Toro 38567, 38569 Operator's Manual

CCR™6053R/ESQuickClearSnowthrower

ModelNo.38567—SerialNo.313000001andUp

ModelNo.38569—SerialNo.313000001andUp

FormNo.3373-685RevA

Operator'sManual

Introduction

Thismachineisintendedtobeusedbyresidential
homeownersorprofessional,hiredoperators.It
isdesignedprimarilyforremovingsnowfrom
pavedsurfaces,suchasdrivewaysandsidewalks,
andothersurfacesfortrafconresidentialor
commercialproperties.Itisnotdesignedfor
removingmaterialsotherthansnow,norisit
designedforclearingoffgravelsurfaces.

Readthisinformationcarefullytolearnhowtooperate
andmaintainyourmachineproperlyandtoavoidinjury
andmachinedamage.Youareresponsibleforoperating
themachineproperlyandsafely.

YoumaycontactTorodirectlyatwww.Toro.comfor
machineandaccessoryinformation,helpndinga
dealer,ortoregisteryourmachine.

Wheneveryouneedservice,genuineToroparts,
oradditionalinformation,contactanAuthorized
ServiceDealerorToroCustomerServiceandhave
themodelandserialnumbersofyourmachineready.
Figure1identiesthelocationofthemodelandserial
numbersonthemachine.Writethenumbersinthe
spaceprovided.

ModelNo.

SerialNo.

Thismanualidentiespotentialhazardsandhassafety
messagesidentiedbythesafetyalertsymbol(Figure2),
whichsignalsahazardthatmaycauseseriousinjury
ordeathifyoudonotfollowtherecommended
precautions.

Figure2

1.Safetyalertsymbol

Thismanualuses2wordstohighlightinformation.
Importantcallsattentiontospecialmechanical
informationandNoteemphasizesgeneralinformation
worthyofspecialattention.

Safety

Readandunderstandthecontentsofthismanual
beforeyoustarttheengine.

1.Modelandserialnumberlocation

©2012—TheT oro®Company
8111LyndaleAvenueSouth
Bloomington,MN55420

Figure1

Registeratwww.Toro.com.

Thisisthesafetyalertsymbol.Itisusedtoalert
youtopotentialpersonalinjuryhazards.Obeyall
safetymessagesthatfollowthissymboltoavoid
possibleinjuryordeath.

Improperlyusingormaintainingthismachine
couldresultininjuryordeath.T oreducethis
potential,complywiththefollowingsafety
instructions.

Training

•Read,understand,andfollowallinstructionsonthe
machineandinthemanual(s)beforeoperatingthis
machine.Bethoroughlyfamiliarwiththecontrols
andtheproperuseofthemachine.Knowhowto
stopthemachineanddisengagethecontrolsquickly.

OriginalInstructions(EN)

PrintedintheUSA

AllRightsReserved

•Neverallowchildrentooperatethemachine.Never
allowadultstooperatethemachinewithoutproper
instruction.

•Keeptheareaofoperationclearofallpersons,
particularlysmallchildren.

•Exercisecautiontoavoidslippingorfalling.

•Alwayswearsafetyglassesoreyeshieldsduring
operationorwhileperforminganadjustmentor
repairtoprotecteyesfromforeignobjectsthatmay
bethrownfromthemachine.

•Lettheengineandmachineadjusttooutdoor
temperaturesbeforestartingtoclearthesnow.

Preparation

•Thoroughlyinspecttheareawherethemachineis
tobeusedandremovealldoormats,sleds,boards,
wires,andotherforeignobjects.

•Donotoperatethemachinewithoutwearing
adequatewintergarments.Avoidloosetting
clothingthatcangetcaughtinmovingparts.Wear
footwearthatwillimprovefootingonslippery
surfaces.

•Handlefuelwithcare;itishighlyammable.

–Useanapprovedfuelcontainer.

–Neveraddfueltoarunningengineorhotengine.

–Fillfueltankoutdoorswithextremecare.Never

llthefueltankindoors.

–Neverllcontainersinsideavehicleorona

truckortrailerbedwithaplasticliner.Always
placecontainersontheground,awayfromyour
vehicle,beforelling.

–Whenpractical,removegas-poweredmachinery

fromthetruckortrailerandrefuelitonthe
ground.Ifthisisnotpossible,thenrefuelsuch
machineryonatrailerwithaportablecontainer,
ratherthanfromagasolinedispensernozzle.

–Keepthenozzleincontactwiththerimofthe

fueltankorcontaineropeningatalltimes,until
refuelingiscomplete.Donotuseanozzle
lock-opendevice.

–Replacegasolinecapsecurelyandwipeupspilled

fuel.

–Iffuelisspilledonclothing,changeclothing

immediately.

–Donotsmokewhilehandlinggasoline.

•Useextensioncordsandreceptaclesasspecied
bythemanufacturerforallmachineswithelectric
startingmotors.

•Donotattempttoclearsnowfromagravelor
crushedrocksurface.Thismachineisintendedfor
useonlyonpavedsurfaces.

•Neverattempttomakeanyadjustmentswhile
theengineisrunning(exceptwhenspecically
recommendedbymanufacturer).

Operation

•Donotputhandsorfeetnearorunderrotatingparts.
Keepclearofthedischargeopeningatalltimes.

•Exerciseextremecautionwhenoperatingonor
crossinggraveldrives,walks,orroads.Stayalertfor
hiddenhazardsortrafc.

•Afterstrikingaforeignobject,stoptheengine,
removetheignitionkey,thoroughlyinspectthe
machineforanydamage,andrepairthedamage
beforerestartingandoperatingthemachine.

•Ifthemachineshouldstarttovibrateabnormally,
stoptheengineandcheckimmediatelyforthecause.
Vibrationisgenerallyawarningoftrouble.

