Toro 74465TE, 74466TE Operator's Manual

FormNo.3424-251RevA

122cmor132cmTITAN
SeriesRidingMower

ModelNo.74465TE—SerialNo.400000000andUp
ModelNo.74466TE—SerialNo.400000000andUp

®

HD1500

Registeratwww.T oro.com.
OriginalInstructions(EN)

*3424-251*A

ThisproductcomplieswithallrelevantEuropean
directives;fordetails,pleaseseetheseparateproduct
specicDeclarationofConformity(DOC)sheet.

Gotowww.Toro.comtoviewspecicationsonyour
model.

GrossorNetTorque:Thegrossornettorque
ofthisenginewaslaboratoryratedbytheengine
manufacturerinaccordancewiththeSocietyof
AutomotiveEngineers(SAE)J1940orJ2723.As
conguredtomeetsafety,emission,andoperating
requirements,theactualenginetorqueonthisclass
ofmowerwillbesignicantlylower.

Important:IfyouareusingamachinewithaT oro

engineabove1500m(5,000ft)foracontinuous
period,ensurethattheHighAltitudeKithasbeen
installedsothattheenginemeetsCARB/EPA
emissionregulations.TheHighAltitudeKit
increasesengineperformancewhilepreventing
spark-plugfouling,hardstarting,andincreased
emissions.Onceyouhaveinstalledthekit,attach
thehigh-altitudelabelnexttotheserialdecalon
themachine.ContactanyAuthorizedT oroService
DealertoobtaintheproperHighAltitudeKitand
high-altitudelabelforyourmachine.Tolocate
adealerconvenienttoyou,accessourwebsite
atwww.T oro.comorcontactourToroCustomer
CareDepartmentatthenumber(s)listedinyour
EmissionControlWarrantyStatement.

Removethekitfromtheengineandrestorethe
enginetoitsoriginalfactorycongurationwhen
runningtheengineunder1500m(5,000ft).Do
notoperateanenginethathasbeenconverted
forhigh-altitudeuseatloweraltitudes;otherwise,
youcouldoverheatanddamagetheengine.

Ifyouareunsurewhetherornotyourmachinehas
beenconvertedforhigh-altitudeuse,lookforthe
followinglabel(Figure3).

Introduction

Thisrotary-blade,ridinglawnmowerisintendedtobe
usedbyprofessional,hiredoperators.Itisdesigned
primarilyforcuttinggrassonwell-maintainedlawnson
residentialorcommercialproperties.Itisnotdesigned
forcuttingbrushorforagriculturaluses.

Readthisinformationcarefullytolearnhowtooperate
andmaintainyourproductproperlyandtoavoid
injuryandproductdamage.Youareresponsiblefor
operatingtheproductproperlyandsafely.

YoumaycontactTorodirectlyatwww.T oro.com
forproductsafetyandoperationtrainingmaterials,
accessoryinformation,helpndingadealer,orto
registeryourproduct.

Wheneveryouneedservice,genuineToroparts,or
additionalinformation,contactanAuthorizedService
DealerorToroCustomerServiceandhavethemodel
andserialnumbersofyourproductready.Figure1
identiesthelocationofthemodelandserialnumbers
ontheproduct.Writethenumbersinthespace
provided.

Important:Withyourmobiledevice,youcan

scantheQRcode(ifequipped)ontheserial
numberdecaltoaccesswarranty,parts,andother
productinformation.

©2018—TheToro®Company
8111LyndaleAvenueSouth
Bloomington,MN55420

Figure3

g233855

Figure1

decal127-9363

ModelNo.

SerialNo.

Thismanualidentiespotentialhazardsandhas
safetymessagesidentiedbythesafety-alertsymbol
(Figure2),whichsignalsahazardthatmaycause
seriousinjuryordeathifyoudonotfollowthe
recommendedprecautions.

Contactusatwww.Toro.com.

2

PrintedintheUSA

AllRightsReserved

Contents

Figure2

Safety-alertsymbol

Thismanualuses2wordstohighlightinformation.
Importantcallsattentiontospecialmechanical
informationandNoteemphasizesgeneralinformation
worthyofspecialattention.

