T8806 Vehicle GPS Tracker

(GSM +GPS+SMS/GPRS)

User Manual

&

Operation Command (SMS)

V1.4

http://www.topflytech.com

This document is copyrighted by Shenzhen Topflytech Communication Technology Co.,Ltd. All rights reserved.
Any unauthorized copy or transmission of the document wholly or partially shall be held liable.

- 2 -

TOPFLYTECH

CONFIDENTIAL

Thanks for your purchase of the high quality GPS trackers from TOPFLYTECH

company. Please read this user manual and operation command carefully to
obtain guidance on installation and operation. The following describes this

device. We will not publish notification should there be cosmetic or color change,

actual product prevails.

This vehicle GPS tracker product rides on GPRS communication technology,

GPS satellite positioning and internet technology. It can realize the real time

remote monitoring and control of the vehicle though a powerful service platform

( http://tracker.topflytech.com ). It provides customers with cost reduction,

efficiency increased, safety guarantee and transparency management. Currently,

it has been widely used in commercial transportation, corporate vehicle fleet,

intelligent transportation, logistics distribution, car rental, engineering machinery,

marine transportation and other fields.

http://www.topflytech.com

This document is copyrighted by Shenzhen Topflytech Communication Technology Co.,Ltd. All rights reserved.
Any unauthorized copy or transmission of the document wholly or partially shall be held liable.

- 3 -

TOPFLYTECH

CONFIDENTIAL

Table of Content

Quick Reference of Connection Diagram……………………………………………………………..5

1. Product Functions.………………………………………………………..…….……...….….….….6

2. Accessories Introduction……..……..…………………………………..…….……………..….…..6

3. Usage Environment……….……………………………………………..……….………...…….….6

4. Key Technical Parameters…………....………………………………...…………………….….…7

4.1 Basic Parameters…..……..……………………………………..……….………..….…...….7

4.2 Indicator Lights Status….……………………………………….…………………....…….…7

5. Installation Manual ……………………………………………………...……………….…………..7

5.1 SIM Card Pre-installation Note…………..………………………….……..……...………….7

5.2 Installation….………………………………..………………………….…………...………….8

5.3 Relay Wiring Method………………….…………………………………………..…..……….8

6. Cautions of Device Wiring………………………….……………………………………….………8

6.1 Power Supply Line…...………………….………………………………………………..…...8

6.2 Microphone Line..……………………….……………………………………………….…….9

6.3 SOS Alarm Line………………………………….…………………………………………..…9

6.4 Microphone & SOS Line……………………………………………………………..…..……9

6.5 Speaker Line…………….....………………………………..………………………..…..……9

7. Device Configuration………...…………………….…….…………………..….….…….…………9

8. Operation of Device………………….…………………………..……………….……..….….……9

8.1 Power On and Power Off…..………………...……………………..……..…….…..……..…9

8.2 Indicator Lights…….……………………………………………….…….……..…..…….……9

8.3 Location Search….…………………………………………………….…..……………...….10

8.4 SOS Alarm…….…………………………………………………...…..………………..…….10

8.5 Monitoring……………….…………………………………………...….……..…....…..……10

8.6 Fuel Cut.……...……………….……………………………………….…..………….…..…..10

8.7 Restore Fuel Supply……………….………………………….……….…..……….……......11

9. Trouble Shooting……………………………………..……………………..…….………..…..…..11

9.1 Unable to Connect….…………………………..……………………………..…….….…….11

9.2 Backstage Shows Offline……………….……………………………………..……….…….11

9.3 Prolong Inability to Locate……………………..…………………...……..…..…………….11

9.4 Severe Drifting in Location……………………..…………………….………..………….…12

9.5 Abnormal Command Reception…….……………………………….………..………........12

http://www.topflytech.com

This document is copyrighted by Shenzhen Topflytech Communication Technology Co.,Ltd. All rights reserved.
Any unauthorized copy or transmission of the document wholly or partially shall be held liable.

