Dear Customer,

Thank you for purchasing this Toshiba TV. This manual will

Important

help you use the many exciting features of your new TV.

Before operating the TV, please read this manual

Safeguards

completely, and keep it nearby for future reference.

Child Safety

It Makes A Difference

Safety Precautions

WARNING

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NOUSER-SER VICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

The lightning symbol in the triangle tells you that the voltage inside this product may be strong enough to cause an electric shock. DO NOT TRY TO SERVICE THIS PRODUCT YOURSELF.

The exclamation mark in the triangle tells you that important operating and maintenance instructions follow this symbol.

CAUTION

TO PREVENT ELECTRIC SHOCK DO NOT USE THIS POLARIZED PLUG WITH AN EXTENSION CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN BE FULLY INSERTED TO PREVENT BLADE EXPOSURE.

NOTE TO CATV INSTALLERS

This is a reminder to call the CATV system installer’s attention to Article 820-40 of the NEC, which provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of cable entry as practical. For additional antenna grounding information, see items 25 and 26 on page 4.

NOTICE OF POSSIBLE ADVERSE EFFECTS

ON TV PICTURE TUBE

If a fixed (non-moving) pattern remains on the TV screen for long periods of time, the image can become permanently ingrained in the picture tube. This type of

damage is NOT COVERED BY YOUR WARRANTY.

See item 33 on page 4.

ENERGY STAR® qualified TV. Products that earn the ENERGY STAR prevent green house gas emissions by meeting strict energy efficiency guidelines set by the U.S. Environmental Protection Agency and the U.S. Department of

ENER Y STAR

Energy. ENERGY STAR and the ENERGY STAR mark are registered U.S. marks.

NEVER CONNECT THIS TV TO A PERSONAL COMPUTER (PC.) This TV is not intended for use with a PC.

Where Your TV Stands

Congratulations on your purchase! As you enjoy your new TV, keep these safety tips in mind:

The Issue

 If you are like most consumers, you have a TV in your home.

Many homes, in fact, have more than one TV.

 The home theater entertainment experience is a growing

trend, and larger TVs are popular purchases; however, they are not always supported on the proper TV stands.

 Sometimes TVs are improperly secured or inappropriately

situated on dressers, bookcases, shelves, desks, audio speakers, chests, or carts. As a result, TVs may fall over, causing unnecessary injury.

Toshiba Cares!

 The consumer electronics industry

is committed to making home

entertainment enjoyable and safe.

 The Consumer Electronics

Association formed the Home

Entertainment Support Safety

Committee, comprised of TV and consumer electronics furniture

manufacturers, to advocate

children’s safety and educate

consumers and their families about

television safety.

Tune Into Safety

 One size does NOT fit all! Use appropriate

furniture large enough to support the weight of your

TV (and other electronic components).

 Use appropriate angle braces, straps, and anchors to secure

your furniture to the wall (but never screw anything directly into the TV).

 Carefully read and understand the other enclosed

instructions for proper use of this product.

 Do not allow children to climb on or play with furniture

and TVs.

 Avoid placing any item on top of your TV (such as a VCR,

remote control, or toy) that a curious child may reach for.

 Remember that children can become excited while watching

a program and can potentially push or pull a TV over.

 Share our safety message about this hidden hazard of

home with your family and friends. Thank you!

2500 Wilson Blvd. Arlington, VA 22201 U.S.A. Tel. 703-907-7600 Fax 703-907-7690 www.CE.org

CEA is the Sponsor, Producer and

0303

Manager of the International CES

the

J3S40121A(E)_P02-06 24/01/2005, 3:55 PM2

QUALIFIED

SERVICE

TECHNICIAN

Safeguards

Important

Important Safety Instructions

1) Read these instructions.

2) Keep these instructions.

3) Heed all warnings.

4) Follow all instructions.

5) Do not use this apparatus near

water.

6) Clean only with a dry cloth.

7) Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.

8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.

9) Do not defeat the safety purpose of the polarized or grounding type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.

Wide plug

Installation, Care, and Service

Installation

Follow these recommendations and precautions and heed all warnings when installing your TV:

16) Never modify this equipment. Changes or modifications may void: a) the warranty, and b) the user’s authority to operate this equipment under the rules of the Federal Communications Commission.

17) DANGER: RISK OF SERIOUS PERSONAL

INJURY, DEATH, OR EQUIPMENT DAMAGE! Never place the TV on

an unstable cart, stand, or table. The TV may fall, causing serious personal injury, death, or serious damage to the TV.

18) Never place or store the TV in direct sunlight; hot, humid areas; areas subject to excessive dust or vibration; or locations with temperatures at or below 41°F (5°C).

19) Always place the TV on the floor or a sturdy, level, stable surface that can support the weight of the unit.

Welcome to

Toshiba

Connecting

your TV

Remote Control

Using the

10) Protect the power cord from being

walked on or pinched, particularly at plugs, convenience receptacles, and the point where it exits the apparatus.

11) Only use attachments/accessories specified by the

manufacturer.

12) Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use

caution when moving the cart/apparatus combination to avoid injury from tip-over.

13) Unplug this apparatus during

lightning storms or when unused for long periods of time.

14) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

15) CAUTION: To reduce the risk of electric shock, do

not use the polarized plug with an extension cord, receptacle, or other outlet unless the blades can

be inserted completely to prevent blade exposure.

20) Never place items such as vases, aquariums, or candles on top of the TV.

21) Never block or cover the slots or openings in the TV cabinet back, bottom, and sides. Never place the TV:

• on a bed, sofa, rug, or similar

surface;

• too close to drapes, curtains,

or walls; or

• in a confined space such as a

bookcase, built-in cabinet, or any other place with poor ventilation.

The slots and openings are provided to protect the TV from overheating and to help maintain reliable operation of the TV.

22) Never allow anything to rest on or roll over the power cord, and never place the TV where the power cord is subject to wear or abuse.

23) Never overload wall outlets and extension cords.

0303

Setting up

your TV

Using the TV’s

Features

Appendix

J3S40121A(E)_P02-06 24/01/2005, 3:55 PM3

Ground clamp

Antenna discharge unit (NEC Section 810-20)

Grounding conductors (NEC Section 810-21)

Power service grounding electrode system (NEC Art 250 Part H)

Ground clamps

Antenna lead-in wire

Electric service equipment

QUALIFIED

SERVICE

TECHNICIAN

Important

24) Always operate this equipment from

Safeguards

a 120 V AC, 60 Hz power source only.

30) [This item applies to projection TVs only.] If the air temperature rises suddenly (for example, when the TV is first delivered), condensation may form on the lenses. This can make the picture appear distorted or the color appear faded. If this happens, turn off the TV for 6 to 7 hours to allow the condensation to evaporate.

25) Always make sure the antenna system is properly grounded to provide adequate protection against voltage surges and built-up static charges (see Section 810 of the National Electric Code).

26) DANGER: RISK OF SERIOUS PERSONAL

INJURY OR DEATH!

• Use extreme care to make sure you are never in

a position where your body (or any item you are in contact with, such as a ladder or screwdriver) can accidentally touch overhead power lines. Never locate the antenna near overhead power lines or other electrical circuits.

• Never attempt to install any of the following during lightning activity: a) an antenna system; or b) cables, wires, or any home theater component connected to an antenna or phone system.

Care

For better performance and safer operation of your TOSHIBA TV, follow these recommendations and precautions:

27) Always sit approximately 10–25 feet away from the TV and as directly in front of it as possible. The picture can appear dull if you sit too far to the left or right of the TV, or if sunlight or room lights reflect on the screen. Turn the TV off to check for reflections on the screen, and then remove the source of reflections while viewing the TV.

28) Always unplug the TV before cleaning. Never use liquid or aerosol cleaners.

31) For added protection of your TV from lightning and power surges, always unplug the power cord and disconnect the antenna from the TV if you leave the TV unattended or unused for long periods of time.

32) During normal use, the TV may make occasional snapping or popping sounds. This is normal, especially when the unit is being turned on or off. If these sounds become frequent or continuous, unplug the power cord and contact a Toshiba Authorized Service Center.

33) Possible Adverse Effects on TV Picture Tube: If a fixed (non-moving) pattern remains on the TV screen for long periods of time, the image can become permanently ingrained in the picture tube and cause subtle but permanent ghost images. This type of damage is NOT COVERED BY YOUR WARRANTY. Never leave your TV on for long periods of time while it is displaying the following formats or images:

• Fixed Images, such as PIP/POP windows, stock tickers,

video game patterns, TV station logos, closed captions, and websites.

• Special Formats that do not use the entire screen. For

example, viewing letterbox style (16:9) media on a normal (4:3) display (gray bars at top and bottom of screen); or viewing normal style (4:3) media on a widescreen (16:9) display (gray bars on left and right sides of screen).

Service

34) WARNING: RISK OF ELECTRIC

SHOCK! Never attempt to service the

TV yourself. Opening and removing the covers may expose you to dangerous voltage or other hazards. Refer all servicing to a Toshiba Authorized Service Center.

35) If you have the TV serviced:

• Ask the service technician to use only replacement parts

specified by the manufacturer.

• Upon completion of service, ask

the service technician to perform routine safety checks to determine that the TV is in safe operating condition.

29) WARNING: RISK OF ELECTRIC SHOCK!

Never spill liquids or push objects of any kind into the TV cabinet slots.

J3S40121A(E)_P02-06 24/01/2005, 3:55 PM4

36) When the TV reaches the end of its useful life, ask a qualified service technician to properly dispose of the TV. Improper disposal may result in a picture tube implosion and possible personal injury.

0303

Important Safety Information ................................................................................................. 2-4

Welcome to Toshiba ................................................................................................................... 6

Exploring your new TV ......................................................................................................................................... 6

Selecting a location for the TV.............................................................................................................................. 6

Connecting your TV ................................................................................................................... 7

Connecting a VCR ................................................................................................................................................ 7

Connecting a cable converter box or Antenna ..................................................................................................... 8

Connecting a DVD player/satellite receiver and a VCR ....................................................................................... 9

Connecting a DVD player with ColorStream Connecting a DTV receiver / set-top box with ColorStream

Connecting two VCRs ........................................................................................................................................ 12

Connecting a camcorder .................................................................................................................................... 13

Connecting an HDMI™ or a DVI device to the HDMI input ................................................................................ 14

Connecting an audio system .............................................................................................................................. 15

(component video) and a VCR ................................................... 10

(component video) and a VCR ............................ 11

Using the remote control......................................................................................................... 16

Preparing the remote control for use .................................................................................................................. 16

Installing the remote control batteries ................................................................................................................ 16

Using the remote control to operate your other devices ..................................................................................... 16

Programming the remote control to operate your other devices ........................................................................ 17

Cable TV converter/satellite receiver, VCR and DVD player code tables .......................................................... 18

Learning about the remote control ..................................................................................................................... 20

Setting up your TV ................................................................................................................... 21

Starting setup ..................................................................................................................................................... 21

Changing the on-screen display language ......................................................................................................... 21

Image tilt correction ............................................................................................................................................ 22

Adding channels to the TV’s memory ................................................................................................................. 22

Using the TV’s features ........................................................................................................... 23

Adjusting the channel settings ............................................................................................................................ 23

Using the locks menu ......................................................................................................................................... 24

Selecting a password ................................................................................................................................. 24

Using the V-Chip (parental control) feature................................................................................................ 25

Locking channels ....................................................................................................................................... 26

Locking the video inputs ............................................................................................................................ 27

Setting the GameTimer

Using the front panel lock feature .............................................................................................................. 28

Labeling channels .............................................................................................................................................. 28

Selecting the video input source ........................................................................................................................ 29

Labeling the video input sources ........................................................................................................................ 29

Setting the clock ................................................................................................................................................. 30

Setting the ON/OFF timer ................................................................................................................................... 30

Viewing the wide-screen picture formats (480i and 480p signals only) .............................................................. 31

Scrolling the TheaterWide

Selecting the cinema mode ................................................................................................................................ 34

Using the ASPECT feature ................................................................................................................................. 34

Selecting the display format (for 480p signals only) ........................................................................................... 34

Adjusting the picture ........................................................................................................................................... 35

Selecting the picture mode ........................................................................................................................ 35

Adjusting the picture quality ....................................................................................................................... 35

Selecting the color temperature ................................................................................................................. 36

Using the CableClear

Selecting the Scan Velocity Modulation (SVM) .......................................................................................... 36

Resetting your picture adjustments ............................................................................................................ 37

Setting the sleep timer ........................................................................................................................................ 37

Using the closed caption feature ........................................................................................................................ 37

Adjusting the sound ............................................................................................................................................ 38

Muting the sound ....................................................................................................................................... 38

Selecting stereo/SAP broadcasts .............................................................................................................. 38

Adjusting the sound quality ........................................................................................................................ 38

Resetting your audio adjustments .............................................................................................................. 39

Using the StableSound

Using the BBE sound feature ..................................................................................................................... 39

Turning off the built-in speakers ................................................................................................................. 40

Selecting the HDMI audio input source ...................................................................................................... 40

Displaying on-screen information ....................................................................................................................... 40

Auto power off .................................................................................................................................................... 41

Understanding the Power Return feature ........................................................................................................... 41

........................................................................................................................... 27

picture (TheaterWide 2 and 3 only) ........................................................................ 33

feature .................................................................................................................. 36

feature ................................................................................................................ 39

Appendix ................................................................................................................................... 41

Troubleshooting .................................................................................................................................................. 41

Specifications ..................................................................................................................................................... 42

Limited Warranty ................................................................................................................................................ 43

Safeguards

Important

Welcome to

Toshiba

Connecting

your TV

Remote Control

Using the

Setting up

your TV

Using the TV’s

Features

Appendix

J3S40121A(E)_P02-06 24/01/2005, 3:55 PM5

Welcome to Toshiba

Congratulations! You have purchased one of the finest color TVs on the market. The goal of this manual is to guide you through setting up and operating your Toshiba TV as quickly as possible. You may need to purchase other audio or video cables to connect your equipment. See “Connecting your TV” on page 7 for more information.

