Toro 2610, 2611, 2615 Operator's Manual

HoverPro

ModelNo.02610—SerialNo.403230000andUp

ModelNo.02611—SerialNo.402000000andUp

®

450and550Machines

FormNo.3425-134RevA

Operator'sManual

Introduction

Readthisinformationcarefullytolearnhowtooperate
andmaintainyourproductproperlyandtoavoid
injuryandproductdamage.Youareresponsiblefor
operatingtheproductproperlyandsafely.

YoumaycontactT orodirectlyatwww.Toro.com
forproductsafetyandoperationtrainingmaterials,
accessoryinformation,helpndingadealer,orto
registeryourproduct.

Wheneveryouneedservice,genuineToroparts,or
additionalinformation,contactanAuthorizedService
DealerorToroCustomerServiceandhavethemodel
andserialnumbersofyourproductready .Figure1
identiesthelocationofthemodelandserialnumbers
ontheproduct.Writethenumbersinthespace
provided.

Thismanualidentiespotentialhazardsandhas
safetymessagesidentiedbythesafety-alertsymbol
(Figure2),whichsignalsahazardthatmaycause
seriousinjuryordeathifyoudonotfollowthe
recommendedprecautions.

g000502

Figure2

Safety-alertsymbol

Thismanualuses2wordstohighlightinformation.
Importantcallsattentiontospecialmechanical
informationandNoteemphasizesgeneralinformation
worthyofspecialattention.

ItisaviolationofCaliforniaPublicResourceCode
Section4442or4443touseoroperatetheengineon
anyforest-covered,brush-covered,orgrass-covered
landunlesstheengineisequippedwithaspark
arrester,asdenedinSection4442,maintainedin
effectiveworkingorderortheengineisconstructed,
equipped,andmaintainedforthepreventionofre.

1.Modelandserialnumberplate

ModelNo.

SerialNo.

©2018—TheT oro®Company
8111L yndaleAvenueSouth
Bloomington,MN55420

Figure1

Registeratwww.Toro.com.

Thismachinedoesnotcomeequippedwitha
sparkarresterstandard.Youmustinstallthe
sparkarresterkitbeforeoperatingthismachinein
California.

Theenclosedengineowner'smanualissupplied
forinformationregardingtheUSEnvironmental
ProtectionAgency(EPA)andtheCaliforniaEmission
ControlRegulationofemissionsystems,maintenance,
andwarranty.Replacementsmaybeorderedthrough
theenginemanufacturer.

g017365

Formodelswithstatedenginehorsepower,thegross
horsepoweroftheenginewaslaboratoryratedbythe
enginemanufacturerinaccordancewithSAEJ1349.
Asconguredtomeetsafety,emission,andoperating
requirements,theactualenginehorsepoweronthis
classmachinewillbesignicantlylower.

OriginalInstructions(EN)

PrintedintheUK

AllRightsReserved

*3425-134*A

WARNING

Safety

CALIFORNIA

Proposition65Warning

Theengineexhaustfromthisproduct

containschemicalsknowntotheStateof

Californiatocausecancer,birthdefects,

orotherreproductiveharm.

Useofthisproductmaycauseexposure

tochemicalsknowntotheStateof

Californiatocausecancer,birthdefects,

orotherreproductiveharm.

Contents

Introduction...............................................................1

Safety.......................................................................2

GeneralSafety...................................................2

SafetyandInstructionalDecals..........................3

Setup........................................................................4

1AssemblingtheHandle....................................4

2InstallingtheFootstop......................................6

3FillingtheEnginewithOil.................................6

ProductOverview.....................................................7

Specications....................................................8

Operation..................................................................8

BeforeOperation...................................................8

BeforeOperationSafety.....................................8

FillingtheFuelT ank............................................8

CheckingtheEngine-OilLevel............................9

AdjustingtheCuttingHeight.............................10

DuringOperation.................................................10

DuringOperatingSafety...................................10

StartingtheEngine............................................11

AdjustingtheChoke..........................................12

ShuttingOfftheEngine.....................................12

OperatingTips.................................................13

AfterOperation....................................................14

AfterOperatingSafety......................................14

CleaningtheMachine.......................................14

Maintenance...........................................................15

RecommendedMaintenanceSchedule(s)...........15

MaintenanceSafety..........................................15

PreparingforMaintenance...............................16

ServicingtheAirFilter.......................................16

ChangingtheEngineOil...................................17

ServicingtheSparkPlug...................................17

ReplacingtheBlade..........................................18

Storage...................................................................19

PreparingtheMachineforStorage...................19

Troubleshooting......................................................20

Thismachinehasbeendesignedinaccordancewith
ANSIB71.4-2012.

GeneralSafety

Thisproductiscapableofamputatinghandsand
feetandofthrowingobjects.Alwaysfollowallsafety
instructionstoavoidseriouspersonalinjury .

Usingthisproductforpurposesotherthanitsintended
usecouldprovedangeroustoyouandbystanders.

•Readandunderstandthecontentsofthis

Operator’sManualbeforestartingtheengine.

•Donotputyourhandsorfeetnearmoving

componentsofthemachine.

•Donotoperatethemachinewithoutallguards

andothersafetyprotectivedevicesinplaceand
workingonthemachine.

•Keepclearofanydischargeopening.Keep

bystandersasafedistanceawayfromthe
machine.

•Keepchildrenoutoftheoperatingarea.Never

allowchildrentooperatethemachine.

•Stopthemachineandshutofftheenginebefore

servicing,fueling,oruncloggingthemachine.

Improperlyusingormaintainingthismachinecan
resultininjury.T oreducethepotentialforinjury,
complywiththesesafetyinstructionsandalwayspay
attentiontothesafety-alertsymbol,whichmeans
Caution,Warning,orDanger—personalsafety
instruction.Failuretocomplywiththeseinstructions
mayresultinpersonalinjuryordeath.

