FORM NO. 3317-212 UK
MODEL NO. 26630BC - 5900001 & UP
MODEL NO. 26635BC - 5900001 & UP
SAFETY INSTRUCTIONS
TRAINING
1. Read the instructions carefully. Be familiar with the
controls and the proper use of the equipment.
2. Never allow children or people unfamiliar with
these instructions to use the lawnmower. Local
regulations may restrict the age of the operator.
3. Never mow while people, especially children, or
pets are nearby.
4. Keep in mind that the operator or user is
responsible for accidents or hazards occurring to
other people or their property.
PREPARATION
1. While mowing, always wear substantial footwear
and long trousers. Do not operate the equipment
when barefoot or wearing open sandals.
2. Thoroughly inspect the area where the equipment
is to be used and remove all objects which may be
thrown by the machine.
3. WARNING - Petrol is highly flammable.
D Store fuel in containers specifically designed
for this purpose.
D Refuel outdoors only and do not smoke while
refuelling.
D Add fuel before starting the engine. Never
remove the cap of the fuel tank or add petrol
while the engine is running or when the
engine is hot.
D If petrol is spilled, do not attempt to start the
engine but move the machine away from the
area of spillage and avoid creating any source
of ignition until petrol vapors have dissipated.
D Replace all fuel tanks and container caps
securely.
4. Replace faulty silencers.
5. Before using, always visually inspect to see that
the blades, blade bolts and cutter assembly are not
worn or damaged. Replace worn or damaged blades
and bolts in sets to preserve balance.
6. On multibladed machines, take care as rotating
one blade can cause other blades to rotate.
OPERATOR'S
MANUAL
53 CM REAR BAGGER
Mower
OPERATION
1. Do not operate the engine in a confined space
where dangerous carbon monoxide fumes can
collect.
2. Mow only in daylight or in good artificial light.
3. Avoid operating the equipment in wet grass,
where feasible.
4. Always be sure of your footing on slopes.
5. Walk, never run.
6. For wheeled rotary machines, mow across the
face of slopes, never up and down.
7. Exercise extreme caution when changing direction
on slopes.
8. Do not mow excessively steep slopes.
9. Use extreme caution when reversing or pulling the
lawnmower towards you.
10. Stop the blade(s) if the lawnmower has to be
tilted for transportation when crossing surfaces other
than grass, and when transporting the lawnmower to
and from the area to be mowed.
11. Never operate the lawnmower with defective
guards or shields, or without safety devices, for
example deflectors and/or grass catchers, in place.
12. Do not change the engine governor settings or
overspeed the engine.
13. Disengage all blade and drive clutches before
starting the engine.
14. Start the engine or switch on the motor carefully
according to instructions and with feet well away from
the blade(s).
15. Do not tilt the lawnmower when starting the
engine or switching on the motor, except if the
lawnmower has to be tilted for starting. In this case,
do not tilt it more than absolutely necessary and lift
only the part which is away from the operator.
16. Do not start the engine when standing in front of
the discharge chute.
17. Do not put hands or feet near or under rotating
parts. Keep clear of the discharge opening at all
times.
EThe Toro Company-1995
All Rights Reserved
TPS
SAFETY INSTRUCTIONS
18. Never pick up or carry a lawnmower while the
engine is running.
19. Stop the engine and disconnect the spark plug
wire.
D before clearing blockages or unclogging
chute;
D before checking, cleaning or working on the
lawnmower;
D after striking a foreign objects. Inspect the
lawnmower for damage and make repairs
before restarting and operating the
lawnmower;
D if lawnmower starts to vibrate abnormally
(check immediately).
20. Stop the engine
D whenever you leave the lawnmower;
D before refuelling.
21. Reduce the throttle setting during engine shut
down and, if the engine is provided with a shutoff
valve, turn the fuel off at the conclusion of mowing.
22. Go slow when using a trailing seat.
MAINTENANCE AND STORAGE
1. Keep all nuts, bolts and screws tight to be sure
the equipment is in safe working condition.
2. Never store the equipment with petrol in the tank
inside a building where fumes may reach an open
flame or spark.
3. Allow the engine to cool before storing in any
enclosure.
4. To reduce the fire hazard, keep the engine,
silencer, battery compartment and petrol storage area
free of grass, leaves, or excessive grease.
5. Check the grass catcher frequently for wear or
deterioration.
6. Replace worn or damaged parts for safety.
7. If the fuel tank has to be drained, this should be
done outdoors.
SOUND EMISSIONS
This unit has a maximum airborne noise emission,
based on measurement of identical machines.