Please read all the safety and operating instructions carefully before you begin.

Exploring your new TV

You can operate your TV by using the buttons on the front panel or the

Toshiba

Welcome to

remote control. The front and back panels provide all the inputs you will need to connect other equipment to your TV.

TV front panel

POWER

Remote sensor

Power indicator

Channel

Volume

The STARTING SETUP feature appears the first time you turn on the TV. See page 21 for details.

Audio(L/R)/Video In

S-video In

TV back panel

Selecting a location for the TV

• Place the TV on the floor or on a sturdy platform in a location where light does not directly hit the screen.

• Place the TV far enough from the walls to allow proper ventilation. Inadequate ventilation may cause overheating, which may damage the TV.

J3S40121A(E)_P02-06 24/01/2005, 3:55 PM6

Connecting your TV

Safeguards

Important

• A coaxial cable is the standard cable that comes in from your antenna or cable converter box. Coaxial cables use “F” connectors.

• Standard A/V (audio/video) cables are usually color coded according to use: yellow for video and red and white for audio. The red audio cable is for the stereo right channel, and the white audio cable is for the stereo left (or mono) channel. If you look at the rear panel of the TV, you will see that the terminals are color coded in the same manner as the cables.

• S-video cables provide better picture performance than standard video cables. S-video cables can only be used with S-video compatible components.

• Component video cables provide better picture performance than S-video cables. Component video cables can only be used with component video compatible components.

• HDMI (High Definition Multimedia Interface) cable is for use with video equipment that has HDMI output (see page 14).

S-Video

ANTENNA

Coaxial Cable

AUDIO Cables

VIDEO

Cable

Component video

Cables

HDMI Cable

NEVER CONNECT THIS TV TO A PERSONAL COMPUTER (PC). This TV is not intended for use with a PC.

NOTICE: RISK OF EQUIPMENT DAMAGE!

Do not plug in any power cords until you have finished connecting all equipment.

Welcome to

Toshiba

Connecting

your TV

Remote Control

Using the

Connecting a VCR

This connection allows you to watch local channels and video programs, play or record on the VCR while watching TV, and record from one channel while watching another channel.

Cable Lead-in from cable box or antenna

IN from ANT

CH 3 CH 4

OUT to TV

OUT

VIDEO

Stereo VCR

AUDIO

You will need:

• two coaxial cables

• one set of standard A/V cables

Note:

If using a mono VCR, connect L/Mono to VCR Audio OUT using only one audio cable. For better picture quality, if your VCR has Svideo, you can use an S-video cable instead of the standard video cable. Do not connect a standard video cable and an S-video cable to VIDEO-1 (or VIDEO-2) simultaneously.

The unauthorized recording, use, distribution or revision of television programs, videotapes, DVDs, and other materials is prohibited under the Copyright Laws of the United States and other countries, and may subject you to civil and criminal liability.

Setting up

your TV

Using the TV’s

Features

Appendix

J3S40121A(E)_P07-15 24/01/2005, 3:55 PM7

Connecting a cable converter box or Antenna

This television has an extended tuning range and can tune most cable channels without using a cable company supplied converter box. Some cable companies offer “premium pay channels” in which the signal is scrambled. Descrambling these signals for normal viewing requires the use of a descrambler device, which is generally provided by the cable company.

Option 1 : For Subscribers to Basic Cable TV Service

For basic cable service not requiring a Converter/Descrambler box, connect the incoming 75 ohm Coaxial Cable directly to the Antenna Jack on the back of the television.

Option 2 : For Subscribers to Scrambled Cable TV Service

If you subscribe to a cable service that requires the use of a Converter/ Descrambler box, connect the incoming cable to the Converter/ Descrambler box and connect the output of the box to the Antenna Jack on the back of the television. Follow the connections shown below. Set the television to the output of the Converter/Descrambler box (usually channel 3 or 4) and use the Converter/Descrambler box to select channels.

your TV

Connecting

Option 3 : For Subscribers to Unscrambled Basic Cable with Scrambled Premium Channels

If you subscribe to a cable service in which basic cable channels are unscrambled and premium channels require the use of a Converter/ Descrambler box, you may wish to use a two-set signal splitter (sometimes called a “two-set coupler”) and an A/B Switch box from the cable installer or an electronics supply store. Follow the connections shown below. With the switch in the “B” position, you can directly tune any nonscrambled channels on your TV. With the switch in the “A” position, tune your TV to the output of the Converter/Descrambler box (usually channel 3 or 4) and use the box to tune scrambled channels.

Note:

When you use a converter box with your TV, there may be features that you cannot program using the remote control, such as labeling channels, blocking channels, and programming your favorite channels.

From Cable

Option 1:

Option 2:

Option 3:

Converter/Descrambler

B SwitchSplitter

J3S40121A(E)_P07-15 24/01/2005, 3:55 PM8

Connecting a DVD player/satellite receiver and a VCR

This connection allows you to watch DVD/satellite, VCR, or TV programs. You can record from the satellite receiver and TV, as well as record one TV channel while watching another channel.

You will need:

• three coaxial cables

• two sets of standard A/V cables

• one S-video cable

• one pair of standard audio cables

Safeguards

Important

From satellite

DVD player / Satellite Receiver

From antenna

Stereo VCR

Satellite IN

S-VIDEO

OUT

AUDIO

Note:

You can use a standard video cable instead of the S-video cable, but the picture quality will decrease. If you use an S-video cable between the TV and DVD player/satellite receiver, make the audio connections but remove the standard video cable. Do not connect both an S-video and a standard video cable to VIDEO1 (or VIDEO2) at the same time or the picture performance will be unacceptable.

Welcome to

Toshiba

Connecting

your TV

Remote Control

Using the

IN from ANT

CH 3 CH 4

OUT to TV

OUT

VIDEO AUDIO

Setting up

your TV

Using the TV’s

Features

Appendix

J3S40121A(E)_P07-15 24/01/2005, 3:55 PM9

Connecting a DVD player with ColorStream

(component video) and a VCR

This connection allows you to watch DVD, VCR, or TV programs and record TV programs. You can record from one source while watching a program from another source. Your TV is capable of using ColorStream (component video.) Connecting your TV to a component video compatible DVD player, such as a Toshiba DVD player with ColorStream greatly enhance picture quality and performance.

DVD player with Component video

OUT

COMPONENT VIDEO

S-VIDEO

AUDIO

VIDEO

OUT

, can

You will need:

• two coaxial cables

• one set of standard A/V cables

• one set of component video cables

• one pair of standard audio cables

Note:

You can connect the component video cables to either set of ColorStream jacks on the TV (HD-1 or HD-2.) The ColorStream HD-1 and HD-2 jacks can be used with Progressive (480p, 720p) and Interlaced (480i, 1080i) scan systems. A 1080i signal will provide the best picture performance.

your TV

Connecting

From antenna

Stereo VCR

IN from ANT

CH 3 CH 4

OUT to TV

OUT

VIDEO

AUDIO

J3S40121A(E)_P07-15 24/01/2005, 3:55 PM10

Connecting a DTV receiver / set-top box with ColorStream

(component video) and a VCR

Safeguards

Important

This connection allows you to watch DTV (digital TV), VCR, and TV programs, and record DTV and TV programs. Your TV has ColorStream® (component video) inputs. Connecting your TV to a DTV receiver with component video can greatly enhance picture quality and realism.

From Antenna

Stereo VCR

OUT

VIDEO

AUDIO

OUT

From DTV Antenna

IN from ANT

CH 3 CH 4

OUT to TV

You will need:

• three coaxial cables

• two sets of standard A/V cables

• one set of standard audio cables

• one set of component video cables

Note:

You can connect the component video cables to either set of ColorStream jacks on the TV (HD-1 or HD-2.) For HDMI connection see page 14. The ColorStream HD-1 and HD-2 jacks and HDMI jacks can be used with Progressive (480p, 720p) and Interlaced (480i, 1080i) scan systems. A 1080i signal will provide the best picture performance. If your DTV receiver does not have component video, use the S-video and standard audio connections instead. Do not connect both an S-video and a standard video cable to VIDEO1 (or VIDEO2) at the same time or the picture performance will be unacceptable.

The unauthorized recording, use, distribution, or revision of television programs, videotapes, DVDs, and other materials is prohibited under the Copyright Laws of the United States and other countries, and may subject you to civil and criminal liability.

Welcome to

Toshiba

Connecting

your TV

Remote Control

Using the

Setting up

your TV

S-VIDEO VIDEO

DTV Receiver with Component video

J3S40121A(E)_P07-15 24/01/2005, 3:55 PM11

COMPONENT VIDEO

OUT

Using the TV’s

Features

Appendix

Connecting two VCRs

This connection allows you to record (dub/edit) from one VCR to another VCR. You will also be able to record from one TV channel while watching another channel.

From antenna

your TV

Connecting

Stereo VCR/Playback

IN from ANT

CH 3 CH 4

OUT to TV

OUT

VIDEO

AUDIO

You will need:

• two coaxial cables

• two sets of standard A/V cables

Note:

Do not connect the same VCR to the output and input jacks on the TV at the same time. For better picture quality, if your VCR has Svideo, you can use an S-video cable instead of the standard video cable. Do not connect a standard video cable and an S-video cable to VIDEO-1 (or VIDEO-2) simultaneously.

Stereo VCR/Recording

IN from ANT

CH 3 CH 4

OUT to TV

OUT

VIDEO

AUDIO

J3S40121A(E)_P07-15 24/01/2005, 3:55 PM12

Connecting a camcorder

This connection allows you to watch videos recorded on a camcorder.

S-VHS Camcorder

AUDIO

VIDEO

S-VIDEO

Front Panel of TV

OUT

You will need:

• one S-video cable

• one pair of standard audio cables

Note:

For better picture quality, if your camcorder has S-video, you can use an S-video cable (plus the standard audio cables) instead of a standard video cable. Do not connect both a standard video cable and an S-video cable at the same time, or the picture performance will be unacceptable.

Safeguards

Important

Welcome to

Toshiba

Connecting

your TV

Remote Control

Using the

Setting up

your TV

Using the TV’s

Features

J3S40121A(E)_P07-15 24/01/2005, 3:55 PM13

Appendix

Connecting an HDMI™ or a DVI device to the HDMI input

The HDMI uncompressed digital video from an HDMI device or uncompressed digital video from a DVI

This input is designed to accept HDCP in digital form from EIA/CEA-861/861B–compliant consumer electronic devices (such as a set-top box or DVD player with HDMI or DVI output.)

The HDMI input is designed for best performance with high definition video signals. It will accept and display 480i, 480p, 720p and 1080i signals.

[1]

input on your TV receives digital audio and

[2]

device.

[3]

program material

[4]

[1]

HDMI = High-Definition Multimedia Interface.

[2]

DVI = Digital Video Interface.

[3]

HDCP = High-bandwidth Digital Content Protection.

[4]

EIA/CEA-861/861B compliance covers the transmission of uncompressed digital video with highbandwidth digital content protection, which is being standardized for reception of high-definition video signals. Because this is an evolving technology, it is possible that some devices may not operate properly with the TV.

To connect an HDMI device, you will need:

• one HDMI cable (type A connector)

your TV

Connecting

You must set the HDMI audio input setting to “HDMI” in the AUDIO menu (see page 40.)

Some CDVs (Video CDs) may not output digital audio signals. In that case, you may hear sound by connecting analog audio cables. If you do use analog audio cables for this reason, you will need to set the HDMI audio input setting to “DVI” to hear the analog audio (see page 40.) Note: If you connect an HDMI device and analog audio cables and play media with digital audio output, to hear digital audio you must set the HDMI audio input setting to “HDMI” (page 40.)

HDMI device

NEVER CONNECT THIS TV TO A PERSONAL COMPUTER (PC.) This TV is not intended for use with a PC.

For proper operation, it is recommended that you use as short an HDMI cable as possible. You should not encounter difficulty if you use an HDMI cable that is shorter than 16.4 ft (5m.)

HDMI cable transfers both video and audio. Separate analog audio cables are not required (see illustration below.)

VIDEO AUDIO

OUT

HDMI OUT

To ensure that the HDMI or DVI device is reset properly, it is recommended that you follow these procedures:

• When turning on your electronic components, turn on the TV first, and then the HDMI or DVI device.

