Toro 74706, 74727 Operator's Manual

FormNo.3417-979RevB

TimeCutter

®

SS4225orMX5025

RidingMower

ModelNo.74706—SerialNo.400000000andUp
ModelNo.74727—SerialNo.400000000andUp

Registeratwww.T oro.com.
OriginalInstructions(EN)

*3417-979*B

WARNING

CALIFORNIA

Proposition65Warning

Thisproductcontainsachemical

orchemicalsknowntotheStateof

Californiatocausecancer,birthdefects,

orreproductiveharm.

Theengineexhaustfromthisproduct

containschemicalsknowntotheStateof

Californiatocausecancer,birthdefects,

orotherreproductiveharm.

ItisaviolationofCaliforniaPublicResourceCode
Section4442or4443touseoroperatetheengineon
anyforest-covered,brush-covered,orgrass-covered
landunlesstheengineisequippedwithaspark
arrester,asdenedinSection4442,maintainedin
effectiveworkingorderortheengineisconstructed,
equipped,andmaintainedforthepreventionofre.

WARNING

Removingstandardoriginalequipmentparts
andaccessoriesmayalterthewarranty,
traction,andsafetyofthemachine.Failureto
useoriginalT oropartscouldcauseserious
injuryordeath.Makingunauthorizedchanges
totheengine,fuel,orventingsystem,may
violateregulations.

Replaceallpartsincluding,butnotlimited
to,tires,belts,blades,andfuelsystem
componentswithoriginalToroparts.

Theenclosedengineowner'smanualissupplied
forinformationregardingtheUSEnvironmental
ProtectionAgency(EPA)andtheCaliforniaEmission
ControlRegulationofemissionsystems,maintenance,
andwarranty.Replacementsmaybeorderedthrough
theenginemanufacturer.

Introduction

Thismachineisaride-on,rotary-bladelawnmower
intendedtobeusedbyhomeownersinresidential
applications.Itisprimarilydesignedforcuttinggrass
onwell-maintainedlawns.Itisnotdesignedforcutting
brush,mowinggrassandothergrowthalongside
highways,orforagriculturaluses.

Readthisinformationcarefullytolearnhowtooperate
andmaintainyourproductproperlyandtoavoid
injuryandproductdamage.Youareresponsiblefor
operatingtheproductproperlyandsafely .

YoumaycontactTorodirectlyatwww.Toro.com
forproductsafetyandoperationtrainingmaterials,
accessoryinformation,helpndingadealer,orto
registeryourproduct.

FortheOperator’sManual,thecompletewarranty
details,ortoregisteryourproduct,usetheQR
codeorvisitwww.Toro.com.Y oumayalsocallus
at1-888-384-9939torequestawrittencopyofthe
productwarranty.

Wheneveryouneedservice,genuineToroparts,or
additionalinformation,contactanAuthorizedService
DealerorToroCustomerServiceandhavethemodel
andserialnumbersofyourproductready.Figure1
identiesthelocationofthemodelandserialnumbers
ontheproduct.Writethenumbersinthespace
provided.

Important:Withyourmobiledevice,youcan

scantheQRcodeontheserialnumberdecal(if
equipped)toaccesswarranty,parts,andother
productinformation.

GrossorNetTorque

Thegrossornettorqueofthisenginewaslaboratory
ratedbytheenginemanufacturerinaccordancewith
theSocietyofAutomotiveEngineers(SAE)J1940
orJ2723.Asconguredtomeetsafety,emission,
andoperatingrequirements,theactualenginetorque
onthisclassofmowerwillbesignicantlylower.
Pleaserefertotheenginemanufacturer’sinformation
includedwiththemachine.

Pleaserefertotheenginemanufacturer’sinformation
includedwiththemachine.

Gotowww.Toro.comtoviewspecicationsonyour
mowermodel.

©2017—TheToro®Company
8111LyndaleAvenueSouth
Bloomington,MN55420

Figure1

1.Modelandserialnumberplate

Writetheproductmodelandserialnumbersinthe
spacebelow:

Contactusatwww.Toro.com.

2

AllRightsReserved

g235765

PrintedintheUSA

ModelNo.

SerialNo.

Thismanualidentiespotentialhazardsandhas
safetymessagesidentiedbythesafety-alertsymbol
(Figure2),whichsignalsahazardthatmaycause
seriousinjuryordeathifyoudonotfollowthe
recommendedprecautions.