•Stoptheenginewheneveryouleavetheoperating
position,beforeuncloggingtherotorbladehousing
ordischargechute,andwhenmakinganyrepairs,
adjustmentsorinspections.

•Whencleaning,repairing,orinspectingthemachine,
stoptheengineandmakecertainthattherotor
bladesandallmovingpartshavestopped.

•Donotruntheengineindoors,exceptwhenstarting
theengineandfortransportingthemachineinor
outofthebuilding.Opentheoutsidedoors;exhaust
fumesaredangerous.

•Exerciseextremecautionwhenoperatingonslopes.

•Neveroperatethemachinewithoutproperguards
andothersafetyprotectivedevicesinplaceand
working.

•Neverdirectthedischargetowardpeopleorareas
wherepropertydamagecanoccur.Keepchildren
andothersaway.

•Donotoverloadthemachinecapacitybyattempting
toclearsnowattoofastarate.

•Lookbehindandusecarewhenbackingupwiththe
machine.

•Disengagepowertotherotorbladeswhenthe
machineisbeingtransportedornotinuse.

•Neveroperatethemachinewithoutgoodvisibility
orlight.Alwaysbesureofyourfooting,andkeepa
rmholdonthehandles.Walk;neverrun.

•Nevertouchahotengineormufer(

Figure3).

2

Figure3

ClearingaCloggedDischarge
Chute

Handcontactwiththerotatingrotorbladesinsidethe
dischargechuteisthemostcommoncauseofinjury
associatedwithsnowthrowers.Neveruseyourhandto
cleanoutthedischargechute.

Toclearthechute:

•Shuttheengineoff!

Keepyourface,hands,feet,andanyotherpart
ofyourbodyorclothingawayfrommovingor
rotatingparts.

•Beforeadjusting,cleaning,repairing,andinspecting
themachine,andbeforeuncloggingthedischarge
chute,stoptheengine,removethekey,andwait

forallmovingpartstostop.

•Beforeleavingtheoperatingposition,stopthe
engine,removetheignitionkey,andwaitforall
movingpartstostop.

•Ifashield,safetydevice,ordecalisdamaged,
illegible,orlost,repairorreplaceitbeforebeginning
operation.Also,tightenanyloosefasteners.

•Donotsmokewhilehandlinggasoline.

•Donotusethemachineonaroof.

•Donottouchtheenginewhileitisrunningorsoon
afterithasstoppedbecausetheenginemaybehot
enoughtocauseaburn.

•Wait10secondstobesuretherotorbladeshave
stoppedrotating.

•Alwaysuseaclean-outtool,notyourhands.

MaintenanceandStorage

•Checkallfastenersatfrequentintervalsforproper
tightnesstobesurethemachineisinsafeworking
condition.

•Neverstorethemachinewithfuelinthefueltank
insideabuildingwhereignitionsourcesarepresent,
suchashotwaterheaters,spaceheaters,orclothes
dryers.Allowtheenginetocoolbeforestoringin
anyenclosure.

•AlwaysrefertotheOperator’sManualforimportant
detailsifthemachineistobestoredforanextended
periodoftime.

•Maintainorreplacesafetyandinstructionlabels,as
necessary.

•Runthemachineafewminutesafterthrowingsnow
topreventfreeze-upoftherotorblades.

•Performonlythosemaintenanceinstructions
describedinthismanual.Beforeperformingany
maintenance,service,oradjustment,stoptheengine
andremovethekey.Ifmajorrepairsareeverneeded,
contactanAuthorizedServiceDealer.

•Donotchangethegovernorsettingsontheengine.

•Whenstoringthemachineformorethan30days,
drainthefuelfromthefueltanktopreventa
potentialhazard.Storefuelinanapprovedfuel
container.Removethekeyfromtheignitionswitch
beforestoringthemachine.

•PurchaseonlygenuineTororeplacementpartsand
accessories.

SoundPressure

Thismachinehasasoundpressurelevelattheoperator’s
earof88dBA,whichincludesanUncertaintyValue(K)
of1dBA.Thesoundpressurelevelwasdetermined
accordingtotheproceduresoutlinedinENISO11201.

SoundPower

ToroSnowthrowerSafety

Thefollowinglistcontainssafetyinformationspecic
toToroproductsorothersafetyinformationthatyou
mustknow.

•Rotatingrotorbladescaninjurengersor
hands.Staybehindthehandlesandawayfrom
thedischargeopeningwhileoperatingthemachine.

Thismachinehasaguaranteedsoundpowerlevelof104
dBA,whichincludesanUncertaintyValue(K)of3.75
dBA.Thesoundpowerlevelwasdeterminedaccording
totheproceduresoutlinedinENISO3744.

3

Hand-ArmVibration

UncertaintyValue(K)=4.3m/s

2

Measuredvibrationlevelforthelefthand=8.4m/s

2

Themeasuredvaluesweredeterminedaccordingtothe
proceduresoutlinedinENISO20643.

Measuredvibrationlevelfortherighthand=10.7m/s

2

SafetyandInstructionalDecals

Important:Safetyandinstructiondecalsarelocatednearareasofpotentialdanger.Replacedamaged

decals.

94-2577

1.Toengagetherotorblades,holdthecontrolbaragainst
thehandle.

2.Todisengagetherotorblades,releasethecontrolbar.

117-9102

Orderpartno.117-6036

Orderpartno.117-9121

1.Warning—readthe

Operator'sManual.

2.Cutting/dismemberment
hazard,impeller—stopthe
enginebeforeleavingthe
machine.

3.Thrownobject
hazard—keepbystanders
asafedistancefromthe
machine.