• When turning off your electronic components, turn off the HDMI or DVI device first, and then the TV.

To connect a DVI device, you will need:

• one HDMI–to–DVI adapter cable (HDMI type A connector)

For proper operation, the length of an HDMI-to-DVI adapter cable should not exceed 9.8 ft (3m.) The recommended length is 6.6 ft (2m.)

• one pair of standard analog audio cables

An HDMI-to-DVI adapter cable transfers only video. Separate analog audio cables are required (see illustration below.)

You must set the HDMI audio input setting to “DVI” in the AUDIO menu (see page 40.)

DVI device

VIDEO AUDIO

OUT

DVI

OUT

HDMI, the HDMI logo, and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing, LLC.

J3S40121A(E)_P07-15 24/01/2005, 3:55 PM14

Connecting an audio system

This connection allows you to use an audio amplifier and external speakers, and adjust the audio level using the TV’s remote control. To control the audio, turn on the TV and the stereo amplifier, and turn off the TV's built-in speakers (see “Turning off the built-in speakers” on page 40.)

Note:

To hear sound when using an external audio amplifier, the volume of both the TV and the amplifier must be set above 0 (zero.) For example, if the volume of the TV is set to 0, you will not be able to hear any sound, even the volume of the amplifier is at its highest level.

Amplifier

LINE IN LR

You will need:

• one pair of standard audio cables

Safeguards

Important

Welcome to

Toshiba

Connecting

your TV

Remote Control

Using the

Setting up

your TV

Using the TV’s

Features

J3S40121A(E)_P07-15 24/01/2005, 3:55 PM15

Appendix

Using the remote control

Preparing the remote control for use

With the remote control, you can operate your TV, most cable TV converters/satellite receivers, VCR and DVD player models together, even if they are different brands. If you will be using your TV with a Toshiba satellite receiver, VCR or DVD player, your remote control is already programmed and ready to use. If you own different brands of cable TV converters/satellite receivers, VCRs and/or DVD players, you first have to program your remote control. (See “Programming the remote control for use with a cable TV converter/satellite receiver, VCR or DVD player” on page 17.)

Installing the remote control batteries

To install the batteries:

1. Open the battery cover on the back of the remote control.

2. Install two “AAA” size batteries. Match the + and – signs on the batteries to the signs on the battery compartment.

Using the

Remote Control

3. Close the battery cover on the remote control until the lock snaps.

Note:

The TV remote control may not operate your VCR, DVD player, or cable TV converter. Refer to the owner's manual supplied with the applicable equipment to see which features may be available. Additionally, the remote control for this TV may not support certain features available on the original remote controls for such additional equipment, in which case, it is suggested that you use the original remote control for the applicable device.

Caution:

• Never throw batteries into a fire.

Notes:

• Be sure to use “AAA” size batteries.

• Dispose of batteries in a designated

disposal area.

• Attention should be drawn to the environmental aspects of battery disposal.

• Do not mix different battery types or combine used batteries with new ones.

• If the remote control does not operate correctly, or if the operating range becomes reduced, replace both batteries with new ones.

• If the batteries are dead or if you will not be using the remote control for a long time, remove the batteries to prevent battery acid from leaking into the battery compartment.

Using the remote control to operate your other devices

To control a cable TV converter/satellite receiver:

Program the remote control to recognize the brand of your cable TV converter/satellite receiver (see “Programming the remote control to operate your other devices” on page 17.) The buttons shown at right will control the cable TV converter/ satellite receiver. Press “CBL/SAT” first.

Power

Input (TV)

Mute (TV)

Channel

Numbers

CH RTN

(Channel Return)

Channel 34

CBL/SAT

Volume +/- (TV)

Pic Size (TV)

TV/VCR

To control a VCR:

Program the remote control to recognize the brand of your VCR (see “Programming the remote control to operate your other devices” on page 17.) The buttons shown at right will then control the VCR. Press “VCR” first.

Input (TV)

Power

Channel

Numbers

CH RTN

(Channel Return)

VCR

Channel 34

Volume +/- (TV)

Pic Size (TV)

VCR controls

J3S40121A(E)_P16-23 24/01/2005, 3:56 PM16

Safeguards

Important

To control a DVD player:

Program the remote control to recognize the brand of your DVD player (see “Program remote control operate your other devices” below.) The buttons shown at right will then control the DVD player. Press “DVD” first.

ming the

Volume +/- (TV)

DVD Skip/Search

Power

Input (TV)

Recall

Mute (TV)

Number

buttons

DVD

Pic Size (TV)

DVD MENU

▼

▲▼

ENTER

DVD controls

TOP Menu DVD Clear

▼

Programming the remote control to operate your other devices

This remote control is pre-programmed to operate Toshiba satellite receivers, VCRs and DVD players. To control cable TV converters/ satellite receivers, VCRs and DVD players other than Toshiba models, you must follow the steps below to program your remote control.

1. Refer to the code tables (on pages 18 and 19) to find the corresponding code for your brand. If more than one code is listed, try each one separately until you find the one that works.

2. If you are programming the remote control to operate your:

• Cable TV converter/satellite receiver: Press “CBL/SAT.”

• VCR: Press “VCR.”

• DVD player: Press “DVD.”

3. While holding down RECALL, press the Channel Number buttons to enter the three-digit code for your cable TV converter/satellite receiver, VCR or DVD player brand.

4. Point the remote control at the cable TV converter/satellite receiver, VCR or DVD player, and press POWER to test the code.

• If the cable TV converter/satellite receiver, VCR or DVD player

responds, you entered the correct code.

• If the cable TV converter/satellite receiver, VCR or DVD player

does not respond, repeat steps 1–4 using another code.

5. Press “TV” to control the TV.

For future reference, write down the codes you used:

Cable TV converter/satellite receiver code _____________________

VCR code ______________________________________________

DVD player code _________________________________________

Recall

Channel Numbers

TV VCR

DVD CBL/SAT

Notes:

• When shipped from the factory, the remote control is set to operate your TV.

• If you do not enter the code within 10 seconds from step 1 or if you enter a code not listed below, this operation is canceled.

• Each time you replace the batteries, you must reprogram the remote control.

• Some newer VCRs are capable of working on either of two remote codes. These VCRs have a switch labeled “VCR1/VCR2.” If your VCR has this kind of switch and does not respond to any of the codes for your VCR, set the switch to the other position (VCR1 or VCR2) and reprogram the remote control.

Welcome to

Toshiba

Connecting

your TV

Remote Control

Using the

Setting up

your TV

Using the TV’

Features

Appendix

J3S40121A(E)_P16-23 24/01/2005, 3:56 PM17

Cable TV converter/satellite receiver, VCR and DVD player code tables

[For CBL/SAT Mode] CABLE Box

Brand Code

ABC

Archer Cableview Century Citizen Contec

Diamond Eagle GE Gemini General Instruments Hamlin Hitachi Jasco

Satellite

Brand Code

Alphastar Chaparral DISH Network Drake

Echostar Express Vu Fujitsu GE General Instruments

Hitachi Hughes

Using the

Remote Control

[For VCR Mode] VCR

Brand Code

Admiral Aiko Aiwa Akai

Audiovox Bell & Howell Broksonic Calix Carver CCE Citizen

Colortyme Craig

Curtis Mathes

Daewoo

Daytron Denon Dimensia Electrohome Emerson

Fisher

061, 062, 063, 082, 084, 087, 091, 092, 096, 098 065, 092, 097, 099 064, 094 092 090, 092, 097 083, 085, 086, 088, 093, 098 093 091 061, 062 069, 070, 094 062, 089, 096 093 062, 095, 096 097

038, 059 034 057 020, 040, 044, 046, 050, 053 018, 041, 051 057 027 008, 009, 013 010, 011, 012, 022, 023, 031, 049 033 033

049 019 018 003, 004, 037, 038, 039, 058, 069 010 007, 068 008, 017 010 026 019 009, 010, 011, 012, 013, 014, 015, 019, 057, 073 005 009, 010, 016, 061, 065, 079 001, 005, 009, 012, 014, 040, 048, 053, 056, 057 011, 013, 015, 017, 018, 019, 057, 078 078 063 001, 048 010, 020, 065 003, 008, 010, 011, 017, 018, 020, 028, 039, 054, 057, 062, 065, 068, 072 007, 016, 021, 022, 023, 057, 064, 068, 070, 071, 079

Brand Code Brand Code

Jerrold

Magnavox Memorex Multi Canal Novavision Panasonic Philco Philips

Pioneer Proscan Radio Shack RCA Realistic Recoton Samsung

062, 069, 071, 082, 086, 089, 091, 096 072, 096 091, 092, 104 090 101 081, 083, 085 087 066, 067, 068, 070, 072, 073, 074, 075, 091, 092 076, 077 061, 062 092, 097, 099 064, 081 065 102 077, 090

Scientific Atlanta

Sears Signature Signature 2000 Sprucer Starcom

Stargate Sylvania TeleView Texscan Tocom U. S. Electronics United Cable Universal

Wards

063, 078, 079, 080, 088, 098, 101, 105 095 062 096 081, 085 069, 082, 087, 096, 103, 104 069, 090 095, 100 090 100 071, 084, 085 087, 096, 098 082 065, 092, 097, 099, 102, 103 096

Brand Code Brand Code

Hughes Network Systems Intersat Janeil JVC Kenwood Magnavox Optimus Pansat Primestar Proscan Radio Shack RCA

019

048 027 017, 057 029 060 058 036, 052 015, 042 008, 009, 013 022, 023, 030 008, 009, 013, 016

Realistic Samsung Sony Star Choice Star Trak STS Toshiba

Uniden

Zenith

030 059 014, 055 057 025, 026, 037, 054 024 000, 001, 002, 003, 004, 005, 006, 007, 020, 031, 056 021, 028, 030, 032, 035, 039, 043, 045, 047, 058 027

Brand Code Brand Code

Fuji Funai Garrard GE

Go Video Goldstar

Gradiente Harman Kardon Hitachi

JBL JC Penney

Jensen JVC

Kenwood

Kodak LG Lloyds Logik LXI Magnasonic Magnavox

004, 041 018, 073 018 001, 002, 009, 040, 042, 048, 056 056, 059, 061, 081 005, 010, 014, 054, 056, 065, 067 018, 065 005 024, 025, 035, 037, 042, 063, 070, 080 076 005, 006, 007, 008, 009, 010, 023, 024, 025, 026, 035, 056, 061, 063, 065 024, 025, 037 005, 006, 007, 014, 037, 043, 062, 063, 068, 082 005, 006, 007, 012, 014, 037, 043, 053, 068, 071 010 010 053, 073, 079 061 010 061, 065, 078 026, 027, 034, 044, 057, 061, 072

Marantz

Memorex

MGA MGN Minolta Mitsubishi

Montgomery Ward Motorola MTC Multitech NEC

Nikko Noblex Optimus Optonica Orion

Panasonic

Pentax

Pentex Research Philco Philips Pioneer

005, 006, 007, 012, 014, 026, 053, 067 007, 009, 010, 016, 018, 034, 049, 063, 065, 066, 068, 075, 079 020, 028, 039 056 024, 025, 035, 063 020, 024, 025, 028, 039, 043, 065 049 049 009, 046, 061 009, 012, 018 005, 006, 007, 012, 014, 037, 043, 053, 054, 067, 070 010 009 010, 049, 065 031 054, 057, 062, 065, 068, 072 036, 045, 046, 057, 061, 072, 079 012, 024, 025, 035, 042, 053, 063 014 026, 027, 063 026, 031, 044, 057 006, 024, 043, 055

J3S40121A(E)_P16-23 24/01/2005, 3:56 PM18

VCR (Continued)

Brand Code

Portland Proscan Proton Quasar Radio Shack Radio Shack/ Realistic

Radix RCA

Realistic

Ricoh Runco Samsung

Sansui

012, 013, 015 001, 002, 048 061 045 010, 031, 065 007, 009, 010, 016, 018, 020, 021, 022, 031, 049 010 001, 002, 003, 009, 024, 025, 029, 035, 040, 042, 045, 048, 055, 056, 063, 071, 083 007, 009, 010, 011, 016, 018, 020, 021, 022, 031, 049, 051, 056, 060, 065, 075, 079 047 034 009, 011, 038, 056, 073, 084 006, 037, 043, 061

TV/VCR Combo

Brand

Action GE Goldstar Panasonic

078 059, 062 065 065

[For DVD Mode] DVD

Brand Code

Aiwa Apex BOSE Broksonic Clarion Classic Daewoo Denon Emerson Fisher Funai GE Go Video GPX Hitachi

JVC

006, 015 016, 017 097 018 019 020 021 022, 023, 024, 025 026, 027 028 027 001, 029, 030 087 031 005, 032, 033, 034, 035 003, 007, 036, 042, 088

