Toro 30857, 30858, 30881, 30882 Brochure

Groundsmaster®
Contour™ Plus Family

There’s more than one way
to lower costs and raise productivity.

The Groundsmaster® Contour™ Plus Family.
Because one size doesn’t fit all your mowing needs.

Since 1973, Toro Groundsmasters have been proven on more of the world’s top golf courses,
delivering consistent, clean cuts and breathtaking roughs. But we’re not satisfied.
That’s why the new Groundsmasters are engineered with innovations like Sidewinder®
cutting units for precise trimming, CrossTrax® all-wheel drive for superior traction, and
SmartCool™ for unsurpassed cooling performance. No matter which Groundsmaster
you choose, you’ll get the legendary performance that makes this an unbeatable foursome.

109”

Take your productivity to
a whole new dimension with
the power and performance of
the new Toro Groundsmasters.

68”

(173 cm)

3.5

acres/hr

(1.4 ha/hr)

90”

(229 cm)

5.4

acres/hr

(2.2 ha/hr)

(277 cm)

6.5

acres/hr

(2.6 ha/hr)

150”

(381 cm)

8.9

acres/hr

(3.6 ha/hr)

3500-D

4300-D

4500-D

4700-D

Productivity per hour dependent on operator and turf conditions. Assume 85% efficiency for turns and overlap.

Groundsmaster® Contour™ Plus Family

Cutting edge
performance
runs in this family.

A cut above the rest.

Contour™ Plus free-floating cutting units

follow the ground on rolling terrain. Air inlet

pockets keep the grass standing tall for a

clean cut on every blade, and an anti-scalp

cup ensures the cutting unit is never

too close for comfort.

Wet grass has met its match.

Unleash the power and efficiency

of a Kubota® turbocharged, liquid

cooled, diesel engine on your rough.

With enough horsepower and torque

to handle the most demanding

mowing conditions, these engines
are almost unstoppable.

Down with downtime.

Routine service and maintenance just got easier.

With quick, tool-free access to regular service

points, and common parts across the Groundsmaster

line, your mowers will be back on the job faster.

Nonstop comfort.

The adjustable Air Ride seat (standard on

Groundsmaster 4500-D and 4700-D), power

steering and one-touch controls work together

to shift the comfort and productivity of

your operators into high gear.

Earns its stripes.

Get a picture-perfect cut every time. Heavy-duty

rollers create the beautiful striping appearance you

see on championship courses and sports fields.

Groundsmaster® 3500-D

The Toro Groundsmaster 3500-D
is small in size, and big on
performance and productivity.

Groundsmaster® 3500-d

• Sidewinder® cutting system

• Three 27” (69 cm) Contour™ Plus

free-floating cutting units with
rear rollers

• 68” (173 cm) cutting swath

• Series/Parallel™ 3-wheel drive traction system

The Groundsmaster 3500-D
effortlessly trims around bunkers,
trees, water hazards and
anything else in its way.

Meet the overachiever.

Its performance is way bigger than its size. The Toro Groundsmaster 3500-D
gives you the precision trimming you’d expect from a reel mower, with the
easy maintenance of a rotary mower, making it a smart addition to any
mowing fleet. Its full-time 3-wheel drive system senses slippage and
shifts the power to at least two wheels at all times, maintaining
traction under tough, wet
conditions. Now areas that
used to require two different
machines can be maintained
with one highly efficient
Groundsmaster.

It boldly goes where
no other riding mower can.

Talk about extending your reach.

The patented Sidewinder cutting system

on the Groundsmaster 3500-D slides the cutting

units from side to 1 cm) to trim hard-to-reach turf.

It also lets operators change tire tracking to reduce

turf compaction in areas where the same

patterns are mowed.

Groundsmaster® 3500-D

“Picture perfect striping.”

Every home game at the University
of Notre Dame is televised. To
make sure the field in Notre Dame
Stadium is looking its best, the
finicky sports field managers trust
the Toro Groundsmaster 3500-D.
Not only does it provide the superior
quality of cut they demand, it produces
the attractive turf striping fans
around the world expect.

