19/22/26/32AV73*G

and

32/40LV73*G

DIGITAL Series

19/22/26/32AV73*G /AV73*G1 and

32/40KV73*G

DIGITAL Series

Contents

Safety Precautions ....................................... 3

Installation and important information ....... 4

The remote control ....................................... 6

Inserting batteries and effective range of

the remote ................................................. 7

Connecting external equipment .................. 8

REGZA-LINK Connections ......................... 10

Connecting an HDMI® or DVI device to the

HDMI input ................................................... 11

To connect an HDMI device ................... 11

DVI device to the HDMI Input ................. 13

Connecting a computer.............................. 15

To connect a PC to the HDMI terminal .. 15

Using the controls ...................................... 17

Switching on ........................................... 18

Using the remote control ....................... 18

Using the side-panel controls ............... 18

Tuning the television .................................. 19

Initial Setup ............................................. 19

Setting the programmes ............................ 20

Auto Scan ................................................ 20

Update Scan ............................................ 21

Single RF Scan ........................................ 21

Favorite Network Select ......................... 21

Analogue Manual Scan .......................... 21

Channel Skip ........................................... 22

Channel Sort ........................................... 23

Channel Edit ........................................... 23

Channel Decode ...................................... 23

Analogue Channel Fine Tune ................ 24

Clean Channel List ................................. 24

Common Interface .................................. 24

Reset TV .................................................. 24

Automatic Power Down .......................... 24

General controls ......................................... 25

Selecting programme positions ............ 25

Time Display ............................................ 25

Stereo and Bilingual transmissions ...... 25

Quick Access Menu ................................ 25

Sound controls ........................................... 25

Volume ..................................................... 25

Balance, Bass, Treble ............................. 25

Surround Sound...................................... 26

Stable Sound

Bass Boost .............................................. 26

Bass Boost Level .................................... 26

Audio Description ................................... 26

Visually Impaired .................................... 26

Advanced Audio Settings ...................... 27

Widescreen viewing ................................... 28

Picture controls .......................................... 30

Picture Mode ........................................... 30

Brightness, Contrast, Colour and Tint .. 30

Sharpness .............................................. 30

Back Light Adjustment ........................... 30

Colour Temperature ................................ 30

Cinema Mode .......................................... 31

DNR .......................................................... 31

MPEG NR ................................................. 31

CTI ............................................................ 31

Adaptive Luma Control .......................... 32

Active Backlight ...................................... 32

Blue Screen ............................................. 32

3D Colour Management .......................... 32

Base Colour Adjustment ........................ 32

HDMI RGB Range .................................... 33

H./V. Position ........................................... 33

VGA .......................................................... 33

Timer control ............................................... 34

Time Zone ................................................ 34

Country Region ID ................................. 34

Time ......................................................... 34

Sleep Timer ............................................. 35

Input selection and AV connections ......... 35

Input selection ........................................ 35

Input signal selection ............................. 36

® ....................................26

REGZA-LINK Controls ................................ 36

Equipment Control.................................. 36

Input Source Selection ........................... 37

Pass-Through Control ............................ 37

REGZA-LINK Menus ................................... 38

One Touch Play ....................................... 38

System Standby ...................................... 38

System Audio Control ............................ 38

PC Link .................................................... 38

Enable REGZA-LINK ............................... 38

TV Auto Power On .................................. 38

Auto Standby .......................................... 39

Amplier Control .................................... 39

Speaker Preference ................................ 39

Media Player ................................................ 39

Enter Media Player .................................. 39

Photo Multi-View ..................................... 40

Playing Photo Slideshow ....................... 40

Viewing Music Files ................................ 41

Playing Music .......................................... 41

Preference control ...................................... 42

Analogue Subtitle ................................... 42

Digital Subtitle ......................................... 42

Subtitle Type ............................................ 42

Audio Languages .................................... 42

Audio Channel ........................................ 43

Auto Format ............................................ 43

4:3 Stretch ............................................... 43

Side Panel Adjustment ........................... 43

Game Mode ............................................. 43

Parental control .......................................... 44

Channel Block ........................................ 44

Programme Block ................................... 44

Input Block .............................................. 45

Change Password ................................... 45

Panel Lock ............................................... 46

Factory Default ........................................ 46

Digital on-screen information and

programme guide ....................................... 46

Information .............................................. 46

Guide ........................................................ 47

EPG Timer ................................................ 47

Software upgrade and system

information.... .............................................. 47

Auto Download........................................ 47

Auto Install .............................................. 47

Manual OAD ............................................ 48

System Information ................................ 48

Text services ............................................... 49

Setting the Language ............................. 49

Text Information ...................................... 49

Control Buttons....................................... 49

Questions and Answers ............................. 50

Specications and accessories ................ 52

License Information used with Toshiba

Televisions .................................................. 53

Exhibit A ................................................... 54

Exhibit B .................................................. 54

Notes ............................................................ 56

Safety Precautions

This equipment has been designed and manufactured to meet international safety standards but, like any electrical equipment, care must be taken to obtain the best results and for safety to be assured. Please read the points below for your own safety. They are of a general nature, intended to help with all electronic consumer products and some points may not apply to the goods you have just purchased.

Air Circulation

Leave more than 10cm clearance around the television to allow adequate ventilation. This will prevent overheating and possible damage to the television. Dusty places should also be avoided.

Heat Damage

Damage may occur if the television is left in direct sunlight or near a heater. Avoid places subject to extremely high temperatures or humidity. Place in a location where the temperature remains between 5°C (41°F) min. and 35°C (94°F) max.

Mains Supply

The mains supply required for this equipment is 220-240V ˜, 50/60Hz. Never connect to a DC supply or any other power source. DO ensure that the television is not standing on the mains lead. Use only the supplied lead.

DO NOT cut off the mains plug from this equipment, this incorporates a special Radio Interference Filter, the removal of which will impair

its performance. In the UK, the fuse tted in this

plug is approved by ASTA or BSI to BS1362. It should only be replaced by a correctly rated

and approved type and the fuse cover must be

retted.

IF IN DOUBT PLEASE CONSULT A COMPETENT ELECTRICIAN.

DO read the operating instructions before you attempt to use the equipment.

DO ensure that all electrical connections (including the mains plug, extension leads and inter-connections between pieces of equipment) are properly made and in accordance with the manufacturers’ instructions. Switch off and withdraw the mains plug before making or changing connections.

DO consult your dealer if you are ever in doubt about the installation, operation or safety of your equipment.

SETTING UP

DO be careful with glass panels on equipment.

DO NOT REMOVE ANY FIXED COVERS AS THIS WILL EXPOSE DANGEROUS AND 'LIVE' PARTS.

THE MAINS PLUG IS USED AS A DISCONNECTING DEVICE AND THEREFORE SHOULD BE READILY OPERABLE.

Do not

DO NOT obstruct the ventilation openings of the equipment with items such as newspapers, tablecloths, curtains, etc. Overheating will cause damage and shorten the life of the equipment.

DO NOT allow electrical equipment to be

exposed to dripping or splashing or objects lled

with liquids, such as vases, to be placed on the equipment.

DO NOT place hot objects or naked ame

sources, such as lighted candles or nightlights on, or close to equipment. High temperatures can

melt plastic and lead to res.

DO NOT use makeshift stands and NEVER

x legs with wood screws. To ensure complete safety, always t the manufacturers’ approved stand, bracket or legs with the xings provided

according to the instructions.

DO NOT leave equipment switched on when it

is unattended, unless it is specically stated that

it is designed for unattended operation or has a standby mode. Switch off by withdrawing the plug, make sure your family know how to do this. Special arrangements may need to be made for people with disabilities.

DO NOT continue to operate the equipment if you are in any doubt about it working normally, or it is damaged in any way – switch off, withdraw the mains plug and consult your dealer.

WARNING – excessive sound pressure from earphones or headphones can cause hearing loss.

ABOVE ALL – NEVER let anyone, especially children, push or hit the screen, push anything into holes, slots or any other openings in the case.

NEVER guess or take chances with electrical equipment of any kind – it is better to be safe than sorry.

English

SETTING UP

Sturdy tie

Hook

Top View

Side View

English

Installation and important information

Where to install

Locate the television away from direct sunlight and strong lights, soft, indirect lighting is recommended for comfortable viewing. Use curtains or blinds to prevent direct sunlight falling on the screen. Place the TV set on a stable, level surface that can support the weight of the TV. As an additional safety measure you can secure the TV to the level surface or a wall, as shown in the illustration, using a sturdy strap. The LCD display panels are manufactured using an extremely high level of precision technology, however sometimes some parts of the screen may be missing picture elements or have luminous spots. This is not a sign of a malfunction. Make sure the television is located in a position where it cannot be pushed or hit by objects, as pressure will break or damage the screen, and that small items cannot be inserted into slots or openings in the case.

Wall mounting of the TV should only be performed by qualied servicing personnel. Use only with the wall mount bracket specied by the manufacturer.

Please take note

EXCLUSION CLAUSE

Toshiba shall under no circumstances be liable for loss and/or damage to the product caused by:

i) re;

ii) earthquake;

iii) accidental damage;

iv) intentional misuse of the product;

v) use of the product in improper conditions;

vi) loss and/or damage caused to the product while in the possession of a third party;

vii) any damage or loss caused as a result of the owner’s failure and/or neglect to follow the

instructions set out in the owner’s manual;

viii) any loss or damage caused directly as a result of misuse or malfunction of the product when

used simultaneously with associated equipment;

Furthermore, under no circumstances shall Toshiba be liable for any consequential loss and/or

damage including but not limited to the following, loss of prot, interruption of business, the loss of

recorded data whether caused during normal operation or misuse of the product.

• The digital reception function of this television is only effective in the countries listed in the "Country" section of the "SETUP" menu. Depending on country/area, some of this television's functions may not be

available. Reception of future additional or modied services can not be guaranteed with this television.

• If stationary images generated by 4:3 broadcasts, text services, channel identication logos, computer

displays, video games, on-screen menus, etc. are left on the television screen for any length of time they could become conspicuous, it is always advisable to reduce both the brightness and contrast settings.

• Very long, continuous use of the 4:3 picture on a 16:9 screen may result in some retention of the image at the 4:3 outlines, this is not a defect of the LCD TV and is not covered under the manufacturers warranty. Regular use of other size modes (eg: Superlive) and varying the “side panel” brightness (if available on the model) will prevent permanent retention.

SYMBOL SYMBOL DEFINITION

DANGEROUS VOLTAGE:

within an equilateral triangle is intended to alert the user to the presence of un-insulated "DANGEROUS VOLTAGE" within the product's enclosure that

may be of sufcient magnitude to constitute a risk of electric shock to persons.

The lightning ash with arrowhead symbol

SETTING UP

English

INSTRUCTIONS:

to alert the user to the presence of important operating and maintenance (servicing) instruction in the literature accompanying the appliance.

WARNING:

ames away from this product at all times.

The exclamation point within on equilateral triangle

To prevent the spread of fire, keep candles or other open

SETTING UP

English

The remote control

Simple at-a-glance reference of your remote control.

14 16

3 4

5 6

9 12

13 15

17 19

1 For On/Standby mode 2 To select input from external sources 3 Still Picture 4 To call up text services in analogue mode

and interactive services in digital mode 5 To turn the subtitle On/Off 6 Stereo/Bilingual transmissions 7 Number buttons 8 Switch the Audio Description On/Off 9 To toggle between ATV and DTV mode 10 To alter the volume 11 To change programme 12 In TV mode: To display on-screen information In Text mode: To access index page 13 To mute the sound 14 To display Quick access menu 15 To exit menus 16 To display the programme guide 17 To return to the previous level of the on-

screen menu 18 To display the on-screen menu 19 ▲, ▼, ◄, ►: To move up, down, left or right

in the on-screen menu

OK: To conrm the selection

20 Colour button: Text control buttons

To reveal concealed text To hold a wanted page To enlarge text display size

In normal picture mode: To

display clock on TV screen In Teletext mode: To toggle between Teletext and normal picture mode

Inserting batteries and effective range of the remote

Remove the back cover to reveal the battery compartment and make sure the batteries are inserted the right way round. Suitable battery types for this remote are AAA, IEC R03 1.5V.