Portable DVD

Brand Code

Aiwa Audiovox

093 094, 095

Brand Code Brand Code

Sanyo

Scott

Sears

Sharp

Shintom Signature Signature 2000 Singer Sony

STS Sylvania

Symphonic

Tandy

007, 009, 016, 054, 064, 068, 071, 075, 079, 085 008, 011, 017, 028, 030, 057, 065, 072 007, 010, 016, 021, 022, 023, 024, 025, 035, 053, 057, 063, 064, 065, 068, 071, 075, 079 013, 020, 031, 049, 051, 060, 066 004, 025, 032, 061 049 075 047, 061 004, 032, 033, 041, 052, 058, 070, 074, 076, 077, 080 035 018, 026, 027, 028, 044, 072 018, 051, 053, 073, 079 007

Tashiko Tatung Teac Technics Teknika Toshiba

Totevision Unitec Unitech Vector Research

Video Concepts

Wards

White Westinghouse XR-1000 Yamaha

Zenith

010 037 018, 029, 037 036 010, 018, 065 000, 011, 021, 023, 024, 028, 030, 039, 057, 074, 078, 079 009, 010, 065 073 009 005, 006, 011, 012, 053 005, 006, 011, 012, 039, 053 009, 010, 011, 016, 018, 020, 024, 025, 031, 035, 049, 051, 056, 057, 060, 065, 066, 079 073 018 005, 006, 007, 014, 037, 053 004, 032, 034, 041, 047, 069, 086

Brand CodeCode Brand Code

Precision Quasar Realistic Sony

078 065 079 074

Toshiba Zenith Totevision

057 065 009, 010, 065

Brand Code Brand Code

Kenwood Konka Magnavox Memorex Mintek NAD Nakamichi Norcent Onkyo Oritron Panasonic

Philips Pioneer Proscan Qwestar RCA

037 008, 009 004, 038 039 040 026 041 043 044 058 010, 045, 046, 047, 048, 049, 050 004, 051 052, 053, 054, 055 001, 056 057, 058 001, 002, 059, 089

Sampo Samsung Sansui Sanyo Sharp Sherwood Sony

Sylvania Teac Technics Techwood Toshiba

Yamaha Zenith

060 061, 062, 086, 090 073 063, 091 064, 067 074 011, 012, 065, 066, 068, 069, 070 027 071 072 075 000, 013, 076, 077, 078 079, 080, 081 014, 082, 092

Brand Code Brand Code

024,096,099Panasonic RCA 098

Safeguards

Important

Welcome to

Toshiba

Connecting

your TV

Remote Control

Using the

Setting up

your TV

Using the TV’

Features

HTIB

Brand Code

Lasonic 083 084Panasonic Venturer 085

[For VCR and DVD Mode] DVD/VCR Combo

Brand VCR Code

Go Video JVC RCA

J3S40121A(E)_P16-23 24/01/2005, 3:56 PM19

081 082 083

Brand Code Brand Code

DVD Code

087 088 089

Brand VCR Code DVD Code

Samsung Sanyo Zenith

084 085 086

090 091 092

Appendix

Learning about the remote control

POWER turns the TV on and off

SLEEP programs the TV to turn off at a set time (page 37)

TV/VIDEO selects the video input source (page 27)

3 /

4 cycles through programmed channels (page 22)

TV select TV mode

CBL/SAT select CBL/SAT mode (page 16)

VCR select VCR mode (page 16)

DVD select DVD mode (page 17)

CHANNEL NUMBERS allow direct access to channels (page 23)

VOL +/- adjusts the volume level

CH RTN (Channel Return) returns to the last viewed channel

(page 23)

MENU/ENTER allows access to programming menus, and sets

programmed menu information (page 21)

FAV ▲ /▼ (Favorite Channels) cycle through favorite channels

(page 23)

MUTE turns off the sound (page 38)

RECALL displays status information on-screen (page 25)

EXIT closes on-screen menus (page 21)

Using the

PIC SIZE cycles through the five picture sizes: Natural, TheaterWide

1, 2, 3, and full (page 31)

Remote Control

TV/Video

Recall

Channel

Numbers

Channel 3 / 4

CBL/SAT

Sleep

DVD Menu

Enter

Pause

Skip/Search

4¢

Rew

TOP Menu

Rec

POWER Mute

Volume +/-

VCR

DVD

Picture Size FAV ▲▼

(Favorite Channels)

Menu/Enter

Exit Play Stop

FF TV/VCR

Clear

STOP stops a videotape/DVD

REC starts recording a videotape

PLAY plays a videotape/DVD

FF fast forwards a videotape/DVD

REW rewinds a videotape/DVD

PAUSE pauses a videotape/DVD

TV/VCR toggles between TV and VCR modes when viewing

while recording

DVD SKIP/SEARCH skips DVD chapter

DVD CLEAR clears input data in DVD mode

TOP MENU access the DVD TOP menu

DVD MENU access the DVD menu

J3S40121A(E)_P16-23 24/01/2005, 3:56 PM20

Setting up your TV

Starting setup

The STARTING SETUP feature appears the first time you turn on the TV, and helps you select the menu language, specify the TV/CABLE setting, and program channels automatically.

IMPORTANT: Make sure that the antenna or cable TV system connection is made!

1. Press POWER to turn on the TV. The starting setup function begins and the language setup menu appears on the screen. Press ▲ or ▼ to select your desired language, then press ENTER.

2. Press ▲ or ▼ to select “TV” or “CABLE”, then press ENTER.

3. Press ▲ or ▼ to select “START”, then press ENTER. If you select “CANCEL” and press ENTER, the STARTING SETUP stops and changes to the TV screen.

4. Now the “AUTO SETUP” starts. After the starting setup is com- pleted, the TV channel appears on the screen.

• If you press the EXIT button in the process of “AUTO SETUP”

the STARTING SETUP stops and changes to the TV screen.

LANGUAGE / LANGUE / IDIOMA

ENGLISH

FRANÇAIS ESPAÑOL

:SELECT SET :ENTER

POWER

Menu/Enter

Safeguards

Important

Welcome to

Toshiba

Connecting

your TV

After you have installed the batteries and programmed the remote control, you need to set some preferences on the TV using the menu system. You can access the menu system with the buttons on the remote control.

• When you make a menu selection, your changes occur immediately. You do not have to press MENU or EXIT to see your changes.

• After 15 seconds, the menu screen will automatically close if you do not make a selection. Your changes will still be saved.

• When you are finished programming the menus, press EXIT.

Changing the on-screen display language

You can choose from three different languages (English, French, and Spanish) for the on-screen displays of adjustment menus and messages.

To select a language:

1. Press MENU, then press

SETUP

LANGUAGE

CLOCK SET TV / CABLE CH PROGRAM ADD / ERASE

:SELECT :ADJUST

ENGLISH

12:00AM CABLE

ADD

2. Press ▲ or ▼ to highlight LANGUAGE.

or until the SETUP menu appears.

Exit

Note:

The position and size of the on-screen menus change for some program formats (such as 1080i or 720p.)

Remote Control

Using the

Setting up

your TV

Using the TV’

Features

ENGLISH

12:00AM CABLE

ADD

:SELECT :ADJUST

3. Press or to highlight your desired language.

J3S40121A(E)_P16-23 24/01/2005, 3:56 PM21

Appendix

Image tilt correction

When you install or change the direction of the TV, the picture may become tilted (caused by the Earth’s magnetism.) If this happens, use the image tilt correction feature to obtain the best possible picture.

To adjust the image tilt:

1. Press MENU, then press until the SETUP menu appears.

2. Press ▲ or ▼ to highlight IMAGE TILT.

3. Press or to adjust the picture tilt (from –10 to 10.)

SETUP

CLOSED CAPTION

PICTURE SIZE PICTURE SCROLL CINEMA MODE ASPECT IMAGE TILT

:SELECT :ADJUST

OFF

VIDEO ON 0

Adding channels to the TV’s memory

When you press CH 3 or 4, your TV will stop only on the channels you have stored in the TV's channel memory. Follow the steps below to program channels into the channel memory.

Programming channels automatically

Your TV can automatically detect all active channels and store them in its memory. After the TV has stored the channels in its memory automatically, you can add or erase channels manually.

To add channels automatically:

Adding and erasing channels manually

your TV

Setting up

After you have programmed the channels automatically, you can add or erase specific channels manually.

To add or erase channels manually:

1. Press MENU, then press

or to display the SETUP menu.

2. Press ▲ or ▼ until the TV/CABLE selection is highlighted.

3. Press or to highlight either TV or CABLE, depending on which you use. If you use an antenna, choose TV.

SETUP

LANGUAGE

CLOCK SET TV / CABLE CH PROGRAM ADD / ERASE

:SELECT :ADJUST

ENGLISH

12:00AM TV / CABLE

ADD

If you use cable, choose CABLE.

4. Press ▼ until the CH PROGRAM selection is highlighted.

Press or to start channel programming. The TV will automatically cycle through all the TV or Cable channels (depending on which you selected), and store all active channels in the channel memory. While the TV is cycling through the channels, the message “PROGRAMMING NOW-PLEASE WAIT” appears.

6. When channel programming is complete, the message “COMPLETED” appears.

7. Press CH 3 or 4 to view the programmed channels.

1. Select the channel you want to add or erase. If you are adding a channel, you must select the channel using the Channel Number buttons.

2. Press MENU, then press

or to

display the SETUP menu.

3. Press ▲ or ▼ to highlight ADD/ ERASE.

4. Press

or to select ADD or

SETUP

LANGUAGE

CLOCK SET TV / CABLE CH PROGRAM ADD / ERASE

:SELECT :ADJUST

ENGLISH

12:00AM CABLE

ADD / ERASE

ERASE, whichever function you want to perform.

5. Repeat steps 1-4 for other channels you want to add or erase.

Channel Numbers

Channel 34

J3S40121A(E)_P16-23 24/01/2005, 3:56 PM22

Changing channels

To change to the next programmed channel:

Press Channel ▼/▲ on the TV or CH 3 / 4 on the remote control.

To change to a specific channel (programmed or unprogrammed):

Press the Channel Number buttons (0-9 and 100) on the remote control. For example, to select channel 125, press 100, 2, 5.

Using the TV’s features

Adjusting the channel settings

Switching between two channels

You can switch between two channels without entering an actual channel number each time.

To switch between two channels:

1. Select the first channel you want to view.

2. Select a second channel using the Channel Number buttons (0-9,

100.)

3. Press CH RTN. The previous channel will be displayed. Each time you press CH RTN, the TV will switch back and forth between the two channels.

Programming your favorite channels

You can preset up to 12 of your favorite channels using the Favorite Channel Programming feature. Because this feature scans through only your favorite channels, it allows you to skip other channels you do not normally watch. You can still use Channel 3 / 4 to scan through all the channels you programmed in the TV’s memory.

To program your favorite channels:

1. Select a channel you want to program as a favorite channel.

2. Press MENU, then press

3. Press ▲ or ▼ to highlight FAVORITE CH.

or to display the OPTION menu.

Channel Numbers

CH RTN

Channel 34

Menu/ Enter

FAV ▲ ▼

Exit

Safeguards

Important

Welcome to

Toshiba

Connecting

your TV

Remote Control

Using the

OPTION

ON/OFF TIMER FAVORITE CH CH LABEL VIDEO LABEL

:SELECT :ADJUST

OFF

4. Press or to display the FAVORITE CH menu. SET/CLEAR will

be highlighted.

FAVORITE CH :CH 002

SET / CLEAR

SETUP CH 0000

TV CABLE 0000

:ADJUST SET :ENTER

0000

END:EXIT

5. Press or to highlight SET and press ENTER.

6. Press EXIT to return to normal viewing.

7. Repeat steps 1-6 for up to 12 channel.

To select your favorite channels:

Press the FAV ▲ ▼ buttons on the remote control to select your favorite channels. The FAV ▲ ▼ buttons will not work until you have programmed your favorite channels.

Setting up

your TV

Using the TV’

Features

Appendix

J3S40121A(E)_P16-23 24/01/2005, 3:56 PM23

To clear your favorite channels:

1. Select a channel you want to clear.

2. Press MENU, then press

or to display the OPTION menu.

3. Press ▲ or ▼ to highlight FAVORITE CH.

4. Press

or to display the FAVORITE CH menu. SET/CLEAR

will be highlighted.

5. Press or to highlight CLEAR.

Channel Numbers

FAVORITE CH :CH 002

SET / CLEAR

SETUP CH 002 0 0 0

TV CABLE 0 0 0 0

:ADJUST CLEAR:ENTER

0 0 0 0

END:EXIT

6. Press ENTER until “0” replaces the channel number you want to erase.

7. Press EXIT to return to normal viewing.

8. Repeat steps 1-6 for the other channels.

Using the LOCKS menu

Note: The V-Chip feature is available for the U.S. V-Chip system only. The Canadian V-Chip system is not supported.

You can prevent others from viewing certain programs or channels by blocking them using the V-Chip feature.

Selecting a password

Before you can use the V-Chip feature to block programs and channels, you must select a password. The password you select prevents others from changing the rating limits you set.

To select your password and access the LOCKS menu:

1. Press MENU, then press

2. Press ▲ or ▼ to display the password entering mode.

or to highlight the LOCKS menu.

Channel 34

Menu/ Enter

Exit

Note:

The password you programmed is also used in the LOCKS menu; see pages 26-28.

Features

Using the TV’s

LOCKS

NEW PASSWORD

SELECT:[0-9] SET :ENTER

----

END:EXIT

3. Use the Channel Number buttons (0-9) to enter your password. If you are accessing the LOCKS menu for the first time, select a four-digit number to be your password. Press ENTER.

LOCKS

NEW PASSWORD

SELECT:[0-9] SET :ENTER

END:EXIT

4. Enter the password again to confirm it, and then press ENTER. The LOCKS menu appears.

LOCKS

CONFIRM PASSWORD

SELECT:[0-9] SET :ENTER

END:EXIT

J3S40121A(E)_P24-30 24/01/2005, 3:56 PM24

5. You may now set up the LOCKS menu. See “Using the V-Chip (parental control) feature” (below), “Locking channels” (page 26), “Locking video inputs” (page 27), “Setting the GameTimer

”

(page 27) or “Using the front panel lock feature” (page 28.)

Recall

Safeguards

Important

To change your password:

1. Press MENU, then press

or to display the LOCKS menu.

2. Press ▲ or ▼ to display the password entering mode.

3. Use the Channel Number buttons (0-9) to enter your password. Press ENTER. The LOCKS menu appears.

4. Press ▲ or ▼ to highlight NEW PASSWORD and press

or to

display the NEW PASSWORD menu.

5. Use the Channel Number buttons (0-9) to enter a new code. Press ENTER.

6. Enter the password again to confirm it, and then press ENTER.

7. Press EXIT to return to normal viewing.

Using the V-Chip (parental control) feature

The Motion Picture Association of America (MPAA) uses a rating system to qualify motion picture content. Television broadcasters employ a rating system to qualify the content of television programs, as well. The TV and MOVIE ratings work with the V-Chip feature and allow you to block programs according to the rating limits you set.

To use the V-Chip to block programs by rating:

1. Press MENU, then press or to display the LOCKS menu.

2. Press ▲ or ▼ to display the password entering mode.

3. Use the Channel Number buttons (0-9) to enter your password. Press ENTER. The LOCKS menu appears.

4. Press ▲ or ▼ to highlight V-CHIP.

• Press

or to highlight ON to enable V-Chip program blocking by rating.

• Press

or to highlight OFF to disable V-Chip program blocking by rating.

5. Press ▲ or ▼ to highlight TV RATING. Then, press display the desired rating.

OFF : TV RATING is not set TV-Y : All children TV-Y7 : 7 years old and above TV-G : General audience TV-PG : Parental guidance TV-14 : 14 years old and above TV-MA : 17 years old and above

• When you select TV-Y7, TV-PG, TV-14, or TV-MA, press RECALL to

explain the rating. Press Press

or to select the setting “ON” or “OFF.”

▲ or ▼ to select the desired rating you want.

6. Press ▲ or ▼ to highlight MOVIE RATING. Then, press or to display the desired rating.

OFF : MOVIE RATING is not set

(no movies will be blocked)

G:All ages PG : Parental guidance PG-13 : Parental guidance less than 13 years old R:Under 17 years old Parental guidance suggested NC17 : 17 years old and above X:Adult only

LOCKS

V-CHIP SET

V-CHIP TV RATING

MOVIE RATING

:SELECT :ADJUST

LOCKS

V-CHIP SET

V-CHIP TV RATING

MOVIE RATING

:SELECT :ADJUST

ON / OFF OFF

OFF

OFF OFF /TV-Y/TV-Y7/TV-G

TV-PG / TV-14 / TV-MA

OFF

or to

LOCKS

V-CHIP SET

V-CHIP TV RATING

MOVIE RATING

OFF / G / PG / PG-13 / R / NC17 / X

:SELECT :ADJUST

TV-PG

OFF

Channel Numbers

Menu/ Enter

Exit

Note:

If you forget your password, press RECALL four times within five seconds while the TV is in password entering mode. This allows you to reset your password.

Welcome to

Toshiba

Connecting

your TV

Remote Control

Using the

Setting up

your TV

Using the TV’s

Features

Appendix

J3S40121A(E)_P24-30 24/01/2005, 3:56 PM25

7. When you are done selecting the ratings, press EXIT to return to normal viewing.

When you try to view a program with a ratings block, a message will appear listing the program’s ratings. The program can still be viewed if you press MUTE and then enter your password to temporarily bypass the block.

Locking channels

With the CH LOCK feature, you can lock specific channels. You will not be able to tune locked channels unless you clear the setting. You can choose to lock up to nine TV channels and nine cable channels.

To lock channels:

1. Select a channel you want to lock.

2. Press MENU, then press

3. Press ▲ or ▼ to display the password entering mode.

4. Use the Channel Number buttons (0-9) to enter your password, then press ENTER. The LOCKS menu appears.

5. Press ▲ or ▼ to highlight CH LOCK and press

or to display

the CH LOCK menu.

6. Press or to select the following:

• SET– to set the channel as one

to be locked. Then press ENTER.

• CLEAR– to clear all channels from

the list of locked channels. Then press ENTER.

7. Repeat steps 1 through 6 to lock other channels. When you are finished locking channels, press EXIT to return to normal viewing.

If you try to tune a locked channel, the TV will not display it, but will display the nearest unlocked channel.

or to display the LOCKS menu.

LOCKS

LOCK

CH LOCK

VIDEO LOCK

GAME TIMER

FRONT PANEL LOCK NEW PASSWORD

:SELECT :ADJUST

CH LOCK :CH 002

SET / CLEAR

SETUP CH 0 0 0

TV CABLE 0 0 0

:ADJUST SET :ENTER

OFF

0 0 0

END:EXIT

Mute

Channel Numbers

Channel 34

Menu/ Enter

Exit

Features

Using the TV’s

To unlock channels:

1. Press MENU, then press

or to display the LOCKS menu.

2. Press ▲ or ▼ to display the password entering mode.

3. Use the Channel Number buttons (0-9) to enter your password, then press ENTER. The LOCKS menu appears.

4. Press ▲ or ▼ to highlight CH LOCK and press

or to display

the CH LOCK menu.

5. Press

or to highlight CLEAR and clear all channels from the

list of locked channels. Press ENTER.

6. Press EXIT to return to normal viewing.

Note:

After programming CH LOCK, change channels before turning off the television.

J3S40121A(E)_P24-30 24/01/2005, 3:56 PM26

Locking the video inputs

With the VIDEO LOCK feature, you can lock out the input sources (VIDEO1, VIDEO2, VIDEO3, COLORSTREAM HD1, COLORSTREAM HD2, HDMI) and channels 3 and 4. You will not be able to select the input sources with the TV/VIDEO button or Channel buttons unless you clear the setting.

To set up the video lock:

1. Press MENU, then press

2. Press ▲ or ▼ to display the password entering mode.

3. Use the Channel Number buttons (0-9) to enter your password, then press ENTER. The LOCKS menu appears.

4. Press ▲ or ▼ to highlight VIDEO LOCK.

5. Press

or to select:

• OFF: Unlocks all video input sources.

VIDEO: Locks VIDEO1, VIDEO2,

•

VIDEO3, COLORSTREAM HD1, COLORSTREAM HD2, and HDMI

• VIDEO +: Locks VIDEO1,

VIDEO2, VIDEO3, COLORSTREAM HD1, COLORSTREAM HD2, HDMI, channel 3, and channel 4. This option should be used if you use the antenna terminal to play a video tape.

6. Press EXIT to return to normal viewing.

To unlock the video inputs:

1. Press MENU, then press

2. Press ▲ or ▼ to display the password entering mode.

3. Use the Channel Number buttons (0-9) to enter your password, then press ENTER. The LOCKS menu appears.

4. Press ▲ or ▼ to highlight VIDEO LOCK and press highlight OFF.

5. Press EXIT to return to normal viewing.

or to display the LOCKS menu.

LOCKS

LOCK

CH LOCK VIDEO LOCK

GAME TIMER

FRONT PANEL LOCK NEW PASSWORD

:SELECT :ADJUST

OFF

OFF / VIDEO / VIDEO+

OFF

or to display the LOCKS menu.

or to

TV/Video

Channel Numbers

Menu/ Enter

Exit

Note:

After programming VIDEO LOCK, change channels or press the TV/VIDEO key before turning off the television.

Safeguards

Important

Welcome to

Toshiba

Connecting

your TV

Remote Control

Using the

Setting the GameTimer

With the VIDEO LOCK feature (VIDEO setting)

GameTimerTM feature, you can automatically activate the

to set a time limit for playing a

video game (30, 60, 90, or 120 minutes.)

To set up the GameTimer:

1. Press MENU, then press

or to display the LOCKS menu.

2. Press ▲ or ▼ to display the password entering mode.

3. Use the Channel Number buttons (0-9) to enter your password, then press ENTER. The LOCKS menu appears.

4. Press ▲ or ▼ to highlight GAME TIMER.

5. Press

or to select a time limit (30 minutes, 60 minutes, 90

minutes, 120 minutes, or OFF.)

6. Press EXIT to return to normal viewing. After the GameTimer is programmed, the display will appear briefly every ten minutes to remind you that the GameTimer operating. When the programmed time is reached, the TV will change

LOCKS

LOCK

CH LOCK VIDEO LOCK

GAME TIMER

FRONT PANEL LOCK NEW PASSWORD

:SELECT :ADJUST

OFF

OFF /30/60/90/120

OFF

channels automatically and enter VIDEO LOCK mode.

Notes:

• Interactive video games that involve shooting a gun type of joy-stick at an onscreen target may not work on this TV.

• To deactivate the GameTimer, set the VIDEO LOCK to OFF (see “Locking the video inputs” above.)

Setting up

your TV

Using the TV’s

Features

Appendix

J3S40121A(E)_P24-30 24/01/2005, 3:56 PM27

SPACE

—

Using the front panel lock feature

You can lock the front panel buttons to prevent your settings from being changed accidentally (by children, for example). When the front panel lock is in ON, all control buttons on the TV front panel (except POWER) do not operate.

To lock the front panel:

1. Press MENU, then press

2. Press ▲ or ▼ to display the password entering mode.

3. Use the Channel Number buttons (0-9) to enter your password, then press ENTER. The LOCKS menu appears.

4. Press ▲ or ▼ to highlight FRONT PANEL LOCK and press highlight ON. If a button on the front panel is pressed, the message “NOT AVAILABLE” appears.

To unlock the front panel:

Press and hold the VOL ▼ button on the TV front panel for about 10 seconds until the message “FRONT PANEL LOCK:OFF” appears on-screen.

You also can unlock the front panel using the menus:

1. Press MENU, and then press

2. Press ▲ or ▼ to display the password entering mode.

3. Use the Channel Number buttons (0-9) to enter your password, then press ENTER. The LOCKS menu appears.

4. Press ▲ or ▼ to highlight FRONT PANEL LOCK, and then press

or to highlight OFF.

or to display the LOCKS menu.

or to

LOCKS

LOCK

CH LOCK VIDEO LOCK

GAME TIMER

FRONT PANEL LOCK NEW PASSWORD

:SELECT :ADJUST

OFF

ON / OFF

or to display the LOCKS menu.

TV front panel

Buttons to be locked

TV front panel

VOL

Channel Numbers

Channel 34

Menu/ Enter

Features

Using the TV’s

Labeling channels

Channel labels appear above the channel number display each time you turn on the TV, select a channel, or press the RECALL button. You can choose any four characters to identify a channel.

To create channel labels:

1. Select a channel you want to label.

2. Press MENU, then press until the OPTION menu appears.

3. Press ▲ or ▼

to highlight CH

LABEL.

4. Press or to display the CH LABEL menu. SET/CLEAR will be highlighted.

5. Press

or to highlight SET.

6. Press ▲ or ▼ to highlight LABEL.

7. Press

or to enter a character in the first space. Press the button repeatedly until the character you want appears on the screen. Press ENTER.

8. Repeat step 7 to enter the rest of the characters. If you would like a blank space in the label name, you must choose an empty space from the list of characters; otherwise, a dash will appear in that space.

9. Repeat steps 1-8 for other channels. You can assign a label to each channel.

10. Press EXIT to return to normal viewing.

OPTION

ON/OFF TIMER FAVORITE CH CH LABEL VIDEO LABEL

:SELECT :ADJUST

CH LABEL :CH 025

SET / CLEAR

LABEL

:ADJUST SET :ENTER

CH LABEL :CH 025

SET

LABEL

:ADJUST SET :ENTER

OFF

— — — —

END:EXIT

Ð ÐÐÐ

END:EXIT

Exit

Note:

The character will change as below.

To erase channel labels:

1. Select a channel with a label.

2. Press MENU, then press OPTION menu appears.

3. Press ▲ or ▼ to highlight CH LABEL.

4. Press

or to display the CH LABEL

menu. SET/CLEAR will be highlighted.

5. Press or to highlight CLEAR.

6. Press ENTER.

7. Repeat steps 1-6 to erase other channel labels.

or until the

J3S40121A(E)_P24-30 24/01/2005, 3:56 PM28

Selecting the video input source

Safeguards

Important

Press TV/VIDEO to view a signal from another device connected to your TV, such as a VCR or DVD player. You can select ANT, VIDEO 1, VIDEO 2, VIDEO 3, ColorStream HD1, ColorStream HD2, or HDMI depending on which input jacks you used to connect your devices (see “Connecting your TV” on page 7.)