3500-D ACCESSORIES

• Work light kit

• Canvas sunshade

• High lift blade

• Combination
blade

• Angle sail blade

• Atomic®
mulching blade

• Leaf mulching kit

• Sectional rear roller

blade

Groundsmaster® 4300-D

The medium-sized Toro
Groundsmaster 4300-D
is unstoppable with

®

CrossTrax

all-wheel drive.

Groundsmaster® 4300-d

• Five 22” (56 cm) Contour™ Plus rotary
cutting units for virtually no scalping

• Full-length striping rear rollers

• 7.5’ (229 cm) width of cut

• Air Ride seat suspension (optional)

• Integrated ControlHub
electronic controls

• 44 hp (32.9 kW) Kubota® turbo-diesel engine

• CrossTrax

®

all-wheel drive system

™

with fingertip

Steep slopes.
Wet grass.
Rolling terrain.
Bring it on.

You’ve never seen traction like this. The new CrossTrax®

all-wheel drive system automatically senses when one of the front

tires begins to slip, and instantly transfers power from the front to the

opposite rear wheel. The Groundsmaster 4300-D turns mountains into

molehills, zooming easily up slippery, steep slopes.

Its five contour cutting units leave the
competition in the rough.

Floating effortlessly over thick grass and rolling terrain,
the new Toro Groundsmaster 4300-D is designed to give
you unsurpassed performance and value in a medium-sized
rotary mower. With its unique CrossTrax®all-wheel drive
system, a powerful 44 (33kW) hp turbo-diesel engine and
five 22” (56 cm) Contour™ Plus cutting units,
it leaves the competition spinning their wheels.

Groundsmaster® 4300-D

“e perfect size.

Why did Cassique on Kiawah Island
choose the new Groundsmaster
4300-D? Just reading the spec sheet
and taking a quick test drive on the
prototype was enough to convince
Club Superintendent Randall Glover
that the Groundsmaster 4300-D,
with its smaller 22” cutting units,
would be the perfect size to mow
Cassique’s hilly rough with thousands
of sharp undulations. According
to Glover, “The 4300-D has to be
the most versatile mower out there,
which is really important to us.”

”

4300-D ACCESSORIES

• Air ride seat
suspension

• Sunshade

• Overhead
operator fan

• High lift blade

• Combination blade

• Angle sail blade

• Leaf mulching kit

Groundsmaster® 4500-D

Mow large with the Toro
Groundsmaster 4500-D
and take your productivity
to the next level.

Groundsmaster® 4500-d

• Five 27” (69 cm) Contour™ Plus rotary cutting units
for virtually no scalping

• Full-length striping rear rollers

• 9’ (277 cm) width of cut

• 6.5” (16.5 cm) cutting unit overlap to eliminate streaking

• SmartCool

• 4-Way Adjustable Seat and Air Ride Suspension

• Integrated ControlHub
electronic controls

• 60 hp (45 kW) Kubota® turbo-diesel engine

• Full-time, bi-directional 4WD

• Reliable planetary gear wheel drive system

™

system with auto-reversing cooling fan

™

with fingertip

Big on power,
precision and performance.

It’s the best of both worlds: a larger than life rotary mower
that devours acres of rough one moment, and the next is an
ultra-precise cutting machine. The Toro Groundsmaster 4500-D
does it all with more torque and power than any mower
in its class. With full-time, bi-directional 4-wheel drive
and individual wheel brakes, the Groundsmaster 4500-D
delivers the kind of superior handling and control
that keeps your operators moving at
peak performance.

Groundsmaster® 4500-D

e right blade

for the right job.

When mowing conditions change,
you can quickly and easily change
the Groundsmaster with accessory
blades designed to get the job done.

Combo Blade Ideal for mowing in

a wide range of conditions, this blade is
provided as original equipment.

Angle Sail Blade A low lift blade

designed for thick grass and heavy
mowing.

Engineered to never lose its cool.

Here’s the coolest advancement in our relentless

drive to end downtime. When things start to heat up

under the hood, our exclusive SmartCool™ system briefly

reverses the cooling fan and blasts chaff and debris from

the air intake screens. The result is nonstop productivity.

