EH244 Encoder Host

969 Horsham Road lHorsham, Pennsylvania 19044 USA l Phone: [phone] Fax: [phone] [e-mail]

The R.L. Drake model EH244 encoder host is a platform for supporting modular MPEG2 and MPEG4 H.264 video encoders,
including the SDE24, HDE24, and SDI24. The encoder host multiplexes the encoder outputs into up to 4 QAM output chan­nels, configurable via a front panel interface or Ethernet web server. The EH244 includes provisions for emergency alert ser­vices, using either video replacement or SCTE18 control messages and is fully compatible with Drake’s “Bandwidth Recovery
Solution”.

The EH244 accepts up to 6 encoder modules, and allows each encoder’s output program(s) to be assigned to any or all 4 out­put program streams. The EH244 can output on up to 4 frequency-adjacent QAM channels between 54 MHz and 1002 MHz
using an internal QAM modulator, and supports optional factory installed ASI outputs that mirror the QAM program streams.

Benefits

• Quad QAM Modulation
The Drake Digital

TM

EH244 Encoder Host can multiplex the encoded video streams and output them on

any one of the 4 QAM outputs allowing for optimization of both bit rate and bandwidth.

• Scalable System
Any combination of Drake SDE24, HDE24 or SDI24 SD and HD encoder modules can be housed in the
EH244 providing maximum flexibility. SD modules may be replaced by HD modules making future HD
upgrades affordable.

• Remote Management
An Ethernet port provides local or remote access to all settings and can be used to monitor basic system
function.

Applications

• Cable Networks

• Hospitality

• Health Care

• Commercial

• Government/Military

• Digital Signage

Input Modules for Use with EH244

Digital Encoder Modules EAS Solution Modules

Works
only with
MEQ1000

Specifications Subject To Change Without Notice Rev 05-12 ©Toner Cable Equipment, Inc.

969 Horsham Road lHorsham, Pennsylvania 19044 USA l Phone: [phone] Fax: [phone] [e-mail]

Multiplexer Specifications

Program Filtering and Grooming: Each encoder output can be disabled or output to any or all

output channels

Multiplexer: All programs directed to each output are multiplexed into a

correct multi-program transport stream

ASI Outputs: An optional ASI output board may be ordered that mirrors the

4 QAM channel output transport streams

PSIP Table Handling

PSIP Table Rewriting: Supported
MGT/VCT Table Generation: Supported
SCTE18 EAS Generation: Supported

Modulator Specifications

Modulation Modes: 64, 256QAM ITU j.83 Annex A

16, 32, 64, 128, 256 QAM ITU j.83 Annex A
Symbol Rates: 1-7 Msps variable, with presets for Annex B
Frequency Coverage: 54-1002 MHz, up to 4 frequency-adjacent channels
Channel Plans: Standard CATV, HRC, IRC, Broadcast
Max Output Power: +54 dBmV
Min Output Power: +42 dBmV
Output Level Accuracy: ±2 dB
Phase Noise: <-108 dBc/Hz @ 10 kHz offset
Broadband Noise: <-75 dBc @ 12 MHz offset in a 6 MHz bandwidth
MER: >44 dB equalized
Channel Frequency Response: <1 dB
Carrier Suppression: >80 dB
I/Q Imbalance: <1 degree
Spurious Emissions: <-60 dBc

Temperature Rating 0-50°C ambient
Form Factor 2RU 19” rack enclosure
Dimensions 14.25”D x 3.5”H x 19”W
Weight 9.5 lbs
Power Requirements 90-260 VAC 65W maximum

Specifications

EH244 Encoder Host