SOURCE SELECTION

0. ANT

1. VIDEO1

2. VIDEO2

3. VIDEO3

4. ColorStream HD1

5. ColorStream HD2

6. HDMI

SELECT: [0-6]

Pressing TV/VIDEO on the remote control displays the current signal source (press TV/ VIDEO again or 0-6 to change)

Labeling the video input sources

The video label feature allows you to label each input source for your TV from the following preset list of labels:

– : Uses the default label name

VCR : Video cassette recorder DVD : DVD video DTV : Digital TV set-top box SAT : Satellite box CBL : Cable box

To label the video input sources:

1. Press MENU, and then press to display the OPTION menu.

2. Press ▲ or ▼ to highlight VIDEO

LABEL.

3. Press

to display the VIDEO

LABEL menu.

4. Press ▲ or ▼ to highlight the video

source you want to label.

5. Press

or to select the desired

label for that input source.

6. Press EXIT to return to normal

viewing.

OPTION

ON/OFF TIMER FAVORITE CH CH LABEL VIDEO LABEL

:SELECT :ADJUST

OPTION

1.VIDEO1

2.VIDEO2

3.VIDEO3

4.ColorStream HD1

5.ColorStream HD2

6.HDMI

:SELECT :ADJUST

OFF / OFF / SET

/ VCR / DVD / DTV

SAT / CBL

Note:

When ColorStream HD 1, HD 2, or HDMI is selected, the video OUT jack does not output a signal. To receive a video OUT signal, you must use a standard video or S-video connection instead.

Please note the following regarding the HDMI source selection:

This TV is not intended for connection to and should not be used with a PC (personal computer.) See “Connecting an HDMI or a DVI device to the HDMI input” on page 14 for details.

TV/VIDEO

Exit

Welcome to

Toshiba

Connecting

your TV

Remote Control

Using the

Setting up

your TV

J3S40121A(E)_P24-30 24/01/2005, 3:56 PM29

Using the TV’s

Features

Appendix

Setting the clock

You must set the clock before you can program the ON/OFF timer.

To set the clock: (Example: 8:30 AM)

1. Press MENU, then press or to display the SETUP menu.

2. Press ▲ or ▼

to highlight CLOCK

SET.

3. Press

or to highlight the hour

position.

4. Press ▲ or ▼ to set the hour, then press

to highlight the minute

position.

5. Press ▲ or ▼ to set the minutes, then press EXIT to return to normal viewing.

SETUP

LANGUAGE

CLOCK SET TV / CABLE CH PROGRAM ADD / ERASE

:SELECT :ADJUST

SETUP

LANGUAGE

CLOCK SET TV / CABLE CH PROGRAM ADD / ERASE

:SELECT :ADJUST

ENGLISH

12:00AM

CABLE

ADD

ENGLISH

8:30AM CABLE

ADD

Menu/ Enter

Setting the ON/OFF timer

This feature allows you to program the TV to turn on or off automatically at a set time. If you program the ON TIMER to “DAILY,” the TV will turn on every day at the same time to the same channel until you clear the ON TIMER.

To set the on timer: (Example: Turning on the TV to channel 012 at 6:30 AM, DAILY)

1. Set the clock, if you have not already done so (see above.)

2. Press MENU, and then press

3. Press ▲ or ▼ to highlight ON/OFF TIMER.

4. Press

or to highlight SET, then press ENTER. The ON/OFF

TIMER menu appears.

5. Press ▲ or ▼ to highlight ON TIMER, then press

to highlight the hour

position.

6. Press ▲ or ▼ to set the desired hour, then press

7. Set the desired minutes and channel, as in step 6.

8. Press or to select ONCE or DAILY, then press ENTER.

9. Press EXIT to return to normal viewing.

or to display the OPTION menu.

ON/OFF TIMER

ON TIMER

6:00AM

OFF TIMER

12:00AM

:SELECT :ADJUST

ON/OFF TIMER

ON TIMER

6:30AM

OFF TIMER

12:00AM

:ADJUST SET :ENTER

CH003 CLEAR

CLEAR

END:EXIT

CH004

ONCE DAILY CLEAR

CLEAR

END:EXIT

Exit

Note:

If the power source for the TV is interrupted (for example, the power cord is unplugged or a power failure occurs), you will need to reset the clock.

Note:

After a power failure or disconnection of the power, the timer settings will be lost.

To set the off timer:

Select OFF TIMER in step 5 above. Set the desired hour, minutes, and ONCE/DAILY as to set the on timer.

To cancel the on timer (off timer):

Features

Select CLEAR in step 8 above. Press EXIT to return to normal viewing.

Using the TV’s

J3S40121A(E)_P24-30 24/01/2005, 3:56 PM30

Viewing the wide-screen picture formats

SETUP

CLOSED CAPTION

PICTURE SIZE PICTURE SCROLL CINEMA MODE ASPECT IMAGE TILT

:SELECT :ADJUST

OFF

VIDEO ON 0

(480i and 480p signals only)

You can view 480i and 480p format programs in a variety of picture sizes—Natural, TheaterWide 1, TheaterWide 2, TheaterWide 3, and Full. The way the image displays in any of the picture sizes will vary depending on the format of the program you are viewing. Select the picture size that displays the current program the way that looks best to you.

0-4

Safeguards

Important

Welcome to

Toshiba

Selecting the picture size

1. Press PIC SIZE on the remote control.

2. Press the corresponding number button (0-4) to select the desired picture size, as described below and on the next page.

PICTURE SIZE

0: NATURAL 1: THEATER WIDE1 2: THEATER WIDE2 3: THEATER WIDE3 4: FULL

SELECT: [0¥4]

Natural picture size

• The image is displayed close to its originally formatted proportion. Some program formats will display with side bars and/or bars at the top and bottom.

Natural picture size example: The way the image displays will vary depending on the format of the program you are currently watching.

Conventional (4:3) picture on a conventional TV screen

Conventional (4:3) picture in Natural size on your wide-screen TV

TheaterWide 1 picture size (for 4:3 format programs)

• The center of the picture remains close to its original proportion, but the left and right edges are stretched wider to fill the screen.

• The top and bottom edges of the picture may be hidden; however, this mode cannot be scrolled.

Pic Size

Note:

You also can change the picture size by selecting PICTURE SIZE in the SETUP menu.

Notes:

• The PICTURE SIZE feature is not available for some program formats (such as 1080i or 720p.) Such formats will display in Natural picture size.

• If you select TheaterWide 2 or 3, the top and bottom edges of the picture may be hidden. To see the hidden edges, either scroll the picture (see page 33) or try viewing the program in Full picture size.

NOTICE OF POSSIBLE ADVERSE EFFECTS ON TV PICTURE TUBE

Avoid displaying stationary images on your TV screen for extended periods of time. Fixed (non-moving) images (such as black/ gray bars in wide-screen picture formats, video game patterns, TV station logos, closed captions) can become permanently ingrained in the picture tube. This type of

damage is NOT COVERED BY YOUR WARRANTY.

Connecting

your TV

Remote Control

Using the

Setting up

your TV

Using the TV’

Using the TV’s

Features

J3S40121A(E)_P31-37 24/01/2005, 3:57 PM31

TheaterWide 1 picture size example

• Using these functions to change the picture size (i.e., changing the height/ width ratio) for any purpose other than your private viewing may be prohibited under the Copyright Laws of the United States and other countries, and may subject you to civil and criminal liability.

Appendix

TheaterWide 2 picture size (for letter box programs)

• The picture is stretched the same amount both wider and taller (retains its original proportion).

• The top and bottom edges of the

A B C D E F G - - - - - - - - - - - - - - - -

picture may be hidden. To view the hidden areas, see “Scrolling the TheaterWide picture” on page 33.

TheaterWide 2 picture size example

TheaterWide 3 picture size (for letter box programs with subtitles)

• The picture is stretched wider to fill the width of the screen, but only slightly stretched taller.

• The top and bottom edges of the picture may be hidden. To view the hidden areas (such as subtitles or captions), see “Scrolling the

TheaterWide picture” on page 33.

A B C D E F G - - - - - - - - - - - - - - - -

Note:

Using these functions to change the picture size (i.e., changing the height/ width ratio) for any purpose other than your private viewing may be prohibited under the Copyright Laws of the United States and other countries, and may subject you to civil and criminal liability.

Features

Using the TV’s

A B C D E F G - - - - - - - - - - - - - - - - - - - - - - - - - -

TheaterWide 3 picture size example

Full picture size (for 16:9 source programs)

• If receiving a 4:3 format program, the picture is stretched wider to fill the width of the screen, but not stretched taller.

• None of the picture is hidden.

Full picture size example

NOTICE OF POSSIBLE ADVERSE EFFECTS ON TV PICTURE TUBE

damage is NOT COVERED BY YOUR WARRANTY.

J3S40121A(E)_P31-37 24/01/2005, 3:57 PM32

Scrolling the TheaterWide® picture (TheaterWide 2 and 3 only)

1. Press PIC SIZE to select the TheaterWide 2 or 3 mode.

2. Press MENU, and then press or until the SETUP menu appears.

3. Press ▲ or ▼ to highlight PICTURE SCROLL.

Safeguards

Important

SETUP

CLOSED CAPTION

PICTURE SIZE PICTURE SCROLL CINEMA MODE ASPECT IMAGE TILT

:SELECT :ADJUST

OFF

VIDEO ON 0

4. Press or to display the Scroll Adjustment mode.

SCROLL ADJUSTMENT 0

: TO ADJUST

5. Press ▲ or ▼ to adjust the vertical position of the picture.

• Normal (center) position

SCROLL ADJUSTMENT 0

: TO ADJUST

• To raise the picture, press ▲.

SCROLL ADJUSTMENT +20

: TO ADJUST

• To lower the picture, press ▼.

Pic Size

Note:

You can scroll the picture in TheaterWide 2 and TheaterWide 3 only. The scroll amounts are as follows:

• 480i/480p signal source: Wide 1 : Not adjustable Wide 2 : -10 to +20 Wide 3 : -10 to +20

Welcome to

Toshiba

Connecting

your TV

Remote Control

Using the

Setting up

your TV

SCROLL ADJUSTMENT Ð10

: TO ADJUST

J3S40121A(E)_P31-37 24/01/2005, 3:57 PM33

Using the TV’

Using the TV’s

Features

Appendix

Selecting the cinema mode

When you view a DVD movie (3:2 pulldown processed) from a DVD player connected to the ColorStream (component video) inputs on the TV, smoother and more natural motion can be obtained by setting the CINEMA MODE to FILM.

To set the CINEMA MODE to FILM:

1. Press MENU, and then press

until the SETUP menu appears.

2. Press ▲ or ▼ to highlight CINEMA MODE, and then press

or to

select FILM.

SETUP

CLOSED CAPTION

PICTURE SIZE PICTURE SCROLL CINEMA MODE ASPECT IMAGE TILT

:SELECT :ADJUST

OFF

FILM / VIDEO ON 0

To set the CINEMA MODE to VIDEO (off):

Press

or to select VIDEO in step 2 above.

Using the ASPECT feature

When the ASPECT feature is set to ON and the TV receives a 480i signal, the picture size is automatically selected (as described in the following table.)

Automatic aspect size

Aspect ratio of signal source

4:3 Normal

16:9 Full

4:3 Letter box

Not defined

(automatically selected

when ASPECT is ON)

Natural

Full TheaterWide 2 User-set mode

Features

Using the TV’s

If the signal does not include aspect information, the picture size you selected on pages 31 and 32 is displayed.

To turn on the ASPECT feature:

1. Press MENU, and then press

or until the SETUP menu

appears.

2. Press ▲ or ▼ to highlight ASPECT, and then press or to select ON.

SETUP

CLOSED CAPTION

PICTURE SIZE PICTURE SCROLL CINEMA MODE ASPECT IMAGE TILT

:SELECT :ADJUST

OFF

VIDEO

ON / OFF

Selecting the display format (for 480p signals only)

This feature converts a 480p input signal to 540p or 1080i.

To select the display format:

1. Press MENU, and then press appears.

2. Press ▲ or ▼ to highlight DISPLAY FORMAT.

3. Press

or to select 540p or 1080i.

or until the PICTURE menu

Notes:

• The DISPLAY FORMAT feature is available only for 480p input. 1080i is always output when a signal other than 480p is input.

• If you notice flickering in a 480p image, try setting the DISPLAY FORMAT to 540p.


CableClear COLOR TEMPERATURE

DISPLAY FORMAT SVM

RESET

:SELECT :ADJUST

J3S40121A(E)_P31-37 24/01/2005, 3:57 PM34

COOL

540p / 1080i HIGH

Adjusting the picture

Selecting the picture mode

You can select four picture modes—Sports, Standard, Movie, and Memory—as described in the following table:

Safeguards

Important

Mode Picture Quality

SPORTS Bright and dynamic picture (factory-set) STANDARD Standard picture quality (factory-set) MOVIE Movie-like picture setting (factory-set) MEMORY Your personal preferences (set by you; see

“Adjusting the picture quality”)

To select the picture mode:

1. Press MENU, then press

or to display the PICTURE menu.

