FormNo.3395-946RevB
MMX-655H-S,MMX-658H-S,and
MMX-858H-SMortarMixer
ModelNo.60213—SerialNo.315000001andUp
ModelNo.60216—SerialNo.315000001andUp
ModelNo.60220—SerialNo.315000001andUp
Registeratwww.T oro.com.
OriginalInstructions(EN)
*3395-946*B
ItisaviolationofCaliforniaPublicResourceCode
Section4442or4443touseoroperatetheengineon
anyforest-covered,brush-covered,orgrass-covered
landunlesstheengineisequippedwithaspark
arrester,asdenedinSection4442,maintainedin
effectiveworkingorderortheengineisconstructed,
equipped,andmaintainedforthepreventionofre.
Theenclosedengineowner'smanualissupplied
forinformationregardingtheUSEnvironmental
ProtectionAgency(EPA)andtheCaliforniaEmission
ControlRegulationofemissionsystems,maintenance,
andwarranty.Replacementsmaybeorderedthrough
theenginemanufacturer.
TireInformation—TheDOTtireinformationislocated
onthesideofeachtire.Thisinformationgivesload
andspeedratings.Replacementtiresshouldhavethe
sameorbetterratings;refertoSpecications(page
15)toensurethatthetiresonyourmachinemeetor
exceedtheweightrequirementsofyourmachine.
WARNING
CALIFORNIA
Proposition65Warning
Theengineexhaustfromthisproduct
containschemicalsknowntotheStateof
Californiatocausecancer,birthdefects,
orotherreproductiveharm.
Useofthisproductmaycauseexposure
tochemicalsknowntotheStateof
Californiatocausecancer,birthdefects,
orotherreproductiveharm.
DealerorToroCustomerServiceandhavethemodel
andserialnumbersofyourproductready.Figure1
identiesthelocationofthemodelandserialnumbers
ontheproduct.Writethenumbersinthespace
provided.
Important:Withyourmobiledevice,youcan
scantheQRcodeontheserialnumberdecal(if
equipped)toaccesswarranty,parts,andother
productinformation.
g248834
Figure1
Introduction
Thismachineisdesignedtomixmortar,plaster,
reproongmaterial,grout,andothersmall-grained
Portlandcementproducts.Avehicleequippedwith
anappropriatepintlehitchorballhitchcantowthe
machine.
Readthisinformationcarefullytolearnhowtooperate
andmaintainyourproductproperlyandtoavoid
injuryandproductdamage.Youareresponsiblefor
operatingtheproductproperlyandsafely .
YoumaycontactTorodirectlyatwww.T oro.com
forproductsafetyandoperationtrainingmaterials,
accessoryinformation,helpndingadealer,orto
registeryourproduct.
Wheneveryouneedservice,genuineToroparts,or
additionalinformation,contactanAuthorizedService
1.Modelandserialnumberlocation
ModelNo.
SerialNo.
Thismanualidentiespotentialhazardsandhas
safetymessagesidentiedbythesafety-alertsymbol
(Figure2),whichsignalsahazardthatmaycause
seriousinjuryordeathifyoudonotfollowthe
recommendedprecautions.
g000502
Figure2
Safety-alertsymbol
©2018—TheToro®Company
8111LyndaleAvenueSouth
Bloomington,MN55420
Contactusatwww.Toro.com.
2
PrintedintheUSA
AllRightsReserved
Thismanualuses2wordstohighlightinformation.
Importantcallsattentiontospecialmechanical
informationandNoteemphasizesgeneralinformation
worthyofspecialattention.
Contents
Safety.......................................................................4
SafeOperatingPractices....................................4
SafetyandInstructionalDecals..........................7
Setup........................................................................9
1InstallingtheDumpHandle..............................9
2InstallingtheT owPole.....................................9
3InstallingtheSafetyChain..............................10
4AdjustingtheMixingPaddles.........................10
ProductOverview...................................................12
Controls...........................................................12
EngineControls............................................13
Specications..................................................15
Operation................................................................16
ThinkSafetyFirst..............................................16
TowingtheMachine..........................................16
AdjustingtheAxleWidth...................................19
PreparingtoUsetheMachine...........................20
OpeningtheCowl.............................................20
OpeningandClosingtheCowl..........................21
AddingFuel......................................................21
PerformingDailyMaintenance..........................23
StartingtheEngine...........................................23
ShuttingOfftheEngine.....................................24
MixingtheMaterial...........................................24
DumpingtheMaterial........................................25
CleaningtheDrum............................................26
Maintenance...........................................................27
RecommendedMaintenanceSchedule(s)...........27
Pre-MaintenanceProcedures..............................28
PreparingtheMachineforMaintenance............28
DisconnectingtheSpark-PlugWire..................28
RemovingtheDividerPlate..............................28
InstallingtheDividerPlate................................28
Lubrication..........................................................29
LubricatingtheBearingsandSeals...................29
EngineMaintenance...........................................30
ServicingtheAirCleaner..................................30
ServicingtheEngineOil....................................31
ServicingtheSparkPlug...................................32
CleaningtheSparkArrester..............................34
RemovingandInstallingtheEngine..................35
FuelSystemMaintenance...................................37
CleaningtheFuel-SedimentCup......................37
DrainingtheFuelT ank......................................37
DriveSystemMaintenance..................................38
TireAirPressure...............................................38
InspectingtheTires..........................................38
TorquingtheWheelLugNuts............................38
ServicingtheReductionCase...........................39
BeltMaintenance................................................41
InspectingtheBelts..........................................41
AdjustingtheBeltT ension.................................41
ReplacingtheBelts...........................................42
AligningthePulleys..........................................44
PaddleMaintenance............................................45
AdjustingthePaddles.......................................45
3
Cleaning..............................................................47
CleaningtheMachine.......................................47
Storage...................................................................47
Troubleshooting......................................................49
Safety
Improperuseormaintenancebytheoperatoror
ownercanresultininjury.T oreducethepotential
forinjury ,complywiththesesafetyinstructions
andalwayspayattentiontothesafety-alertsymbol
(Figure2),whichmeans:Caution,Warning,or
Danger—personalsafetyinstruction.Failureto
complywiththeinstructionmayresultinpersonal
injuryordeath.
SafeOperatingPractices
Thisproductiscapableofamputatinghands.Always
followallsafetyinstructionstoavoidseriousinjuryor
death.
WARNING
Machiningorhandlingstone,masonry,
concrete,metal,andothermaterialscan
generatedust,mists,andfumescontaining
chemicals,suchassilica,knowntocause
seriousorfatalinjuryorillness,suchas
respiratorydisease,silicosis,cancer,birth
defects,orotherreproductiveharm.
•Controldust,mist,andfumesatthe
sourcewherepossible.Usewaterfordust
suppressionwheneverpossible.
•Usegoodworkpracticesandfollowthe
recommendationsofthemanufactureror
suppliers,OSHA,andotheroccupational
andtradeassociations.
•Alwaysfollowrespiratoryprecautions.
•Whenyoucannoteliminatethehazards
frominhalation,youandallbystanders
shouldweararespiratorapprovedby
OSHAforthematerialthatyouare
handling.
WARNING
Engineexhaustcontainscarbonmonoxide,
whichislethalifinhaled.
Donotruntheengineindoorsorinan
enclosedarea.
Training
•Parkthemachineonalevelsurface,shutoffthe
engine,waitforallmovingpartstostop,andallow
themachinetocoolbeforeadjusting,cleaning,
storing,orrepairingthemachine.
4
•Readandunderstandthecontentsofthis
Operator’sManualbeforeyoustarttheengine.
Ensurethateveryoneusingthisproductknows
howtouseitandunderstandsthewarnings.
•Becomefamiliarwiththesafeoperationofthe
equipment,operatorcontrols,andsafetysigns.
•Alloperatorsandmechanicsshouldbetrained.
Theownerisresponsiblefortrainingthem.
•Neverletchildrenoruntrainedpeopleoperateor
servicetheequipment.Localregulationsmay
restricttheageoftheoperator.
•Theowner/usercanpreventandisresponsible
foraccidentsorinjuriestopeopleordamageto
property.
Towing
•Checkwithyourlocalcountyorstatetowingsafety
regulationsbeforetowingthemachine.
•Toreducethepossibilityofanaccidentwhile
transportingthemachineonpublicroads,ensure
thatthetowingvehicleismechanicallysoundand
ingoodoperatingcondition.
•Shutofftheenginebeforetransportingthe
machine.
•Whentowingwithaballhitch,ensurethatitisthe
propersizeforthehitchcoupleronthemachine.
•Whentowingwithapintlehitch,ensurethatthe
eyeofthetowpoleisthecorrectdimensionfor
thepintlehook.
•Inspectthehitchandcouplingforwear.Donot
towthemachinewithdamagedorwornhitches,
couplings,chains,orothercomponents.
•Checktheairpressureofthetiresonthetowing
vehicleandadjustthepressureasneeded.
•Checkthetiretreadandsidewallfordamageand
wearandreplacethetireifnecessary.
•Properlyattachthesafetychainstothetowing
vehiclebycrossingthechainsandremovingany
extraslack.
•Ensurethatthedirectionalandbrakelightsare
workingproperly(ifequipped).
•Ensurethatthedirectional,backup,andbrake
lightsofthetowvehicleareworkingproperly(if
equipped).
•Beforetowing,ensurethatyourmachineis
correctlyandsecurelyattachedtothetowing
vehicle.
•Ensurethatthesafetychainsareproperlysecured
tothevehicle,andleaveenoughslackforturning.
•Donotcarryanymaterialinthemachinewhen
towing.
•Avoidsuddenstopsandstarts.Thiscancause
skiddingorjackkning.Smooth,gradualstartsand
stopsimprovestowing.
•Avoidsharpturnstopreventrolling.T owonlywith
avehiclethathasahitchdesignedfortowing.Do
notattachtowedequipmentexceptatthehitch
point.
•Donottowthemachinefasterthan88km/h(55
mph).
•Usecautionwhenbackingup;useaspotter
outsidethevehicletoguideyou.
•Donotallowanyonetositorrideonthemachine.
•Disconnectthemachinefromthetowvehicle
beforeusingit.
•Placechocksunderneaththetirestopreventthem
fromrollingwhilethemachineisparked.
Preparation
Becomefamiliarwiththesafeoperationofthe
equipment,operatorcontrols,andsafetysigns.
•Useonlyaccessoriesandattachmentsapproved
bythemanufacturer.
•Wearpersonalprotectiveequipmentand
appropriateclothingincluding:
–Hardhat
–Respiratorordustmask
–Faceshield
–Safetyglasses
–Hearingprotection
–Safetyshoes
–Longpants
–Shirtwithlongsleevesthataretightatthe
wrists
–Tight-ttinggloveswithoutdrawstringsorloose
cuffs
•Wearappropriateclothing,includingeye
protection;longpants;substantial,slip-resistant
footwear;andhearingprotection.Tiebacklong
hairanddonotwearloosejewelry .
•Ensurethatthemachineisonalevelsurface
beforeoperatingit.
•Chockthetiresofthemachinetoprevent
unintendedmovement.
•Beforeeveryuse,dothefollowing:
–Inspectthecoupler,ball,andhitch.
–Ensurethatalllightsarefunctioningproperly
(ifequipped).
–Ensurethatthetiresareproperlyinated.
–Ensurethatthelugnutsaretightandtorqued
properly.
–Ensurethatthemachineisproperlysecured.
5
FuelSafety
•Useextremecareinhandlingfuel.Itisammable
anditsvaporsareexplosive.
•Extinguishallcigarettes,cigars,pipes,andother
sourcesofignition.
•Ifthemixingpaddlesstrikeanobjectorifthe
machinestartsmakinganunusualnoiseor
vibration,shutofftheengine,waitforallmoving
partstostop,andemptythedrum.Inspectfor
cloggingordamage.Clean,repair,and/orreplace
anydamagedparts.
•Useonlyanapprovedfuelcontainer.
•Donotremovethefuelcaporllthefueltank
whiletheengineisrunningorhot.
•Donotaddordrainfuelinanenclosedspace.
•Donotstorethemachineorfuelcontainerwhere
thereisanopename,spark,orpilotlight,such
asonawaterheaterorotherappliance.
•Ifyouspillfuel,donotattempttostarttheengine;
avoidcreatinganysourceofignitionuntilthefuel
vaporshavedissipated.
Operation
•Useyourfullattentionwhileoperatingthe
machine.Donotengageinanyactivitythat
causesdistractions;otherwise,injuryorproperty
damagemayoccur.
•Donotrunanengineinanenclosedorpoorly
ventilatedarea.
•Operatethemachineonlyingoodlighting
conditions.
•Beforestartingthemachine,ensurethatthereare
nopeopleorobstaclesnearorunderthemachine.
•Shutofftheenginebeforeleavingthemachinefor
anyreason.
Neverleavearunningmachineunattended.
Alwaysshutofftheengineandverifythatall
movingpartshavestopped.
•Chockthetiresofthemachineorkeepitattached
tothetowingvehiclewhenitisnotinuse.
•Keepyourhandsawayfromanymovingparts.
