in a designated disposal area.

• Batteries should always be disposed of with the

environment in mind. Always dispose of batteries in accordance with applicable laws and regulations.

• If the remote control does not operate correctly, or if the operating range becomes reduced, replace batteries with new ones.

• When necessary to replace batteries in the remote control, always replace both batteries with new ones. Never mix battery types or use new and used batteries in combination.

Chapter 3: Using the remote control

Learning about the remote control

The buttons used for operating the TV only are described here. For a complete list of the remote control’s functions, see the remote control functional key chart (- page 26).

1 POWER turns the TV on and off. When the TV is on, the

green LED indicator on the TV front will be illuminated.

2 PIC MODE selects the picture mode (- page 45).

3 SLEEP accesses the sleep timer (

- page 55).

4 PIC SIZE cycles through the picture sizes: Natural,

TheaterWide 1/2/3, Full, 4:3 HD, and Native (

page 42).

5 Channel Numbers (0–9, –/100) directly tune

channels. The = button is used to tune digital channels (

- page 41) or to edit the Favorites List (- page 39).

6 INPUT selects the video input source (

- page 38).

7 CH Bb cycles through programmed channels when no

menu is on-screen (

- page 33).

8 VOL + – adjusts the volume level.

9 FAV BROWSER accesses the Favorites List in the

Channel Brower

™

(- page 39).

10 RECALL displays TV status information (- page 56).

11 CH RTN returns to the last viewed channel or source

(- page 41).

12 MUTE reduces or turns off the sound (- page 47).

13 INFO displays TV status information as well as program

details, when available. (- page 56).

14 3C / #c While watching TV, these buttons open the

Channel Browser

™

and tune to the previous/next channel

in the channel history (- page 40). (Also see “Arrow buttons.”)

15 Arrow buttons (BbC c) When a menu is on-screen,

these buttons select or adjust programming menus. (Also see 3C/ #c.)

16 ENTER activates highlighted items in the main menu

system.

17 MENU accesses the main TV menu system (

- pages 30

and 31).

18 EXIT closes on-screen menus.

19 MODE SELECT switch switches between TV,

CABLE/SAT, AUX 1, and AUX 2 modes (

- page 25).

Set to “TV” to control the TV.

Note: The error message “Not Available” may appear if you press a key for a function that is not available.

You can also control the built-in DVD when the MODE SELECT switch on the remote control is in TV mode. For

DVD operation the following buttons are used:

TOP MENU, DVD RTN, SET UP, DVD CLEAR, PAUSE, PLAY, STOP, SKIP, REW, FF, SEARCH, SLOW, ANGLE, SUB TITLE, AUDIO, and EJECT

(- Chapter 8).

Chapter 3: Using the remote control

Using the remote control to control your other devices

If you have a non-Toshiba device or a Toshiba device that the remote control is not preprogrammed to operate, you must first program the remote control to recognize the device (if you have not already done so) (- pages 27–29).

To use your TV remote control to operate a:

• Cable converter box or satellite receiver, set the MODE

SELECT switch to CABLE/SAT.

• VCR, set the MODE SELECT switch to AUX 1.

• DVD player or HTIB, set the MODE SELECT switch to

AUX 2.

Note: Even after the TV remote control is programmed, it may not operate certain features on any other devices. If this happens and you wish to use those features, you will need to use the device’s original remote control.

Point the remote control

directly at the device.

1 POWER Turns the selected device on and off.

2 Channel Numbers (0-9) Press to directly access

channels (as opposed to < ,).

3 +10 Press to directly access DVD chapters higher than 10.

4 TOP MENU Accesses a DVD’s top menu.

5 CH Bb For channels programmed into the channel

memory (- page 41): B selects the next higher channel. b selects the next lower channel.

6 GUIDE Displays the channel guide in the CABLE/SAT

mode. SET UP Accesses a DVD’s setup menu in the AUX mode.

7 INFO Displays TV status information on-screen.

8 BbC c Press to navigate DVD menus (may not work on

some DVD players).

9 ENTER Required by some satellite receivers and DVD

players to activate certain functions.

10 DVD CLEAR Press to reset the title and chapter number.

16 17 18

11 PLAY Begins playback of a tape or DVD.

12 PAUSE Press during play or record mode to pause the

picture; press again to restart.

13 STOP Stops the tape or DVD.

14 SKIP z Skips forward to locate later DVD chapters.

15 FF Fast-forwards the tape or DVD. (Press during play

mode to view the picture moving rapidly forward.)

16 SKIP Z Skips back to beginning of current DVD

chapter, or locates previous chapters.

17 REW Rewinds/reverses the tape or DVD. (Press during

play mode to view the picture moving rapidly backward.)

18 TV/VCR To view one program while recording another,

press to select TV mode.

SEARCH selects a specific DVD chapter, title or time.

19 REC Starts tape recording.

20 SLOW X Slow-forwards the DVD.

21 SLOW x Slow-reverses the DVD.

22 MODE SELECT switch

“CABLE/SAT” to control a cable converter box or satellite receiver; “AUX 1” to control a VCR; “AUX 2” to control a DVD player or HTIB.

Set to “TV” to control the TV;

Chapter 3: Using the remote control

Remote Control functional key chart

Note:

• “---” = key does not send a signal in that remote control mode.

• “sTV” = key will affect the TV, even though the remote control is in another mode.

• * Not available for your TV.

REMOTE CONTROL KEY

POWER Power Power Power Power Power SLEEP Sleep timer s TV s TV s TV s TV PIC SIZE Picture size s TV s TV s TV s TV PIC MODE PIC MODE s TV s TV s TV s TV

1-9 Digit 1-9 Digit 1-9 Digit 1-9 Digit 1-9 Digit 1-9

0 Digit 0 Digit 0 Digit 0 Digit 0 Digit 0

100/–/+10 – (sub CH) --- – (sub CH) 100 +10 INPUT TV/Video select s TV s TV s TV s TV

FAV BROWSER/ TOP MENU

MUTE Sound mute s TV s TV s TV s TV

SET UP/GUIDE DVD setup --- SAT Guide --- Setup VOL + – Volume up/down s TV s TV s TV s TV

CHBb

RECALL RECALL s TV s TV s TV s TV

CH RTN/DVD RTN

INFO Info --- Info --- Display

ENTER Enter --- Select, Enter --- Enter

Bb Menu up/down ---

C 3

c #

MENU Menu --- Action Menu --- DVD Menu

EXIT/DVD CLEAR

PAUSE/STEP Pause --- --- Pause Pause

PLAY Play --- --- Play Play

STOP Stop --- --- Stop Stop SKIP Z Skip REV --- --- --- Skip REV SKIP z Skip FWD --- --- --- Skip FWD

REW Rewind --- --- Rewind Rewind

FF Fast FWD --- --- Fast FWD Fast FWD

TV/VCR/ SEARCH

REC REC MENU* --- --- Record (2 click) ---

SLOW – SLOW REW --- --- --- ---

SLOW + SLOW FWD --- --- --- ---

ANGLE Angle --- --- --- DVD Angle

SUB TITLE Sub title --- --- --- DVD Sub title

AUDIO Audio --- --- --- DVD Audio

EJECT Eject --- --- --- DVD Eject

Toshiba TV/ Built-in DVD

FAV BROWSER DVD TOP Menu

Channel up/down

Previous channel DVD previous menu

Menu left/ Channel Browser

Menu right/ Channel Browser

Exit DVD clear

DVD search --- --- TV/VCR DVD search

™

CABLE SAT (satellite) AUX 1 (VCR) AUX 2 (DVD or HTIB)

--- --- --- Top Menu

Channel up/down

--- --- --- DVD Return

--- Menu left --- Menu left

--- Menu right --- Menu right

--- Exit --- DVD Clear

Channel up/down

Menu up/down

Channel up/down

--- Menu up/down

---

Chapter 3: Using the remote control

Programming the remote control to control your other devices

Your Toshiba TV remote control is preprogrammed to operate most Toshiba devices. To program your TV remote control to operate a non-Toshiba device (or a Toshiba device that it is not preprogrammed to operate), follow the steps below. For details on using the remote control to operate the device, see page 25.

1 In the remote control code table (- page 28), find the

code for your device. If more than one code is listed, try each one separately until you find one that works.

2 Set the MODE SELECT switch to the type of device

you are programming the remote control to operate — CABLE/SAT (for a cable converter box or satellite receiver), AUX 1 (for a VCR or TV/VCR combo), or AUX 2 (for a DVD player or HTIB [home theater in a box]).

3 While holding down E, press the Channel Number

buttons to enter the 3-digit code for your device.

4 To test the code, turn on the device, point the remote

control at it, and press p. See notes below.

• If the correct code was entered, the device will turn off.

• If the device does not respond, repeat steps 1–4 using

another code.

• If the device does not respond to another code, you will

need to use the remote control that came with the device.

5 Remember to set the MODE SELECT switch back to

“TV” to control the TV.

6 For future reference, write down the code(s) you used:

DEVICE CODE DEVICE CODE

Note:

• In addition to POWER, confirm that all necessary keys on the TV remote control operate your device. If some keys are not operational, repeat the device code setup using another code (if other codes are listed for your device). If, after trying all listed codes, the necessary keys do not operate your device, use the device’s original remote control.

• Every time you change the batteries, you will need to reprogram the remote control.

• Some newer VCRs respond to either of two codes. These VCRs have a switch labeled “VCR1/VCR2.” If your VCR has this kind of switch and does not respond to the codes for your VCR brand, set the switch to the other position (“VCR1” or “VCR2”) and reprogram the remote control.

Chapter 3: Using the remote control

Remote control codes

In some cases you may not be able to operate your device with the TV remote control. Your other device may use a code that is not recognized by the TV remote control. If this happens, use the device’s remote control.

Cable converter box

ABC 061, 062, 063, 082,

084, 087, 092, 096,

098 Archer 065, 092, 097, 099 Cableview 064, 094 Century 092 Citizen 090, 092, 097 Contec 083, 085, 086, 088,

093, 098 Diamond 093 GE 061, 062 Gemini 069, 070, 094 Hamlin 093 Hitachi 062, 095, 096 Jasco 097 Motorola/GI/Jerrold 062, 069, 071, 082,

086, 089, 096, 107 Magnavox 072, 096 Memorex 092, 104 Multi Canal 090 Novavision 101 Panasonic 081, 083, 085 Philco 087 Philips 066, 067, 068, 070,

072, 073, 074, 075,

092 Pioneer 076, 077 Proscan 061, 062 Radio Shack 092, 097, 099 RCA 064, 081 Realistic 065 Recoton 102 Samsung 077, 090 Scientific Atlanta 063, 078, 079, 080,

088, 098, 101, 105 Sears 095 Signature 062 Signature 2000 096 Sprucer 081, 085 Starcom 069, 082, 087, 096,

103, 104 Stargate 069, 090 Sylvania 095, 100 TeleView 090 Texscan 100 Tocom 071, 084, 085 U. S. Electronics 087, 096, 098 United Cable 082 Universal 065, 092, 097, 099,

102, 103 Wards 096

Satellite receiver

Alphastar 038, 059 Chaparral 034 DISH Network 057

Drake 020, 040, 044, 046,

050, 053 Echostar 018, 041, 051 Express Vu 057 Fujitsu 027 GE 008, 009, 013 General Instruments 010, 011, 012, 022,

023, 031, 049 Hitachi 033 Hughes 033 Hughes Network

Systems 019 Intersat 048 Janeil 027 JVC 017, 057 Kenwood 029 Magnavox 060 Optimus 058 Pansat 036, 052 Primestar 015, 042 Proscan 008, 009, 013 Radio Shack 022, 023, 030 RCA 008, 009, 013, 016 Realistic 030 Samsung 059 Sony 014, 055 Star Choice 057, 106 Star Trak 025, 026, 037, 054 STS 024 Toshiba 000, 001, 002, 003,

004, 005, 006, 007, 020, 031, 056

Uniden 021, 028, 030, 032,

035, 039, 043, 045, 047, 058

Zenith 027

TV/VCR Combo

Action 078 GE 059, 062 Goldstar 065 Panasonic 065 Precision 078 Quasar 065 Realistic 079 Sony 074 Toshiba 057 Zenith 065 Totevision 009, 010, 065

DVD/VCR Combo

Go Video DVD=087,

VCR=081

JVC DVD=088,

VCR=082

RCA DVD=089,

VCR=083

Samsung DVD=090,

VCR=084

Sanyo DVD=091,

VCR=085

Zenith DVD=092,

VCR=086

DVD player

Aiwa 006, 015 Apex 016, 017 BOSE 097 Broksonic 018

Clarion 019 Classic 020 Daewoo 021 Denon 022, 023, 024, 025 Emerson 026, 027 Fisher 028 Funai 027 GE 001, 029, 030 Go Video 087 GPX 031 Hitachi 005, 032, 033, 034,

035

JVC 003, 007, 036, 042,

088 Kenwood 037 Konka 008, 009 Magnavox 004, 038 Memorex 039 Mintek 040 NAD 026 Nakamichi 041 Norcent 043 Onkyo 044 Oritron 058 Panasonic 010, 045, 046, 047,

048, 049, 050 Philips 004, 051 Pioneer 052, 053, 054, 055 Proscan 001, 056 Qwestar 057, 058 RCA 001, 002, 059, 089 Sampo 060 Samsung 061, 062, 086, 090 Sansui 073 Sanyo 063, 091 Sharp 064, 067 Sherwood 074 Sony 011, 012, 065, 066,

068, 069, 070 Sylvania 027 Teac 071 Technics 072 Techwood 075 Toshiba 000, 013, 076, 077,

078 Yamaha 079, 080, 081 Zenith 014, 082, 092

Portable DVD player

Aiwa 093 Audiovox 094, 095 Panasonic 024, 096, 099 RCA 098

VCR

Admiral 049 Aiko 019 Aiwa 018 Akai 003, 004, 037, 038,

039, 058, 069 Audiovox 010 Bell & Howell 007, 068 Broksonic 008, 017 Calix 010 Carver 026 CCE 019 Citizen 009, 010, 011, 012,

013, 014, 015, 019,

057, 073 Colortyme 005

Chapter 3: Using the remote control

Craig 009, 010, 016, 061,

065, 079

Curtis Mathes 001, 005, 009, 012,

014, 040, 048, 053, 056, 057

Daewoo 011, 013, 015, 017,

018, 019, 057, 078 Daytron 078 Denon 063 Dimensia 001, 048 Electrohome 010, 020, 065 Emerson 003, 008, 010, 011,

017, 018, 020, 028,

039, 054, 057, 062,

065, 068, 072 Fisher 007, 016, 021, 022,

023, 057, 064, 068,

070, 071, 079 Fuji 004, 041 Funai 018, 073 Garrard 018 GE 001, 002, 009, 040,

042, 048, 056 Go Video 056, 059, 061, 081 Goldstar 005, 010, 014, 054,

056, 065, 067 Gradiente 018, 065 Harman Kardon 005 Hitachi 024, 025, 035, 037,

042, 063, 070, 080 JBL 076 JC Penney 005, 006, 007, 008,

009, 010, 023, 024,

025, 026, 035, 056,

061, 063, 065 Jensen 024, 025, 037, 050 JVC 005, 006, 007, 014,

037, 043, 055, 062,

063, 068, 082 Kenwood 005, 006, 007, 012,

014, 037, 043, 050,

053, 068, 071 Kodak 010 LG 010 Lloyds 053, 073, 079 Logik 061 LXI 010 Magnasonic 061, 065, 078 Magnavox 026, 027, 034, 044,

057, 061, 072 Marantz 005, 006, 007, 012,

014, 026, 053, 067 Memorex 007, 009, 010, 016,

018, 034, 049, 063,

065, 066, 068, 075,

079 MGA 020, 028, 039 MGN 056 Minolta 024, 025, 035, 063 Mitsubishi 020, 024, 025, 028,

039, 043, 065 Montgomery Ward 049 Motorola 049 MTC 009, 046, 061 Multitech 009, 012, 018 NEC 005, 006, 007, 012,

014, 037, 043, 053,

054, 067, 070 Nikko 010 Noblex 009 Optimus 010, 049, 065 Optonica 031

Orion 054, 057, 062, 065,

068, 072

Panasonic 036, 045, 046, 057,

061, 072, 079

Pentax 012, 024, 025, 035,

042, 053, 063 Pentex Research 014 Philco 026, 027, 063 Philips 026, 031, 044, 057 Pioneer 006, 024, 043, 055 Portland 012, 013, 015 Proscan 001, 002, 048 Proton 061 Quasar 045 Radio Shack 010, 031, 065 Radio Shack/Realistic 007, 009, 010, 016,

018, 020, 021, 022,

031, 049 Radix 010 RCA 001, 002, 003, 009,

024, 025, 029, 035,

040, 042, 045, 048,

055, 056, 063, 071,

083 Realistic 007, 009, 010, 011,

016, 018, 020, 021,

022, 031, 049, 051,

056, 060, 065, 075,

079 Ricoh 047 Runco 034 Samsung 009, 011, 038, 056,

073, 084 Sansui 006, 037, 043, 061 Sanyo 007, 009, 016, 054,

064, 068, 071, 075,

079, 085 Scott 008, 011, 017, 028,

030, 057, 065, 072 Sears 007, 010, 016, 021,

022, 023, 024, 025,

035, 053, 057, 063,

064, 065, 068, 071,

075, 079 Sharp 013, 020, 031, 049,

051, 060, 066 Shintom 004, 025, 032, 061 Signature 049 Signature 2000 075 Singer 047, 061 Sony 004, 032, 033, 041,

052, 058, 070, 074,

076, 077, 080 STS 035 Sylvania 018, 026, 027, 028,

044, 072 Symphonic 018, 050, 051, 053,

073, 079 Tandy 007 Tashiko 010 Tatung 037 Teac 018, 029, 037 Technics 036 Teknika 010, 018, 065 Toshiba 000, 011, 021, 023,

024, 028, 030, 039,

057, 074, 078, 079 Totevision 009, 010, 065 Unitec 073 Unitech 009 Vector Research 005, 006, 011, 012,

053

Video Concepts 005, 006, 011, 012,

039, 053

Wards 009, 010, 011, 016,

018, 020, 024, 025, 031, 035, 049, 051, 056, 057, 060, 065,

066, 079 White Westinghouse 073 XR-1000 018 Yamaha 005, 006, 007, 014,

037, 053 Zenith 004, 032, 034, 041,

047, 069, 086

HTIB

Lasonic 083 Panasonic 084 Venturer 085

Chapter 4: Menu layout and navigation

Main menu layout

The tables below and on the next page provide a quick overview of your TV’s menu system. To open the main menus (illustrated below), press Y on the remote control or TV control panel.