Do not combine a used, old battery with a new one or mix battery types. Remove dead batteries immediately to prevent acid from leaking into the battery compartment. Dispose of them in accordance with instructions on page 56 of this manual. Warning: batteries must not be exposed

to excessive heat such as sunshine, re or the

like.

The performance of the remote control will deteriorate beyond a distance of ten meters or outside an angle of 30 degrees from the center of the television. If the operating range becomes reduced the batteries may need replacing.

SETTING UP

English

SETTING UP

English

Connecting external equipment

Before connecting any external equipment, turn off all main power switches. If there is no switch remove the mains plug from the wall socket. Connect the power cord into the AC-IN socket found at the back of the TV.

Model 19/22

*a decoder could

be Digital Satellite or any other compatible decoder.

AC-IN

RGB/PC

media recorder

decoder*

PC/HDMI 1

(AUDIO)

Model 26/32/40

be Digital Satellite or any other compatible decoder.

media recorder

*a decoder could

AC-IN

decoder*

Digital Audio

(1)

NOTE: SCART can support Canal+ decoder.

NOTE: SCART1 : (INPUT/TV OUT) SCART2 : (INPUT/TV OUT)

(1)

(2)

NOTE: SCART1 can support Canal+ decoder.

SETTING UP

Aerial cables: - - - - - - - - - - - - - - - - -

Connect the aerial to the ANT socket on the rear of the television. If you use a decoder and/or a media recorder, it is essential that the aerial cable is connected through the aerial socket on the decoder and/ or on the media recorder to the TV.

SCART leads: - - - - - - - - - - - - - - - - -

Connect the video recorder IN/OUT or decoder TV socket to the television. Connect the media recorder SAT socket to the decoder MEDIA REC. socket.

Before running Auto Scan put your decoder and media recorder to Standby.

The phono sockets alongside the VIDEO INPUT socket will accept L and R audio signals. These sockets are located on the side of the TV. (See page 17.)

SPDIF (Optical Digital Audio Out) When a digital audio signal is associated with the input selected for viewing, the digital audio will be available on this SPDIF connection to your home theater system.

(High-Denition Multimedia Interface) is for use with a DVD, decoder or electrical equipment

HDMI

with digital audio and video output. It is designed for best performance with 1080p high-denition video

signals but will also accept and display VGA, SVGA, XGA, WXGA, SXGA, 480i, 480p, 576i, 576p, and 720p signals.

NOTE: Although this television is able to connect to HDMI equipment it is possible that some equipment may not operate correctly.

REGZA-LINK controls the basic functions of connected audio/video equipment using the television's remote control.

A wide variety of external equipment can be connected to the back of the television, therefore the relevant owner's manuals for all additional equipment must be referred to.

If the television automatically switches over to monitor external equipment, return to normal television by pressing the desired programme position button. To recall external equipment, press

HDMI, the HDMI Logo, and High-Denition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC in the

United States and other countries.

to select.

English

SETTING UP

English

REGZA-LINK Connections

The basic functions of connected audio/video equipment can be controlled using the television's remote control if a REGZA-LINK compatible device is connected.

Model 19/22

The back of your television

AV amplifier

HDMI outHDMI in

Playback equipment

HDMI out

Playback equipment

HDMI out

Model 26/32/40

The back of your television

AV amplifier

HDMI outHDMI in

Playback equipment

HDMI out

Playback equipment

HDMI out

NOTE 1: It is recommended that for correct operation all audio/video devices are connected using HDMI cables branded with the HDMI logo ( ). If several devices are connected, the REGZALINK feature may not operate properly. After connecting the equipment use the REGZA-LINK menus

to setup the desired options. The connected equipment must also be set. For details see the operation

manual for each connected device.

NOTE 2: The REGZA-LINK feature uses CEC Technology as regulated by the HDMI standard. This feature is limited to models incorporating Toshiba’s REGZA-LINK. However,Toshiba is not liable for those operations. Refer to individual instruction manuals for compatibility information.

SETTING UP

Connecting an HDMI® or DVI device to the HDMI input

The HDMI input on your television receives digital audio and uncompressed digital video from an HDMI source device, or uncompressed digital video from a DVI (Digital Visual Interface) source device. This input is designed to accept HDCP (High-Bandwidth Digital- Content Protection) programme material in digital form from EIA/CEA-861-D–compliant [1] consumer electronic devices (such as a set-top box or DVD player with HDMI or DVI output). For acceptable video signal formats, see page 16.

NOTE:

• Some early HDMI equipment may not work properly with your latest HDMI TV, due to the adoption

of a new standard.

• Supported Audio format: Linear PCM, sampling rate 32/44.1/48kHz.

To connect an HDMI device

Connect an HDMI cable (type A connector) to the HDMI terminal.

For proper operation, it is recommended that you use an HDMI cable with the HDMI Logo (

• HDMI cable transfers both video and audio. Separate analogue audio cables are not required (see

illustration).

Model 19/22

English

HDMI device

HDMI cable

HDMI out

(not supplied)

SETTING UP

English

Model 26/32/40

HDMI device

To view the HDMI device video, press

to select the mode.

HDMI out

HDMI cable

(not supplied)

SETTING UP

DVI device to the HDMI Input

Connect an HDMI-to-DVI adapter cable (HDMI type A connector) to HDMI1 terminal and audio cables to the PC/HDMI1 Audio socket (see illustration).

• The recommended HDMI-to-DVI adapter cable length is 6.6 ft (2m).

An HDMI-to-DVI adapter cable transfers video only.

• Separate analogue audio cables are required.

Model 19/22

English

Audio cable for HDMI to television connection (not supplied)

HDMI-to-DVI adapter cable

DVI device

PC/HDMI 1

(AUDIO)

(not supplied)

SETTING UP

English

Model 26/32/40

PC/HDMI 1

(AUDIO)

Audio cable for HDMI to television connection (not supplied)

HDMI-to-DVI adapter cable

DVI device

NOTE:

o ensure that the HDMI or DVI device is reset properly, it is recommended that you follow these

procedures:

• When turning on your electronic components, turn on the television first, and then the HDMI or

DVI device.

• When turning off your electronic components, turn off the HDMI or DVI device first, and then the

television.

[1] EIA/CEA-861-D compliance covers the transmission of uncompressed digital video with high-

bandwidth digital content protection, which is being standardized for reception of high-denition video

signals. Because this is an evolving technology, it is possible that some devices may not operate properly with the television.

HHDMI, the HDMI Logo, and High-Denition Multimedia Interface are trademarks or registered

trademarks of HDMI Licensing LLC in the United States and other countries.

(not supplied)

SETTING UP

PC/HDMI 1

(AUDIO)

Computer

the back of your television

HDMI-to-DVI adapter cable (not supplied)

Audio cable for PC to television connection (not supplied)

Connecting a computer

With the HDMI connection, you can watch your computer’s display on the television and hear the sound from the televisions speakers.

To connect a PC to the HDMI terminal

When connecting a PC to the HDMI terminal on the television, use an HDMI-to-DVI adapter cable and analogue audio cables. If connecting a PC with an HDMI terminal, use an HDMI cable (type A connector). Separate analogue cables are not necessary (see page 11).

Model 19/22

the back of your television

English

Computer

HDMI-to-DVI adapter cable (not supplied)

Audio cable for PC to television connection (not supplied)

PC/HDMI 1

(AUDIO)

Model 26/32/40

For acceptable PC signal formats, see “Acceptable PC signals through HDMI/D-SUB terminals” on page 16.

SETTING UP

Acceptable Video signals through HDMI terminals

English

Format Resolution Refresh Rate H. Frequency Pixel Clock

VGA 640 x 480 60.000Hz 31.500kHz 25.200MHz

59.940Hz 31.469kHz 25.175MHz

72.809Hz 37.861kHz 31.500MHz

75.000Hz 37.500kHz 31.500MHz

480i 720 x 480 60.000Hz 15.750kHz 27.000MHz

59.940Hz 15.734kHz 27.000MHz

576i 720 x 576 50.000Hz 15.625kHz 27.000MHz

480p 720 x 480 60.000Hz 31.500kHz 27.027MHz

59.940Hz 31.469kHz 27.000MHz

576p 720 x 576 50.000Hz 31.250kHz 27.000MHz

720p 1280 x 720 60.000Hz 45.000kHz 74.250MHz

59.940Hz 44.955kHz 74.176MHz

50.000Hz 37.500kHz 74.250MHz

1080i 1920 x 1080 60.000Hz 33.750kHz 74.250MHz

59.940Hz 33.716kHz 74.176MHz

50.000Hz 28.125kHz 74.250MHz

1080p 1920 x 1080 60.000Hz 67.500kHz 148.500MHz

59.940Hz 67.433kHz 148.352MHz

50.000Hz 56.250kHz 148.500MHz

24.000Hz 27.000kHz 74.250MHz

23.976Hz 26.975kHz 74.176MHz

Acceptable PC signals through HDMI/D-SUB terminals

Format Resolution Refresh Rate H. Frequency Pixel Clock

VGA

(for D-Sub only)

SVGA 800 x 600 56.250Hz 35.156kHz 36.000MHz

XGA 1024 x 768 60.004Hz 48.363kHz 65.000MHz

WXGA 1280 x 768 59.995Hz 47.396kHz 68.250MHz

SXGA 1280 x 1024 60.020Hz 63.981kHz 108.000MHz

HDMI, the HDMI Logo, and High-Denition Multimedia Interface are trademarks or registered trademarks of HDMI

Licensing LLC in the United States and other countries

NOTE 1: The PC input signals are supported by the "HDMI 1" socket only. The "HDMI 2" and "HDMI 3" ("HDMI 3" is for model 32/40KV73*G only) do not support PC signal.

NOTE 2: Only a supported PC signal will show the correct resolution on the TV display.

640 x 480 59.940Hz 31.469kHz 25.175MHz

72.809Hz 37.861kHz 31.500MHz

75.000Hz 37.500kHz 31.500MHz

60.317Hz 37.879kHz 40.000MHz

72.188Hz 48.077kHz 50.000MHz

75.000Hz 46.875kHz 49.500MHz

70.069Hz 56.476kHz 75.000MHz

75.029Hz 60.023kHz 78.750MHz

59.870Hz 47.776kHz 79.500MHz

74.893Hz 60.289kHz 102.250MHz

1360 x 768 60.015Hz 47.712kHz 85.500MHz

75.025Hz 79.976kHz 135.000MHz

SETTING UP

Using the controls

While all the necessary adjustments and controls for the television are done using the remote control, the buttons on the television may be used for some functions.

NOTE: COMMON INTERFACE (CI)

The common interface is for a Conditional Access Module (CAM). Contact a service provider for details.

Model 19/22

DVB COMMON INTERFACE

VIDEO INPUT

Headphone

CI Card

Video

USB

AUDIO

(2)

VIDEO

USB

Power

Programme up

Programme down

Volume up

Volume down

Input

English

Model 26/32/40

VIDEO INPUT

Headphone

The “HDMI 3” port is available for model 32/40KV73*G only.

CI Card

Video

USB

HDMI 3

GREEN LED - On Timer/EPG Timer On

DVB COMMON INTERFACE

AUDIO

(3)

VIDEO

USB

GREEN LED - On Timer/EPG Timer On

HDMI 3

IR SENSOR

RED LED - Standby GREEN LED - Power on

IR SENSOR

RED LED - Standby GREEN LED - Power on

Power

Programme up

Programme down

Volume up

Volume down

Input

SETTING UP

English

Before switching on the television, make sure to connect the aerial cable, and select TV as the input source.

If the RED LED is off, check that the mains plug is connected to the power supply. If the picture does not appear, press

To put the television into Standby mode, press again. The picture may take a few seconds to appear.

on the remote control, it may take a few seconds to appear.

