Toshiba 13A26C, 19A26C User Manual
13A26C
19A26C
3X00221A(E)_COVER 22/12/05, 4:40 PM1
Dear Customer,
Thank you for purchasing this Toshiba TV. This manual will
help you use the many exciting features of your new TV.
Before operating the TV, please read this manual
completely, and keep it nearby for future reference.
Safety Precautions
WARNING
TO REDUCE THE RISK OF FIRE OR ELECTRIC
SHOCK, DO NOT EXPOSE THIS APPLIANCE TO
RAIN OR MOISTURE.
WARNING: TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT REMOVE COVER
(OR BACK). NO USER-SERVICEABLE PARTS
INSIDE. REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
The lightning symbol in the triangle tells you that the
voltage inside this product may be strong enough to
cause an electric shock. DO NOT TRY TO SERVICE
THIS PRODUCT YOURSELF.
The exclamation mark in the triangle tells you that
important operating and maintenance instructions
follow this symbol.
CAUTION: To reduce the risk of electric shock,
do not use the polarized plug with an extension
cord, receptacle, or other outlet unless the
blades can be inserted completely to prevent
blade exposure.
NOTE TO CATV INSTALLERS
This is a reminder to call the CATV system installer’s
attention to Article 820-40 of the U.S. NEC, which
provides guidelines for proper grounding and, in
particular, specifies that the cable ground shall be
connected to the grounding system of the building,
as close to the point of cable entry as practical. For
additional antenna grounding information, see
items 25 and 26 on page 4.
NOTICE OF POSSIBLE ADVERSE EFFECTS
ON TV PICTURE DISPLAY
If a fixed (non-moving) pattern or image remains
on the TV screen for extended periods of time, the
image can become permanently ingrained in the
cathode ray tube(s) of the TV and cause subtle
but permanent ghost images. This type of
damage is NOT COVERED BY YOUR
WARRANTY. (See item 33 on page 4 for details.)
2
0303
Child Safety
It Makes A Difference
Where Your TV Stands
Congratulations on your purchase! As you enjoy
your new TV, keep these safety tips in mind:
The Issue
If you are like most consumers, you have a TV in your home.
Many homes, in fact, have more than one TV.
The home theater entertainment experience is a growing
trend, and larger TVs are popular purchases; however, they
are not always supported on the proper TV stands.
Sometimes TVs are improperly secured or inappropriately
situated on dressers, bookcases, shelves, desks, audio
speakers, chests, or carts. As a result, TVs may fall over,
causing unnecessary injury.
Toshiba Cares!
The consumer electronics industry
is committed to making home
entertainment enjoyable and safe.
The Consumer Electronics
Association formed the Home
Entertainment Support Safety
Committee, comprised of TV and
consumer electronics furniture
manufacturers, to advocate
children’s safety and educate
consumers and their families about
television safety.
Tune Into Safety
One size does NOT fit all! Use
appropriate furniture large enough to
support the weight of your TV (and other
electronic components).
Use appropriate angle braces, straps, and anchors to
secure your furniture to the wall (but never screw anything
directly into the TV).
Carefully read and understand the other enclosed
instructions for proper use of this product.
Do not allow children to climb on or play with furniture
and TVs.
Avoid placing any item on top of your TV (such as a VCR,
remote control, or toy) that a curious child may reach for.
Remember that children can become excited while watching
a program and can potentially push or pull a TV over.
Share our safety message about this hidden hazard of
home with your family and friends. Thank you!
2500 Wilson Blvd.
Arlington, VA 22201 U.S.A.
Tel. 703-907-7600 Fax 703-907-7690
www.CE.org
CEA is the Sponsor, Producer and
Manager of the International CES
the
®
3X00221A(E)_P02-07 22/12/05, 4:41 PM2
Important Safety Instructions
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near
water.
Installation, Care, and Service
Installation
Follow these recommendations and precautions and heed
all warnings when installing your TV:
16) Never modify this equipment. Changes or modifications
may void: a) the warranty, and b) the user’s authority to
operate this equipment under the rules of the Federal
Communications Commission.
6) Clean only with a dry cloth.
7) Do not block any ventilation
openings. Install in accordance with
the manufacturer’s instructions.