Figure2

Safety-alertsymbol

Thismanualuses2wordstohighlightinformation.
Importantcallsattentiontospecialmechanical
informationandNoteemphasizesgeneralinformation
worthyofspecialattention.

Contents

Safety.......................................................................4

GeneralSafety...................................................4

SlopeIndicator...................................................5

SafetyandInstructionalDecals..........................6

ProductOverview...................................................13

Controls...........................................................13

BeforeOperation.................................................15

BeforeOperationSafety...................................15

AddingFuel......................................................15

PerformingDailyMaintenance..........................16

BreakinginaNewMachine..............................16

g000502

UsingtheSafety-InterlockSystem....................16

PositioningtheSeat..........................................17

AdjustingtheMotion-ControlLevers.................17

DuringOperation.................................................18

DuringOperationSafety...................................18

OperatingtheMowerBlade-ControlSwitch

(PTO)............................................................20

OperatingtheThrottle.......................................20

OperatingtheChoke........................................20

StartingtheEngine...........................................21

ShuttingOfftheEngine.....................................21

UsingtheMotion-ControlLevers.......................21

DrivingtheMachine..........................................22

UsingtheSideDischarge.................................23

AdjustingtheHeightofCut...............................24

AdjustingtheAnti-ScalpRollers........................24

AdjustingtheAnti-ScalpRollers........................25

OperatingTips.................................................25

AfterOperation....................................................26

AfterOperationSafety......................................26

PushingtheMachinebyHand..........................26

TransportingtheMachine.................................27

Maintenance...........................................................29

RecommendedMaintenanceSchedule(s)...........29

Pre-MaintenanceProcedures..............................30

MaintenanceSafety..........................................30

RaisingtheSeat...............................................30

Lubrication..........................................................31

GreasingtheBearings......................................31

EngineMaintenance...........................................31

EngineSafety...................................................31

ServicingtheAirCleaner..................................31

ServicingtheEngineOil....................................32

ServicingtheSparkPlug...................................34

CleaningtheCoolingSystem............................35

FuelSystemMaintenance...................................35

ReplacingtheIn-LineFuelFilter.......................35

ElectricalSystemMaintenance...........................36

ElectricalSystemSafety...................................36

ServicingtheBattery.........................................36

ServicingtheFuses..........................................38

DriveSystemMaintenance..................................38

CheckingtheTirePressure...............................38

ReleasingtheElectricBrake.............................39

BeltMaintenance................................................39

3

InspectingtheBelts..........................................39

ReplacingtheMower-DeckBelt........................39

MowerMaintenance.............................................42

ServicingtheCuttingBlades.............................42

LevelingtheMowerDeck..................................44

RemovingtheMowerDeck...............................46

InstallingtheMowerDeck.................................47

ReplacingtheGrassDeector..........................48

Cleaning..............................................................50

WashingtheUndersideoftheMower

Deck..............................................................50

DisposingofWaste...........................................50

Storage...................................................................51

StorageSafety..................................................51

CleaningandStorage.......................................51

StoringtheBattery............................................52

Troubleshooting......................................................53

Schematics.............................................................55

Safety

ThefollowinginstructionsarefromANSIstandard
B71.1-2012.

GeneralSafety

Thisproductiscapableofamputatinghandsand
feetandofthrowingobjects.Alwaysfollowallsafety
instructionstoavoidseriouspersonalinjury.

Usingthisproductforpurposesotherthanitsintended
usecouldprovedangeroustoyouandbystanders.

•Donotoperatethemachineneardrop-offs,

ditches,embankments,water,orotherhazards,or
onslopesgreaterthan15degrees.

•Useyourfullattentionwhileoperatingthe

machine.Donotengageinanyactivitythat
causesdistractions;otherwise,injuryorproperty
damagemayoccur

•Readandunderstandthecontentsofthis

Operator’sManualbeforestartingtheengine.

•Donotputyourhandsorfeetnearmoving

componentsofthemachine.

•Donotoperatethemachinewithoutallguards

andothersafetyprotectivedevicesinplaceand
workingonthemachine.

•Keepchildrenandbystandersoutoftheoperating

area.Neverallowchildrentooperatethemachine.

•Stopthemachine,shutofftheengine,andremove

thekeybeforeservicing,fueling,orunclogging
themachine.

Improperlyusingormaintainingthismachinecan
resultininjury.Toreducethepotentialforinjury,
complywiththesesafetyinstructionsandalwayspay
attentiontothesafety-alertsymbol,whichmeans
Caution,Warning,orDanger—personalsafety
instruction.Failuretocomplywiththeseinstructions
mayresultinpersonalinjuryordeath.

