TOORX ERX70 Instruction

Edizione : Revisione : 00

INSTRUCTION

08/16 00

Exploded Diagram:

3

4

5

26

40

46

52R

52L

14L

8

7

29

12

14R

37

46

15

2

2

9

10

11

13

13

15

19

20

17

18

8

22

21L

22

23

24

25

24

23

22

22

17

18

20

8

19

27

28

21R

31

32

33

33

34

35

35

34

33

33

31

32

36

37

38

37

38

39L

41

42

29

36

43

44

45

37

37

46

41

47

48

47

41

41

51

34

35

53L

54

51

34
35

53R

54

56

57

22

22

23

60

60

23

22

22

57

56

39R

S13-S14-S15

S13-S14

S17-S19

1

16

16

16

16

16

16

30

49

64

65

30

49

64
65

58

58

59

59

SPARE PARTS

NO.

DESCRIPTION

Q’TY

1

Computer

1

2

Foam grip Φ23*5*500

2

3

Hand pulse grip

2

4

Middle handle bar

1

5

End cap φ31*16

2 7 Bolt ST4*19

2

8

Spring washer d8

4 9 Bolt M8*30*S6

2

10

Handlebar clamp cover

1

11

Plug Φ12*11*Φ3

1

12

Hand pulse wire

1

13

End cap Φ32*46*Φ50

2

14L/R

Handle bar

2

15

Foam grip Φ30*5*670

2

16

Cap S13

6

17

Bolt M6*16*S5

4

18

Bolt Φ8*27.5*H4*M6

4

19

Hex Bolt M8*16*S14

2

20

Washer d8*Φ32*2

2

21L/R

Coupler Bar

2

22

Sleeve 2 Φ
32*3*Φ28*21*Φ19.4

8

23

Wave washer d19*Φ25*0.3

4

24

Long spacer Φ

31.8*Φ19.2*76

2

25

Handle bar post

1

26

Arc washer d5*Φ20* R30*1.5

1

27

Bolt M5*55

1

28

Bolt M5*10

2

29

Trunk wire

1

30

Hex Bolt M10*55*13*S17

2

31

Hex bolt M8*75*13*S14

2

32

Spacer Φ14*Φ8.3*59

2

33

Spacer 1Φ
32*3*Φ28*16*Φ14.3

4

34

Washer d8*Φ16*1.5

6

35

Nylon Nut M8*H7.5*S13

6

36

Tension Control

1

37

Arc washer d8*Φ20*2*R30

8

NO.

DESCRIPTION

Q’TY

38

Bolt M8*16*S6

4

39L/R

End cap Φ60*Φ70*95

2

40

Front stablizer

1

41

Bolt M8*73*20*H5

4

42

Bolt ST3*10

2

43

Sensor wire

1

44

Tension wire lower

1

45

Main frame

1

46

Nut M8*H16*S13

4

47

End cap Φ60

2

48

Rear Stabizer

1

49

U Bracket

2

51

Square end cap J60*30*15

2

52L/R

Connecting rod

2

53L/R

Pedal

2

54

Hex Bolt M8*45*20*S14

4

56

Nylon Nut M10*1.25*H9.5*S17

2

57

Washer d10*Φ32*2

2

58

Cap S16

2

59

Cap S18

2

60

Spacer Φ32*Φ19.2*30

2

62

Hex Bolt M10*55

2

63

Bushing 18*3*Φ10.1

4

64

Washer d10*Φ20*2

4

65

Nylon Nut M10

4

66

Pedal Connect Join

2

67

Wrench S13-14-15

1

68

Wrench S5

1

69

Wrench S6

1

70

Wrench S13-14

1

71

Wrench S17-19

1

STEP 1：

Secure front stabilizer (40) and rear stabilizer (48) to main frame (45) with bolts (41), arc

washers (37) and nuts (46).
