Toshiba 1360, 1370 Diagram
1360/1370 COVER-ASM DECEMBER 2002
1
1360/1370 DECEMBER 2002
ITEM
NO.
PARTS
NO.
1A F-COV-F-1360 1 1/PP F97C852 1360 4402 861250
1B F-COV-F-1370 1 1/PP F97C852 1370 4402 861350
2 ACTR-SW-DOOR 1 1/P 4402 843500
3 LBL-INST-TNR1 1 1/KP 4402 841670
5 LBL-INST-TNR2 1 1/KP 4402 841960
6 COVER-RIGHT-U 1 1/PP 4402 841620
7 COVER-LEFT 1 1/PP 4402 841610
8 COVER-TOP 1 1/PP 4402 841640
9 COVER-REAR 1 1/PP 4402 841650
10 PLATE-HINGE 1 1/P 4407 686030
11 PLATE-HINGE-L 1 1/P 4407 686960
12 MANUAL-POKET 1 1/PP 4400 553270
13 CAP-COVER-LEFT 1 1/P 4402 841750
14 LBL-INST-TNR3-E 1 5/KP FOR EUROPE 4402 841590
15 BRKT-FRONT-COV 1 1/P 4402 841570
16 LBL-MEMORY-F120 1 5/KP 4402 844590
18A LABEL-CANADA 1 5/P NAD 4400 945700
19B LABEL-CE 1 5/P FOR EUROPE 4402 090460
51 PTBR30*08MSZN3A 8 50/P 4842 040846
52 TBID3006MSCR3C 10 50/P 4842 040684
11 PLATE-HINGE-L 1 1/P 4407 686960
Q'TY
Q'TY
/
PARTS NAME P I R
PAGE
/
PACK
SPE
PRICE
IN NONE
BSI
NO.
TO FROM
SERIAL
NO.
REMARKS
1
TOSHIBA
1360/1370 CONTROL-PANEL-ASM DECEMBER 2002
2
1360/1370 DECEMBER 2002
ITEM
NO.
PARTS
NO.
1 COV-CONP 1 1/PP 4402 842100
2A PANEL-DSP-1370U 1 1/KP F97C852 1370 NAD 4402 861900
2B PANEL-DSP-1370E 1 1/KP F97C852 1370 OTHERS 4402 861910
3 KEYTOP-C/S 1 1/D 4402 842150
4 KEYTOP-TEN 1 1/D 4402 842160
5 KEYTOP-PRINT 1 1/D 4402 842170
6A KEYTOP-FNC 1 1/P F97C852 1360 4402 862000
6B KEYTOP-FNC 2 1/P F97C852 1370 4402 862000
7 KEYTOP-65 1 1/P F97C852 1370 4402 862010
8 KEYTOP-141 1 1/P F97C852 1370 4402 862020
9 KEY-TOP-DSP 1 1/P F97C852 1370 4402 862030
10 ARM-SLIDE-V 1 1/P 4402 842250
11 BLIND-SLIDE-V 1 1/P 4402 842260
12 KNOB-SLIDE 1 1/P F97C852 4402 862040
13 COV-IN 1 1/PP 4402 842300
14 BRKT-CONP 2 1/P 4402 842310
15 PWA-F-PNL-121 1 1/SB 1370 4402 858050
16 WH-PNL-121 1 1/P 4402 858600
17 CTR-E650B-523 1 1/D 4400 357700
18 SHIELD-MYLAR 1 1/P 4402 842350
19 PANEL-DSP-1360 1 1/KP F97C852 1360 4402 861800
20 PWA-F-PNL-120 1 1/SB 1360 4402 858110
21 LBL/W-DRUM 1 1/KP 4400 553200
41 PTBR30*12MSZN3A 2 50/P 4842 040848
42 PTBR30*06MSZN3A 15 50/P 4842 040495
43 TZPAN3008MSZN3L 2 50/P 4842 040692
44 TZPAN3006MSZN3L 3 50/P 4842 040690
Q'TY
Q'TY
/
PARTS NAME P I R
PAGE
/
PACK
SPE
PRICE
IN NONE
BSI
NO.
TO FROM
SERIAL
NO.
REMARKS
2
TOSHIBA
1360/1370 TABLE-ASM DECEMBER 2002
3
1360/1370 DECEMBER 2002
ITEM
NO.
PARTS
NO.