Icon Item Option

Video

Audio

Preferences

Locks

Setup

Mode S Sports/Standard/Movie/Preference Picture Settings S [Opens the Picture Settings menu] Noise Reduction S [Opens the Noise Reduction menu] Game Mode S On/Off Theater Settings S [Opens the Theater Settings menu] Digital Audio Selector S [Launches the temporary Audio Selector] Audio Settings S [Opens the Audio Settings menu] Advanced Audio Settings S [Opens the Advanced Audio Settings menu] Audio Setup S [Opens the Audio Setup menu] CC Selector S [Launches the temporary CC Selector] Base CC Mode S Off/CC1/CC2/CC3/CC4/T1/T2/T3/T4 Digital CC Settings S [Opens the Digital CC Setup menu] Input Labeling S [Opens the Input Labeling menu] Channel Labeling S [Opens the Channel Labeling menu] Menu Language S English/French/Spanish Channel Browser Setup S [Opens the Channel Browser Setup menu] Enable Rating Blocking S Off/On Edit Rating Limits S [Opens the Edit Rating Limits menu] Channels Block S [Opens the Channels block menu] Input Lock S Off/Video/Video+ Front Panel Lock S Off/On New PIN Code S [Opens the New PIN Code entry screen] Installation S [Opens the Installation menu (- page 31)] Sleep Timer S [Opens the Sleep Timer menu] PC Settings S [Opens the PC Settings menu]

Chapter 4: Menu layout and navigation

Setup/Installation menu layout

The Installation menu contains the Terrestrial and System Status menus. To open the Installation menu (illustrated below), press Y on the remote control or TV control panel, open the Setup menu,

select Installation, and press T.

Icon Item Option

Press Y, open the Setup menu, and then open the Installation sub-menu.

Terrestrial

System Status

Input Configuration S [Opens the Input Configuration menu] Channel Program S [Start] S [Scans for new channels on ANT] Channel Add/Delete S [Opens the Channel Add/Delete menu] Signal Meter S [Opens the Signal Meter menu]

System Information S [Opens the System Information screen]

Navigating the menu system

You can use the buttons on the remote control or TV control panel to access and navigate your TV’s on-screen menu system.

• Press Y to open the menu system.

• When a menu is open, use the up/down/left/right arrow

buttons (BbC c) on the remote control or TV control panel to move in the corresponding direction in the menu.

• Press T to save your menu settings or select a highlighted

item. (A highlighted menu item appears in a different color in the menu.)

• All menus close automatically if you do not make a selection

within 60 seconds, except the signal meter menu, which closes automatically after about 5 minutes.

• To close a menu instantly, press O.

Note:

• The menu background may sometimes appear black, depending on the signal the TV is receiving. This is not a sign of malfunction.

Video

Mode Sports

Picture Settings

Noise Reduction

Game Mode

Theater Settings

Navigate

Select

Off

Back Exit

CH RTNENTER

EXIT

• The Video sub-menu appears with a black background, which looks different from other menus.

Picture Settings

Contrast 100

Back Light 100

DynaLight

Brightness

Color

Tint

Sharpness

Advanced Picture Settings

Reset

Mode: Sports

Done

Chapter 5: Setting up your TV

Selecting the menu language

You can choose from three different languages (English, French and Spanish) for the on-screen display of menus and messages.

To select the menu language:

1 Press Y and open the Preferences menu. 2 Highlight Menu Language and press c. 3 Press B or b to select your preferred menu language and

press T.

Preferences

CC Selector

Base CC Mode

Digital CC Settings

Input Labeling

Channel Labeling

Menu Language

Channel Browser Setup

4 Press O to close the Preferences menu.

Off

English

Français

Español

Configuring the antenna input source for the ANT terminal

To configure the ANT input source:

1 Press Y and open the Setup menu. 2 Highlight Installation and press T.

Setup

Installation

Sleep Timer

PC Settings

3 (A new set of Installation menu icons will appear, as

shown below.) Open the Terrestrial menu, highlight Input Configuration, and press T.

Installation

Terrestrial

Input Configuration

Channel Program

Channel Add/Delete

Signal Meter

4 Press C or c to select the input source (Cable or

Antenna) for the ANT input on the TV.

Input Configuration

Antenna In Cable

Cancel Done

5 To save your new settings, highlight Done and press T.

To revert to your original settings, highlight Cancel and press T.

Chapter 5: Setting up your TV

Programming channels into the TV’s channel memory

4 (A new set of Installation menu icons will appear, as

shown below.) Open the Terrestrial menu, highlight Channel Program to bring up the Start, and press T again to begin channel programming.

When you press < or , on the remote control or TV control panel, your TV will stop only on the channels you programmed into the TV’s channel memory.

Follow the steps below to program channels into the TV’s channel memory.

Programming channels automatically

Your TV can automatically detect all active channels in your area and store them in its memory. After the channels are programmed automatically, you can manually add or erase individual channels in the channel memory.

Note:

• You must configure the antenna input source before

programming channels (- page 32).

• If the Antenna input signal type is set to Cable, the automatic channel programming process erases channels that were previously programmed into the TV’s memory.

• If the Antenna input signal type is set to Antenna, the automatic channel programming process adds newly found channels to the existing set of programmed channels (and does NOT erase channels that were previously programmed into the TV’s memory.) To remove an Antenna source channel from the memory, you must manually delete it.

• To tune the TV to a channel not programmed in the channel memory, you must use the Channel Number buttons on the remote control.

• Programming channels when the antenna input is configured for Cable will take substantially longer than when the antenna input is configured for Antenna. This is normal; however, once channel programming is finished, you should not have to repeat the programming process again unless your Cable TV service lineup changes significantly.

To program channels automatically:

1 Configure the antenna input source, if you have not

already done so (

- page 32).

2 Press Y and open the Setup menu. 3 Highlight Installation and press T.

Setup

Installation

Sleep Timer

PC Settings

Installation

Terrestrial

Input Configuration

Channel Program

Channel Add/Delete

Signal Meter

ANT Cable Scanning channels, please wait ...

Number of Channels Found - 73 Scanning Digital Channels Found Channel - 118

Abort

Start

52%

The TV will automatically cycle through all the antenna channels, and store all active channels in the channel memory. While the TV is cycling through the channels, the message “Scanning channels, please wait” appears (as shown above).

5 To cancel channel programming, press O on the remote

control (or highlight Abort in the on-screen display and press T).

When channel programming is finished, press < or , to view the programmed channels.

Manually adding and deleting channels in the channel memory

After automatically programming channels into the channel memory, you can manually add or delete individual channels.

To add or delete channels in the channel memory:

1 Press Y and open the Setup menu. 2 Highlight Installation and press T. 3 (A new set of Installation menu icons will appear, as

shown below.) Open the Terrestrial menu, highlight Channel Add/Delete, and then press T.

Installation

Terrestrial

Input Configuration

Channel Program

Channel Add/Delete

Signal Meter

(continued)

Chapter 5: Setting up your TV

To add a channel to the channel memory:

Highlight the unchecked box next to the channel number you want to add, and then press T to check the box.

To manually add digital subchannels on a physical channel:

Use the Channel Numbers and the Dash (=) on the remote control to enter the channel number (for example, 56–1).

If the channel is found, the number will be added to the list and the box will be checked.

If the channel is not found, a message will appear.

To remove a channel from the channel memory:

Highlight the checked box next to the channel number you want to remove, and then press T to uncheck the box.

To save your new settings:

Highlight Done and press T.

To revert to your original settings:

Highlight Cancel and press T before saving.

To remove all channels from the channel memory:

Highlight Reset and press T, and then highlight Done and press T.

Channel Add/Delete

2 - 1

2 - 2

7 - 1

Analog

Digital

Analog

Digital

Analog

Digital

Analog

Reset

Cancel

Done

To remove encrypted channels from the channel memory:

If an encrypted channel is accidentally added to the channel list by programming channels, you can remove the unwanted encrypted (non-viewable) channel while you are channel surfing. When you tune to an encrypted channel, the following message will appear.

Digital Channel Is Encrypted - Press 1 on remote to remove channel

Press “1” button while the message is on the screen to remove the unnecessary channel from the channel list.

Labeling channels

A list of common channel labels (logos) for various channels (ABC, CBS, etc.) will be programmed into the TV. You will be able to view and assign these logos from the Channel Labeling window. If the desired channel label is not provided in the list, you will be able to manually enter/edit labels using the software keyboard.

To assign channel labels:

1 Press Y and open the Preferences menu. 2 Highlight Channel Labeling and press T.

The Channel Labeling window opens.

Preferences

CC Selector

Base CC Mode

Digital CC Settings

Input Labeling

Channel Labeling

Menu Language

Channel Browser Setup

Channel Labeling

{No Label}

A&E

ABC

ABCFAM

ABCHD

AMAX

AMAXW

AMC

ANIMAL

English

3 Press < or , to select the channel you want to label. 4 Press BbC c to highlight the desired channel label and

press T.

5 Repeat steps 3 and 4 for other channels. 6 To save your settings, highlight Done and press T.

Channel Labeling

{No Label}

A&E

ABC

ABCFAM

ABCHD

AMAX

AMAXW

AMC

ANIMAL

The maximum number of labels that can be stored is 128.

Off

CC1

CC2

CC3

CC4

ANT

A&E

Press CH UP/DOWN to change channels.

Custom

Clear All

Done

ANT

A&E

Press CH UP/DOWN to change channels.

Custom

Clear All

Done

To remove channel labels:

1 Open the Channel Labeling window. 2 Press < or , to select the channel for which you want to

remove the label.

Chapter 5: Setting up your TV

3 Press BbC c to highlight No Label and press T.

Channel Labeling

{No Label}

A&E

ABC

ABCFAM

ABCHD

AMAX

AMAXW

AMC

ANIMAL

ANT

Press CH UP/DOWN to change channels.

Custom

Clear All

Done

4 Repeat steps 2 and 3 for other channels. 5 To save your settings, highlight Done and press T.

If the desired channel label is not available from the list of presets, you can create a custom label.

To create and assign a custom label:

1 Open the Channel Labeling window. 2 Press < or , to select a channel you want to label. 3 Press Bb c to highlight Custom and press T.

The software keyboard will appear.

Channel Labeling

{No Label}

A&E

1 A B C a b c 2

ABC

G H I g h i 4

ABCFAM

P Q R S p q r s 7

ABCHD

Backspace

100

AMAX

AMAXW

AMC

ANIMAL

ANT

A&E

Edit

Press CH UP/DOWN to

J K L j k l 5

change channels.

T U V t u v 8

Clear All

Done

CH RTN

Cancel

Send

Exit

EXIT

D E F d e f 3

M N O m n o 6

W X Y Z w x y z 9

INPUT

Space

4 Repeatedly press the corresponding key on the remote

control to highlight the desired character on the on-screen software keyboard.

5 The highlighted character is entered after you either press

a different key, press c key, or after a two-second pause.

6 Repeat steps 4 and 5 until you have entered all desired

text.

7 When finished, press T. 8 (New labels will be added to the list in alphabetical order

and marked with an icon to indicate that they are custom.) Highlight the new custom label and press T to assign. Assigned channel labels will be displayed in the banner, Channel Add/Delete window, and Channels

Block window.

3 Highlight Yes from the deletion confirmation window

and press T.

Channel Labeling

TIMES

TLC

TMC

TMCX

TMCXw

TMCw

TNT

TNTHD

TOCDEFG

ANT

Delete the selected custom label?

Press CH UP/DOWN to change channels.

Custom

Clear All

Done

YesNo

4 Highlight Done and press T to save changes, and go

back to the Channel Labeling window.

Setting the HDMI™ audio mode

To set the HDMI audio mode:

1 Press Y and open the Audio menu. 2 Highlight Audio Setup and press T. 3 Press B or b to select HDMI 1 Audio and then press C

or c to select the HDMI 1 audio mode (Auto, Digital, or Analog). (Auto is the recommended mode.) See

“Connecting an HDMI or DVI device to the HDMI input” (- page 20).

Audio Setup

PC Audio No

HDMI 1 Audio

MTS Stereo

Language

Optical Output Format

Dolby Digital Dynamic Range Control

DVD Audio

Reset

Note: Because the PC and HDMI-1 inputs share the same set of analog audio inputs, the PC Audio menu setting influences the HDMI 1 Audio menu setting. If PC Audio is set to “No,” the HDMI 1 Audio setting changes to “Auto.” If PC Audio is set to “Yes,” the HDMI 1 Audio setting is set to “Digital” and is grayed out in the menu. (Also see item 4 on page 14 and “Setting the PC Audio” on page 55.)

Auto

English

Dolby Digital/Surround

Compressed

Stereo

Done

To delete the custom label:

1 Open the Channel Labeling window. 2 Highlight the label to be deleted and press =.

Chapter 5: Setting up your TV

Viewing the digital signal meter

You can view the digital signal meter in the ANT digital TV input source only.

To view the digital signal meter:

1 Press Y and open the Setup menu. 2 Highlight Installation and press T. 3 A new set of Installation menu icons will appear, as shown

below. Open the Terrestrial menu, highlight Signal Meter, and press T.

Installation

Terrestrial

Input Configuration

Channel Program

Channel Add/Delete

Signal Meter

4 Press BbC c to select the antenna input and digital

channel whose signal you want to check.

Note: The physical digital channel number listed in the Signal Meter screen may not correspond to a virtual TV channel number. Contact your local broadcasters to obtain the RF channel numbers for your local digital stations.

Signal Meter

Signal Locked

Physical Digital Channel 4

Virtual Digital Channel

Peak

4-1

DoneAdvanced

Viewing the system status

To view the system status:

1 Press Y and open the Setup menu. 2 Highlight Installation and press T. 3 A new set of Installation menu icons will appear, as shown

below. Open the System Status menu, highlight System Information, and press T.

Installation

System Status

System Information

4 Press C c to scroll through the menu bar to select the

Software Version and view the related information.

System Information

Software Version

LV07

3.2.21.0

Nov 17 2006 - 01:52:20

FW: 0B

Done

To close the screen and return to the Installation menu:

Highlight Done and press T.

To return to normal viewing:

Press O.

To close the screen and return to the Terrestrial menu:

Highlight Done and press T.

To return to normal viewing:

Press O.

Chapter 5: Setting up your TV

Reset Factory Defaults

To reset all settings and channels to their factory default values:

1 Press Y and open the Setup menu. 2 Highlight Installation and press T. A new set of

Installation menu icons will appear.

3 Open the System Status menu, highlight System

Information, and press T.

4 Press C c to scroll through the menu bar to select

Factory Defaults.

System Information

Factory Defaults

This window provides the ability to reset the TV settings.Type in your PIN now (or "0000" if no PIN has been set) to restore settings to their factory default values.

Done

5 Enter your PIN code (or 0000 if no PIN code has been set). 6 Highlight Yes and press T. The TV will turn off

automatically after a few seconds. After the TV turns off, unplug the TV power cord and then plug it in again to complete the reset process.

System Information

Press YES to confirm. After the TV turns off, unplug it and plug it back in to complete the reset.

To cancel the reset:

Highlight No and press T.

YesNo

Chapter 6: Using the TV’s features

Selecting the video input source to view

To select the video input source to view:

1 Press + on the remote control or TV control panel. 2 And then either:

a) Press 0–9; or b) Repeatedly press Bb on the remote control and then

press T to change the input; or

c) Repeatedly press + on the remote control or TV

control panel to change the input.

The current signal source displays in the top right corner of the Input Selection screen.

Input Selection ANT

ANT ANT

Built-In DVD

Video 1

Video 2

ColorStream HD1

ColorStream HD2

HDMI 1

HDMI 2 HDMI 3

INPUT

- / to Select

Note:

• You can label the video input sources according to the specific devices you have connected to the TV (- “Labeling the video input sources” at right).

• Sources can also be “hidden” (- “Labeling the video input sources” at right).

• “No Video Signal” will appear randomly on the screen if no signal is received in video input mode.

Navigate

Labeling the video input sources

You can label each video input source according to the type of device you connected to each source, from the following preset list of labels:

• – – (default label)

• Audio Receiver

• Cable

• Compact Disc

• DTV

• DVD

• Game Console

• HD DVD

• Laser Disk

• Satellite/DSS

• VCR

• Video Recorder

•

Hide (to hide an unused input in the

Note: If you select Built-In DVD or PC in the Input Selection screen, you can choose only “– –” or “Hide” as the label.

To label the video input sources:

1 Press Y and open the Preferences menu. 2 Highlight Input Labeling and press T. 3 Press B or b to highlight the video source you want to

label.

Preferences

CC Selector

Base CC Mode

Digital CC Settings

Input Labeling

Channel Labeling

Menu Language

Channel Browser Setup

English

Input Selection

Off

CC1

CC2

CC3

CC4

screen)

Input Labeling

Built-In DVD

Video 1 VCR

Video 2 Cable

ColorStream HD 1 Video Recorder

ColorStream HD 2 Hide

HDMI 1 DTV

HDMI 2

HDMI 3 DVD

Reset

Satellite/DSS

Done

Chapter 6: Using the TV’s features

4 Press C or c to select the desired label for that input

source. If a particular input is not used, you can select Hide as the label, which will cause that input to be “grayed out” in the Input Selection screen and skipped over when you press + on the remote control.

5 To save the new input labels, highlight Done and press

T. To revert to the factory default labels, highlight Reset

and press T.

