TORISAN TM121XG-02L02 Specification
Global LCD Panel Exchange Center
TFT COLOR LCD MODULE
TFT COLOR LCD MODULE
www.panelook.com
TM121XG-02L02
31cm / 12.1" XGA format 1ch.-LVDS I/F
Specifications
Item Typ. Unit
Screen size
Display format
Pixel pitch
Bezel Opening size
Outer dimensions
Weight
Panel mode
Backlight type
diagonal
31/12.1 (cm/inch)
1,024 x (RGB) x 768
0.24 x 0.24 W x H [mm]
250.4 x 188.9
261 x 199 x 5.5(Max.)
370
Transmissive type
1CCFT
W x (RGB) x H [dots]
W x H x D [mm]
W x H [mm]
g
Logic voltage
Power consumption Logic &
backlight
Brightness
Contrast ratio
Response time
Operating temperature
Strage temperature
Item
1,024 x RGB x 768dots
Ta=
Typ.
3.3
4.4
150
300 : 1
45
0~+50
-20~+60
Unit
V
W
(cd/m
ms
2
)
Outer Dimensions
(14.5)
170 0.2
5.5max.
2.8 0.3
199 0.5
(99.5)
261 0.5
(131.4) (129.6)
GRB
Inserting
Direction
(51)
CN1
120
(21)
Bezel Opening Area
(
Active Area center
Effective Viewing Area
(
248.2 x 186.75 min.
250.4 x 188.9
Active Area
(
245.76 x 184.32
)
)
)
2.6
70 5
FPC with Shrink tube
4-M2 (DEPTH 2.2max.)
CN1 : DF19L-20P-1H (HIROSE)
FLCN1 : BHSR-02VS-1 (JST)
