1. T-ONE
kit c
ontent
s
1 T-ONE electronic stimul
ator;
4 connection cables, for the tran
smissi
on of elect
ric impulses
;
2 packages containing 4 pre-gelled self-adhe
siv
e 48x48 mm electrodes;
2 packages containing 4 pre-gelled self-adhe
siv
e 50x90 mm electrodes;
1 packages containing 8 round pre-gelled self-adhe
siv
e 32 mm diameter;
1 battery charger;
4 rechargeable
Ni-M
h batteries AA (8 for model MEDI-PRO)
1 T-ONE user m
anual;
1 electrode position manual;
1 Ionophore
sis Kit;
1 ca
rry
bag;
Spare part
s available:
• Pre-gelled self-adhe
siv
e electrodes 48x48mm, 50x90mm, round 32mm
•
Ionophore
sis
pads: 60x80mm • 80x120mm;
• Elastic band for Ionophore
sis tr
eatment 80 mm high (code FI80X60)
• S
et elastic band for legs drainage (codes FC250-265 and FP
235-245);
2. Purpo
se.
T
he T-ONE
electronic stimulator is a medical de
vice specifically i
ntended for adults with
adequate knowledge of the de
vic
e acquired from reading the manual for domestic use.
T-ONE is used to apply elect
rical microimpulses, c
apable of producing energy, to the human
body. This energy, modulated in accordance with parameters typical to each impulse, can be
used for various purposes, from pain reduction to winding-down exe
rcises
, from mu
scl
e
str
engthening to drainage, from isotonic exe
rcises
to treating haematomas, to the treatment of
imperfections usi
ng the beauty programs. We recommend to consult your doctor before using
TENS and REHAB programs
.
Contraindications.
This
de
vice mus
t not be used by people with a pace-maker, epilept
ics
, pregnant women,
people with a high temperature, anxious people or people suffering from heart disease,
phlebitis, thrombophlebitis or serious
illnesses
.
In the event of injury, mu
scle stress
or any other health problem use the de
vic
e only under
medical s
upe
rvisi
on.
T
he ionophore
sis
program uses monopha
sic impuls
e, so it is pola
rizi
ng: do not use near
m
eta
llic pros
the
sis
under
skin (minimum
10 cm from meta
llic pros
the
sis)
.
Sid
e effects
No signific
ant side effects are known of. Some particula
rly sensitiv
e people have reported
ski
n
r
edness in the area where the electrodes were positioned: the redness usua
lly dis
appears a
few minutes after the end of the treatment. Should the redness pe
rsis
t please consult a doctor.
In rare cases, stimulation ca
rri
ed out in the evening can cause some people to experience
difficulty in fa
lli
ng asleep. If this occurs, suspend the treatment and consult a doctor.
Page 5
USER
MANUAL T-ONE Medi/Medi-Pro MNPG06-
03 Pag. 5
3. Warning
s.
T-ONE has been designed and manufactured to be operated with 4 rechargeable AA batteries.
• T
he de
vice mus
t not be used in the presence of patient monitoring equipment.
• D
o not use T-ONE wi
th electrosurgical or shortwave or
microwav
e therapy equipment .
• Us
e of the de
vice is prohibi
ted to persons known to be of unsound mind.
• Us
e of the de
vice is prohibi
ted to persons suffering from sensib
ility disorders
.
• Us
e of the de
vice is
prohibited to permanently or tempora
rily
disabled persons unless
a
ssis
ted by qualified personnel (e.g. a doctor or therapist).
• Us
e of the de
vice is prohibi
ted in the presence of signs of deterioration of the de
vice itsel
f.
S
hould any foreign matters penetrate the de
vice c
ontact the retailer or manufacturer
immedi
ately.
If dropped, check that the housing is not cracked or damaged in any way; if so, contact the
r
etailer or manufacturer.
S
hould you notice any changes in the de
vice’s
performance during treatment, interrupt the
treatment
immedi
ately and consult the retailer or manufacturer (patients being treated in a
c
entre must also be informed of the event).
• Us
e of the de
vice is prohibi
ted in combination with other medical de
vices
.
• Us
e of the de
vice is prohibi
ted close to flammable substances or in en
vironm
ents with high
conc
entrations of oxygen.
• Consul
t a doctor before using T-ONE wi
th meta
llic os
teosynthe
sis
de
vices
.
Muscl
e heaviness and cramps may be experienced in the event of prolonged mu
scl
e
stimulati
on. Should this occur we recommend suspending treatment with T-ONE
for a few
days and then continuing with mu
scle recovery
and cap
illarizati
on programs.
Make sur
e that the plug and battery charger are intact. Should one of these parts show any
si
gn of damage, suspend use of the battery charger
immedi
ately and contact the retailer or
m
anufacturer.
Only use battery charger
s s
upp
lied by the ma
nufacturer; the use of battery chargers not
s
upplied by the manufacturer
will fr
ee the same from any responsib
ility rel
ated to damage to
the equipment or user, and
will expos
e the user to
risks suc
h as short
circuits
and fire.
•
It is forbidden to position the electrodes in such a way that the current crosses the heart area (e.g.
a black electrode on the chest and a red electrode on the shoulder blade); however electrodes
c
an be positioned along the muscular fa
sci
a of the heart area, as used for pectoral strengthening.
• Us
e of the de
vice is prohibi
ted with electrodes positioned on or close to injuries or cuts.
• T
he electrodes must not be positioned on the carotid sinuses (carotid) or genitals.
• T
he electrodes must not be positioned close to the eyes; make sure that the current
de
liver
ed does not cross the eyeball (one electrode diamet
rically
opposite to the other in
relati
on to the eye); keep a distance of at least 3 cm. from the eyeball.
• W
hen using the electrodes, follow the instructions given in this manual and on the package of
the electrodes themselves. Use single-patient electrodes, supplied e
xclusively
by the
m
anufacturer or retailer, and take great care to avoid the exchange of electrodes between
different users. T-ONE
has been tested and guaranteed for use with the electrodes supplied.
•
Insuff
ici
ently
siz
ed electrode sections can cause
skin reactions or
burns. Only use the round
electrodes supplied by the manufacturer for facial app
lications
.
• D
o not use electrodes when damaged, even if they st
ick
to the
skin well
.