8) Do not install near any heat
sources such as radiators,
heat registers, stoves, or other
apparatus (including amplifiers)
that produce heat.
9) Do not defeat the safety purpose of the polarized or
grounding type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug has
two blades and a third grounding
prong. The wide blade or the third
prong are provided for your safety.
If the provided plug does not fit into
your outlet, consult an electrician
for replacement of the obsolete outlet.
10) Protect the power cord from being
walked on or pinched, particularly at
plugs, convenience receptacles, and
the point where it exits the apparatus.
11) Only use attachments/accessories specified by the
manufacturer.
12) Use only with the cart, stand, tripod,
bracket, or table specified by the
manufacturer, or sold with the
apparatus. When a cart is used, use
caution when moving the cart/apparatus
combination to avoid injury from tip-over.
13) Unplug this apparatus during
lightning storms or when
unused for long periods
of time.
14) Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power supply
cord or plug is damaged, liquid has
been spilled or objects have fallen into
the apparatus, the apparatus has been
exposed to rain or moisture, does not
operate normally, or has been dropped.
Wide plug
17) DANGER: RISK OF SERIOUS PERSONAL
INJURY, DEATH, OR EQUIPMENT
DAMAGE! Never place the TV on
an unstable cart, stand, or table. The TV
may fall, causing serious personal injury,
death, or serious damage to the TV.
18) Never place or store the TV in direct
sunlight; hot, humid areas; areas
subject to excessive dust or vibration;
or locations with temperatures at or
below 41°F (5°C).
19) Always place the TV on the floor
or a sturdy, level, stable surface that
can support the weight of the unit.
20) Never place items such as vases,
aquariums, or candles on top of the TV.
21) Never block or cover the slots or
openings in the TV cabinet back,
bottom, and sides. Never place
the TV:
• on a bed, sofa, rug, or similar
surface;
• too close to drapes, curtains,
or walls; or
• in a confined space such as a
bookcase, built-in cabinet, or any
other place with poor ventilation.
The slots and openings are provided
to protect the TV from overheating
and to help maintain reliable
operation of the TV.
22) Never allow anything to rest on or roll over the power
cord, and never place the TV where the power cord is
subject to wear or abuse.
15)
inserted completely to prevent blade exposure.
3X00221A(E)_P02-07 22/12/05, 4:41 PM3
CAUTION: To reduce the risk of electric shock, do
not use the polarized plug with an extension cord,
receptacle, or other outlet unless the blades can be
23) Never overload wall outlets and
extension cords.
0303
3
3
24) Always operate this equipment from
Ground clamp
Antenna discharge unit
(NEC Section 810-20)
Grounding conductors
(NEC Section 810-21)
Power service grounding
electrode system (NEC Art 250 Part H)
Ground clamps
Antenna lead-in wire
Electric service equipment
a 120V AC, 60 Hz power source only.
25) Always make sure the antenna system is properly
grounded to provide adequate protection against
voltage surges and built-up static charges (see Section
810 of the National Electric Code).
26) DANGER: RISK OF SERIOUS PERSONAL
INJURY OR DEATH!
• Use extreme care to make sure you are never
in a position where your body (or any item you are in
contact with, such as a ladder or screwdriver) can
accidentally touch overhead power lines. Never locate
the antenna near overhead power lines or other
electrical circuits.
• Never attempt to install any of the following during
lightning activity:
a) an antenna system; or b) cables, wires, or any home
theater component connected to an antenna or phone
system.
Care
For better performance and safer operation of your
TOSHIBA TV, follow these recommendations and
precautions:
27) Always sit approximately 10–25 feet away from the TV
and as directly in front of it as possible. The picture can
appear dull if you sit too far to the left or right of the TV,
or if sunlight or room lights reflect on the screen. Turn
the TV off to check for reflections on the screen, and
then remove the source of reflections while viewing the
TV.
30) [This item applies to projection TVs only.] If the air
temperature rises suddenly (for example, when the TV
is first delivered), condensation may form on the lenses.
This can make the picture appear distorted or the color
appear faded. If this happens, turn off the TV for 6 to 7
hours to allow the condensation to evaporate.
31)For added protection of your TV from lightning and
power surges, always unplug the power cord and
disconnect the antenna from the TV if you leave the TV
unattended or unused for long periods of time.