What more could you ask for?

Atomic Blade A high-performance

mulching blade that also helps hide
clippings in the turf.

High Lift Blade Designed for cool

season grasses that may be heat stressed
or maintained at higher HOC, this blade
also helps in dispersion.

4500-D ACCESSORIES

• Sunshade

• Angle sail blade

®

• Atomic
mulching blade

• Combination blade

• High lift blade

• Leaf mulching kit

• Sectional rear roller

Groundsmaster® 4700-D

The Toro Groundsmaster 4700-D
is engineered to give you an extra
large return on your investment.

Groundsmaster® 4700-d

• Seven 27” (69 cm) Contour™ Plus rotary
cutting units for virtually no scalping

• Full-length striping rear rollers

• 12.5’ (381 cm) width of cut

• 6.5” (16.5) cutting unit overlap to eliminate streaking

• SmartCool

• 4-Way Adjustable Seat and Air Ride Suspension

• Integrated ControlHub
electronic controls

• 60 hp (45 kW) Kubota® turbo-diesel engine

• Full-time, bi-directional 4WD

• Reliable planetary gear wheel drive system

™

system with auto-reversing cooling fan

™

with fingertip

Mission control.

Want to raise operator productivity?

Put your operators in control of their own

comfort. Start with a Toro Air Ride seat and

armrests that adjust for individual preferences,

a steering tower that quickly tilts for optimum fit,

and electronic controls that are easy to access

from the seat arm. Throw in plenty of storage

space behind the seat, and your operators

will be ready to go the distance.

Master of the universe.

Is wider better? That’s like asking if more productivity is better.
The Groundsmaster 4700-D answers with a resounding yes, in the
form of an awe-inspiring 12.5’ (381 cm) width of cut, powered by a
60 hp (45 kW) turbo-diesel Kubota® engine that lets you mow up
to 8.9 acres per hour (3.6 ha/hr). Add in 7 floating Contour™ Plus

cutting units, full-time bi-directional 4-wheel drive

and the innovative Smart Cool™ system, and

you have productivity and performance
no other mower can touch.

Groundsmaster® 4700-D

“A real workhorse.”

With nearly 1,000 acres of turf to
maintain, including around 70 soft
ball diamonds and 45 soccer fields,
the city of Eagan, Minnesota needs
a mower that can devour thick,
long grass from sunrise to sunset,
day after day. The Groundsmaster
4700-D, with its seven Contour Plus
cutting units, does that and more.
Mowing 8.9 acres per hour, the
Groundsmaster 4700-D is the
workhorse Eagan counts on to
look great all summer long.

4500-D ACCESSORIES

• Sunshade

• Angle sail blade

®

• Atomic
mulching blade

• Combination blade

• High lift blade

• Leaf mulching kit

• Sectional rear roller

Specifications

4700-D

Groundsmaster® Contour™ Plus Family

Model

Engine

Rating: Gross

Rating: Net

Auto Reversing
Cooling Fan

Fuel Capacity

Fuel Consumption*

Mow Speed

Transport Speed

Mowing Capacity

Total Width of Cut

4700-D

®

Kubota

Diesel

60 hp (45 kW)

58 hp (43.5 kW)
@ 2600 rpm

SmartCool™

22 gal (79.5 L)

1.7 gal/h (6.4 L/h)

0-7 mph
(0-11.3 km/h)

0-13 mph
(0-21 km/h)

8.9 acres per hour
(3.6 ha/h)
@ 7 mph (11.3 km/h)

150” (381 cm)

4500-D

®

Diesel

Kubota

60 hp (45 kW)

58 hp (43.5 kW)
@ 2600 rpm

SmartCool™

22 gal (79.5 L)

1.6 gal/h (6.1 L/h)

0-7 mph
(0-11.3 km/h)

0-13 mph
(0-21 km/h)

6.5 acres per hour
(2.6 ha/h)
@ 7 mph (11.3 km/h)

109” (277 cm)

4500-D

The Toro Groundsmaster Contour Plus series meets the specifications of any sized job. For more detailed information, visit www.toro.com.

4300-D

®

Diesel

Kubota

44.2 hp (32.9 kW)

42 hp (31.3 kW)
@ 3000 rpm

NA

13.5 gal (51.1 L)

1.5gal/h (5.7 L/h)

0-7 mph
(0-11.3 km/h)

0-10 mph
(0-16.7 km/h)

5.4 acres per hour
(2.2 ha/h)
@ 7 mph (11.3 km/h)

90” (229 cm)

3500-D

®

Diesel

Kubota

35 hp (26.1 kW)

32 hp (23.9kW)
@ 2800 rpm

NA

11 gal (42 L)

0.9 gal/h (3.43 L/h)

0-6 mph
(0-10 km/h)

0-9 mph
(0-14 km/h)

3.5 acres per hour
(1.4 ha/h)
@ 6 mph (9.6 km/h)

68” (173 cm)

Model

Cutting Decks

Traction Unit
Drive System

Four/All Wheel
Drive System

Overall Height

Overall Length

Overall Width

Transport Width

Wheelbase

Ground Clearance

Overall Weight**

4300-D

4700-D

Seven

™

Plus 27”

Contour
(69 cm) Decks

Hydrostatic,
Closed Loop

Full Time 4WD
Bi-Directional

85” (216 cm)

145.8” (370 cm)

153.8” (391 cm)

88.3” (224 cm)

67.5” (172 cm)

6” (15.3 cm)

4824 lbs. (2193 kg)

4500-D

Five

™

Contour
(69 cm) Decks

Hydrostatic,
Closed Loop

Full Time 4WD
Bi-Directional

85” (216 cm)

145.8” (370 cm)

112.8” (287 cm)

88.3” (224 cm)

67.5” (172 cm)

6” (15.3 cm)

4273 lbs. (1942 kg)

Plus 27”

3500-D

4300-D

Five

™

Plus 22”

Contour
(56 cm) Decks

Series Parallel
Hydrostatic,
Closed Loop

®

Cross Trax

86” (2xx cm)

126” (320 cm)

96.3” (224 cm)

88.3” (224 cm)

60” (152.4 cm)

5” (12.7 cm)

3254 lbs. (1476 kg)

AWD

3500-D

Three

™

Plus 27”

Contour
(69 cm) Decks w/
Sidewinder Feature

Series Parallel
Hydrostatic,
Closed Loop

3 WD

71” (180 cm)

116” (295 cm)

72”” (173cm)

72” (173 cm)

60” (152.4 cm)

6” (15.3 cm)

2200 lbs. (1100 kg)

T O R O® P R O F E S S I O N A L S ER V I C E S

Toro Financing A full-service offering for all your
equipment and irrigation purchases. Flexible
financing options can be tailored to meet your
operational needs.

Toro Protection Plus Extended Protection
Plan Protect your budget and your equipment

investment. Plans are available for both new
and used equipment, and you can choose from
various terms to fit your financing terms.

Products depicted in this brochure are for demonstration purposes only. Actual products offered for sale may vary.
©2010 The Toro Company, 8111 Lyndale Ave. S., Bloomington, MN 55420-1196 Part No.10-043-T. Printed in U.S.A.

Toro Genuine Parts Keep the productivity and
performance of your equipment at its peak.
Learn about Performance Parts pricing and MVP
kits. Find replacement parts online at Toro.com/
partsviewer.

Toro Training Toro Factory Service Schools are
available. Explore the training and customer care
areas of Toro.com and ToroNSN.com for readily
available education and training materials.

*Dependent on operator and turf conditions. Assume 85% efficiency for turns and overlap. **With full fluids.

Toro Controller Repair Provides irrigation
controller boards ready for immediate board
exchange to assure that downtime is minimal and
your turf stays protected. Toro is the choice for
reliability.

®

Toro NSN

An industry-first support network
that provides reliable, around-the-clock irrigation
central control system troubleshooting and
operation assistance. Call 1-800-ASK-TORO.

NEW! myTurf™ Fleet Management This on-line

tool from Toro keeps track of maintenance for
all of your turf equipment. Complete product
information and parts ordering is also included.
Ask your distributor for availability.