• Electrodes must not be used when they no longer st
ick
to the
ski
n. Repeated use of the
sam
e electrodes can compro
mis
e the safety of the stimulation, in fact it can cause
ski
n
r
edness that can last for many hours after stimulation.
• Warni
ng! During treatment with round and 35 x 45 mm. electrodes, current density may be
i
n excess of 2 mA/cm²
for each electrode. In these cases take special care regarding any
skin r
edness.
• D
o not use anal or vaginal probes in event of
ski
n or mu
scle injuries. D
o not use without a
medical prescripti
on.
Page 6
Pag
. 6 USER
MANUAL T-ONE Medi/Medi-Pro cod. do
c. MNPG06-03
4.
Legend of
symbo
ls marked on T-ONE and found in th
e
manu
al
.
M
anufactured in compliance with the 93/42/EEC
directive concerning medical
de
vices
Interna
lly
powered de
vice wi
th type BF
applied parts
Product subject to WEEE r
egulations concerning separate waste collection
R
ead the instructions for use carefu
lly
before using the de
vic
e
ON/OFF
button.
Selec
t program and mu
scles
to stimulate.
Multi
function buttons: select Sport, Beauty or Tens program, male, female
and
ski
p phase.
Start/S
top program, conf
irm selecti
on and pause.
Increase intensity.
Decrease i
ntensity.
5.
How to use T-ONE
.
Page 7
USER
MANUAL T-ONE Medi/Medi-Pro MNPG06-
03 Pag. 7
Preliminary instructions.
B
efore using T-ONE cl
ean the
ski
n of the area to be treated; with the cable d
isc
onnected from
T-ONE, connect the electrostimulation cable ja
cks
to the self-adhe
siv
e electrodes; position the
self-
adhe
siv
e electrodes on the
skin (s
ee photos of electrode positions); connect the impulse
tran
smissi
on cables to the relative ja
cks (C
hannel 1 and/or Channel 2), then turn T-ONE
on.
Warni
ng: make sur
e that T-ONE is switc
hed off before d
isc
onnecting the electrodes at the
end of the treatment.
Operating instructions (N.B. read the who
le manual before using th
e equipment)
1. Turn T-ONE
on using the button
2. Select the program group: Sport, Beauty, Tens, Mem (only Medi-Pro ve
rsion)
using the
button
3. Select the program using the buttons
4. Select male or female with buttons .
Male selecti
on
Femal
e
selecti
on
5. Select the mu
scl
e group with buttons
6. press to start program; the display shows connect cables and electrodes and increase
i
ntensity of the used channels; to start intensity press for each used channel; T-ONE will
begin the se
ssi
on.
7. press the button for each use channel to increase current intensity until the personal
tolerance level is reached.
Page 8
Pag
. 8 USER
MANUAL T-ONE Medi/Medi-Pro cod. do
c. MNPG06-03
A
bar indicating the start and end of a contraction
will
appear on the display wh
ils
t the
electronic stimulator is wo
rki
ng. The periods of muscular contraction (bold bar) and the periods
of recovery (dotted or striped bar) are graphica
lly visualis
ed under the bar with a cursor. This
enables the user to know exactly when a contractions starts.
8. At the end of the f
irs
t phase, the T-ONE cancels
the previou
sly selec
ted intensity, and warns
the user with an inte
rmi
ttent signal; to continue with the program, press the button for the
relev
ant channels again until you reach the de
sir
ed level of stimulation.
A
n audio signal
will s
ound three times when the program has finished.
9. At the end of the program
switc
h off the T-ONE
and remove the cables. Attach the
electrodes to the transparent f
ilms
and replace them in their original packaging.
Option to simultaneou
sly increase the intensity on all channels:
Selec
t the de
sir
ed program:
Star
t program
Increase each channel to at least intensity 1:
Blue
CH
1
Yellow
CH
2
R
ed
CH
3
Whi
te
CH
4
To simul
taneou
sly increas
e the intensity of all channels use the following buttons:
Increase
Decreas
e
Skip ph
ase: press the button during the wo
rki
ng program to
ski
p to the next phase.
Pau
se/s
top program:
during the wo
rki
ng program, press the button once to
mom
enta
rily
pause the normal wo
rki
ng
cycli
ng. Press
the button again to restart the
program.
Switch off the machine to stop the program.
6. Battery charging
.
T
he display shows when the battery is low of energy:
B
atteries
fu
lly char
ged
B
atteries partia
lly
d
ischar
ged
B
atteries fu
lly
d
ischar
ged
BATTERY CHARGER
SPECIFICATIONS: see battery charger datasheet.
Us
e only battery charger supplied by the manufacturer or by autho
riz
ed dealers.
Usi
ng other
battery chargers can seriou
sly compromis
e equipment and user safety.
B
atteries specifications: use only AA type batteries
lik
e the ones supplied with the equipment
(rechar
geable
Ni-Mh AA
1,2V or Alkali
ne AA 1,5V ). The manufacturer is not responsible for
damages due to the use of different batteries.
WARNING: do not recharge other batteries than the ones supplied with
Ni-M
h battery charger.
Page 9
USER
MANUAL T-ONE Medi/Medi-Pro MNPG06-
03 Pag. 9
Recharging instructions:
•
Insert the rechargeable batteries into the charger respecting the indicated polarity;
• C
onnect the charger to the domestic plug.
• T
he batteries need 8/12 hours for a complete charge.
• Duri
ng charging, both batteries and charger get warm: this is a normal condition and do
not imply any danger.
WARNING: d
isc
onnect the batter
y charger from domest
ic plug when not in u
se.
D
o dot
immer
ge the battery in water or other liquids and do not expose it to heat sources.
D
o not dispose of d
ischar
ged or defective batteries with domestic waste; dispose of in an
autho
ris
ed waste collection bin.
B
efore storing T-ONE
for long periods of time, we recommend that it is fu
lly char
ged and
stor
ed in a dry place, che
cki
ng that it is
switc
hed off.
Do not u
se the battery charger if:
• T
he plug is damaged or parts of it are broken.
•
It has been exposed to rain or any other type of liquid.
• T
he components have been damaged by a fall.
D
o not
immer
ge the battery charger in water. Use a dry cloth to clean the battery charger. Do
not open the battery charger: it does not contain repairable parts.