VIBRATION LEVEL
Model 26630BC
This unit has a maximum vibration level of 4.65 m/s@,
based on measurement of identical machines.
Model 26635BC
This unit has a maximum vibration level of 1.73 m/s@,
based on measurement of identical machines.
UK2
SYMBOL GLOSSARY
Safety alert triangle––
symbol within triangle
indicates a hazard
Safety alert symbol
Read operator’s manual
Consult technical
manual for proper
service procedures
Stay a safe distance
from the machine
Do not open or
remove safety shields
while engine is running
Rotating blade can cut off
toes or fingers. Stay clear of
mower blade as long as
engine is running.
To avoid blade failure when
mulching, use blade stiffener
when mower is equipped
with mulching plug
Transmission
Stay a safe distance
from the mower
Thrown or flying objects––
Whole body exposure
Thrown or flying objects––
Rotary side-mounted mower.
Keep deflector shield in
place.
Stop engine before
leaving operator
position
Oil
On/Run
Engage
Disengage
Battery charging
condition
UK3
SYMBOL GLOSSARY
Hourmeter/elapsed
operating hours
Fast
Slow
Decreasing/increasing
Grease lubrication
point
Engine start
Fuel
Neutral
First gear
Second gear
Third gear
Cutting element––
basic symbol
Engine stop
Choke
Primer (start aid)
Push primer
three times
Cutting element––
Height adjustment
Pull rope
Wheel
Wheel traction
UK4
Properly dispose
of batteries
Insert key into
ignition switch
Turn key in ignition
switch
Move control
SYMBOL GLOSSARY
Lower control bar
Raise control bar
Raise/lower control bar
Move control forward
Move control rearward
Raise/lower control bar
Raise control bar
Raise control bar
Lower control bar
UK5
TABLE OF CONTENTS
Page Page
Set-Up Instructions 6. . . . . . . . . . . . . . . . . . . . . . . . . . .
Before Operating 8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Operating Instructions 9. . . . . . . . . . . . . . . . . . . . . . . . .
Maintenance 12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Servicing Air Cleaner 12. . . . . . . . . . . . . . . . . . . . . . .
Replacing Spark Plug 12. . . . . . . . . . . . . . . . . . . . . .
Draining Gasoline 12. . . . . . . . . . . . . . . . . . . . . . . . .
Changing Crankcase Oil 12. . . . . . . . . . . . . . . . . . .
Adjusting Throttle 13. . . . . . . . . . . . . . . . . . . . . . . . . .
Adjusting Traction Wheel Drive 13. . . . . . . . . . . . . .
Lubrication 15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Charging Battery 15. . . . . . . . . . . . . . . . . . . . . . . . . .
Replacing Fuse 16. . . . . . . . . . . . . . . . . . . . . . . . . . .
Cleaning Mower Housing 16. . . . . . . . . . . . . . . . . . .
Preparing Mower For Storage 16. . . . . . . . . . . . . . .
Optional Equipment 17. . . . . . . . . . . . . . . . . . . . . . . . . .
Product Identification 17. . . . . . . . . . . . . . . . . . . . . . . . .
Toro Service Support 17. . . . . . . . . . . . . . . . . . . . . . . . .
The Toro Starting Guarantee 18. . . . . . . . . . . . . . . . . . .
Guaranteed To Start Maintenance Record 19. . . . . . .
Inspecting/Removing/Sharpening Blade 14. . . . . .
SETUP INSTRUCTIONS
INSTALL HANDLE
1. INSTALLING HANDLELoosen knobs on
mounting brackets (Fig. 1).
2. Position mounting brackets in a vertical position so
that holes face up.
3. Slide handle ends into holes in mounting brackets
until handle ends are completely seated in brackets
(Fig. 1). Make sure throttle cable, electric start cable
(electric start model) and traction cable rest on top of
left mounting bracket (Fig. 2).
3
1
2
1
2
4
3
1. Handle
2. Mounting bracket
Figure 1
3. Knobs
4. Housing pocket
4. Rotate handle and brackets rearward until
brackets fit securely into housing pockets (Fig. 2).
792
793
Figure 2
1. Throttle cable
2. Traction cable
* 3. Electric start cable
* Electric start model
5. Tighten knobs until edges of slots on top of
mounting brackets touch.
6. Use cable tie to secure cable(s) to lower side of
left hand tube (Fig. 3). Cable tie should be positioned
25 mm (1") from bend in handle. See Figure 3 for
correct cable placement.
Note: Make sure cable(s) do not interfere with the
raising or lowering of discharge door.
UK6