Youcanndadditionalsafetyinformationwhere
neededthroughoutthismanual.

2

SafetyandInstructionalDecals

Safetyandinstructionaldecalsareeasilyvisibleandarelocatednearareasofpotential
danger.Replaceanydamagedormissingdecal.

130-8322

decal130-8322

1.Useonlyfuelwithan
alcoholcontentbyvolume
under10%.

2.ReadtheOperator's
Manualformore
informationonfuel.

3.Donotusefuelwithan
alcoholcontentbyvolume
greaterthan10%.

decal11 1-9826

111–9826

1.Cutting/dismemberment
hazardofhandorfoot,
cuttingunit—keepyour
handsandfeetawayfrom
movingparts.

2.ReadtheOperator’s
Manual.

decal11 1-5393

111-5393

1.Warning—Receivetrainingontheproduct;readthe

Operator’sManual.

2.Cutting/dismembermenthazardofhandorfoot,mowerblade;
disconnectthewirefromthesparkplugbeforeworkingonthe
machine;nevertmetalcuttingparts.

3.Warning—weareyeandhearingprotection.

4.Thrownobjecthazard;keepbystandersawayfromthe
machine.

5.Warning—donottouchhotsurfaces;keepguardsinplace;
Stayawayfrommovingparts;keepguardsinplace.

3

Setup

1

AssemblingtheHandle

94-8072

1.Warning—cutting/dismembermenthazardofhandorfoot,
cuttingmechanism.

H295159

1.Enginestop(shutoff)

133-8062

decal94-8072

NoPartsRequired

Procedure

1.Slide2bushingsintotheframe.

g017410

decal133-8062

Figure3

1.Lowerhandle4.Frame

2.Bushings5.Bolt

3.Nut6.Washers

2.Placethelowerhandlebetweenthebushings
andsecureitwith1handlebarbolt,2washers,
and1nut.

4

g017333

Note:Placethelowerhandlebetweenthe

bushingswiththekickstopassemblyattheright
side.

3.Repeatfortheoppositeside.

4.Aligntheholesontheupperhandlewiththe
lowerhandle.

g209280

Figure5

1.Nut2.Panscrew

Figure4

1.Upperhandle4.U-bolt

2.Handwheel5.Lowerhandle

3.Washer

5.FittheU-boltthroughtheupperandlower
handleandsecureitwithawasherandahand
wheel.

6.Attachthethrottleassemblytotheoutsideofthe
handlebarandsecureitwithanutandapan
screw.

g209291

5

2

3

InstallingtheFootstop

NoPartsRequired

Procedure

Securethefootstoptotheboltontherightsideofthe
lowerhandleusinganutand2washers(Figure6).

Note:Installthefootstopusingthelowerholeinthe

footstopasshowninFigure6.

FillingtheEnginewithOil

NoPartsRequired

Procedure

Important:Yourmachinedoesnotcomewithoil

intheengine.Beforestartingtheengine,llthe
enginewithoil.

EngineOilSpecications

Engineoilcapacity

OilviscositySAE10W-30multigrade

APIserviceclassicationSJorhigher

1.Movethemachinetoalevelsurface.

2.Removethedipstickbyrotatingthecap
counterclockwiseandpullingitout(Figure7).

0.59L(20oz)

mineraloil

Figure6

1.Footstop4.Bolt

2.Nut5.Lowerhandle

3.Washer

g027774

g017332

Figure7

1.Full3.Low

2.High

3.Carefullypourabout3/4oftheenginecapacity
ofoilintotheoil-lltube(Figure8).

6

Figure8

4.Wait3minutesfortheoiltosettleintheengine.

5.Wipethedipstickcleanwithacleancloth.

6.Insertthedipstickintotheoil-lltube,butdonot
screwitin,thenremovethedipstick.

7.Readtheoillevelonthedipstick(Figure7).

•Iftheoillevelonthedipstickistoolow,

carefullypourasmallamountofoilintothe
oil-lltube,wait3minutes,andrepeatsteps

5through7untiltheoilonthedipstickisat

thecorrectlevel.

ProductOverview

g017338

•Iftheoillevelonthedipstickistoohigh,drain

theexcessoiluntiltheoilonthedipstickis
atthecorrectlevel;refertoChangingthe

EngineOil(page17).

Important:Iftheoillevelintheengineistoo

lowortoohighandyouruntheengine,you
maydamagetheengine.

8.Installthedipstickandhandtightenitsecurely.

Important:Changetheengineoilafterthe

rst5operatinghours;changeityearly

thereafter.RefertoChangingtheEngineOil

(page17).

Figure9

1.Fuelcap6.Handlebarsecuringknob

2.Enginestart7.Enginecover

3.Throttlecontrol8.Exhaustguard

4.Operator-presencecontrol

5.Handlebar

1.Sparkplug

2.Exhaustguard7.Fingerguard

3.Exhaust8.Aircleaner

4.Dipstick

5.Startergrip

9.Dipstick

Figure10

6.Fuelcap

9.Carburetor

g017341

g017335

7

Specications

FuelSafety

Model

02610

02611

Cuttingwidth

46.5cm(18-1/2
inches)

53.5cm(21inches)63.5cm(25inches)

Productwidth

57.5cm(22-1/2
inches)

Operation

Note:Determinetheleftandrightsidesofthe

machinefromthenormaloperatingposition.

BeforeOperation

BeforeOperationSafety

GeneralSafety

•Becomefamiliarwiththesafeoperationofthe

equipment,operatorcontrols,andsafetysigns.

•Checkthatallguardsandsafetydevicesarein

placeandworkingproperly.

•Alwaysinspectthemachinetoensurethatthe

blades,bladebolts,andcuttingassemblyarenot
wornordamaged.

•Inspecttheareawhereyouwillusethemachine

andremoveallobjectsthatthemachinecould
throw.