Keepyourfeetawayfromthetiresandthefront
post.
•Donotoperatethemachineundertheinuence
ofalcoholordrugs.
•Donotplaceyourhandsoranysolidobjectinto
thedrumwhenthemachineisinoperation.
•Donottouchpartsthatmaybehotfromoperation.
Allowthemtocoolbeforeattemptingtomaintain,
adjust,orservicethemachine.
•Nevermovethemachinewhiletheengineis
running.
•Donotchangetheenginegovernorsettingor
overspeedtheengine.
•Donotoperatethemachinewhenthereistherisk
oflightning.
MaintenanceandStorage
•Beforeperformingmaintenance,dothefollowing:
–Parkthemachineonalevelsurface.
–Shutofftheengineandwaitforallmovement
tostopbeforeadjusting,cleaning,orrepairing
themachine.
–Lettheenginecoolbeforeperforming
maintenanceorstoringthemachine.
–Disengageallpowerandoperationcontrols.
•Neverlubricate,service,repair,oradjustthe
machinewiththeenginerunning.
•Keepequipmentmaterialsclearfromthemufer
andenginetopreventres.Cleanupoilorfuel
spills.
•Neverallowuntrainedpersonneltoservicethe
machine.
•Keepyourhands,feet,andclothingawayfrom
movingparts.Ifpossible,donotmakeadjustments
withtheenginerunning.
•Keepallpartsingoodworkingconditionandall
fastenerstightened.Replaceallwornordamaged
decals.
•Removeanybuildupofgrease,oil,ordebrisfrom
themachine.
•Stopandinspectthemachineifanobjectenters
thedrumorcausesanotherobstruction.Makeall
necessaryrepairsbeforestartingthemachine.
•Donottamperwithsafetydevices.
•Chockthetireswhenstoringthemachine.
•Keepallfastenersandhoseclampssecurely
tightenedandallequipmentingoodcondition.
•UseonlygenuineTororeplacementparts.
•Keepthecowlclosedandlatchedduringoperation.
•Ensurethatalltheguardsandshieldsaresecurely
inplacebeforeoperatingthemachine.
6
SafetyandInstructionalDecals
Safetydecalsandinstructionsareeasilyvisibletotheoperatorandarelocatednearanyarea
ofpotentialdanger.Replaceanydecalthatisdamagedormissing.
decal125-8175
125-8175
1.ReadtheOperator’sManualforinformationongreasing
themachine.
1.Warning—readthe
Operator’sManual.
2.Handandarm
entanglementatthe
beltdrive;crushinghazard
ofhand;entanglement
hazardofhandatthe
shaft—keepyourhands
awayfrommovingparts;
keepallguardsand
shieldsinplace.
3.Entanglementhazard
atpaddles—shutoff
theengineandwait
forallmovingpartsto
stopbeforeperforming
maintenance.
decal125-4939
125-4939
4.Toxicgasinhalation
hazard—Donotrunthe
engineinanenclosed
space.
5.Explosionhazard—shut
offtheengineandkeep
awayfromameswhen
refueling.
1.ReadtheOperator’s
Manualforinformationon
howtotowthemachine.
125-8216
2.Warning—limittowing
speedtolessthan88km/h
(55mph).
decal125-8216
7
decal130-8322
130-8322
1.Usefuelwithanalcohol
contentbyvolumeunder
10%only.
2.ReadtheOperator's
Manualformore
informationonfuel.
3.Donotusefuelwithan
alcoholcontentgreater
than10%byvolume.
decal133-5619
133-5619
8
Setup
LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.
ProcedureDescription
Dumphandle1
1
2
3
4
Carriagebolt
Nut2
Towpolekit(soldseparately)
Safetychain(includedwiththetowpole
kit)
Connectinglink(includedwiththetow
polekit)
Nopartsrequired
1
InstallingtheDumpHandle
Partsneededforthisprocedure:
1Dumphandle
2
Carriagebolt
2Nut
Qty.
Use
2
1
1
2
–
Installthedumphandle.
Installthetowpole(side-dumpmodels
only).
Installthesafetychain.
Adjustingthemixingpaddles.
Procedure
1.Cutthecabletiestoremovethedumphandle
fromtheundersideofthegrate.
2.Installthedumphandletothesideofthedrum
using2carriagebolts(installedontheinsideof
thedrum)andnutsasshowninFigure3.
g028569
Figure3
9
2
InstallingtheTowPole
Partsneededforthisprocedure:
1
Towpolekit(soldseparately)
4.Threadthenutontotheboltandtightenthem
untiltheyaretightagainsttheframetting
(Figure4).