Page 10
Pag
. 10 USER
MANUAL T-ONE Medi/Medi-Pro cod. do
c. MNPG06-03
7. T-ONE maintenan
ce and storag
e.
We recomm
end that T-ONE is switc
hed off and the cables are removed from the connectors at
the end of every se
ssi
on. T-ONE s
hould be kept in the ca
rry
bag supplied, together with the
res
t of the equipment supplied with it, and carefu
lly stor
ed on a secure surface and protected
from situations
lis
ted in the Warnings paragraph.
T-ONE should be stored in the following conditions:
Temper
ature: from -20°C to +40°C
Maximum relativ
e humidity: 75%
Atmos
phe
ric pressur
e: from 700 hPa to 1060 hPa
C
leani
ng:
only clean the de
vic
e using a dry cloth.
We recomm
end that the de
vic
e be subjected to a functional test ca
rri
ed out by the
m
anufacturer every 24 months.
T
he manufacturer retains that the T-ONE
de
vice c
annot be repaired by personnel external to
its
own company. Any work of this nature ca
rri
ed out by personnel not autho
ris
ed by the
m
anufacturer
will
be classed as tampering with the de
vic
e, freeing the manufacturer from
res
ponsib
ility
for the warranty and hazards that the operator or user may be exposed to.
N.B
. d
isc
onnect the cables before placing the electronic stimulator in the bag. If not, the cables
will
bend exce
ssively clos
e to the connectors. This may damage the cables.
8. Resolution of problems and questions.
Any
type of work on T-ONE mus
t be ca
rri
ed out e
xclusively
by the manufacturer or by an
autho
ris
ed dealer. In any event, any presumed malfunction of T-ONE mus
t be verified before
s
ending the de
vic
e to the manufacturer.
Her
e below are some typical situations:
T-ONE ca
nnot be turned on:
• Ensur
e of presence of batteries in the unit.
• Rechar
ge the batteries and try to
switch i
t on again.
• Check
that the ON/OFF button has been pressed correctly (held down for at least one
sec
ond).
• Check
that batteries have correct polarity of the batteries.
T-ONE does
not transmit electr
ic impu
lses:
• Check
that the cable ja
cks
have been inserted in the electrodes and that the plastic
protection has been removed from the electrode.
• Check
that the cables have been connected correctly (connector well inserted in the de
vice)
.
T-ONE switches
off during operati
on:
• Rechar
ge the batteries and start the treatment again. If the problem pe
rsists c
ontact the
m
anufacturer.
Dispo
sal
T
o protect the en
vironm
ent, the de
vic
e, its accessories and above all the batteries must be
disposed of in areas equipped for that purpose or as special waste.
Product subject to WEEE r
egulations concerning separate waste collection
Page 11
USER
MANUAL T-ONE Medi/Medi-Pro MNPG06-
03 Pag. 11
9. Electrostimulation and stimulation intensity.
Electrostimulation con
sists
of the tran
smissi
on of elect
ric microimpulses
to the human body.
Fields
of app
licati
on of electrostimulation are: pain therapy, recovery of mu
scl
e troph
ism
after
injury or
a surgical operation, athletic preparation and beauty treatments.
Specific electric impulses ar
e used for every one of these app
lications
.
Th
e stimulation
intensity is displayed on the T-ONE scr
een for each channel in a scale
progre
ssi
ng from 0 to 120.
T
he types of impulses can be cla
ssifi
ed as follows:
1. Tens impu
lse: for tens programs, the intensity should be adjusted to a level between
the thresholds of perception and pain. The ma
ximum limit is reac
hed when the mu
scles
surr
ounding the area treated begin to contract. It is best to stay below that
limi
t.
2. I
onophoresis impu
lse: the intensity must be strong enough to produce a relevant
perception, near pain, t
ill
the mu
scles surr
ounding the area treated begin to contract.
3. Lipolysis/drainag
e impu
lse: the “pump” effect is produced by sequential tonic
c
ontractions. The intensity must be enough to produce these contractions: the greater
the contraction is, the greater the pump effect
will
be. But beware: there is no benefit to
be gained from enduring intensity high enough to cause pain. The f
irs
t
electrostimulation se
ssions s
hould be ca
rri
ed out at a low intensity to allow the organ
ism
to get used to new sensations. That way intensity can be increased gradua
lly
and
will
not be traumatic.
4. Warming-up impulse: in this case stimulation intensity must be increased gradua
lly
to
increas
e the metabo
lism
of the mu
scle concer
ned gradua
lly. A
bit
like wi
th a car: the
engine needs wa
rming-
up before it is taken to full speed.
5.
Toning, training, atr
oph
y c
ontraction impu
lse: the mu
scl
e treated must
visibly
c
ontract during a training impulse. The fact that the mu
scl
e tends to stiffen and increase
in volume will
be
visibl
e to the naked eye. Intensity should be increased gradua
lly (i
n the
f
irst c
ontraction) to enable you to identify the right level of stimulation comfort. Intensity
c
an be increased up to the personal tolerance threshold during the second training
c
ontraction; this operation is then repeated during each contraction until the wo
rkl
oad
reaches
the level of intensity recommended in the de
scripti
on of the single programs.
We recomm
end that you record the level of intensity reached in order to try to improve
the level of stimulation and consequently your performance.
6. Massage, winding down, active recovery impu
lse: intensity must be adjusted
gradua
lly
to massage the mu
scl
e treated. The level of intensity should be suff
ici
ent to
obtain a comfortable massage. Bear in mind that there is no need to endure high
i
ntensity levels in this case as it is meant to be a massage, meaning that intensity can be
increas
ed gradua
lly wi
thout excesses.
7. Capillarization impu
lse: increase the intensity gradua
lly
to produce constant,
visibl
e
stimulati
on of the area treated; a medium stimulation threshold is recommended, always
below the pain threshold.
Page 12
Pag
. 12 USER
MANUAL T-ONE Medi/Medi-Pro cod. do
c. MNPG06-03
10. T.E.N.S. Program
s.
The product
c
onforms to th
e 93/42/EEC direct
ive concerning med
ical devices for th
e
following program
s.
WARNING!
It must be remembered that an electronic stimulator is a very effective analge
sic
instrum
ent and that pain can indicate various types of medical conditions!
