BRUSH CUTTER BRC-28
RENTAL EQUIPMENT
The comprehensive Toro product line-up has expanded with the addition of the 28-inch hydraulic drive
brush cutter. This versatile machine is ideal for the rental industry, as performance, durability and
usability are key elements in its design. The commercial grade, self-propelled brush cutter allows operators to level brush, tall weeds, saplings and heavy vegetation with ease. The Toro hydro drive brush
cutter, featuring a pivoting deck, can handle brush up to six feet tall and saplings up to two inches in
diameter.
FE ATUR E S
QUALITY PERFORMANCE
• Larger fuel tank capacity combined with the 28 inch cutting deck increases operator productivity
• The flail blade can handle the toughest of jobs with increased cutting performance
• The pivoting deck makes for easy maneuvering over uneven terrain
• The standard hour meter keeps your machine up-to-date on service needs and back to work
DURABLE AND POWERFUL
• Superior product design, including a high-strength steel deck, 1 3/8 inch spindle shaft and large
diameter pulleys optimizes the longevity of the machine
• Sealant-filled, aggressive tread tires provide eective traction for brush removal projects on slopes,
ditches or culverts
• Standard electric start and a powerful 14.5 hp* Toro engine
• Improved electric clutch design holds-up against the force of blade impacts
EASY-TO-USE
• Simple, intuitive traction controls ensures both professional and novice operators alike will be
able to master
• Two-step blade engagement, coupled with a parking brake enhances usability for the operator
• Knuckle guards and durable rubber deck flaps give added protection during brush removal
• Maneuver this powerful machine in both forward and reverse with one-hand control feature
SPECIFICATIONS
BRC-28
(23522)
Cutting Width 28"
Cutting Height 3-3/4"
Engine* Toro 14.5 hp*
Electric Start Standard
Fuel Capacity 1 gallon
Deck
Spindle Diameter 1-3/8"
Transaxle Hydrogear T2
Dimensions (LxWxH) 89" x 30" x 42"
50 ksi high strength steel
Pivoting +/- 10 degrees w/spring return
Weight 375 lbs.
Brush cutter products are CARB exempt meeting EPA regulations
*The gross horsepower of this engine was laboratory rated at 3600 rpm by the engine
manufacturer in accordance with SAE J1940. As configured to meet safety, emission and
operating requirements, the actual horsepower on this class of product will be significantly
©2017 The Toro Company Part No. 490-9549 toro.com/rental
Produ cts dep icted in this lit erature are for demons tration purp oses only. Actual produc ts oered for sale may va ry in use, desi gn, required attachm ents and safet y features. We r eserve the
right to i mprove our prod ucts and make cha nges in specifi cations, designs and standard e quipment with out notice and without in curring obli gation. See yo ur dealer for det ails on all of our wa rranties.
lower.
Page 2
TORO ENGINE
THE RIGHT ENGINE
Engines… it’s where the Toro story started a century ago and one reason we continue
to excel today. Since 1914, we’ve earned our reputation based on a winning legacy
of dependability, durability and intelligent design. Built for longevity and raw power,
Toro single cylinder engines are perfectly matched to maximize performance of the
product they control. With heavy-duty components and innovative features, it is a
powerful ally to tackle your toughest outdoor tasks.
TESTED, PROVEN PERFORMANCE
We take quality control very seriously. Before each Toro engine leaves the assembly
line, it is tested under load and checked for power levels and governor response to
ensure consistent peak performance. Components are held to tight tolerances to
ensure consistent production.
PARTS AND SERVICE BACKED BY TORO
The Toro engine is fully supported by our parts and service team. Replacement parts for the engine are available through the
Toro parts department and available on tororental.com. Warranty on the engine is handled by our Toro warranty team, eliminating
the need for extra work contacting additional vendors and allows you to get your product back to work for your customers.
ENGINE BENEFITS:
LARGE BEARING MOUNTS
Increased size better distributes loading to help the engine last longer.
AUTOMOTIVE-STYLE PISTON ASSEMBLY
Triple ring design reduces engine oil consumption and blowby for maximum power.
CAST-IRON CYLINDER LINERS
Durable construction delivers extended wear for longer engine life.
See operator’s manual
for full details
