Introduction

Thisrotary-blade,walk-behindlawnmowerisintended
tobeusedbyresidentialhomeowners.Itisdesigned
primarilyforcuttinggrassonwell-maintainedlawnson
residentialproperties.Usingthisproductforpurposes
otherthanitsintendedusecouldprovedangerousto
youandbystanders.

Readthisinformationcarefullytolearnhowtooperate
andmaintainyourproductproperlyandtoavoid
injuryandproductdamage.Youareresponsiblefor
operatingtheproductproperlyandsafely.

Visitwww.T oro.comformoreinformation,including
safetytips,trainingmaterials,accessoryinformation,
helpndingadealer,ortoregisteryourproduct.

Wheneveryouneedservice,genuineToroparts,or
additionalinformation,contactanAuthorizedService
DealerorToroCustomerServiceandhavethemodel
andserialnumbersofyourproductready .Figure1
identiesthelocationofthemodelandserialnumbers
ontheproduct.Writethenumbersinthespace
provided.

Important:Withyourmobiledevice,youcan

scantheQRcodeontheserialnumberdecal(if
equipped)toaccesswarranty,parts,andother
productinformation.

Figure1

1.Modelandserialnumberlocation

ModelNo.

seriousinjuryordeathifyoudonotfollowthe
recommendedprecautions.

g000502

Figure2

Safety-alertsymbol

Thismanualuses2wordstohighlightinformation.
Importantcallsattentiontospecialmechanical
informationandNoteemphasizesgeneralinformation
worthyofspecialattention.

Besuretoregisteryourmachineat
www.T oro.com/register.Registrationensures
thatyouarenotiedshouldtherebeaproductrecall.
Yourregistrationinformationisneversoldorshared
withthirdpartycompanies.Toavoidwasteand
helptheenvironment,adischargechutedoesnot
comewithyourpurchase(mostcustomerspreferto
recycleorbagtheirgrassclippings).Youcanrequest
adischargechutewhenyouregisteryourproduct
atwww.T oro.com/register.Simplychecktheboxin
theonlineregistrationformandT orowillsendyoua
dischargechuteatnoadditionalcharge.Pleaseallow
1to2weeksfordelivery .

ItisaviolationofCaliforniaPublicResourceCode
Section4442or4443touseoroperatetheengineon
anyforest-covered,brush-covered,orgrass-covered
landunlesstheengineisequippedwithaspark
arrester,asdenedinSection4442,maintainedin
effectiveworkingorderortheengineisconstructed,

g374150

equipped,andmaintainedforthepreventionofre.

Theenclosedengineowner'smanualissupplied
forinformationregardingtheUSEnvironmental
ProtectionAgency(EPA)andtheCaliforniaEmission
ControlRegulationofemissionsystems,maintenance,
andwarranty.Replacementsmaybeorderedthrough
theenginemanufacturer.

SerialNo.

Thismanualidentiespotentialhazardsandhas
safetymessagesidentiedbythesafety-alertsymbol
(Figure2),whichsignalsahazardthatmaycause

©2021—TheT oro®Company
8111LyndaleAvenueSouth
Bloomington,MN55420Registeratwww.Toro.com.

GrossorNetTorque:Thegrossornettorque

ofthisenginewaslaboratoryratedbytheengine
manufacturerinaccordancewiththeSocietyof
AutomotiveEngineers(SAE)J1940orJ2723.As
conguredtomeetsafety,emission,andoperating
requirements,theactualenginetorqueonthisclass
ofmowerwillbesignicantlylower.Pleasereferto

OriginalInstructions(EN)

PrintedinMexico

AllRightsReserved

*3448-976*

theenginemanufacturer’sinformationincludedwith
themachine.

Contents

WARNING

CALIFORNIA

Proposition65Warning

Theengineexhaustfromthisproduct

containschemicalsknowntotheStateof

Californiatocausecancer,birthdefects,

orotherreproductiveharm.

