Toro 51621 Operator's Manual

UltraPlusBlower/Vacuum

51621

Soplador/AspiradorUltraPlus

51621

Soufeur/aspirateurUltraPlus

FormNo.3390-837RevB

51621

www.T oro.com.

*3390-837*B

UltraPlusBlower/Vacuum

ModelNo.51621—SerialNo.314000001andUp

Ifyouhavequestionsorproblems,calltollfree1-888-367-6631 (US),1-888-430-1687(Canada),or1-800-574-3312(Mexico)before returningthisproduct.

FormNo.3384-350RevC

Operator'sManual

IMPORTANTSAFETY INSTRUCTIONS

WARNING

CALIFORNIA

Proposition65Warning

Thisproductcontainsachemical

orchemicalsknowntotheStateof

Californiatocausecancer,birthdefects,

orreproductiveharm.

Whenusinganelectricalappliance,basicprecautionsshould alwaysbefollowed,includingthefollowing:

READALLINSTRUCTIONS BEFOREUSINGVAC/BLOWER

WARNING—Toreducetheriskofre,electric

shock,orinjury,followthesesafetyinstructions.

Toensuremaximumsafety,bestperformance,andtogain knowledgeoftheappliance,itisessentialthatyouoranyother operatoroftheappliancereadandunderstandthecontentsofthis manualbeforeoperatingtheappliance.Payparticularattentionto thesafety-alertsymbol DANGER—personalsafetyinstruction.Readandunderstandthe instructionbecauseithastodowithsafety .Failuretocomply

withtheseinstructionsmayresultinpersonalinjury,riskof re,orelectricalshock.

Donotleavetheappliancewhenitispluggedin.Unplugitfrom theelectricaloutletwhennotinuseandbeforeservicing.

WARNING-T oreducetheriskofelectricshock,donotusethe applianceonwetsurfaces.Donotexposeittorain.Storeit indoors.

Donotallowtheappliancetobeusedasatoy.Donotusethe appliancenearchildren.Donotletchildrenusetheappliance.

Usetheapplianceonlyasdescribedinthismanual.Useonlythe manufacturer'srecommendedattachments.

Dressproperly .Keephair,looseclothing,ngers,andallpartsof thebodyawayfromopeningsandmovingparts.Beawareofthe positionoftheblowerandtheairinletsduringoperation.Loose

whichmeansCAUTION,WARNINGor

clothing,jewelry ,andhaircanbedrawnintotheinlets(refertothe followinggure)andmayresultinpersonalinjury.Alwayswear substantialfootwear,longpants,andeyeprotection.

g227712

Caution—MovingParts—donotoperatetheappliancewithout theairinletguard(bottominletcover)inplace.RefertoSetupfor properassemblyinstructions.

Donotusetheappliancewithadamagedelectricalcordorplug. Iftheapplianceisnotworkingasitshould,hasbeendropped, damaged,leftoutdoors,ordroppedintowater,returnittoan AuthorizedServiceDealer.

Donotpullorcarrytheappliancebytheelectricalcord,use thecordasahandle,closeadooronthecord,orpullthecord aroundsharpedgesorcorners.Keepthecordawayfromheated surfaces.

Donotunplugtheappliancebypullingontheelectricalcord.To unplugthecord,grasptheplug,notthecord.

Donothandletheplugorappliancewithwethands.

Donotputanyobjectintotheopenings.Donotusetheappliance withanyopeningblocked;keepitfreeofdust,lint,hair ,and anythingthatmayreduceairow.

Turnoffallcontrolsbeforeunpluggingtheappliance.

Useextracarewhencleaningonstairs.

Donotusetheappliancetovacuumammableorcombustible liquids,suchasgasoline,oruseinareaswheretheymaybe present.

Thisapplianceisprovidedwithdoubleelectricalinsulation.Use onlyidenticalreplacementparts.Seetheinstructionsforservicing double-insulatedappliances.

Donotvacuumanythingthatisburningorsmoking,suchas cigarettes,matches,orhotashes.

Donotusetheappliancewithoutthevacuumbagorproper attachmentsinplace.

Registeratwww.Toro.com.

OriginalInstructions(EN)

PrintedinMexico

AllRightsReserved

*3384-350*C

SAVETHESEINSTRUCTIONS

SafetyandInstructionalDecals

Important:Safetyandinstructiondecalsarelocatednearareasofpotentialdanger .Replacedamagedormissingdecals.