•Adjustingthecuttingheightmaybringyouinto

contactwiththemovingblade,causingserious
injury.

–Shutofftheengineandwaitforallmoving

partstostop.

–Disconnectthespark-plugwirefromthespark

plugbeforeadjustingthecuttingheight.

DANGER

Fuelisextremelyammableandhighly
explosive.Areorexplosionfromfuel
canburnyouandothersandcandamage
property.

•Topreventastaticchargefromignitingthe
fuel,placethecontainerand/ormachine
directlyonthegroundbeforelling,notin
avehicleoronanobject.

•Fillthefueltankoutdoors,inanopenarea,
whentheengineiscold.Wipeupanyfuel
thatspills.

•Donothandlefuelwhensmokingor
aroundanopenameorsparks.

•Storefuelinanapprovedcontainerand
keepitoutofthereachofchildren.

WARNING

Fuelisharmfulorfatalifswallowed.
Long-termexposuretovaporscancause
seriousinjuryandillness.

•Avoidprolongedbreathingofvapors.

•Keepyourhandsandfaceawayfromthe
nozzleandthefuel-tankopening.

•Keepfuelawayfromyoureyesandskin.

FillingtheFuelTank

•Forbestresults,useonlyclean,fresh,unleaded

gasolinewithanoctaneratingof87orhigher
((R+M)/2ratingmethod).

•Oxygenatedfuelwithupto10%ethanolor15%

MTBEbyvolumeisacceptable.

•Donotuseethanolblendsofgasoline,such

asE15orE85,withmorethan10%ethanolby
volume.Performanceproblemsand/orengine
damagemayresult,whichmaynotbecovered
underwarranty.

•Donotusegasolinecontainingmethanol.

•Donotstorefueleitherinthefueltankorinfuel

containersoverthewinterunlessfuelstabilizer
hasbeenaddedtothefuel.

•Donotaddoiltogasoline.

Fillthefueltankwithfreshunleadedregulargasoline
fromamajorname-brandservicestation(Figure11).

Important:Toreducestartingproblems,addfuel

stabilizer/conditionertofreshfuelasdirectedby
thefuel-stabilizermanufacturer.

8

Refertoyourengineowner’smanualforadditional
information.

Figure11

•Iftheoillevelonthedipstickistoolow

(Figure12),carefullypourasmallamountof
multigrademineralSAE10W-30oilwithan
APIseriesclassicationofSJorhigherinto
theoil-lltube,wait3minutes,andrepeat
steps3through5untiltheoilonthedipstick
isatthecorrectlevel.

•Iftheoillevelonthedipstickistoohigh

(Figure12),draintheexcessoiluntiltheoil
onthedipstickisatthecorrectlevel;referto

ChangingtheEngineOil(page17).

Important:Iftheoillevelintheengineistoo

lowortoohighandyouruntheengine,you
maydamagetheengine.

6.Installthedipstickintotheoil-lltubesecurely.

Important:Changetheengineoilafterthe

rst5operatinghours;changeityearly

thereafter.RefertoChangingtheEngineOil

(page17).

g017340

CheckingtheEngine-Oil Level

1.Movethemachinetoalevelsurface.

2.Removethedipstickbyrotatingthecap
counterclockwiseandpullingitout(Figure12).

Figure12

1.Full3.Low

2.High

g017332

3.Wipethedipstickcleanwithacleancloth.

4.Insertthedipstickintotheoil-lltube,butdonot
screwitin,thenremovethedipstick.

5.Readtheoillevelonthedipstick(Figure12).

9

AdjustingtheCutting Height

WARNING

DuringOperation

DuringOperatingSafety

Adjustingthecuttingheightmaybringyou
intocontactwiththemovingblade,causing
seriousinjury.

•Shutofftheengineandwaitforallmoving
partstostop.

•Weargloveswhilehandlingthecutting
unit.

CAUTION

Iftheenginehasbeenrunning,themufer
willbehotandcanseverelyburnyou.

Keepawayfromthehotmufer.

Adjustthecuttingheightasdesired.

1.TurnthefuelswitchtotheOFFposition.

2.Disconnectthewirefromthesparkplug.

3.Tipthemachineonitssidewiththedipstick
down.

4.Wearingprotectivegloves,removetheblade
boltandcuttingunit.

5.Positionthespacerstothedesiredheight,then
installthecuttingunitasshowninFigure13.

GeneralSafety

•Wearappropriateclothing,includingeye

protection;longpants;substantial,slip-resistant
footwear;andhearingprotection.Tiebacklong
hairanddonotwearlooseclothingorloose
jewelry.

•Useyourfullattentionwhileoperatingthe

machine.Donotengageinanyactivitythat
causesdistractions;otherwise,injuryorproperty
damagemayoccur.

•Donotoperatethemachinewhileill,tired,or

undertheinuenceofalcoholordrugs.

•Thebladeissharp;contactingthebladecanresult

inseriouspersonalinjury.Shutofftheengine,and
waitforallmovingpartstostopbeforeleavingthe
operatingposition.

•Whenyoureleasetheoperator-presencecontrol,

theengineshouldshutoffandthebladeshould
stopwithin3seconds.Ifnot,stopusingyour
machineimmediatelyandcontactanAuthorized
ServiceDealer.

•Operatethemachineonlyingoodvisibilityand

appropriateweatherconditions.Donotoperate
themachinewhenthereistheriskoflighting.

•Wetgrassorleavescancauseseriousinjuryif

youslipandcontacttheblade.Avoidmowingin
wetconditionsifpossible.

Figure13

1.Cutterbar

2.Spacers

3.Bladeretainer

4.Bladebolt

5.Largespacer

Note:Thelargespacermustbedirectlybelow

theimpelleratalltimes.

6.Torquethebladeboltto25N∙m(18ft-lb).