g000502

Safety.......................................................................4

GeneralSafety...................................................4

SlopeIndicator...................................................5

SafetyandInstructionalDecals..........................6

ProductOverview...................................................12

Controls...........................................................12

Specications..................................................14

BeforeOperation.................................................14

BeforeOperationSafety...................................14

AddingFuel......................................................15

PerformingDailyMaintenance..........................16

BreakinginaNewMachine..............................16

UsingtheRollover-ProtectionSystem

(ROPS).........................................................16

UsingtheSafety-InterlockSystem....................17

PositioningtheSeat..........................................18

AdjustingtheMyRide™Suspension

System..........................................................19

UsingAttachmentsandAccessories.................20

DuringOperation.................................................20

DuringOperationSafety...................................20

EnteringtheOperator’sPosition.......................22

OperatingtheParkingBrake.............................22

OperatingtheMowerBlade-ControlSwitch

(PTO)............................................................22

OperatingtheThrottle.......................................23

OperatingtheChoke........................................23

StartingtheEngine...........................................24

ShuttingOfftheEngine.....................................24

UsingtheMotion-ControlLevers.......................25

DrivingtheMachine..........................................25

AdjustingtheHeightofCut...............................26

AdjustingtheAnti-ScalpRollers........................27

UsingtheSideDischarge.................................28

OperatingTips.................................................28

AfterOperation....................................................29

AfterOperationSafety......................................29

UsingtheFuel-ShutoffValve.............................29

UsingtheDrive-WheelReleaseValves.............29

TransportingtheMachine.................................30

Maintenance...........................................................32

RecommendedMaintenanceSchedule(s)...........32

Pre-MaintenanceProcedures..............................33

MaintenanceSafety..........................................33

ReleasingtheMower-DeckCurtain..................33

RemovingtheSheet-MetalGuard.....................34

Lubrication..........................................................34

GreasingtheMachine.......................................34

EngineMaintenance...........................................35

EngineSafety...................................................35

ServicingtheAirCleaner..................................35

ServicingtheEngineOil....................................37

ServicingtheSparkPlug...................................39

CleaningtheCoolingSystem............................40

CheckingtheSparkArrester.............................40

3

ReplacingtheEmissions-AirIntake

Filter..............................................................40

FuelSystemMaintenance...................................41

ReplacingtheFuelFilter...................................41

ServicingtheFuelT ank.....................................41

ElectricalSystemMaintenance...........................42

ElectricalSystemSafety...................................42

ServicingtheBattery.........................................42

ServicingtheFuses..........................................44

DriveSystemMaintenance..................................44

CheckingtheSeatBelt.....................................44

CheckingtheRoll-BarKnobs............................44

AdjustingtheTracking......................................45

CheckingtheTirePressure...............................46

CheckingtheWheelLugNuts...........................46

CoolingSystemMaintenance..............................46

CleaningtheEngineScreen.............................46

BrakeMaintenance.............................................47

AdjustingtheParkingBrake..............................47

BeltMaintenance................................................48

InspectingtheBelts..........................................48

ReplacingtheMowerBelt.................................48

ReplacingtheHydraulic-Pump-Drive

Belt................................................................49

ControlsSystemMaintenance.............................50

AdjustingtheControl-HandlePosition..............50

AdjustingtheMotion-ControlLinkage...............51

HydraulicSystemMaintenance...........................52

HydraulicSystemSafety...................................52

ServicingtheHydraulicSystem........................52

MowerDeckMaintenance....................................55

ServicingtheCuttingBlades.............................55

LevelingtheMowerDeck..................................57

RemovingtheMowerDeck...............................59

ReplacingtheGrassDeector..........................59

Cleaning..............................................................60

CleaningundertheMowerDeck.......................60

CleaningtheSuspensionSystem.....................60

DisposingofWaste...........................................60

Storage...................................................................61

StorageSafety..................................................61

CleaningandStorage.......................................61

Troubleshooting......................................................62

Schematics.............................................................64

Safety

Thismachinehasbeendesignedinaccordancewith
ENISO5395:2013.

GeneralSafety

Thisproductiscapableofamputatinghandsand
feetandofthrowingobjects.Alwaysfollowallsafety
instructionstoavoidseriouspersonalinjury .

Usingthisproductforpurposesotherthanitsintended
usecouldprovedangeroustoyouandbystanders.

•Alwayskeeptherollbarinthefullyraisedand

lockedpositionandusetheseatbelt.

•Useyourfullattentionwhileoperatingthe

machine.Donotengageinanyactivitythat
causesdistractions;otherwise,injuryorproperty
damagemayoccur.

•Donotoperatethemachineneardrop-offs,

ditches,embankments,water,orotherhazards,or
onslopesgreaterthan15degrees.

•Readandunderstandthecontentsofthis

Operator’sManualbeforestartingtheengine.

•Donotputyourhandsorfeetnearmoving

componentsofthemachine.

•Donotoperatethemachinewithoutallguards

andothersafetyprotectivedevicesinplaceand
workingonthemachine.

•Keepchildrenandbystandersoutoftheoperating

area.Neverallowchildrentooperatethemachine.

•Stopthemachine,shutofftheengine,andremove

thekeybeforeservicing,fueling,orunclogging
themachine.

Improperlyusingormaintainingthismachinecan
resultininjury .T oreducethepotentialforinjury,
complywiththesesafetyinstructionsandalwayspay
attentiontothesafety-alertsymbol,whichmeans
Caution,Warning,orDanger—personalsafety
instruction.Failuretocomplywiththeseinstructions
mayresultinpersonalinjuryordeath.