Input labeling example:

The screen below left shows the default Input Selection screen (with none of the inputs labeled as a specific device). The screen below right is an example of how you could label the inputs if you connected a VCR to VIDEO 1, Cable TV to VIDEO 2, a video recorder to ColorStream HD1, a DTV settop box to HDMI 1, a satellite/DSS set-top box to HDMI 2, and a DVD player to HDMI 3. Also note that the ColorStream HD2 input is labeled “Hidden,” which means that input will be skipped over when + is pressed.

Input Selection ANT

ANT ANT

Built-In DVD

Video 1

Video 2

ColorStream HD1

ColorStream HD2

HDMI 1

HDMI 2 HDMI 3

INPUT

to Select

Navigate

Input Selection screen with no inputs labeled.

To clear the input labels:

Input Selection ANT

ANT ANT

Built-In DVD

VCR

Cable

Video Recorder

ColorStream HD2 (Hidden)

DTV

Satellite/DSS DVD

INPUT

to Select

Navigate

Input Selection screen with all inputs labeled except input 5, which has been hidden.

Tuning channels

Tuning channels using the Channel Browser

The Channel Browser™ provides an easy navigation interface for all your channels and inputs. This feature allows you to:

• Navigate the contents of all of your inputs.

• Keep a list of your favorite channels (see “Favorites

Browser,” below).

• Keep a history of the last 32 channels or inputs viewed.

• Quickly surf and tune your recently viewed channels/inputs

from the Channel Browser next page).

• Surf via Browse mode (to immediately tune channels as you

highlight them in the Channel Browser surf over channels in the Channel Browser select one to tune).

• Quickly change inputs from the Inputs List.

Favorites Browser

The Favorites Browser allows you to quickly set up a favorite channels/inputs list that is integrated into the Channel Browser

To add a favorite channel/input:

1 Tune to the channel or input. 2 Press and hold n for 3 seconds.

Note: Additions are added to the beginning of the Favorites list on the left side of the Channel Browser

™

History List (illustrated on the

™

) or Select mode (to

™

before you

™

1 Press Y and open the Preferences menu. 2 Highlight Input Labeling and press T. 3 Highlight Reset and press T.

To delete a favorite channel/input:

1 Press n to open the Favorites browser list. 2 Highlight the channel or input to delete by pressing

3 C or # c.

3 Press and hold = for 3 seconds. The channel/input will

be removed from the Favorites list.

To set up the Channel Browser™:

1 Press Y and open the Preferences menu. 2 Highlight Channel Browser Setup and press T. 3 Press B to highlight Navigation, and then press C or c

to select either Browse Mode or Select Mode.

Channel Browser Setup

Navigation

History List

ANT List On

Inputs List On

Favorites List On

Reset

Select Mode

Power Off Clear (On)

Done

(continued)

Chapter 6: Using the TV’s features

4 Press b to highlight History List, and then press C or c

to select the setting you prefer: either Power Off Clear (On), On, or Off.

Note: When History List is set to On, the channels and inputs stored in the list will be saved every power on/off cycle. When History List is set to Power Off Clear (On), the channels and inputs stored in the list will be cleared with every power on/off cycle of the TV.

5 Press b to highlight ANT List, and then press C or c to

select On or Off.

6 Press b to highlight Inputs List, and then press C or c

to select On or Off.

7 Press b to highlight Favorites List, then press C or c to

select On or Off.

8 To save your entries, highlight Done and press T.

To return to factory defaults, highlight Reset and press T.

To open the Channel Browser™:

• Press 3 C or # c on the remote control.

• Press 3 C to surf backward through the previously tuned 32

channels in the History list, the channels in the ANT channel list, the inputs in the Inputs list, or the favorite channels/ inputs in Favorites list.

• Press # c to surf forward through the channel History, the

ANT channel list, the Inputs list, or the favorite channels/ inputs in Favorites list.

Note: To access the Channel Browser™ while on the Built-In DVD input, first press E then press 3 C, # c or n.

Note:

• The Channel Browser Once another list has been selected, the Channel Browser will open in the last selected list.

• If all lists are turned off, pressing display the Channel Browser off, n will have no effect.

• Pressing n will bring up the Channel Browser list regardless of the last selected list in the Channel Browser

™

opens in History List by default.

3 C, # c, or n will not

™

. If Favorites List is turned

™

Favorites

To tune to a channel or input in Browse mode:

1 While watching TV, press 3 C or # c to open the

Channel Browser surf forward to the next item in the list.

In Browse mode, when you stop on an item in the Channel Browser automatically tune to the channel or input.

2 Press O to close the Channel Browser

To tune to a channel or input in Select mode:

™

and surf back to a previous item or

™

, it will be highlighted and the TV will

™

1 While watching TV, press 3 C or # c to open the

Channel Browser forward to the next item in the list.

In Select mode, when you stop on an item in the Channel Browser

™

tune the TV to the highlighted item.

™

and surf back to a previous item or

, it will be highlighted but you must press T to

2 Press T to tune the TV to the highlighted item. 3 Press O to close the Channel Browser

™

Elements of the Channel Browser

™

1 2 43

History

10 32 11 8

TVLAND ABCHD WEATHER

1 Current list (History, ANT, Inputs, or Favorites)

2 Input type

3 Channel or input currently being viewed

4 Channel or input that is currently highlighted in the

browser

5 Channels stored in the History List

6 Channel labels

To toggle among the available lists:

After opening the Channel Browser™, press B or b to toggle among History, ANT, Inputs, and Favorites.

Adding and clearing channels and inputs in the History List

Adding channels and inputs to the History List:

As a channel or input is tuned, the Channel Browser™ adds it to the History List and displays it on the “right side” of the Channel Browser “shifted” to the left, eventually moving off the left side. Press 3 C to surf backward through the previously tuned channels/ inputs. Any channel or input that is tuned repeatedly will not be repeated in the History List, but instead is moved to the end of the list on the right side of the Channel Browser

The Channel Browser

• All channels that are tuned using the numeric buttons on the

remote control.

• All channels that are tuned using < or , on the remote

control.

Note: Whenever an item is selected that cannot be tuned (for various reasons), the TV will automatically tune to the previously viewed channel or input.

™

. Previously tuned channels/inputs are

™

will store the following channels:

Chapter 6: Using the TV’s features

Clearing channels from the History List:

• Reconfiguring the ANT input will clear the History List.

Note: See page 32 for details on configuring the antenna input.

Once 32 channels or inputs are stored in the History List, the

•

oldest item will be removed from the list when a new channel or input is tuned.

• If History List in the Channel Browser Setup is set to

“Power Off Clear (On),” turning off the TV will clear the History List.

Tuning to the next programmed channel

To tune to the next programmed channel:

Press < or , on the remote control or TV control panel.

Note:This feature will not work unless you program channels into the TV’s channel memory (- page 33).

Tuning to a specific channel (programmed or unprogrammed)

Tuning analog channels:

Press the Channel Number (0–9) on the remote control. For example, to select channel 125, press 1, 2, 5.

Switching between two channels using SurfLock

The SurfLock™ feature temporarily “memorizes” one channel to the R button, so you can return to that channel quickly from any other channel by pressing R. To memorize a channel to the R button:

™

1 Tune the TV to the channel you want to program into the

R button.

2 Press and hold R for about 2 seconds until the message

“Channel Memorized” appears on-screen. The channel has been programmed to the R button.

3 You can then change channels repeatedly, and when you

press R, the memorized channel will be tuned.

The TV will return to the memorized channel one time only. Once you press R and then change channels again, the CH RTN memory will be cleared and the button will function as Channel Return, by switching back and forth between the last two channels that are tuned. This feature also works for external inputs.

Tuning digital channels:

Press the Channel Number (0–9) on the remote control, followed by the dash (=) button and then the sub-channel number. For example, to select digital channel 125-1, press 1, 2, 5, –, 1.

Note: If a digital channel is not programmed—either through the automatic channel scan (- page 33) or the channel add/ delete function (- page 33)—you will have to tune the RF channel using the Channel Number and dash ( remote control.

=) on the

Switching between two channels using Channel Return

The Channel Return feature allows you to switch between two channels without entering an actual channel number each time.

1 Select the first channel you want to view. 2 Select a second channel using the Channel Number

buttons (and the dash (=) button if selecting a digital channel).

3 Press R on the remote control. The previous channel

will display. Each time you press R, the TV will switch back and forth between the last two channels that were tuned.

Note: If you press R from a non-antenna input, the TV will return to the last-viewed input.

Chapter 6: Using the TV’s features

Selecting the picture size

You can view many program formats in a variety of picture sizes—Natural, TheaterWide 1, TheaterWide 2, TheaterWide 3, Full, 4:3 HD and Native.

Note: The “picture size” illustrations are examples only. The format of the image (in any of the picture sizes) will vary depending on the format of the signal you are currently watching. Select the picture size that displays the current program the way that looks best to you.

You can save separate picture size preferences for each input on your TV.

To select the picture size using the remote control:

Note: If you select one of the TheaterWide

picture sizes, the top and bottom edges of the picture (including subtitles or captions) may be hidden. To view the hidden edges, either scroll the picture (TheaterWide 2 and 3 only) or try viewing the program in Full or Natural picture size.

Natural picture size

• The image is displayed close to its originally formatted

proportion. Some program formats will display with sidebars and/or bars at the top and bottom.

1 Press I on the remote control. 2 While the Picture Size screen is open, you can do one of

the following to select the desired picture size:

• Repeatedly press I.

• Press the corresponding Number button (0–6) while the

Picture Size screen is open.

• Press B or b while the Picture Size screen is open.

Picture Size

Natural

TheaterWide 1

TheaterWide 2

TheaterWide 3

Full

4:3 HD

Native

PIC SIZE

- / to Select

To select the picture size using the menus:

1 Select Picture Size in the Theater Settings menu. 2 Press C or c to select the desired picture size setting. 3 Highlight Done and press T.

Theater Settings

Picture Size Full

Picture Scroll

Cinema Mode Film

Auto Aspect Ratio On

DVD Aspect Ratio 16:9 Wide

Reset

Mode: Sports

Done

Natural picture size example

TheaterWide 1 picture size (for 4:3 format programs)

• The center of the picture remains close to its original

proportion, but the left and right edges are stretched wider to fill the screen.

TheaterWide 1 picture size example

TheaterWide 2 picture size (for letter box programs)

• The picture is stretched wider to fill the width of the screen,

but only slightly stretched taller.

• The top and bottom edges of the picture may be hidden. To

view the hidden areas, see “Scrolling the TheaterWide picture” (- page 43).

A B C D E F G - - - - - - - - - - - - - - - -

TheaterWide 2 picture size example

Note: Some of the picture sizes may not be available depending on the receiving signal format (those will be “grayed out” in the Picture Size screen).

Using these functions to change the picture size (i.e., changing the height/ width ratio) for any purpose other than your private viewing may be prohibited under the Copyright Laws of the United States and other countries, and may subject you to civil and criminal liability.

Chapter 6: Using the TV’s features

TheaterWide 3 picture size (for letter box programs with subtitles)

• The picture is stretched wider to fill the width of the screen,

but only slightly stretched taller.

• The top and bottom edges are hidden. To view the hidden

areas (such as subtitles or captions), see “Scrolling the TheaterWide

A B C D E F G - - - - - - - - - - - - - - - -

picture.”

A B C D E F G - - - - - - - - - - - - - - - - - - - - - - - - - -

TheaterWide 3 picture size example

Full picture size (for 16:9 [480i, 480p] source programs only)

• If receiving a squeezed 4:3 format program, the picture is

stretched wider to fill the width of the screen, but not stretched taller.

• None of the picture is hidden.

Note:

• Native picture size is available for 720p, 1080i, and 1080p

signals only. If the signal being received is other than 1080i, 1080p, or 720p, “Native” will be grayed out in the Picture Size screen.

• This mode is supported only for HDMI and ColorStream

inputs.

• Depending on the input signals, the border of the picture

may be hidden, displayed in black, or noisy.

Native picture size example

Scrolling the TheaterWide® picture (TheaterWide 2 and 3 only)

You can set separate scroll settings for the TheaterWide 2 and TheaterWide 3 modes for each input.

To set the scroll settings:

Full picture size example

4:3 HD picture size (for 720p, 1080i, and 1080p program sources only)

• Sidebars fill the empty vertical spaces.

• Picture is not distorted from original size.

4:3 HD picture size example

Native picture size (for 720p, 1080i, and 1080p signal programs)

• If receiving a 720p, 1080i, or 1080p signal program, Native

mode scales the video to display the entire picture within the borders of the screen (i.e. no overscanning).

• This is especially useful for external HD sources such as

HD-DVD, DVHS movies, or PC graphics.

1 Press Y and open the Video menu. 2 Highlight Theater Settings and press T.

Video

Mode

Picture Settings

Noise Reduction

Game Mode

Theater Settings

Sports

Off

3 In the Picture Size field, select either TheaterWide 2

or TheaterWide 3 (you cannot scroll in any other mode).

4 Press b to highlight the Picture Scroll field. 5 Press C or c to scroll the picture up and down as needed,

from –10 to +20.

Theater Settings

Picture Size TheaterWide 2

Picture Scroll -5

Cinema Mode Film

Auto Aspect Ratio On

DVD Aspect Ratio 16:9 Wide

Mode: Sports

DoneReset

6 To save the new settings, highlight Done and press T.

To revert to the factory defaults, highlight Reset and press T.

Chapter 6: Using the TV’s features

Using the auto aspect ratio feature

When the auto aspect ratio feature is set to On, the TV will automatically select the picture size when one of the following input sources is received:

• A 480i signal from the VIDEO 1, VIDEO 2, ColorStream

HD-1, or ColorStream HD-2 input.

• A 480i, 480p, 720p, 1080i, 1080p, or VGA signal from the

HDMI input.

Aspect ratio of signal source

4:3 normal Natural (with sidebars)

4:3 letter box TheaterWide 2

16:9 full Full

Not defined (no ID-1 data or HDMI aspect data)

Note: The auto aspect ratio feature is not applicable to antenna or cable input sources.

To turn on the auto aspect ratio feature:

1 Press Y and open the Video menu. 2 Highlight Theater Settings and press T. 3 In the Auto Aspect Ratio field, select On.

Automatic aspect size (automatically selected when Auto Aspect is On)

The current picture size you set under “Selecting the picture size” on page 42.

Theater Settings

Picture Size Natural

Picture Scroll --

Cinema Mode Film

Auto Aspect Ratio On

DVD Aspect Ratio 16:9 Wide

DoneReset

Mode: Sports

Selecting the cinema mode (480i and 1080i signals)

When you view a DVD (3:2 pulldown processed) from a DVD player connected to the VIDEO 1, VIDEO 2, ColorStream HD-1, ColorStream HD-2 (component video), or HDMI inputs on the TV, smoother motion can be obtained by setting the Cinema Mode to Film.

To set the Cinema Mode to Film:

1 Press Y and open the Video menu. 2 Highlight Theater Settings and press T. 3 In the Cinema Mode field, select Film.

Theater Settings

Picture Size Natural

Picture Scroll --

Cinema Mode Film

Auto Aspect Ratio On

DVD Aspect Ratio 16:9 Wide

4 To save the new settings, highlight Done and press T.

To revert to the factory defaults, highlight Reset and press T.

To set the Cinema Mode to Video:

Select Video in step 3 above.

Mode: Sports

DoneReset

4 To save the new settings, highlight Done and press T.

To revert to the factory defaults, highlight Reset and press T.

To turn off the auto aspect ratio feature:

Select Off in step 3 above.

Chapter 6: Using the TV’s features

Adjusting the picture

Selecting the picture mode

You can select your desired picture settings from four different modes, as described below.

Mode Picture Quality

Sports Bright and dynamic picture (factory setting)

Standard Standard picture settings (factory setting)

Movie

Preference Your personal preferences

To select the picture mode:

Press u on the remote control. The following popup menu appears on-screen.

Press B or b to select the picture mode you prefer and press T.

To select the picture mode using the menu system:

1 Press Y and open the Video menu. 2 Highlight Mode and press T.

3 Press B or b to select the picture mode you prefer and

press T.

Note: The picture mode you select affects the current input only. You can select a different picture mode for each input.

Lower contrast for darkened room (factory setting)

Sports

Standard

Movie

Preference

Video

Mode

Picture Settings

Noise Reduction

Game Mode Theater Settings

Sports

Off

Sports

Standard

Movie

Preference

Adjusting the picture quality

You can adjust the picture quality (Contrast, Back Light, DynaLight™, Brightness, Color, Tint, and Sharpness) to your personal preferences.

Selection Pressing C Pressing c

Contrast lower higher

Back Light* darker lighter

DynaLight** On/Off On/Off

Brightness darker lighter

Color paler deeper

Tint reddish greenish

Sharpness softer sharper

* Back Light

This feature adjusts the brightness of the entire screen. When in video mode and no signal is input, this will automatically be set to 0. (Settings are stored in memory.)

**DynaLight

This function automatically strengthens the black coloring of dark areas in the video according to the level of darkness.

To adjust the picture quality:

1 Press Y and open the Video menu. 2 Highlight Picture Settings and press T. 3 Press B or b to select the picture quality you want to

adjust (Contrast, Back Light, DynaLight, Brightness, Color, Tint, or Sharpness), and then

press C or c to adjust the setting, as described in the table above.

Picture Settings

Contrast 100

Back Light 100

DynaLight

Brightness

Color

Tint

Sharpness

Advanced Picture Settings

Picture Settings Mode: Preference

Contrast 70

Reset

Mode: Sports

Done

4 To save the new settings, highlight Done and press T.

You can use any of the picture modes (- “Selecting the picture mode,” above left) as a starting point for adjusting the picture settings.

To revert back to the base mode that you began adjusting the picture settings from, highlight Reset and press T.

The picture qualities you adjusted are automatically saved in the Preference mode (- “Selecting the picture mode,” above left) until Reset is selected.

Chapter 6: Using the TV’s features

Using the closed caption mode

Base closed captions

The closed caption mode has two options:

• Captions—An on-screen display of the dialogue, narration,

and sound effects of TV programs and videos that are closed captioned (usually marked “CC” in program guides).