•Usecarewhenapproachingblindcorners,shrubs,

trees,orotherobjectsthatmayblockyourview.

•Watchforholes,ruts,bumps,rocks,orother

hiddenobjects.Uneventerraincouldcausea
slip-and-fallaccident.

•Stopthemachineandinspectthebladesafter

strikinganobjectorifthereisanabnormal

g017336

vibrationinthemachine.Makeallnecessary
repairsbeforeresumingoperation.

•Beforeleavingtheoperatingposition,shutoffthe

engine,andwaitforallmovingpartstostop.

•Iftheenginehasbeenrunning,themuferwillbe

hotandcanseverelyburnyou.Keepawayfrom
thehotmufer.

•Useaccessoriesandattachmentsapprovedby

TheToro®Companyonly .

10

SlopeSafety

•Beforeoperatingonanyslope,completeasite

surveytodeterminetheactualslopewhereyou
willoperatethemachine.

•Avoidmowingonwetgrass.Poorfootingcould

causeaslip-and-fallaccident.

•Mowwithcautionneardrop-offs,ditches,or

embankments.

•Whenusingthemachine,alwayskeepbothhands

onthehandle.

•Whencuttingfromthetopofasteepslopeand

youneedlongerreach,useanapprovedextended
handleifyouneedalongerreach.

StartingtheEngine

1.Placethethrottlecontroltothechokeposition,
ensurethatthefuelswitchisintheONposition.

Figure15

1.Handle

2.Operator-presencecontrol

3.Placeyourfootonthedeckandtiltthemachine
towardyou(Figure16).

g017334

Figure14

2.Holdtheoperator-presencecontrolagainstthe
handle.

g017346

g017329

Figure16

4.Pulltherecoil-starthandle.

Note:Ifthemachinedoesnotstartafterseveral

attempts,contactanAuthorizedServiceDealer.

11

AdjustingtheChoke

ShuttingOfftheEngine

Usethethrottleassemblytoadjustthechoke(Figure

17).

ServiceInterval:Beforeeachuseordaily

Toshutofftheengine,releasetheoperator-presence
control(Figure18).

Important:Whenyoureleasethe

operator-presencecontrol,boththeengine
andbladeshouldstopwithin3seconds.Ifthey
donotstopproperly,stopusingyourmachine
immediatelyandcontactanAuthorizedService
Dealer.

Figure17

1.Chokeon2.Chokeoff

g017366

Figure18

g017367

12

OperatingTips

GeneralMowingTips

Important:Operatingthemachineonslopesof

morethan45°willcausesevereenginedamage
duetoalackoflubrication.Donotoperatethe
machineonslopesgreaterthan45°.

•Inspecttheareawhereyouwillusethemachine

andremoveallobjectsthatthemachinecould
throw.

•Avoidstrikingsolidobjectswiththeblade.Never

deliberatelymowoveranyobject.

•Ifthemachinestrikesanobjectorstartstovibrate,

immediatelyshutofftheengine,disconnect
thewirefromthesparkplug,andexaminethe
machinefordamage.

•Forbestperformance,installanewbladebefore

thecuttingseasonbegins.

•ReplacethebladewhennecessarywithaToro

replacementblade.

CuttingGrass

•Cutonlyaboutathirdofthegrassbladeata

time.Donotcutbelowthehighestsettingunless
thegrassissparseoritislatefallwhengrass
growthbeginstoslowdown.RefertoAdjusting

theCuttingHeight(page10).

•Mowinggrassover15cm(6inches)inlengthis

notrecommended.Ifthegrassistoolong,the
machinemayplugandcausetheenginetostall.

•Wetgrassandleavestendtoclumpontheyard

andcancausethemachinetoplugortheengine
tostall.Avoidmowinginwetconditions.

WARNING

Wetgrassorleavescancauseserious
injuryifyouslipandcontacttheblade.
Mowonlyindryconditions,ifpossible.

•Beawareofapotentialrehazardinverydry

conditions,followalllocalrewarnings,andkeep
themachinefreeofdrygrassandleafdebris.

•Ifthenishedlawnappearanceisunsatisfactory,

try1ormoreofthefollowing:

–Replacethebladeorhaveitsharpened.

–Walkataslowerpacewhilemowing.

–Raisethecuttingheightonyourmachine.

–Cutthegrassmorefrequently.

–Overlapcuttingswathsinsteadofcuttingafull

swathwitheachpass.

CuttingLeaves

•Aftercuttingthelawn,ensurethathalfofthelawn

showsthroughthecutleafcover.Y oumayneed
tomakemorethanasinglepassovertheleaves.

•Mowinggrassover15cm(6inches)inlengthis

notrecommended.Iftheleafcoveristoothick,the
machinemayplugandcausetheenginetostall.

•Slowdownyourmowingspeedifthemachine

doesnotcuttheleavesnelyenough.

13

AfterOperation

AfterOperatingSafety

GeneralSafety

•Cleangrassanddebrisfromthemachinetohelp

preventres.Cleanupoilorfuelspills.

•Allowtheenginetocoolbeforestoringthemachine

inanyenclosure.

•Neverstorethemachineorfuelcontainerwhere

thereisanopename,spark,orpilotlight,such
asonawaterheateroronotherappliances.

HaulingSafety

•Usecarewhenloadingorunloadingthemachine.

•Securethemachine.

•Usecarewhenloadingandunloadingthemachine

toavoidsharpedges.

CleaningtheMachine

ServiceInterval:Beforeeachuseordaily

Aftereachuse

WARNING

Themachinemaydislodgematerialfrom
underthemachinehousing.

•Weareyeprotection.

•Stayintheoperatingposition(behindthe
handle).

•Donotallowbystandersinthearea.

1.Tipthemachineonitssidewiththedipstick
down.

2.Useabrushorcompressedairtoremovegrass
anddebrisfromtheexhaustguard,thetopcowl,
andthesurroundingdeckareas.

