Toro 22470, 22471 Parts Catalogue
Trencher Head
Compact Utility Loaders
Model No. 22470 - 250000001 and up.
Form Number 3358-538 Rev A
Model No.
22471 - 250000001 and up.
Parts Catalog
Ordering Replacement Parts
To order replacement parts, please supply the part
number, the quantity, and the description of each part
desired.
Understanding Reference Numbers
Each Identified part in an illustration has a reference
number. The reference number for a part also
appears in the parts list, along with other information
about the part.
This catalog uses two special reference number
formats, one to indicate parts in a service assembly
and another to indicate the quantity of a given part in
an illustration.
Service Assembly Reference Numbers
Parts in service assemblies have reference numbers
in the form a:b. The a represents the reference
number of the entire service assembly and the b
represents a sequential number unique to each part
within the service assembly.
For example, a wheel assembly might be identified
by reference number 6, the tire by 6:1, the valve by
6:2, and the wheel by 6:3. When you order the
assembly identified by reference number 6, you
receive all parts identified by reference numbers 6:1,
6:2, and 6:3. However, you may also order any part
individually. Reference numbers of this type appear
in illustrations and in part lists.
Reference Numbers Indicating Quantity
In an illustration, if a reference number indicates
more than one part, the reference number has the
form nX y. The n represents the quantity of the part,
the X is the multiplication symbol, and the y
represents the reference number.
For example, in an illustration, the reference number
2X 37 means that two of the parts identified by
reference number 37 are indicated.
Register your product at www.Toro.com
© The Toro Company - 2007
All Rights Reserved
Contents
Description Page
. . . . . . 3Trencher Assembly
. . . . . . 4Boom Assembly No. 104-1949
Description Page
High Speed Hydraulic Motor Assembly No.
104-5701
High Torque Hydraulic Motor Assembly No.
107-9350
Part Description Abbreviations
Part descriptions in this catalog may include the following abbreviations.
AR. . . . . . . . . . . . . . .as required
ASM. . . . . . . . . . . . . assembly
BBC. . . . . . . . . . . . . blade brake clutch
CARR. . . . . . . . . . . . carriage
DEG. . . . . . . . . . . . . degrees
EXT. . . . . . . . . . . . . .external
FH. . . . . . . . . . . . . . .flat head
GA. . . . . . . . . . . . . . .gauge
HD. . . . . . . . . . . . . . .heavy-duty
HF. . . . . . . . . . . . . . . hex flange
HH. . . . . . . . . . . . . . .hex head
HHF. . . . . . . . . . . . . hex head flange
HHFTF. . . . . . . . . . . hex head flange thread forming
HJ. . . . . . . . . . . . . . . hex jam
HLH. . . . . . . . . . . . . .hex lag head
HOC. . . . . . . . . . . . . height-of-cut
HSBH. . . . . . . . . . . . hex socket button head
HSFH. . . . . . . . . . . . hex socket flat head
HSH. . . . . . . . . . . . . hex socket head
HWH. . . . . . . . . . . . . hex washer head
HWHTF. . . . . . . . . . .hex washer head thread
forming
HYD. . . . . . . . . . . . . hydraulic
LH. . . . . . . . . . . . . . . left hand
NI. . . . . . . . . . . . . . . nylon insert
NPTF. . . . . . . . . . . . national pipe thread fine
PFH. . . . . . . . . . . . . .phillips flat head
PPH. . . . . . . . . . . . . phillips pan head
PPHTF. . . . . . . . . . . phillips pan head thread
PRH. . . . . . . . . . . . . phillips round head
PTH. . . . . . . . . . . . . .phillips truss head
PTO. . . . . . . . . . . . . power-take-off
RH. . . . . . . . . . . . . . .right hand
ROPS. . . . . . . . . . . . roll-over protection system
SFH. . . . . . . . . . . . . .slotted fillister head
SHH. . . . . . . . . . . . . slotted hex head
SHWH. . . . . . . . . . . .slotted hex washer head
SPH. . . . . . . . . . . . . slotted pan head
SQH. . . . . . . . . . . . . square head
SRH. . . . . . . . . . . . . slotted round head
STD. . . . . . . . . . . . . .standard
TAP. . . . . . . . . . . . . .self tapping
TTH. . . . . . . . . . . . . .torx truss head
. . . . . . 5
. . . . . . 6
. . . . . . 7Attachments and Accessories List
forming
Footnotes
n
Not illustrated
2
3358-538 Rev A
Ref Part No. Qty. Description
Coupler-Face, Flush1
104-6134
100-4701
n
100-6120
104-5877
104-5895
3256-27
104-1938
99-9952
99-9953
104-5894-03
32128-50
3296-23
104-5912-03
325-35
3274-4
104-1964
104-1969
104-1967
104-1966
104-1965
353-990
237-78
104-1931-03
104-1972
1
Nipple-Connect, Pressure2
1
Seal Kit2:1
1
Screw-HH3
2
Screw-HH4
3
Washer-Flat6
5
Mount ASM7
1
Decal-Danger7:2
1
Decal-Danger7:3
1
Crossbar ASM8
1
Nut-Flange9
5
Nut-Lock, NI10
1
Auger ASM11
1
Screw-HH12
1
Screw-HSH13
6
Sprocket-Trencher14
1
Shaft-Trencher15
1
Seal-Shaft16
1
Cone-Bearing17
2
Cup-Bearing18
2
Plug19
1
O-Ring19:1
1
Mount-Boom20
1
Washer-Tongued21
1
Trencher Assembly
Ref Part No. Qty. Description
104-5915
104-1973
104-1920
3253-7
325-8
27
27
104-5701
107-9350
104-5870
340-7
237-65
237-80
104-1932
237-80
104-5935
104-1939
99-9952
104-1949
98-3206
1
Lockwasher-Bearing22
Locknut-Bearing23
1
O-Ring24
1
Washer-Lock25
4
Screw-HH26
4
Motor-HYD, High Speed (Only
1
On: 22471)
Motor-HYD, High Torque (Only
1
On: 22470)
Screw28
6
Adapter29
2
O-Ring29:1
1
O-Ring29:2
1
Hose ASM30
2
O-Ring30:5
1
Spacer33
1
Safety Rail ASM35
1
Decal-Danger35:2
2
Boom ASM36
1
Decal37
2
3