• Text—An on-screen display of information not related to

the current program, such as weather or stock data (when provided by individual stations).

To view captions or text:

1 Press Y and open the Preferences menu. 2 Highlight Base CC Mode and press c. 3 Press B or b to select the desired closed caption mode and

press T.

Preferences

CC Selector

Base CC Mode

Digital CC Settings

Input Labeling

Channel Labeling

Menu Language

Channel Browser Setup

English

• To view captions:

Highlight CC1, CC2, CC3, or CC4. (CC1 displays translation of the primary language in your area.)

Off

CC1

CC2

CC3

CC4

Note: A closed caption signal may not display in the following situations:

• When a videotape has been dubbed

• When the signal reception is weak

• When the signal reception is non-standard

Digital CC Settings

You can customize the closed caption display characteristics by changing the background color, opacity, text size, type, edge, and color.

Note:

• This feature is available for digital channels only.

• You cannot set the Caption Text and Background as the

same color.

To customize the closed captions:

1 Press Y and open the Preferences menu. 2 Highlight Digital CC Settings and press T. 3 Press B or b to highlight the characteristic you want to

change, and then press C or c to select the format for that characteristic (see table below).

Digital CC Settings

Caption Size Auto

Caption Text Type

Caption Text Edge

Caption Text Color

Text Foreground Opacity

Background Color

Text Background Opacity

Caption Text Edge Color

Reset

Auto

ABC123

Done

Preview window

Giant pandas eat leaves.

Note: If the program or video you selected is not closed captioned, no captions will display on-screen.

To view text:

•

Highlight T1, T2, T3, or T4.

WORLD WEATHER

Temps Current F C Weather LONDON 51 11 MOSCOW PARIS ROME TOKYO

57 14 53 12 66 19 65 18

Clear Cloudy Clear Cloudy Rain

Note: If text is not available in your area, a black rectangle may appear on screen. If this happens, set the Base CC Mode to Off.

To turn off the closed caption mode:

•

Select Off in step 3 above.

4 To save the new settings, highlight Done and press T.

To revert to the factory defaults, highlight Reset and press T.

Caption Size Auto, Small, Standard, Large

Caption Text Type

Caption Text Edge

Caption Text Color

Text Foreground Opacity

Background Color

Text Background Opacity

Caption Text Edge Color

Auto, Default, Mono w. Serif, Prop. w. Serif, Mono w/o Serif, Prop. w/o Serif, Casual, Cursive, Small Capitals

Auto, None, Raised, Depressed, Uniform, Left Drop Shadow, Right Drop shadow

Auto, Black, White, Red, Green, Blue, Yellow, Magenta, Cyan

Auto, Transparent, Translucent Flashing, Solid

Auto, Black, White, Red, Green, Blue, Yellow, Magenta, Cyan

Auto, Transparent, Translucent Flashing, Solid

Auto, Black, White, Red, Green, Blue, Yellow, Magenta, Cyan

Chapter 6: Using the TV’s features

CC Selector

You can use the CC Selector to temporarily override the default analog caption mode (set in Base CC Mode) for a particular channel. However, once you change to another analog channel, the closed caption setting will automatically change back to the current Base CC Mode setting.

You can also use the CC Selector to select digital closed caption services (if available). When such services are not available, the CC Selector presents a default list of services. If the selected service is not available, the next best service will be used instead.

To select closed captions:

1 Press Y and open the Preferences menu. 2 Highlight CC Selector and press T.

Preferences

CC Selector

Base CC Mode

Digital CC Settings

Input Labeling

Channel Labeling

Menu Language

Channel Browser Setup

English

Off

CC1

CC2

CC3

CC4

Adjusting the audio

Muting the sound

Press W to partially reduce (1/2 MUTE) or turn off (MUTE) the sound. Each time you press W, the mute mode will change in the following order:

Volume1/2 Mute Mute

If the closed caption mode is set to Off when you select “MUTE” mode, the closed caption feature is automatically activated. To mute the audio without automatically activating the closed caption feature, use Z to set the volume to 0. See “Using the closed caption mode” (- page 46) for more information on closed caption modes.

Using the digital audio selector

You can use the Digital Audio Selector to conveniently switch between audio tracks on a digital channel (for those channels that have multiple audio tracks). This temporarily overrides the audio track chosen by the language option under Audio Setup (- “Selecting stereo/SAP broadcasts” on page 48).

3 Press B or b to select Closed Caption, and then press

C or c to select the desired service.

Closed Caption

Audio

CC 1

None

4 Press O.

To use the digital audio selector:

1 Press Y and open the Audio menu. 2 Highlight Digital Audio Selector and press T.

Audio

Digital Audio Selector

Audio Settings

Advanced Audio Settings

Audio Setup

3 Press B or b to select Audio, and then press C or c to

select the desired service.

CC 1Closed Caption

Audio

None

4 Press O.

Chapter 6: Using the TV’s features

Selecting stereo/SAP broadcasts

The multi-channel TV sound (MTS) feature allows you to output high-fidelity stereo sound. MTS also can transmit a second audio program (SAP) containing a second language, music, or other audio information (when provided by individual stations).

When the TV receives a stereo or SAP broadcast, the word “STEREO” or “SAP” appears on-screen when E is pressed. The MTS feature is not available when the TV is in VIDEO mode.

To listen to stereo sound:

1 Press Y and open the Audio menu. 2 Highlight Audio Setup and press T.

Audio

Digital Audio Selector

Audio Settings

Advanced Audio Settings

Audio Setup

3 In the MTS field, select Stereo.

Audio Setup

PC Audio No

HDMI 1 Audio

MTS Stereo

Language

Optical Output Format

Dolby Digital Dynamic Range Control

DVD Audio

Reset

Auto

English

Dolby Digital/Surround

Compressed

Stereo

Done

To listen to a second audio program on an analog station (if available):

Select SAP in step 3 above.

Note:

• A second audio program (SAP) can be heard only on those

TV stations that offer it. For example, a station might broadcast another language as a second audio program. If you have SAP on, you will see the current program on the screen but hear the other language instead of the program’s normal audio.

• If you have SAP on and the station you are watching is not

broadcasting a second audio program, the station’s normal audio will be output. However, occasionally there is no sound at all in SAP mode. If this happens, set the MTS feature to Stereo mode.

Adjusting the audio quality

You can adjust the audio quality by adjusting the bass, treble, and balance.

To adjust the audio quality:

1 Press Y and open the Audio menu. 2 Highlight Audio Settings and press T. 3 Press b or B to highlight the item you want to adjust

(Bass, Treble, or Balance).

Audio Settings

Bass 100

Treble

Balance

StableSound Off

Reset

100

Done

4 To save the new settings, highlight Done and press T.

To reset the settings to the factory defaults, highlight Reset and press T.

Note:

• You can typically leave the TV in Stereo mode because it will automatically output the type of sound being broadcast (stereo or monaural).

• If the stereo sound is noisy, select Mono to reduce the noise.

To listen to an alternate language on an ATSC digital station (if available):

Highlight the Language field in step 3 above, and then press C or c to select the language you prefer.

4 Press C or c to adjust the level.

• C makes the bass or treble weaker or increases the

balance in the left channel (depending on the item selected).

• c makes the bass or treble stronger or increases the

balance in the right channel (depending on the item selected).

5 To save the new settings, highlight Done and press T.

To reset the settings to the factory defaults, highlight Reset and press T.

Chapter 6: Using the TV’s features

Using the StableSound® feature

The StableSound® feature limits the highest volume level to prevent extreme changes in volume when the signal source changes (for example, to prevent the sudden increase in volume that often happens when a TV program switches to a commercial).

To turn on the StableSound® feature:

1 Press Y and open the Audio menu. 2 Highlight Audio Settings and press T . 3 In the StableSound field, select On.

Audio Settings

Bass 100

Treble

Balance

StableSound On

Reset

100

Done

4 To save the new settings, highlight Done and press T.

To revert to the factory defaults, highlight Reset and press T.

Note: The RESET function returns your audio adjustments to the following factory settings:

Bass . . . . . . . . center (50)

Treble . . . . . . . center (50)

Balance . . . . . . center (0)

StableSound . . Off

To turn off the StableSound feature:

Select Off in step 3 above.

Selecting the optical audio output format

You can use this feature to select the optical audio output format when you connect a Dolby Digital decoder or other digital audio system to the Optical Audio Out terminal on the TV (see “Connecting a digital audio system” on page 21).

To select the optical audio output format:

1 Press Y and open the Audio menu. 2 Highlight Audio Setup and press T.

3 In the Optical Output Format field, select either

Dolby Digital/Surround or PCM, depending on your

device.

Audio Setup

PC Audio No

HDMI 1 Audio

MTS Stereo

Language

Optical Output Format

Dolby Digital Dynamic Range Control

DVD Audio

Reset

Auto

English

Dolby Digital/Surround

Compressed

Stereo

Done

4 To save the new settings, highlight Done and press T.

To revert to the factory defaults, highlight Reset and press T.

Note: You cannot change the optical audio output format while you are viewing a DVD. (You must be in FULL-STOP mode, not RESUME-STOP mode.)

Using the Dolby® Digital Dynamic Range Control feature

This dynamic range control feature causes the ATSC dynamic range to be further compressed, allowing you to switch from ATSC to analog broadcasts at the same dynamic range.

To use the Dolby Digital Dynamic Range Control:

1 Press Y and open the Audio menu. 2 Highlight Audio Setup and press T. 3 In the Dolby Digital Dynamic Range Control field,

select Compressed. When Standard is selected, the audio is output with minimal compression.

Audio Setup

PC Audio No

HDMI 1 Audio

MTS Stereo

Language

Optical Output Format

Dolby Digital Dynamic Range Control

DVD Audio

Reset

Auto

English

Dolby Digital/Surround

Compressed

Stereo

Done

4 To save the new settings, highlight Done and press T.

To revert to the factory defaults, highlight Reset and press T.

Note:

• This item will be grayed out for NTSC signals, Video, ColorStream, and PC inputs.

• The Dolby Digital Dynamic Range Control will function in relation to Optical Output Format (PCM mode).

Using the Locks menu

Chapter 6: Using the TV’s features

When the correct PIN code is entered, the Locks menu opens.

The Locks menu includes the Enable Rating Blocking, Edit Rating Limits, Channels Block, Input Lock, Front (control) Panel Lock, and New PIN Code features. You can use these features after entering the correct PIN code.

Entering the PIN code

Press Y and highlight the Locks menu icon.

Locks

Enable Rating Blocking

Edit Rating Limits

Channels Block

Input Lock

Front Panel Lock

New PIN Code

Off

2 Press b, which displays the PIN code entry screen.

• The Lock System screen (below) appears if a PIN

code has not been stored. Press the Channel Number buttons to enter a new four-digit code, enter the code a second time to confirm, and press T.

Lock System

Please enter a 4 digit PIN code

Confirm PIN code

Locks

Enable Rating Blocking

Edit Rating Limits

Channels Block

Input Lock

Front Panel Lock

New PIN Code

Off

If you cannot remember your PIN code

While the PIN code entering screen is displayed, press E four times within five seconds. The PIN code will be cleared and you can enter a new PIN code.

Changing your PIN code

Press Y and highlight the Locks menu icon.

2 Press b to display the PIN code entering screen. 3 Enter your four-digit PIN code and press T. 4 Press b to highlight New PIN Code and press T.

Locks

Enable Rating Blocking

Edit Rating Limits

Channels Block

Input Lock

Front Panel Lock

New PIN Code

Off

Cancel Done

• The Locks/Active screen (below) appears if the PIN

code is already stored. Use the Number buttons to enter your four-digit code and press T.

Locks Active

Please enter the 4 digit PIN code

****

Cancel

Done

If the wrong PIN code is entered, the message “Incorrect PIN code, please try again!” appears. Highlight Retry and press T. Enter the code again and press T.

5 Press the Number buttons to enter a new four-digit code.

Reenter the PIN code to confirm it.

6 Press T. The new PIN code is now active.

New PIN Code

Please enter a 4 digit PIN code

****

Confirm PIN code

****

Cancel Done

Chapter 6: Using the TV’s features

Blocking TV programs and movies by rating (V-Chip)

Some TV programs and movies include signals that classify the content of the program (violence, sex, dialog, language). The V-Chip feature in this TV detects the signals and blocks the programs according to the ratings you select. (For rating descriptions, see the tables on the next page.)

Note: Rating blocking is a function of the V-Chip feature in this TV, which supports the U.S. V-Chip system only.

To block and unblock TV programs and movies:

1 Press Y and highlight the Locks menu icon. 2 Press b to display the PIN code entering screen. 3 Enter your four-digit PIN code and press T. 4 Press b to highlight Enable Rating Blocking. 5 Press c and b to select On, and then press T.

Locks

Enable Rating Blocking

Edit Rating Limits

Channels Block

Input Lock

Front Panel Lock

New PIN Code

Off

6 Press b to highlight Edit Rating Limits and press T.

The Edit Rating Limits screen (below) appears.

7 Press BbC c and then press T to select the level of

blocking you prefer. A box with an “5” is a rating that will be blocked. As you highlight a rating, a definition for the rating appears at the bottom of the screen.

8 When done selecting the ratings you want to block,

highlight Done and press T.

Edit Rating Limits

(V-CHIP) FV

D L S V

TV-Y

TV-Y7

TV-G

TV-PG

TV-14

TV-MA

"None" Rated

Movies

PG-13

NC-17

Children

Youth

Alt RS

Cancel

Done

Downloading an additional rating system for blocking TV programs and movies

In the future, an additional rating system may become available for use in selectively blocking programs.

Note: The currently tuned station must be receiving a digital signal before an additional rating system can be downloaded.

To download the additional rating system (if available):

The Edit Rating Limits screen appears.

7 Highlight Alt RS and press T. The Edit Alternate

Ratings screen will appear.

Note:

• The Alt RS button will only be available if an additional rating system is currently available.

• It may take several minutes for the TV to download the additional rating system.

• The information displayed in the Alternate Ratings screen will depend on the configuration of the additional rating system available at the time of download.

8 Press B b C c and then press T to select the level of

blocking you prefer. A box with an “5” is a rating that will be blocked.

9 When you are finished selecting the ratings you want to

block, highlight Done and press T.

10 In the Edit Rating Limits screen, highlight Done and

press T.

Note:

• The additional rating system can only be downloaded one time. You will not be able to download any updates to the rating system should such updates become available.

• The additional rating system is not designed, transmitted, or controlled by the TV or Toshiba, nor is the availability of an additional rating system determined or controlled by Toshiba. Similarly, the rating of programs in an additional rating system is not determined, transmitted, or controlled by the TV or Toshiba.

• The additional rating system is an evolving technology; therefore, availability, content, and format may vary.

(continued)

Chapter 6: Using the TV’s features

Independent rating system for broadcasters Ratings Description and Content themes

Mature Audience Only (This program is specifically designed to be viewed by adults and therefore may

TV-MA

TV-14

be unsuitable for children under 17.) L) Crude or indecent language S) Explicit sexual activity V) Graphic violence

Parents Strongly Cautioned (This program contains some material that many parents would find unsuitable for children under 14 years of age.)

Intensely suggestive dialog L) Strong, coarse

language

S) Intense sexual situations V) Intense

violence

Parental Guidance Suggested (This program contains material parents may find unsuitable for

TV-PG

younger children.)

Some suggestive dialog L) Infrequent coarse

language

S) Some sexual situations V) Moderate

violence

TV-G

TV-Y7, TV-Y7FV

TV-Y

General Audience (Most parents would find this program suitable for all ages.)

Directed to Older Children (This program is designed for children age 7 and above. Note: Programs in which fantasy violence may be more intense or more combative than other programs in this category are designated TV-Y7FV.)

All Children (This program is designed to be appropriate for all children.)

Independent rating system for movies Ratings Description and Content themes

X NC-17

PG-13

Note:

• If you place an “ 5” in the box next to “ ‘None’ Rated,”

programs rated “None” will be blocked; however, programs that do not provide any rating information will not be blocked.

• To display the rating of the program you are watching, press

X-rated (For adults only)

Not intended for anyone 17 and under

Restricted (Under 17 requires accompanying parent or adult)

Parents Strongly Cautioned (Some material may be inappropriate for children under 13)

Parental Guidance Suggested (Some material may not be suitable for children)

General Audience (Appropriate for all ages)

E on the remote control. If it is rated “None,” the word

“NONE” appears in the RECALL screen (as shown below right). If rating information is not provided, no rating will appear in the RECALL screen.

Blocking channels

With the Channels Block feature, you can block specific channels. You will not be able to tune blocked channels unless you unlock them.

To block channels:

1 Press Y and highlight the Locks menu icon. 2 Press b to display the PIN code entering screen. 3 Enter your four-digit PIN code and press T

(- page 50).

4 Press b to highlight Channels Block and then press T.

A list of the channels available for that input will be displayed along with the call letters for each channel, if available.

Locks

Enable Rating Blocking

Edit Rating Limits

Channels Block

Input Lock

Front Panel Lock

New PIN Code

Off

5 Press Bb to highlight the channel you want to block and

press T, which puts an “5” in the box next to that channel.

Channels Block

Allow All

Block All

Cancel

Done

6 Repeat step 5 for other channels you want to block. 7 Highlight Done and press T.

To unblock individual channels:

In step 5 above, press Bb to highlight the channel you want to unblock, press T to remove the “5” from the box, highlight Done and press T.

TV - PG L V NONE

Chapter 6: Using the TV’s features

To block all channels at once:

Highlight Block All in step 5 on previous page and then highlight Done and press T.

To unblock all locked channels at once:

Highlight Allow All in step 5 on previous page and then highlight Done and press T.

Channels Block

Allow All

Block All

Cancel

Done

Unlocking programs temporarily

If you try to tune the TV to a program that exceeds the rating limits you set, the TV will enter program lock mode and the following message will appear on-screen:

This program exceeds the rating limit you set.

Push 'mute' to enter PIN.