4.Fuelspillhazard—donot
tipmachinebackward.

115–5698

5.EngineswitchOn

6.EngineswitchOff

7.Primer

8.Pushtheprimerthree
timestoprimetheengine.

9.ReadtheOperator's
Manualbeforechecking
engineoillevel.

1.Cuttingdismembermenthazards,impellerandauger—do
notplaceyourhandinthechute;removetheignitionkey
andreadtheinstructionsbeforeservicingorperforming
maintenance.

4

Orderpartno.117-6046

117-9103

1.Warning—readthe

Operator'sManual.

2.Cutting/dismemberment
hazard,impeller—stopthe
enginebeforeleavingthe
machine.

3.Thrownobject
hazard—keepbystanders
asafedistancefromthe
machine.

4.Fuelspillhazard—donot
tipmachinebackward.

5.EngineswitchOn

6.EngineswitchOff

7.Primer

8.Pushtheprimerthree
timestoprimetheengine.

9.ReadtheOperator's
Manualbeforechecking
engineoillevel.

10.Plugthemachineinto
powertheelectricstarter .

5

Setup

LooseParts

Usethechartbelowtoverifythatallpartshavebeenshipped.

ProcedureDescription

1
2

Nopartsrequired

Screws
Chuteassembly

1

UnfoldingtheHandle

NoPartsRequired

Procedure

1.Loosenthehandleknobs,pulloutthe“U”-shaped
handlelocksuntilyoucanmovethehandlefreely,
androtatethehandletotheoperatingposition

Figure4).

(

Qty.

–

3
1

Important:Ensurethatyoudonotpinchor
kinkthecontrolcableortheQuickShoot™
cables(Figure6).

Unfoldthehandle.

Installthedischargechute.

Figure5

Use

Figure4

1.“U”-shapedhandlelock(2)

2.Inserttheendofthe“U”-shapedhandlelockinto
theopenholeinthehandleandtightenthehandle
knobsuntiltheyaresnug(Figure5).

2.Handleknobs

Figure6

1.Controlcable2.QuickShoot™cables

6

Note:Thebottleofoilmaycontainmorethanis
required.Donotoverlltheengine.

2

InstallingtheDischargeChute

Partsneededforthisprocedure:

3

Screws

1

Chuteassembly

Procedure

Installthedischargechuteasshown(Figure7).

Figure7

Maxll:20oz.(0.6l),type:automotivedetergentoil
withanAPIserviceclassicationofSJ,SL,orhigher.

Figure8belowtoselectthebestoilviscosityforthe

Use
outdoortemperaturerangeexpected:

Figure8

1.UsingSAE30atoutdoor
temperaturesbelow40°F
(4°C)willresultinhard
starting.

2.Using10W-30atoutdoor
temperaturesabove
80°F(27°C)mayresultin
increasedoilconsumption;
therefore,checktheoil
levelmorefrequentlyin
thesecircumstances.

1.Dischargechute

Note:Foreasierinstallation,useasmallratchetwrench
totightenthescrews.

Important:Donotovertightenthescrews;
otherwiseyoumaydamagethedischargechuteand
preventitfromturningfreely.

2.Screw(3)

3

FillingtheEnginewithOil

NoPartsRequired

Procedure

Yourmachinedoesnotcomewithoilintheengine,but
itdoescomewithabottleofoil.

Important:Beforestartingtheengine,llthe
enginewithoil.

Note:0W30syntheticoilisacceptableforuseincold
temperatures.

1.Movethemachinetoalevelsurface.

2.Cleanaroundtheoilllcap(

Figure9

1.Oilllcap

3.Unscrewtheoilllcapandremoveit.

4.Withthemachineintheoperatingposition,carefully
pouroilintothecrankcase.Wait3minutes,thenadd
oiluntilthepointofoverow .

Figure9).

7

Note:Youmaytipthemachineforward(handle
up)alittletomakeaddingoileasier.Rememberto
returnthemachinetotheoperatingpositionbefore
checkingtheoillevel.

Important:Donottipthemachinealltheway
forwardontoitsnose,orfuelmayleakoutof
themachine.

5.Screwtheoilllcapintotheoilllholeandtighten
itsecurely.

4

AdjustingtheControlCable

ProductOverview

NoPartsRequired

Procedure

RefertoAdjustingtheControlCableinMaintenance.

Figure10

1.Chutedeectortrigger

2.Dischargechute9.Ignitionkey

3.Fueltankcap

4.Controlbar11.Oildrainplug

5.QuickShoot™control12.Oilllcap

6.Recoilstarthandle

7.Primer

8.Electric-startbutton
(model38569only)

10.Chokelever

13.Chutedeector

Operation

Note:Determinetheleftandrightsidesofthemachine

fromthenormaloperatingposition.

DANGER

Gasolineisextremelyammableandexplosive.A
reorexplosionfromgasolinecanburnyouand
others.

•Topreventastaticchargefromignitingthe
gasoline,placethecontainerand/ormachine
onthegroundbeforelling,notinavehicleor
onanobject.

•Fillthetankoutdoorswhentheengineiscold.
Wipeupspills.

•Donothandlegasolinewhensmokingoraround
anopenameorsparks.

•Storegasolineinanapprovedfuelcontainer,out
ofthereachofchildren.

•Donottipthemachinebackwardwithfuelin
thefueltank;otherwise,fuelmayleakoutof
themachine.

8

FillingtheFuelTank

•Forbestresults,useonlyclean,fresh,unleaded
gasolinewithanoctaneratingof87orhigher
((R+M)/2ratingmethod).

•Oxygenatedfuelwithupto10%ethanolor15%
MTBEbyvolumeisacceptable.