T
he Tens1 to Tens20 programs de
scri
bed in this paragraph are analge
sic. Y
ou are
ad
vis
ed to read the manual carefu
lly
before using T-ONE
.
REMEMBER THAT PAIN IS A SIGN:
consult a doctor to identify the med
ical c
ondition before using T-ONE!
TENS, an acronym standing for “transcutaneous elect
rical
nerve stimulation”, is a therapeutic
technique mainly used for analge
sic
purposes to counter the effects (usua
lly
pain) of a wide
variety
of medical conditions. For this purpose it finds app
licati
on in treating everyday a
ilm
ents
troubling mankind: neck pain, arthro
sis, myalgi
a, neuritis, back pain, periarthritis, heaviness in
legs, muscle weakness, jus
t to mention a few.
O
n an acade
mic level, TENS can be d
ivi
ded into various categories according to the
mec
han
ism
used to reduce the pain. The main types are: conventional TENS (or
fast
analge
sic)
, electro acupuncture training TENS (or
delayed analge
sic), TENS at ma
ximum
values wi
th antidro
mic acti
on and consequently an
immedi
ate local anaesthetic effect.
T
he rehab
ili
tative action of TENS is repres
ented by its power to reduce pain thereby restoring
ph
ysiological c
onditions; more often than not this allows the patient to regain normal motor
function. Consider a patient suffering from
irri
tating periarthritis; they either resort to using
analge
sics
or learn to
live wi
th the pain that often makes even the
simplest movem
ents
impossibl
e. Immob
ility r
educes metabo
lic
act
ivity maki
ng it impo
ssibl
e to e
limi
nate algogenic
subs
tances. So a
vicious circl
e begins. In addition to relieving pain, TENS causes i
nduced
muscle stimulati
on increasing metabo
lic
act
ivity
and blood flow and improving t
iss
ue
oxygenation with an intake of nutritional substances. So the positive effect can be amplified by
combini
ng TENS wi
th mu
scle stimulati
on of the area concerned.
Position of electrodes and intensity levels.
T
he electrodes should be positioned to form a square surrounding the painful area using
C
hannel 1 and Channel 2 as shown in
illustrati
on 1. The intensity should be adjusted to a level
between the thresholds of perception and pain: the ma
ximum i
ntensity level is the moment in
whic
h the mu
scles surr
ounding the area treated begin to contract; over this
limit stimulati
on
does not become more effective, just more
irri
tating, so it is best to stop before that point.
illustrati
on 1
WARNING
Cr
eate a square area with the
electrodes, over the painful zone.
K
eep 4cm minimum distance
between electrodes.
Page 13
USER
MANUAL T-ONE Medi/Medi-Pro MNPG06-
03 Pag. 13
T
01 • rapid TENS
.
(Medical program)
.
Program also called conventional tens, used for analge
sic
purposes; its purpose is to induce
the organ
ism i
nto blo
cki
ng pain at the spine, in accordance with the “G
ate Control Theo
ry” by
Melzack
and Wall. Pain impulses leave part of the body (for example the hand) and run along
the nerve tracts (through sma
ll-diam
eter nerve fibres) until they reach the central nervous
system wher
e the impulses are interpreted as pain. Conventional tens activates large-diameter
nerve fibres, blo
cki
ng the path of sma
ll-diam
eter nerve fibres at the spine. So action is mainly
taken against the
sym
ptom: to
simplify i
t further, the
wir
e tran
smitti
ng pain information is
obstructed.
Tr
eatment duration should be no less than 30/40 minutes.
Convention
al tens is a current
that
can be used to treat gener
al everyday pain. The average number required to benefit
from the treatment is 10/12 per day (there are no contraindications for up to double this
amount).
T
he program has a duration of 40 minutes in a single phase. The program can be repeated at
the end of the se
ssi
on for particula
rly
pe
rsis
tent pain. The nature of the impulse means that the
patient may experience an “addictive” effect due to which the impulse
will
be felt less and
less: i
f necessary the intensity can be increased by one level to counter this effect.
Positi
on of electrodes: form a square above the pai
nfu
l area as shown in illustration
1.
T
02 • e
ndorphin
ic TENS
. (Medical program).
This
type of stimulation produces two types of effects according to how the electrodes are
positioned: positioning the electrodes in the dorsal region, see photo 08 in the positions
m
anual, promotes the endogenous production of morphine
-like subs
tances capable of ra
isi
ng
the pain perception threshold; positioning the electrodes to form a square above the painful
area as shown in
illustrati
on 1 produces a vascula
rizi
ng effect. Vascula
rizati
on increases
arterial flow and consequently aids the removal of algogenic substances and helps to restore
normal ph
ysiological c
onditions.
Tr
eatment duration 30 minutes in a single phase, da
ily fr
equency.
Do not position th
e electrodes close to inflamed areas.
Intensity adjusted for good so
lici
tation of the part stimulated, the sensation must be
similar
to
that of a massage.
Page 14
Pag
. 14 USER
MANUAL T-ONE Medi/Medi-Pro cod. do
c. MNPG06-03
T
03 • TENS
sequential.
(Medical program)
.
T
he action of this program is very
similar
to the one of T01 program. During stimulation, this
program modifies by itself the frequency and impulse width so to contrast the habit at the
stimulati
on (no need to continuou
sly
adjust the intensity value). Select the intensity at the
beginning of the program and maintain it t
ill
the end of the program. In the event during the
program current perception decreases a lot, do not increase intensity value and wait t
ill
the
end of therapy. TENS program is worki
ng prope
rly
.
Program duration: 20 minutes for each phase. Intensity: set above the threshold of perception.
Positi
on of electrodes: form a square on the painful area as shown in
illustrati
on 1 or see
pictures from 25 to 33.
T04• TENS at maximum values
.
(Medical program)
.
Very shor
t duration, 3 minutes. Blocks
pain impulses periphera
lly cr
eating a proper
anaesthet
isi
ng effect in the area treated. This type of stimulation is suitable for injuries or
bruises when rapid action is required. The intensity selected is the ma
ximum
tolerable value
(well i
n excess of conventional tens, and therefore with considerable contraction of the
muscles surr
ounding the area treated). That is the reason why such stimulation is undoubtedly
the least tolerated but is extremely effective. This type of stimulation is not recommended for
particula
rly sensitiv
e people and in any case the electrodes should not be positioned in
sensitiv
e areas such as the face and genitals or close to wounds.