1 COVER-PLATEN 1 1/PP 4402 841810
2 SHEET-PLATEN-JU 1 1/KP 4402 841830
3 TOP-POCKET 1 1/PP 4402 841840
4 HINGE-PLATEN 1 1/P 4402 841850
5 BKT-HINGE-R 1 1/P 4402 841870
6 BKT-HINGE-L 1 1/P 4402 841880
31 PTBR30*08MSZN3A 4 50/P 4842 040846
32 TZPAN4012MSZN3L 2 50/P 4842 040704
Q'TY
Q'TY
/
PARTS NAME P I R
PAGE
/
PACK
SPE
PRICE
IN NONE
BSI
NO.
TO FROM
SERIAL
NO.
REMARKS
3
TOSHIBA
1360/1370 UPPER-UNIT-ASM DECEMBER 2002
4
1360/1370 DECEMBER 2002
ITEM
NO.
PARTS
NO.
1 FRAME-UP-F 1 N/A*** 4402 843020
2 ACTR-SW-SHELL 1 1/P 4402 843860
3 SHAFT-ARM-LOCK 1 1/P 4402 843330
4 ARM-LOCK-F 1 1/P 4402 843340
5 LABEL-ARM-LOCK 1 5/P 4402 843950
6 ARM-LOCK-R 1 1/P 4402 843350
7 SPE-ARM-LOCK 1 5/P 4402 843960
8 GUIDE-CLN 1 1/P 4402 847230
9 GUIDE-DEV 1 1/P 4402 843140
10 ASM-BAR-TORSION 1 1/P 4402 843200
12 MYLAR-GUIDE-CL2 1 5/KP 4402 844080
13 SPL-ROL-GUIDE 2 1/P 4402 844210
14 ROLLER-GUIDE-CL 2 1/P 4402 844220
41 TZPAN3006MSZN3L 10 50/P 4842 040690
42 ZPAN30*08MSZN3A 2 50/P 7640 300851
43 ERR050SKZN3A 1 50/P 7405 005031
44 TZPAN3008MSZN3L 1 50/P 4842 040692
Q'TY
Q'TY
/
PARTS NAME P I R
PAGE
/
PACK
SPE
PRICE
IN NONE
BSI
NO.
TO FROM
SERIAL
NO.
REMARKS
4
TOSHIBA
1360/1370 DRIVE-ASM DECEMBER 2002
5
1360/1370 DECEMBER 2002
ITEM
NO.
PARTS
NO.
1 K-FRAME-U-R 1 N/A*** 4402 844270
2 GEAR-0.8-Z32-20 1 1/P 4402 853110
3 GEAR-0.8-Z28-20 1 1/P 4402 853100
4 BRKT-ARM-FUSER 1 1/P 4402 853010
5 GEAR-0.8-Z35-20 1 1/P 4402 853020
6 BRKT-SFT-ARM-FU 1 1/P 4402 853170
7 BRKT-DRIVE-DEV 1 1/P 4402 853160
8 BRKT-COV-R 1 1/P 4402 844230
9 CLP/W-OCB-375 1 5/P 4843 390803
10 J-0-175694-3 1 5/P 4843 306486
11 GEAR-20/0.8-Z28 1 1/P 4402 853030
12 STUD-6-41-M3 1 1/P 4402 853040
16 K-FRAME-DRIVE 1 1/P 4402 853080
17 M/DC-MAIN-121 1 1/C 4402 858800
18 K-PLY/T-3M-MTR 1 1/P 4402 852860
19 K-PLY/T-3M-DEV 1 1/P 4402 852880
20 GEAR-Z26-DEV 1 1/P 4402 852900
21 PLY-TENSION-F 1 1/P 4400 353370
22 PLY/T-3M-30-FED 1 1/P 4402 852910
23 BRKT-FULL-SW 1 1/P 4402 853180
24 SP-CS3A-B2BA 1 1/D 4402 859600
25 BRKT-ARM-FEED 1 1/P 4402 853200
26 GEAR-0.8-Z37 1 1/P 4402 852960
27 STUD-6-26-M3 1 1/P 4402 852970
28 BLT/T-73133-4 1 1/P 4402 852920
29 CLP/W-WS-1U 1 5/P 4843 390887
30 THMS-DRUM-121 1 1/C 4402 842890
31 BRKT-COV-R-SUB 1 1/P 4402 844260
32 WASHER 1 10/P 4348 141020
71 ZPAN30*08MSZN3A 2 50/P 7640 300851
72 ERR050SKZN3A 1 50/P 7405 005031
73 TZPAN3006MSZN3L 12 50/P 4842 040690
74 TZPAN3012MSZN3L 2 50/P 4842 040696
Q'TY
Q'TY
/
PARTS NAME P I R
PAGE
/
PACK
SPE
PRICE
IN NONE
BSI
NO.