•DoNotuseethanolblendsofgasoline(suchasE15
orE85)withmorethan10%ethanolbyvolume.
Performanceproblemsand/orenginedamagemay
resultwhichmaynotbecoveredunderwarranty.

•DoNotusegasolinecontainingmethanol.

•DoNotstorefueleitherinthefueltankorfuel
containersoverthewinterunlessafuelstabilizeris
used.

1.Movethemachinetoalevelsurface.

2.Cleanaroundtheoilllcap(

Figure12

1.Oilllcap

Figure12).

•DoNotaddoiltogasoline.

Figure11

1.1/4inch(6mm)

Important:Donotaddoiltothegasoline.

Important:DonotuseE85orE20fuel.Alternative

fuelswithhighalcoholcontentcancausehard
starting,poorengineperformance,andmaycause
internalenginedamage.

3.Unscrewtheoilllcapandremoveit.

4.Iftheoillevelislow,keepthemachineinthe
operatingpositionandcarefullypouroilintothe
crankcase.Wait3minutes,thenaddoiluntilthe
pointofoverow .(Max.ll:20oz.(0.6l),type:SAE
30detergentoilwithanAPIserviceclassication
ofSJ,SL,orhigher.)

Note:Youmaytipthemachineforward(handle
up)alittletomakeaddingoileasier.Rememberto
returnthemachinetotheoperatingpositionbefore
checkingtheoillevel.

Important:Donottipthemachinealltheway
forwardontoitsnose,orfuelmayleakoutof
themachine.

5.Screwtheoilllcapintotheoilllholeandhand
tightenitsecurely.

StartingtheEngine

1.TurntheignitionkeyclockwisetotheOnposition

Figure13).

(

Note:Forbestresults,purchaseonlythequantityof
gasolinethatyouexpecttousein30days.Otherwise,
youmayaddfuelstabilizertonewlypurchasedgasoline
tokeepitfreshforupto6months.

CheckingtheEngineOilLevel

ServiceInterval:Beforeeachuseordaily—Check

theengineoillevelandaddoilif
necessary.

Figure13

2.Pulloutthechokelever(Figure14).

9

Figure14

1.Chokelever

3.Firmlypushintheprimerwithyourthumb3times
(0°For-18°Corabove)or6times(0°For-18°Cor
below),holdingtheprimerinaforasecondbefore
releasingiteachtime(Figure15andFigure16).

Note:Removeyourglovewhenyoupushinthe
primersothataircannotescapefromtheprimer
hole.

Important:Donotusetheprimerorthechoke
iftheenginehasbeenrunningandishot.
Excessiveprimingmayoodtheengineand
preventitfromstarting.

4.Connectanextensioncordtoapowersourceand
themachine,andpushtheelectric-startbutton
(model38569only)(

Figure17),orpulltherecoil

starthandle(Figure18).

Figure15

Figure17

Note:UseonlyaUL-listed,16-gaugeextension

cordrecommendedforoutdoorusethatisnot
longerthan50feet(15m).

WARNING

Theelectricalcordcanbecomedamaged,
causingashockorre.

Thoroughlyinspecttheelectricalcordbefore
pluggingitintoapowersource.Ifthe
cordisdamaged,donotuseittostartthe
machine.Replaceorrepairthedamagedcord
immediately.ContactanAuthorizedService
Dealerforassistance.

Figure16

1.Symbolsonthechokeleverindicatingtomovethechoke
levertothelefttoactivatethechoke.

10

Figure18

Figure19

1.Controlbar

Important:Runtheelectricstarternomore
than10timesatintervalsof5secondson,then
5secondsoff.Runningtheelectricstarter
extensivelycanoverheatanddamageit.Ifthe
enginedoesnotstartafterthisseriesofattempts,
waitatleast40minutestoallowthestarterto
coolbeforeattemptingtostartitagain.Ifthe
enginedoesnotstartafterthesecondseriesof
attempts,takethemachinetoanAuthorized
ServiceDealerforservice(model38569only).

Note:Ifyoupulltherecoilhandleandfeelno
resistance,thestartermaybefrozen.Thawoutthe
starterbeforeattemptingtostartthemachine.

5.Whiletheengineisrunning,pushinthechokelever
slowly.

6.Unplugtheextensioncordfromthepowersource
andthemachine(model38569only).

CAUTION

Ifyouleavethemachinepluggedintoapower
source,someonecaninadvertentlystartthe
machineandinjurepeopleordamageproperty
(model38569only).

DisengagingtheRotorBlades

Todisengagetherotorblades,releasethecontrolbar
(Figure20).

Figure20

StoppingtheEngine

Tostoptheengine,turntheignitionkeycounterclockwise
totheOffposition(Figure21).

Unplugthepowercordwheneveryouarenot
startingthemachine.

EngagingtheRotorBlades

Toengagetherotorblades,holdthecontrolbaragainst
thehandle(Figure19).

Figure21

11

AdjustingtheDischargeChute

ClearingaCloggedDischarge

andChuteDeector

Toadjustthedischargechute,pressthetriggerofthe
QuickShoot™controlontherighthandsideofthe
handleandmoveitupordownalongthehandle.Moving
thecontroldownthehandlerotatesthedischargechute
totheleft;movingthecontrolupthehandlerotatesthe
dischargechutetotheright(

Figure22).

Chute

Important:Handcontactwiththerotatingrotor

bladesinsidethedischargechuteisthemost
commoncauseofinjuryassociatedwithsnow
throwers.Neveruseyourhandtocleanoutthe
dischargechute.

Toclearthechute:

•Shuttheengineoff!

•Wait10secondstobesuretherotorbladeshave
stoppedrotating.

•Alwaysuseaclean-outtool,notyourhands

Figure24).