Youcanndadditionalsafetyinformationwhere
neededthroughoutthismanual.

4

SlopeIndicator

Figure3

Thispagemaybecopiedforpersonaluse.

1.Themaximumslopeyoucanoperatethemachineonis15degrees.Usetheslopecharttodeterminethedegreeofslopeof
hillsbeforeoperating.Donotoperatethismachineonaslopegreaterthan15degrees.Foldalongtheappropriateline
tomatchtherecommendedslope.

2.Alignthisedgewithaverticalsurface,atree,building,fencepole,etc.

3.Exampleofhowtocompareslopewithfoldededge

5

g011841

SafetyandInstructionalDecals

Safetydecalsandinstructionsareeasilyvisibletotheoperatorandarelocatednearanyarea
ofpotentialdanger.Replaceanydecalthatisdamagedormissing.

BatterySymbols

Someorallofthesesymbolsareonyourbattery .

decalbatterysymbols

1.Explosionhazard

2.Nore,opename,or
smoking

3.Causticliquid/chemical
burnhazard

4.Weareyeprotection.9.Flusheyesimmediately

5.ReadtheOperator's

Manual.

6.Keepbystandersasafe
distanceawayfromthe
battery.

7.Weareyeprotection;
explosivegasescan
causeblindnessandother
injuries.

8.Batteryacidcancause
blindnessorsevereburns.

withwaterandgetmedical
helpfast.

10.Containslead;donot
discard

Manufacturer'sMark

1.Indicatesthebladeisidentiedasapartfromtheoriginal
machinemanufacturer.

decal99-3943

99-3943

ForModelswith127cm(50inch)Decks

1.Engine

decaloemmarkt

93-7009

1.Warning—donotoperatethemowerwiththedeectorup
orremoved;keepthedeectorinplace.

2.Cutting/dismembermenthazardofhandorfoot,mower
blade—stayawayfrommovingparts.

decal105-7015

decal93-7009

1.Beltrouting

ForModelswith107cm(42-inch)Decks

105-7015

6

106-8717

1.Readtheinstructionsbeforeservicingorperforming
maintenance.

2.Checktirepressureevery25operatinghours.

3.Greaseevery25operatinghours.

4.Engine

decal106-8717

decal119-8870

119-8870

ForModelswith127cm(50inch)Decks

ForModelswith127cm(50inch)Decks

1.ReadtheOperator's
Manual.

2.Heightofcut

decal112-9840

1.Height-of-cut

112-9840

3.Removethekeyandread
theinstructionsbefore
servicingorperforming
maintenance.

decal117-2718

117-2718

119-8815

1.Parkingposition4.Neutral

2.Fast5.Reverse

3.Slow

decal119-8815

decal119-8871

119-8871

ForModelswith107cm(42inch)MowerDecks

1.Heightofcut

2.4-1/2inches6.2-1/2inches

3.4inches7.2inches

4.3-1/2inches8.1-1/2inches

5.3inches

7

121-0772

ForModelswith107cm(42inch)Decks

decal121-0772

1.Fast

4.Choke

2.Continuous-variablesetting5.Powertakeoff(PTO),blade-controlswitch

3.Slow

8

121-0773

ForModelswith127cm(50inch)Decks

decal121-0773

1.Fast

4.Choke

2.Continuous-variablesetting5.Powertakeoff(PTO),blade-controlswitch

3.Slow

9

decal121-2989b

121-2989

1.Bypassleverpositionfor
pushingthemachine

1.Trim—slow

2.Tow—medium

2.Bypassleverpositionfor
operatingthemachine

decal131-3947

131-3947

3.Mow—fast

10

132-0869

Note:Thismachinecomplieswiththeindustrystandardstabilitytestinthestaticlateralandlongitudinaltestswiththemaximum

recommendedslopeindicatedonthedecal.ReviewtheinstructionsforoperatingthemachineonslopesintheOperator’sManualas
wellastheconditionsinwhichyouwouldoperatethemachinetodeterminewhetheryoucanoperatethemachineinthoseconditions
onthatdayandatthatsite.Changesintheterraincanresultinachangeinslopeoperationforthemachine.Ifpossible,keepthe
cuttingunitsloweredtothegroundwhileoperatingthemachineonslopes.Raisingthecuttingunitswhileoperatingonslopescan
causethemachinetobecomeunstable.

decal132-0869

1.Warning—readthe
Operator'sManual.