Batteryposts,terminals,andrelated

accessoriescontainleadandlead

compounds,chemicalsknownto

theStateofCaliforniatocause

cancerandreproductiveharm.Wash

handsafterhandling.

Useofthisproductmaycauseexposure

tochemicalsknowntotheStateof

Californiatocausecancer,birthdefects,

orotherreproductiveharm.

Introduction...............................................................1

Safety.......................................................................3

GeneralSafety...................................................3

SafetyandInstructionalDecals..........................3

Setup........................................................................5

1UnfoldingtheHandle.......................................5

2InstallingtheBlade-ControlBar........................6

3InstallingtheRecoil-StarterRopeinthe

RopeGuide.....................................................7

4AddingOiltotheEngine...................................8

5AssemblingtheGrassBag...............................8

ProductOverview.....................................................9

Specications....................................................9

Attachments/Accessories...................................9

Operation................................................................10

BeforeOperation.................................................10

BeforeOperationSafety...................................10

FillingtheFuelTank..........................................10

CheckingtheEngine-OilLevel...........................11

AdjustingtheHandleHeight.............................12

AdjustingtheCuttingHeight.............................13

DuringOperation.................................................14

DuringOperationSafety...................................14

StartingtheEngine...........................................15

UsingtheSelf-PropelDrive...............................16

ShuttingOfftheEngine.....................................16

RecyclingtheClippings....................................16

BaggingtheClippings.......................................16

OperatingTips.................................................18

AfterOperation....................................................18

AfterOperationSafety......................................18

CleaningUndertheMachine............................19

StoringtheMachineintheVertical-Stow

Position.........................................................19

Maintenance...........................................................21

RecommendedMaintenanceSchedule(s)...........21

MaintenanceSafety..........................................21

PreparingforMaintenance...............................21

ServicingtheAirFilter.......................................22

ChangingtheEngineOil...................................22

ChargingtheBattery.........................................23

ReplacingtheFuse...........................................23

ReplacingtheBlade..........................................24

AdjustingtheSelf-PropelDrive.........................25

Storage...................................................................26

StorageSafety..................................................26

PreparingtheMachineforStorage...................26

RemovingtheMachinefromStorage................26

2

Safety

Thismachinehasbeendesignedinaccordancewith
ANSIB71.1-2017.

GeneralSafety

Thisproductiscapableofamputatinghandsand
feetandofthrowingobjects.Alwaysfollowallsafety
instructionstoavoidseriouspersonalinjuryordeath.

•Read,understand,andfollowtheinstructions

andwarningsinthisOperator’sManualandon
themachineandattachmentsbeforestartingthe
engine.

•Donotputyourhandsorfeetnearmovingpartsor

underthemachine.Keepclearofanydischarge
opening.

SafetyandInstructionalDecals

•Donotoperatethemachinewithoutallguards

andothersafetyprotectivedevicesinplaceand
functioningproperlyonthemachine.

•Keepbystandersandchildrenoutoftheoperating

area.Donotallowchildrentooperatethemachine.
Allowonlypeoplewhoareresponsible,trained,
familiarwiththeinstructions,andphysically
capabletooperatethemachine.

•Stopthemachine,shutofftheengine,removethe

electric-startbutton(ifequipped),andwaitforall
movingpartstostopbeforeservicing,fueling,or
uncloggingthemachine.

Improperlyusingormaintainingthismachinecan
resultininjury.T oreducethepotentialforinjury,
complywiththesesafetyinstructionsandalways
payattentiontothesafety-alertsymbol
meansCaution,Warning,orDanger—personalsafety
instruction.Failuretocomplywiththeseinstructions
mayresultinpersonalinjuryordeath.

,which

Safetydecalsandinstructionsareeasilyvisibletotheoperatorandarelocatednearanyarea
ofpotentialdanger.Replaceanydecalthatisdamagedormissing.

Manufacturer'sMark

1.Thismarkindicatesthatthebladeisidentiedasapart
fromtheoriginalmachinemanufacturer .