14

Maintenance

RecommendedMaintenanceSchedule(s)

MaintenanceService

Interval

Beforeeachuseordaily

Aftereachuse

Beforestorage

Yearly

MaintenanceProcedure

•Ensurethattheengineshutsoffwithin3secondsafterreleasingthe
operator-presencecontrol.

•Cleangrassclippingsanddirtfromtheentiremachine.

•Cleangrassclippingsanddirtfromtheentiremachine.

•Emptythefueltankbeforerepairsasdirectedandbeforeannualstorage.

•Cleanthecoolingsystem;removegrassclippings,debris,ordirtfromtheengine
aircoolingnsandstarter.Cleanthesystemmorefrequentlyindirtyorhigh-chaff
conditions.

•Servicetheairlter;serviceitmorefrequentlyindustyoperatingconditions.

•Changetheengineoil.

•Servicethesparkplugandreplaceitifnecessary.

•Replacethebladeorhaveitsharpened(morefrequentlyiftheedgedullsquickly).

MaintenanceSafety

•Disconnectthespark-plugwirefromthesparkplug

beforeperforminganymaintenanceprocedure.

•Wearglovesandeyeprotectionwhenservicing

themachine.

•Thebladeissharp;contactingthebladecanresult

inseriouspersonalinjury .Weargloveswhen
servicingtheblade.

•Nevertamperwithsafetydevices.Checktheir

properoperationregularly .

•Tippingthemachinemaycausethefueltoleak.

Fuelisammableandexplosive,andcancause
personalinjury.Runtheenginedryorremovethe
fuelwithahandpump;neversiphonthefuel.

•Toensureoptimumperformanceandcontinued

safetycerticationofthemachine,useonly
genuineTororeplacementpartsandaccessories.
Replacementpartsandaccessoriesmadeby
othermanufacturerscouldbedangerous,and
suchusecouldvoidtheproductwarranty .

15

PreparingforMaintenance

WARNING

Tippingthemachinemaycausethefuelto
leak.Fuelisammable,explosiveandcan
causepersonalinjury.

Runtheenginedryorremovethefuelwitha
handpump;neversiphon.

1.Shutofftheengineandwaitforallmovingparts
tostop.

2.Disconnectthespark-plugwirefromthe
sparkplug(Figure19)beforeperformingany
maintenanceprocedure.

Important:Alwaystipthemachineontoits

side,withthedipstickdown.Ifthemachine
istippedinanotherdirection,oilmayllthe
valvetrain,requiringatleast30minutesto
drain.

ServicingtheAirFilter

ServiceInterval:Yearly

1.Pressdownonthelatchtabsontopofthe
air-ltercover(Figure20).

Figure20

1.Cover

2.Latchtabs

3.Filter

g017339

Figure19

1.Spark-plugwire

3.Afterperformingthemaintenanceprocedure(s),
connectthespark-plugwiretothesparkplug.

2.Openthecover.

3.Removetheair-lterelements(Figure20).

4.Inspecttheairlterandreplaceitifitisdamaged
orexcessivelydirty.

5.Inspectthepaperairlter.

A.Ifthelterisdamagedoriswetwithoilor

fuel,replaceit.

B.Ifthelterisdirty,tapitonahardsurface

severaltimesorblowcompressedairless
than207kPa(30psi)throughthesideof
thelterthatfacestheengine.

Note:Donotbrushthedirtoffthelter;

brushingforcesdirtintothebers.

g017342

6.Removedirtfromtheair-lterbodyandcover
usingamoistrag.

Important:Donotwipedirtintotheairduct.

7.Inserttheair-lterelementsintotheair-lter
body.

8.Installthecover.

16

ChangingtheEngineOil

ServiceInterval:Yearly

oil-lltube,wait3minutes,andrepeatsteps

8through10untiltheoillevelonthedipstick

iscorrect.

Note:Runtheengineafewminutesbeforechanging

theoiltowarmit.Warmoilowsbetterandcarries
morecontaminants.

EngineOilSpecications

Engineoilcapacity

OilviscositySAE10W-30multigrade

APIserviceclassicationSJorhigher

1.Ensurethatthefueltankcontainslittleornofuel
sothatthefueldoesnotleakwhenyoutipthe
engineontoitsside.

2.RefertoCheckingtheEngine-OilLevel(page9).

3.Removethedipstickbyrotatingthecap
counterclockwiseandpullingitout(Figure21).

0.59L(20oz)

mineraloil

•Iftheoillevelonthedipstickistoohigh,

draintheexcessoiluntiltheoillevelonthe
dipstickiscorrect.

Important:Iftheoillevelintheengineistoo

lowortoohighandyouruntheengine,you
maydamagetheengine.

11.Installthedipstickintotheoil-lltubesecurely.

12.Recycletheusedoilproperly.

ServicingtheSparkPlug

ServiceInterval:Yearly—Servicethesparkplugand

replaceitifnecessary.

UseaTorosparkplug;contactanAuthorizedService
Dealer.

1.Shutofftheengineandwaitforallmovingparts
tostop.

2.Disconnectthewirefromthesparkplug(Figure

19).

3.Cleanaroundthesparkplug.

Figure21

1.Full3.Low

2.High

4.Tipthemachineontoitsside(sothattheairlter
isup)todraintheusedoilfromtheoil-lltube.

5.Afterdrainingtheusedoil,returnthemachineto
theoperatingposition.

6.Carefullypourabout3/4oftheenginecapacity
ofoilintotheoil-lltube.

7.Wait3minutesfortheoiltosettleintheengine.

8.Wipethedipstickcleanwithacleancloth.

9.Insertthedipstickintotheoil-lltube,butdonot
screwitin,thenremovethedipstick.

10.Readtheoillevelonthedipstick(Figure21).