Youcanndadditionalsafetyinformationwhere
neededthroughoutthismanual.

4

SlopeIndicator

Figure4

Youmaycopythispageforpersonaluse.

1.Themaximumslopeyoucanoperatethemachineonis15degrees.Usetheslopecharttodeterminethedegreeofslopeof
hillsbeforeoperating.Donotoperatethismachineonaslopegreaterthan15degrees.Foldalongtheappropriateline
tomatchtherecommendedslope.

2.Alignthisedgewithaverticalsurface,atree,building,fencepole,etc.

3.Exampleofhowtocompareslopewithfoldededge

5

g011841

SafetyandInstructionalDecals

Safetydecalsandinstructionsareeasilyvisibletotheoperatorandarelocatednearanyarea
ofpotentialdanger.Replaceanydecalthatisdamagedormissing.

Manufacturer'sMark

1.Indicatesthebladeisidentiedasapartfromtheoriginal
machinemanufacturer.

BatterySymbols

Someorallofthesesymbolsareonyourbattery.

decaloemmarkt

decal106-5517

106-5517

1.Warning—donottouchthehotsurface.

decalbatterysymbols

1.Explosionhazard

2.Nore,opename,or
smoking

3.Causticliquid/chemical
burnhazard

4.Weareyeprotection.9.Flusheyesimmediately

5.ReadtheOperator's

Manual.

6.Keepbystandersasafe
distanceawayfromthe
battery.

7.Weareyeprotection;
explosivegasescan
causeblindnessandother
injuries.

8.Batteryacidcancause
blindnessorsevereburns.

withwaterandgetmedical
helpfast.

10.Containslead;donot
discard

93-7818

1.Warning—readtheOperator'sManualforinstructionson
torquingthebladebolt/nutto115-149N∙m(85-110ft-lb).

decal107-3069

107-3069

1.Warning—thereisnorolloverprotectionwhentherollbaris
down.

decal93-7818

2.Toavoidinjuryordeathfromarolloveraccident,keepthe
rollbarinthefullyraisedandlockedpositionandwear
theseatbelt.Lowertherollbaronlywhenabsolutely
necessary;donotweartheseatbeltwhentherollbaris
down.

3.ReadtheOperator'sManual;driveslowlyandcarefully .

6

decal112-3858

112-3858

1.ReadtheOperator's
Manual.

2.Readtheinstructions

3.Removethekeybefore
adjustingtheheightofcut.

4.Height-of-cutsettings.

beforeservicingor
performingmaintenance.

decal112-9028

112-9028

1.Warning—stayawayfrommovingparts;keepallguardsin
place.

decal116-8588

116-8588

1.ReadtheOperator’sManual.

2.Rotatethedrivereleaseknobtoloosen,slidetheknob,
andtighten.

3.Pushthemachine.

decal109-6014

109-6014

116–5610

1.Hourmeter4.Neutral

2.Powertake-off(PTO)5.Operator-presenceswitch

3.Parkingbrake6.Battery

decal116-5610

decal117-1 194

117-1194

1.Engine

7

117-3848

1.Thrownobjecthazard—keepbystandersasafedistance
awayfromthemachine.

2.Thrownobjecthazard,mower—donotoperatethemachine
withoutdeector,dischargecover ,orgrasscollection
systeminplace.

3.Cutting/dismembermentofhandorfoot—stayawayfrom
movingparts;keepallguardsandshieldsinplace.

decal117-3848

decal126-7816

126-7816

126-4363

1.Cutting/dismembermenthazard,fanandentanglement
hazard,belt.Shutofftheengineandremovethekeybefore
adjusting,servicingorcleaningthemachine.

decal126-4363

1.Heightofcut

decal126-8172

126-8172

1.Parkingbrakedisengaged2.Parkingbrakeengaged

8

decal126-9939

126-9939

1.ReadtheOperator’s
Manual.

1.Oildrain

131-1097

ToroEnginesOnly

2.Filltothebottomofthe
llerneck;warning—do
notoverllthetank.

decal136-8992

136-8992

1.Fuel—full

2.Fuel—50%

decal131-1097

3.Fuel—empty

decalptosymbols

PTOSwitchSymbols

1.PTO–disengage2.PTO–engage

136-9024

1.ReadtheOperator’s
Manualbeforeperforming

maintenance.

2.Operatinghours5.Hydraulic-uidlevel

3.Engine-oillevel6.Tirepressure

4.Greasepoint

decal136-9024

decaltransportlock

TransportLock

1.Heightofcut

2.Pulluptounlockthe
transportlock.