(

Figure22

Toraiseorlowertheangleofthechutedeector,press
thetriggeronthechutedeectorandmovethechute
deectorupordown(Figure23).

Figure23

1.Chutedeectortrigger2.Chutedeector

Figure24

PreventingFreeze-upafterUse

•Lettheenginerunforafewminutestoprevent
movingpartsfromfreezing.Stoptheengine,wait
forallmovingpartstostop,andremoveiceand
snowfromthemachine.

•Cleanoffanysnowandicefromthebaseofthe
chute.

•Rotatethedischargechuteleftandrighttofreeit
fromanyicebuildup.

•WiththeignitionkeyintheOffposition,pullthe
recoilstarterhandleseveraltimesorconnectthe
electricalcordtoapowersourceandthemachine
andpushtheelectricstartbuttononce(model38569

12

only)topreventtherecoilstarterand/ortheelectric
starterfromfreezingup.

•Insnowyandcoldconditions,somecontrolsand
movingpartsmayfreeze.Donotuseexcessiveforce
whentryingtooperatefrozencontrols.Ifyouhave
difcultyoperatinganycontrolorpart,startthe
engineandletitrunforafewminutes.

OperatingTips

WARNING

Therotorbladescanthrowstones,toys,andother
foreignobjectsandcauseseriouspersonalinjuryto
theoperatorortobystanders.

•Keeptheareatobeclearedfreeofallobjects
thattherotorbladescouldpickupandthrow.

•Keepallchildrenandpetsawayfromthearea
ofoperation.

•Removethesnowassoonaspossibleafteritfalls.

•Ifthemachinedoesnotpropelitselfforwardon
slipperysurfacesorinheavysnow,pushforwardon
thehandle,butallowthemachinetoworkatitsown
pace.

•Overlapeachswathtoensurecompletesnow
removal.

•Dischargethesnowdownwindwheneverpossible.

Maintenance

Note:Determinetheleftandrightsidesofthemachinefromthenormaloperatingposition.

RecommendedMaintenanceSchedule(s)

MaintenanceService

Interval

Afterthersthour

Aftertherst2hours

Beforeeachuseordaily

Yearly

Yearlyorbeforestorage

MaintenanceProcedure

•Checkthecontrolcableandadjustitifnecessary.

•Checkforloosefastenersandtightenthemifnecessary.

•Changetheengineoil.

•Checktheengineoillevelandaddoilifnecessary.

•Checkthecontrolcableandadjustitifnecessary.

•InspecttherotorbladesandhaveanAuthorizedServiceDealerreplacetherotor
bladesandscraperifnecessary.

•Changetheengineoil.

•Servicethesparkplugandreplaceitifnecessary.

•Checkforloosefastenersandtightenthemifnecessary.

•HaveanAuthorizedServiceDealerinspectthedrivebeltandreplaceitifnecessary.

•Preparethemachineforstorage.

AdjustingtheControlCable

CheckingtheControlCable

ServiceInterval:Afterthersthour—Check

thecontrolcableandadjustitif
necessary.

Yearly—Checkthecontrolcableand
adjustitifnecessary.

Movethecontrolbarbacktowardthehandletoremove
theslackinthecontrolcable(Figure25).

13

Figure25

1.Controlbar2.1/16-inchto1/8-inch(2
mmto3mm)gap

Note:Ensurethata1/16-inchto1/8-inch(2mmto3
mm)gapexistsbetweenthecontrolbarandthehandle

Figure25).

(

Important:Thecontrolcablemustcontainsome
slackwhenyoudisengagethecontrolbarforthe
rotorbladestostopproperly.

Note:MovingtheZ-ttinghigherdecreasesthe
gapbetweenthecontrolbarandthehandle;moving
itlowerincreasesthegap.

3.Hookthespringtotheadjusterlinkandslidethe
springcoverovertheadjusterlink.

4.Checktheadjustment;refertoCheckingtheControl
Cable.

Note:Afterextendeduse,thedrivebeltmaywear
andloseitsproperbelttension.Ifthedrivebelt
slips(continuouslysqueals)underaheavyload,
disconnectthespringfromtheadjustorlinkand
movetheupperendofthespringtotheholethat
isfurtherfromthepivotpointinthecontrolbar

Figure27).Thenconnectthespringtotheadjustor

(
linkandadjustthecontrolcable.

AdjustingtheControlCable

1.Slideupthespringcoverandunhookthespring
fromtheadjusterlink(Figure26).

Figure26

1.Adjusterlink

2.Z-tting

3.Springcover

4.Unhookthespringhere.

Figure27

1.Removetheupperendof
springfromthishole

2.Inserttheupperendof
springintothishole

3.Pivotpoint

4.Upperendofspring

Note:Thebeltmayslip(squeal)inwetconditions;
todryoutthedrivesystem,starttherotorandrun
itwithoutaloadfor30seconds.

Note:Youcanpulluptheadjusterlinkandcableto
makeunhookingthespringeasier.

2.MovetheZ-ttingtoahigherorlowerholeonthe
adjusterlinkasneededtoobtainthe1/16-inchto
1/8-inch(2mmto3mm)gapbetweenthecontrol
barandthehandle(Figure25).

14

InspectingtheRotorBlades

ServiceInterval:Yearly—Inspecttherotorbladesand

haveanAuthorizedServiceDealer
replacetherotorbladesandscraperif
necessary.

Beforeeachsession,inspecttherotorbladesforwear.
Whenarotorbladeedgehasworndowntothewear
indicatorhole,haveanAuthorizedServiceDealer
replacetherotorbladesandthescraper(

Figure28).

4.Afterdrainingtheusedoil,returnthemachinetothe
operatingposition.

5.Installtheoildrainplugandtightenitsecurely.