32) During normal use, the TV may make
occasional snapping or popping
sounds. This is normal, especially
when the unit is being turned on or
off. If these sounds become frequent
or continuous, unplug the power cord
and contact a Toshiba Authorized Service Center.
33) Possible Adverse Effects on TV Picture Display: If a
fixed (non-moving) pattern or image remains on the TV
screen for extended periods of time, the image can
become permanently ingrained in the cathode ray
tube(s) of the TV and cause subtle but permanent
ghost images. This type of damage is NOT
COVERED BY YOUR WARRANTY.
Never leave the TV on for extended periods of time
while it is displaying the following images or formats:
• Fixed Images, including but not limited to PIP/POP
windows, closed captions, video game patterns, TV
station logos, stock tickers, and websites.
• Special Formats that do not use the entire screen,
including but not limited to widescreen or letterbox
format media viewed on a 4:3 aspect ratio display
(with gray or black bars at the top and bottom of the
screen); or 4:3 aspect ratio format media viewed on a
widescreen/16:9 aspect ratio display (with gray or
black bars on the left and right sides of the screen).
Service
34) WARNING: RISK OF ELECTRIC
SHOCK! Never attempt to service the
TV yourself. Opening and
removing the covers may expose
you to dangerous voltage or other
hazards. Refer all servicing to a
Toshiba Authorized Service Center.
28) Always unplug the TV before
cleaning. Never use liquid or
aerosol cleaners.
29) WARNING: RISK OF ELECTRIC SHOCK!
Never spill liquids or push objects of any kind
into the TV cabinet slots.
4
3X00221A(E)_P02-07 22/12/05, 4:41 PM4
35) If you have the TV serviced:
• Ask the service technician to use only replacement
parts specified by the manufacturer.
• Upon completion of service, ask
the service technician to perform
routine safety checks to determine
that the TV is in safe operating
condition.
36)When the TV reaches the end of its useful life, ask a
qualified service technician to properly dispose of the
TV. Improper disposal may result in a picture tube
implosion and possible personal injury.
0303
FEATURES
• 181 Channel Tuner - The tuning system is capable of receiving all 68 VHF/UHF standard broadcast channels that
are available in your area. When operating on a cable system, it can tune to the standard VHF channel frequencies
plus up to 113 cable channel frequencies. The actual number of channels received depends upon channel
reception in your area or your cable system.
• On-screen 3 Language Display - This TV can display the on-screen language in English, Spanish, or French.
• Sleep Timer - Operable from the remote control, the TV can be programmed to turn off automatically (from 10 to
120 minutes, in 10-minute increments).
• Memory Back Up - This system prevents loss of memorized channel selections in case a power interruption to the
TV should occur.
• Picture Control Adjustments - The on-screen display allows precise remote control adjustment of BRIGHTNESS,
CONTRAST, COLOR, TINT, and SHARPNESS.
• Closed Captioned Decoder - Displays closed captions or text on-screen (when available).
• Lock feature - This feature has three functions, LOCKING CHANNELS, LOCKING VIDEO INPUT, and SETTING
THE GameTimer
TM
.
• Programmable ON Timer - Allows you to program the TV to automatically turn on at a set time.
LOCATION OF CONTROLS
FRONT BACK
PHONE
POWER
VOLUME
CHANNEL
SET
ENTER RESET
MENU
13A26C 19A26C
VIDEO AUDIO
VIDEO
CHANNEL
AUDIO
VOLUMEPOWER
SET
RESETENTER
MENU
8 9
PHONE
POWER
VOLUME
CHANNEL
VIDEO AUDIO
SET
ENTER RESET
MENU
POWER
VOLUME
MENU
SET
CHANNEL
VIDEO
AUDIO
RESETENTER
134 6572724 653
1. PHONE (Earphone) Jack - Plug an earphone or
monaural headphones with a 1/8” miniplug into this
jack for private listening.
2. POWER indicator - Lights up when the power is
turned on.
3. Remote Sensor - Signals from the Remote Control
unit are received here.
4. POWER Button - Press to turn the TV on or off.
5. VOLUME ▲/▼ Buttons - Press to raise or lower the
level of the sound.
