DMG 3000/3100 Turnkey Headend Solution
969 Horsham Road
Horsham, Pennsylvania 19044 USA
DMG 3000/3100
Digital Cable System, Multiplexer
Turnkey Headend Solution
Sencore’s DMG 3000/3100 multiplexer is the simplest, most
powerful digital cable solution for operators launching or expanding their digital service offering.
The DMG 3000/3100 advanced multiplex software simplifies
engineers’ deployment and operational routines. Developed
specifically for digital cable operators, the multiplexer performs
full analysis of source PSI/SI and PSIP tables, with automatic
regeneration of all tables as required, up to a maximum 250 multiplexes.
Sencore’s DMG 3000/3100 offers a high performance QAM output module for direct insertion of digital services into the cable
network. Based on a full digital-modulation and up-conversion
architecture, the QAM Output module delivers a clearer signal,
and makes future upgrades easier.
Central Headend
Ease of configuration makes the DMG 3000/3100 the ideal solution for deployments requiring aggregation of services from multiple sources, service processing and preparation for QAM broadcast over cable networks.
Remote Headend
With IP, DVB-T or ASI input sources, powerful edge processing
capabilities, high density QAM output alongside decoder options
for analog simulcast, operators can deliver all broadcast services
via a common platform.
Contribution
High throughput ASI feeds, multiplexing functionality, and an
easy to use user interface make dynamic service adjustments
possible.
Regional Adaptation
For insertion of local programming at regional broadcast locations, the DMG 3000/3100 is a powerful, space efficient solution.
Transparent mode enables direct transport stream forwarding for
network conversion applications.
Resilience is built into the DMG architecture. Modules are hotswappable, including power supplies and fans, and the ‘Always
On’ redundancy solution offers full or partial redundancy for a
variety of failure scenarios.cast over cable networks.
Key Features
• 1 RU, 9 Module Chassis
• 4 RU, 16 Module Chassis with Dual
Redundant Power Supplies
• Ethernet Gbit/s, ASI, DVB-S/S2, DVB-T,
DVB-C, 8-VSB Inputs
• Ethernet Gbit/s (MPTS or SPTS), ASI,
QAM Outputs
• 11 Different Modules
• Multiplexing, PSI/SI Regeneratiion,
PSI/SI/PSIP Input Analysis
• SNMP Alarm MIB
• SOAP/XML Interface
• Web Browser Control and Setup
• DVB, AES SW Scrambling,
Descrambling
• Common Scrambling Algorithm Module
DMG3100
DMG3000
DMG 3000 Chassis (4RU) MC/CAB4PS-04
• Modular Configuration with up to 16+2 board positions
• WEB based configuration, SNMP Alarms, SOAP/XML
interface
• Forced air-cooling
• Hot-Swappable modules
• Dual redundant hot-swappable 300 W power supply
• 4 individually monitored hot-swappable fans
DMG 3100 Chassis (1RU) MC/CAB1PSSW
• Modular configuration with up to 9+1 board positions
• WEB based configuration, SNMP Alarms, SOAP/XML
interface
• Forced air-cooling
• Hot-swappable modules in back
• Optional IP IO and descramblers in front
• Switch module included
• 10/100/1000BaseT input card (RJ45)
• Mini-GBIC interface (SFP) for optical input
• Supports UDP/RTP Multicast/Unicast reception
• Supports reception of MPTS and SPTS
• Up to 850 MBit/s
• Service filtering
• PCR regeneration
• 10/100/1000BaseT management port (RJ45)
• Enables WEB management
• 1 slot wide
• 3xASI input
• BNC connectors
• 213 Mbit/s per input
• Supports reception of MPTS and SPTS
• Service filtering
• 10/100/1000BaseT management port (RJ45)
• Enables WEB management
• 1 slot wide
Switch Module (supplied with chassis) MC/SWM
• One needed per chassis in position 1