6.Cleanaroundtheoilllcap(

Figure30

1.Oilllcap

Figure30).

7.Unscrewtheoilllcapandremoveit(Figure30).

Figure28

1.Thewearindicatorholeis
intact;youdonotneedto
replacetherotorblades.

2.Thewearindicatorholeis
exposed;replacetherotor
blades.

ChangingtheEngineOil

ServiceInterval:Aftertherst2hours

Yearly

Runtheengineafewminutesbeforechangingtheoil
towarmit.Warmoilowsbetterandcarriesmore
contaminants.

1.Siphonthefuelfromthefueltankintoanapproved
fuelcontainer,orruntheengineuntilitstops.

2.Movethemachinetoalevelsurface.

3.Placeanoildrainpanundertheoildrainplug,
removetheoildrainplug,andtipthemachine
backwardanddraintheusedoilintheoildrainpan
Figure29).

8.Withthemachineintheoperatingposition,carefully
pouroilintotheoilllhole.Waitthreeminutes,
thenaddoiltothepointofoverow(

Figure32).

Note:Youmaytipthemachineforward(handle
up)alittletomakeaddingoileasier.Rememberto
returnthemachinetotheoperatingpositionbefore
checkingtheoillevel.

Important:Donottipthemachinealltheway
forwardontoitsnose,orfuelmayleakoutof
themachine.

Maxll:20oz.(0.6l),type:automotivedetergentoil
withanAPIserviceclassicationofSJ,SL,orhigher.

Figure31belowtoselectthebestoilviscosity

Use
fortheoutdoortemperaturerangeexpected:

Figure29

15

Figure31

2.Rotatethedischargechutesothatitfacesforward.

3.Removethedischargechute,thedischargechute
handle,andthechutesealbyremovingthe3large
screwsandonesmallscrew(

Figure33).

1.UsingSAE30atoutdoor
temperaturesbelow40°F
(4°C)willresultinhard
starting.

2.Using10W-30atoutdoor
temperaturesabove
80°F(27°C)mayresultin
increasedoilconsumption;
therefore,checktheoil
levelmorefrequentlyin
thesecircumstances.

Note:0W30syntheticoilisacceptableforusein
coldtemperatures.

Figure32

Figure33

1.Fueltankcap

2.Largescrews(3)5.Chuteseal

3.Dischargechute

4.Smallscrew

4.Removethe4screwsthatsecuretheshroud
(Figure34).

9.Screwtheoilllcapintotheoilllhole,andhand
tightenitsecurely.

10.Wipeupanyspilledoil.

11.Disposeoftheusedoilproperlyatalocalrecycling
center.

ServicingtheSparkPlug

ServiceInterval:Y early—Servicethesparkplugand

replaceitifnecessary.

UseaNGKBPR6ESorChampionRN9YCspark
plugorequivalent.

1.Stoptheengineandwaitforallmovingpartstostop.

Figure34

1.Screw(4)3.Sparkplug

2.Shroud4.Spark-plugwire

16

5.Removethefueltankcap.

6.Removetheshroud(Figure34).

7.Installthefueltankcap.

8.Disconnectthewirefromthesparkplug.

9.Cleanaroundthesparkplug.

10.Removethesparkplugfromthecylinderhead.

Important:Replaceacracked,fouled,or
dirtysparkplug.Donotcleantheelectrodes
becausegritenteringthecylindercandamage
theengine.

11.Setthegapontheplugto0.030inch(0.76mm)
(

Figure35).

Note:Ensurethattheupperandlowershroudst
togetherinthesidegrooves.

16.Installthefueltankcap.

17.Installthechuteseal,thedischargechute,andthe
dischargechutehandleontothemachineusingthe
hardwareyouremovedinstep

3.

Note:Thesmallscrewgoesthroughthesmallhole
inthechutesealatthefrontofthedischargechute
opening.

Figure35

1.Centerelectrodeinsulator3.Airgap(nottoscale)

2.Sideelectrode

12.Installthesparkplugandtorqueitto20–22ft-lb
(27–30N-m).

13.Connectthewiretothesparkplug.

Note:Ensurethatthebreathertubeisroutedabove
thesparkplugwireasshowninFigure36.

Figure36

1.Breathertube

2.Carburetordrainbolt

14.Removethefueltankcap.

15.Installtheshroudwiththescrewsyouremovedin
step4.

17

AdjustingtheQuickShoot™
Control

Ifthereismorethan1/2inch(13mm)ofslackinthe
QuickShootcable(
doesnotrotateleftandrightinequalangles,adjustthe
QuickShootcontrolcables.

1.1/2inch(13mm)maximumslack

1.LoosenthetwoQuickShootcontrolcableclamps
(Figure38).

Figure37)orthedischargechute

Figure37

Figure39

1.Arrows

3.Rotatethedischargechutesothatitfacesstraight
aheadandthearrowonthebackofthedischarge
chutealignswiththearrowontheshroud(

Figure40).

Figure38

1.Cableclamps

2.PositiontheQuickShootcontrolbetweenthetwo
arrowslocatedontherighthandsideoftheupper
handle(

Figure39).

Figure40

4.Holdthedischargechuteinthestraight-ahead
position,pullthelowercablecasingdownwarduntil
youremovetheslackinthecable,andtightenthe
screwonthelowercableclampsecurely(Figure41).

18

Figure41

1.Lowercablecasing

5.Pulltheuppercablecasingforwarduntilyouremove
theslackinthecable,andtightenthescrewonthe
uppercableclampsecurely(Figure42).

Figure42

1.Uppercablecasing

Note:Donotover-tensionthecables.Ifthecables
areover-tensioned,theQuickShootwillbehardto
operate.