Positi
on of electrodes: form a square above the pai
nfu
l area as shown in illustration
1.
T
05 • TENS Burst impu
lse.
(Medical program)
.
This program pr
oduces a training effect using the frequencies of conventional TENS
.
Us
eful for pain therapy. The action is
similar
to the one of endorphinic TENS, wi
th a treatment
time of 15 minutes for a phase.
Position of electrodes: form a square above the painful area as shown in
illustrati
on 1.
T
06 • Microcurre
nt
.
(Medical program)
.
T
he use of
microcurr
ent is very
similar
to conventional Tens, the only difference is the use of
the very fine elect
ric impuls
e, more suitable for the sensib
ility
of
sli
ghtly anxious people, or for
mor
e de
lic
ate parts of the body.
It can genera
lly
be applied for everyday pains, bearing in mind that you should always consult
your
doctor to identify the cause of the pain.
It is considered a good a
ll-purpos
e analge
sic curr
ent, as it does not have any side effects
(exc
ept
sli
ght
skin r
edness after long app
lications)
, and has very few contraindications (those
specifi
ed in the paragraph at the beginning).
Program duration
: 30 minutes. Intensity set above the threshold of perception.
Position of electrodes: above the painful area as shown in
illustrati
on 1.
T
07 • Vascularizati
on
.
(Medical program)
.
Has
a vascula
rizi
ng effect on the area treated. Vascula
rizati
on increases arterial flow and
cons
equently aids the removal of algogenic substances and helps to restore normal
ph
ysiological c
onditions. Do not position the electrodes close to inflamed areas.
Daily
app
licati
on is recommended, the number of app
lications is
not defined; the program can
be used to reduce pain.
Stimulati
on intensity should be between the thresholds of perception and
sli
ght d
iscomfor
t.
Program duration
: 20 minutes.
Position of electrodes: see photo 25 and 33 in the manual of positions.
Page 15
USER
MANUAL T-ONE Medi/Medi-Pro MNPG06-
03 Pag. 15
T
08 • Dec
ontracting.
(Medical program).
Program used to speed up the recovery of mu
scl
e function after intense training or strain from
work
; the effect is
immedi
ate. Adjust the intensity for moderate mu
scle solici
tation. Two
treatments per day for three or four days. Program
duration: 35 minutes. Position of
electrodes: from photo 1 to 28.
T08Decontractin
g
Electrodes positioning:
Cr
eate a square area with the electrodes, over the painful zone.
Phase1 Phase
2
T
09 •
Anti-inflammatory
.
(Medical program)
.
Program recommended for inflammatory conditions. To be applied until the inflammatory state
is less
ened (10-15 app
lications
, once a day; the da
ily tr
eatments can be doubled if required).
Identify the area to be treated and position the electrodes as shown in
illustrati
on 1. Adjust the
intensity until a tingling feeling is produced in the area treated; avoid contracting the
surr
ounding mu
scles
.
Program duration: 30 minutes.
T
10 • Neck pain / Headache.
(Medical program)
.
Specific program
for the treatment of pain in the neck area.
T
he intensity should be adjusted to a level between the thresholds of perception and pain: the
maximum i
ntensity level is the moment in which the mu
scles surr
ounding the area treated
begin to contract; over this
limit stimulati
on does not become more effective, just more
irri
tating, so it is best to stop before that point. The f
irs
t benefits can be seen after 10 to 12
treatments ca
rri
ed out on a da
ily
ba
sis
; proceed with the treatment until the
sym
ptoms pass.
Positi
on of electrodes: photo 25.
T10Neck pain/Headach
e
Eletcrodes Positioning:
Phase1 Phase
2
T
11 • Backache/Sciatic pain.
(Medical program)
.
Specific
program for the treatment of pain in the lumbar area or along the
sciatic
nerve, or
both. The intensity should be adjusted to a level between the thresholds of perception and
pain: the ma
ximum intensity level is
the moment in which the mu
scles surr
ounding the area
treated begin to contract; over this
limit stimulati
on does not become more effective, just more
irri
tating, so it is best to stop before that point. The f
irs
t benefits can be seen after 15 to 20
treatments ca
rri
ed out on a da
ily
ba
sis
; proceed with the treatment until the
sym
ptoms pass.
Program duration: 35 minutes.
Positi
on of electrodes: see
27 and 28 in the manual of positions.
T11Lumbal/sciatic pai
n
Electrodes positioning:
Phase 1 Phase
2
Page 16
Pag
. 16 USER
MANUAL T-ONE Medi/Medi-Pro cod. do
c. MNPG06-03
T
12 • Sprains / Bruises.
(Medical program)
.
T
he program develops its effectiveness after this type of injury by inhibiting pain loca
lly
,
producing three selectively acting, differentiated impulses. The intensity should be adjusted to
a level between the thresholds of perception and pain.
Number
of treatments: until pain is lessened, on a da
ily
ba
sis (ev
en 2/3 times a day).
T12Sprain
s
/
Bruise
s
Electrodes positioning:
Phase 1 Phase
2
T
13 • Hand and wrist pain.
(Medical program)
.
This program is sui
table for all types of hand and
wris
t pain: aching caused by strains, arthritis
i
n the hand, carpal tunnel syndrome, etc. Total program duration: 40 minutes. A combination of
various
types of square-wave impulses has a general analge
sic
effect on the area to be
treated
(impulses
at different frequencies stimulate different
siz
ed nerve fibres promoting an
inhibitory
action at spinal level). The intensity should be adjusted to a level between the
thresholds of perception and pain, without causing mu
scle c
ontraction:
Position of electrodes: form a square above the area to be treated as shown in
illustrati
on 1.
T13Handand wrist pai
n
Electrodes positioning:
Phase 1 Phase
2Ph
ase
3
T
14 • Plantar stimulation
.
This program
has a relaxing and draining effect on the
limb stimul
ated. It is ideal for people
s
uffering from a sense of “heaviness in the legs”.
Durati
on: 40 minutes. Intensity: just above the threshold of perception.
Position of electrodes: 2 electrodes (one positive, the other negative) on the sole of the foot,
one close to the toes, the other under the heel.