9

LeftMotionControl

decalmotioncntrllh-126-6194

decalmotioncntrlrh-126-6183

RightMotionControl

1.Machinespeed4.Neutral

2.Fast5.Reverse

3.Slow

1.Machinespeed4.Neutral

2.Fast5.Reverse

3.Slow

136-1305

1.Fast

2.Continuous-variablesetting5.Worklight(optional)

3.Slow

4.Choke

6.Powerpoint

10

decal136-1305

136-1720

1.Camlock2.Camunlock

decal136-1720

132-0871

Note:Thismachinecomplieswiththeindustrystandardstabilitytestinthestaticlateralandlongitudinaltestswiththemaximum

recommendedslopeindicatedonthedecal.ReviewtheinstructionsforoperatingthemachineonslopesintheOperator’sManualas
wellastheconditionsinwhichyouwouldoperatethemachinetodeterminewhetheryoucanoperatethemachineinthoseconditions
onthatdayandatthatsite.Changesintheterraincanresultinachangeinslopeoperationforthemachine.Ifpossible,keepthe
cuttingunitsloweredtothegroundwhileoperatingthemachineonslopes.Raisingthecuttingunitswhileoperatingonslopescan
causethemachinetobecomeunstable.

1.Warning—readtheOperator’sManual;donotoperatethis
machineunlessyouaretrained;wearhearingprotection.

2.Cutting,dismembering,andentanglementhazard—keep
handsawayfrommovingparts;keepallguardsandshieldsin
place.

3.Thrownobjecthazard—keepbystandersaway.6.Tippinghazardonslopes—donotuseonslopesnearopen

4.Ramphazard—whenloadingontoatrailer,donotusedual
ramps;onlyuseasingularrampwideenoughforthemachine
andthathasaninclinelessthan15°;backuptheramp(in
reverse)anddriveforwardofftheramp.

5.Bodilyharmhazard—donotcarrypassengers;lookbehind
youwhenmowinginreverse.

water;donotuseonslopesgreaterthan15°.

decal132-0871

11

ProductOverview

Figure5

1.Height-of-cutdeck-lift
pedal

2.Height-of-cutpositions8.Seatbelt

3.Transportlock9.Fuelcap

4.Controls

5.Motion-controllevers11.Mowerdeck

6.Rollbar

7.Shockassembly

10.Parking-brakelever

12.Casterwheel

KeySwitch

Thekeyswitch,usedtostartandshutofftheengine,
has3positions:OFF,RUN,andST ART.Referto

StartingtheEngine(page24).

ChokeControl

Usethechokecontroltostartacoldengine.Pullthe
chokecontroluptoengageit.Pushdownonthe
chokecontroltodisengageit.

ThrottleControl

Thethrottlecontrolstheenginespeed,andithasa
continuous-variablesettingfromtheSLOWtoFAST
position(Figure6).

g227688

Blade-ControlSwitch(Power
Takeoff)

Theblade-controlswitch,representedbya
power-takeoff(PTO)symbol,engagesand
disengagespowertothemowerblades(Figure6).

HourMeter

Controls

Becomefamiliarwithallthecontrolsbeforeyoustart
theengineandoperatethemachine(Figure5and

Figure6).

ControlPanel

Figure6

1.Powerport5.Blade-controlswitch

2.Chokecontrol

3.Throttlecontrol

4.Hourmeter

(powertakeoff)

6.Keyswitch

7.Switchpositionforoptional
lightkit

Thehourmeterrecordsthenumberofhoursthe
enginehasoperated.Itoperateswhentheengine
isrunning.Usethesetimesforschedulingregular
maintenance(Figure7).

Safety-InterlockIndicators

Therearesymbolsonthehourmeterthatindicate
withablacktrianglethattheinterlockcomponentis
positionedcorrectly(Figure7).

g037119

12

Battery-IndicatorLight

IfyouturntheignitionkeytotheONpositionfora
fewseconds,thebatteryvoltagedisplaysinthearea
wherethehoursarenormallydisplayed.

Thebatterylightturnsonwhentheignitionisturned
onandwhenthechargeisbelowthecorrectoperating
level(Figure7).

Figure7

g187133

1.Safety-interlocksymbols

2.Hourmeter

3.Batterylight

Motion-ControlLevers

Usethemotion-controlleverstodrivethemachine
forward,reverse,andturneitherdirection(Figure5).

Neutral-LockPosition

UsetheNEUTRAL-LOCKpositionwiththe
safety-interlocksystemtoengageandtodetermine
theNEUTRALposition.

Fuel-ShutoffValve

Closethefuel-shutoffvalvewhentransportingor
storingthemachine;refertoUsingtheFuel-Shutoff

Valve(page29).

Attachments/Accessories

AselectionofT oroapprovedattachmentsand
accessoriesisavailableforusewiththemachine
toenhanceandexpanditscapabilities.Contact
yourAuthorizedServiceDealerorauthorizedT oro
distributororgotowww.Toro.comforalistofall
approvedattachmentsandaccessories.