(MENU Buttons) - Press both VOLUME ▲/▼ buttons
at the same time to display the on-screen menu functions.
(SET + / – Buttons) - Press to select the desired setting during on-screen operations.
6. CHANNEL ▲/▼ Buttons - Press to select a higher or
lower numbered channel set into memory.
(ENTER Button) - Press to enter or select information
for on-screen operations.
(RESET Button) - Press, while in the on-screen menu
mode, to reset the on-screen picture adjustments to
their factory preset positions.
7. AUDIO/VIDEO IN Jacks - Audio and video signal
cables from an external source can be connected here.
8. AC Power Cord - Plug into an outlet with 120V, 60
Hz AC power only.
9. VHF/UHF IN (ANT) Jack - Connect a VHF/UHF
antenna or Cable TV 75 ohm coaxial cable to this
jack.
13A26C
ANT
19A26C
ANT
8 9
5
3X00221A(E)_P02-07 22/12/05, 4:41 PM5
REMOTE CONTROL
1
2
3
4
5
6
7
8
9
1. POWER Button - Press to turn on the TV. Press again
to turn off the TV.
2. Direct Channel Selection/Channel Number Buttons
(0–9) - Allow direct tuning of any channel.
3. CH RTN Button - Repeatedly press CH RTN to toggle
back and forth between the last two channels you tuned.
POWER
123
456
7
89
CH RTN RECALL
0
VOL
SLEEP
–
MENU
–
RESET
TV/VIDEO
CH +
CH –
SET
CAP/TEXT
CT-859
MUTE
VOL
ENTER
+
1/2
10
11
+
12
13
14
15
4. SLEEP Button - To set the TV to turn off after a preset
amount of time, press the SLEEP button on the remote
control. The clock will count down 10 minutes each time
the button is pressed in the order of 120, 110, 100, ······ 20,
10, 0. After the sleep time is programmed, the display will
disappear then reappear momentarily every ten minutes to
remind you the sleep timer function is operating. To
confirm the sleep time setting, press the SLEEP button
once and the remaining time will be momentarily displayed.
To cancel the sleep timer, press the SLEEP button
repeatedly until the display turns to 0.
5. VOL (VOLUME) + / – Buttons - Press the + button to
increase or the – button to decrease the volume level.
6. MENU Button - Press to display the on-screen menu
function.
7. SET + / – Buttons - Press to select the desired setting
during on-screen operations.
8. RESET Button - Press to reset the on-screen picture
adjustments to their factory preset positions.
9. TV/VIDEO Button - Switches between the TV and external
device inputs.
10. RECALL Button - When you press this button, the
channel number will appear in the upper right corner of the
screen. Press the button again to remove it from the
screen.
11. MUTE Button - To turn off the sound, press this button
once. The TV will be silenced and the word “MUTE” will
appear on the screen. The muting feature can be released
by pressing the MUTE button again or one of the VOL + or
– buttons.
12. CH (CHANNEL) + / – Buttons - Press the CH + button to
change to a higher numbered channel set into memory.
Press the CH – button to change to a lower numbered
channel set into memory.
13. ENTER Button - Press to enter or select information for
on-screen operations.
14. 1/2 Button - Switches between captions channel 1 and
captions channel 2 in the closed caption mode.
15. CAP/TEXT Button - Press to switch between normal TV
and the two closed caption modes (captions or text), when
available.
Before using the remote control, batteries must first
be installed.
HOW TO INSTALL BATTERIES
1. Open the battery compartment cover.
2. Install two “AAA” (penlight size) batteries.
3. Replace the battery compartment cover.
6
3X00221A(E)_P02-07 22/12/05, 4:41 PM6
Use two “AAA” size penlight batteries (supplied) for the
remote control. The batteries may last approximately one
year depending on how much the remote control is used.
For best performance, it is recommended that you replace
the batteries on a yearly basis or when the remote operation
becomes erratic.
Caution:
• Never throw batteries into a fire.
Notes :
• Be sure to use AAA size batteries.
• Dispose of batteries in a designated disposal area.
• Batteries should always be disposed of with the
environment in mind. Always dispose of batteries in
accordance with applicable laws and regulations.
