Tornado 98190 User Manual

Tornado

Operation & Maintenance Manual

For Commercial Use Only

TORNADO INDUSTRIES

7401 W. LAWRENCE AVENUE

CHICAGO, IL 60706

(708) 867-5100 FAX (708) 867-6968

www.tornadovac.com

Marathon 2000 Forward Only Extractor

CATALOG NO.

98190 (115V, 60 HZ)

For parts list see L8190GHP

Effective 12/19/2005

NOTES

Write your machine’s serial number here:_________________________________

This illustrated instruction book covers:

CATALOG NO. SERIES SIZE CAPACITY VOLTS AMPS

All specifications are subject to change without notice.

TABLE OF CONTENTS:

Warranty 4 Safety Instructions 5 Preparation & General Precautions 6 Cleaning Tips 9 Machine Specifications 11 Operation Instructions 12 Maintenance Issues 14 Troubleshooting Table 16

98190

22”

20 Gal.

115V

Thank you for choosing Tornado products. We are proud to offer the most

complete line of commercial and industrial cleaning equipment in the industry.

Our reputation for quality, innovation and durability is unsurpassed.

* Effective January 1 st, 2005. Terms subject to change without notice.

1) Windshear™ Blower-Dryer, Insulation Blowers, T191, T201, T12/1, CV 30, CV 38, CW 50, CW 100, Pro PAC Vacs, Duo-Upright Carpetkeepers™, and all chargers are warranted for 1 (one) year for both parts and labor.

2) Warranties on all riding sweepers including the ICC1, KM 100/100 R, KMR 1250, and KMR 1700 are 24 months parts/6 months labor OR 1000 hours of operation, whichever comes first. Warranties on the 75/140 & 90/140 are 24 months parts/12 months’ labor OR 1,000 hours of operation whichever comes first.

3) All non-wear item parts purchased after warranty expiration are warranted for 90 days.

4) Warranty starts from the date of sale to the consumer or, at Tornado’s discretion, 6 months after dealer purchased the unit from Tornado, whichever comes first.

Note: Tornado, The Latest Dirt, Floorkeeper, Carpetkeeper, Carpetrinser, Carpetrinser/Dryer, Headmaster, Taskforce, PAC-VAC, T-Lite, Glazer, Windshear, Max-Vac, CV 30, CV 38, and Trot-Mop are trademarks of Tornado Industries.

1-800-VACUUMS

Chicago area: (708) 867-5100

Fax: (708) 867-6968

7401 W. Lawrence Avenue

Chicago, IL 60706

IMPORTANT SAFETY INSTRUCTIONS

FOR COMMERCIAL USE

WHEN USING AN ELECTRICAL APPLIANCE, BASIC PRECAUTIONS SHOULD

ALWAYS BE FOLLOWED INCLUDING THE FOLLOWING:

READ ALL INSTRUCTIONS BEFORE USING THIS MACHINE

WARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY:

1. Do not leave machine when plugged in. Unplug from outlet when not in use and before servicing.

2. Use indoors only. Do not use outdoors and do not expose to rain.

3. Do not allow to be used as a toy. Close attention is necessary when used by or near children.

4. Use only as described in this manual. Use only manufacturer’s recommended attachments.

5. Do not use with damaged cord or plug. If machine is not working as it should, has been dropped, damaged, left outdoors, or dropped into water, return it to a service center.

6. Do not pull or carry by cord, use cord as a handle, close a door on cord, or pull cord around sharp edges or corners. Do not run machine over cord. Keep cord away from heated surfaces.

7. Do not unplug by pulling on cord. To unplug, grasp the plug not the cord.

8. Do not handle plug or machine with wet hands.

9. Do not put any object into openings. Do not use with any opening blocked; keep free of dust, lint, hair, and anything that may reduce air flow.

10. Keep hair, loose clothing, fingers, and all parts of body away from openings and moving parts.

11. Turn off all controls before unplugging.

12. Use extra care when cleaning on stairs.

13. Do not use to pick up flammable or combustible liquids, such as gasoline or use in areas where they may be present.

14. Connect to a properly grounded outlet only. See Grounding Instructions.