2. Press ▲ or ▼ to highlight MODE.


MODE

SPORTS / STANDARD / MOVIE/MEMORY

BRIGHTNESS CONTRAST COLOR TINT SHARPNESS

:SELECT :ADJUST

SPORTS

25 50 25

3. Press or to highlight the mode you prefer.

4. Press EXIT to return to normal viewing.

Adjusting the picture quality

You can adjust the picture quality to your personal preferences, including the brightness, contrast, color, tint, and sharpness. The qualities you choose will be stored automatically in your TV’s memory so you can recall them at any time.

To adjust the picture quality:

1. Press MENU, then press

2. Press ▲ or ▼ until the item you want to adjust is highlighted.


MODE

BRIGHTNESS CONTRAST COLOR TINT SHARPNESS

:SELECT :ADJUST

SPORTS

25 50 25

or to display the PICTURE menu.

Exit

Welcome to

Toshiba

Connecting

your TV

Remote Control

Using the

Setting up

your TV

3. Press or to adjust the level.

Selection Pressing

BRIGHTNESS darker lighter CONTRAST lower higher COLOR paler deeper TINT reddish greenish SHARPNESS softer sharper

4. Press EXIT to return to normal viewing.

J3S40121A(E)_P31-37 24/01/2005, 3:57 PM35

Using the TV’

Using the TV’s

Features

Appendix

Selecting the color temperature

Change the picture quality by selecting from three preset color temperatures—cool, medium, and warm—as described in the following table:

Mode Picture Quality

COOL Blueish MEDIUM Neutral WARM Reddish

To select the color temperature:

1. Press MENU, then press

2. Press ▲ or ▼ to highlight COLOR TEMPERATURE.

or to display the PICTURE menu.


CableClear COLOR TEMPERATURE

DISPLAY FORMAT SVM

RESET

:SELECT :ADJUST

3. Press

or to highlight the mode you prefer.

ONCOOL

COOL COOL / MEDIUM / WARM

1080i HIGH

4. Press EXIT to return to normal viewing.

Using the CableClear

™

feature

CableClear™ reduces visible interference in your TV picture. This is useful when receiving a broadcast with a weak signal (especially a Cable channel) or playing a video cassette or disc damaged by repeated use.

To turn on the CableClear™:

1. Press MENU, then press

or to display the PICTURE menu.

2. Press ▲ or ▼ to highlight CableClear.


CableClear COLOR TEMPERATURE

DISPLAY FORMAT SVM

RESET

:SELECT :ADJUST

ON/OFF

COOL

1080i HIGH

3. Press or to select ON.

To turn off the CableClear™:

Select OFF in step 3.

Exit

Selecting the Scan Velocity Modulation (SVM)

The SVM feature enhances picture contrast and sharpness. This feature has three modes: HIGH, LOW, and OFF.

To select the SVM feature:

1. Press MENU, then press

2. Press ▲ or ▼ to highlight SVM.

Features

Using the TV’s

To turn off the SVM:

J3S40121A(E)_P31-37 24/01/2005, 3:57 PM36


CableClear COLOR TEMPERATURE

DISPLAY FORMAT SVM

RESET

:SELECT :ADJUST

3. Press or to select the mode you prefer.

Select OFF in step 3.

COOL

1080i

HIGH HIGH / LOW / OFF

or to display the PICTURE menu.

Note:

SVM is not required when viewing some high-quality video material. If you are watching high-quality video material, you may want to set SVM to OFF.

Resetting your picture adjustments

The RESET function returns your picture quality adjustments to the following factory settings:

Mode ............................ sports

Brightness ............ center (25)

Contrast .................. max (50)

Color .................... center (25)

To reset your picture adjustments:

1. Press MENU, then press or to display the PICTURE menu.

2. Press ▲ or ▼ to highlight RESET, and then press .

Tint ......................... center (0)

Sharpness............ center (25)

Color temperature ........... cool

SVM ................................ high

Sleep

Safeguards

Important

Welcome to

Toshiba


CableClear COLOR TEMPERATURE

DISPLAY FORMAT SVM

RESET

:SELECT :ADJUST

COOL

1080i HIGH

Setting the sleep timer

You can set the TV so it turns off automatically.

To set the sleep timer:

Repeatedly press SLEEP on the remote control to set the length of time until the TV turns off. The clock will increase 10 minutes for each press of the SLEEP button (0h00m, 0h10m, ...1h50m, 2h00m.) After the sleep timer is programmed, the display will appear briefly every ten minutes to remind you that the sleep timer is operating.

To confirm the sleep timer setting:

Press SLEEP one time. The remaining time will be momentarily displayed.

To cancel the sleep timer:

Repeatedly press SLEEP until the display turns to 0h00m.

Using the closed caption feature

The Closed Caption feature has two options:

• Captions—An on-screen display of the dialogue, narration, and sound effects of programs and videos that are closed-captioned (usually identified in your local TV listing as “CC”.)

• Text—An on-screen display of information not related to the program, such as weather or stock data (if available in your viewing area).

To view captions or text:

1. Tune the TV to the desired program.

2. Press MENU, and then press

3. Press ▲ or ▼ to highlight CLOSED CAPTION.

SETUP

CLOSED CAPTION

PICTURE SIZE PICTURE SCROLL CINEMA MODE ASPECT IMAGE TILT

:SELECT :ADJUST

OFF

C1 / C2 / T1 / T2 / OFF

VIDEO ON 0

or to display the SETUP menu.

Note:

A closed caption signal may not be decoded in the following situations:

• when a video tape has been dubbed

• when the signal reception is weak

• when the signal reception is non-standard

Connecting

your TV

Remote Control

Using the

Setting up

your TV

Using the TV’

Using the TV’s

Features

4. Press or to select the desired Closed Caption mode, as follows:

• To view captions, select C1 or C2 (C1 displays translation of the

primary language in your area.) Note: If the program or video you selected is not closedcaptioned, no captions will display on-screen.

• To view text, select T1 or T2. Note: If text is not available in your

viewing area, a black rectangle may appear on-screen. If this happens, set the Closed Caption feature to OFF.

• To turn the Closed Caption feature off, highlight

OFF in the Closed Caption menu.

J3S40121A(E)_P31-37 24/01/2005, 3:57 PM37

Appendix

Adjusting the sound

Muting the sound

Press MUTE to temporarily turn off the sound. While the sound is off, the screen will display the word MUTE in the lower right-hand corner. To restore the sound, press MUTE again.

Mute

Recall

Selecting stereo/SAP broadcasts

The multi-channel TV sound (MTS) feature provides high-fidelity stereo sound. MTS also can transmit a second audio program (SAP) containing a second language or other audio information. Note: The MTS feature is not available in VIDEO mode.

When the TV receives a stereo or SAP broadcast, the word “STEREO” or “SAP” displays on-screen every time you turn the TV on, change the channel, or press RECALL.

To listen to stereo sound:

1. Press MENU, then press or to display the AUDIO menu.

2. Press ▲ or ▼ to highlight MTS.

3. Press Notes:

• In general, you can leave your TV in stereo mode because the

•

4. Press EXIT to return to normal viewing.

To listen to a second audio program (SAP):

1. Press MENU, then press or to display the AUDIO menu.

2. Press ▲ or ▼ to highlight MTS.

3. Press second audio program instead of normal audio.

4. Press EXIT to return to normal viewing.

or to highlight STR (stereo.)

TV automatically outputs the type of sound being broadcast (stereo or mono.) If the stereo sound is noisy, select MONO to reduce the noise.

AUDIO

MTS BASS TREBLE BALANCE STABLE SOUND SPEAKERS

:SELECT :ADJUST

STR / SAP / MONO

25 25

0 OFF ON

or to highlight SAP. The TV speakers will output the

Exit

Note:

A second audio program (SAP) can be heard only on those TV stations that offer it.

For example, a station might broadcast music as a second audio program. If you have SAP on, you will see the current program on the screen but hear music instead of the program’s normal audio.

However, if you have SAP on, and the station you are watching is not currently broadcasting a second audio program, the station’s normal audio will be output; however, occasionally there is no sound at all in SAP mode. If this happens, set the MTS feature to STEREO mode.

Adjusting the sound quality

You can change the sound quality of your TV by adjusting the bass, treble, and balance.

To adjust the sound quality:

1. Press MENU, then press

2. Press ▲ or ▼ to highlight the item you want to adjust.

Features

Using the TV’s

J3S40121A(E)_P38-Back 24/01/2005, 3:57 PM38

AUDIO

MTS BASS TREBLE BALANCE STABLE SOUND SPEAKERS

:SELECT :ADJUST

3. Press or to adjust the level.

• makes the sound quality weaker or decreases the balance in the right channel, depending on the item selected.

makes the sound quality stronger or decreases the balance

•

in the left channel, depending on the item selected.

STEREO

25 25

OFFONOFF ON

or until the AUDIO menu appears.

Note:

Adjusting the sound quality (bass, treble and balance) does not affect from the variable audio OUT jacks.

Resetting your audio adjustments

The RESET function returns the audio adjustments to the following factory settings:

Bass ................. center (25)

Treble ............... center (25)

Balance ............ center (0)

To reset your audio adjustments:

1. Press MENU, then press

2. Press ▲ or ▼ to highlight RESET, and then press

or to display the AUDIO menu.

Safeguards

Important

Welcome to

Toshiba

AUDIO

BBE HDMI RESET

:SELECT :ADJUST

OFF HDMI

Using the StableSound® feature

The StableSound feature limits the highest volume level to prevent extreme changes in volume when the signal source is changed.

To turn on the StableSound

1. Press MENU, then press or to display the AUDIO menu.

2. Press ▲ or ▼ to highlight STABLE SOUND.

3. Press

or to highlight ON.

AUDIO

MTS BASS TREBLE BALANCE STABLE SOUND SPEAKERS

:SELECT :ADJUST

STEREO

ON / OFF ON

To turn off the StableSound

Highlight OFF in step 3 above.

Using the BBE sound feature

By correcting the phase delay and distortion naturally generated by speaker systems, the BBE sound feature ensures that the sound that reaches your ears is as natural as the original sound. Human voices are clearer and music is natural and well-defined.

To turn on the BBE sound feature:

1. Press MENU, then press

2. Press ▲ or ▼ to highlight BBE.

3. Press

or to highlight ON.

AUDIO

BBE HDMI RESET

ON / OFF HDMI

feature:

25 25

feature:

or until the AUDIO menu appears.

Note:

Make sure the volume control of your audio amplifier is set to a moderate listening level.

Connecting

your TV

Remote Control

Using the

Setting up

your TV

Using the TV’

Features

:SELECT :ADJUST

To turn off the BBE sound feature:

Highlight OFF in step 3 above.

Licensed by BBE Sound, Inc. under USP5510752 and 5736897. BBE and BBE symbol are registered trademarks of BBE Sound, Inc.

J3S40121A(E)_P38-Back 24/01/2005, 3:57 PM39

Appendix

Turning off the built-in speakers

Use this feature to turn the TV speakers off when you connect an audio system (see “Connecting an audio system” on page 15.)

To turn off the built-in speakers:

1. Press MENU, then press or to display the AUDIO menu.

2. Press ▲ or ▼ to highlight SPEAKERS, and then press or to select OFF.

AUDIO

MTS BASS TREBLE BALANCE STABLE SOUND SPEAKERS

:SELECT :ADJUST

STEREO

25 25

0 OFF

ON / OFF

To turn on the built-in speakers:

Select ON in step 2 above.

Selecting the HDMI audio input source

See page 14 for details on connecting an HDMI or a DVI device to the TV’s HDMI input. If you connect a DVI device, to hear audio you must also connect the analog audio cables to the HDMI audio IN jacks (see page 14.) Set the HDMI audio input setting to “DVI” with this connection. If you connect an HDMI device and play media with digital audio output, to hear digital audio set the HDMI audio input setting to “HDMI” with this connection. If you connect an HDMI device but play media with analog audio output (for example, certain CDVs do not output digital audio), to hear audio you must also connect the analog audio cables to the HDMI audio IN jacks (see page

14.) Set the HDMI audio input setting to “DVI” with this connection.

Recall

Features

Using the TV’s

To select the HDMI audio input source:

1. Press MENU, and then press or to display the AUDIO menu.

2. Press or to highlight HDMI.

3. Press or to select HDMI or DVI.

AUDIO

BBE HDMI RESET

:SELECT :ADJUST

OFF

HDMI / DVI

Displaying on-screen information

Press RECALL to display the following on-screen information:

• Clock

• Channel number or VIDEO mode selected

• Channel label (if preset)

• Stereo or SAP (second audio program) audio status

• Content rating

• On timer, Sleep timer (if preset)

• Picture size

STEREO SAP TV-PG L V ON TIMER 12:00AM SLEEP TIMER 2h00m

FULL ABCD

CABLE

CLOCK 12:00AM

ANT

007

J3S40121A(E)_P38-Back 24/01/2005, 3:57 PM40

Auto power off

The TV will automatically turn off after approximately 15 minutes if it is tuned to a vacant channel or a station that completes broadcast for the day and stops broadcasting on that channel. This feature does not work in VIDEO mode.

its

Understanding the Power Return feature

If the power is cut off while you are viewing the TV and the power is resupplied, the Power Return feature will turn the TV on automatically.