4.Removethesparkplugfromthecylinderhead.

Important:Replaceacracked,fouled,or

dirtysparkplug.Donotcleantheelectrodes
becausegritenteringthecylindercan
damagetheengine.

5.Setthegapontheplugto0.76mm(0.030inch)

g017332

asshowninFigure22.

g000533

Figure22

1.Center-electrodeinsulator3.Airgap(nottoscale)

2.Sideelectrode

6.Installthesparkplug.

7.Torquetheplugto27to30N∙m(20to22ft-lb).

8.Connectthewiretothesparkplug.

•Iftheoillevelonthedipstickistoolow,

carefullypourasmallamountofoilintothe

17

ReplacingtheBlade

ServiceInterval:Yearly

Important:Youwillneedatorquewrenchto

installthebladeproperly.Ifyoudonothavea

torquewrenchorareuncomfortableperforming
thisprocedure,contactanAuthorizedService
Dealer.

Examinethebladewheneveryourunoutoffuel.Ifthe
bladeisdamagedorcracked,replaceitimmediately.
Ifthebladeedgeisdullornicked,haveitsharpened
andbalanced,orreplaceit.

WARNING

Thebladeissharp;contactingthebladecan
resultinseriouspersonalinjury.

•Disconnectthewirefromthesparkplug.

•Weargloveswhenservicingtheblade.

1.RefertoPreparingforMaintenance(page16).

2.Tipthemachineontoitsside,withthedipstick
down.

theratchetorwrenchandtightenthe
boltsecurely.Thisboltisverydifcultto
overtighten.

3.Useablockofwoodtoholdthebladesteady.

Figure23

4.Removetheblade(turnthebladebolt
counterclockwise),savingallthemounting
hardware.

5.Installthenewblade(turnthebladebolt
clockwise)andallmountinghardware.

g209201

Important:Positionthecurvedendsofthe

bladetopointtowardthemachinehousing.

6.Useatorquewrenchtotightenthebladebolt
to25N∙m(18ft-lb).

Important:Whileholdingthebladewith

ablockofwood,putyourweightbehind

18

Storage

Storethemachineinacool,clean,dryplace.

PreparingtheMachinefor Storage

WARNING

Fuelvaporscanexplode.

•Donotstorefuelmorethan30days.

•Donotstorethemachineinanenclosure
nearanopename.

•Allowtheenginetocoolbeforestoringit.

1.Onthelastrefuelingoftheyear,addfuel
stabilizertothefuelasdirectedbytheengine
manufacturer.

2.Runthemachineuntiltheengineshutsofffrom
runningoutoffuel.

3.Primetheengineandstartitagain.

4.Allowtheenginetorununtilitshutsoff.
Whenyoucannolongerstarttheengine,itis
sufcientlydry.

5.Disconnectthewirefromthesparkplug.

6.Removethesparkplug,add30ml(1oz)of
oilthroughthespark-plughole,andpullthe
starterropeslowlyseveraltimestodistribute
oilthroughoutthecylindertopreventcylinder
corrosionduringtheoff-season.

7.Installthesparkplugandtightenitwithatorque
wrenchto20N∙m(15ft-lb).

8.Tightenallnuts,bolts,andscrews.

19

Troubleshooting

Problem

Theenginedoesnotstart.

Theenginestartshardorlosespower.

PossibleCauseCorrectiveAction

1.Thewireisnotconnectedtothespark
plug.

2.Theholeinthefuel-capventis
plugged.

3.Thesparkplugispitted,fouled,orthe
gapisincorrect.

4.Thefueltankisemptyorthefuel
systemcontainsstalefuel.

1.Theholeinthefuel-capventis
plugged.

2.Theairlterelementisdirtyandis
restrictingtheairow.

3.Theundersideofthemachinehousing
containsclippingsanddebris.

4.Thesparkplugispitted,fouled,orthe
gapisincorrect.

5.Theengineoil-levelistoolow,too
high,orexcessivelydirty.

6.Thefueltankcontainsstalefuel.

1.Connectthewiretothesparkplug.

2.Cleantheholeinthefuel-capventor
replacethefuelcap.

3.Checkthesparkplugandadjustthe
gapifnecessary .Replacethespark
plugifitispitted,fouled,orcracked.

4.Drainand/orllthefueltankwithfresh
fuel.Iftheproblempersists,contactan
AuthorizedServiceDealer.

1.Cleantheholeinthefuel-capventor
replacethefuelcap.

2.Cleantheairlterpre-cleanerand/or
replacethepaperairlter.

3.Cleanunderthemachinehousing.

4.Checkthesparkplugandadjustthe
gapifnecessary .Replacethespark
plugifitispitted,fouled,orcracked.

5.Checktheengineoil.Changetheoilif
itisdirty;addordraintheoiltoadjust
theoilleveltotheFullmarkonthe
dipstick.

6.Drainandllthefueltankwithfresh
fuel.

Theenginerunsrough.

Themachineorenginevibrates
excessively.

Thereisanunevencuttingpattern.

1.Thewireisnotconnectedtothespark
plug.

2.Thesparkplugispitted,fouled,orthe
gapisincorrect.

3.Theairlterelementisdirtyandis
restrictingtheairow.

1.Theundersideofthemachinehousing
containsclippingsanddebris.

2.Theenginemountingboltsareloose.2.Tightentheenginemountingbolts.

3.Theblademountingboltloose.3.Tightentheblademountingbolt.

4.Thebladeisbentorisoutofbalance.

1.Youaremowinginthesamepattern
repeatedly.

2.Theundersideofthemachinehousing
containsclippingsanddebris.

3.Thebladeisdull.

1.Connectthewiretothesparkplug.

2.Checkthesparkplugandadjustthe
gapifnecessary .Replacethespark
plugifitispitted,fouled,orcracked.

3.Cleantheairlterpre-cleanerand/or
replacethepaperairlter.