Switching on

on the remote control. To view the picture, press

Using the remote control

To set up the television, you need to use the on-screen menus. Press on the remote control to see the menus.

The on-screen menu appears as a list of ve topics. As each symbol is selected by pressing ◄ or ►on the navigation ring on the remote control, its respective options will appear below.

To use the options, press  or  on the navigation ring to move up and down through them and use

, ◄ or ► to select the required choice. Follow the on-screen instructions. The functions of each

menu are described in detail throughout the manual.

Using the side-panel controls

To alter the volume, press – +.

To alter the programme position press  P .

Press MENU and

To select the external input, press selected as described on page 35.

Please always refer to the owner’s manual of the equipment to be connected for full details.

, , or to control the sound and picture options. Press MENU to nish.

to move through the list until the appropriate input source is

Tuning the television

menu can also be accessed at any

Before switching on the television, put your decoder and media recorder to Standby if they are connected.

Make sure to connect the aerial cable, and select TV as the input source.

To set up the television, press the buttons on the remote control as detailed on page 6.

Initial Setup

Connect the television to the main power

and press the

screen will appear at the rst use.

Press to start the initial setup.

Initial Setup

Welcome to the initial setup wizard.

Please press [OK] to start the wizard.

Press ▲ or ▼ to select your language, and

then press ►.

Initial Setup

Please select your language:

button. The Initial Setup

Welcome

Language

English

Español Français Deutsch

Italiano

Ελληνικά

Български

TUNING THE TELEVISION

Press ▲ or ▼ to select your country and

press ► to the next step.

Initial Setup

Please select your country:

Back Select Next

Country

United Kingdom

Italy

Netherlands

Sweden

Bulgaria

Greece Russia

EXIT

Exit

To start channel scan, press ►.

Initial Setup

First, please connect antenna. Start channel scan now ? If you skip this step, the channel scan can be performed in the TV Menu.

Back Select Next

Channel Scan

Scan

Skip Scan

EXIT

Exit

The search will begin for all available stations. The slide bar will move along the line as the search progresses.

The initial setup is now complete. Press

to exit the wizard.

Initial Setup

Congratulations!!

Initial Setup Complete.

Please press [OK] to exit the wizard.

Complete

English

Back Select Next Exit

EXIT

Press ▲ or ▼ to select between Home or

Store mode (for normal home use, select Home), and then press ►.

If Home mode is selected, the Standard picture mode will be selected

Initial Setup

To use this TV for displaying in a retail showroom, please select [Store].

[Home] mode is recommended for normal home use.

Back Select Next Exit

Engrgy Saving Mode

Home

Store

EXIT

Back Select Next Exit

EXIT

NOTE 1: If you skip this step, the channel scan can be performed in the TV Menu.

NOTE 2: The time will be set automatically using the broadcaster data but can be advanced or

decreased by from -12 to +13 hours using Time Zone in Time Setup. (See page 34)

PLEASE NOTE

The Factory Default time in the Parental control from the SETUP menu.

TUNING THE TELEVISION

English

Setting the programmes

NOTE: When Channel Block is activated the 4-digit password is needed to enter the Channels

submenu under SETUP menu.

Auto Scan

The Auto Scan will completely re-tune the television and can be used to update the channel list.

It is recommended that Auto Scan is run periodically to ensure that all new services are added.

NOTE: All the current programmes and settings

i.e. the locked programmes, will be lost.

Press MENU and press ◄ or ► to select

SETUP.

SETUP

Enter

SETUP

United Kingdom

English

Home

English

Home

EXIT

Select Back Exit

United Kingdom

Country

OSD Language

Channels

Automatic Power Down

Location

Software Upgrade

Parental

Reset TV

OK RETURN

Press ▼ to highlight Country and press ◄

or ► to select.

NOTE: In order to receive the information from

the broadcaster correctly, please set the correct country.

Press ▼ to highlight OSD Language and

press ◄ or ► to select.

Press ▼ to highlight Channels and press

► or

to enter.

Country

OSD Language

Channels

Automatic Power Down

Location

Software Upgrade

Parental

Reset TV

Select Auto Scan and press .

Auto Scan

Update Scan

Analogue Manual Scan

Favorite Network Select

Channel Skip

Channel Sort

Channel Edit

Channel Decode

Analogue Channel Fine Tune

Clean Channel List

Channels

OK RETURN

Scan

Select Back Exit

EXIT

Press Cancel for no change, or press to

enter Auto start screen.

Previous settings will be lost ! Press Cancel for

no change, Press OK to start Auto scan.

OK Cancel

For Country option of Finland, Germany,

Switzerland, Norway, Sweden or Others,

the Scan Mode option will be available if the Tuner Mode in SETUP menu is set to Cable.

• Scan Mode: The options are Full, Quick,

and Advance. The Quick scan is a simplified version of the Full scan designed to complete in less time, and is available for Country option of Finland or Others only.

Scan All Channels.

Scan Mode

Start Frequency (KHz)

End Frequency (KHz) 362000

Modulation

Symbol Rate (Ksym/s)

Network ID

Scan

Auto Scan

Advance

362000

Auto

6900

100

Select

EXIT

Exit

NOTE: The options Start Frequency, End Frequency, Modulation, Symbol Rate, and Network ID is available for Advance mode only.

Press ▲ or ▼ to highlight Scan and press

► or

to start scanning. Press RETURN

to cancel, or press EXIT to stop scanning.

OK RETURN

Enter

Select Back Exit

EXIT

TUNING THE TELEVISION

English

Update Scan

Search the new channels that are not in the programme list.

Press MENU and press ◄ or ► to select

SETUP.

Press ▼ to highlight Channels and press

► or

Select Update Scan and press to start

scanning.

Update Scan

Status: Scanning..

Digital Channels: 0 Analogue Channels: 0

EXITRETURN

Cancel Exit

NOTE: This option is available for DVB_T only.

Single RF Scan

Scan single RF channels. You can check the Signal Strength and the Signal Quality.

Select Channels from the SETUP menu.

Highlight Single RF Scan and press ► or

to enter.

Press ◄ and ► to select the RF Channel,

then press

to start scanning.

Favorite Network Select

If there are more than two networks detected after running the Auto Scan in Channels menu, you can select the network you prefer.

Select Channels from the SETUP menu.

Highlight Favorite Network Select and

press ► or

Auto Scan

Update Scan

Single RF Scan

Favorite Network Select

Channel Skip

Channel Sort

Channel Edit

Clean Channel List

Press ▲ or ▼ to select the network you

prefer, and then press

Please select your favorite network:

NOTE: This feature is available only for the Country option of Norway, and with DVB_T

input source.

to enter.

Channels

OK RETURN

Select Back Exit

Enter

Favorite Network Select

Oslo og Akershus

to set.

TVBS Network

Select

EXIT

Exit

Single RF Scan

Scan single RF channel. (Digital Only)

Start Frequency (KHz)

Modulation

Symbol Rate (Ksym/s)

Signal Strength

Auto

474000

6875

EXITOK RETURN

BackScan Exit

NOTE: This option is available for DVB_C and DVB_T only.

Analogue Manual Scan

The television can be tuned-in manually using Analogue Manual Scan. For example: if the television cannot be connected to a media recorder/decoder with a SCART lead or to tune-in a station on another System.

Press MENU and press ◄ or ► to select

SETUP.

Press ▼ to highlight Channels and press

► or

TUNING THE TELEVISION

Select Analogue Manual Scan and press

English

► or to conrm it.

Auto Scan

Update Scan

Analogue Manual Scan

Favorite Nework Select

Channel Skip

Channel Sort

Channel Edit

Channel Decode

Analogue Channel Fine Tune

Clean Channel List

Press number buttons 0~9 to enter the

Channels

OK RETURN

Enter

Select Back Exit

Start Frequency. Press ▲ or ▼ to select

Scan Up or Scan Down and press ► or

to start scan. Press to stop scanning.

Analogue Manual Scan

Search for analogue channels

Start Frequency (MHz) 45.00

Scan Up

Scan Down

Channel Skip

To prevent certain programmes from being viewed, the programme position can be skipped. The remote control must be removed as the channels will still be available using the number buttons. Programmes can then be watched as normal using the controls on the television, but the television will not show the skipped programme position.

EXIT

In the SETUP menu, press ▼ to highlight

Channels and press ► or

SETUP

Enter

United Kingdom

Select Back Exit

Country

OSD Language

Channels

Automatic Power Down

Location

Software Upgrade

Parental

Reset TV

OK RETURN

English

Home

to enter.

EXIT

Press ▼ to highlight Channel Skip and

press ► or

to enter.

Scan Up

EXITRETURN

Back Exit

NOTE: This option is available for Analogue TV

mode only.

Auto Scan

Update Scan

Analogue Manual Scan

Favorite Nework Select

Channel Skip

Channel Sort

Channel Edit

Channel Decode

Analogue Channel Fine Tune

Clean Channel List

Channels

OK RETURN

Enter

Select Back Exit

EXIT

Press ▲ or ▼ to select the channels you

want to skip, then press

1 Analogue BBC1

Channel Skip

OK RETURN

Set

to set.

Select Back Exit

EXIT

The Skipped programme positions cannot be selected by pressing P and P or by the controls on the television, but can still be accessed by the number buttons on the remote control.

TUNING THE TELEVISION

English

Channel Sort

Change the order of the programme list.

Select Channels from the SETUP menu.

Highlight Channel Sort and press ► or

to enter.

Press ▲ or ▼ to select the rst channel

you want for sorting and then press

mark it. Press ▲ or ▼ again to select the

second channel and then press

to swap

their positions.

1 Analogue BBC1

2 Analogue -----

3 Analogue -----

4 Analogue -----

5 Analogue -----

6 Analogue -----

7 Analogue -----

8 Analogue -----

9 Analogue -----

Channel Sort

OK RETURN

Select Back Exit

Set

EXIT

Channel Edit

Edit the channel number and channel name.

Select Channels from the SETUP menu.

Highlight Channel Edit and press ► or

to enter.

Press ▲ or ▼ to highlight the channel you

want for editing and press "Channel Edit" screen.

Edit the Channel Number by pressing the

number buttons 0~9. Edit the Channel Name by pressing the number buttons 0~9

to enter numbers and letters.

Network Name:

Channel Number:

Channel Name:

Frequency

Colour system

Sound system

Channel Edit

Auto

D/K

-----

175.25

to enter the

The number buttons on the remote control have the following characters assigned to them. Use the language characters to enter text. Repeatedly pressing the numbered key changes the text

character, pressing ◄ deletes the previous text

character.

Number Character

1 A B C 1 2 D E F 2 3 G H I 3 4 J K L 4 5 M N O 5 6 P Q R 6 7 S T U 7 8 V W X 8 9 Y Z 9 0 + - . 0

Channel Decode

Channel Decode support the Canal+ (paid

television channel); however, the channel also

broadcast some un-encrypted programmes. These programmes without encryption can be viewed free of charge.

Select Channels from the SETUP menu.

Highlight Channel Decode and press ► or

to enter.

Press ▲or ▼ to highlight the channel and

press

to set.

Channel Decode

BBC1

Analogue

NOTE: This option is available for Analogue TV

mode only.

RTP1

Analogue

-----

Analogue

-----

Analogue

-----

Analogue

-----

Analogue

-----

Analogue

-----

Analogue

-----

Analogue

-----

Analogue

OK RETURN

Set

Select Back Exit

EXIT

OK RETURN

Select Back Exit

Set

EXIT

NOTE: The option Frequency, Colour system, and Sound system is available for Analogue TV mode only.

CONTROLS AND FEATURES

English

Analogue Channel Fine Tune

When the reception is poor, you can use this

function to do the ne tuning.

In the SETUP menu, press ▼ to highlight

Channels and press ► or

to enter.

Press ▼ to highlight Analogue Channel

Fine Tune and press

to enter.

Highlight and press to select the

channel.

Press ◄ or ► to adjust the frequency.

Press ◄ to decrease and ► to increase

the frequency.