T14Plantar stimulatio
n
Phase 1 Phase
2Ph
ase
3
T
15 • Epicond
ylitis.
(Medical program)
.
Also known as “tennis elbow”, it is an insertional tendinopathy concerning insertion of the
elbow bone into the epicondylar mu
scles
, those enabling finger and
wris
t extension (bending
ba
ckwards)
. 15 app
lications
once a day (even t
wice)
, until the
sym
ptoms pass. We
recomm
end that you consult your doctor to identify the pre
cise caus
e of the pain in order to
prevent the condition from reoccu
rri
ng.
Program duration 40 minutes, intensity adjusted above the threshold of perception.
Position of electrodes: photo 29.
T15Epicondyliti
s
Electrodes positioning:
Phase1 Phase
2Ph
ase
3
Page 17
USER
MANUAL T-ONE Medi/Medi-Pro MNPG06-
03 Pag. 17
T
16 • Epitro
clea.
(Medical program)
.
Also known as “golfing elbow”, it affects golfers but also those who ca
rry
out repetitive ta
sks or
ta
sks involvi
ng frequent intense strain (for example ca
rryi
ng a particula
rly
heavy suitcase). It
causes
pain in the flexor and pronator tendons inserted in the epitroclea. Pain is felt when
bending or straightening the
wris
t against re
sis
tance, or when clenching a hard rubber ball in
the hand. 15 app
lications
once a day (even t
wice)
, until the
sym
ptoms pass. We recommend
that you consult your doctor to identify the pre
cise caus
e of the pain in order to prevent the
c
ondition from reoccu
rri
ng.
Program duration 40 minutes, intensity set above the threshold of perception.
Position of electrodes: photo 29 but with all of the electrodes positioned on the inside of the
arm
(wi
th a rotation of about 90°).
T16Epitrocle
a
Electrodes positioning:
Phase 1 Phase
2
T
17 • Periarthritis.
(Medical program)
.
Scapulo-humeral periarthritis is an inflammatory condition affecting the fibrous t
issues
surr
ounding joints: tendons, serous sacs and connective t
iss
ue. These appear altered and
c
an break into fragments and ca
lcify
. If neglected, this condition can become hea
vily crippli
ng.
For
this reason, after ca
rryi
ng out a
cycl
e of 15/20 app
lications
once a day, we recommend
that you consult your doctor for a
cycl
e of specific rehab
ili
tation exe
rcises
to reduce the pain.
T
he Tens17 program con
sists
of various phases including Tens and mu
scle stimulati
on aimed
at improving the tone of the mu
scles surr
ounding the joint.
Program duration 41 minutes, intensity set above the threshold of perception with small
muscle c
ontractions at the end of the program (10 minutes before the end).
T17Periarthriti
s
Electrodes positioning:
Phase 1 Phase
2Ph
ase
3
T
18 • Heaviness in legs.
This
program is used to improve blood flow and mu
scl
e oxygenation speeding up the
e
limi
nation of lactic acid (produced after anaerobic se
ssions
for mu
scl
e definition), reducing
sor
eness and the
risk
of contractures. Thanks to this program the mu
scl
e treated
will
be ready
for a new training se
ssi
on or competition much more qu
ickly
.
Program duration: 25 minutes. Recommended initial intensity: mediu
m-low
, enough to
produce good movement of the part treated; increase intensity progre
ssively
until the mu
scl
e
treated is subjected to a strong massage.
Positi
on of electrodes: see
s 01 to 20 in the manual of positions.
T18Heaviness in leg
s
Electrodes positioning:
Phase 1 Phase
2Ph
ase
3
Page 18
Pag
. 18 USER
MANUAL T-ONE Medi/Medi-Pro cod. do
c. MNPG06-03
11. RE
HAB Programs.
R
01/R02 • I
onophoresis 1 / I
onophoresis 2.
(Medical program)
.
Ionophore
sis is
an electrotherapic technique that uses continuous current to ca
rry drugs i
nto
painful area or contracture area. Ionophore
sis m
eans “ions transport”: through continuous
curr
ent, active pharmacologic ions are d
riv
en through the
ski
n. Electric curr
ent favours drugs
penetration into the ce
lls
, and at the same time it stimulates the e
limi
nation of metabo
lic sl
ag.
T
he drug can have negative polarity, positive polarity or double polarity. The current induce the
drug to run from one pole to the other, cro
ssi
ng the painful area and releasing the specific
active ingredient.
WARNING:
before starting the therapy, wet the sponge electrodes and
wri
ng them so to avoid
dripping, then put the drug on the electrode as follow:
• Act
ive polarity drug: d
issolv
e this drug on the electrode connected to positive pole
(r
ed connector)
• Negat
ive polarity drug: d
issolv
e this drug on the electrode connected to negative
pole (black connector)
• Doub
le polarity drug: can be d
issolv
ed on positive pole or negative pole without
distinction.
Position the electrode with the drug on pai
nfu
l area, and the
other
electrode
hori
zont
ally.
Program duration: 20 minutes. Select channel 1 or channel 2 (select both channel only if you
need to stimulate two different areas). Position the electrodes (positive and negative)
ho
riz
onta
lly
to the treatment area. Channel 3 and channel 4 are d
isc
onnected. Set up an
i
ntensity value so to have “pins and needles” on treatment area. At the end of the program, the
skin could li
ghtly turn bright red; the reddening usua
lly vanishi
ng few minutes after the end of
program.
Program 1 wo
rks
at 1000 Hz, program 2 wo
rks
at 1500 Hz. Program
2 has a stronger action in
carry drugs tr
ough
ski
n than program 1, but also has a higher probab
ility
of
skin r
eddening. Do
not u
se i
onophoresis program near met
allic prosthesis.
R
03 • Atr
ophy preventi
on
.
(Medical program)
.
Program created to maintain mu
scl
e troph
ism
.
This tr
eatment concentrates on mu
scl
e toning, paying particular attention to slow-twitch fibres.