1.Cleanunderthemachinehousing.

4.Balancetheblade.Ifthebladeisbent,
replaceit.

1.Changethemowingpattern.

2.Cleanunderthemachinehousing.

3.Sharpenandbalancetheblade.

20

Notes:

Notes:

CaliforniaProposition65WarningInformation

Whatisthiswarning?

Youmayseeaproductforsalethathasawarninglabellikethefollowing:

WARNING:CancerandReproductiveHarm—www.p65Warnings.ca.gov.

WhatisProp65?

Prop65appliestoanycompanyoperatinginCalifornia,sellingproductsinCalifornia,ormanufacturingproductsthatmaybesoldinorbroughtinto
California.ItmandatesthattheGovernorofCaliforniamaintainandpublishalistofchemicalsknowntocausecancer,birthdefects,and/orother
reproductiveharm.Thelist,whichisupdatedannually,includeshundredsofchemicalsfoundinmanyeverydayitems.ThepurposeofProp65isto
informthepublicaboutexposuretothesechemicals.

Prop65doesnotbanthesaleofproductscontainingthesechemicalsbutinsteadrequireswarningsonanyproduct,productpackaging,orliteraturewith
theproduct.Moreover ,aProp65warningdoesnotmeanthataproductisinviolationofanyproductsafetystandardsorrequirements.Infact,the
CaliforniagovernmenthasclariedthataProp65warning“isnotthesameasaregulatorydecisionthataproductis‘safe’or‘unsafe.’”Manyofthese
chemicalshavebeenusedineverydayproductsforyearswithoutdocumentedharm.Formoreinformation,gotohttps://oag.ca.gov/prop65/faqs-view-all

AProp65warningmeansthatacompanyhaseither(1)evaluatedtheexposureandhasconcludedthatitexceedsthe“nosignicantrisklevel”;or(2)
haschosentoprovideawarningbasedonitsunderstandingaboutthepresenceofalistedchemicalwithoutattemptingtoevaluatetheexposure.

Doesthislawapplyeverywhere?

Prop65warningsarerequiredunderCalifornialawonly.ThesewarningsareseenthroughoutCaliforniainawiderangeofsettings,includingbutnot
limitedtorestaurants,grocerystores,hotels,schools,andhospitals,andonawidevarietyofproducts.Additionally ,someonlineandmailorder
retailersprovideProp65warningsontheirwebsitesorincatalogs.

.

HowdotheCaliforniawarningscomparetofederallimits?

Prop65standardsareoftenmorestringentthanfederalandinternationalstandards.TherearevarioussubstancesthatrequireaProp65warning
atlevelsthatarefarlowerthanfederalactionlimits.Forexample,theProp65standardforwarningsforleadis0.5μg/day,whichiswellbelow
thefederalandinternationalstandards.

Whydon’tallsimilarproductscarrythewarning?

•ProductssoldinCaliforniarequireProp65labellingwhilesimilarproductssoldelsewheredonot.

•AcompanyinvolvedinaProp65lawsuitreachingasettlementmayberequiredtouseProp65warningsforitsproducts,butothercompanies

makingsimilarproductsmayhavenosuchrequirement.

•TheenforcementofProp65isinconsistent.

•CompaniesmayelectnottoprovidewarningsbecausetheyconcludethattheyarenotrequiredtodosounderProp65;alackofwarningsfora

productdoesnotmeanthattheproductisfreeoflistedchemicalsatsimilarlevels.

WhydoesToroincludethiswarning?

Torohaschosentoprovideconsumerswithasmuchinformationaspossiblesothattheycanmakeinformeddecisionsabouttheproductstheybuyand
use.Toroprovideswarningsincertaincasesbasedonitsknowledgeofthepresenceofoneormorelistedchemicalswithoutevaluatingthelevelof
exposure,asnotallthelistedchemicalsprovideexposurelimitrequirements.WhiletheexposurefromT oroproductsmaybenegligibleorwellwithinthe
“nosignicantrisk”range,outofanabundanceofcaution,T orohaselectedtoprovidetheProp65warnings.Moreover,ifT orodoesnotprovidethese
warnings,itcouldbesuedbytheStateofCaliforniaorbyprivatepartiesseekingtoenforceProp65andsubjecttosubstantialpenalties.

RevA

TheToroWarranty

ATwo-YearLimitedWarranty

ConditionsandProductsCovered

TheT oroCompanyanditsafliate,T oroWarrantyCompany,pursuant
toanagreementbetweenthem,jointlywarrantyourT oroCommercial
product(“Product”)tobefreefromdefectsinmaterialsorworkmanship
fortwoyearsor1500operationalhours*,whicheveroccursrst.This
warrantyisapplicabletoallproductswiththeexceptionofAerators
(refertoseparatewarrantystatementsfortheseproducts).Wherea
warrantableconditionexists,wewillrepairtheProductatnocosttoyou
includingdiagnostics,labor,parts,andtransportation.Thiswarranty
beginsonthedatetheProductisdeliveredtotheoriginalretailpurchaser.
*Productequippedwithanhourmeter.

InstructionsforObtainingWarrantyService

YouareresponsiblefornotifyingtheCommercialProductsDistributoror
AuthorizedCommercialProductsDealerfromwhomyoupurchasedthe
Productassoonasyoubelieveawarrantableconditionexists.Ifyouneed
helplocatingaCommercialProductsDistributororAuthorizedDealer,or
ifyouhavequestionsregardingyourwarrantyrightsorresponsibilities,
youmaycontactusat:

ToroCommercialProductsServiceDepartment
ToroWarrantyCompany
811 1LyndaleAvenueSouth
Bloomington,MN55420-1196

952–888–8801or800–952–2740
E-mail:[e-mail]

OwnerResponsibilities

AstheProductowner ,youareresponsibleforrequiredmaintenanceand
adjustmentsstatedinyourOperator'sManual.Failuretoperformrequired
maintenanceandadjustmentscanbegroundsfordisallowingawarranty
claim.