94-8072

decaloemmarkt

133-8062

131-4514

1.Warning—readtheOperator'sManual.

2.Cutting/dismembermenthazardofhand,mower
blade—stayawayfrommovingparts;keepallguardsand

decal94-8072

shieldsinplace.

3.Cutting/dismembermenthazardofhand,mower
blade—disconnectthespark-plugwirebeforeperforming
maintenance.

4.Thrownobjecthazard—keepbystandersaway;shutoffthe
enginebeforeleavingtheoperatingposition;pickupany
debrisbeforemowing.

5.Cutting/dismembermenthazardoffoot,mowerblade—do
notoperateupanddownslopes;operatesidetosideon
slopes;lookbehindyouwhenmovinginreverse.

decal133-8062

decal131-4514

3

decal133-1900

133-1900

1.ReadtheOperator’sManualformoreinformationonstarting
theengine—1)Inserttheelectric-startbuttonintothe
electricstarter;2)Engagetheblade-controlbar;3)Pushthe
electric-startbuttontostarttheengine.

133-8198

1.Warning—readtheOperator'sManual;addfueluptothe
indicatedlevel,thentipthemachineontotherearwheels
forstorage.

140-4357

1.Warning—readthe
Operator’sManualfor
batteryinformation;donot
discardtheleadbattery .

2.Attention—readthe

Operator’sManual

forbatterycharging
information.

2.ReadtheOperator’sManualformoreinformationonstopping
theengine—1)Releasetheblade-controlbar;2)Removethe
electric-startbuttonfromtheelectricstarter.

decal133-8198

decal140-4357

4

Setup

Important:Removeanddiscardtheprotectiveplasticsheetthatcoverstheengineandanyother

plasticorwrappingonthemachine.

Important:T opreventaccidentalstarting,donotinserttheelectric-startbuttonintotheelectric-start

ignition(ifequipped)untilyouarereadytostarttheengine.

1

UnfoldingtheHandle

NoPartsRequired

Procedure

g374347

5

2

InstallingtheBlade-ControlBar

NoPartsRequired

Procedure

g374348

Figure3

Figure4

6

g344378

3

InstallingtheRecoil-Starter
RopeintheRopeGuide

NoPartsRequired

Procedure

Important:Tostarttheenginesafelyandeasilywheneveryouusethemachine,installtherecoil-starter

ropeintheropeguide.

Figure5

g367802

7

4

AddingOiltotheEngine

NoPartsRequired

Procedure

Important:Iftheoillevelintheengineistoolowortoohighandyouruntheengine,youmaydamage

theengine.

5

AssemblingtheGrassBag

NoPartsRequired

Procedure

g231765

Figure6

g241560

Figure7

8

ProductOverview

Attachments/Accessories

AselectionofToroapprovedattachmentsand
accessoriesisavailableforusewiththemachine
toenhanceandexpanditscapabilities.Contact
yourAuthorizedServiceDealerorauthorizedT oro
distributororgotowww.T oro.comforalistofall
approvedattachmentsandaccessories.

Toensureoptimumperformanceandcontinuedsafety
certicationofthemachine,useonlygenuineToro
replacementpartsandaccessories.Replacement
partsandaccessoriesmadebyothermanufacturers
couldbedangerous,andsuchusecouldvoidthe
productwarranty.

g371239

Figure8

1.Handle

2.Blade-controlbar

3.Electric-startbutton

4.Adjustmentforthe
self-propeldrive

5.Reardeector12.Handleknob(2)

6.Batterycharger

7.Fuel-tankcap14.Recoil-starthandle

8.Airlter

9.Cutting-heightlever(4)

10.Sparkplug

11.Oilll/dipstick

13.Grassbag

Specications

ModelWeightLengthWidthHeight

41kg154cm58cm1 15cm

21564

(90lb)(60.6

inches)

(23inches)(45.3

inches)

9