- 4 -

TOPFLYTECH

CONFIDENTIAL

10. Warranty Details…………………..……………………………………………....…....……...…12

10.1 Special Statement…………...……………..….……………………………...……….……12

10.2 Warranty Period……………………………....…………………….......……….………….12

10.3 After Sales Service…………………………..………………………………...…..….……12

11. Operation Command (SMS)………….…………………………..……………..…….…..…..…12

Command Instruction………………….....…...…………...……...………...…………....…..…12

Command Setting List……………………………………………...…..…………...……..….…13

11.1 APN Setting……………………………………...……………….....…………………….…14

11.2 Server Setting…….…….………………………………..……………………………….....14

11.3 Upload Interval Setting…………………………..…………………..…………………..…15

11.4 Heartbeat Setting………….………………………………..……….………………………15

11.5 GMT Setting………..…………………………………………………………….….……….15

11.6 PIN Setting…….………………………..…..…………………..…..…….….….……..……16

11.7 Manager Setting………………...………….……………………...….…………………….16

11.8 Manager Delete………………...………….…………….……………………….………….16

11.9 Manager List………………...………….…………….………………….……….………….16

11.10 Speaker Setting…………………………………..….………………………….………….17

11.11 Antitheft Setting………….…..……………………………………………..….….………..17

11.12 Drag Setting…………………………………………………………………..…….………17

11.13 Speed Limit Setting…………………………..………….…………….….……….………17

11.14 SMS Tracking Mode Setting……….…...………………..…………………..………..….18

11.15 SIM Card Credit Checking……….…...………………..……………..……..…….…..….18

11.16 Relay Control……………………………………………………………….…..……..……18

11.17 Google Map Search……………….…………………...........……………………………19

11.18 Identity Read Back…….………………………………...……………….………………..19

This document is copyrighted by Shenzhen Topflytech Communication Technology Co.,Ltd. All rights reserved.
Any unauthorized copy or transmission of the document wholly or partially shall be held liable.

PIN1

PIN3

PIN4

PIN5

PIN6

PIN7

PIN8

PIN9

PIN10

PIN11

PIN12

PIN2

Connector

PIN No.

Line Color

Function

1

1

Red

Power+

2

Black

Power-

3

Orange

ACC detect

(Digital input 1)

4

Yellow

Relay control

(Digital output 1)

2

5

Green

Digital input 2

(Door/AC…)

6

White

Fuel detect

(Analog input 1)

7

Gray

Analog input 2

(Temperature…)

3

8

Orange

SOS

9

Red

Microphone

10

Black

GND

4

11

Red

Speaker+

12

Black

Speaker-

Connector1

Connector4

Connector3

Connector2

Fuse

- 5 -

TOPFLYTECH

CONFIDENTIAL

Quick Reference of Connection Diagram

http://www.topflytech.com

http://www.topflytech.com

This document is copyrighted by Shenzhen Topflytech Communication Technology Co.,Ltd. All rights reserved.
Any unauthorized copy or transmission of the document wholly or partially shall be held liable.

- 6 -

TOPFLYTECH

CONFIDENTIAL

1. Product Functions

 Quad band GSM (850/900/1800/1900MHz);
 Wide DC input range: 6-36V;
 GPS continuous positioning, GPRS timing upload;
 Vehicle location tracking;
 ACC ignition signal test, vehicle status prompt;
 AC(Air Conditioner) detection (Car door or any other digital input signal);
 Two-way analog input for Fuel detection, Temperature detection

or any other analog input signal;

 SIM credit check (USSD);
 Two-way audio;
 Tow car alarm;
 Antitheft alarm;
 Built-in battery for alarm when the power line is cut off illegally;
 External fuel cut;
 External SOS button for emergency call for help.

2. Accessories Introduction (Pictures for reference only)

Sponge Double-side Adhesive Tape (Standard) Power Supply Extension Line (Standard)

1 Digital Input & 2 Analog Input Speaker Extension Line (Optional)

Extension Line (Standard)

Microphone & SOS Line (Optional) Relay (Optional) - 12V/24V

3. Usage Environment

 Operation temp：-20°C ~ 65°C (-4°F ~ 149°F)
 Storage temp：-30°C ~ 80°C (-22°F ~ 176°F)

 Operation humidity: 10% ~ 80% (Non-condensing)
 Storage humidity：0% ~ 90% (Non-condensing)

 Install in area away from rain or snow