ItemsandConditionsNotCovered

Notallproductfailuresormalfunctionsthatoccurduringthewarranty
periodaredefectsinmaterialsorworkmanship.Thiswarrantydoesnot
coverthefollowing:

•Productfailureswhichresultfromtheuseofnon-T ororeplacement

parts,orfrominstallationanduseofadd-on,ormodiednon-T oro
brandedaccessoriesandproducts.Aseparatewarrantymaybe
providedbythemanufactureroftheseitems.

•Productfailureswhichresultfromfailuretoperformrecommended

maintenanceand/oradjustments.Failuretoproperlymaintainyour
ToroproductpertheRecommendedMaintenancelistedinthe
Operator’sManualcanresultinclaimsforwarrantybeingdenied.

•ProductfailureswhichresultfromoperatingtheProductinanabusive,

negligent,orrecklessmanner.

•Partssubjecttoconsumptionthroughuseunlessfoundtobedefective.

Examplesofpartswhichareconsumed,orusedup,duringnormal
Productoperationinclude,butarenotlimitedto,brakepadsand
linings,clutchlinings,blades,reels,rollersandbearings(sealedor
greasable),bedknives,sparkplugs,castorwheelsandbearings,tires,
lters,belts,andcertainsprayercomponentssuchasdiaphragms,
nozzles,andcheckvalves,etc.

•Failurescausedbyoutsideinuence.Conditionsconsideredtobe

outsideinuenceinclude,butarenotlimitedto,weather,storage
practices,contamination,useofunapprovedfuels,coolants,lubricants,
additives,fertilizers,water,orchemicals,etc.

•Failureorperformanceissuesduetotheuseoffuels(e.g.gasoline,

diesel,orbiodiesel)thatdonotconformtotheirrespectiveindustry
standards.

•Normalnoise,vibration,wearandtear,anddeterioration.

•Normal“wearandtear”includes,butisnotlimitedto,damagetoseats

duetowearorabrasion,wornpaintedsurfaces,scratcheddecalsor
windows,etc.

Parts

Partsscheduledforreplacementasrequiredmaintenancearewarranted
fortheperiodoftimeuptothescheduledreplacementtimeforthatpart.
Partsreplacedunderthiswarrantyarecoveredforthedurationofthe
originalproductwarrantyandbecomethepropertyofT oro.T orowillmake
thenaldecisionwhethertorepairanyexistingpartorassemblyorreplace
it.Toromayuseremanufacturedpartsforwarrantyrepairs.

DeepCycleandLithium-IonBatteryWarranty:

DeepcycleandLithium-Ionbatterieshaveaspeciedtotalnumberof
kilowatt-hourstheycandeliverduringtheirlifetime.Operating,recharging,
andmaintenancetechniquescanextendorreducetotalbatterylife.Asthe
batteriesinthisproductareconsumed,theamountofusefulworkbetween
chargingintervalswillslowlydecreaseuntilthebatteryiscompletelyworn
out.Replacementofwornoutbatteries,duetonormalconsumption,
istheresponsibilityoftheproductowner.Batteryreplacementmaybe
requiredduringthenormalproductwarrantyperiodatowner’sexpense.
Note:(Lithium-Ionbatteryonly):ALithium-Ionbatteryhasapartonly
proratedwarrantybeginningyear3throughyear5basedonthetime
inserviceandkilowatthoursused.RefertotheOperator'sManualfor
additionalinformation.

MaintenanceisatOwner’sExpense

Enginetune-up,lubrication,cleaningandpolishing,replacementoflters,
coolant,andcompletingrecommendedmaintenancearesomeofthe
normalservicesToroproductsrequirethatareattheowner’sexpense.

GeneralConditions

RepairbyanAuthorizedToroDistributororDealerisyoursoleremedy
underthiswarranty.

NeitherTheT oroCompanynorToroWarrantyCompanyisliablefor
indirect,incidentalorconsequentialdamagesinconnectionwiththe
useoftheToroProductscoveredbythiswarranty,includingany
costorexpenseofprovidingsubstituteequipmentorserviceduring
reasonableperiodsofmalfunctionornon-usependingcompletion
ofrepairsunderthiswarranty.ExceptfortheEmissionswarranty
referencedbelow,ifapplicable,thereisnootherexpresswarranty .All
impliedwarrantiesofmerchantabilityandtnessforusearelimitedto
thedurationofthisexpresswarranty.

Somestatesdonotallowexclusionsofincidentalorconsequential
damages,orlimitationsonhowlonganimpliedwarrantylasts,sotheabove
exclusionsandlimitationsmaynotapplytoyou.Thiswarrantygivesyou
speciclegalrights,andyoumayalsohaveotherrightswhichvaryfrom
statetostate.

Noteregardingenginewarranty:

TheEmissionsControlSystemonyourProductmaybecoveredby
aseparatewarrantymeetingrequirementsestablishedbytheU.S.
EnvironmentalProtectionAgency(EP A)and/ortheCaliforniaAirResources
Board(CARB).Thehourlimitationssetforthabovedonotapplytothe
EmissionsControlSystemWarranty.RefertotheEngineEmissionControl
WarrantyStatementsuppliedwithyourproductorcontainedintheengine
manufacturer’sdocumentationfordetails

CountriesOtherthantheUnitedStatesorCanada

CustomerswhohavepurchasedT oroproductsexportedfromtheUnitedStatesorCanadashouldcontacttheirT oroDistributor(Dealer)toobtain
guaranteepoliciesforyourcountry ,province,orstate.IfforanyreasonyouaredissatisedwithyourDistributor'sserviceorhavedifcultyobtaining
guaranteeinformation,contacttheT oroimporter.

374-0253RevD