Common Interface

This function enables you to watch some pay services (encrypted services). When the module is inserted into the CI slot, you can access the module menu. To purchase a module and smart card, contact your dealer. Common Interface functions may not be possible depending upon the country broadcasting circumstances.

Press MENU and press ◄ or ► to select

APPLICATIONS.

Press ▼ to highlight Common Interface

and press ► or

Press to select the CI card to view the

Module information.

Analogue Channel Fine Tune

BBC 1

RTP1

-----

10 -----

175.25 MHz

687.25 MHz

55.85 MHz

209.25 MHz

223.2 MHz

572.3 MHz

590.25 MHz

623.25 MHz

759.2 MHz

772.2 MHz

BackSelectAdjust

EXITRETURN

Exit

Clean Channel List

This feature cleans all the TV channels while your channel list is not empty.

In the SETUP menu, press ▼ to highlight

Channels and press ► or

Press ▼ to highlight Clean Channel List

and press ► or

Auto Scan

Update Scan

Single RF Scan

Favorite Network Select

Channel Skip

Channel Sort

Channel Edit

Clean Channel List

to enter.

Channels

OK RETURN

Enter

Select Back Exit

to enter.

EXIT

Reset TV

Selecting Reset TV will reset all TV settings to their original factory values, excludes Country, OSD Language, and Channels.

In the SETUP menu, press ▼ to highlight

Reset TV and press ► or

to enter.

Select OK to conrm or select Cancel to

exit.

Automatic Power Down

The TV will automatically turn itself off (standby) after approximately 4 hours, if you do not touch the control buttons on the remote control or on the TV control panel.

In the SETUP menu, press ▼ to highlight

Automatic Power Down.

Press ◄ or ► to select On or Off.

The Clean Channel List screen appears.

Press

to clean now.

Previous settings will be lost ! Press Cancel for no

change. Press OK to continue.

OK Cancel

CONTROLS AND FEATURES

English

General controls

Selecting programme

positions

To select a programme position, press the numbered buttons on remote control.

The programme positions can also be selected by pressing P

To display on-screen information, i.e. programme position, input mode, or stereo/mono signal, press

The time display facility allows the current (text service) time to be seen on the television screen.

Press a normal television broadcast to see the time display from the broadcaster. It will remain on screen for about 5 seconds.

NOTE: This option is available for Analogue TV

mode only and may not be available in some cases.

Stereo and Bilingual

If the stereo or dual language broadcasts are transmitted, the icon appear on the screen each time the programme positions are changed, and will disappear after a few seconds. If the broadcast is not in stereo, the icon

Stereo… Press Bilingual… Bilingual transmissions are rare. If

they are transmitted, the icon display. Choose the required programme number. If the Dual1, Dual2, or Mono.

and P .

. Press it again to cancel.

Time Display

on the remote control while watching

transmissions

Stereo or Dual will

Mono will appear.

to select Stereo or Mono.

Dual will

Dual appears, press to select

Quick Access Menu

Quick access menu helps you access some options quickly, such as Picture Mode, Picture Size, Sleep, REGZA-LINK, and Media Player. Press QUICK button to display the Quick access

menu and press ▲ or ▼ to select the option.

Quick access

Picture Mode

Picture Size

Sleep

REGZA-LINK

Media Player

Standard

Wide

Off

Sound controls

Volume

Press

Sound Mute

Press to cancel.

or to adjust the volume.

once to turn the sound off, press again

Balance, Bass, Treble

Press MENU and ◄ or ► to select

SOUND.

Balance

Bass

Treble

Surround Sound

Stable Sound

Bass Boost

Bass Boost Level

Audio Description

Visually Impaired

Advanced Audio

Press ▼ to highlight Balance, Bass or

Treble. Press ◄ or ► to change the

setting.

SOUND

Off

Normal

OK RETURN

Enter

Select Back Exit

EXIT

CONTROLS AND FEATURES

English

This function enriches (expanding and deepening) the sound quality.

Stable Sound reduces the volume level differences between channels. It automatically remains on the same volume level when you change channels.

Surround Sound

In the SOUND menu, press ▼ to select

Surround Sound.

Press ◄ or ► to switch function On or Off.

Stable Sound

In the SOUND menu, press ▼ to select

Stable Sound.

Press ◄ or ► to switch function On or Off.

Bass Boost

Bass Boost enhances the depth of the sound on the TV speakers. The difference will only be noticeable on sound with strong bass.

In the SOUND menu, press ▼ to highlight

Bass Boost.

Press ◄ or ► to switch function On or

Off.

NOTE: The Surround Sound and Bass Boost

functions are available for the sound from the TV's built-in speakers only.

Bass Boost Level

After setting the Bass Boost to On in the SOUND menu, you can adjust its level.

In the SOUND menu, press ▼ to highlight

Bass Boost Level.

Press ◄ or ► to change the setting.

Audio Description

Audio Description is an additional narration describing on-screen action, body language, expressions and movements for people with visual disabilities while watching the TV. This function enables you to choose the type of narrations.

Press MENU and press ◄ or ► to select

SOUND.

Press ▼ to highlight Audio Description

and press ◄ or ► to select Normal, Hard

of Hearing, and Visually Impaired.

NOTE: Press AD button on the remote control to switch the Audio Description On or Off.

Hard of Hearing: This function provides narration to deaf and hard of hearing viewers.

Visually Impaired: This function provides descriptive narration of key visual elements -

making television programmes, feature lms,

home video and other visual media accessible to people who are visually blind or visually impaired.

Visually Impaired

When the Audio Description is set to “Visually Impaired”, you can adjust the volume of the

Audio Description.

Press MENU and press ◄ or ► to select

SOUND.

Press ▼ to highlight Audio Description

and use ◄ or ► to select Visually Impaired.

Press ▼ to highlight Visually Impaired

and press ► or

to enter.

Make sure the Speaker Out option is set

to On. Press ▼ to highlight Volume option, and press ◄ or ► to adjust the volume.

CONTROLS AND FEATURES

English

Speaker Out On

Visually Impaired

Select Back Exit

20Volume

EXITRETURN

Advanced Audio Settings

The Advanced Audio settings help to create an enhanced surround sound experience with deep, rich bass from stereo sound sources. Your TV’s audio will sound fuller, richer, and wider.

Highlight the Advanced Audio in the SOUND

menu and press ► or

Audio settings.

PC / HDMI1 Audio

HDMI1 Audio

Lip Sync

SPDIF Type

• PC/HDMI1 Audio: Receive sound from a

connected PC.

• HDMI1 Audio: If the connected HDMI source

does not support digital audio, plug the audio cable into PC/HDMI1 (Audio) on the back of the TV, then use the HDMI1 Audio setting. If the sound is missing, select an alternative setting.

• Lip Sync: Activates an audio/video display

timing adjustment that allows HDMI devices to automatically synchronize accurately. Available for HDMI source only.

• SPDIF Type: Sends digital audio signal to

the external audio system. The options are PCM, Dolby Digital, or Off.

to enter the Advanced

Advanced Audio

Auto

PCM

Select Back Exit

EXITRETURN

Manufactured under licence from Dolby

Laboratories.

"Dolby" and the double-D symbol are trademarks of Dolby Laboratories.

CONTROLS AND FEATURES

4:3

Use this setting to view a true 4:3

broadcast.

Wide

Use this setting when watching a

widescreen DVD, widescreen video tape

or a 16:9 broadcast (when available). Due

to the range of widescreen formats (16:9, 14:9, 20:9 etc.) black bars may be visible

on the top and bottom of the screen.

Cinema

When watching "all sides panel format"

films/video tapes, this setting will eliminate

or reduce the black bars at all sides of the screen

by zooming in and selecting the image without distortion.

Native

This setting will enlarge a 4:3 image to

fit the screen by stretching the image

horizontally and vertically, holding better

proportions at the center of the image.

Some distortion may occur.

Super Live

This setting is available when

watching video signal source via HDMI,

and will show the picture without over scan.

Subtitle

When subtitles are included on a letterbox

format broadcast, this setting will raise

the picture to ensure that all the text is

displayed.

English

Widescreen viewing

Depending on the type of broadcast being transmitted, programmes can be viewed in a number of formats.

CONTROLS AND FEATURES

English

14:9

PC Wide

PC Normal

Dot by Dot

Use this setting when watching a 14:9

Use this setting for PC connected via

HDMI or RGB/PC terminal when receiving

PC signal format. This setting will display

Use this setting for PC connected via

HDMI or RGB/PC terminal when receiving

PC signal format. This setting will display

the image correctly without distortion or

“Dot by Dot” is a non-scaling display.

Depending on the input signal format,

the picture is displayed with side panels

broadcast.

the image without picture clipping.

picture clipping.

and/or bars at the top and bottom

(i.e. VGA input source).

Press QUICK to display the Quick access menu and press  or  to select the Picture Size and press .

Quick access

Picture Mode

Picture Size

Sleep

REGZA-LINK

Media Player

Standard

Wide

Off

You can choose the picture size from Wide, Cinema, 4:3, Super Live, Subtitle, 14:9, Native, PC Wide, PC Normal, and Dot by Dot.

Using the special functions to change the size of the displayed image (i.e. changing the height/width ratio) for the purposes of public display or commercial gain may infringe on copyright laws.

Available Picture Size

Screen Mode SD (up to 480p) HD (up to 1080p) PC Mode

Wide Yes Yes No

4:3 Yes Yes No

Super Live Yes No No

Cinema Yes No No Subtitle Yes No No

14:9 Yes No No

Native Yes(only in HDMI) Yes(only in HDMI) No

PC Wide No No Yes

PC Normal No No Yes

Dot by Dot No No Yes

CONTROLS AND FEATURES

English

Picture controls

Picture Mode

You can adjust the best picture appearance by selecting the preset value in picture mode based on the programme category.

Press MENU and press ◄ or ► to select

PICTURE.

Press ▼ to highlight Picture Mode and

press ◄ or ► to select Store, Dynamic,

Standard, Movie, PC, or User.

Picture Mode Standard

Brightness

Contrast

Colour

Tint

Sharpness

Picture Size

Colour Temperature

Advanced Video


Wide

OK RETURN

Enter

Select Back Exit

100

100Back Light

EXIT

NOTE: The Store mode is available only when the Location in SETUP menu is set to Store.

Brightness, Contrast, Colour

and Tint

Back Light Adjustment

Adjusting the Back Light can improve the clarity of the screen when viewing.

Press MENU and press ◄ or ► to select

PICTURE.

Press ▼ to highlight Back Light and press

◄ or ► to adjust.

Picture Mode Standard

Brightness

Contrast

Colour

Tint

Sharpness

Back Light

Picture Size

Colour Temperature

Advanced Video


Wide

OK RETURN

Adjust

Select Back Exit

100

EXIT

Colour Temperature

Colour Temperature increases the ‘warmth’ or ‘coolness’ of a picture by increasing the red or blue tint.

In the PICTURE menu, press ▼ to highlight

Colour Temperature and press ► or

enter.

In the PICTURE menu, press ▼ to select

Brightness, Contrast, Colour or Tint.

Press ◄ or ► to adjust your preference.

Sharpness

This function increase or decrease the sharpness of the picture. The picture shows the clear edge when you increase the values.

In the PICTURE menu, press ▼ to select

Sharpness.

Press ◄ or ► to adjust your preference.

Picture Mode Standard

Brightness

Contrast

Colour

Tint

Sharpness

Picture Size

Colour Temperature

Advanced Video


Wide

OK RETURN

Enter

Select Back Exit

100

100Back Light

EXIT

CONTROLS AND FEATURES

English

Press ◄ or ► to select Cool, Medium,

Warm or User to suit your preference.

Colour Temperature User

R Gain

G Gain

B Gain

Colour Temperature

Select Back Exit

EXITRETURN

NOTE: R/G/B Gain: Increase or decrease the red/green/blue levels in the picture.

Cinema Mode

The frame rate of a movie lm is generally 24

frames a second whereas the movie software such as DVD, etc. that you enjoy watching on television at home is 30 or 25 frames a second.