TO FROM
SERIAL
NO.
REMARKS
5
TOSHIBA
1360/1370 OPTICAL-DRIVE-1-ASM DECEMBER 2002
6
1360/1370 DECEMBER 2002
ITEM
NO.
PARTS
NO.
1 BASE-OPT 1 N/A*** 4402 851520
2 SHEET-CRG 1 5/KP 4402 852990
3 MIRROR-6-120 1 1/C 4402 851550
4 SPL-MIRROR1-R/6 2 5/P 4402 851560
5 COVER-OPT-L 1 1/PP 4402 851470
6 K-M/P-SCN-121 1 1/C 4402 858910
7 PLY/T-25/39 1 1/P 4402 851680
8 STUD-PLY/T-OPT 1 1/P 4402 851690
9 K-PLY/T-ADJ-OPT 1 1/P 4402 851780
10 K-BRKT-BLT-ADJ 1 1/P 4402 851750
11 SPE-063-080-235 1 5/P 4363 271330
12 BLT/T-2M-75-4 1 1/P 4402 851710
13 BLT/T-2M-475-4 1 1/P 4402 851700
14 SHAFT-SCAN-120 1 1/P 4402 851660
15 FELT-OPT-121 2 1/P 4402 850700
16 BRKT-SHAFT-SCAN 1 1/P 4402 851810
17 WIRE/R-SCAN-120 1 1/P 4402 851730
18 SZ-HOME-121 1 1/P 4402 842620
19 COV-OPT-L-SLIT 1 1/PP 4402 851490
20 GLASS-DUSTPROOF 1 1/S 4402 851480
21 HLDR-CABLE-OPT 1 1/P 4402 850570
22 SEAL-HOLE-OPT 1 5/P 4402 851300
23 TAPE-WHITE-120 1 1/KP 4402 851370
24B BAND-SG-130 1 5/P 1370 4407 737310
25 SEAL-BASE-OPT 1 1/KP 4402 852790
26 SEAL-MIRROR6-F 1 5/P 4402 851250
27 SEAL-MIRROR6-R 1 5/P 4402 851260
61 TZPAN3006MSZN3L 7 50/P 4842 040690
62 TPPAN4006MSZN3L 1 50/P 4842 040724
63 ZPAN30*08MSZN3A 1 50/P 7640 300851
65 ERR070SKZN3A 1 50/P 7405 007031
66 ERR050SKZN3A 1 50/P 7405 005031
67 PTBR30*08MSZN3A 1 50/P 4842 040846
Q'TY
Q'TY
/
PARTS NAME P I R
PAGE
/
PACK
SPE
PRICE
IN NONE
BSI
NO.
TO FROM
SERIAL
NO.
REMARKS
6
TOSHIBA
1360/1370 OPTICAL-DRIVE-2-ASM DECEMBER 2002
7
1360/1370 DECEMBER 2002
ITEM
NO.
PARTS
NO.
1B GUIDE-L/M 1 1/P 1370 4402 851580
2B SHEET-LENS 1 5/KP 1370 4402 851530
3B SHEET-MIRROR 1 5/P 1370 4402 851540
4A BASE-CRG3-1340 1 N/A*** 1360 4402 856330
4B K-CRG3 1 1/P 1370 4402 852620
5 HOLDER-MIR4/5-F 1 1/P 4402 852060
6 HOLDER-MIR4/5-R 1 1/P 4402 852130
7 MIRROR-4-120 1 1/C 4402 852070
8 MIRROR-5-120 1 1/S 4402 852080
9 SPL-MIRROR4/5 4 5/P 4402 852090
10B K-BKT-LINK-CRG3 1 1/P 1370 4402 852630
11B RLR-LINK-CRG3 1 1/P 1370 4402 852260
12 SEAL-CRG3 2 5/P 4402 851310
13B PL-GUIDE-CRG3 1 1/P 1370 4402 852120
14A BASE-LENS-1340 1 N/A*** 1360 4402 856340
14B K-BASE-LENS 1 N/A*** 1370 4402 852150