2.Warning—beforeservicing,
engagetheparkingbrake,
removethekeyandthe
sparkplugconnection.

3.Cuttinghazardofhand,
mowerblade;pinching
hazardofhand,belt—keep
handsandfeetawayfrom
movingparts;keepall
guardsandshieldsinplace.

4.Thrownobject
hazard—keepbystanders
awayfromthemachine;
removedebrisfromthe
areabeforemowing;keep
thedeectorshielddown.

5.Ramptipping
hazard—whenloading
ontoatrailer,donotuse
dualramps;useonlya
singlerampwideenough
forthemachineandthat
hasaninclinelessthan
15degrees;backupthe
ramp(inreverse)anddrive
forwardofftheramp.

6.Bodilyharmhazard—no
riders;lookbehindyou
whenmowinginreverse.

7.Tippinghazardon
slopes—donotuseon
slopesnearopenwater;do
notuseonslopesgreater
than15degrees.

11

decal132-0872

132-0872

1.Thrownobject
hazard—keepbystanders
awayfromthemachine.

2.Thrownobjecthazard,
raisedbafe—donot
operatethemachinewith
anopendeck;usea
baggerorabafe.

1.ReadtheOperator’s
Manual.

2.Parkthemachineona
levelsurfacewhenlling
thefueltank.

3.Severinghazardofhand
orfoot—keepawayfrom
movingparts.

4.Entanglement
hazard—keepaway
frommovingparts;keep
allguardsandshieldsin
place.

decal138-2456

138-2456

3.Donotoverllthefuel
tank.

12

ProductOverview

Controls

Becomefamiliarwithallthecontrolsbeforeyoustart
theengineandoperatethemachine.

ControlPanel

g028411

Figure4

1.Footrest

2.Deector9.SmartSpeed™lever

3.Height-of-cutlever

4.Motion-controllever11.Mowerdeck

5.Controlpanel

6.Operatorseat

7.Engine

8.Gas-tankcap

10.Reardrivewheel

12.Anti-scalproller

13.Frontcasterwheel

Figure5

1.Throttlecontrol

2.Chokecontrol

3.Blade-controlswitch
(powertakeoff)

4.Keyswitch

KeySwitch

Thekeyswitch,usedtostartandshutofftheengine,
has3positions:OFF,RUN,andST ART.Referto

StartingtheEngine(page21).

ThrottleControl

Thethrottlecontrolstheenginespeed,andithasa
continuous-variablesettingfromtheSLOWtoFAST
position(Figure5).

ChokeControl

Usethechokecontroltostartacoldengine.

g032603

Blade-ControlSwitch(Power
Takeoff)

Theblade-controlswitch,representedbya
power-takeoff(PTO)symbol,engagesand
disengagespowertothemowerblades(Figure5).

Motion-ControlLevers

Usethemotion-controlleverstodrivethemachine
forward,reverse,andturneitherdirection(Figure4).

13

ParkPosition

Height-of-CutLever

Movethemotion-controlleversoutwardfromthe
centertothePARKpositionwhenexitingthemachine
(Figure18).Alwayspositionthemotion-controllevers
intothePARKpositionwhenyoustopthemachineor
leaveitunattended.

SmartSpeed™ControlSystem
Lever

TheSmartSpeed™Control-Systemlever,located
belowtheoperatingposition,givesyouachoiceto
drivethemachineat3speedranges—trim,tow,and
mow(Figure21).

Fuel-PresenceWindow

Youcanusethefuelwindow,locatedontheleftside
ofthemachine,toverifythepresenceoffuelinthe
tank(Figure6).

Usetheheight-of-cutlevertolowerandraisethedeck
fromtheseatedposition.Movingtheleverup(toward
you)raisesthedeckfromthegroundandmovingthe
leverdown(awayfromyou)lowersthedecktoward
theground.Adjusttheheight-of-cutonlywhilethe
machineisnotmoving(Figure22).

Attachments/Accessories

AselectionofToroapprovedattachmentsand
accessoriesisavailableforusewiththemachineto
enhanceandexpanditscapabilities.Contactyour
AuthorizedServiceDealerorDistributororgoto
www.T oro.comforalistofallapprovedattachments
andaccessories.

Tobestprotectyourinvestmentandmaintainoptimal
performanceofyourToroequipment,countonT oro
genuineparts.Whenitcomestoreliability,T oro
deliversreplacementpartsdesignedtotheexact
engineeringspecicationofourequipment.Insiston
Torogenuineparts.