• If the remote control does not operate correctly, or if the
operating range becomes reduced, replace batteries with
new ones.
• When necessary to replace batteries in the remote
control, always replace both batteries with new ones.
Never mix battery types or use new and used batteries in
combination.
• Always remove batteries from remote control if they are
dead or if the remote control is not to be used for an
extended period of time. This will prevent battery acid
from leaking into the battery compartment.
ANTENNA/CABLE TV CONNECTIONS
VIDEO Game
VIDEO
CHANNEL
RESETENTER
AUDIO
Choose one of the following seven connections, based on your
equipment and service:
Combination VHF/UHF antenna
Single 75 ohm cable
(or)
Single 300 ohm twin-lead wire*
For best performance, if you have a splitter connected, remove
*
the splitter and connect the single wire to the transformer,
and then to the TV’s antenna input (as illustrated here).
TRANSFORMER
(not supplied)
To ANT input
on back of TV
To ANT input
on back of TV
Separate VHF and UHF antennas or
Combination VHF/UHF antenna with separate cables/wires
UHF Antenna
VHF Antenna
300 ohm twin-lead wire
75 ohm cable
(not supplied)
COMBINER
To ANT input
on back of TV
(or)
UHF Antenna
300 ohm twin-lead wire
VHF Antenna
300 ohm twin-lead wire*
Cable TV service
From cable
TV service
(or)
From cable
TV service
(or)
From cable
TV service
TRANSFORMER
(not supplied)
CONVERTER/ DESCRAMBLER
CONVERTER/ DESCRAMBLER
SPLITTER
A / B SWITCH
COMBINER
(not supplied)
A
B
To ANT input
on back of TV
To ANT input
on back of TV
To ANT input
on back of TV
To ANT input
on back of TV
Combination VHF/UHF antenna (Single 75 ohm cable or 300
ohm twin-lead wire)
Connect the 75 ohm cable from a combination VHF/UHF
antenna to the antenna jack.
If your combination antenna has a 300 ohm twin-lead wire, use
the 300-75 ohm matching transformer (not supplied).
Combination VHF/UHF antenna (Separate VHF and UHF 300
ohm twin-leads)
Connect the UHF twin-lead wire to a combiner (not supplied).
Connect the VHF twin-lead to the 300-75 ohm matching
transformer (not supplied). Attach the transformer to the
combiner. Attach the combiner to the antenna jack.
Separate VHF/UHF antennas
Connect the 75 ohm cable from the VHF antenna and the UHF
antenna twin-lead to a combiner (not supplied). Attach the
combiner to the antenna jack.
NOTE: If your VHF antenna has a twin-lead wire, use the 300-75
ohm matching transformer (not supplied), then connect the transformer to the combiner.
For subscribers to basic cable TV service
For basic cable service not requiring a converter/descrambler
box, connect the Cable TV 75 ohm coaxial cable directly to the
antenna jack on the back of the television.
For subscribers to scrambled cable TV service
If you subscribe to a cable service that requires the use of a
converter/descrambler box, connect the incoming cable to the
converter/descrambler box and connect the output of the box to
the antenna jack on the back of the television. Follow the
connections shown at left. Set the television to the output of the
converter/descrambler box (usually channel 3 or 4) and use the
converter/descrambler box to select channels.
For subscribers to unscrambled basic cable with scrambled
premium channels
If you subscribe to a cable service in which basic cable channels
are unscrambled and premium channels require the use of a
converter/descrambler box, you may wish to use a two-set signal
splitter (sometimes called a “two-set coupler”) and an A/B switch
box from the cable installer or an electronics supply store. Follow
the connections shown at left. With the switch in the “B” position,
you can directly tune any nonscrambled channels on your TV.
With the switch in the “A” position, tune your TV to the output of the
converter/descrambler box (usually channel 3 or 4) and use the
box to tune scrambled channels.
This television has an extended tuning range and can tune most
cable channels without using a cable company supplied
converter box. Some cable companies offer “premium pay
channels” in which the signal is scrambled. Descrambling these
signals for normal viewing requires the use of a descrambler
device, which is generally provided by the cable company.
CONNECTION TO OTHER EQUIPMENT
The exact arrangement you use to interconnect various video and audio components to the TV is dependent on the model and features
of each component. Check the owner’s manual provided with each component for the location of video and audio inputs and outputs.
