Important
Safeguards
Dear Customer,
Thank you for purchasing this Toshiba TV. This manual
will help you use the many exciting features of your new
TV. Before operating the TV, please read this manual
completely, and keep it nearby for future reference.
Child Safety
It Makes A Difference
Where Y our TV Stands
Safety Precautions
WARNING
TO REDUCE THE RISK OF FIRE OR ELECTRIC
SHOCK, DO NOT EXPOSE THIS APPLIANCE TO
RAIN OR MOISTURE.
WARNING: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
The lightning symbol in the triangle tells you that the
voltage inside this product may be strong enough to
cause an electric shock. DO NOT TRY TO SERVICE
THIS PRODUCT YOURSELF.
The exclamation mark in the triangle tells you that
important operating and maintenance instructions
follow this symbol.
NOTE TO CATV INSTALLERS IN THE USA
This is a reminder to call the CATV system installer’s
attention to Article 820-40 of the NEC, which provides
guidelines for proper grounding and, in particular,
specifies that the cable ground shall be connected to the
grounding system of the building, as close to the point of
cable entry as practical. For additional antenna
grounding information, see items 24 and 25 on page 4.
NOTICE OF POSSIBLE TV STAND INSTABILITY
DANGER: RISK OF SERIOUS PERSONAL
INJURY OR DEATH! Use this TV with the
TOSHIBA TV stand recommended in the
“Specifications” section only.
result in instability, causing possible injury or death.
NOTICE OF POSSIBLE ADVERSE EFFECTS
ON TV PICTURE TUBE
If a fixed (non-moving) pattern remains on the TV
screen for long periods of time, the image can
become permanently engrained in the picture tube.
This type of damage is NOT COVERED BY
Y OUR W ARRANTY . See item 32 on page 4.
Use with other stands may
Congratulations on your purchase! As you enjoy
your new TV, keep these safety tips in mind:
The Issue
¾
If you are like most consumers
home. Many homes, in fact, have more than one TV.
¾
The home theater entertainment experience is a growing
trend, and larger TVs are popular purchases; however,
they are not always supported on the proper TV stands.
¾
Sometimes TVs are improperly secured or inappropr iately
situated on dressers, bookcases, shelves, desks, audio
speakers, chests, or carts. As a result, TVs may fall over,
causing unnecessary injury.
, you have a TV in your
Toshiba Cares!
¾
The consumer electronics industry
is committed to making home
entertainment enjoyable and safe.
¾
The Consumer Electronics
Association formed the Home
Entertainment Support Safety
Committee, comprised of TV
and consumer electronics
furniture manufacturers, to
advocate children’s safety and
educate consumers and their
families about television safety.
Tune Into Safety
¾
One size does NOT fit all! Use
appropriate furniture large enough to support
the weight of your TV (and other electronic
components).
¾
Use appropriate angle braces, straps, and anchors to
secure your furniture to the wall (but never screw anything
directly into the TV).
¾
Carefully read and understand the other enclosed
instructions for proper use of this product.
¾
Do not allow children to climb on or play with furniture
and TVs.
¾ Avoid placing any item on top of your TV (such as a VCR,
remote control, or toy) that a curious child may reach f or.
¾
Remember that children can become excited while
watching a program and can potentially push or pull a TV over.
¾ Share our safety message about this hidden hazard of
home with your family and friends. Thank you!
2500 Wilson Blvd.
Arlington, VA 22201 U.S.A.
Tel. 703-907-7600 Fax 703-907-7690
www.CE.org
CEA is the Sponsor, Producer and
05/02.2
Manager of the International CES
the
®
