Form No. 3354-110 Rev A
Hitch Kit
For Z590-D Series Z Master Riding Mowers
Model No. 110–0444
Installation Instructions
Safety
Safety and Instructional
Decals
Safety decals and instr uctions
are easily visible to the operator
and are located near any area of
potential dang er . R e place any
decal that is damag ed or lost.
1-633668
Installation
Step
1
Installing the Hitch
Parts needed for this step:
1
Hitch
2
U-bolt
4
Flanged locknut, (3/8 inch)
Procedure
Figure 1
1. U-bolt
2. Hitch 4. Machine frame
2. Install the hitc h onto the mac hine frame with 2
U-bolts (3/8 x 5 inc h) and 4 flang ed loc kn uts
(3/8 inc h) ( Figure 1 ).
3. Flanged locknut, (3/8 inch)
1. R emo v e any debris from the mac hine frame
( Figure 1 ).
© 2005—The Toro® Company
8111 Lyndale Avenue South
Bloomington, MN 55420
Register at www.Toro.com. Original Instructions (EN)
Printed in the USA.
All Rights Reserved