The following connection diagrams are offered as suggestions. You may need to modify them to accommodate your particular
assortment of components.
TV/VIDEO SELECTION
To view the picture from a VCR,
camcorder, or VIDEO game, you must put
the TV in VIDEO mode first. Press TV/
VIDEO to select VIDEO mode. The word
“VIDEO” displays briefly on-screen. Press
TV/VIDEO
1. To connect the TV to a VCR
The unauthorized recording, use, distribution, or
revision of television programs, videotapes, DVDs, and
other materials is prohibited under Copyright Law, and
may subject you to civil and criminal liability.
3X00221A(E)_P02-07 22/12/05, 4:41 PM7
again to return to TV mode.
VCR
To Audio/
Video OUT
(not supplied)
Front of TV
CHANNEL
RESETENTER
VIDEO
VIDEO
AUDIO
AUDIO
2. To connect the TV to a VIDEO Game
VIDEO
The TV also can be used as a display device for many video
games. However, due to the wide variety of signals generated
by these devices and subsequent hook-up variations required,
they have not all been included in the suggested connection
diagrams. You will need to consult each device's owner's
manual for additional information.
To Audio/Video OUT
3. To connect the TV to a camcorder
To playback from the camcorder, connect the camcorder to
the TV as shown.
To AV OUT jack
(not supplied)
(not supplied)
Front of TV
Front of TV
VIDEO
CHANNEL
RESETENTER
AUDIO
7
SETTING THE LANGUAGE
This TV can display the on-screen displays and adjustment menus in English, Spanish, or French.
The on-screen language selection (step 3, below) will automatically appear on the screen when you press the MENU button
initially. Select the language you prefer first, then proceed with the other menu options.
Press MENU.
1
Press SET + or – to select the
2
LANGUAGE mode, then press
ENTER.
MENU
CH SETUP
LANGUAGE
LOCK
ON TIMER
+
〈
/Ð/ ENTER / MENU
Press SET + or – until the
3
indicator points to the desired
language: English (ENGLISH),
Spanish (ESPAÑOL) or French
(FRANCAIS), then press ENTER.
〉
Press MENU repeatedly until the
4
“
”
LANGUAGE / IDIOMA / LANGUE
ENGLISH
ESPAÑOL
FRANCAIS
+
〈
/
– / ENTER / MENU
menu screen is cleared.
NOTE:
If Spanish or French is chosen, the closed caption indicators will be in the selected language, but the closed caption text
will not be affected by the language selection.
TV OPERATION
To turn on the TV, press POWER.
1
The VOLUME can be adjusted to a desired level by
2
pressing VOL (VOLUME) + or –.
The sound level will be indicated on the TV screen by
GREEN BARS AND A NUMBER. As the sound level
increases, so do the number of BARS AND THE
NUMBER on the screen. The same is true for
decreasing the level.
Set the TV/CABLE menu option to the appropriate
3
position. When shipped from the factory, this menu
“
option is in the CABLE setting. See
CHANNELS
” on page 9.
TO MEMORIZE
TV - VHF/UHF channels
CABLE - CABLE TV channels
CH (CHANNEL) + and – buttons
4
Press and release CH (CHANNEL) + or –. The
channel automatically stops at the next channel
programmed into the TV’s memory. Press and hold the
button down to change channels more quickly.
For proper operation, make sure you program
channels into the TV’s memory before tuning
channels. See “TO MEMORIZE CHANNELS
” on page 9.
DIRECT CHANNEL SELECTION buttons (0–9) - Press
these buttons to select a channel. The channel number will
appear in the upper right corner of the TV screen. If an
invalid channel number is selected, the display will revert to
the previous channel.
TV MODE DIRECT CHANNEL SELECTION - When the
TV/CABLE menu option is in
the “TV” position, all channels
can be instantly selected by using two buttons (For example,
to select channel 2, press “0,” then “2.” If you press only “2,”
channel selection will be delayed for a few seconds). For
channels 10 and above, press the two digits in order.
CABLE mode direct channel selection
When the TV/CABLE menu option is in the CABLE position,
channels can be selected as follows:
1-9
Press “0” twice, then 1-9 as needed.