Using the input lock feature

You can use the Input Lock feature to lock the video inputs (Built-In DVD, VIDEO 1, VIDEO 2, ColorStream HD-1, ColorStream HD-2, HDMI 1, HDMI 2, HDMI 3 and PC) and channels 3 and 4. You will not be able to view the input sources or channels until you unlock the inputs.

To lock/unlock the video inputs:

1 Press Y and highlight the Locks menu icon. 2 Press b to display the PIN code entering screen. 3 Enter your four-digit PIN code and press T. 4 Press b to highlight Input Lock and press c. 5 Press B or b to select the level of video input locking you

prefer, as described below. Video: Locks Built-In DVD, VIDEO 1, VIDEO 2,

ColorStream HD1/HD2, HDMI 1, HDMI 2, HDMI 3, and PC.

Video+: Locks Built-In DVD, VIDEO 1, VIDEO 2, ColorStream HD1/HD2, HDMI 1, HDMI 2, HDMI 3, PC and channels 3 and 4.

• Select Video+ if you play video tapes via an ANT

input.

You can either temporarily unlock the program or select an unlocked program to watch.

To temporarily unlock the program:

1 Press W. 2 Enter your four-digit PIN code and press T. If the correct

code is entered, the program lock mode is released and the normal picture appears. All locking is disabled until the TV is turned off, and will be enabled when the TV is turned on again.

Locks Active

Enter PIN code to temporarily unblock.

****

Cancel

Done

Locks

Enable Rating Blocking

Edit Rating Limits

Channels Block

Input Lock

Front Panel Lock

New PIN Code

Off

Video

Off

Video +

Off: Unlocks all video inputs and channels 3 and 4.

6 Press T.

Chapter 6: Using the TV’s features

Using the control panel lock feature

You can lock the control panel to prevent your settings from being changed accidentally (by children, for example). When the control panel lock is On, none of the controls on the TV control panel will operate except POWER.

To lock the control panel:

1 Press Y and highlight the Locks menu icon. 2 Press b to display the PIN code entering screen. 3 Enter your four-digit PIN code and press T. 4 Press b to highlight Front Panel Lock. 5 Press c and C or c to highlight On and press T. When

the control panel is locked and any button on the control panel (except POWER) is pressed, the message “Not Available” appears.

Locks

Enable Rating Blocking

Edit Rating Limits

Channels Block

Input Lock

Front Panel Lock

New PIN Code

To unlock the control panel:

Highlight Off in step 5 above, or press and hold the VOLUME – button on the TV control panel for about 10

seconds until the volume icon appears.

Off

Using the PC settings feature

You can view an image from a PC on the TV screen. When a PC is connected to the TV's PC IN terminal, you can

use the PC Settings feature to make adjustments to the image. If the edges of the picture are cut off, readjust the Horizontal

Position and Vertical Position. If the picture is affected by interference, readjust the Clock Phase and Sampling Clock.

To adjust the PC settings:

1 Repeatedly press + to select PC input mode

(- “Selecting the video input source to view” page 38).

2 Press Y and open the Setup menu. 3 Highlight PC Settings and press T.

Setup

Installation

Sleep Timer

PC Settings

Note: If a PC is not connected or there is no pc input signal, this feature will be grayed out in the Setup menu.

4 Press B or b to highlight the item you want to adjust. 5 Press C or c to make the appropriate adjustments.

PC Settings

Horizontal Position 0

Vertical Position

Clock Phase

Sampling Clock

Reset

Done

Note: The screen is disrupted momentarily when adjusting the PC settings. This is not a sign of malfunction.

Horizontal Position:

•

Moves the picture left/right. The adjustment range is within ±10 from center.*

• Vertical Position:

Moves the picture up/down. The adjustment range is within ±10 from center.*

• Clock Phase:

Helps to reduce noise and sharpen the picture. The adjustment range is within ±4 from center.*

• Sampling Clock:

Helps to reduce noise and minimize periodic vertical stripes on the screen. The adjustment range is within ±5 from center.*

* The default settings may vary depending on the input signal format.

Chapter 6: Using the TV’s features

Setting the PC Audio

This function allows you to output the sound from your PC (if connected) or mute the sound from your PC and output the sound from your HDMI (DVI) connection. (- page 20)

To set the PC Audio:

1 Press Y and open the Audio menu. 2 Highlight Audio Setup and press T. 3 Press B or b to select PC Audio and then press C or c

to select No or Yes.

Yes: Outputs the sound from your PC. No: Mutes the sound from your PC, and outputs the

sound from the HDMI-1 connection.

Audio Setup

PC Audio No

HDMI 1 Audio

MTS Stereo

Language

Optical Output Format

Dolby Digital Dynamic Range Control

DVD Audio

Reset

Auto

English

Dolby Digital/Surround

Compressed

Stereo

Done

™

Audio mode”

Setting the sleep timer

You can set the sleep timer to turn off the TV after a set length of time (maximum of 180 minutes).

To set the sleep timer using the remote control:

Press [ on the remote control to set the length of time until the TV turns off. Repeatedly press [ to increase the time in 10-minute increments, or press B or b to increase or decrease the time in 10-minute increments, to a maximum of 180 minutes.

To set the sleep timer using the on-screen menus:

1 Press Y and open the Setup menu. 2 Highlight Sleep Timer and press T.

Setup

Installation

Sleep Timer

PC Settings

3 Press the Number buttons to enter the length of time in

10-minute increments.

Sleep Timer

Enter total minutes until the TV

turns off automatically (Maximum

180 minutes)

120

Cancel Done

4 Highlight Done and press T.

Note: When a power failure occurs, the sleep timer setting may be cleared.

To display the remaining sleep time:

Press [.

Sleep Timer

120 minutes

Note: A message will display on-screen when there is one minute remaining on the sleep timer.

To cancel the sleep timer:

Repeatedly press [ until it is set to 0 minute.

Chapter 6: Using the TV’s features

Displaying TV status information

To display TV status information using RECALL:

Press E on the remote control. The following information will display (if applicable):

• Current input (ANT, VIDEO 1, etc.)

• If ANT is the current input, either “CABLE” (for cable TV)

or “ANT” (for over-the-air broadcasts).

• Channel number (if in ANT mode)

• Channel label (if set)

• Digital signal strength indicator (bar graph in lower right

corner of box; for ATSC signal only)

• Stereo, Mono or SAP audio status (when HDMI input mode,

Dolby Digital or PCM)

• Video resolution

• Aspect ratio of incoming video signal (4:3 or 16:9)

• V-Chip rating status

ANT

123-456

ABCHD

Stereo SAP

16:9

TV-PG L V1080i

9:00pm

Understanding the auto power off feature

The TV will automatically turn itself off after approximately 15 minutes if it is tuned to a vacant channel or a station that completes its broadcast for the day. This feature functions in ANT mode and Built-In DVD mode (No disc) only.

Understanding the last mode memory feature

If the power is cut off while you are viewing the TV, the Last Mode Memory feature automatically turns on the TV when the power is resupplied.

Note: You should unplug the TV’s power cord if it is possible that you will be away from the TV for an extended period of time after the power is restored.

To close the RECALL screen:

Press E again.

To display TV status information using INFO:

Press Q on the remote control. The following additional information will display for off air

digital channels (if applicable):

• Title

• Duration

• Detailed description

ANT

123-456

ABCHD

Note: The location of the banner can be moved to the top or bottom of the screen by pressing B or b while the RECALL or INFO display is on-screen. (The last position will be stored to memory.)

Stereo SAP

MLB Young,s XXX...

Today,s Major League Baseball.

16:9

TV-PG L V1080i

East

9:00pm -11:00pm

Chapter 7: Using the TV’s advanced features

Using the advanced picture settings features

Using dynamic contrast

When dynamic contrast is set to Low, Middle, or High, the TV will detect changes in the picture quality that affect the appearance of your contrast settings and then automatically adjust the video.

To select dynamic contrast preferences:

1 Press Y and open the Video menu. 2 Highlight Picture Settings and press T.

Video

Mode

Picture Settings

Noise Reduction

Game Mode Theater Settings

3 Highlight Advanced Picture Settings and press T.

Picture Settings

Contrast 100

Back Light 100

DynaLight

Brightness

Color

Tint

Sharpness

Advanced Picture Settings

4 In the Dynamic Contrast field, select either Off, Low,

Middle or High.

Advanced Picture Settings Mode: Preference

Dynamic Contrast

Static Gamma

Color Temperature

5 To save the new settings, highlight Done and press T.

To revert to the factory defaults, highlight Reset and press T.

Note: If you select one of the factory-set picture modes (Sports, Standard, or Movie) and then change the dynamic contrast setting, the picture mode automatically changes to Preference.

Reset

Sports

Off

Mode: Sports

Done

Off

Cool

Done

Using the static gamma feature

The static gamma feature allows you to adjust the levels of black in the picture.

To adjust the static gamma settings:

1 Press Y and open the Video menu. 2 Highlight Picture Settings and press T.

Video

Mode

Picture Settings

Noise Reduction

Game Mode Theater Settings

Sports

Off

3 Highlight Advanced Picture Settings and press T.

Picture Settings

Contrast 100

Back Light 100

DynaLight

Brightness

Color

Tint

Sharpness

Advanced Picture Settings

Reset

Mode: Sports

Done

4 In the Static Gamma field, press C or c to adjust the

static gamma. The adjustment range is within ±5 from center.

Advanced Picture Settings Mode: Preference

Dynamic Contrast

Static Gamma

Color Temperature

Reset

High

Cool

Done

• If the setting is moved in the minus direction, the detail

of black colors will be decreased.

• If the setting is moved in the plus direction, the detail of

black colors will be increased.

5 To save the new settings, highlight Done and press T.

To revert the factory defaults, highlight Reset and press T.

Note: If you select one of the factory-set picture modes (Sports, Standard or Movie) and then change the static gamma setting, the picture mode automatically changes to Preference.

Chapter 7: Using the TV’s advanced features

Selecting the color temperature

You can change the quality of the picture by selecting from three preset color temperatures (Cool, Medium, and Warm), as described below.

Mode Picture Quality

Cool blueish

Medium neutral

Warm reddish

To select the color temperature:

1 Press Y and open the Video menu. 2 Highlight Picture Settings and press T. 3 Highlight Advanced Picture Settings and press T. 4 Highlight Color Temperature and press T.

Advanced Picture Settings Mode: Preference

Dynamic Contrast

Static Gamma

Color Temperature

Reset

High

Cool

Done

5 In the Color Temperature field, select the mode you

prefer (Cool, Medium, or Warm).

Color Temperature Mode: Preference

Color Temperature

B Drive

G Drive

Reset

Cool

Done

6 Press B or b to select either B Drive or G Drive, and

then press C or c to adjust the settings.

B Drive

G Drive

• B Drive: c makes the picture blueish.

• G Drive: c makes the picture greenish.

Note: The B Drive and G Drive settings are connected to the Color Temperature settings and will change based on which setting is selected in step 5 above.

7 To save the new settings, highlight Done and press T.

To revert to the factory defaults, highlight Reset and press T.

Note: If you select one of the factory-set picture modes (Sports, Standard, or Movie) and then change the color temperature mode, the picture mode automatically changes to Preference.

Using CableClear® digital noise reduction

The CableClear® digital noise reduction feature allows you to reduce visible interference in your TV picture. This may be useful when receiving a broadcast with a weak signal (especially a Cable channel) or playing a noisy video cassette or disc.

To change the CableClear settings:

1 Press Y and open the Video menu. 2 Highlight Noise Reduction and press T.

Video

Mode

Picture Settings

Noise Reduction

Game Mode Theater Settings

Sports

Off

3 In the CableClear field, select your desired setting.

Noise Reduction ANT

CableClear

MPEG Noise Reduction

Reset

Done

Auto

Low

Note:

• If the current input is ANT, VIDEO 1, or VIDEO 2, the menu will display the text “CableClear.” The available selections are Off, Auto, Low, Middle, and High.

• If the current input is ColorStream HD1, ColorStream HD2, HDMI 1, HDMI 2, or HDMI 3 the menu will display the text “DNR.” The available selections are Off, Auto, Low, Middle, and High. Auto will react proportionally

to the strength of the noise. Low, Middle, and High will reduce the noise in varying degrees, from lowest to highest, respectively.

4 To save the new settings, highlight Done and press T.

To revert to the factory defaults, highlight Reset and press T.

Chapter 7: Using the TV’s advanced features

Using MPEG noise reduction

The MPEG noise reduction feature allows you to reduce visible interference caused by MPEG compression. Choices for MPEG noise reduction are Off, Low, Middle, and High. Off is automatically selected when this feature is disabled (“grayed out”).

To select the MPEG noise reduction level:

1 Press Y and open the Video menu. 2 Highlight Noise Reduction and press T. 3 Press B or b to highlight the MPEG Noise Reduction

field, and then press C or c to select either Off, Low, Middle or High.

Noise Reduction ANT

CableClear

MPEG Noise Reduction

Reset

Done

Auto

Low

4 To save the new settings, highlight Done and press T.

To revert to the factory defaults, highlight Reset and press T.

Using the Game Mode feature

You can use the Game Mode feature for shorter frame delays when playing a video game requiring split-second timing between the on-screen display and input from the controller (such as music creation and high-action games).

This feature is more effective for 480i and 1080i input signals.

Note: To use the Game Mode feature, the current video input must be Video 1, Video 2, ColorStream HD1, ColorStream HD2, HDMI 1, HDMI 2, or HDMI 3. The Game Mode cannot be turned on when any other video input is selected.

To turn on Game Mode:

1 Press Y and open the Video menu. 2 Press B or b to highlight the Game Mode field, and then

press C or c to select On.

Video

Mode

Picture Settings

Noise Reduction

Game Mode

Theater Settings

Sports

Off

To turn off Game Mode:

Select Off in step 2 above, change the video input, or turn the TV off and then on again.

Note: You can change the video input by pressing + on the remote control (- page 38).

Chapter 7: Using the TV’s advanced features

Using the advanced audio settings features

Using the SRS WOW™ surround sound feature

SRS WOW™ is a special combination of SRS Labs audio technologies (SRS 3D, SRS Focus, and SRS TruBass) that creates a thrilling surround sound experience with deep, rich bass from stereo sound sources. Your TV’s audio will sound fuller, richer, and wider.

To adjust the WOW™ settings:

1 Put the TV in STEREO mode (- “Selecting stereo/SAP

broadcasts” on page 48).

2 Press Y and open the Audio menu. 3 Highlight Advanced Audio Settings and press T. 4 Press b or B to highlight the WOW feature you want to

adjust, and then press C or c to adjust the item.

Advanced Audio Settings

WOW: SRS 3D

WOW: SRS Focus

WOW: SRS TruBass Low

Reset

Off

Done

• WOW: SRS 3D — To turn the surround sound effect

On or Off.

Note: If the broadcast is monaural, the SRS 3D effect will not work.

WOW: SRS Focus — To turn the vocal emphasis effect

•

On or Off.

• WOW: SRS TruBass — To select the desired bass

expansion level (Off, Low, or High).

5 To save the new settings, highlight Done and press T.

To revert to the factory defaults, highlight Reset and press T.

WOW, SRS and l symbol are trademarks of SRS Labs, Inc. WOW technology is incorporated under license from SRS Labs, Inc.

Chapter 8: DVD Playback

Playing a disc

Be sure to set the MODE SELECT switch on the remote control to TV mode when using the Built-In DVD input.

VCD CD

Basic playback

Press p on the TV or on the remote control to turn on the TV. Press + on the remote control or INPUT on the TV to select the Built-In DVD mode.

2 The DVD startup screen will appear on the screen.

3 Load the disc in the disc slot with the label side facing

forward. (If the disc has a label.) Hold the disc without touching either of its surfaces, align it with the guides, and place it in position.

DVD

NO DISC

WelcomeWelcome

Resume feature

• Depending on the disc you are playing, when you press D

one time, the TV memorizes the location where playback is stopped. Press S to resume the playback from the stopped location.

• If you press D again or eject the disc, the TV will clear the

stopped location.

Auto Play feature

If you load a disc when the TV is off, the TV will power on and playback will commence automatically. However, loading the disc may take 1-2 seconds.

About the Parental Lock screen

If the Parental Lock YES/NO screen appears after loading a disc and you want to temporarily unlock the Parental Lock, select “YES” and then input the PIN CODE following the onscreen menu. (The Parental Lock YES/NO screen may be repeated two times depending on the disc.)

THE PARENTAL LEVEL OF THE

PLAYER HAS BEEN SET.

PRESS "YES" TO CONTINUE.

YES STOP

Note: When inserting a disc into the DVD disc slot, do not jam or force it strongly, otherwise the TV may malfunction or the disc might be damaged. If left with half the disc inserted, the disc will be loaded automatically.

4 “READING” appears on the screen, then playback starts.

READING

WelcomeWelcome

• A menu screen will appear on the TV screen, if the disc

has a title menu. Press B b C c to select title, then press T. Title is selected and play commences.

5 Press z Z to adjust the volume.

Volume 16

Note: When using an amplifier, adjust the volume with the amplifier.

6 Press D to end playback.

Note:

• Some unlocked discs may not resume playback after the input source has been changed.

• If you stop and restart playback, a message may appear on the screen. In this case, please eject the disc and reload it.

• If you are unable to proceed from the Parental Lock screen, please eject the disc and reload it.

CAUTION

Never insert your finger into the disc hole when loading a disc into the disc slot. Keep your fingers well clear of the disc slot when a disc is loading or unloading. Neglecting to do so may cause personal injury.

Because of problems and errors that can occur during the creation of DVD and CD software and/or the manufacture of DVD and CD discs, Toshiba cannot assure that the DVD player contained in this television will successfully play every disc bearing the DVD and CD logos. If you happen to experience any difficulty playing a DVD and/or CD disc on the DVD player contained in this television, please contact Toshiba Customer Service.