19

Storage

areasbeforepainting,andusearustpreventativeto
preventthemetalpartsfromrusting.

StoringtheMachine

WARNING

•Gasolinefumesarehighlyammable,explosive,
anddangerousifinhaled.Ifyoustorethe
machineinanareawithanopename,the
gasolinefumesmayigniteandcausean
explosion.

•Donotstorethemachineinahouse(living
area),basement,oranyotherareawhereignition
sourcesmaybepresent,suchashotwaterand
spaceheaters,clothesdryers,furnaces,and
otherlikeappliances.

•Donottipthemachinebackwardwithfuelin
thefueltank;otherwise,fuelmayleakoutof
themachine.

1.Onthelastrefuelingoftheseason,addfuelstabilizer
tofreshfuelasdirectedbytheenginemanufacturer.

2.Runtheenginefor10minutestodistributethe
conditionedfuelthroughthefuelsystem.

15.Tightenanyloosefasteners.Repairorreplaceany
damagedparts.

16.Coverthemachineandstoreitinaclean,dryplace
outofthereachofchildren.Allowtheengineto
coolbeforestoringitinanyenclosure.

3.Stoptheengine,allowittocool,andsiphonthefuel
tankorruntheengineuntilitstops.

4.Starttheengineandrunituntilitstops.

5.Chokeorprimetheengine,startitathirdtime,and
runtheengineuntilitwillnotstart.

6.Drainthefuelinthecarburetorthroughthe
carburetordrainbolt(
gasolinecontainer.

7.Disposeofunusedfuelproperly.Recycleitaccording
tolocalcodes,oruseitinyourautomobile.

8.Whiletheengineisstillwarm,changetheengineoil.
RefertoChangingtheEngineOil.

9.Removethesparkplug.

10.Squirt2teaspoonsofoilintothesparkplughole.

11.Installthesparkplugbyhandandthentorqueitto
20–22ft-lb(27–30N-m).

12.WiththeignitionkeyintheOffposition,pullthe
recoilstarterslowlytodistributetheoilontheinside
ofthecylinder.

Figure36)intoanapproved

13.Cleanthemachine.

14.Touchupchippedsurfaceswithpaintavailable
fromanAuthorizedServiceDealer.Sandaffected

20

Notes:

21

EuropeanPrivacyNotice

TheInformationT oroCollects
ToroWarrantyCompany(Toro)respectsyourprivacy.Inordertoprocessyourwarrantyclaimandcontactyouintheeventofaproductrecall,weaskyou
tosharecertainpersonalinformationwithus,eitherdirectlyorthroughyourlocalT orocompanyordealer.

TheTorowarrantysystemishostedonserverslocatedwithintheUnitedStateswhereprivacylawmaynotprovidethesameprotectionasapplies
inyourcountry.

BYSHARINGYOURPERSONALINFORMATIONWITHUS,YOUARECONSENTINGTOTHEPROCESSINGOFYOURPERSONALINFORMATION
ASDESCRIBEDINTHISPRIVACYNOTICE.

TheW ayToroUsesInformation
Toromayuseyourpersonalinformationtoprocesswarrantyclaims,tocontactyouintheeventofaproductrecallandforanyotherpurposewhichwetell
youabout.ToromayshareyourinformationwithT oro'safliates,dealersorotherbusinesspartnersinconnectionwithanyoftheseactivities.Wewillnot
sellyourpersonalinformationtoanyothercompany .Wereservetherighttodisclosepersonalinformationinordertocomplywithapplicablelawsand
withrequestsbytheappropriateauthorities,tooperateoursystemsproperlyorforourownprotectionorthatofotherusers.

RetentionofyourPersonalInformation
Wewillkeepyourpersonalinformationaslongasweneeditforthepurposesforwhichitwasoriginallycollectedorforotherlegitimatepurposes
(suchasregulatorycompliance),orasrequiredbyapplicablelaw.

Toro'sCommitmenttoSecurityofY ourPersonalInformation
Wetakereasonableprecautionsinordertoprotectthesecurityofyourpersonalinformation.Wealsotakestepstomaintaintheaccuracyandcurrent
statusofpersonalinformation.

AccessandCorrectionofyourPersonalInformation
Ifyouwouldliketorevieworcorrectyourpersonalinformation,[e-mail].

374-0282RevB

IntlDistList

Distributor:

AtlantisSuveSulamaSisstemleriLt
BalamaPrimaEngineeringEquip.HongKong85221552163
B-RayCorporation
CascoSalesCompany
CeresS.A.CostaRica
CSSCTurfEquipment(pvt)Ltd.SriLanka
CyrilJohnston&Co.
EquiverMexico525553995444
FemcoS.A.Guatemala
G.Y .K.CompanyLtd.
GeomechanikiofAthensGreece
GuandongGoldenStarChina
HakoGroundandGardenSweden
HakoGroundandGarden
HayterLimited(U.K.)