Particularly indic
ated for patients recovering from an a
cci
dent or an operation. Prev
ents the
r
eduction of mu
scl
e troph
ism caus
ed by ph
ysical inactivity. T
he mu
scl
e area concerned can be
stimul
ated with da
ily
app
lications
of medium intensity; if you increase the intensity, leave a
day of rest between app
lications
to allow the mu
scles
to recover. The intensity of this program
Page 19
USER
MANUAL T-ONE Medi/Medi-Pro MNPG06-
03 Pag. 19
mus
t be adjusted to produce good mu
scle c
ontraction in the area treated. Position of
electrodes from photo 1 to photo 20.
Program duration: 30 minutes.
R03Atrophy preventio
n
Phase 1 Phase
2Ph
ase
3Ph
ase
4
R
04 • Atr
ophy-trophism rehab
ilitation.
(Medical program)
.
This program acts selectively
on slow-twitch fibres. Ideal for recovering mu
scl
e troph
ism
after
a long period of inact
ivity or
an a
cci
dent.
Program to be ca
rri
ed out when loss of mu
scl
e tone has already occurred. Apply with caution
(
at low intensity, enough to produce light mu
scle c
ontractions) in the f
irs
t 2/3 weeks. Increase
i
ntensity progre
ssively
over the next 3/4 weeks. App
licati
on on alternate days. Position of
electrodes from photo 1 to photo 20.
Program duration: 30 minutes.
R04Atroph
y
Phase1 Phase
2
Phase
3
R
05 • Sequential
ton
ic c
ontractions 1.
This program increases microcirculati
on within and around the mu
scl
e fibres treated creating
rhythmic c
ontractions, fostering better drainage and toning. It can also be applied to older
people to improve blood and
lym
phatic
circulati
on in the lower
limbs (
e.g. app
lyi
ng
CH
1
to the
ri
ght calf,
CH
2
to the left calf,
CH
3
to the right thigh,
CH
4
to the left thigh).
Thes
e programs can be ca
rri
ed out using self-adhe
siv
e electrodes. Stimulation intensity must
be suff
ici
ent to produce good mu
scle c
ontractions during the treatment but not enough to
caus
e any soreness. It mainly wo
rks
on slow-twitch fibres.
Page 20
Pag
. 20 USER
MANUAL T-ONE Medi/Medi-Pro cod. do
c. MNPG06-03
R05sequentialtoniccontractions1
Muscles:
Phase 1 Phase
2Ph
ase
3Ph
ase
4
R
06 • Sequential phasic c
ontractions 2.
This program pr
oduces rhyth
mic c
ontractions with a stimulation frequency typical of fast-twitch
fibres. Thanks to the high stimulation frequency it is suitable for increasing mu
scle str
ength
s
equentia
lly
.
T
he programs produce sequential pha
sic c
ontractions on four channels. Stimulation intensity
mus
t be suff
ici
ent to produce good mu
scle c
ontractions during the treatment but not enough to
caus
e any soreness.
Unlik
e the previous program, this one uses a higher stimulation frequency during the
c
ontraction phase and therefore wo
rks mainly
on fast-twitch fibres.
R06Sequential prasicontractions2
Muscles:
Phase1 Phase
2
Phase
3
Phase
4
R
07 • Stress inc
ontinen
ce.
(Medical program)
.
Program duration 9 minutes (two phase 4+5 minutes), intensity set above the threshold of
perception to produce light internal stimulation.
This program
, for which no photographs are provided regarding the position of the electrodes,
r
equires the use of appropriate internal stimulation probes, supplied separately together with
the relative instructions. We recommend to consult your doctor before using this program.
R
08 • Urgency inc
ontinen
ce.
(Medical program)
.
Program duration 9 minutes (two phases 4+5 minutes), intensity set above the threshold of
perception to produce light internal stimulation.
This program
, for which no photographs are provided regarding the position of the electrodes,
r
equires the use of appropriate internal stimulation probes, supplied separately together with
the relative instructions. We recommend to consult your doctor before using this program.
WARNING: on program R07 and R08, we suggest to use certified probes
(class
IIa medical
de
vices). D
atasheet of the probes must contains how to use informations, storage and
cl
eaning precautions and any other useful informations
R
09 • Haematom
as.
(Medical program)
.
Consul
t a doctor before using this program to treat haematomas. Total program duration: 20
mi
nutes. Few app
lications carri
ed out within a few hours of the bruise. A combination of
various
types of square-wave impulses has a graduated draining effect on the area to be
treated
(impulses
at different frequencies drain the area at different depths). The intensity
s
hould be adjusted to a level between the thresholds of perception and pain, without causing
Page 21
USER
MANUAL T-ONE Medi/Medi-Pro MNPG06-
03 Pag. 21
muscle c
ontraction. Position of
electrodes: form a square above the area to be treated as
shown in illustrati
on 1.
12. Fitness program
.
IMPORTANT
. Intensity of stimulation: fi
tness programs
(Firmi
ng up, Toning up, Strength,
Resis
tance/Endurance, Agonist/Antagonist) are d
ivi
ded in 3 phases: warm up phase, work
phase, recovery phase. During warm up phase (phase1) the intensity of stimulation has to be
s
etted so to produce a reasonable so
lici
tation of the mu
scl
e, so to warm it up without getting
tired (18÷30mA). During work phases (the middle phases of each program), T-ONE alter
nates
c
ontraction impulses with active recovery impulses. The intensities of the two impulses have to
be setted separately: contraction intensity (shown by a full bar on the display) should be setted
at 20÷30mA
for out of train people, 30÷50mA
for trained people, over 50mA
for well trained
people.
We s
uggest to set recovery intensity value (between one contraction and another) around
15÷20% lower than contraction intensity value. During the last recovery phase, the intensity
val
ue has to be setted to produce a good massage on the stimulated part, without produce
pain (18÷30mA).
F
01 • Firming up
.
Indicated for f
irmi
ng up mu
scles i
n the a
rms
and bust, or the legs ; wo
rki
ng mainly on slo
w-
twitch fibres. Suitable for those who have never done any ph
ysical
act
ivity
or have been
inactiv
e for a long period of time. Method of use:
1. identify the mu
scl
e to be treated. To obtain good results it is best to treat just a few
muscles
at a time and complete the process de
scri
bed below;
2. position the electrodes as shown in the photo;
3. increase the intensity until the impulse can be felt (use a low intensity for the f
irs
t
sessi
on to help you understand how the machine wo
rks)
;
4. during the program and over the next few days the intensity should be increased
gradua
lly s
o that mu
scle c
ontractions are not painful;
5. during machine contractions, contract the mu
scle vol
unta
rily
;
6. a
cycl
e of 15/20 app
lications mus
t be completed before the f
irst results c
an be seen;
one app
licati
on for each mu
scl
e every two days with a day of rest in between.