Note:Iftheself-lockingnyloninsertinthe
locknutwearswithuse,replacethenutwitha
newGrade5orGrade8locknut.
3
TowPoleSpecications
Purchasethetowpolekit(includingfasteners)that
meetsyourneedsfromyourAuthorizedService
Dealer.Themachinehasthefollowingtowpole
options:
HitchTypeLength
50mm(2inch)ball—stamped78.7cm(31inches)or127cm
50mm(2inch)ball—forged78.7cm(31inches)or127cm
Pintle
(50inches)
(50inches)
78.7cm(31inches)or127cm
(50inches)
InstallingtheTowPole
1.Removetheboltandnutfromthetowpole
(Figure4).
InstallingtheSafetyChain
Partsneededforthisprocedure:
1
Safetychain(includedwiththetowpolekit)
2
Connectinglink(includedwiththetowpolekit)
Procedure
Safetychainandconnectinglinkareincludedinthe
towpolekit(soldseparately);referto2Installingthe
TowPole(page9).
Formahookontheendofabendablepieceofrodor
stiffwire(notincluded)andinstallthesafetychainand
connectinglinksasshowninFigure5.
Figure4
1.Towpole4.Bolthole
2.Frontpost
3.Bolt6.Nut
2.Slidethetowpoleforwardandaligntheholein
thepolewiththeholeintheframetting(Figure
4).
3.Inserttheboltthroughtheholesinthettingand
thepole(Figure4).
5.Frametting
g019804
g035100
Figure5
Note:Ensurethatapproximatelyequallengthsof
safetychainextendfromeithersideofthefrontpost.
10
4
AdjustingtheMixing
Paddles
NoPartsRequired
Procedure
Ifthemixingpaddlesandwipersneedadjustment,
adjustthepaddlesandwipers;refertoAdjustingthe
Paddles(page45).
11
ProductOverview
g019875
Figure7
1.Clutchlever
Figure6
Rightside
1.Rearcowl
2.Frontcowl8.Drumlatch14.Axle
3.Grate
4.Bagsplitter10.Towpole
5.Dumphandle
6.Grateliftarm
7.Clutchlever13.Chute
9.Frontpost15.Wheel
assembly
16.Cowllatch
11.Safety-chain
keyhole
12.Drum
Controls
Becomefamiliarwithallthecontrolsbeforeyou
operatethemachine.
ClutchLever
Usetheclutchlevertoengageanddisengagethe
paddles.
g028571
DrumLatch
Usethedrumlatchtosecurethedrumtothemix
position(upright)formixingoperationsandwhen
transportingthemachine.
g019877
Figure8
1.Drumlatch
12
DumpHandle
Usethedumphandletorotatethedrumtothedump
positionandtorotatethedrumtothemixposition
(upright).
Figure9
EngineControls
g019744
Figure10
1.Recoil-starthandle5.Fuelcap
2.Fuelvalve
3.Chokelever
g028572
4.Throttlelever
6.Oildipstick
7.Oil-drainplug
8.On/Offswitch
1.Dumphandle
FuelValve
Thefuelvalve(Figure11)islocatedunderneaththe
chokelever.Movetheleverforthefuelvalvetothe
ONpositionbeforeattemptingtostarttheengine.
Whenyouhavenishedmixing,shutofftheengine
andmovethefuel-valvelevertotheOFFposition.
Figure11
1.Fuelvalve3.Throttlelever
2.Chokelever
13
g018792
ChokeLever
Usethechokelever(Figure11)tostartacoldengine.
Beforepullingtherecoil-starthandle,movethechoke
levertotheCLOSEDposition.Oncetheengineis
running,movethechokelevertotheOPENposition.
Donotusethechokeiftheengineisalreadywarmed
uporiftheairtemperatureishigh.
ThrottleLever
Thethrottlelever(Figure11)controlsthespeed(rpm)
oftheengine.Itislocatednexttothechokelever.It
setstheenginespeedandthereforecanincreaseand
decreasetherotationspeedofthemixingpaddles.
Forbestperformance,setthiscontroltotheFAST
positionwhenmixingmaterial.
EngineOn/OffSwitch
TheOn/Offswitchislocatedonthefrontoftheengine.
•RotateittotheONpositiontostartandrunthe
engine.
•RotateittotheOFFpositiontoshutofftheengine.