(continued)

Chapter 8: DVD Playback

Note: You cannot adjust the following items while a DVD is playing:

• Optical Output Format (- page 49)

• Audio Language (- page 48)

• DVD Audio (- page 65)

• Menu Language (- page 32)

• V-Chip (parental control) setting (- page 51)

• DVD Aspect Ratio (- page 63)

If you want to adjust any of the above, stop the DVD by pressing

Note: Strong static electricity may affect the DVD player’s operation and cause it to work improperly. If this happens, turn OFF the POWER, disconnect and then reconnect the AC power cord, and turn ON the TV again.

About

The icons on the heading bar show the playable

D twice, and then adjust (- “Resume feature”).

VCD CD

DVD

VCD CD

DVD

discs for the function described under that heading.

DVD

: You can use this function with DVD video discs.

VCD

: You can use this function with Video CDs.

: You can use this function with Audio CDs and CD-R/

RW discs.

To start playback from stop mode:

Press S.

Note:

• If a non-compatible disc is loaded, “DISK REGION INCORRECT” will appear on the TV screen. In this case, check your disc again (- page 7).

• Some discs may take a minute or so to start playback.

• If you insert a single-sided disc the wrong way, “READING”

will appear on the display for about 30-60 seconds and then “BAD DISC” will display until you remove the disc.

• Some discs may not resume playing the same scene after stopping.

• Some DVD playback operation may be intentionally fixed by the software producers. Since this TV plays DVDs according to the disc contents as designed by the software producers, some playback features may not be available. Also refer to the instructions supplied with the DVDs.

• Do not move the TV during playback. Doing so may damage the disc. If you want to move the TV to another place or room, be sure to eject the disc and turn off the power beforehand.

• If the disc does not load when it is first inserted into the DVD disc slot, remove the disc once and try to load the disc again.

• Do not put any objects other than discs in the disc slot. Doing so may cause the TV to malfunction.

• When you press a button, there may be a slight delay before the function activates.

To pause playback (still mode):

Press A during playback. To resume normal playback, press S.

Note: The sound is muted during still mode.

To stop playback:

Press D.

To remove the disc:

1 Press d on the remote control or OPEN/CLOSE on the

TV. The disc will come out halfway.

2 Press d again to remove the disc or press S to play

again.

Chapter 8: DVD Playback

Using the DVD aspect ratio feature

When you view a DVD from the Built-In DVD input, you can select the DVD aspect ratio, as described below.

• 4:3 Pan Scan: Black bars are visible on right and left sides

of the screen.

Picture where both sides of the original wide screen image are cropped.

• 4:3 Letter Box: The picture is stretched wider and taller to

fill the screen.

A B C D E F G - - - - - - - - - - - - - - - -

Letter box picture

• 16:9 Wide: The picture is stretched wider to fill the width

of the screen.

Playing in fast reverse or fast

VCD CD

forward

Press H or J during playback. H: Fast reverse playback (DVD/VCD: 2X-64X, CD/MP3:

2X-16X) J: Fast forward playback (DVD/VCD: 2X-64X, CD/MP3:

2X-16X) Each time you press H or J , the playback speed changes.

To resume normal playback:

Press S.

Note:

• The TV mutes sound and subtitles during reverse and forward scan of DVD video discs. However, the TV plays sound during fast forward or fast reverse play of audio CDs.

• The playback speed may differ depending on the disc.

DVD

VCD CD

Squeezed picture

To select the DVD aspect ratio:

1 Press Y and open the Video menu. 2 Highlight Theater Settings and press T. 3 In the DVD Aspect Ratio field, select the mode you

prefer (4:3 Pan Scan, 4:3 Letter Box, or 16:9 Wide).

Theater Settings

Picture Size Natural

Picture Scroll --

Cinema Mode Film

Auto Aspect Ratio On

DVD Aspect Ratio 16:9 Wide

DoneReset

4 To save the new settings, highlight Done and press T.

To revert to the factory defaults, highlight Reset and press T.

Note: You cannot change the DVD aspect ratio while you are viewing a DVD. (You must be in FULL-STOP mode, not RESUME-STOP mode.)

To pause playback (still playback)

VCD CD

DVD

Press A during playback.

To resume normal playback:

Press S.

Note: The sound is muted during still playback.

Chapter 8: DVD Playback

VCD

Playing frame by frame

Press A during still playback. Each time you press A, the picture advances one frame.

DVD

To resume normal playback:

Press S.

Note: The sound is muted during frame by frame playback.

VCD

Playing in slow motion

Press v or V during playback. Each time you press the button, the slow-motion speed

changes (DVD/VCD: 1/32-1/2).

DVD

To resume normal playback:

Press S.

Note:

• The sound is muted during slow-motion playback.

• V is not available for the VCD disc.

VCD CD

Locating a chapter or track

Press F or G repeatedly to select the chapter or track you want.

Playback starts from beginning of the selected chapter or track.

DVD

Changing angles

You can change the viewing angle of the scene during playback if the disc is recorded with multi-angle facility.

DVD

1 Press a during playback.

The current angle will appear.

2 Press a repeatedly until the desired angle is selected.

Note: Depending on the DVD, you may not be able to change the angles even if multi-angles are recorded on the DVD.

Title selection

Two or more titles are recorded on some discs. If the title menu is recorded on the disc, you can select the desired title.

DVD

1 Press N during playback.

Title menu appears on the screen.

2 Press B b C c to select the desired title. 3 Press T or S.

The playback of the selected title will start.

Note:

• Depending on the DVD, you may not be able to select the title.

• Depending on the DVD, a “title menu” may simply be called a “menu” or “title” in the instructions supplied with the disc.

• Depending on the DVD, the title menu may be displayed automatically when the disc is loaded.

• Depending on the DVD, a chapter menu may be displayed after you select a title.

Note: A “Prohibition” symbol may appear at the upper right of the screen. This symbol means either the feature you tried is not available on the disc, or the TV cannot access the feature at this time. This does not indicate a problem with the TV.

Chapter 8: DVD Playback

Changing soundtrack language

VCD

DVD

You can select the language when you play a multilingual disc.

1 Press c during playback.

The current soundtrack language will appear.

AUDIO 1 / 4 : ENG D 5 . 1

2 Press c repeatedly until the desired language is selected.

• The on-screen display will disappear after a few

seconds.

AUDIO 2 / 4 : FRE D 5 . 1

Note:

• If the desired language is not heard after pressing the button several times, the language is not recorded on the disc.

• Changing soundtrack language is cancelled when you eject the disc. The initial default language or available language will be heard if the disc is played back again.

• If you select DTS in playing DTS-encoded disc, no sound will be heard from the TV’s speakers.

Subtitles

DVD

When playing back a disc recorded with subtitles, you can select the subtitle language or turn the subtitle off.

1 Press b repeatedly during playback until your desired

language appears.

SUBTITLE 02 / 02 : FRE

In case of Video CD playback

1 Stop the disc playback. 2 Press Y and open the Audio menu. 3 Highlight Audio Setup and press T.

Audio

Digital Audio Selector

Audio Settings

Advanced Audio Settings

Audio Setup

4 Press B or b to highlight DVD Audio, and then press C

or c to select the desired audio mode (Stereo, L-Mono, R-Mono, or MIX-Mono).

Note: This item may not be selectable depending on the disc.

Audio Setup

PC Audio No

HDMI 1 Audio

MTS Stereo

Language

Optical Output Format

Dolby Digital Dynamic Range Control

DVD Audio

Reset

Auto

English

Dolby Digital/Surround

Compressed

Stereo

Done

2 To turn off the subtitle, press b until “SUBTITLE OFF”

appears.

• The “SUBTITLE OFF” on-screen display will

disappear after a few seconds.

SUBTITLE OFF

Note:

• Depending on the DVD, you may not be able to change subtitles, or to turn subtitles on or off.

• While playing a DVD, the subtitles may turn on or off when you load or eject the disc.

• In some cases, a selected subtitle language may not be changed immediately.

Disc status

DVD

VCD CD

Chapter 8: DVD Playback

MP3/JPEG CD operation

With each press of E, the status of the disc will appear on the screen and change as follows:

Display example

DVD MP3 Files

TITLE / CHAPTER FILE ELAPSED CHAPTER ELAPSED FILE REMAIN CHAPTER REMAIN OFF TITLE ELAPSED

TITLE REMAIN

OFF

VCD

TRACK **/** TRACK ELAPSED

TRACK REMAIN

OFF

TRACK **/** TRACK ELAPSED

TRACK REMAIN

DISC ELAPSED

DISC REMAIN

OFF

This TV can play MP3/JPEG-data which has been recorded on CD-R or CD-RW.

To produce MP3/JPEG-data, you need a Windows-PC with CD-R/RW drive and MP3/JPEG-encoding Software (not supplied).

Files recorded on an Apple

HFS (hierarchical file system)

volume cannot be played. Apple is a registered trademark of Apple Computer, Inc.

MP3/JPEG CD information

VCD

Limitations on MP3/JPEG CD playback

• MP3/JPEG CDs must meet ISO9660 standards. Files must

have one of the following extensions: .mp3, or .jpg.

• MP3/JPEG CDs cannot be used for the purpose of

recording.

• If the CD has both audio tracks and MP3/JPEG files, only

audio tracks are played.

• It may take more than 1 minute for this TV to read MP3/

JPEG files depending on its structure.

Note:

• Some MP3/JPEG CDs cannot be played back depending on the recording conditions.

• The CD-R/RWs that has no music data or non MP3/JPEG files cannot be played back.

Chapter 8: DVD Playback

MP3 CD playback

Load a disc on which MP3 files have been recorded in the

disc slot.

2 A file menu screen will appear on the screen. Press B or

b to select a folder and then press T to open the folder.

File Elapsed 00:00:00

CD-ROM

ROOT

100TOSHIBA

101TOSHIBA

3 Press BbC c to highlight the desired file. The selected

file is highlighted in blue.

Note: To return to the previous menu, press {.

File Elapsed 00:00:00

CD-ROM

ROOT/100TOSHIBA

001 TDCFILE....

002 TDCFILE 003 TDCFILE 004 TDCFILE 005 TDCFILE 006 TDCFILE 007 TDCFILE

ROOT

001 TDCFILE....

4 Press S (the file is highlighted in yellow).

Note:

• The DIGITAL AUDIO OUT terminal on the TV outputs MP3 sounds in the linear PCM format regardless of the current “Optical Output Format” selection.

• The DVD player contained in this television requires discs/ recordings to meet certain technical standards in order to achieve optimal playback quality. There are many different types of recordable disc formats (including CD-R containing MP3/WMA files). Not all recordable discs will operate or produce optimal playback quality. The technical criteria set forth in this owner's manual are meant only as a guide. Use of CD-RW for MP3 files is not recommended.

• You must obtain any required permission from copyright owners to download or use copyrighted content. Toshiba cannot and does not grant such permission.

About the menu icons

• : Indicates MP3 file

• : Indicates JPEG file

Note:

• The slide show will start automatically when the FUJICOLOR CD or the Kodak Picture CD is played. Pressing D displays thumbnail view. However, depending on the recording conditions, those discs may not operate properly.

• MP3 files on the Kodak Picture CD are not recognized on this TV.

• When displaying the MP3/JPEG files, use the Natural or Full picture size (- page 42).

File Elapsed 00:01:38

CD-ROM

ROOT/100TOSHIBA

001 TDCFILE....

002 TDCFILE 003 TDCFILE 004 TDCFILE 005 TDCFILE 006 TDCFILE 007 TDCFILE

ROOT

001 TDCFILE....

The selected file starts playing back. To advance to the next MP3 file, press G. To return to the previous MP3 file, press F. To restart the playing MP3 file, press T. For fast reverse playback, press H. For fast forward playback, press J.

5 Press D to end playback (the file is highlighted in

yellow).

• The TV records the stopped point where playback

ended. Press S to resume playback (from the same point).

• If you press D again (the file is highlighted in blue) or

unload the disc, the TV will clear the stopped point.

Chapter 8: DVD Playback

JPEG CD playback

You can select your desired JPEG file from the file menu. The slide show enables you to view pictures (files) one after another automatically.

1 Load a disc on which JPEG files have been recorded in the

disc slot.

2 A file menu screen will appear. Press B or b to select a

folder and then press T to open the folder.

File Elapsed 00:00:00

CD-ROM

ROOT

100TOSHIBA

101TOSHIBA

3 Press BbC c to select the desired file.

File Elapsed 00:00:00

CD-ROM

ROOT/101TOSHIBA

001 TDCFILE....

002 TDCFILE 003 TDCFILE 004 TDCFILE 005 TDCFILE 006 TDCFILE 007 TDCFILE

4 Press S to start the slide show from the selected file.

If you playback the selected file only, press T. While the picture is on-screen, you can rotate the picture by 90° using BbC c buttons.

5 Press D to end playback. The file menu will appear on

the screen. If you want to view another file, repeat steps 3–4.

• If you press A during the slide show, the slide

show stops temporarily. “PAUSE” appears on the screen. Press S again to resume the slide show.

• To display the next file, press G.

• To display the previous file, press F.

• When slide show playback has finished, the file list

appears.

• To stop the slide show, press D. The file list will

appear.

Chapter 9: Troubleshooting

General troubleshooting

Before calling a service technician, please check this chapter for a possible cause of the problem and some solutions you can try.

Black box on-screen

• The closed caption feature is set to one of the Text modes

(T1, T2, T3, or T4). Set the closed caption feature to Off (- page 46).

TV stops responding to controls

• If the TV stops responding to the controls on the remote

control or TV control panel and you cannot turn off the TV, press and hold the POWER button on the TV control panel for 5 or more seconds to reset the TV.

Other problems

• If your TV’s problem is not addressed in this

Troubleshooting section or the recommended solution has not worked, use the Restore Factory Defaults procedure (- page 37).

TV will not turn on

• Make sure the power cord is plugged in, and then press

• The remote control batteries may be dead. Replace the

batteries or try the control panel buttons.

Picture problems

General picture problems

• Check the antenna/cable connections (- Chapter 2).

• Press + on the remote control or TV and select a valid

video input source (- page 38). If no device is connected to a particular input on the TV, no picture will display when you select that particular input source. For device connection details, see Chapter 2.

• Antenna reception may be poor. Use a highly directional

outdoor antenna (if applicable).

• The station may have broadcast difficulties. Try another

channel.

• Adjust the picture qualities (- page 45).

• If you are using a VCR, make sure l on the remote

control is set correctly (- page 25).

• Do not connect both a standard video cable and an

S-video cable to the VIDEO 1 input at the same time (- page 17).

Noisy picture

• If you are watching an analog channel (off-air broadcast

or Cable TV), you can set the CableClear feature to AUTO to reduce visible interference in the TV picture (- page 58).

Video Input Selection problems

• If the Input Selection window does not appear when

you press + on the remote control or TV, press + a second time, which will change to the next video input source and display the Input Selection window.

/DNR

Cannot view external signals or channel 3 or 4

• If you cannot view signals from external devices

connected to VIDEO 1, VIDEO 2, ColorStream HDMI 1, HDMI 2, PC or from channels 3 or 4, make sure the Input Lock is set to Off (- page 53).

Poor color or no color

• The station may have broadcast difficulties. Try another

channel.

• Adjust the Tint and/or Color (- page 45).

Poor composite or S-video picture

• If the TV is connected to an external A/V device (e.g.,

DVD player, video game system, set-top box, etc.) try using a ColorStream or HDMI video connection instead.

Picture and sound are out of sync

• As with all products that contain a digital display, in rare

instances, when viewing certain content (e.g.. television broadcasts, video games, DVDs), you may notice that the sound and picture are slightly out of sync. This phenomenon can be caused by various factors including, without limitation, video processing within the TV, video processing in an attached gaming system, and video processing or different compression rates used by broadcasters in their programming. You may want to try one or more of the following suggestions, which may help to reduce the effect of this phenomenon: – If the TV is connected to an A/V receiver that has a

programmable audio delay feature, use this feature to help synchronize the sound to the picture.

– If you notice this phenomenon only on certain TV

channels, please contact your local broadcast, cable, or satellite provider to inform them of this issue.

LED indications while in reboot from standby

• When you plug the power cord in, the yellow LED will

blink until the TV enters standby mode, (plugged in but not powered on). This is normal and is not a sign of malfunction.

Sound problems

• Check the antenna/cable connections (- Chapter 2).

• The station may have broadcast difficulties. Try another

channel.

• The sound may be muted. Press VOLUME.

• If you hear no sound, try setting the MTS feature to

Stereo mode (- page 48).

• If you are not receiving a second audio program from a

known SAP source, make sure the MTS feature is set to SAP mode (- page 48).

• If you hear audio that seems “incorrect” for the program

you are watching (such as music or a foreign language), the SAP mode may be on. Set the MTS feature to Stereo mode (- page 48).

Remote control problems

• Make sure the remote control is set to the correct device

mode (- page 24).

• Remove all obstructions between the remote control and

the TV.

• The remote control batteries may be dead. Replace the

batteries (- page 23).

(continued)

• Your TV remote control may not operate certain features

on your external device. Refer to the owner’s manual for your other device to determine its available features. If your TV remote control does not operate a specific feature on another device, use the remote control that came with the device (- pages 25–29).

• If the TV still does not act as expected, use the Reset

Factory Defaults procedure (- page 37).

Channel tuning problems

• Make sure the remote control is set to the correct device

mode (- page 24).

• The channel may have been erased from the channel

memory by the Channel Add/Delete feature. Add the channel to the channel memory (- page 33).

• The channel may be blocked by the Channels Block

feature. Unblock the channel (- page 52).

• If you are unable to tune digital channels, check the

antenna configuration (- page 32). If you are still unable to tune digital channels, clear all channels from the channel list (- page 34) and reprogram channels into the channel memory (- page 33). If you are still unable to tune digital channels, use the Reset Factory Defaults procedure (- page 37). Also see “TV stops responding to controls” and “Other problems” (- page 69).

Closed caption problems

• If the program or video you selected is not closed-

captioned, no captions will display (- page 46).

• If text is not available, a black rectangle may appear.

If this happens, turn off the closed caption feature (-

page 46).

