Topaz GemView 7, TD-LBK070VA-USB-R User Manual

Copyright © Topaz Systems Inc. All rights reserved.

For Topaz Systems, Inc. trademarks and patents, visit www.topazsystems.com/legal.

User Manual

GemView® 7 Tablet Display

TD-LBK070VA-USB-R

2 www.topazsystems.com Back to Top

GemView 7 Tablet Display User Manual

Table of Contents

Compliant & Copyright Information ....................................................................................... 3

Introduction .............................................................................................................................. 6

Packing List ............................................................................................................................ 6

Product Overview ................................................................................................................... 7

Front and Side View ....................................... 7

Rear View ......................................................... 7

Interactive Electromagnetic Pen ................... 7

Installation ................................................................................................................................ 8

Connect Tablet Display to PC ................................................................................................ 8

Connect Pen to Tablet Display ............................................................................................... 9

Install DisplayLink Driver ........................................................................................................ 9

Configure Tablet Display for Installation ................................................................................. 9

Install GemView Tablet Display Driver ................................................................................. 11

Configure Tablet Display for Pen Input ................................................................................. 11

Install Second Tablet Display and Configure for Clone Operation ....................................... 13

Install Bundled Topaz Software ............................................................................................ 13

Troubleshooting .................................................................................................................... 14

Screen Problems .................................................................................................................. 14

Problems with the Electromagnetic Pen ............................................................................... 14

Product Specification ............................................................................................................ 15

Screen .................................................................................................................................. 15

Interactive Electromagnetic Pen ........................................................................................... 16

Appendix ................................................................................................................................ 16

Replace the Pen Tip ................................................................ ............................................. 16

3 www.topazsystems.com Back to Top

GemView 7 Tablet Display User Manual

Compliant Information

This device complies with part 15 of FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.

This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses, and
can radiate radio frequency energy, and if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more
of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver

is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Warning: You are cautioned that changes or modifications not expressly approved by the party
responsible for compliance could void your authority to operate the equipment.

CE Conformity for European Countries
The device complies with the EMC Directive 2004/108/EC and Low Voltage Directive

2006/95/EC.

Following information is only for EU-member states:

The mark shown to the right is in compliance with the Waste Electrical and Electronic
Equipment Directive 2012/19/EU (WEEE). The mark indicates the requirement NOT
to dispose the equipment as unsorted municipal waste, but use the return and collection
systems according to local law.

If the batteries, accumulators and button cells included with this equipment, display
the chemical symbol Hg, Cd, or Pb, then it means that the battery has a heavy metal
content of more than 0.0005% Mercury or more than, 0.002% Cadmium, or more than

0.004% Lead.

4 www.topazsystems.com Back to Top

GemView 7 Tablet Display User Manual

Important Safety Instructions

1. DO NOT place objects on top of the device, as objects may scratch the screen.

2. DO NOT expose the device to dirty or dusty environments.

3. DO NOT place the device on an uneven or unstable surface.

4. DO NOT insert any foreign objects into the device.

5. DO NOT expose the device to strong magnetic or electrical field.

6. DO NOT expose the device to direct sunlight as it can damage the LCD Screen. Keep it

away from heat sources.

7. DO NOT use the device in the rain.

8. Please check with your Local Authority or retailer for proper disposal of electronic

products.

9. The device may produce some heat during normal operation or charging. To prevent

discomfort or injury from heat exposure, DO NOT leave the device on your lap.

10. POWER INPUT RATING: Refer to the rating label on the device. Only use accessories

specified by the manufacturer.

11. DO NOT use any sharp object to tap the screen.

12. Clean the touch screen with a soft cloth. If needed, dampen the cloth slightly before

cleaning. Never use abrasives or cleaning solutions.

13. Disconnect the device from an electrical outlet and power off before cleaning the device.

14. DO NOT disassemble the device. Only a certified service technician should perform

repair.

15. Users have to use the connection to USB interfaces with USB 2.0 version or higher

5 www.topazsystems.com Back to Top

GemView 7 Tablet Display User Manual

Declaration of RoHS2 Compliance

This product has been designed and manufactured in compliance with Directive 2011/65/EU of
the European Parliament and the Council on restriction of the use of certain hazardous
substances in electrical and electronic equipment (RoHS2 Directive) and is deemed to comply
with the maximum concentration values issued by the European Technical Adaptation
Committee (TAC) as shown below:

Substance

Proposed Maximum
Concentration

Actual
Concentration

Lead (Pb)

0.1%

< 0.1%

Mercury (Hg)

0.1%

< 0.1%

Cadmium (Cd)

0.01%

< 0.01%

Hexavalent Chromium (Cr6+)

0.1%

< 0.1%

Polybrominated biphenyls (PBB)

0.1%

< 0.1%

Polybrominated diphenyl ethers (PBDE)

0.1%

< 0.1%

Certain components of products as stated above are exempted under the Annex III of the RoHS2
Directives as noted below: Examples of exempted components are:

1. Mercury in cold cathode fluorescent lamps and external electrode fluorescent lamps (CCFL

and EEFL) for special purposes not exceeding (per lamp):
(1) Short length (≦500 mm): maximum 3.5 mg per lamp.
(2) Medium length (＞500 mm and ≦1,500 mm): maximum 5 mg per lamp.

(3) Long length (＞1,500 mm): maximum 13 mg per lamp.

2. Lead in glass of cathode ray tubes.

3. Lead in glass of fluorescent tubes not exceeding 0.2% by weight.

4. Lead as an alloying element in aluminum containing up to 0.4% lead by weight.

5. Copper alloy containing up to 4% lead by weight.

6. Lead in high melting temperature type solders (i.e. lead-based alloys containing 85% by

weight or more lead).

7. Electrical and electronic components containing lead in a glass or ceramic other than

dielectric ceramic in capacitors, e.g. piezoelectronic devices, or in a glass or ceramic matrix
compound.