1.Fuel-presencewindow

g014521

Figure6

14

Operation

Note:Determinetheleftandrightsidesofthe

machinefromthenormaloperatingposition.

BeforeOperation

BeforeOperationSafety

GeneralSafety

•Neverallowchildrenoruntrainedpeopleto

operateorservicethemachine.Localregulations
mayrestricttheageoftheoperator.Theowner
isresponsiblefortrainingalloperatorsand
mechanics.

•Becomefamiliarwiththesafeoperationofthe

equipment,operatorcontrols,andsafetysigns.

•Knowhowtostopthemachineandshutoffthe

enginequickly.

•Checkthatoperator-presencecontrols,safety

switches,andshieldsareattachedandfunctioning
properly.Donotoperatethemachineunlessthey
arefunctioningproperly.

•Beforemowing,alwaysinspectthemachineto

ensurethattheblades,bladebolts,andcutting
assembliesareingoodworkingcondition.
Replacewornordamagedbladesandboltsinsets
topreservebalance.

•Inspecttheareawhereyouwillusethemachine

andremoveallobjectsthatthemachinecould
throw.

•Evaluatetheterraintodeterminetheappropriate

equipmentandanyattachmentsoraccessories
requiredtooperatethemachineproperlyand
safely.

FuelSafety

•Toavoidpersonalinjuryorpropertydamage,use

extremecareinhandlingfuel.Fuelvaporsare
ammableandexplosive.

•Extinguishallcigarettes,cigars,pipes,andother

sourcesofignition.

•Useonlyanapprovedfuelcontainer.

•Donotremovethefuelcaporaddfueltothefuel

tankwhiletheengineisrunningorwhilehot.

•Donotrefuelthemachineindoors.

•Donotstorethemachineorfuelcontainerwhere

thereisanopename,spark,orpilotlight,such
asonawaterheateroronotherappliances.

•Donotllcontainersinsideavehicleoronatruck

ortrailerbedwithaplasticliner.Alwaysplace

containersontheground,awayfromyourvehicle
beforelling.

•Removetheequipmentfromthetruckortrailer

andrefuelitwhileitisontheground.Ifthisisnot
possible,thenrefuelfromaportablecontainer
ratherthanafuel-dispensernozzle.

•Donotoperatethemachinewithouttheentire

exhaustsysteminplaceandinproperworking
condition.

•Keepthefuel-dispensernozzleincontactwith

therimofthefueltankorcontaineropeningat
alltimesuntilfuelingiscomplete.Donotusea
nozzlelock-opendevice.

•Ifyouspillfuelonyourclothing,changeyour

clothingimmediately.Wipeupanyfuelthatspills.

•Neveroverllthefueltank.Replacethefuelcap

andtightenitsecurely.

•Storefuelinanapprovedcontainerandkeepit

outofthereachofchildren.Neverbuymorethan
a30-daysupplyoffuel.

•Donotllthefueltankcompletelyfull.Addfuelto

thefueltankuntilthelevelis6to13mm(1/4to
1/2inch)belowthebottomofthellerneck.This
emptyspaceinthetankallowsfueltoexpand.

–Avoidprolongedbreathingofvapors.
–Keepyourfaceawayfromthenozzleandfuel

tankopening.

–Avoidcontactwithskin;washoffspillswith

soapandwater.

AddingFuel

RecommendedFuel

•Forbestresults,useonlyclean,fresh(lessthan

30daysold),unleadedgasolinewithanoctane
ratingof87orhigher((R+M)/2ratingmethod).

•Ethanol:Gasolinewithupto10%ethanol

(gasohol)or15%MTBE(methyltertiarybutyl
ether)byvolumeisacceptable.Ethanoland
MTBEarenotthesame.Gasolinewith15%
ethanol(E15)byvolumeisnotapprovedforuse.

Neverusegasolinethatcontainsmorethan
10%ethanolbyvolume,suchasE15(contains

15%ethanol),E20(contains20%ethanol),orE85
(containsupto85%ethanol).Usingunapproved
gasolinemaycauseperformanceproblemsand/or
enginedamagewhichmaynotbecoveredunder
warranty.

•Donotusegasolinecontainingmethanol.

•Donotstorefueleitherinthefueltankorfuel

containersoverthewinterunlessyouuseafuel
stabilizer.

•Donotaddoiltogasoline.