The difference in frame rate may cause ickers while viewing the lms on television; set the

Cinema Mode to convert the signal to reproduce a smooth motion and picture quality.

In the PICTURE menu, press ▼ to

highlight Advanced Video and press ► to enter.

Press ▼ to highlight Cinema Mode, and

press ◄ or ► select from On or Off.

Press ▲ or ▼ to highlight NR and press ►

to enter.

Press ▲ or ▼ to highlight DNR and press

◄ or ► to select Low, Middle, High, Auto or Off.

DNR

MPEG NR

Auto

Low

Select Back Exit

EXITRETURN

MPEG NR

If the receiving signal of MPEG has a grained noise depending on the compression and conversion, the noise may be reduced when using this function.

In the PICTURE menu, press ▲ or ▼ to

highlight Advanced Video and press ► or

to enter.

Press ▲ or ▼ to highlight NR and press

► or

to enter.

Select the MPEG NR and press ◄ or ► to

select Low, Middle, High, or Off.

CTI

Adaptive Luma Control

Blue Screen

3D Colour Management

Base Colour Adjustment

Advanced Video

OnCinema Mode

Auto

OnActive Backlight

Off

Select Back Exit

EXITRETURN

DNR

DNR (Digital Noise Reduction) enables you to ‘soften’ the screen representation of a weak signal to reduce the noise effect.

In the PICTURE menu, press ▼ to

highlight Advanced Video and press ► or

to enter.

DNR

MPEG NR

Auto

Low

Select Back Exit

EXITRETURN

CTI

The Colour Transient Improvement (CTI) involves the detection and sharpening of edges around colour objects on the screen.

In the PICTURE menu, press ▼ to

highlight Advanced Video and press ► or

to enter.

Select the CTI, and press◄ or ► to select

Auto or Off.

CONTROLS AND FEATURES

English

Adaptive Luma Control

Automatically adjusts the brightness and contrast after analyzing the input signal. This function enriches the colours and the depth of the picture.

In the PICTURE menu, press ▼ to

highlight Advanced Video and press ► or

to enter.

Press ▼ to highlight Adaptive Luma

Control and press ◄ or ► to adjust your

preference.

Active Backlight

When Active Backlight control is activated, it will automatically optimise the backlighting levels for dark scenes.

In the PICTURE menu, press ▼ to

highlight Advanced Video and press ► to enter.

Press ▼ to highlight Active Backlight and

press ◄ or ► to select On or Off.

Blue Screen

When Blue Screen is selected, the screen will turn blue and the sound will be muted when no signal is received.

In the PICTURE menu, press ▼ to

highlight Advanced Video and press ► or

to enter

Press ▼ to highlight Blue Screen and press

◄ or ► to select On or Off.

3D Colour Management

When 3D Colour Management is selected, it allows the ‘Base Colour Adjustment’ feature to become available.

In the PICTURE menu, press ▲ or ▼ to

highlight Advanced Video and press ► or

to enter.

Press ▲ or ▼ to highlight 3D Colour

Management.

CTI

Adaptive Luma Control

Blue Screen

3D Colour Management

Base Colour Adjustment

Advanced Video

OnCinema Mode

Auto

OnActive Backlight

Off

Select Back Exit

EXITRETURN

Press ◄ or ► to select On or Off.

Base Colour Adjustment

The Base Colour Adjustment feature allows the adjustment of individual colours to suit personal preference. This can be useful when using an external source. It only can be adjusted when Colour Management is set to On.

Highlight Advanced Video in the

PICTURE menu. Press ▲ or ▼ to highlight 3D Colour Management and press ◄ or ► to select On.

CTI

Adaptive Luma Control

Blue Screen

3D Colour Management

Base Colour Adjustment

Advanced Video

Auto

OnCinema Mode

OnActive Backlight

Off

Select Back Exit

EXITRETURN

CONTROLS AND FEATURES

English

Press ▲ or ▼ to highlight Base Colour

Adjustment and then press ► or

CTI

Adaptive Luma Control

Blue Screen

3D Colour Management

Base Colour Adjustment

Enter

Advanced Video

OnCinema Mode

Auto

OnActive Backlight

Off

Select Back Exit

EXITRETURN

Press ▲ or ▼ to select an option, then

press

to enter the adjustment setting

window.

Base Colour Adjustment

Red

Green

Blue

Yellow

Magenta

Cyan

Reset

Press ◄ or ► to select Hue, Saturation,

Hue

OK RETURN

Enter

Brightness

Saturation

0 0 0

Select Back Exit

EXIT

or Brightness, then press ▲ or ▼ to adjust the settings as required.

NOTE: To return to the original factory settings,

select Reset and press

HDMI RGB Range

Adjusts RGB full range signal automatically. When Limit is selected the RGB signal’s output range is 16 to 235. When Full is selected the RGB signal’s output range is 0 to 255.

In the PICTURE menu, press ▲ or ▼ to

highlight Advanced Video and press ► or

to enter.

Press ▲ or ▼ to highlight HDMI RGB

Range and press ◄ or ► to select Auto, Full, or Limit.

NOTE: If the HDMI connection is capable of 1080p and/or the television is capable of refresh rates greater than 50Hz or supports Deep Colour, a Category 2 cable will be required. Conventional HDMI/DVI cables may not work properly with this

mode.

H./V. Position

Adjust the horizontal and vertical position of the picture.

In the PICTURE menu, press ▲ or ▼ to

highlight Advanced Video and press ► or

to enter.

Press ▼ to highlight H./V. Position and

press ► or

H.Position

V.Position

to enter.

H./V. Position

SelectAdjust

EXITRETURN

Back Exit

Press ▲ or ▼ to select H. Position or V.

Position and press◄ or ► to adjust.

NOTE: For PC input, V. Position adjustment is not linear. In another words, when you adjust

V. Position, the OSD value will change by 2 or

greater value depending TV's calibration process.

VGA

The VGA adjustment is available only when the input source is PC and your TV is receiving a computer signal.

In the PICTURE menu, press ▼ to

highlight VGA and press ► or

Select Auto Adjust for automatic adjusting,

or press ◄ or ► to manually adjust the

H.Position, V.Position, Phase, or Clock.

Auto Adjust

H.Position

V.Position

Phase

Clock

VGA

OK RETURN

Enter

Select Back Exit

127

EXIT

to enter.

-1

CONTROLS AND FEATURES

English

Timer control

Time Zone

When you select a Time Zone, the TV time is set by the time offset information based on Time Zone and GMT (Greenwich Mean Time) which is received with the broadcast signal and the time is set automatically by a digital signal.

Highlight the Time Setup in the

APPLICATIONS menu and press ► or to select Time Zone.

Time Zone

Country Region ID

Time

Time Setup

As Broadcaster

Country Region 1

Select Back Exit

EXITRETURN

Press ◄ or ► to select your viewing area

or “As Broadcaster".

Country Region ID

This option is only available for Country option of

Spain or Portugal and Time Zone is set to As Broadcaster.

Time

The time is set automatically when receiving a digital signal. (You can set the time manually only if the TV has no DTV signal.)

You must set the time correctly before using Power On/Off Timer function.

Highlight the Time Setup in the

APPLICATIONS menu and press ► or

to enter.

Press ◄ or ► to set the Auto

Synchronization On/Off.

Auto Synchronization On

Date

Time

Timer Off

Power On Timer

Power Off Timer

Time

2011/01/01

19:22:30

00:00:00

Select Back Exit

EXITRETURN

If you set the Auto Synchronization Off,

you can set the Date and Time manually

by pressing ▲, ▼, ◄ and ► to select

position, and pressing the number buttons

0~9 to enter the gures.

Press ▲, ▼, ◄ and ► to select the Power

On/Off Timer.

Auto Synchronization On

Date

Time

Timer Both On

Power On Timer

Power Off Timer

Time

2011/01/01

19:22:30

00:00:00

Select Back Exit

EXITRETURN

The Power On Timer function switches the TV on automatically at a preset time.

The Power Off Timer function switches the TV off automatically at a preset time.

CONTROLS AND FEATURES

Main

1 2

3C HDMI 1 HDMI 2 PC

English

Sleep Timer

The television can be set to turn itself Off automatically after a preset time.

Press ▼ to highlight Sleep Timer in the

APPLICATIONS menu.

Press ◄ or ► to set the timer from Off, 10,

20, 30, 40, 50, 60, 90 or 120 Minutes.

Media Player

Time Setup

Sleep Timer

Common Interface

NOTE: To cancel the Sleep Timer, select Off in above setting.

APPLICATIONS

Select Back Exit

Off

EXITRETURN

Input selection and AV connections

Dening the INPUT and OUTPUT sockets so that

the television recognises connected equipment.

See page 8 for a clear view of the back connection recommendations.

Most media recorders and decoders send a signal through the SCART lead to switch the television to the correct Input socket.

Alternatively press the external source selection button equipment is shown.

Use the input selection if the television does not switch over automatically.

until the picture from connected

Input selection

Press . A list will appear on screen

showing all stored external equipment.

Press ▲ and ▼to highlight and

select.

Model 19/22

Model 26/32/40

Main

1 2

3 HDMI 1 HDMI 2 HDMI 3 PC

NOTE: The "HDMI 3" port is available for model 32/40KV73*G only.

displays equipment connected to Input

HDMI HDMI on the back or side of the television. It is designed for best performance with 1080p high

denition signals.

CONTROLS AND FEATURES

English

Input signal selection

This species the type of signal going into SCART

on the back of the television. Please refer to the manufacturers instructions for the connected equipment.

In the SETUP menu, press ▼ to highlight

SCART, then press ► or

OSD Language

SCART

Automatic Power Down

Location

Software Upgrade

Parental

Reset TV

SETUP

OK RETURN

Enter

Select Back Exit

English

Home

to enter.

EXIT

Model 19/22:

Press ◄ or ► to select Auto, Mixed, RGB, Composite, or S-Video.

SCART Auto

SCART

Select Back Exit

EXITRETURN

Model 26/32/40:

• Press ▲ or ▼ to select SCART 1 and press ◄ or ► to select Auto, Mixed, RGB,

Composite, or S-Video.

• Press ▲ or ▼ to select SCRAT 2 and press ◄ or ► to select Auto, Composite,

or S-Video.

REGZA-LINK Controls

This feature uses CEC (Consumer Electronics Control) technology, and allows the control of Toshiba REGZA-LINK compatible equipment from the television’s remote control.

NOTE: Not all Toshiba products currently support REGZA-LINK.

Equipment Control

The REGZA-LINK mode on the television’s remote control allows the control of connected REGZA-LINK equipment being watched.

To control the REGZA-LINK input source, rst select the equipment with REGZA-LINK input source selection, then switch the mode on the remote control to REGZA-LINK and press any buttons.

The available functions are dependent on the equipment connected. Not all the remote control keys may be available. Please refer to the operation manual for each piece of equipment connected.

NOTE: The television features that can be

controlled by the connected equipment are: Standby, Volume, Channel, Sound Mute, Display

Information, Number Buttons and Previous

Programme.

SCART 1

SCART 2

SCART

Auto

Select Back Exit

EXITRETURN

Check the signal output of the DVD or compatible device, please select the correct setting for “SCART input”.

CONTROLS AND FEATURES

English

Input Source Selection

When any equipment using CEC technology is connected, the REGZA-LINK icon will appear in the input source list allowing selection of individual devices.

Press . A list will appear on screen

showing modes and all stored external equipment.

Main

1 2

3 HDMI 1 HDMI 2 HDMI 3 PC

NOTE: The "HDMI 3" port is available for model 32/40KV73*G only.

The REGZA-LINK icon appears

automatically after detected with REGZALINK compatible equipment. Press ▼ to highlight the input source shown with the REGZA-LINK icon.

Hlavní

REGZA-LINK

HDMI 1

HDMI 2 HDMI 3 PC

Press ►. A second selection screen will

appear showing all connected REGZA- LINK equipment.

Press ▲ or ▼ to highlight an input source,

and then press

to select.