Example, to select channel 2, press
“002.”
10-12
Press “0”, then the remaining 2 digits.
Example, to select channel 12, press
“012.”
13-99
Press the 2 digits in order.
Example, to select channel 36, press
“36.”
100-125
Press the 3 digits in order.
Example, to select channel 120, press
“120.”
〉
8
3X00221A(E)_P08-12 22/12/05, 4:41 PM8
NOTE: If the station being viewed stops broadcasting, the TV
will automatically shut off after 15 minutes.
TO MEMORIZE CHANNELS
This TV is equipped with a channel memory feature that allows the
TV to skip up or down to the next channel in the TV’s memory,
skipping over unwanted channels.
Before selecting channels, you must program them into the TV’s
memory. In addition to normal VHF and UHF channels, this TV can
receive up to 113 Cable TV channels. To use this TV with an
antenna, set the TV/CABLE menu option to the TV setting. When
shipped from the factory, this menu option is in the CABLE setting.
TV/CABLE SELECTION
Press MENU.
1
Press SET + or – until the indicator next to
2
“CH SETUP” begins to flash, then press
ENTER.
Press SET + or – until the indicator next
3
to “TV/CABLE” begins to flash.
Press ENTER to select the TV or CABLE
4
mode. The arrow indicates the selected
mode.
Repeatedly press MENU until the
5
menu screen closes.
NOTE:
Contact your cable company to determine the type of cable
system used in your area.
AUTOMATIC CHANNEL MEMORY
Press MENU.
1
Press SET + or – until the indicator next to
2
“CH SETUP” begins to flash, then press
ENTER.
Press SET + or – until the indicator next
3
to “AUTO CH MEMORY” begins to flash,
then press ENTER. The TV will begin
memorizing all the channels available in
your area. Channel numbers will remain
red until auto memorizing is complete.
〈
CABLE
TV
AUTO CH MEMORY
ADD / DELETE
+
〈
/ – / ENTER / MENU
〈
TV
CABLE
AUTO CH MEMORY
ADD / DELETE
+
〈
/ – / ENTER / MENU
〉
〉
〉
〉
TO ADD/DELETE CHANNELS
Press MENU.
1
Press SET + or – until the indicator next to
2
“CH SETUP” begins to flash, then press
ENTER.
Press SET + or – until the indicator
3
next to “ADD/DELETE” begins to
flash, then press ENTER.
Select the desired channels to be
4
added or deleted using the Direct
Channel Selection buttons (0–9),
CH + or –, SET + or –.
Press ENTER to select ADD or DELETE.
5
If an unmemorized channel was selected (step 4), the
channel indication will be red. Press ENTER if you wish
to ADD the unmemorized channel. The channel
indicator will change from red to green when a channel
is added and the channel will be memorized.
If a memorized channel was selected (step 4), the
channel indication will be green. To delete the channel
from memory, press ENTER repeatedly
until “DEL” appears on-screen. The
channel indicator will change from
green to red when a channel is deleted.
Repeat steps 4 and 5 for each channel
to be added or deleted.
Repeatedly press MENU until the menu screen closes.
6
〈
TV
AUTO CH MEMORY
ADD / DELETE
+
〈
/ – / ENTER / MENU
ADD CH 012
〈
0 – 9 / + / – / ENTER / MENU
〉
CABLE
〉
〉
Repeatedly press MENU until the menu screen closes.
4
ADJUSTING THE PICTURE
You can adjust the settings for brightness, contrast, color,
tint and sharpness.
Press MENU.
1
Press SET + or – until the indicator next to “PICTURE”
2
begins to flash, then press ENTER.
Repeatedly press ENTER to select the item you want to
3
adjust.
CONTRAST COLORBRIGHTNESS TINT SHARPNESS
3X00221A(E)_P08-12 22/12/05, 4:41 PM9
Press SET + or – to adjust the setting.
4
+
BRIGHTNESS
CONTRAST
COLOR
TINT
SHARPNESS
higher
lighter
deeper
greenish
sharper
lower
darker
paler
reddish
softer
TO RETURN TO FACTORY SETTINGS:
Press RESET while the picture adjusting mode is
on-screen.
–
9
Loading...