If the power is going to be off for a long time or you are going to be away from home for a long time, unplug the power cord from the wall outlet to prevent the TV from turning on in your absence.

Appendix

Troubleshooting

Before calling a service technician, please check the following table for a possible cause of the symptom and some solutions.

Symptom Solution

TV will not turn on • Make sure the power cord is plugged in, then press POWER.

• The remote control batteries may be dead. Replace the batteries.

No picture, no sound • Check the antenna/cable connections.

No sound, picture OK • The sound may be muted. Press VOLUME.

• The station may have broadcast difficulties. Try another

• The MTS feature may be in SAP mode. Select STR or MONO in the

MTS menu.

Poor sound, picture OK • The station may have broadcast difficulties. Try another channel.

• The MTS feature may be in SAP mode. Select STR or MONO in the MTS menu.

Poor picture, sound OK • Check the antenna connections.

• The station may have broadcast difficulties. Try another channel.

• Adjust the PICTURE menu.

Poor reception of broadcast channels • The station may have broadcast difficulties. Try another channel.

• Check the antenna connections.

• If you are using a video input, make sure the TV/VIDEO button is set

correctly.

Cannot receive above channel 13 • Make sure the TV/CABLE in the SETUP menu is set to “CABLE.”

Unable to select a certain channel • The channel may be blocked by the V-Chip feature or CH LOCK

feature, or erased with the add/erase feature.

Cannot access signal input sources (Video1, • Check the VIDEO LOCK feature. Video2, Video3, ColorStream HD1, ColorStream HD2, and HDMI) and/or Channels 3 and 4

Multiple images • The station may have broadcast difficulties. Try another channel.

• Use a highly directional outdoor antenna.

Poor color or no color • The station may have broadcast difficulties. Try another channel.

• Adjust the TINT and/or COLOR in the PICTURE menu.

• If you change the direction of the TV while it is turned on, the picture

could suffer from color shading. If so, turn off the TV and allow it to cool for several hours before turning it on again.

Black box on screen • Select OFF in the Closed Caption menu to turn off the Closed Caption

Text mode.

No stereo or SAP sound from a • Make sure the MTS feature is set properly (AUDIO menu). known MTS broadcast

The V-Chip password does not work • Change or reset your password. (U.S. V-Chip system only)

The remote control does not operate • Make sure the TV • CBL/SAT • VCR • DVD mode is set properly on the

remote control.

• Remove all obstructions between the remote control and the TV.

• The remote control batteries may be dead. Replace the batteries.

The front panel buttons do not operate • Check the FRONT PANEL LOCK feature.

channel.

Safeguards

Important

Welcome to

Toshiba

Connecting

your TV

Remote Control

Using the

Setting up

your TV

Using the TV’

Features

Appendix

J3S40121A(E)_P38-Back 24/01/2005, 3:57 PM41

Specifications

• This model complies with the specifications below.

• Design and specifications are subject to change without notice.

• This model may not be compatible with features and/or specifications that may be added in the future.

26HF85 30HF85

Picture Tube 26 in. (657 mm) diagonal 30 in. (760 mm) diagonal

(Screen size is approximate.) (Screen size is approximate.)

Television system NTSC standard

Channel coverage VHF: 2–13

UHF: 14–69

Cable TV: 4A, A-5–A-1, A-I,

J–W, W+1–W+84

Power source 120V AC, 60 Hz

Power consumption 175 W 185 W

Audio power 5.0 W + 5.0 W 10 W + 10 W

Speaker type 1-13/16 x 3-7/8 in. (45.7 x 99.1 mm) x 2 pcs.

Video/Audio terminals S-VIDEO INPUT

Y-INPUT: 1V (p-p), 75 ohm, negative sync.

C-INPUT: 0.286V (p-p) (burst signal), 75 ohm

VIDEO/AUDIO INPUT

VIDEO: 1V (p-p), 75 ohm, negative sync.

AUDIO: 150 mV (rms) (30% modulation equivalent, 47k ohm)

ColorStream

Y: 1V (p-p), 75 ohm

PR: 0.7V (p-p), 75 ohm

PB: 0.7V (p-p), 75 ohm

VIDEO/AUDIO OUTPUT

VIDEO: 1V (p-p), 75 ohm, negative sync.

AUDIO: 150 mV (rms) (30% modulation equivalent, 47k ohm)

HDMI INPUT: HDMI compliant (type A connector)

HDCP compliant

E-EDID compliant

Suggested scan rates: 1080i, 480p, 480i, 720p

HDMI Audio: 2-channel PCM

Dimensions Width: 27-9/16 in. (700 mm) 31-5/16 in. (796 mm)

Height: 19-1/2 in. (495.5 mm) 21-5/8 in. (549.2 mm)

Depth: 19-3/4 in. (502 mm) 22-3/16 in. (563 mm)

Weight 79.4 lbs. (36 kg) 111.4 Ibs. (50.5 kg)

Supplied accessories Remote control with two size “AAA” batteries

(component video) INPUT

32/44.1/48 kHz sampling frequency

16/20/24 bits per sample

Appendix

J3S40121A(E)_P38-Back 24/01/2005, 3:57 PM42

Limited United States Warranty

for 27'' FST PURE® and All Larger TVs and All HD-Ready and HD Integrated TVs

Toshiba America Consumer Products, L.L.C. (“TACP”) makes the following limited warranties to original consumers in the United States. THESE LIMITED WARRANTIES EXTE ND TO THE

ORIGINAL CONSUMER PURCHASER OR ANY PERSON RECEIVING THIS TELEVISION AS A GIFT FROM THE ORIGINAL CONSUM ER PURCHASER AND TO NO OTHER PURCHAS ER OR TRANSFEREE.

TELEVISIONS PURCHASED IN THE U.S.A. AND U SED ANYWHERE OUTSIDE OF THE U.S.A., INCLUDING, WITHOUT LIMITATION, CANADA AND M EXICO, ARE NOT COVERED BY THESE WARRANTIES.

TELEVISIONS PURCHASED ANYWHERE OUTSI DE OF THE U.S.A., INCLUDING, WITHOUT LIMITATION, CANADA AND MEXICO, AND USED IN TH E U.S.A., ARE NOT COVERED BY THESE WARRANTIES.

Limited One (1) Year Warranty on Parts and Labor*

TACP warrants this television and its parts against defects in materials or workmanship for a period of one (1) year after the date of original retail purchase. DURING THIS PERIOD, TACP WILL, AT

TACP’S OPTION, REPAIR OR REPLACE A DEFECTIVE PART WITH A NEW OR REFURBISHED PART WITHOUT CHARGE TO YOU FOR PARTS OR LABOR. TACP Authorized Service Station

personnel will come to your home when warranty service is required. Depending on the type of repair required, either the service will be performed in your home or the set will be taken to the TACP Authorized Service Station for repair and returned to your home at no cost to you.

Limited Two (2) Year Warranty on Picture Tube*

TACP warrants the picture tube in this television against defects in materials or workmanship for a period of two (2) years after the date of original retail purchase. DURING THIS PERIOD, TACP WILL, AT

TACP’S OPTION, REPAIR OR REPLACE A DEFECTIVE PICTURE TUBE WITH A NEW OR REFURBISHED PICTURE TUBE WITHOUT CHARGE TO YOU, EXCEPT THAT, IF A DEFECTIVE PICTURE TUBE IS RE PAIRED OR REPLACED AFTER ONE (1) YEAR AFTER THE DATE OF THE ORIGI NAL RETAIL PURCHASE, YOU MUST PAY ALL LABOR CHARGES INVOLVED IN THE REPAIR OR REPLACEMENT OF SUCH PICTURE TUBE. TAC P

Authorized Service Station personnel will come to your home when warranty service is required. Depending on the type of repair required, either the service will be performed in your home or the set will be taken to the TACP Authorized Service Station for repair and returned to your home at no cost to you.

Rental Units

The warranty for rental units begins with the date of first rental or thirty (30) days from the date of shipment to the rental firm, whichever comes first.

*Limited Warranty for Commercial Units

TACP warrants televisions sold and used for commercial purposes as follows: all parts are warranted against defects in materials or workmanship for a period of ninety (90) days after the date of original purchase. DURING TH IS PERIOD, TACP WILL, AT TACP’S

OPTION, REPAIR OR REPLACE A DE FECTIVE PART WITH A NEW OR REFURBISHED PART WITHOUT CHARGE TO YOU.

Owner’s Manual and Product Registration

Read this owner’s manual thoroughly before operating this television.

Complete and mail the enclosed product registration card or register your television on-line at www.tacp.toshiba.com/service as soon as possible. By registering your television you will enable TACP to bring you new products specifically designed to meet your needs and help us to contact you in the unlikely event a safety notification is required under the Consumer Product Safety Act. Failure to register your television does not diminish your warranty rights. support. Failure to register your product does not diminish your warranty rights.

Your Responsibility

THE ABOVE WARRANTIES ARE SUBJECT TO THE FOLLOWING CONDITIONS:

(1) You must provide your bill of sale or other proof of purchase. (2) All warranty servicing of this television must be performed by an

Authorized TACP Service Station.

(3) These warranties from TACP are effective only if the television is

purchased and operated in the U.S.A. or Puerto Rico.

(4) Labor charges for installation, setup, adjustment of customer

controls, and installation or repair of antenna systems are not covered by these warranties. Reception problems caused by inadequate antenna systems are your responsibility.

(5) Warranties extend only to defects in materials or workmanship

as limited above, and do not extend to any television or parts that have been lost or discarded by you or to damage to the television or parts caused by fires, misuse, accident, Acts of God (such as lightning or fluctuations in electric power), improper installation, improper maintenance, or use in violation of instructions furnished by TACP; use or malfunction through simultaneous use of this product and connected equipment; or to units that have been modified or had the serial number removed, altered, defaced, or rendered illegible.

How to Obtain Warranty Services

If, after following all of the operating instructions in this manual and checking the “Troubleshooting” section, you find that service is needed:

(1) To find the nearest TACP Authorized Service Station, visit

TACP’s web site at www.tacp.toshiba.com/service or call toll free 1-800-631-3811.

(2) Present your bill of sale or other proof of purchase to the

Authorized Service Station.

For additional information, visit TACP’s web site:

ALL WARRANTIES IMPLIED BY THE LAW OF ANY STATE OF THE U.S.A., INCLUDING THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE EXPRESSLY LIMITED TO THE DURATION OF THE LIMITED WARRANTIES SET FORTH ABOVE. WITH THE EXCEPTION OF ANY WARRANTIES IMPLIED BY THE LAW OF ANY STATE OF THE U.S.A. AS HEREBY LIMITED, THE FOREGOING WARRANTY IS EXCLUSIVE AND IN LIEU OF ALL OTHER WARRANTIES, GUARANTEES, AGREEMENTS, AND SIMILAR OBLIGATIONS OF TACP WITH RESPECT TO THE REPAIR OR REPLACE MENT OF ANY PARTS. IN NO EVENT SHALL TACP BE LIABLE FOR CONSEQUE NTIAL OR INCIDENTAL DAMAGES (INCLUDING, BUT NOT LIMITE D TO, LOST PROFITS, BUSINESS INTERRUPTION, OR MODIFICATION OR ERASURE OF RECORDED DATA CAUSED BY USE, MISUSE, OR INABILITY TO USE THIS PRODUCT).

No person, agent, distributor, dealer, or company is authorized to change, modify, or extend the terms of these warranties in any manner whatsoever. The time within which action must be commenced to enforce any obligation of TACP arising under this warranty or under any law of the United States or of any state thereof is hereby limited to 90 days from the date you discover, or should have discovered, the defect. This limitation does not apply to implied warranties arising under the law of any state of the U.S.A.

THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AN D YOU MAY ALSO HAVE OTHER RIGHTS, WHICH MAY VARY FROM STATE TO STATE IN THE U.S.A. SOME STATES OF TH E U.S.A. DO NOT ALLOW LIMITATIONS ON THE DURATION OF AN IMPLIED WARRANTY, LIMITATIONS ON THE TIME WITHI N WHICH AN ACTION MAY BE BROUGHT, OR THE EXCLUSION OR LIM ITATION OF INCIDENTAL OR CONSEQUE NTIAL DAMAGE S; THEREFORE, THE ABOVE LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO YOU UNDER SUCH CIRCUMSTANCE S.

FST PUR E® is a registered trademark of Toshiba America Consumer Products, L.L.C. 061404

www.tacp.toshiba.com

Safeguards

Important

Welcome to

Toshiba

Connecting

your TV

Remote Control

Using the

Setting up

your TV

Using the TV’

Features

Appendix

J3S40121A(E)_P38-Back 24/01/2005, 3:57 PM43

National Service Division

ColorStream, FST Pure, TheaterWide and StableSound are registered trademarks of Toshiba America Consumer Products, L.L.C. CableClear and GameTimer are trademarks of Toshiba America Consumer Products, L.L.C.

PRINTED IN THAILAND

J3S40121A(E)_P38-Back 24/01/2005, 3:57 PM44

Toshiba 26HF85 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