The following features are dependent on the connected equipment. For operating information, refer to the operation manual for all connected equipment.

Pass-Through Control

The Pass-Through feature allows you to control the connected REGZA-LINK device by the television’s remote control.

Press ▲ or ▼ to select REGZA-LINK in

the Quick Access Menu, and then press OK. The control panel will appear.

When there are two or more REGZA-LINK devices connected to the television, a device selection menu will appear. Highlight the device you want to control, and then

to select.

press

GUIDE EXIT

CONTENTSROOT TOP DVD

Press the key on the television’s remote

control as guided by the control panel shown.

NOTE: The available functions are dependent on the connected equipment, not all the remote functions may be available. Please refer to the

operation manual of the connected equipment.

RETURN

NOTE 1: When the television is switched on,

it will take a few minutes for the REGZA-LINK icon to appear in the list, when an HDMI cable is

removed, it will take a few minutes for the logo to

disappear.

NOTE 2: If the HDMI cable from the connected

equipment is changed, or HDMI equipment settings are changed, the Enable REGZA-LINK in the REGZA-LINK setup menu may need to be reset to On.

NOTE 3: When the REGZA-LINK input source is selected, some REGZA-LINK equipment may automatically switch on.

CONTROLS AND FEATURES

English

REGZA-LINK Menus

By activating the Enable REGZA-LINK feature in the REGZA-LINK setup menu, individual REGZA-LINK features can then be activated.

One Touch Play

The function of REGZA-LINK will automatically power on the television that was in standby mode and switch the television’s input source to the port connected with the audio/video equipment by powering-on or playing from the audio/video equipment.

NOTE: This feature is dependent on the

connected equipment and television setting.

System Standby

This feature automatically switches the connected equipment into standby when the television goes into standby and conversely for the television to switch into standby when connected equipment goes into standby. It is selected in the REGZA- LINK setup menu.

NOTE: This feature is dependent on the

connected equipment and television setting.

System Audio Control

PC Link

This feature automatically adjusts the suitable widescreen formats and picture preferences when connected to a REGZA-LINK PC.

NOTE: This feature is dependent on the

connected equipment.

Enable REGZA-LINK

When the Enable REGZA-LINK is set to On, it allows the other functions to be enabled.

In the PREFERENCES menu, press ▼

to select REGZA-LINK Setup, and then

press ► or

REGZA-LINK Setup

Teletext

Audio Channel

Auto Format

4:3 Stretch

Side Panel

Game Mode

Press ▼ to highlight Enable REGZA-

LINK, then press ◄ or ► to select On or Off.

PREFERENCES

Stereo

Off

OK RETURN

Enter

Select Back Exit

EXIT

Using the Speaker Preference feature allows the televisions remote control to adjust the volume or mute the sound of the speakers connected to the

television via an AV amplier.

Ensure that the connected AV amplier and

REGZA-LINK equipment are selected in the input source selection and that the Speaker

Preference is set to Amplier in the REGZALINK setup menu.

NOTE: When the AV Amplier is switched on, its

input source changed or the volume adjusted,

the sound will be output from the AV Amplier’s speakers even if TV Speakers has been selected. Turn the television off then on again to output the sound from the TV’s speakers.

The full function may not work and is dependent on the Amplier being used.

Enable REGZA-LINK

Auto Power On

Auto Standby

Amplifier Control

Speaker Preference

REGZA-LINK Setup

Amplifier

Select Back Exit

EXITRETURN

TV Auto Power On

The Auto Power On setting allows the television to be automatically switched On or Off if a REGZA-LINK device is turned On or Off.

In the REGZA-LINK Setup menu, press

▼ to highlight Auto Power On.

Press ◄ or ► to select On or Off.

CONTROLS AND FEATURES

English

Auto Standby

When the Auto Standby is enabled, switching off the television will automatically switch off all connected REGZA-LINK equipment.

In the REGZA-LINK Setup menu, press

▼ to highlight Auto Standby.

Press ◄ or ► to select On or Off.

Amplier Control

When Amplier Control is enabled REGZALINK allows some of the amplier features to be

controlled with the television remote control.

In the REGZA-LINK Setup menu, press▼

to highlight Amplier Control.

Press ◄ or ► to select On or Off.

Speaker Preference

This feature allows the audio output preference

to be set to the TV speakers or AV amplier speakers. The AV Amplier option lets the

televisions remote control adjust or mute the volume of the audio.

In the REGZA-LINK Setup menu, press

▼ to highlight Speaker Preference.

Press ◄ or ► to select TV Speakers or

Amplier.

Media Player

Enter Media Player

The Media Player allows the viewing of photos

(JPEG les) and music (MP3 les) stored in

a USB storage device. (Connectivity is not guaranteed for all devices.)

To open Media Player, highlight the Media

Player in the APPLICATIONS menu and press ► or

Media Player

Time Setup

Sleep Timer

Common Interface

Press ▲ or ▼ to highlight Photo or Music,

then press You may also use the Quick Access Menu to enter.

Media Player


Music

NOTE 1: The Media Player will open even if there are no images on the USB ash drive.

NOTE 2: On-screen menus will not display while the Media Player is being used.

NOTE 3: MP3 is the MPEG Layer-3 audio coding technology licensed from Fraunhofer IIS and

Thomson.

APPLICATIONS

Off

Select Back Exit

EXITRETURN

, the Media Player will open.

CONTROLS AND FEATURES

English

Photo Multi-View

This view mode allows all the images within a selected folder to be viewed simultaneously, using thumbnail views in a grid. The initial highlighted position will be the top left image within the grid.

Open Media Player. Press ▲, ▼, ◄, or

► to select a folder then press

. All the images in the folder will appear in the Multi View grid.

Photo100MSDCF DSC00166.J... 2048:1536 01/02

DSC0016 ...

Size Sort BrowserMenu

Press ▲, ▼, ◄, or ► to move through

the images. If there are too many images

for the screen, pressing ◄ on the top left

image will show the previous page moving the highlight to the bottom right image.

Alternatively, pressing ► on the bottom

right image will show the next page moving the highlight to the top left image.

If there is more than one page of images within the folder pressing P

and P

will move through the pages.

Press RETURN to leave the current folder.

Press EXIT to return to the last viewed source.

• Menu: Enter menu option. The options are:

Sort, Media Type, and Thumbnail Size.

• Size: Decides to show the Multi View by

Small, Middle, or Large thumbnail size.

• Sort: Decides to sort the photo files by File

Date or Name.

• Browser/Menu: Decides to browse photos

by thumbnail or list mode.

Playing Photo Slideshow

This view mode displays all the images in a selected folder as a slideshow, scrolling through them automatically.

In the Multi View grid, press ▲, ▼, ◄,

or ► to highlight an image. Press

Slideshow will now display all the images in the selected folder.

Pressing P and P will display next or

previous images. The images can also be rotated and their information displayed.

Press EXIT to return to the last viewed

source.

• Menu: Select the playing method. The

options are: Pause, Repeat, Shuffle, Duration, Effect, and Show Info.

• Duration/Rotate: While in play mode, press

to select the duration to play next one. The options are: Short, Medium, and Long. While in pause mode, press to rotate the still photo.

• Effect/Zoom: While in play mode, press to

select the playing effect: The options are:

None, Dissolve, Wipe right, Wipe left, Wipe up, and Wipe down. While in pause mode, press to Zoom the still photo by 1X, 2X, or 4X size.

• Pause/Play: Press to pause while in play

mode. Press to play while in pause mode

CONTROLS AND FEATURES

Media Player


Music

MusicAlan.Parsons... 01 - A Dream... 00:04:14 01/02

01 - A Dr ...

Size Sort BrowserMenu

English

Viewing Music Files

This view mode allows all the music les within a

selected folder to be viewed simultaneously, using thumbnail views in a grid. The initial highlighted position will be the top left image within the grid.

Open Media Player. Press ▼ to highlight

Music.

In Media Player, press ▲, ▼, ◄, or ► to

select a folder then press

les in the folder will appear in the Multi

View grid.

Press ▲, ▼, ◄, or ► to move through the

music les. If there are too many music les for the screen, pressing ◄ on the top left le will show the previous page moving the highlight to the bottom right le. Alternatively, pressing ► on the bottom right le will show the next page moving the highlight to the top left le.

If there is more than one page of images within the folder pressing P move through the pages.

Press RETURN to leave the current folder.

Press EXIT to return to the last viewed source.

• Menu: Enter menu option. The options are:

Sort, Media Type, and Thumbnail Size.

• Size: Decides to show the thumbnail size by

Small, Middle, or Large.

• Sort: Decides to sort the music files by

Name, Genre, Artist, or Album.

• Browser/Menu: Decides to browse music

files by thumbnail or list mode.

. All the music

and P will

Playing Music

The Music feature plays MP3 les stored on a

USB storage device.

In the Multi View grid, press ▲, ▼, ◄, or

► to highlight a music le. Press playing all the music les in the selected

folder.

Press to pause, press it again to play.

Press EXIT to return to the last viewed source

NOTE 1: While playing the music les, you may select the playing methods among Repeat, Shufe, Audio Only, or display the music le Info.

NOTE 2: MP3 is the MPEG Layer-3 audio coding

technology licensed from Fraunhofer IIS and

Thomson

to start

CONTROLS AND FEATURES

English

Preference control

Analogue Subtitle

You can set the subtitle on or off while watching TV.

Highlight Subtitle in the PREFERENCES

menu, and press ► or

REGZA-LINK Setup

Teletext

Subtitle

Audio Channel

Auto Format

4:3 Stretch

Side Panel 1

PREFERENCES

OK RETURN

Enter

Press ▲ or ▼ to select the Analogue

Subtitle and press ◄ or ► to select On, Mute, or Off.

Analogue Subtitle

Digital Subtitle Language

Digital Subtitle Language 2nd

Subtitle Type Normal

Subtitle

to enter.

Stereo

Off

English

EXIT

Select Back Exit

Digital Subtitle

Use the Digital Subtitle function when two or more subtitle languages are broadcasted. If subtitle data in a selected language is not broadcasted, the default language subtitle will be displayed.

Highlight Subtitle in the PREFERENCES

menu, and press ► or

to enter.

Press ▲ or ▼ to select the Digital Subtitle

Language or Digital Subtitle Language 2nd and press ◄ or ► to select the

language.

NOTE: If the language in the Digital Subtitle Language is not available, the Digital Subtitle Language 2nd will be displayed.

Subtitle Type

You can choose the Subtitle Type from Normal or Hearing Impaired. If the "Hearing Impaired" is selected, it provides subtitle services to deaf and hard of hearing viewers with additional descriptions.

Highlight Subtitle in the PREFERENCES

menu, and press ► or

Press ▲ or ▼ to select the Subtitle Type

and press ◄ or ► to select Normal or

Hearing Impaired.

to enter.

Select Back Exit

EXITRETURN

NOTE: When Analogue Subtitle is selected to “Mute”, the analogue subtitle will be displayed on

the screen but the speaker muted simultaneously.

Audio Languages

This feature allows a programme or lm to be

viewed with a choice of soundtrack language, provided they are currently being broadcast.

In the PREFERENCES menu, press ▼

to highlight Audio Language or Audio Language 2nd.

Press ◄ or ► to select an option.

NOTE: The option V.O. is only available when the Country in the SETUP menu is set to France.

CONTROLS AND FEATURES

English

Audio Channel

If stereo or dual language broadcasts are transmitted, the word Stereo or Dual will appear on the screen each time the programme positions are changed, and then disappear after a few seconds. If the broadcast is not in stereo, the word Mono will appear.

In the PREFERENCES menu, press ▼ to

highlight Audio Channel.

Press ◄ or ► to select Stereo, Dual1,

Dual2, or Mono.

Auto Format

When the television receives a true Widescreen picture and Auto Format is On, it will automatically be displayed in Widescreen format, irrespective of the television’s previous setting

In the PREFERENCES menu, press ▼ to

highlight Audio Format.

Press ◄ or ► to select On or Off.

