Toro 08703 Setup Instructions

Preliminary

SandPro/IneldPro3040&5040TractionUnits

g012056

1

2

3

ModelNo.08703—SerialNo.290000001andUp

ModelNo.08705—SerialNo.290000001andUp

LooseParts

Usethechartbelowtoverifythatallpartshavebeenshipped.

FormNo.3363-940RevA

SetupInstructions

Description

Pushnuts2Installthepushnuts

Qty.

InstallingthePushNuts

1.Loosenthetwoboltssecuringthecentershroudto
theframe(Figure1).Donotremovetheboltsand
thewashersfromtheshroud.

2.Liftthecentershroudoffthemachineframe.

Use

Figure1

1.Boltsandwashers(2)3.Pushnut(2)

2.Centershroud

3.Insidetheshroud,installapushnutontoeachbolt
(Figure1).

4.Placetheshroudontothemachineandsecureitto
theframewiththebolts.

©2009—TheT oro®Company
8111LyndaleAvenueSouth
Bloomington,MN55420

Registeratwww.Toro.com.

OriginalInstructions(EN)

PrintedintheUSA.

AllRightsReserved