• Gbits/s routing between modules in a chassis
• Integrated from the front
• 4xDVB-S/S2 inputs
• F connectors
• DVB-S, DVB-S2 QPSK and 8PSK modes
• 950 – 2150 MHz Frequency Range
• -25 to -70 dBm input level
• 1-45 MSym/s (mode dependent)
• LDPC and BCH decoding
• 1/2, 2/3, 3/4, 5/6, 7/8, 8/9, 9/10 FEC (mode
dependent)
• Normal DVB-S2 FEC frames
• Supports reception of MPTS and SPTS
• LNB Voltage: 0/13/18 Volt
• 400 mA maximum LNB supply current
• LNB Voltage +22 kHz continuous tone LNB signaling
• Service filtering
• ASI monitoring port
• 10/100/1000BaseT management port (RJ45)
• Enables WEB management
• 2 slots wide
DVB-S/S2 Input (EN300 421, EN 302 307) *MC/4DVBS-MMI | *MC/4DVBSS2-MMI
Ethernet Input w/ Management *MC/GBIPIN-MMI
ASI Input w/ Management *MC/3ASI-MMI
DMG 3000 / 3100 Digital Cable System, Multiplexer Solution
INPUT MODULES
• 4xCOFDM inputs
• F connector
• 49 - 861 MHz frequency range
(center frequency)
• 7 and 8 MHz channel bandwidth
(6 MHz optional)
• -20 to -65 dBm input level
• 1/4, 1/8, 1/16, 1/32 guard interval
• 1/2, 2/3, 3/4, 5/6, 7/8 FEC
• FEC: Reed Solomon & Viterb fully compliant with
ETS 300 744 and NorDig 2 specifications
• Non-inverted and inverted spectrum
• 2k and 8k carrier mode
• QPSK, 16QAM, 64QAM modulation
• Supports reception of MPTS and SPTS
• Service filtering
• ASI monitoring port
• 10/100/1000BaseT manageport (RJ45)
• Enables WEB management
• 2 slots wide
• 4xQAM inputs
• F connector
• 51-858 MHz frequency range
• 7 and 8 MHz channel bandwidth
(6 MHz optional)
• 4, 16, 32, 64, 128, 256 QAM mode
• 0.87-6.9 Ms/s
• Non-inverted and inverted spectrum
• FEC: ITU-T J83 annex A, B, and C, and ETS
300 429
• Supports reception of MPTS and SPTS
• Service filtering
• ASI monitoring port
• 10/100/1000BaseT manage port (RJ45)
• Enables WEB management
• 2 slots wide
• 4x8VSB Inputs
• F connectors
• 50 to 860 MHz Frequency Range
• -34 to +40 dBmV input level
• Broadcast band
• Supports reception of MPTS and SPTS
• ASI monitoring port
• Service Filtering
• 10/100/1000 BaseT management port (RJ45)
• Enables WEB management
• 2 slots wide
DVB-C Input w/Management (EN 300 429) *MC/4QAM-MMI
8VSB Input w/Management *MC/4 x8VSB-MMI
DVB-T Input (EN 300 744) *MC/4COFDM-MMI
• 10/100/1000BaseT input card (RJ45)
• Mini-GBIC interface (SFP) for optical input
• Supports UDP/RTP Multicast/Unicast
transmission
• Supports multiple of output cards
• Streaming of up to 850 Mbit/s
• Maximum 250 service per output card
• Transport stream, MPEG-2 SD/HD and MPEG-4
SD/HD video formats
• Supports streaming of SPTS
• Support streaming of MPTS with Multiplexing
(optional)
• PSI/SI regeneration
• PCR regeneration
• 1 slot wide
Ethernet Output *MC/GBIPOUT
OUTPUT MODULES
• 4xASI outputs
• BNC connectors
• 213 Mbit/s per output
• 4 different multiplexed outputs
• Maximum 250 service per output card (sum of all
4 ports)
• Transport stream output, SPTS and MPTS
• Output format constant bit-rate
• PSI/SI regeneration
• 1 slot wide
ASI Output *MC/4ASIOUTMX
• 8 QAM outputs, 4 and 4 paired
• Full digital modulation and upconversion
• DOCSIS 3.0 RF compliant
• 32 / 64 / 128 / 256 QAM modulation
• Frequency range of 50 – 850 MHz
• Frequency step size of 12.5 kHz
• Frequency stability of 5 ppm
• Output level with 8 carriers on of 40 to 50
dBmV per carrier
• Output level adjustment step size (GUI) of 0.5 dB
• 4.48 to 7.00 Mbaud symbol rate
• Maximum 250 service per output card (sum of all
8 ports)
• Supports multiplexing and transparent pass
through
• PSI/SI regeneration
• F connector for RF output
• External mute of RF output
• 2 slots wide
• 4 & 16 QAM output models also available
QAM Output *MC/8QAMOUTMX