4:3 Stretch

If the 4:3 stretch is On, the picture size will auto stretch to 4:3 aspect ratio in Widescreen format.

Highlight 4:3 Stretch in the PREFERENCES menu, and press ◄ or ► to select On or Off.

NOTE: 4:3 Stretch is only activated when Auto Format is set to On.

Game Mode

The Game Mode helps to speed up video response for game application.

the PREFERENCES menu, press ▼ to

highlight Game Mode.

Press ◄ or ► to select On or Off.

Side Panel Adjustment

The Side Panel feature lightens or darkens the band each side of the screen when in 4:3 or 14:9 format. This helps prevent image retention of the band and can also make viewing in bright or dark conditions more comfortable.

In the PREFERENCES menu, press ▼ to

highlight Side Panel.

Press ◄ or ► to select 1, 2, or 3.

NOTE: This function is not available in DTV

mode.

CONTROLS AND FEATURES

English

Parental control

This function blocks channels or programmes that you do not want to or that you do not want your children to watch. A password is required to access this function. The factory default password is “0000”.

NOTE: When Channel Block, Programme Block and Input Block are activated, you will need to enter the 4-digit password before you enter the Channels submenu under the SETUP. After auto scan, all the channel blocks will be cleared.

Channel Block

This function blocks channels that you do not want to or that you do not want your children to watch.

Highlight Parental in the SETUP menu,

and press ► or

Country

OSD Language

Channels

Automatic Power Down

Location

Software Upgrade

Parental

Reset TV

Enter the 4-digit password.

Password

to enter.

SETUP

United Kingdom

English

Home

OK RETURN

Enter

Parental

Select Back Exit

EXIT

EXITRETURN

Back Exit

Press ▼ to highlight the Channel Block

and press ► or

Channel Block

Programme Block

Input Block

Change Password

Panel Lock

Factory Default

Press ▼ to highlight the channels you want

to block, then press

Digital

to enter.

Parental

OK RETURN

Enter

Select Back Exit

to set.

Channel Block

TF1

TV4 Stockholm

TMC

NT1

NRJ12

TV4 Film

TV4 Fakta

PARIS PREMIERE

OK RETURN

Select Back Exit

Set

Off

EXIT

Programme Block

This function prevents children from watching certain TV programmes, according to the rating limit set.

This function operates according to information from the broadcasting station. Therefore if the signal has no information, this function does not operate.

Highlight the Parental in the SETUP menu,

and press ► or

Enter the 4-digit password.

Press ▼ to highlight the Programme

Block and press ► or

to enter.

Channel Block

Programme Block

Input Block

Change Password

Panel Lock

Factory Default

Parental

OK RETURN

Enter

Select Back Exit

Off

EXIT

CONTROLS AND FEATURES

English

Press ◄ or ► to set the Age Rating

from age 4~18 or select None to turn this function off.

Age Rating None

Programme Block

Select Back Exit

EXITRETURN

NOTE: This function is available for the

programme with Age Rating information.

Input Block

This function can disable the specic external

input signals.

Highlight Parental in the SETUP menu,

and press ► or

Enter the 4-digit password.

Press ▼ to highlight the Input Block and

press ► or

SCART

Component

HDMI 1

HDMI 2

Press ▲ or ▼ to highlight the input that you

want to disable and press

Model 19/22

to enter.

Input Block

to enter.

EXITRETURN

BackSelectSet

to lock.

Exit

Model 26/32/40

Input Block

SCART 1

SCART 2

Component

HDMI 1

HDMI 2

HDMI 3

EXITRETURN

BackSelectSet

Exit

NOTE: The "HDMI 3" port is available for model 32/40KV73*G only.

Change Password

Change the 4-digit parental control password. The default password is 0000.

Highlight Parental in the SETUP menu,

and press ► or to enter.

Enter the 4-digit password.

Press ▲ or ▼ to highlight the Change

Password and press ► or to enter.

Channel Block

Programme Block

Input Block

Change Password

Panel Lock

Factory Default

Enter the 4-digit new password, and

re-enter the new password again to

conrm.

New Password

Confirm Password

Parental

Off

OK RETURN

Select Back Exit

Enter

Change Password

EXIT

Input Block

SCART

Component

HDMI 1

HDMI 2

EXITRETURN

BackSelectSet

Exit

EXITRETURN

Back Exit

CONTROLS AND FEATURES

English

Panel Lock

You can lock the control buttons on your TV by using this Panel Lock. When this function enables, the TV can be controlled only by the remote control.

Highlight Parental in the SETUP menu,

and press ► or

to enter.

Enter the 4-digit password.

Press ▼ to highlight the Panel Lock and

press ◄ or ► to switch the function On or Off.

Channel Block

Programme Block

Input Block

Change Password

Panel Lock

Factory Default

Parental

Off

Select Back Exit

EXITRETURN

NOTE: When the Panel Lock is set to “On”, TV

can be turned off by pressing the power keys on

the TV or the remote control, but can be turned on only by the remote control.

Factory Default

Selecting Factory Default will reset all TV settings, including stored channels, to their original factory values.

Highlight Parental in the SETUP menu,

and press ► or

Enter the 4-digit password.

Press ▼ to highlight the Factory Default

and press ► or

Previous settings will be lost ! Press Cancel for no

to enter.

to select.

change. Press OK to continue.

OK Cancel

Digital on-screen information and programme guide

The on-screen information and programme guide give access to programme details for all available channels.

Information

Press , the information screen will

appear giving details of the programme and event currently being viewed.

1 2

1 Channel Title

D+

English

Current Programme Title

Now

Next Programme Title

SD AD 1816:9 Entertainment 8 mins left

Display current programme information ......

Change

10 11 12

1 Service type

2 Skip

3 Channel block

4 Signal strength

5 Current time and date

6 Audio information

7 Current programme and time

8 Next programme and time

9 Event information

10 Current programme information

11 Change between Now and Next

programme list

12 Exit the information screen

Press again to close the information

screen.

EXIT

3 4 5

Exit

10:52 Fri, 10 April

10:00 - 11:00

11:00 - 11:45

CONTROLS AND FEATURES

English

Guide

Select the on-screen guide by pressing

GUIDE, the guide screen will appear highlighting details of the programme and event currently being viewed. This may take a few moments to appear.

Press ◄ or ► for information on other

events scheduled for the programme selected.

For details of other programmes currently

available, press ▲ and ▼ to scroll up and

down the programme list.

NOTE: For the recording operation to work

properly, the media recorder must be set to the

same time as the TV. Regarding the process for recording, please refer to the owner's manual of

the recording equipment.

EPG Timer

EPG (Electronic Programme Guide) supports 8 sets of timers. You can set or cancel a timer for a selected programme within the guide. When the TV is on and the timer activates, a dialogue box is shown informing you that the programme is about to start. When the TV is in standby mode and the timer activates, the TV will wake up with backlight off, speaker mute on, and change to the channel selected.

You must set the time correctly before using this function. All set timers are cleared when performing a new channel scan.

Software upgrade and system information

Auto Download

This feature enables your TV to download new software by air automatically.

In the SETUP menu, press ▼ to highlight

Software Upgrade and press ► or

enter.

Press ▼ to highlight Auto Download.

Press ◄ or ► to select On or Off.

Auto Download

Manual OAD

System Information

Software Upgrade

Select Back Exit

Off

OffAuto Install

EXITRETURN

Auto Install

This feature enables your TV to install new software automatically.

In the SETUP menu, press ▼ to highlight

Software Upgrade and press ► or

enter.

Press ▼ to highlight Auto Install.

Press ◄ or ► to select On or Off.

Press button to set/unset Timer in the

selected programme.

An indicator will be shown in the detail

information area when a timer function is set..

Press BLUE button to enter the

programme timer list page.

NOTE: Time can be set manually in the Menu/ Timer/Time OSD menu.

After adjustment, the TV clock may not match the time in the EPG Programme Guide. The EPG Programme Guide time follows the broadcast

stream time which can not be adjusted.

Auto Download

Auto Install

Manual OAD

System Information

Software Upgrade

Select Back Exit

Off

EXITRETURN

CONTROLS AND FEATURES

English

Manual OAD

This feature enables upgrading your TV software by air manually.

In the SETUP menu, press ▼ to highlight

Software Upgrade and press ► or

enter.

Press ▼ to highlight Manual OAD and

press ► or

Auto Download

Manual OAD

System Information

to enter.

Software Upgrade

Select Back Exit

Off

OffAuto Install

EXITRETURN

The Over-Air Download screen appears.

Follow the on-screen instruction to complete the software upgrade.

Over-Air Download

Scanning.

Cancel

Exit

System Information

This feature can be used to check the version of software currently installed.

In the SETUP menu, press ▼ to highlight

Software Upgrade and press ► or

enter.

Press ▼ to highlight System Information.

Auto Download

Auto Install

Manual OAD

System Information

Software Upgrade

Off

SelectEnter

EXITRETURN

Back Exit

Press ► or to display the system

information.

Service Page

TOSHIBA

2010

Signal Strength 100

Signal Quality Good

V1.19B 20100203

EXITRETURN

Back Exit

NOTE: In DTV mode, this service page includes

additional diagnostic information, such as signal strength, signal quality, center frequency,

modulation, etc.

TEXT SERVICES

English

Text services

This television has a multi-page text memory, which takes a few moments to load.

Setting the Language

You can set the teletext language.

In the PREFERENCES menu, press ▼ to

highlight Teletext, then press ► or

conrm.

REGZA-LINK Setup

Teletext

Subtitle

Audio Channel

Auto Format

4:3 Stretch

Side Panel

Press ▲ and ▼ to select the options,

and then press ◄ and ► to select the

language.

Digital Teletext Language

Decoding Page Language WEST EUR

PREFERENCES

Stereo

Off

OK RETURN

Enter

Teletext

Select Back Exit

English

EXIT

Control Buttons

Below is a guide to the functions of the remote control text buttons.

To display the index/initial page:

Press displayed is dependant on the broadcaster.

To discover the solutions on quiz and joke pages press the

At times it is convenient to hold a page of text. Press screen. The page will be held on screen until the button is pressed again.

Press press again to enlarge the bottom half of the page. Press again to revert to normal size.

picture mode:

Enter the page number then press picture will be displayed. The television will indicate when the page is present by displaying the page number at the top of the screen.

Sub page will be automatically displayed.

to access the index/initial page. The one

To reveal concealed text:

button.

To hold a wanted page:

and will appear in the top of the

To enlarge the text display size:

once to enlarge the top half of the page,

To toggle between Teletext and normal

, a normal

Select Back Exit

EXITRETURN

Text Information

The rst text page shown will be the index page.

Any text page can be accessed by entering the 3-digit page number using the numbered buttons, pressing the coloured buttons or pressing P advance to the next page and P to go back to the previous page.

PROBLEM SOLVING

English

Questions and Answers

Below are the answers to some of the most common queries.

Why is there no sound or picture?

Check the television is not in standby mode. Check the mains plug and all mains connections.

Why is there incorrect or no sound when in DTV mode?

Press to ensure the hard of hearing option has not been selected.

Why doesn’t the video/DVD being played show on screen?

Make sure the VCR or DVD player is connected to the television as shown on page 8, then select the correct input by pressing

Why is there a good video picture but no sound?

Check all lead connections.

Why is there a picture but no sound?

Check the volume has not been turned down or that sound mute has not been selected.

Why is the VCR/DVD picture in black and white?

Check the correct input has been chosen, S-VIDEO or AV. See AV connections on page 34.

What else can cause a poor picture?

Interference or a weak signal. Try a different television station. Analogue Manual Scan may help.

Why doesn’t the remote control work?

Check the batteries aren’t dead or inserted incorrectly.

Why is there a message permanently on the screen?

Remove it by pressing .

Why are there problems with analogue text?

Good performance of text depends on a good strong broadcast signal. This normally requires a roof or loft aerial. If the text is unreadable or garbled, check the aerial. Go

to the main index page of the text service and look for the User Guide. This will explain the basic operation of text in some detail.