15 BRKT-LENS 1 N/A*** 4402 852250
16 LENS-155-6.7 1 N/A*** 4402 852180
17 BAND-LENS 1 N/A*** 4402 852200
18 COVER-LENS 1 1/P 4402 852210
19B PLATE-H/P-L/M 1 N/A*** 1370 4402 852220
20B SEAL-COV-LENS 1 5/P 1370 4402 851320
21B BRUSH-BASE-LENS 1 N/A*** 1370 4402 851340
22B PL-GUIDE-LENS 1 1/P 1370 4402 852230
23B PLATE-BELT-LENS 1 1/P 1370 4402 852240
24B K-DRIVE-L/M 1 1/P 1370 4402 851910
25B K-M/P-CAM-121 1 1/C 1370 4402 858820
29B PLY/T-16-Z20 1 1/P 1370 4402 852000
30B K-IDLE-L/M 1 1/P 1370 4402 852710
31B PLY/T-16 1 1/P 1370 4402 852740
32B BLT/T-2M-242-4 1 1/P 1370 4402 852010
33B BRKT-SENSOR-L/M 1 1/P 1370 4402 851890
34B SZ-HOME-121 1 1/P 1370 4402 842620
35B SPE-CRG3 1 5/P 1370 4402 852750
36 BLK-AES-120 1 1/P 4402 851830
37 PWA-F-AES-121 1 1/SB 4402 858020
38A WH-AES-120 1 1/P 1360 4402 858710
38B WH-ZOOM-121 1 1/P 1370 4402 858610
39 CLP/W-OCB-375 1 5/P 4843 390803
40 COVER-OPT-U 1 1/PP 4402 851590
41 STAY-GLASS-F 1 1/P 4402 851620
42 STAY-GLASS-R 1 1/P 4402 851630
43 CUSH-GLASS 8 5/P 4400 831600
44 GLASS-395-266-4 1 1/S 4402 851400
45 K-PLT-GLASS-ORG 1 1/PP 4402 851280
46A LBL-SCALE-UC 1 1/KP USA SIZE 4402 851430
46B LBL-SCALE-EUR 1 1/KP EUR SIZE 4402 851440
47B BOLT-CRG3 1 10/P 1370 4402 852360
49B CLP/W-UAMS-05-2 1 5/P 1370 4408 363830
50A ASM-LENS-1340-S 1 1/C 1360 4402 854700
50B ASM-LENS-1350-S 1 1/C 1370 4402 854710
51 SHEET-STAY-GLAS 1 5/P 4402 852390
52B MYL-COV-OPT-U 1 5/P 1370 4402 852760
53A SEAL-COV-OPT-U 1 5/P 1360 4402 850720
61A TZPAN3006MSZN3L 17 50/P 1360 4842 040690
61B TZPAN3006MSZN3L 28 50/P 1370 4842 040690
62 BID30*08MSCR1AI 2 50/P 7043 300813
63B ERR025SKZN3A 2 50/P 1370 7405 002531
64B TPAN30*04MSZN3A 1 50/P 1370 4842 040920
66B TPAN3006MSZN3L 2 50/P 1370 4842 040665
68B ERR030SKZN3A 3 50/P 1370 7405 003031
69 PTBR30*08MSZN3A 2 50/P 4842 040846
70A TPPAN3006MSZN3L 6 50/P 1360 4842 040710
70B TPPAN3006MSZN3L 2 50/P 1370 4842 040710
Q'TY
Q'TY
/
PARTS NAME P I R
PAGE
/
PACK
SPE
PRICE
IN NONE
BSI
NO.
TO FROM
SERIAL
NO.
REMARKS
7
TOSHIBA
1360/1370 OPTICAL-UNIT-1-ASM DECEMBER 2002
8
1360/1370 DECEMBER 2002
ITEM
NO.
PARTS
NO.