Figure12
1.OFFposition2.ONposition
Recoil-StartHandle
Tostarttheengine,pulltherecoil-starthandle(Figure
10)quicklytoturntheengineover.Theengine
controlsdescribedabovemustallbesetcorrectlyfor
theenginetostart.
Oil-LevelSwitch
Theoil-levelswitchislocatedinsidetheengine,andit
doesnotallowtheenginetorunintheeventtheoil
levelisbelowthesafeoperatinglimit.
g021103
14
Specications
Note:Specicationsanddesignaresubjecttochangewithoutnotice.
MachineSpecications
Model
BatchCapacity0.17m
TotalVolume
60217,60217C60221,60221C
3
(6.0ft3)0.23m
3
0.19m
(6.7ft3)0.24m
3
(8.0ft3)0.23m
3
(8.6ft3)0.24m
DrumMaterialPolyethylenePolyethylenePolyethylene
Length
(withouttowpole)
Width86cm
Height142cm
Weight250kg
Axle
Engine
150cm
(59inches)
(34inches)
(56inches)
(552lb)
86to117cm(34to46inches)
extendable
®
Kohler
CH395Kohler
168cm
(66inches)
86cm
(34inches)
142cm
(56inches)
254kg
(560lb)
86to117cm(34to46inches)
extendable
®
CH395Honda
Drivebeltbeltbelt
60221HD
3
(8.0ft3)
3
(8.6ft3)
168cm
(66inches)
86cm
(34inches)
142cm
(56inches)
254kg
(560lb)
86to117cm(34to46inches)
extendable
®
GX240
15
Operation
ThinkSafetyFirst
Carefullyreadallsafetyinstructionsandsymbolsin
thismanual,ontheproductdecals,andothermedia
suppliedwiththeproduct.Knowingthisinformation
couldhelpyouorbystandersavoidinjury.
Knowhowtoquicklyshutdownthemachineinan
emergency.
Useahard-hat,hearingprotection,ashirtwithlong
sleevesthataretightatthewrists,tight-ttinggloves
withoutdrawstringsorloosecuffs,eyeprotection,and
adustmaskorrespirator.Ameshvisoralonedoes
notprovidesufcienteyeprotection;supplementwith
protectiveglasses.
CAUTION
Thismachineproducessoundlevelsthatcan
causehearinglossthroughextendedperiods
ofexposure.
Wearhearingprotectionwhenoperatingthis
machine.
TowingtheMachine
Beforetowingthemachine,readalltheinformation
andperformalltheapplicableprocedurestointhis
sectiontoensuresafeandpropertowing.
WARNING
Towingthemachineathighspeedincreases
theriskofahitchmalfunctionandtirefailure.
Higherspeedsalsoincreasethemomentum
ofthemachineandbrakingdistance.Ifthe
machinedetachesfromthetowvehicleathigh
speed,itcouldcausedamagetoproperty,or
injuryordeathtobystanders.
Donotexceed88km/h(55mph)whentowing
themachine.Forpoorroadconditionsor
inclementweather,reducespeedaccordingly .
WARNING
Towingthemachinewithmaterialinthedrum
increasestheriskofahitchmalfunctionand
tirefailure.Inaddition,materialcouldbounce
outofthedrumandhitothervehiclesand/or
people.Materialinthedrumincreasesthe
weight,whichaffectsmomentumandbraking
distance.
1.Wearhearingprotection.
Figure13
Donottowthemachinewithmaterialinthe
drum.
•ReviewandunderstandtheSafeOperating
g229846
Practices(page4).
•Testthebrakesofthetowvehiclebeforetowing.
•Avoidsuddenstartsandstopswhiletowingthe
machine.
TowVehicleRequirements
Beforeconnectingthemachinetoyourtowvehicle,
ensurethatyourvehicleispreparedasfollows:
•Ensurethatyourtowvehiclehastowing
capacityfortheweightofthemachine;referto
Specications(page15).
•UseaClass2orlargerreceiver.
•Ensurethatyourtowvehiclehastheappropriate
hitchtotowthemachine;optionsincludea50mm
(2inch)ballhitchorapintlehitch.
•Ifthemachineisequippedwithatrailer-lightkit,
ensurethattheelectricalconnectorofthetow
vehicleiscompatiblewiththeelectricalconnector
ofthemachine.Themachineusesastandard
4-pin,atplug.Ifyourtowvehiclehasadifferent
typeofplug,obtainanadapterfromanautomotive
partsstore.
16