Why are the four coloured text numbers visible but no text?

Text has been selected while viewing an external source i.e. DVD or VCR. No text will appear on screen or a box may appear

HDMI, the HDMI Logo, and High-Denition Multimedia Interface are trademarks or registered trademarks of

HDMI Licensing LLC in the United States and other countries.

stating no information is available. Select a broadcasting channel and press

Why don't the devices connected via HDMI operate properly?

Make sure to use cables with the HDMI logo

(see page 11).

Some early HDMI equipment may not work

properly with the latest HDMI TV products, due to new standard adoption.

Why when digital subtitles have been selected are they not showing on screen?

Subtitles are not currently being transmitted by the broadcaster.

Why is there no digital text service?

The digital programme being viewed is not broadcasting digital text. Try another digital

programme.

What can be done if the user-dened password has

been forgotten?

Use the universal password 1276, then change to a new number of your choice.

to access.

Why does the TV turn off by itself?

After roughly 15 minutes without any input video signal at TV mode, the TV will turn off to save power.

Does this TV support the DPMS?

This set is equipped with a function for saving energy which supports the VESA Display Power Management Signaling (DPMS) standard. This means that the monitor must be connected to a computer which supports VESA DPMS. To exit DPMS mode, press button on the remote control to wake up the TV.

Why does some on-screen information appear as strange symbols?

Please make sure your “Country” setting is correct.

Why don't the REGZA-LINK devices work?

When the connected REGZA-LINK device does not work correctly after you have changed the settings of the device, turn off your television and unplug the power cord, and then plug and turn on again. Unplug the HDMI cable of the REGZA-LINK device and lead again.

Why is the REGZA-LINK logo still showing when the equipment has been disconnected?

If the REGZA-LINK device is disconnected, the logo will disappear after approximately one minute.

PROBLEM SOLVING

English

INFORMATION

English

Speciﬁcations and accessories

• This television complies with the specification listed below.

• Design and specifications are subject to change without notice.

DVB-T Broadcast systems/channels Broadcast systems/channels

UK UHF 21-68 PAL-I UHF UK21-UK69

France VHF 05-10 (VHF 01-05) PAL-B/G UHF E21-E69

Germany VHF 05-12 SECAM-L UHF F21-F69

Austria VHF 05-12 SECAM-D/K UHF R21-R69

Switzerland VHF 05-12

Italia VHF 05-12 (D,E,F,G,H,H1,H2)

Spain UHF 21-69

Nederlands VHF 05-12

Sweden VHF 05-12

Finland VHF 05-12

Greece VHF 05-12

Video Input PAL, SECAM, NTSC 3.58/4.43

External connections

Model 19/22 EXT1 Input Phono jacks Y, P

EXT2 Input Phono jack Vídeo

EXT3 nput/Output 21-pin SCART Auto, Mixed, RGB,

PC Input D-sub RGB

HDMI 1/2 Input HDMI

PC/HDMI1 Audio Phono jacks Audio L + R

Component Phono jack Audio L + R

Digital Audio Output (S/PDIF) Optical

Model 26/32/40

EXT1 Input Phono jacks Y, P

EXT2 Input Phono jack Vídeo

EXT3 Input/Output 21-pin SCART 1 Auto, Mixed, RGB,

EXT4 Input/Output 21-pin SCART 2 Auto, Mixed, RGB,

PC Input D-Sub RGB

HDMI1/2/3 Input HDMI

PC/HDMI1 Audio 3.5mm Audio L + R

Component Phono jacks Audio L + R

Digital Audio Output (S/PDIF) Optical

USB Port Interface version: USB 2.0

UHF 21-69 VHF E2-E12, S1-S41

UHF 21-69 VHF F1-F10, B-Q

UHF 21-69 VHF R1-R12

UHF 21-69

Phono jacks Audio L + R

USB Class: Mass Storage File system: FAT12, FAT16

and FAT32

B/CB, PR/CR

Composite, S-Vídeo / TV Out

B/CB, PR/CR

Composite, S-Vídeo / TV Out

Stereo Nicam

Visible Screen Size Model 19 409.80 x 230.40

(H x V mm)(approx.) 22 477.42 x 268.42

Display 16:9

Sound output Model 19 3.5W + 3.5W

(at 10% distortion) 22 3.5W + 3.5W

Power consumption Model 19 40W as specied in 22 55W EN60065:2002 26 90W

Standby (approx.) Model 19 0.5W

Dimensions Model 19 365.8 x 480.5 x 192.8

(H x W x D mm) 22 408.7 x 555.3 x 212.0 (approx.) 26 474.6 x 665.4 x 265.2

Weight (approx.) Model 19 5.0 kg

Headphone socket R3.5mm stereo

Operating condition Temperature 5 °C - 35 °C (41 °F - 94 °F)

Accessories Remote control

NOTE: The "HDMI 3" port is available for model 32/40KV73*G only.

2 carrier system

26 575.77 x 323.71 32(32AV73**) 697.69 x 392.26 32(32AV73**1) 697.69 x 392.26

32(32KV73**) 698.40 x 392.85

40 885.60 x 498.15

26 5W + 5W 32 10W + 10W 40 10W + 10W

32(32AV73**) 105W 32(32AV73**1) 115W 32(32KV73**) 130W 40 160W

22 0.5W 26 0.5W 32 0.5W 40 0.5W

32(32AV73**) 578.2 x 798.9 x 271.4 32(32AV73**1) 578.2 x 798.9 x 271.4 32(32KV73**) 578.2 x 798.9 x 271.4 40 703.0 x 992.8 x 282.9 (Height dimension includes foot stand)

22 5.5 kg 26 9.0 kg 32(32AV73**) 12.5 kg 32(32AV73**1) 12.5 kg 32(32KV73**) 12.5 kg 40 16.5 kg (weight includes foot stand)

Humidity : 20 - 80% (non-condensing)

2 batteries (AAA, IEC R03 1.5V) Power cord User Manual

INFORMATION

License Information used with Toshiba Televisions

The software pre-installed in the TOSHIBA Digital Televisions consists of multiple, independent software components. Each software component is copyrighted by TOSHIBA or a third party.

The TOSHIBA Digital Televisions uses software components that are distributed as freeware under a third-party end-user license agreement or copyright notice (hereinafter referred to as a “EULA”). Some EULAs require that the source code of the applicable component be disclosed as the condition for distributing the software component in executable format.

You can check the software components subject to such EULA requirements on the following Home Page:

URL : http://tesc.toshiba.co.uk/Web/Website.nsf/ContentFrameSet?OpenFrameset

In addition, some of the software components which are used in Toshiba Digital Televisions include the software that are made or developed originally by TOSHIBA. These software and accompanied documents are copyrighted by TOSHIBA, and protected by Copyright Act, an international treaty's articles and other governing laws. The software components which are made or developed originally by TOSHIBA and not subject to EULAs are not a target of source code offering.

The Toshiba warranty provided in respect of the Digital TV is the only warranty provided and no additional warranties are provided in respect of the software components subject to EURAs.

Some of the software components distributed under EULAs are made available for use by the user on the premise that they are not copyrighted or warranted by TOSHIBA or any third party. These software components are licensed to the user free of charge and therefore not covered by any warranty within the scope of the applicable laws. These software components are provided in “as is” condition without any warranty, whether express or implied. “Warranty” here includes, but not limited to, an

implied warranty for marketability or tness for specic uses. All risks associated with the quality or

performance of these software components are assumed by the user. TOSHIBA shall not be liable whatsoever for any cost of repair or correction or other incidental expense incurred in connection with

a defect found in any of these software components. Unless specied under the applicable laws or in

a written agreement, a party who changes or redistributes the software with consent from the copyright holders or based on the aforementioned licenses shall not be held liable whatsoever for any loss arising from the use of or inability to use such software components. The same applies even when the copyright holders or relevant third parties have been informed of the possibility of such loss. “Loss” here includes normal, special, incidental and indirect loss (including, but not limited to, the loss of data or its

accuracy; loss incurred by the user or any third party; and interface incompatibility with other software).

Please read each EULA for details on the use conditions and items that must be observed regarding these software components.

The table below lists the software components pre-installed in the TOSHIBA Digital Televisions, which are subject to EULAs. The user should read the applicable EULAs carefully before using these software components. The EULAs are exhibited in their original text (English) as exactly written by the respective parties other than TOSHIBA.

Pre-Installed Software EULA

FreeType Exhibit A

ICU Exhibit B

English

INFORMATION

English

Exhibit A

Exhibit B

ICU License - ICU 1.8.1 and later

Permission is hereby granted, free of charge, to any person obtaining a copy of this software and

associated documentation les (the "Software"), to deal in the Software without restriction, including

without limitation the rights to use, copy, modify, merge, publish, distribute, and/or sell copies of the Software, and to permit persons to whom the Software is furnished to do so, provided that the above copyright notice(s) and this permission notice appear in all copies of the Software and that both the above copyright notice(s) and this permission notice appear in supporting documentation.

THE SOFTWARE IS PROVIDED "AS IS", WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT OF THIRD PARTY RIGHTS. IN NO EVENT SHALL THE COPYRIGHT HOLDER OR HOLDERS INCLUDED IN THIS NOTICE BE LIABLE FOR ANY CLAIM, OR ANY SPECIAL INDIRECT OR CONSEQUENTIAL DAMAGES, OR ANY DAMAGES WHATSOEVER RESULTING FROM LOSS OF USE, DATA OR PROFITS, WHETHER IN AN ACTION OF CONTRACT, NEGLIGENCE OR OTHER TORTIOUS ACTION, ARISING OUT OF OR IN CONNECTION WITH THE USE OR PERFORMANCE OF THIS SOFTWARE.

Except as contained in this notice, the name of a copyright holder shall not be used in advertising or otherwise to promote the sale, use or other dealings in this Software without prior written authorization of the copyright holder.

ICU License - ICU 1.8.1 and later

INFORMATION

English

DVB is a registered trademark of the DVB Project

HDMI, the HDMI Logo, and High-Denition Multimedia Interface are trademarks or registered

trademarks of HDMI Licensing LLC in the United States and other countries.

Printed on recycled paper. 100% Chlorine free.

Reproduction in whole or part without written permission is strictly prohibited.

TOSHIBA Television Central Europe Sp. z o.o.

ul. Pokoju 1, Biskupice Podgórne, 55-040 Kobierzyce, Poland

Specication is subject to change without notice

INFORMATION

English

Notes

For your own records

Cleaning the screen and cabinet…

Turn off the power, clean the screen and cabinet with a soft, dry cloth. We recommend that you do not

use any proprietary polishes or solvents on the screen or cabinet as this may cause damage.

Disposal…

The following information is only for EU-member states:

Disposal of products The crossed out wheeled dust bin symbol indicates that products must be collected and disposed of separately from household waste. Integrated batteries and accumulators can be disposed of with the product. They will be separated at the recycling

center.

The black bar indicates that the product was placed on the market after August 13, 2005. By participating in separate collection of products and batteries, you will help to assure the proper disposal of products and batteries and thus help to prevent potential negative consequences for the

environment and human health.

For more detailed information about the collection and recycling programmes available in your country, please contact your local city ofce or the shop where you purchased the product.

Disposal of batteries and/or accumulators.

The crossed out wheeled dust bin symbol indicates that batteries and/or accumulators must be collected and disposed of separately from household waste.

If the battery or accumulator contains more than the specied values of lead (Pb), mercury (Hg), and/or cadmium (Cd) dened in the Battery Directive (2006/66/EC), then the chemical symbols for lead (Pb), mercury (Hg) and/or cadmium (Cd) will appear below the crossed out wheeled dust bin symbol. By participating in separate collection of batteries, you will help to assure the proper disposal of products and batteries and thus help to prevent potential negative consequences for the

environment and human health.

For more detailed information about the collection and recycling programmes available in your country, please contact your local city ofce or the shop where you purchased the product.

Toshiba 19AV731G, 19AV731G1, 22AV731G, 22AV731G1, 26AV731G Owner Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