1 K-BASE-CRG1 1 1/PP 4402 852490
2 MIRROR-1-120 1 1/S 4402 852540
3 SPL-MIRROR1-F 1 5/P 4402 852580
4 SPL-MIRROR1-R/6 1 5/P 4402 851560
5 REFLECTOR-U-120 1 1/PP 4402 852560
6 REFLECTOR-L-120 1 1/PP 4402 852570
7 PLATE-ADJ-EXPO 2 1/P 4402 852590
8A LP-92-250W 1 1/S 100V SERIES 4402 859020
8B LP-184-250W 1 1/S 200V SERIES 4402 859030
9 BRG-DR22 1 1/P 4400 328270
10 K-SLIDER-CRG1 1 1/P 4400 326500
11 HOLDER-BLADE-F 1 1/P 4400 327810
12 BLADE-LAMP-EXPF 1 1/P 4400 326400
13 BLADE-FUSE-EXP 1 1/P 4400 327800
14 K-FU/T-091G4 1 1/P 4400 321200
15 TUBE/I-TFE-523 1 5/P 4400 358440
16 HOLDER-BLADE-R 1 1/P 4402 852660
17 BLADE-LAMP-EXPR 1 1/P 4400 326440
18A WH-EXPO-121 1 1/P 100V SERIES 4402 858420
18B WH-EXPO-121E 1 1/P 200V SERIES 4402 858520
19 SKB-BAND-1 2 5/P 4346 754010
20 PLATE-BELT-120 1 1/P 4402 851720
21 PLATE-WIRE-120 1 1/P 4402 851800
22 REFL-SIDE-F 1 1/P 4402 851380
23 REFL-SIDE-R 1 1/P 4402 851390
24 PL-ADJ-EXPO-FR 2 1/P 4402 852610
51 PAN30*06MSZN3A 1 50/P 7040 300611
52 PAN30*04MSZN3A 8 50/P 7040 300411
53 PAN30*10MSZN3A 2 50/P 7040 301011
54 ZPAN30*06MSZN3A 2 50/P 7640 300651
55 THPAN3006MSZN3L 1 50/P 4842 040480
56 6/0NUT60MSZN3A 1 50/P 7360 600011
57 PAN30*06BSDG 3 50/P 7040 300660
58 ZPAN30*08MSZN3A 2 50/P 7640 300851
Q'TY
Q'TY
/
PARTS NAME P I R
PAGE
/
PACK
SPE
PRICE
IN NONE
BSI
NO.
TO FROM
SERIAL
NO.
REMARKS
8
TOSHIBA
1360/1370 OPTICAL-UNIT-2-ASM DECEMBER 2002
9
1360/1370 DECEMBER 2002
ITEM
NO.
PARTS
NO.
1 BASE-CRG2 1 N/A*** 4402 852290
2 GUIDE-CRG2 1 1/P 4402 852300
3 HLDER-MIR2/3-F 1 1/P 4402 852370
4 HLDER-MIR2/3-R 1 1/P 4402 852320
5 K-PLY/Z-WIRE 2 1/P 4402 852330
6 MIRROR-2-120 1 1/C 4402 852400
7 MIRROR-3-120 1 1/C 4402 852410
8 SPL-MIRROR2/3 2 1/P 4402 852420
9 SPL-MIRROR2-F 1 1/P 4402 852440
10 BUSH-CRG2 2 1/P 4400 327110
11 GUIDE-CABLE-V 1 1/P 4400 329240
12 RING-CRG2-V 2 5/P 4400 329610
13 FOOT-CRG 1 1/P 4400 328470
14 SPL-MIRROR1-R/6 1 5/P 4402 851560
31 TZPAN3006MSZN3L 8 50/P 4842 040690
32 PAN30*12MSZN3AI 1 50/P 7040 301211
33 6/0NUT30MSZN3A 1 50/P 7360 300011
Q'TY
Q'TY
/
PARTS NAME P I R
PAGE
/
PACK
SPE
PRICE
IN NONE
BSI
NO.
TO FROM
SERIAL
NO.
REMARKS
9
TOSHIBA
1360/1370 FEEDER-ASM DECEMBER 2002
10
1360/1370 DECEMBER 2002
ITEM
NO.
PARTS
NO.