15

UsingStabilizer/Conditioner

Useafuelstabilizer/conditionerinthemachineto
providethefollowingbenets:

•Keepsfuelfreshduringstorageof90daysorless

(drainthefueltankwhenstoringthemachinefor
morethan90days)

•Cleanstheenginewhileitruns

•Eliminatesgum-likevarnishbuildupinthefuel

system,whichcauseshardstarting

Important:Donotusefueladditives

containingmethanolorethanol.

Addthecorrectamountoffuelstabilizer/conditioner
tothefuel.

Note:Afuelstabilizer/conditionerismost

effectivewhenmixedwithfreshfuel.T ominimize
thechanceofvarnishdepositsinthefuelsystem,
usefuelstabilizeratalltimes.

FillingtheFuelTank

g027243

Figure7

1.Parkthemachineonalevelsurface.

2.Engagetheparkingbrake.

3.Shutofftheengineandremovethekey.

4.Cleanaroundthefuel-tankcap.

5.Fillthefueltanktothebottomofthellerneck
(Figure7).

Note:Donotllthefueltankcompletelyfull.

Theemptyspaceinthetankallowsthefuelto
expand.

PerformingDaily Maintenance

Beforestartingthemachineeachday ,performthe
EachUse/DailyprocedureslistedinMaintenance

(page29).

BreakinginaNewMachine

Newenginestaketimetodevelopfullpower.Mower
decksanddrivesystemshavehigherfrictionwhen
new,placingadditionalloadontheengine.Allow
40to50hoursofbreak-intimefornewmachinesto
developfullpowerandbestperformance.

UsingtheSafety-Interlock System

WARNING

Ifthesafety-interlockswitchesare
disconnectedordamaged,themachinecould
operateunexpectedly,causingpersonal
injury.

•Donottamperwiththeinterlockswitches.

•Checktheoperationoftheinterlock
switchesdailyandreplaceanydamaged
switchesbeforeoperatingthemachine.

16

Understandingthe Safety-InterlockSystem

Thesafety-interlocksystemisdesignedtopreventthe
enginefromstartingunless:

•Theblade-controlswitch(PTO)isdisengaged.

•Themotion-controlleversareinthePARKposition.

Thesafety-interlocksystemalsoisdesignedtoshut
offtheenginewheneverthecontrolleversareoutof
thePARKpositionandyourisefromtheseat.

TestingtheSafety-Interlock System

Testthesafety-interlocksystembeforeyouusethe
machineeachtime.Ifthesafetysystemdoesnot
operateasdescribedbelow,haveanAuthorized
ServiceDealerrepairthesafetysystemimmediately .

1.Sitontheseat,movethemotion-controllevers
inthePARKposition,andmovetheblade-control
switchtotheONposition.Trystartingthe
engine;theengineshouldnotcrank.

2.Sitontheseatandmovetheblade-controlswitch
totheOFFposition.Moveeithermotion-control
levertothecenter,unlockedposition.Try
startingtheengine;theengineshouldnotcrank.
Repeatwiththeothermotion-controllever.

3.Sitontheseat,movetheblade-controlswitch
totheOFFposition,andlockthemotion-control
leversinthePARKposition.Starttheengine.
Whiletheengineisrunning,engagethe
blade-controlswitch,andriseslightlyfromthe
seat;theengineshouldshutoff.

4.Sitontheseat,movetheblade-controlswitch
totheOFFposition,andlockthemotion-control
leversinthePARKposition.Starttheengine.
Whiletheengineisrunning,movethe
motion-controlleverstothecenter,unlocked
position,engagetheblade-controlswitch,and
riseslightlyfromtheseat;theengineshould
shutoff.

g027632

Figure8

Adjustingthe Motion-ControlLevers

AdjustingtheHeight

Youcanadjustthemotion-controllevershigheror
lowerformaximumcomfort(Figure9).

g027252

Figure9

PositioningtheSeat

Theseatcanmoveforwardandbackward.Position
theseatwhereyouhavethebestcontrolofthe
machineandaremostcomfortable(Figure8).

AdjustingtheTilt

Youcanadjustthemotion-controlleversforwardor
rearwardforyourcomfort.

1.Loosentheupperboltholdingthecontrollever
tothecontrol-armshaft.

2.Loosenthelowerboltjustenoughtopivotthe
controlleverforwardorrearward(Figure9).

3.Tightenbothboltstosecurethecontrolleverin
thenewposition.

4.Repeattheadjustmentfortheothercontrollever.

17