Toensureoptimumperformanceandcontinuedsafety
certicationofthemachine,useonlygenuineT oro
replacementpartsandaccessories.Replacement
partsandaccessoriesmadebyothermanufacturers
couldbedangerous,andsuchusecouldvoidthe
productwarranty.

13

Specications

Note:Specicationsanddesignaresubjecttochangewithoutnotice.

Width:

122cmmowerdeck132cmmowerdeck

Withoutmowerdeck

Deectorup133cm(53inches)144cm(56-3/4inches)

Deectordown160cm(63-1/4inches)171cm(67-1/4inches)

Length:

Length

Height:

RollBarUpRollBarDown

179cm(70-1/2inches)125cm(49inches)

Weight:

MachinesWeight

121cm(47-1/2inches)124cm(49inches)

122cmmowerdeck132cmmowerdeck

208cm(82inches)208cm(82inches)

421kg Machineswith122cmmowerdeck

928lb

429kg Machineswith132cmmowerdeck

946lb

Operation

Note:Determinetheleftandrightsidesofthe

machinefromthenormaloperatingposition.

BeforeOperation

BeforeOperationSafety

GeneralSafety

•Neverallowchildrenoruntrainedpeopleto

operateorservicethemachine.Localregulations
mayrestricttheageoftheoperator.Theowner
isresponsiblefortrainingalloperatorsand
mechanics.

•Becomefamiliarwiththesafeoperationofthe

equipment,operatorcontrols,andsafetysigns.

•Knowhowtostopthemachineandshutoffthe

enginequickly.

•Checkthatoperator-presencecontrols,safety

switches,andshieldsareattachedandfunctioning
properly.Donotoperatethemachineunlessthey
arefunctioningproperly.

•Beforemowing,alwaysinspectthemachineto

ensurethattheblades,bladebolts,andcutting
assembliesareingoodworkingcondition.
Replacewornordamagedbladesandboltsinsets
topreservebalance.

•Inspecttheareawhereyouwillusethemachine

andremoveallobjectsthatthemachinecould
throw.

•Evaluatetheterraintodeterminetheappropriate

equipmentandanyattachmentsoraccessories
requiredtooperatethemachineproperlyand
safely.

FuelSafety

•Toavoidpersonalinjuryorpropertydamage,use

extremecareinhandlingfuel.Fuelvaporsare
ammableandexplosive.

•Extinguishallcigarettes,cigars,pipes,andother

sourcesofignition.

•Useonlyanapprovedfuelcontainer.

•Donotremovethefuelcaporaddfueltothefuel

tankwhiletheengineisrunningorwhilehot.

•Donotrefuelthemachineindoors.

14

•Donotstorethemachineorfuelcontainerwhere

thereisanopename,spark,orpilotlight,such
asonawaterheateroronotherappliances.

•Donotllcontainersinsideavehicleoronatruck

ortrailerbedwithaplasticliner.Alwaysplace
containersontheground,awayfromyourvehicle
beforelling.

•Removetheequipmentfromthetruckortrailer

andrefuelitwhileitisontheground.Ifthisisnot
possible,thenrefuelfromaportablecontainer
ratherthanafuel-dispensernozzle.

•Donotoperatethemachinewithouttheentire

exhaustsysteminplaceandinproperworking
condition.

•Keepthefuel-dispensernozzleincontactwith

therimofthefueltankorcontaineropeningat
alltimesuntilfuelingiscomplete.Donotusea
nozzlelock-opendevice.

•Ifyouspillfuelonyourclothing,changeyour

clothingimmediately.Wipeupanyfuelthatspills.

•Neveroverllthefueltank.Replacethefuelcap

andtightenitsecurely.

•Storefuelinanapprovedcontainerandkeepit

outofthereachofchildren.Neverbuymorethan
a30-daysupplyoffuel.

•Donotllthefueltankcompletelyfull.Addfuelto

thefueltankuntilthelevelis6to13mm(1/4to
1/2inch)belowthebottomofthellerneck.This
emptyspaceinthetankallowsfueltoexpand.

–Avoidprolongedbreathingofvapors.

–Keepyourfaceawayfromthenozzleandfuel

tankopening.

–Avoidcontactwithskin;washoffspillswith

soapandwater.

AddingFuel

RecommendedFuel

•Forbestresults,useonlyclean,fresh(lessthan

30daysold),unleadedgasolinewithanoctane
ratingof87orhigher((R+M)/2ratingmethod).

•Ethanol:Gasolinewithupto10%ethanol

(gasohol)or15%MTBE(methyltertiarybutyl
ether)byvolumeisacceptable.Ethanoland
MTBEarenotthesame.Gasolinewith15%
ethanol(E15)byvolumeisnotapprovedforuse.