• A closed-caption signal may not display correctly in the

following situations: a) when a videotape has been dubbed; b) when the signal reception is weak; or c) when the signal reception is nonstandard (- page 46).

Rating blocking (V-Chip) problems

• If you forget your PIN code: While the PIN code entering

screen is displayed, press E four times within 5 seconds. The PIN code you previously stored will be cleared (- page 50).

• The V-Chip feature is available for the U.S. V-Chip

system only (- page 51).

Chapter 9: Troubleshooting

DVD Troubleshooting

Playback doesn’t start

• The disc is reversed. Load the disc with the playback side

facing backward.

• No disc is loaded. Load the playable disc.

• The disc may be dirty. Clean the disc.

• The TV cannot play CD-ROMs, etc. Load a playable

disc.

No picture

• TV selector is not set correctly.

No sound

• The analog audio output terminals on the TV do not

output the sounds from the disc. Connect your digital audio system to the DIGITAL AUDIO OUT terminal on the TV.

• Make sure the input selector of the amplifier is set

properly.

• The TV is in the special playback mode.

Picture is distorted during fast reverse/forward playback

• The picture will be distorted occasionally.

Stopping playback, search, slow-motion play, or changing angles, etc. cannot be performed

• Some discs may not perform certain functions.

No surround sound

• The setup may not match your stereo system.

The TV or remote operation key is not functioning

• Turn off the TV and unplug the AC power cord for

several minutes, then replug it.

Audio soundtrack and/or subtitle language is not changed when you play back a DVD

• Multilingual language is not recorded on the DVD disc.

No subtitle

• Some discs have no subtitles.

• Subtitles are cleared. Press b.

Angle cannot be changed

• Multi-angles are not recorded on the DVD discs.

appears on the screen

• The function is prohibited with the TV or the disc.

Chapter 9: Troubleshooting

LED indications

The green and yellow LED lights on the TV front indicate the TV’s status, as described below.

Note: If the TV loses A/C power (e.g., a power outage occurs or the power cord is unplugged), when power is restored, the yellow LED will blink while the TV is booting until the remote control is usable. This is normal and is not a sign of malfunction.

TV front

DISC POWER

Yellow LED Green LED

LED Indication Condition Solution

1) Green is ON (solid). The TV is operating properly. –

2) Yellow is ON (solid). A disc is in the disc slot. –

3) Yellow blinks three times.

4) Green blinks slowly. Abnormal operation of BUS line. Turn OFF the TV and unplug the power cord.

5) Green blinks quickly.

TV is powering up. Wait several seconds until the yellow LED stops

Power protect detection.

blinking.

Plug the power cord in again and turn ON the TV.

If, after trying the solutions, the problem still exists:

• In the U.S., call TACP Consumer Solutions at 1-800-575-5469.

• In Canada, locate the nearest Toshiba authorized service depot by directing your web browser to www.toshiba.ca; click

“Home Entertainment,” and then click “Support.”

Chapter 10: Appendix

Specifications

Note:

• This model complies with the specifications listed below.

• Designs and specifications are subject to change without notice.

• This model may not be compatible with features and/or specifications that may be added in the future.

Television System

NTSC standard ATSC standard (8VSB) Digital Cable (64 QAM, 256 QAM; in-the-clear,

unencrypted)

Channel Coverage

VHF: 2 through 13 UHF: 14 through 69 Cable TV: Mid band (A-8 through A-1, A through I)

Super band (J through W) Hyper band (AA through ZZ, AAA, BBB) Ultra band (65 through 94, 100 through 135)

Power Source: 120 V AC, 60 Hz

Power Consumption

xxx W (average) xxx W in standby mode

Audio Power: 10 W + 10 W

Speaker Type: Two 2-3/8 × 4-3/4 inches (6 × 12 cm)

Video/Audio Terminals

S-VIDEO INPUT:

Y: 1 V(p-p), 75 ohm, negative sync. C: 0.286 V(p-p) (burst signal), 75 ohm

VIDEO/AUDIO INPUT:

VIDEO: 1 V(p-p), 75 ohm, negative sync. AUDIO: 150 mV(rms) (30% modulation equivalent, 22 k

ohm or greater)

ColorStream

VIDEO:Y: 1V(p-p), 75 ohm

AUDIO: 150 mV(rms), 22 k ohm or greater

(component video) HD INPUT:

R: 0.7 V(p-p), 75 ohm

B: 0.7 V(p-p), 75 ohm

P Suggested formats: 1080i, 720p, 480p, 480i

HDMI™ INPUT:

HDMI compliant (type A connector) HDCP compliant Audio Lip Sync supported Suggested formats: See table below. HDMI Audio: 2-channel L-PCM; 32/44.1/48 kHz

sampling frequency; 16/20/24 bits per sample

FIXED AUDIO OUTPUT:

150 mv (rms) (30% modulation equivalent, 2.2 k ohm

or less)

DIGITAL AUDIO OUTPUT:

Optical type

PC INPUT:

15-Pin D-sub Analog RGB

DVD/CD Player

DVD signal system NTSC DVD region number 1 Applicable disc 1. DVD (12cm, 8cm [with Disc adapter])

2. CD (12cm, 8cm [with Disc adapter])

Pickup 1-Lens, 2-Beams system

Dimensions

Width: 26-1/4 inches (666 mm) Height: 20-1/4 inches (515 mm) Depth: 9-1/2 inches (241 mm)

Mass (weight)

xxx lbs (xxx kg)

Operating conditions

Temperature: 32ºF - 95ºF (0ºC - 35ºC) Humidity: 20 - 80% (no moisture condensation)

Supplied Accessories

• Remote control with two size “AAA” batteries

• Owner’s manual (this book)

• Lead clip Use this clip to attach the TV to a wall, pillar, or other immovable structure. See item 20 on page 3.

HDMI input supports the following signal formats:

Format Resolution V. Frequency H. Frequency Pixel Clock Frequency

VGA 640 × 480p 59.940/60Hz 31.469/31.500kHz 25.175/25.200MHz

480i 720 × 480i 59.940/60Hz 15.734/15.750kHz 27.000/27.027MHz

480p 720 × 480p 59.940/60Hz 31.469/31.500kHz 27.000/27.027MHz

720p 1280 × 720p 59.940/60Hz 44.955/45.000kHz 74.176/74.250MHz

1080i 1920 × 1080i 59.940/60Hz 33.716/33.750kHz 74.176/74.250MHz

1080p 1920 × 1080p 23.976/24Hz 26.973/27.000kHz 74.176/74.250MHz

1080p 1920 × 1080p 59.940/60Hz 67.433/67.500kHz 148.352/148.500MHz

Chapter 10: Appendix

Limited United States Warranty

for LCD TV/DVD Combinations 26” and Larger

Toshiba America Consumer Products, L.L.C. (“TACP”) makes the following limited warranties to original consumers in the United States.

THESE LIMITED WARRANTIES EXTEND TO THE ORIGINAL CONSUMER PURCHASER OR ANY PERSON RECEIVING THIS LCD TV/DVD COMBINATION AS A GIFT FROM THE ORIGINAL CONSUMER PURCHASER AND TO NO OTHER PURCHASER OR TRANSFEREE. LCD TV/DVD COMBINATIONS PURCHASED IN THE U.S.A. AND USED ANYWHERE OUTSIDE OF THE U.S.A., INCLUDING, WITHOUT LIMITATION, CANADA AND MEXICO, ARE NOT COVERED BY THESE WARRANTIES. LCD TV/DVD COMBINATIONS PURCHASED ANYWHERE OUTSIDE OF THE U.S.A., INCLUDING, WITHOUT LIMITATION, CANADA AND MEXICO, AND USED IN THE U.S.A., ARE NOT COVERED BY THESE WARRANTIES.

Limited One (1) Year Warranty on Parts and Labor

TACP warrants this LCD TV/DVD Combination and its parts against defects in materials or workmanship for a period of one (1) year after the date of original retail purchase.

TACP’S OPTION, REPAIR OR REPLACE A DEFECTIVE PART WITH A NEW OR REFURBISHED PART WITHOUT CHARGE TO YOU FOR PARTS OR LABOR. During this period,

personnel will come to your home when warranty service is required. Depending on the type of repair required, the service will either be performed in your home or the LCD TV/DVD Combination will be taken to a TACP Authorized Service Station for repair and returned to your home at no cost to you.

Rental Units

The warranty for LCD TV/DVD Combination rental units begins on the date of the first rental or thirty (30) days after the date of shipment to the rental firm, whichever comes first.

Limited Warranty for Commercial Units

TACP warrants LCD TV/DVD Combinations that are sold and used for commercial purposes as follows: all parts are warranted against defects in materials or workmanship for a period of ninety (90) days after the date of original retail purchase.

TACP’S OPTION, REPAIR OR REPLACE A DEFECTIVE PART WITH A NEW OR REFURBISHED PART WITHOUT CHARGE TO YOU.

Owner’s Manual and Product Registration Card

Read this owner’s manual thoroughly before operating this LCD TV/DVD Combination.

Complete and mail the enclosed product registration card or register your LCD TV/DVD Combination online at as soon as possible. By registering your LCD TV/DVD Combination you will enable TACP to bring you new products specifically designed to meet your needs and help us to contact you in the unlikely event a safety notification is required under the U.S. Consumer Product Safety Act.

Failure to complete and return the product registration card does not diminish your warranty rights.

Your Responsibility

THE ABOVE WARRANTIES ARE SUBJECT TO THE FOLLOWING CONDITIONS:

(1) You must retain your original bill of sale or provide other proof of

purchase.

(2) All warranty servicing of this LCD TV/DVD Combination must be

performed by an Authorized TACP Service Station.

(3) The warranties from TACP are effective only if this LCD TV/DVD

Combination is purchased and operated in the Continental U.S.A. or Puerto Rico.

(4) Labor service charges for set installation, setup, adjustment of

customer controls, and installation or repair of antenna systems are

DURING THIS PERIOD, TACP WILL, AT

TACP Authorized Service Station

DURING THIS PERIOD, TACP WILL, AT

www.tacp.toshiba.com/service

not covered by this warranty. Reception problems caused by inadequate antenna systems, misaligned satellite dishes, cable television distribution, VCRs, DVD players/recorders, personal computer level IEEE-1394 devices, and any other connected signal source device are your responsibility.

(5) Warranties extend only to defects in materials or workmanship as

limited above, and do not extend to any LCD TV/DVD Combination or parts that have been lost or discarded by you or to damage to the LCD TV/DVD Combination or parts caused by fires, misuse, accident, Acts of God (such as lightning or fluctuations in electric power), improper installation, improper maintenance, or use in violation of instructions furnished by TACP; use or malfunction through simultaneous use of this LCD TV/DVD Combination and connected equipment; or to units that have been modified or had the serial number removed, altered, defaced, or rendered illegible.

How to Obtain Warranty Service

If, after following all of the operating instructions in this manual and reviewing the section entitled “Troubleshooting,” you find that service is needed:

(1) To find the nearest TACP Authorized Service Station, visit TACP’s

website at Consumer Solution Center toll free at 1-800-575-5469.

(2) You must present your original bill of sale or other proof of purchase

to the TACP Authorized Service Station.

ALL WARRANTIES IMPLIED BY THE LAW OF ANY STATE OF THE U.S.A., INCLUDING THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE EXPRESSLY LIMITED TO THE DURATION OF THE LIMITED WARRANTIES SET FORTH ABOVE. WITH THE EXCEPTION OF ANY WARRANTIES IMPLIED BY THE LAW OF ANY STATE OF THE U.S.A. AS HEREBY LIMITED, THE FOREGOING WARRANTY IS EXCLUSIVE AND IN LIEU OF ALL OTHER WARRANTIES, GUARANTEES, AGREEMENTS, AND SIMILAR OBLIGATIONS OF TACP WITH RESPECT TO THE REPAIR OR REPLACEMENT OF ANY PARTS. IN NO EVENT SHALL TACP BE LIABLE FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, LOST PROFITS, BUSINESS INTERRUPTION, OR MODIFICATION OR ERASURE OF RECORDED DATA CAUSED BY USE, MISUSE OR INABILITY TO USE THIS LCD TV/DVD COMBINATION).

No person, agent, distributor, dealer, or company is authorized to change, modify, or extend the terms of these warranties in any manner whatsoever. The time within which an action must be commenced to enforce any obligation of TACP arising under the warranty or under any statute or law of the United States or any state thereof is hereby limited to ninety (90) days from the date you discover, or should have discovered, the defect. This limitation does not apply to implied warranties arising under the law of any state of the U.S.A.

THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS AND YOU MAY ALSO HAVE OTHER RIGHTS WHICH MAY VARY FROM STATE TO STATE IN THE U.S.A. SOME STATES OF THE U.S.A. DO NOT ALLOW LIMITATIONS ON THE DURATION OF AN IMPLIED WARRANTY, WHEN AN ACTION MAY BE BROUGHT, OR THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES. THEREFORE, THE ABOVE PROVISIONS MAY NOT APPLY TO YOU UNDER SUCH CIRCUMSTANCES.

www.tacp.toshiba.com/service

For additional information, visit TACP’s website:

www.tacp.toshiba.com

or contact TACP’s

Chapter 10: Appendix

Limited Canadian Warranty

for Toshiba Brand Flat Panel Televisions

Toshiba of Canada Limited (“ to original consumers in Canada.

EXTEND TO THE ORIGINAL CONSUMER PURCHASER OR ANY PERSON RECEIVING THIS TOSHIBA BRAND FLAT PANEL TELEVISION (the “TELEVISION(S)” or “Television(s)”) AS A GIFT FROM THE ORIGINAL CONSUMER PURCHASER AND TO NO OTHER PURCHASER OR TRANSFEREE.

TELEVISIONS PURCHASED IN CANADA, AND USED ANYWHERE OUTSIDE OF CANADA INCLUDING, WITHOUT LIMITATION, THE UNITED STATES AND MEXICO, ARE NOT COVERED BY THESE WARRANTIES.

TELEVISIONS PURCHASED ANYWHERE OUTSIDE OF CANADA, INCLUDING, WITHOUT LIMITATION, THE UNITED STATES AND MEXICO, AND USED IN CANADA, ARE NOT COVERED BY THESE WARRANTIES.

Limited One (1) Year Warranty on Parts and Labour

Subject to the more limited warranty if the Television is used for any commercial or business purposes as set out below, TCL warrants the Television and its parts against material defects in materials or workmanship that result in the Television failing for a period of one (1) year after the date of original retail purchase.

WILL, AT TCL’S OPTION, REPAIR OR REPLACE A DEFECTIVE PART WITH A NEW OR REFURBISHED PART WITHOUT CHARGE TO YOU FOR PARTS OR LABOUR.

(a) FOR TELEVISIONS 32 INCHES OR LESS:

ENTIRE TELEVISION TO A TCL TELEVISION AUTHORIZED SERVICE PROVIDER (“ASP”). YOU MUST PAY FOR ALL TRANSPORTATION AND INSURANCE CHARGES FOR THE TELEVISION TO AND FROM THE ASP.

(b) FOR TELEVISIONS OVER 32 INCHES: During this period, ASP

personnel will come to your home when warranty service is required. Depending on the type of repair required, the service will either be performed in your home or the Television will be taken to an ASP for repair and returned to your home at no cost to you.

SERVICE ONLY APPLIES WITHIN 100 KILOMETERS OF AN ASP. IF YOU ARE NOT WITHIN 100 KILOMETERS OF AN ASP, YOU MUST DELIVER THE ENTIRE TELEVISION TO AN ASP. YOU MUST PAY FOR ALL TRANSPORTATION AND INSURANCE CHARGES FOR THE TELEVISION TO AND FROM THE ASP.

Limited Warranty for Commercial Units

TCL warrants Televisions that are used for any commercial or business purposes as follows: all parts are warranted against material defects in materials or workmanship that result in the Television failing for a period of ninety (90) days after the date of original retail purchase.

PERIOD, TCL WILL, AT TCL’S OPTION, REPAIR OR REPLACE THE DEFECTIVE PART WITH A NEW OR REFURBISHED PART WITHOUT CHARGE TO YOU.

ENTIRE TELEVISION TO AN ASP. YOU MUST PAY FOR ALL TRANSPORTATION AND INSURANCE CHARGES FOR THE TELEVISION TO AND FROM THE ASP.

TCL

”) makes the following limited warranties

THESE LIMITED WARRANTIES

DURING THIS PERIOD, TCL

YOU MUST DELIVER THE

IN-HOME

DURING THIS

YOU MUST DELIVER THE

(d) FOR TELEVISIONS OVER 32 INCHES: During this period, ASP

personnel will come on-site when warranty service is required. Depending on the type of repair required, the service will either be performed on-site or the Television will be taken to an ASP for repair and returned at no cost to you.

WITHIN 100 KILOMETERS OF AN ASP. IF YOU ARE NOT WITHIN 100 KILOMETERS OF AN ASP, YOU MUST DELIVER THE ENTIRE TELEVISION TO AN ASP. YOU MUST PAY FOR ALL TRANSPORTATION AND INSURANCE CHARGES FOR THE TELEVISION TO AND FROM THE ASP.

Rental Units

The warranty for Television rental units begins with the date of first rental or thirty (30) days from the date of shipment to the rental firm, whichever comes first.

Your Responsibility

THE ABOVE WARRANTIES ARE SUBJECT TO THE FOLLOWING CONDITIONS:

(1) You must provide your bill of sale or other proof of purchase. (2) All warranty servicing of this Television must be performed by an ASP. (3) The warranties from TCL are effective only if the Television is (i)

purchased as new and unopened from TCL or from TCL’s authorized distributors, dealers or resellers (“ Canada.

(4) Labour charges for set installation, setup, adjustment of customer

controls, and installation or repair of antenna systems are not covered by these warranties. Reception problems caused by inadequate antenna systems are your responsibility.