1 FRAME-FEED-F 1 1/P 4402 845710
2 FRAME-FEED-R 1 1/P 4402 845750
3 TERMINAL-BIAS 1 1/P 4402 843700
4 PLT-BIAS 1 1/P 4402 843710
5 SPC-BIAS-240 1 5/P 4400 532330
6 WH-DEV-BIAS-121 1 1/P 4402 858690
7 K-GUIDE-P-L 1 1/KP 4402 844810
8 MYLAR-GUIDE-L 2 5/KP 4402 844850
9 STAY-FEED 1 1/P 4402 845860
10 BRUSH-ALIGN-L 1 1/S 4402 845040
11 SZ-RGT-121 1 1/C 4402 842640
12 WH-FED-121 1 1/P 4402 858640
13 GUIDE-PAPER-U 1 N/A*** 4402 843110
14 MYLAR-GUIDE-U 1 N/A*** 4402 843130
15 CLR-030*0030F 2 5/P 4350 120890
16 ROLLER-ALIGN-L 1 1/KP 4402 844410
17 GEAR-Z30-0.5 1 1/P 4402 845180
19 BUSH-6-GCB 1 5/P 4407 734980
20 CLT-30E-CW-30 2 1/D 4402 858980
21 KNOB-RGT 1 1/P 4402 845890
22 SHAFT-CLT-FEED 1 1/P 4402 845340
23 BUSH-6L 3 5/P 4400 802070
24 BKT-CLH-FEED-1 1 1/P 4402 844440
25 GEAR-Z27-Z35 1 1/P 4402 845080
26 ROLLER-ALIGN-U 1 1/KP 4402 844460
27 GEAR-Z20-0.5 1 1/P 4402 845190
28 BUSH-ALIGN-U 2 5/P 4402 845260
29 SPE-ROL-RGT-F 1 5/P YELLOW 4402 845830
30 SPE-ROL-RGT-R 1 5/P BLACK 4402 845840
31 SHAFT-ROL-FEED 1 1/P 4402 845140
32 K-ROLL-FEED 2 1/P 4402 845130
33 CLUTCH-6-R 1 1/D 4402 833100
34 ROL-FEED-120 2 1/P 4402 845120
35 ROL-GUIDE-FED-R 1 1/P 4402 845770
36 GEAR-Z25-0.8 1 1/P 4402 845380
37 SZ-P-EMP-121 1 1/C 4402 842630
38 ROL-GUIDE-FED-F 1 1/P 4402 845760
39 STOP-RING-6.5 1 5/P 4407 972860
40 SPE-ROL-FEED-F 1 5/P 4402 845780
41 SPE-ROL-FEED-R 1 5/P 4402 845790
42 BUSH-CLT 1 5/P 4402 845930
43 GEAR-Z15-0.8 2 1/P 4402 845360
44 ARM-JOINT-CLT 1 1/P 4402 845920
45 J-6-175694-2 1 1/P BLACK 4843 308158
46 J-D-175694-2 1 5/P WHITE 4843 306485
47 K-GUIDE-P-U 1 1/PP 4402 843100
49 BRKT-BRUSH-ALN 1 1/P 4402 846040
50 STUD-6-23-M3 1 5/P 4402 844450
70 PTBR30*08MSZN3A 1 50/P 4842 040846
71 9HSS30/05MSFB 2 50/P 4842 011063
72 ERR050SKZN3A 9 50/P 7405 005031
73 TPAN3006MSZN3L 7 50/P 4842 040665
74 HPIN20/06SUSH7 1 50/P 4842 904018
75 HPIN20/12SUSH7 1 10/P 4842 904020
76 NPIN2-8 2 10/P 4407 403790
77 HPIN20/10SUSH7 1 50/P 4842 904035
78 TPAN3008MSZN3L 2 50/P 4842 040666
79 TZPAN3006MSZN3L 1 50/P 4842 040690
80 BID30*06MSCR1AI 1 50/P 7043 300613
Q'TY
Q'TY
/
PARTS NAME P I R
PAGE
/
PACK
SPE
PRICE
IN NONE
BSI
NO.
TO FROM
SERIAL
NO.
REMARKS
10
TOSHIBA
1360/1370 MANUAL-TRAY-ASM DECEMBER 2002
11
1360/1370 DECEMBER 2002
ITEM
NO.
PARTS
NO.
1 STAY-DEV-PUSH 1 1/P 4402 843150
2 HOLDER-DEV 2 1/P 4402 843900
3 PUSHER-DEV 2 1/P 4402 843910
4 ROLLER-PUSHER 2 5/P 4402 843920
5 SPC-STAY-PUS-DN 2 5/P 4402 844120
6 MYLAR-STAY 1 5/KP 4402 843870
7 COVER-RIGHT-L 1 1/PP 4402 841630
8 GUIDE-BYPASS-F 1 1/P 4402 845600
9 GUIDE-BYPASS-R 1 1/P 4402 845610
10 RACK-BYPASS 2 1/P 4402 845620
11 PINION-08-14 1 5/P 4402 845660
12 K-PLT-ADJUST 1 1/P 4402 845630
13A K-COV-BYPASS-LT 1 1/PP LT SIZE 4402 841900
13B K-COV-BYPASS-A4 1 1/PP A4 SIZE 4402 841910
51 TZPAN3006MSZN3L 8 50/P 4842 040690
52 12PAN3006MSZN3A 1 50/P 7120 300611
53 PTBR30*08MSZN3A 2 50/P 4842 040846
Q'TY
Q'TY
/
PARTS NAME P I R
PAGE
/
PACK
SPE
PRICE
IN NONE
BSI
NO.
TO FROM
SERIAL
NO.
REMARKS
11
TOSHIBA
Loading...