127-2265

decal127-2265

Setup

Registeryourproductatwww .Toro.comsothatT orocannotify youinthecaseofasafetyorwarrantyproductrecall.

Figure2

1.Blowertube3.Upper-vacuumtube

2.Bottominletcover4.Lower-vacuumtube

AssemblingtheBlower

Important:Themotorshouldnotrununlessthebottom

inletcoverislockedinplace.

Note:Ifthemotorrunswithoutthebottominletcoverinplace,

donotusetheappliance.ReturnittoanAuthorizedService Dealer.

Installtheblowertubeandbottominletcover.

g224170

g227713

ConvertingfromBlowerto

ConvertingfromVacuumto

Vacuum

WARNING

Theimpellerrotatesforafewsecondsafteryouturn offtheapplianceandcancutorinjurengers.

Donotremovethebottominletcoverwhenthemotor isrunningorwhentheapplianceispluggedintoa poweroutlet.

1.Removethebottominletcoverandtheblowertube.

2.Installthevacuumtubeandbag.

Blower

1.Removethevacuumbagandthevacuumtube.

g227714

g227717

Important:Themotorshouldnotrununlessthe

vacuumtubeislockedinplace.

Note:Ifthemotorrunswithoutthevacuumtubeinplace,

donotusetheappliance.ReturnittoanAuthorizedService Dealer.

2.Installtheblowertubeandbottominletcover.

Important:Themotorshouldnotrununlessthe

bottominletcoverislockedinplace.

Note:Ifthemotorrunswithoutthebottominletcoverin

place,donotusetheappliance.ReturnittoanAuthorized ServiceDealer.

3.Adjustthebagstrapasneededforcomfortableoperation.

g227718

g227715

Operation

Important:Thisapplianceisintendedforoutdoor,

residentialuseonly.Donotuseitindoorsorforcommercial orindustrialpurposes.Thisapplianceisforhouseholduse only.

ConnectingtoaPower Source

Toreducetheriskofelectricshock,thisappliancehasapolarized plug(i.e.,onebladeiswiderthantheother).Useonlyapolarized, ULlisted(CSAcertiedinCanada)extensioncordrecommended foroutdooruse.Apolarizedplugwilltinapolarizedcordonly oneway .Iftheplugdoesnottfullyinthecord,reversethecord. Ifitstilldoesnott,purchaseapolarizedextensioncord.Ifyou haveapolarizedextensioncordandtheextensioncordplugdoes nottfullyintothewallreceptacle,reversetheplug.Ifitstilldoes nott,contactaqualiedelectriciantoinstalltheproperoutlet.Do notchangetheapplianceorextensioncordpluginanyway .

Useonlyanextensioncordrecommendedforoutdooruse.

WARNING

Ifyoudonotfullyseattheextensioncordonthe inletplug,oriftheplugandcorddonottrmly,the looseplugcouldleadtooverheatingandcauseare, possiblyburningyouorothers.

•Ensurethatyoufullyseatthecordontheplug.

•Checktheconnectionregularlytoensurethatthe

cordisrmlyattached.

•Donotuseaworn-outorlooseextensioncord.

ExtensionCordLength

100ft

150ft

MinimumWireGage

(A.W.G.)

1.Extensioncord

Starting/Stopping/Adjusting theAirSpeed

g224197

Figure8

2.Cordlock

Note:Donotuseanextensioncordover150feet.

Important:Checktheextensioncordfrequentlyduring

useforholesorcracksintheinsulation.Donotusea damagedelectricalcord.Donotrunthecordthrough standingwaterorwetgrass.

Securetheextensioncordtotheapplianceusingthemolded incord-lockfeature.

g025396

UsingtheNozzles

UsingtheApplianceasa

Installthepowerandconcentratornozzlesintotheblowertube toreachintonarrowspacesortoremovematteddebrisfrom hardsurfaces.

1.Blowertube

2.PowerNozzle

3.Concentratornozzle

4.Cordwrap

UsingtheOscillatorNozzle Accessory

Installtheoscillatornozzleontotheblowertubetosavetime clearinghardscapes.Itautomaticallysweepstheback-and-forth, creatingawiderblowingpathwithlessside-to-sidewrist movement.

Vacuum

Theapplianceusedasavacuumisintendedforresidentialuse only.Useitoutdoorstocollectdebrisasneeded.

WARNING

Usingtheapplianceasavacuumcanthrowdebris, possiblycausingseriouspersonalinjurytoyouor bystanders.