Neverusegasolinethatcontainsmorethan
10%ethanolbyvolume,suchasE15(contains

15%ethanol),E20(contains20%ethanol),orE85
(containsupto85%ethanol).Usingunapproved
gasolinemaycauseperformanceproblemsand/or
enginedamagewhichmaynotbecoveredunder
warranty.

•Donotusegasolinecontainingmethanol.

•Donotstorefueleitherinthefueltankorfuel

containersoverthewinterunlessyouuseafuel
stabilizer.

•Donotaddoiltogasoline.

UsingStabilizer/Conditioner

Usefuelstabilizer/conditionerinthemachineatall
timestokeepthefuelfreshlongerwhenusedas
directedbythefuel-stabilizermanufacturer.

Important:Donotusefueladditivescontaining

methanolorethanol.

Addtheamountoffuelstabilizer/conditionertofresh
fuelasdirectedbythefuel-stabilizermanufacturer.

FillingtheFuelTank

1.Parkthemachineonalevelsurface.

2.Engagetheparkingbrake.

3.Shutofftheengineandremovethekey.

4.Cleanaroundthefuel-tankcap.

5.Fillthefueltankuntilthefuelgaugereadsatthe
fullmark(Figure8).

Note:Donotllthefueltankcompletelyfull.

Theemptyspaceinthetankallowsthefuelto
expand.

15

Usingthe Rollover-ProtectionSystem (ROPS)

WARNING

Toavoidinjuryordeathfromrollover,keep
therollbarinthefullyraised,lockedposition
andusetheseatbelt.

Ensurethattheseatissecuredtothe
machine.

WARNING

Thereisnorolloverprotectionwhentheroll
barisinthedownposition.

•Lowertherollbaronlywhenabsolutely
necessary.

•Donotweartheseatbeltwhentherollbar
isinthedownposition.

Figure8

PerformingDaily Maintenance

Beforestartingthemachineeachday,performthe
EachUse/DailyprocedureslistedinMaintenance

(page32).

BreakinginaNewMachine

Newenginestaketimetodevelopfullpower.Mower
decksanddrivesystemshavehigherfrictionwhen
new,placingadditionalloadontheengine.Allow
40to50hoursofbreak-intimefornewmachinesto
developfullpowerandbestperformance.

•Driveslowlyandcarefully.

•Raisetherollbarassoonasclearance

g036751

permits.

•Checkcarefullyforoverheadclearances
(i.e.,branches,doorways,electricalwires)
beforedrivingunderanyobjectsanddo
notcontactthem.

LoweringtheRollBar

Important:Lowertherollbaronlywhen

absolutelynecessary.

1.T olowertherollbar,applyforwardpressureto
theupperpartoftherollbar.

2.Pullbothknobsoutandrotatethem90degrees
sotheyarenotengaged(Figure9).

3.Lowertherollbartothedownposition(Figure

9).

16

UsingtheSafety-Interlock System

WARNING

Ifthesafety-interlockswitchesare
disconnectedordamaged,themachinecould
operateunexpectedly,causingpersonal
injury.

•Donottamperwiththeinterlockswitches.

•Checktheoperationoftheinterlock
switchesdailyandreplaceanydamaged
switchesbeforeoperatingthemachine.

Understandingthe Safety-InterlockSystem

Thesafety-interlocksystemisdesignedtopreventthe
enginefromstartingunless:

•Theblade-controlswitch(PTO)isdisengaged.

Figure9

1.Rollbarintheupright
position

2.ROPSknobinthelatched
position

3.PulltheROPSknobout.6.Rollbarinthefolded

4.RotatetheROPSknob90
degrees.

5.ROPSknobinthe
unlatchedposition

position

RaisingtheRollBar

Important:Alwaysusetheseatbeltwiththeroll

barintheraisedposition.

1.Raisetherollbartotheoperatingpositionand
rotatetheknobsuntiltheymovepartiallyinto
thegrooves(Figure9).

2.Raisetherollbartothefulluprightpositionwhile
pushingontheupperrollbarsothatthepins
snapintopositionwhentheholesalignwiththe
pins(Figure9).

3.Pushontherollbarandensurethatbothpins
areengaged.

g036746

•Themotion-controlleversareintheNEUTRAL-LOCK

position.

•Theparkingbrakeisengaged.

Thesafety-interlocksystemisalsodesignedtoshutoff
theenginewhenthetractioncontrolsaremovedfrom
thelockedpositionwiththeparkingbrakeengagedor
ifyourisefromtheseatwhenthePTOisengaged.

Thehourmeterhassymbolstonotifytheuserwhen
theinterlockcomponentisinthecorrectposition.
Whenthecomponentisinthecorrectposition,a
trianglelightsupinthecorrespondingsquare.

g187670

Figure10

1.Triangleslightupwhentheinterlockcomponentsareinthe
correctposition

17

TestingtheSafety-Interlock System

ServiceInterval:Beforeeachuseordaily

Testthesafety-interlocksystembeforeyouusethe
machineeachtime.Ifthesafetysystemdoesnot
operateasdescribedbelow,haveanAuthorized
ServiceDealerrepairthesafetysystemimmediately .

1.Sitontheseat,engagetheparkingbrake,and
movetheblade-controlswitch(PTO)totheON
position.Trystartingtheengine;theengine
shouldnotcrank.

2.Sitontheseat,engagetheparkingbrake,and
movetheblade-controlswitch(PTO)totheOFF
position.Moveeithermotion-controllever(out
oftheNEUTRAL-LOCKposition).Trystartingthe
engine;theengineshouldnotcrank.Repeatfor
othercontrollever.

PositioningtheSeat

Theseatcanmoveforwardandbackward.Position
theseatwhereyouhavethebestcontrolofthe
machineandaremostcomfortable(Figure11).

3.Sitontheseat,engagetheparkingbrake,
movetheblade-controlswitch(PTO)totheOFF
position,andmovethemotion-controlleversto
theNEUTRAL-LOCKposition.Starttheengine.
Whiletheengineisrunning,disengagethe
parkingbrake,engagetheblade-controlswitch
(PTO),andriseslightlyfromtheseat;theengine
shouldshutoff.

4.Sitontheseat,engagetheparkingbrake,
movetheblade-controlswitch(PTO)totheOFF
position,andmovethemotion-controllevers
toNEUTRAL-LOCKposition.Starttheengine.
Whiletheengineisrunning,centereither
motion-controlleverandmoveitforwardor
reverse;theengineshouldshutoff.Repeatfor
othermotion-controllever.

5.Sitontheseat,disengagetheparkingbrake,
movetheblade-controlswitch(PTO)totheOFF
position,andmovethemotion-controlleversto
NEUTRAL-LOCKposition.Trystartingtheengine;
theengineshouldnotcrank.

g027632

Figure11

18

AdjustingtheMyRide™ SuspensionSystem

TheMyRide™suspensionsystemadjuststoprovide
asmoothandcomfortableride.Y oucanadjustthe
rear2-shockassembliestoquicklyandeasilychange
thesuspensionsystem.Positionthesuspension
systemwhereyouaremostcomfortable.

Adjusttherear-shockassemblies(Figure13).

AdjustingtheRear-Shock Assemblies

Theslotsfortherear-shockassemblieshave
detentpositionsforreference.Y oucanpositionthe
rear-shockassembliesanywhereintheslot,notjust
inthedetentpositions.

Thefollowinggraphicshowsthepositionforasoftor
rmrideandthedifferentdetentpositions(Figure12).

g227752

Figure12

1.Firmestposition3.Detentsintheslots

2.Softestposition

Note:Ensurethattheleftandrightrear-shock

assembliesarealwaysadjustedtothesamepositions.

g227753

g227751

Figure13

19

UsingAttachmentsand Accessories

UseonlyT oroapprovedattachmentsandaccessories.

Ifmorethanoneaccessory-mountkit(i.e.,bucket
kitoruniversalmountkit)isaddedtoanyofthe4
locationsshowninFigure14,addafront-weight
kit.ContactyourAuthorizedServiceDealerforthe
front-weightkit.

Figure14

1.Addafront-weightkitwhen2ormoreaccessory-mountkits

areinstalledatthesepositions.

•Keepyourhandsandfeetawayfromthecutting

units.Keepclearofthedischargeopeningatall
times.

•Lookbehindanddownbeforebackinguptobe

sureofaclearpath.

•Usecarewhenapproachingblindcorners,shrubs,

trees,orotherobjectsthatmayobscureyour
vision.

•Donotmowneardrop-offs,ditches,or

embankments.Themachinecouldsuddenlyroll
overifawheelgoesovertheedgeoriftheedge
givesway.

•Stopthebladeswheneveryouarenotmowing.

•Stopthemachine,shutofftheengine,remove

thekey,andinspectthebladesafterstrikingan
objectorifthereisanabnormalvibrationinthe
machine.Makeallnecessaryrepairsbefore
resumingoperation.

•Slowdownandusecautionwhenmakingturns

andcrossingroadsandsidewalkswiththe
machine.Alwaysyieldtheright-of-way.

g037417

•Disengagethedrivetothecuttingunit,shutoffthe

engine,andremovethekeybeforeadjustingthe
heightofcut(unlessyoucanadjustitfromthe
operatingposition).

DuringOperation

DuringOperationSafety

GeneralSafety

•Theowner/operatorcanpreventandisresponsible

foraccidentsthatmaycausepersonalinjuryor
propertydamage.

•Wearappropriateclothing,includingeye

protection;longpants;slip-resistant,substantial
footwear;andhearingprotection.Tiebacklong
hairanddonotwearloosejewelry.