(5) Warranties extend only to material defects in materials or

workmanship as limited above, and do not extend to: a. Service, repairs or replacement made necessary by accident,

misuse, abuse, moisture, liquids, dust, dirt, neglect, accident, damage, 24/7 applications, improper installation, improper operation, improper cleaning, improper maintenance, normal wear and tear, screen burn or image retention caused by prolonged display of static images and/or phosphor aging, or any other external cause or event, act or omission outside the control of TCL, including fire, theft, acts of God, alteration, power failures, power surges or power shortages, lightning, other electrical faults, or repairs, modifications or replacements by persons other than those authorized by TCL to service the Television;

b. Replacement of missing, discarded or lost parts, the provision of

retrofits, or preventive maintenance;

c. Repair of damage that is cosmetic only or does not affect the

Television functionality, such as wear and tear, scratches and dents;

d. Service on Toshiba-branded accessory items (such accessory

items may be covered by their own warranty);

e. Service on third party products or service made necessary by

use of incompatible third party products;

f. Service made necessary by the simultaneous use of this

Television and connected equipment;

g. Modifications to the Television not approved in writing by TCL,

and service made necessary by the use or installation of nonToshiba modifications to the Television;

h. Service of a Television on which the TOSHIBA label or logo, rating

label or serial number have been defaced or removed;

i. On-site service and repair of the Television; and j. Damage to the Television caused by failure to follow the

specifications, User manuals or guides as to usage and/or storage.

ON-SITE SERVICE ONLY APPLIES

ADR’s

”) and (ii) located/operated in

Chapter 10: Appendix

Disclaimer and Limitation of Remedy

TO THE EXTENT NOT PRECLUDED BY LAW, ALL OTHER EXPRESS AND IMPLIED WARRANTIES, CONDITIONS AND REPRESENTATIONS FOR THIS TELEVISION, INCLUDING THE IMPLIED WARRANTIES, CONDITIONS AND REPRESENTATIONS OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE HEREBY DISCLAIMED AND EXCLUDED. IF THE APPLICABLE LAW, STATUTORY OR OTHERWISE, PRECLUDES THE EXCLUSION OF ANY IMPLIED WARRANTIES, CONDITIONS AND REPRESENTATIONS THEN SUCH IMPLIED WARRANTIES, CONDITIONS AND REPRESENTATIONS ARE OTHERWISE LIMITED IN DURATION TO THE TERM OF THIS EXPRESS WRITTEN LIMITED WARRANTY. TO THE EXTENT NOT PRECLUDED BY LAW, STATUTORY OR OTHERWISE, THIS WRITTEN WARRANTY SUPERCEDES AND SPECIFICALLY DISCLAIMS ANY OTHER WARRANTY, CONDITION OR REPRESENTATION NOT STATED IN THIS WARRANTY, WHETHER MADE BY TCL, TOSHIBA CORPORATION, THEIR AFFILIATES, ADRs AND ASPs AND WHETHER MADE ORALLY OR IN WRITING (INCLUDING ANY STATEMENT IN ANY BROCHURE, PRESS RELEASE, ANNOUNCEMENT, ADVERTISEMENT, POINT OF SALE DISPLAY, ETC.).

YOU MUST READ AND FOLLOW ALL SET-UP AND USAGE INSTRUCTIONS IN THE APPLICABLE USER GUIDES AND/OR MANUALS. IF YOU FAIL TO DO SO, THIS TELEVISION MAY NOT FUNCTION PROPERLY AND YOU MAY SUFFER DAMAGE. THIS WARRANTY WILL NOT COVER ANY SERVICE THAT IS REQUIRED, IN PART OR IN WHOLE, AS A RESULT OF ANY FAILURE TO FOLLOW THE SET-UP AND USAGE INSTRUCTIONS. THIS WARRANTY DOES NOT APPLY AND SHALL BE VOID AND UNENFORCEABLE IF THE TELEVISION IS OPENED, SERVICED, OR REPAIRED BY PERSONS OTHER THAN THOSE AUTHORIZED BY TCL TO SERVICE OR REPAIR THE TELEVISION.

IF THE TELEVISION FAILS TO WORK AS WARRANTED ABOVE, YOUR SOLE AND EXCLUSIVE REMEDY SHALL BE REPAIR OR REPLACEMENT OF THE DEFECTIVE PART. IN NO EVENT WILL TCL, TOSHIBA CORPORATION, THEIR AFFILIATES, ADRs OR ASPs (THE “

PARTIES

DAMAGES, MONEY, REIMBURSEMENT, COSTS OR EXPENSES. THIS LIMITATION APPLIES TO DAMAGES, MONEY, REIMBURSEMENT, COSTS OR EXPENSES OF ANY KIND WHATSOEVER INCLUDING ANY DIRECT OR INDIRECT DAMAGES, DAMAGE TO PROPERTY OR PERSON, LOST PROFITS, LOST SAVINGS, INCONVENIENCE OR OTHER SPECIAL, INCIDENTAL, EXEMPLARY OR CONSEQUENTIAL DAMAGES, WHETHER FOR BREACH OF WARRANTY, BREACH OF CONTRACT, TORT (INCLUDING NEGLIGENCE), UNDER A STATUTE OR UNDER ANY OTHER LAW OR FORM OR ACTION, OR WHETHER ARISING OUT OF THE USE OF OR INABILITY TO USE THE TELEVISION, EVEN IF ANY OF THE RELATED PARTIES HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR OF ANY CLAIM BY ANY OTHER PARTY.

No person, agent, distributor, dealer or company is authorized to change, modify or extend the terms of these warranties in any manner whatsoever.

Arbitration and Dispute Resolution

To the extent not precluded by law, any claim, dispute, controversy or disagreement (whether for breach of warranty, breach of contract, tort (including negligence), under a statute or under any other law or form of action) against any of the Related Parties arising out of, or otherwise relating to: (i) this warranty; (ii) the Television; (iii) any oral or written representations, statements, brochures, press releases, advertising, announcement, point of sale display, or promotional material relating to the Television; (iv) the relationships that result from this warranty, (the foregoing claims, disputes controversies and disagreements are collectively referred to as the “Dispute”), shall be referred to and resolved by final and binding arbitration (to the exclusion of the courts). To the extent not precluded by law, you agree to waive any right that you may have to commence or participate in any representative or class proceeding against the Related Parties relating to any Dispute. If and where applicable and to the extent not precluded by law, you further

”) BE LIABLE TO YOU OR ANY THIRD PARTY FOR ANY

agree to opt out of any such representative or class proceedings. Arbitration of any Dispute will be conducted in the forum and in the manner as agreed to between you and TCL. Failing such agreement, the arbitration will be conducted by one arbitrator pursuant to the laws and rules relating to arbitration generally in force in the jurisdiction in which you reside at the time that the Dispute arises. To the extent not precluded by law, no claim, dispute, controversy or disagreement of any other person may be joined or combined with any Dispute by you, without the prior written consent of TCL.

Critical Applications

The Television you have purchased is not designed for any “critical applications.” “Critical applications” means life support systems, medical applications, connections to implanted medical devices, commercial transportation, nuclear facilities or systems or any other applications where Television failure could lead to injury to persons or loss of life or catastrophic property damage.

IF THE CUSTOMER USES THE TELEVISION IN ANY CRITICAL APPLICATION, THE CUSTOMER - AND NOT TCL, ITS AFFILIATES, ADRs OR ASPs - ASSUME SOLE AND FULL RESPONSIBILITY FOR SUCH USE. TCL RESERVES THE RIGHT TO REFUSE TO SERVICE ANY TELEVISION USED IN A CRITICAL APPLICATION. TCL, ITS AFFILIATES, ADRs AND ASPs HEREBY DISCLAIM ANY AND ALL LIABILITY, DAMAGES AND CONSEQUENCES ARISING OUT OF THE SERVICE OR REFUSAL TO SERVICE SUCH TELEVISION AND FURTHER DISCLAIM ANY AND ALL LIABILITY, CONSEQUENCES AND DAMAGES THAT MAY ARISE OR RESULT FROM THE USE OF THE TELEVISION IN ANY CRITICAL APPLICATIONS.

General Provisions

If and to the extent that any provision of this limited warranty should generally be found to be unenforceable, the unenforceable provision shall be severed from the warranty and deemed not to form part of the warranty. The remaining provisions of this warranty shall be and remain valid and enforceable. If and to the extent that any provision of this limited warranty as it relates to any of the Related Parties is found to be invalid or unenforceable in respect of that party (the “ Excluded Party shall be deemed to be severed or excluded from the provision, and the provision shall remain valid, enforceable and applicable in respect of the other or remaining Related Parties.

To the extent permitted by law, this limited warranty shall be governed and construed in accordance with the laws of Ontario.

If there is any inconsistency between this limited warranty, on the one hand, and any statement in the packaging of the Television or in any other document enclosed with, or used in the context of the promotion or sale of, the Television, on the other hand, the provisions of this limited warranty shall prevail.

How to Obtain Warranty Services

If, after following all of the operating instructions in this manual and checking the “Troubleshooting” section, you find that service is needed:

(1) To find the nearest ASP, visit TCL’s web site at

call toll free 1-800-268-3404

(2) Present your bill of sale or other proof of purchase to the ASP.

For additional information, visit TCL’s website at

Excluded Party

www.toshiba.ca

”), the

, or

Chapter 10: Appendix

A copy of the GPL source code in this product may be obtained by contacting Toshiba Consumer Solutions at (800)631-3811. There will be a charge to cover the costs of providing the source code.

A copy of the LGPL source code in this product may be obtained by contacting Toshiba Consumer Solutions at (800)631-3811. There will be a charge to cover the costs of providing the source code.

Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met:

(1) Redistributions of source code must retain the above copyright

notice, this list of conditions and the following disclaimer.

(2) Redistributions in binary form must reproduce the above copyright

notice, this list of conditions and the following disclaimer in the documentation and/or other materials provided with the distribution.

(3) Neither the name of The NetBSD Foundation nor the names of its

contributors may be used to endorse or promote products derived from this software without specified prior written permission.

THIS SOFTWARE IS PROVIDED BY THE NETBSD FOUNDATION, INC. AND CONTRIBUTORS “AS IS” AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE FOUNDATION OR CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.

This product includes software developed by the OpenSSL Project for use in the OpenSSL Toolkit (http://www.openssl.org).

This product includes cryptographic software written by Eric Young (eay@cryptsoft.com).

OpenSSL 0.9.7d Copyright © 1998-2000 the OpenSSL Project. All Rights reserved. Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met:

(1) Redistributions of source code must retain the above copyright

notice, this list of conditions and the following disclaimer.

(2) Redistributions in binary form must reproduce the above copyright

notice, this list of conditions and the following disclaimer in the documentation and/or other materials provided with the distribution.

(3) All advertising materials mentioning features or use of this software

must display the following acknowledgement: This product includes software developed by the OpenSSL Project for use in the OpenSSL Toolkit (http://openssl.org).

(4) The names “OpenSSL Toolkit” and “Open SSL Project” must not be

used to endorse or promote products derived from this software without prior written permission. For written permission, please contact openssl-core@openssl.org.

(5) Products derived from this software may not be called “OpenSSL” nor

may “Open SSL” appear in their names without prior written permission of the OpenSSL Project.

(6) Redistributions of any form whatsoever must retain the following

acknowledgement: “This product includes software developed by the OpenSSL Project for use in the OpenSSL Toolkit (http:// www.openssl.org).”

THIS SOFTWARE IS PROVIDED BY THE OpenSSL PROJECT “AS IS” AND ANY EXPRESSED OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE OpenSSL PROJECT OR CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE. This product includes cryptographic software written by Eric Young (eay@cryptsoft.com). This product includes software written by Tim Hudson (tjh@cryptsoft.com). Copyright © 1995-1998 Eric Young (eay@cryptsoft.com). All Rights reserved. This package is an SSL implementation written by Eric Young (eay@cryptsoft.com). The implementation was written so as to conform with Netscapes SSL. This library is free for commercial and noncommercial use so long as the following conditions are adhered to. The following conditions apply to all code found in this distribution, be it the RC4, RSA, Ihash, DES, etc., code; not just the SSL code. The SSL documentation included with this distribution is covered by the same copyright terms except that the holder is Tim Hudson (tjh@cryptsoft.com). Copyright remains Eric Young’s, and as such any Copyright notices in the code are not to be removed. If this package is used in a product, Eric Young should be given attribution as the author of the parts of the library used. This can be in the form of a textual message at program startup or in documentation (online or textual) provided with the package. Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met:

(1) Redistributions of source code must retain the copyright notice, this

list of conditions and the following disclaimer.

(2) Redistributions in binary form must reproduce the above copyright

notice, this list of conditions and the following disclaimer in the documentation and/or other materials provided with the distribution.

(3) All advertising materials mentioning features or use of this software

must display the following acknowledgement: “This product includes cryptographic software written by Eric Young (eay@cryptsoft.com).” The word ‘cryptographic’ can be left out if the routines from the library being used are not cryptographic related.

(4) If you include any Windows specific code (or derivative thereof) from

the apps directory (application code) you must include an acknowledgement: “This product includes software written by Tim Hudson (tjh@cryptosoft.com).”

THIS SOFTWARE IS PROVIDED BY ERIC YOUNG “AS IS” AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE AUTHOR OR CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE. The license and distribution terms for any publicly available version or derivative of this code cannot be changed, i.e. this code cannot simply be copied and put under another distribution license (including the GNU Public License).

Index

Antenna cable ................................ 15

Antenna input configuration ............ 32

Audio quality adjustments ............... 48

Audio system connection ................ 21

Auto aspect.................................... 44

Auto power off................................ 56

Back of the TV................................ 14

Base closed captions...................... 46

Blocking channels .......................... 52

Cable box connection ..................... 17

CableClear®..................................... 58

Camcorder connection

CH Bb buttons ........................24, 41

CH RTN button......................... 24, 41

Channel Browser Setup .................. 39

Channel Browser™........................... 39

Channel labeling ............................ 34

Channel Number buttons ..........24, 41

Channel programming

Automatic programming Manually adding and deleting... 33

Cinema mode................................. 44

Closed captions.............................. 46

Color temperature .......................... 58

ColorStream®................................... 18

Component video

Component video cables ................ 15

Connecting cables .......................... 15

.................... 19

........... 33

........................... 18

Digital Audio Out ............................ 21

Digital audio selector ...................... 47

Digital CC Settings ......................... 46

Digital signal meter ......................... 36

Dolby Digital................................... 21

Dolby Digital Dynamic Range

DVD

DVD player connection ................... 18

DVI connection............................... 20

DynaLight™...................................... 45

Dynamic contrast

........................................ 49

Control

DVD aspect ratio

Fast forward ............................ 63

Fast reverse ............................ 63

Frame by frame ....................... 64

MP3/JPEG CD operation ......... 66

Playback ................................. 61

..................... 63

............................ 57

Features, TV ..................................11

Front of the TV ............................... 13

Game Mode feature........................ 59

HDMI audio mode...........................35

HDMI cable ....................................15

HDMI™ connection.......................... 20

INFO button.................................... 56

INPUT button.................................. 38

Installation, care, and service ............ 3

Installation, setup............................ 12

Integrated digital tuning................... 11

JPEG .............................................68

Labeling video input ........................ 38

Language selection......................... 32

Last mode memory feature ............. 56

LED indications.........................13, 71

LOCKS menu

Channels, blocking

Enable rating blocking ..............51

New PIN code.......................... 50

Panel lock................................ 54

Unlocking programs

temporarily

Video inputs, locking ................53

Locks menu.................................... 50

...................52

.................53

MP3 ...............................................67

MPEG noise reduction ....................59

MTS feature ...................................48

MUTE button .................................. 47

Optical audio cable .........................15

Optical audio output format .............49

PC Audio........................................ 55

PC connection ................................ 22

PC settings..................................... 54

Picture adjustment..........................45

Picture mode .................................. 45

Picture quality................................. 45

Picture scroll................................... 43

Picture size selection ...................... 42

POWER button ........................ 13, 24

RECALL button...............................56

Remote control

Battery installation

Device code table.....................28

Effective range.........................23

Functional key chart .................26

Learning about the buttons .......24

Programming ...........................27

Reset Factory Defaults....................37

....................23

Safety...............................................2

SAP sound .....................................48

Satellite receiver connection ............18

Scroll settings .................................43

Selecting Menu Language ...............32

Service .............................................4

Side panel control ...........................13

Sleep timer .....................................55

Specifications .................................72

StableSound®................................... 49

Stereo sound

SurfLock™........................................ 41

S-video cable

System status .................................36

..................................48

..................................15

TheaterWide® picture size ...............42

Troubleshooting ..............................69

TV status information ......................56

V-Chip blocking (Locks menu) .........50

VCR connection ................. 16, 17, 18

Video cables ...................................15

Video input label .............................38

Video input lock ..............................53

Warranty

Canada

U.S. .........................................73

WOW:SRS 3D ................................60

WOW:SRS Focus ...........................60

WOW:SRS TruBass........................60

....................................74

Corporate Headquarters: 82 TOTOWA ROAD, WAYNE, NJ 07470, U.S.A. NATIONAL SERVICE DIVISION: 1420-B TOSHIBA DRIVE, LEBANON, TN 37087, U.S.A.

HEAD OFFICE: 191 McNABB STREET, MARKHAM, ONTARIO, L3R 8H2, CANADA – TEL: (905) 470-5400 SERVICE CENTERS: TORONTO: 191 McNABB STREET, MARKHAM, ONTARIO L3R 8H2, CANADA – TEL: (905) 470- 5400 MONTREAL: 18050 TRANS CANADA, KIRKLAND, QUEBEC, H9J 4A1, CANADA – TEL: (514) 390-7766 VANCOUVER: 13551 COMMERCE PARKWAY, SUITE 110, RICHMOND, B.C., V6V 2L1, CANADA – TEL: (604) 303-2500

MANUFACTURED BY

CableClear, ColorStream, StableSound, and TheaterWide are registered trademarks of Toshiba America Consumer Products, L.L.C. Channel Browser, SurfLock, DynaLight, and LCDVD logo are trademarks of Toshiba America Consumer Products, L.L.C. REGZA is a resistered trademark of Toshiba Corporation.

PRINTED IN USA

(07-08)

Toshiba 26LV47 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