•Donotoperatethevacuumwithoutthebaginstalled

orwiththebagzipperopen.

g025397

•Donotvacuumsharp,pointed,orhardobjectsthat

couldbethrownthroughthefabricofthebag,such aswires,staples,nails,orrocks.

Note:Removetheoscillatornozzlebeforeusingthecordwrap

tostoretheappliance.

UsingtheApplianceasa Blower

Theapplianceusedasablowerisintendedforresidentialuse only.Useitoutdoorstomovedebrisasneeded.

WARNING

Usingtheapplianceasablowercanthrowdebris, possiblycausingseriouspersonalinjurytoyouor bystanders.

•Donotblowhardobjectssuchasnails,bolts,or

rocks.

•Donotoperatetheblowernearbystandersorpets.

•Useextracarewhencleaningdebrisfromstairsor

othertightareas.

•Wearsafetygogglesorothersuitableeye

protection,longpants,andshoes.

g017098

Important:Vacuumonlyleavesandsoftitems.Hard

g026691

itemssuchassticks,rocks,acorns,andpineconeswill damagetheimpeller.

Important:Donotforcethevacuumtubeintoapileof

debrisorholdthetubeuprightwhileforcefeedingdebrisinto thetube.Eitheractionmaycloganddamagetheimpeller.If theappliancestartstovibrateormakeabnormalnoise,stop it,unplugthecord,andcheckforthecause.

EmptyingtheBag

1.Turnofftheapplianceandunplugitfromthepowersource.

2.Emptyanydebrisfromthebag.

g026692

Donotstoredebrisinthebag.T ocleanthebag,turnit insideoutandshakeoutanyexcessdebris.Onceayear, handwashthebaginsoapywaterandallowittoairdry.

DANGER

Normalusageofthebagcausesittowearand deteriorateovertime.Awornordeterioratedbag allowssmallobjectstobethrownthroughthebag, possiblyinjuringyouorbystanders.

Checkthebagfrequently.Ifitiswornor deteriorated,replaceitwithagenuineT oro vacuumbag.

Service

Tobestprotectyourinvestmentandmaintainoptimalperformance ofyourT oroequipment,countonT orogenuineparts.Whenit comestoreliability,Torodeliversreplacementpartsdesignedto theexactengineeringspecicationsofourequipment.Forpeace ofmind,insistonT orogenuineparts.

Double-insulated

SeparatingtheVacuumTube

RemovingCloggedDebris fromtheImpeller

1.Turnoffandunplugtheappliancefromthepowersource

andwaitforallmovingpartstostop.

2.Removethevacuumtubethenremovethedebrisfromthe impellerblades.

Appliances

Inadouble-insulatedappliance,twosystemsofinsulation areprovidedinsteadofgrounding.Nogroundingmeans isprovidedonadouble-insulatedappliance,norshoulda meansforgroundingbeaddedtotheappliance.Servicinga double-insulatedappliancerequiresextremecareandknowledge ofthesystem,andshouldbedoneonlybythequaliedservice personnelatanAuthorizedServiceDealer.Replacementpartsfor adouble-insulatedappliancemustbeidenticaltothepartsthey replace.Adouble-insulatedapplianceismarkedwiththewords

g227719

“DoubleInsulation”or“DoubleInsulated.”Thesymbol(square withinasquare)

mayalsobemarkedontheappliance.

Storage

Storetheapplianceandextensioncordindoors,inacooldry location,outofreachofchildrenandanimals.

UsingtheCordWrap

InstallthecordwrapasillustratedinUsingtheNozzles(page

5).Wrapyourextensioncord(cordnotprovided)aroundthe

appliance,asshown,foreaseofstorage.

3.Checktheimpellerforanysignsofdamage.Ifitisdamaged, contactanAuthorizedServiceDealer.

4.Installthevacuumtube,or,ifyouwanttoswitchtoblower mode,installthebottominletcover .RefertoConverting

fromV acuumtoBlower(page3)orConvertingfromBlower toV acuum(page3)formoreinformation.

Important:Alwaysunplugtheappliancebeforewrapping

thecordorstoringit.

g017267

g227720

Troubleshooting

Ifyourappliancefailstorunwhenyouturniton,checkthe followingbeforecontactinganAuthorizedServiceDealer:

•Ensurethatthebottominletcoverorvacuumtubeislockedin

place.

•Ensurethatthepowercordissecuredinplaceatthebackof

theapplianceandthattheplugisfullyseated.

Notes:
