Leveler
for Compact Utility Loaders
Model No. 22419 – 890001 and Up
Form No. 3353-817 Rev A
Operator’s Manual
Register your product at www.Toro.com
Original Instructions (EN)
Contents
Introduction 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Safety 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Safety Decal 3. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Specifications 4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Stability Ratings 4. . . . . . . . . . . . . . . . . . . . . . . . . .
Installation 6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Operation 6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Leveler Operation 6. . . . . . . . . . . . . . . . . . . . . . . .
Operating Tips 6. . . . . . . . . . . . . . . . . . . . . . . . . . .
Maintenance 6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Storage 6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Introduction
Page
Two other words are also used to highlight information.
“Important” calls attention to special mechanical
information and “Note” emphasizes general information
worthy of special attention.
The left and right side of the machine is determined by
sitting on the seat in the normal operator’s position.
Safety
Improper use or maintenance by the operator or owner
can result in injury. To reduce the potential for injury,
comply with these safety instructions and those in the
traction unit operator’s manual. Always pay attention
to the safety alert symbol, which means CAUTION,
WARNING, or DANGER—“personal safety
instruction.” Failure to comply with the instruction
may result in personal injury or death.
We want you to be completely satisfied with your new
product, so feel free to contact your local Authorized
Service Dealer for help with service, genuine replacement
parts, or other information you may require.
Whenever you contact your Authorized Service Dealer or
the factory, always know the model and serial numbers of
your product. These numbers will help the Service Dealer
or Service Representative provide exact information about
your specific product. You will find the model and serial
number on a plate located to the left on the back of the
leveler. For your convenience, write the product model
and serial numbers in the space below.
Model No:
Serial No.
The warning system in this manual identifies potential
hazards and has special safety messages that help you and
others avoid personal injury, even death. DANGER,
WARNING and CAUTION are signal words used to
identify the level of hazard. However, regardless of the
hazard, be extremely careful.
DANGER
POTENTIAL HAZARD
• There may be buried power, gas, and/or
telephone lines in the work area.
WHAT CAN HAPPEN
• Shock or explosion may occur.
HOW TO AVOID THE HAZARD
• Have the property or work area marked for
buried lines and don’t dig in marked areas.
DANGER
POTENTIAL HAZARD
• There may be overhead power lines in the area.
WHAT CAN HAPPEN
• Shock may occur if a power line is touched by a
tree or other object that is being transported.
HOW TO AVOID THE HAZARD
• Survey and mark the area where there are
overhead power lines, and do not transport
trees or tall objects under the power lines.
DANGER signals an extreme hazard that will cause
serious injury or death if the recommended precautions
are not followed.
WARNING signals a hazard that may cause serious injury
or death if the recommended precautions are not followed.
CAUTION signals a hazard that may cause minor or
moderate injury if the recommended precautions are not
followed.
W 2005 by The Toro Company
8111 Lyndale Avenue South
Bloomington, MN 55420-1196
Contact us at www.Toro.com
All Rights Reserved
2
Printed in the USA
WARNING
CAUTION
POTENTIAL HAZARD
• When the engine is off, attachments in the
raised position can gradually lower.
WHAT CAN HAPPEN
• Someone nearby may be pinned or injured by
the attachment as it lowers.
HOW TO AVOID THE HAZARD
• Always lower the attachment lift each time you
shut off the traction unit.
WARNING
POTENTIAL HAZARD
• When going up or down hill, the machine could
overturn if the heavy end is toward the
downhill side.
WHAT CAN HAPPEN
• Someone may be pinned or seriously injured by
the machine if it overturns.
HOW TO AVOID THE HAZARD
• Operate up and down slopes with the heavy end
of the machine uphill. An empty leveler will
make the rear end heavy and a loaded leveler
will make the front end heavy.
POTENTIAL HAZARD
• If the leveler is not kept level while lifting, the
load could be inadvertently dumped on the
operator.
WHAT CAN HAPPEN
• The operator could be injured when the load is
dumped.
HOW TO AVOID THE HAZARD
• When lifting the leveler, tilt it forward to keep
it level and prevent it from spilling backwards.
Safety Decal
1
1. Machine rollover–
exceeding rated load
capacity can cause
instability
# 99–9936
Figure 1
2. Read operator’s manual
3. Maximum load capacity
2
3
WARNING
POTENTIAL HAZARD
• Standing on or riding on the leveler can be
dangerous.
WHAT CAN HAPPEN
• The rider may fall or be injured by the moving
machine.
HOW TO AVOID THE HAZARD
• Do not allow anyone to stand on the leveler or
to ride it in any way.
CAUTION
POTENTIAL HAZARD
• If you step off of the platform with the load
raised, the machine could tip forward.
WHAT CAN HAPPEN
• Someone nearby may be pinned or injured.
HOW TO AVOID THE HAZARD
• Lower the leveler before stepping off of the
platform.
3
Specifications
Note: Specifications and design are subject to change without notice.
Overall width
Overall length 36.0 inches (91 cm)
Overall height 16.0 inches (41 cm)
Weight 170 lbs (77 Kg)
49.0 inches (124 cm)
Stability Ratings
To determine the degree of slope you can traverse with the
leveler installed on a traction unit, find the stability rating
for the hill position you want to travel in the appropriate
table on the following page, then find the degree of slope
for the same rating and hill position in the Stability Data
section of the traction unit operator’s manual.
The leveler may be used when loaded or unloaded and
with or without the counterweight on the traction unit.
The following tables reflect the differences in stability of
these various conditions.
POTENTIAL HAZARD
• Exceeding the maximum slope can cause the
traction unit to tip.
WHAT CAN HAPPEN
• If the traction unit tips, you or bystanders could
be crushed.
HOW TO AVOID THE HAZARD
• Do not drive the the traction unit on a slope
steeper that the maximum slope.
WARNING
4
Stability With a Loaded Leveler Without
the Counterweight
Stability With a Loaded Leveler With the
Counterweight
Orientation Stability Rating
Front Uphill
B
Rear Uphill
C
Side Uphill
B
Stability With an Unloaded Leveler
Without the Counterweight
Orientation Stability Rating
Front Uphill
Orientation Stability Rating
Front Uphill
C
Rear Uphill
C
Side Uphill
B
Stability With an Unloaded Leveler With
the Counterweight
Orientation Stability Rating
Front Uphill
Rear Uphill
Side Uphill
D
B
B
D
Rear Uphill
B
Side Uphill
B
5
Installation
Refer to your traction unit Operator’s Manual for
complete instructions on installing attachments onto the
traction unit and connecting hydraulic hoses.
Operation
Leveler Operation
When leveling the ground, angle the leveler slightly to
keep the forward edge higher than the rear edge.
Therefore, when driving the traction unit forward, the
edge farthest from the traction unit should be higher;
when driving in reverse, the edge closest to the traction
unit should be higher.
Operating Tips
• The leveler can be used to haul container grown trees,
shrubs, and other bulky materials.
• Position a load as close to the rear of the leveler as
possible to maximize lifting capability.
• When transporting a load, keep the leveler as close to
the ground as possible.
• Never attempt to lift more than the rated lift capacity
of the traction unit.
Maintenance
Storage
1. Before long term storage, wash the attachment with
mild detergent and water to remove dirt and grime
from the entire attachment.
2. Paint all scratched or bare metal surfaces. Paint is
available from your Authorized Service Dealer.
3. Store the attachment in a clean, dry garage or storage
area. Cover it to protect it and keep it clean.
6
7