•Donotoperatethemachinewhileill,tired,or

undertheinuenceofalcoholordrugs.

•Nevercarrypassengersonthemachineandkeep

bystandersandpetsawayfromthemachine
duringoperation.

•Operatethemachineonlyingoodvisibilitytoavoid

holesorhiddenhazards.

•Avoidmowingonwetgrass.Reducedtraction

couldcausethemachinetoslide.

•Ensurethatalldrivesareinneutral,theparking

brakeisengaged,andyouareintheoperating
positionbeforeyoustarttheengine.

•Neverrunanengineinanareawhereexhaust

gasesareenclosed.

•Neverleavearunningmachineunattended.

•Beforeleavingtheoperatingposition(including

toemptythecatchersortounclogthechute),do
thefollowing:

–Stopthemachineonlevelground.

–Disengagethepowertakeoffandlowerthe

attachments.

–Engagetheparkingbrake.

–Shutofftheengineandremovethekey .

–Waitforallmovingpartstostop.

•Donotoperatethemachinewhenthereistherisk

oflightning.

•Donotusethemachineasatowingvehicleunless

ithasahitchinstalled.

•Donotchangethegovernorspeedoroverspeed

theengine.

•Useonlyaccessoriesandattachmentsapproved

byToro.

•Thismachineproducessoundlevelsinexcess

of85dBAattheoperator’searandcancause
hearinglossthroughextendedperiodsof
exposure.

20

Figure15

1.Wearhearingprotection.

RolloverProtectionSystem (ROPS)Safety

•Donotremovetherollbarfromthemachine.

•Ensurethattheseatbeltisattachedandthatyou

canreleaseitquicklyinanemergency.

•Alwayswearyourseatbeltwhentherollbarisup.

•Checkcarefullyforoverheadobstructionsanddo

notcontactthem.

•Keeptherollbarinsafeoperatingconditionby

thoroughlyinspectingitperiodicallyfordamage
andkeepingallthemountingfastenerstight.

•Replaceadamagedrollbar.Donotrepairoralter

it.

machineorahandtrimmertomowthegrassin
theseareas.

•Avoidstarting,stopping,orturningthemachineon

slopes.Avoidmakingsuddenchangesinspeedor
direction;turnslowlyandgradually.

g229846

•Donotoperateamachineunderanyconditions

wheretraction,steering,orstabilityisinquestion.
Beawarethatoperatingthemachineonwet
grass,acrossslopes,ordownhillmaycausethe
machinetolosetraction.Lossoftractiontothe
drivewheelsmayresultinslidingandalossof
brakingandsteering.Themachinecanslideeven
ifthedrivewheelsarestopped.

•Removeormarkobstaclessuchasditches,holes,

ruts,bumps,rocks,orotherhiddenhazards.Tall
grasscanhideobstacles.Uneventerraincould
overturnthemachine.

•Useextracarewhileoperatingwithaccessoriesor

attachments,suchasgrass-collectionsystems.
Thesecanchangethestabilityofthemachine
andcausealossofcontrol.Followdirectionsfor
counterweights.

•Ifpossible,keepthedeckloweredtotheground

whileoperatingonslopes.Raisingthedeckwhile
operatingonslopescancausethemachineto
becomeunstable.

SlopeSafety

•Slopesareamajorfactorrelatedtolossofcontrol

androlloveraccidents,whichcanresultinsevere
injuryordeath.Theoperatorisresponsiblefor
safeslopeoperation.Operatingthemachineon
anysloperequiresextracaution.Beforeusingthe
machineonaslope,dothefollowing:

–Reviewandunderstandtheslopeinstructions

inthemanualandonthemachine.

–Useanangleindicatortodeterminethe

approximateslopeangleofthearea.

–Neveroperateonslopesgreaterthan15

degrees.

–Evaluatethesiteconditionsofthedayto

determineiftheslopeissafeformachine
operation.Usecommonsenseandgood
judgmentwhenperformingthisevaluation.
Changesintheterrain,suchasmoisture,can
quicklyaffecttheoperationofthemachineon
aslope.

•Identifyhazardsatthebaseoftheslope.Do

notoperatethemachineneardrop-offs,ditches,
embankments,water,orotherhazards.The
machinecouldsuddenlyrolloverifawheelgoes
overtheedgeortheedgecollapses.Keepasafe
distance(twicethewidthofthemachine)between
themachineandanyhazard.Useawalk-behind

1.SafeZone—usethe
machinehereonslopes
lessthan15degreesor
atareas.

2.DangerZone—usea
walk-behindmowerand/or
ahandtrimmeronslopes
greaterthan15degrees
andneardrop-offsor
water.

3.Water

g221745

Figure16

4.W=widthofthemachine

5.Keepasafedistance
(twicethewidthofthe
machine)betweenthe
machineandanyhazard.

21