HydroturfInt.CoDubai
HydroturfEgyptLLC
IbeaS.P .A.
IrriamcPortugal351212388260
IrrigationProductsInt'lPvtLtd.India862283960789
JeanHeybroekb.v.Netherlands3130639461 1
MaquiverS.A.Colombia
MaruyamaMfg.Co.Inc.
MetraKft
Mountelda.s.CzechRepublic
MunditolS.A.
OslingerTurfEquipmentSA
OyHakoGroundandGardenAb
ParklandProductsLtd.NewZealand6433493760
Prochaska&Cie
RTCohen2004Ltd.
Riversa
ScSvendCarlsenA/S
SolvertS.A.S.
SpyprosStavrinidesLimitedCyprus
SurgeSystemsIndiaLimited
T-MarktLogisticsLtd.Hungary3626525500
ToroAustraliaAustralia61395807355
ToroEuropeNVBelgium3214562960

Country:

Turkey902163448674

Korea82325512076
PuertoRico7877888383

NorthernIreland442890813121

Japan81726325861

Norway4722907760
UnitedKingdom441279723444

UnitedArabEmirates97143479479
Egypt2025194308
Italy390331853611

Japan81332522285
Hungary3613263880

Argentina541 148219999
Ecuador59342396970
Finland35898700733

Austria4312785100
Israel97298617979
Spain
Denmark4566109200
France33130817700

India911292299901

PhoneNumber:

5062391138
941 12746100

5024423277

30109350054
862087651338
4635100000

5712364079

420255704220

34952837500

35722434131

374-0269RevC

TheToroWarranty

ConditionsandProductsCovered

TheToroCompanyanditsafliate,T oroWarrantyCompany,pursuantto
anagreementbetweenthem,jointlypromisetotheoriginalpurchaser*
torepairtheT oroProductslistedbelowifdefectiveinmaterialsor
workmanship.

Thefollowingtimeperiodsapplyfromthedateofpurchase:

ProductsWarrantyPeriod

WalkPowerMowers

•CastDeck

5yearsResidentialUse
45DaysCommercialUse

•Engine

5yearsGTSPromise
Seeenginemanufacturer'swarranty

•SteelDeck

2yearsResidentialUse
45DaysCommercialUse

•Engine

2yearsGTSPromise
Seeenginemanufacturer'swarranty

ElectricHandHeldProducts2yearlimitedwarranty

Snowthrowers

•SingleStage

2yearsResidentialUse
45DaysCommercialUse

•TwoStage

2yearsResidentialUse
45DaysCommercialUse

•Electric2yearsResidentialUse

AllRide-OnUnitsBelow

•Engine

Seeenginemanufacturer'swarranty
1yearPartsonly

•Attachments1year

RearEngineRiders2yearsResidentialUse

90DaysCommercialUse

Lawn&GardenTractors

2yearsResidentialUse
90DaysCommercialUse

TimeCutterZMowers

3yearsResidentialUse
30DaysCommercialUse

TITANMowers3yearsor240hours

•Frame

Lifetime(originalowneronly)

TITANMXMowers3yearsor400hours

•Frame
ZMasterMowers—2000Series

•Frame

Lifetime(originalowneronly)
5yearsor1200hours
Lifetime(originalowneronly)

2

2

2

2

2

2

2

2

3

4

3

4

3

4

OwnerResponsibilities

YoumustmaintainyourToroProductbyfollowingthemaintenance
proceduresdescribedintheOperator'sManual.Suchroutine
maintenance,whetherperformedbyadealerorbyyou,isatyourexpense.

InstructionsforObtainingWarrantyService

IfyouthinkthatyourT oroProductcontainsadefectinmaterialsor
workmanship,followthisprocedure:

1.Contactyoursellertoarrangeserviceoftheproduct.Ifforanyreason
itisimpossibleforyoutocontactyourseller,youmaycontactany
ToroAuthorizedDistributortoarrangeservice.

1

2.Bringtheproductandyourproofofpurchase(salesreceipt)tothe
ServiceDealer.IfforanyreasonyouaredissatisedwiththeService
Dealer’sanalysisorwiththeassistanceprovided,contactusat:

1

CustomerCareDepartment,RLCDivision
TheT oroCompany
811 1LyndaleAvenueSouth
Bloomington,MN55420-1196
Manager:TechnicalProductSupport:001–952–887–8248

SeeattachedDistributorList

ItemsandConditionsNotCovered

1

Thisexpresswarrantydoesnotcoverthefollowing:

•Costofregularmaintenanceserviceorwearparts,suchasblades,

rotorblades(paddles),scraperblades,belts,fuel,lubricants,oil
changes,sparkplugs,cable/linkageorbrakeadjustments

•Anyproductorpartwhichhasbeenalteredormisusedandrequires

replacementorrepairduetoaccidentsorlackofpropermaintenance

•Repairsnecessaryduetofailuretousefreshfuel(lessthanone

monthold),orfailuretoproperlypreparetheunitpriortoanyperiod
ofnon-useoveronemonth

•Engineandtransmission.Thesearecoveredbytheappropriate

manufacturer’sguaranteeswithseparatetermsandconditions

Allrepairscoveredbythesewarrantiesmustbeperformedbyan
AuthorizedToroServiceDealerusingT oroapprovedreplacementparts.

*OriginalPurchasermeansthepersonwhooriginallypurchasedtheT oroProduct.

1

SomeenginesusedonT oroProductsarewarrantedbytheenginemanufacturer.

2

Residentialusemeansuseoftheproductonthesamelotasyourhome.Useatmorethanone

locationisconsideredcommercialuseandthecommercialusewarrantywouldapply.

3

Whicheveroccursrst.

4

LifetimeFrameW arranty-Ifthemainframe,consistingofthepartsweldedtogethertoformthe

tractorstructurethatothercomponentssuchastheenginearesecuredto,cracksorbreaksin

normaluse,itwillberepairedorreplaced,atToro'soption,underwarrantyatnocostforparts

andlabor.Framefailureduetomisuseorabuseandfailureorrepairrequiredduetorustor

corrosionarenotcovered.

Thiswarrantyincludesthecostofpartsandlabor,butyoumustpay
transportationcosts.

Warrantymaybedeniedifthehourmeterisdisconnected,altered,or
showssignsofbeingtamperedwith.

GeneralConditions

Thepurchaseriscoveredbythenationallawsofeachcountry.Therights
towhichthepurchaserisentitledwiththesupportoftheselawsarenot
restrictedbythiswarranty .

374-0268RevC