It is po
ssibl
e to work on pa
irs
of mu
scles
, for example thighs and abdominal mu
scles
, treating
one set one day and the other the next day. Wo
rki
ng on too many mu
scles
at the same time is
not recommended. A bit at a time but con
sis
tently!
F01Firming u
p
Phase1 Phase
2
Phase
3
Phase
4
Page 22
Pag
. 22 USER
MANUAL T-ONE Medi/Medi-Pro cod. do
c. MNPG06-03
F
02 •
Toning up
.
Indicated for toning up mu
scles i
n the a
rms
and bust, or the legs; wo
rki
ng mainly on fast-twitch
fibres. Suitable for people who already practice moderate ph
ysical activity. M
ethod of use:
1. identify the mu
scl
e to be treated. To obtain good results it is best to treat just a few
muscles
at a time and complete the process de
scri
bed below;
2. position the electrodes as shown in the photo;
3. increase the intensity until the impulse can be felt (use a medium intensity for the
f
irst sessi
on to help you understand how the machine wo
rks)
;
4. during the program and over the next few days the intensity should be increased
gradua
lly
to produce marked mu
scle c
ontractions;
5. during machine contractions, contract the mu
scle vol
unta
rily
;
6. a
cycl
e of 15/20 app
lications mus
t be completed before the f
irst results c
an be seen;
one app
licati
on for each mu
scl
e every two days with a day of rest in between.
It is po
ssibl
e to work on pa
irs
of mu
scles
, for example thighs and abdominal mu
scles
, treating
one set one day and the other the next day. Wo
rki
ng on too many mu
scles
at the same time is
not recommended. A bit at a time but con
sis
tently!
F02Toning u
p
Phase1 Phase
2
Phase
3
Phase
4
F
03 • Basic strength
.
T
he Ba
sic str
ength program is used in sport to develop ba
sic str
ength of a mu
scl
e. The
c
ontractions alternate with periods of active recovery during the work phase, allowing the
muscl
e to be trained without subjecting it to stress and improving oxygenation of the same
muscl
e. The following ba
sic proc
edure
will
enable you to obtain the f
irst results
: two se
ssions
per week (for each mu
scle region)
for the f
irs
t three weeks at medium/low intensity, three
sessions
per week for the next three weeks at high intensity.
Intensity must be increased gradua
lly tr
eatment by treatment. Suspend training for a few days
i
n the event of fatigue and proceed with the “F09 Recove
ry” program
.
F03Basic strengt
h
Phase1 Phase
2
Phase
3
Phase
4
Page 23
USER
MANUAL T-ONE Medi/Medi-Pro MNPG06-
03 Pag. 23
F
04 • Fast strength (Speed)
.
This program is
designed to increase speed in fast athletes and develop it in athletes la
cki
ng
the quality.
T
he exe
rcis
e assumes a fast pace and the contraction is short, as is the recovery. It is usua
lly
best to complete a three-week ba
sic str
ength
cycl
e of increasing intensity before using this
program. Then continue with three weeks of fast strength three times a week at high intensity
(30÷50mA)
, almost past endurance during the contraction.
F04Fast strengt
h
Phase1 Phase
2
Phase
3
Phase
4
F
05 • Explosive strength
.
Explo
sive str
ength programs increase the explo
siv
e power and speed of the mu
scle mass
,
wi
th extremely short, strengthening contractions and very long active recovery times to allow
the mu
scl
e to regain strength. It is usua
lly
best to complete a three-week ba
sic str
ength
cycl
e
of increasing intensity before using this program. Then continue with three weeks of explo
siv
e
str
ength t
wic
e a week. During the contraction, the intensity must be the highest that can be
endured in order to obtain ma
ximum muscl
e exertion wh
ilst involvi
ng the greatest number of
fibres (over 35mA).
F05Explosivestrengt
h
Phase1 Phase
2
Phase
3
Phase
4
F
06 • Resistant strength (Long effort)
.
This
program is designed to help increase re
sis
tance to ph
ysical stress
, or rather withstand
i
ntense exertion for a longer amount of time in mu
scle regions subjec
ted to stimulation.
Indicated for sporting d
isciplines involvi
ng long, intense periods of exertion.
Stimulati
on intensity during the contraction: start with a low level of intensity, increasing it
gradua
lly. For
practised athletes the intensity used should be enough to produce
visibl
e
muscle c
ontractions.
In the event of mu
scl
e ache after stimulation, use the “F09 Recove
ry” program
.
Page 24
Pag
. 24 USER
MANUAL T-ONE Medi/Medi-Pro cod. do
c. MNPG06-03
F06Resistantstrengt
h
Phase1 Phase
2
Phase
3
Phase
4
F
07 • Resistance/Endurance.
T
he Re
sis
tance program is used in sports to increase mu
scle resis
tance, acting mainly on
slow-twitc
h fibres.
Program indicated for endurance sports: marathon runners, cro
ss-c
ountry
skiers, ironm
an, etc.
Program duration: 50 minutes. Stimulation intensity during the contraction: if not particula
rly
fit, start with a low intensity then increase gradua
lly
. For practised athletes the intensity used
s
hould be enough to produce
visible muscle c
ontractions. In the event of mu
scl
e ache after
stimulati
on, use the “F09 Recove
ry” program
.
F07Resistance/Enduranc
e
Phase1 Phase
2
Phase
3
Phase
4
F
08 • Capillarization.
This
program significantly increases arterial flow in the area treated. Prol
onged use of this
program develops the intramuscular cap
illary
network of fast-twitch fibres. The effect obtained
is
an increase in the capacity of fast-twitch fibres to withstand strain over extended periods of
time.
For
an athlete with good re
sis
tance, the cap
illarizati
on program is very useful for recovery after
i
ntense aerobic work, before anaerobic work and when training is not po
ssible (
due to bad
w
eather or an inju
ry). Program duration: 30 minutes / one phase. Recommended stimulation
intensity: medium. Position of
electrodes: see photos 01 to 20 in the manual of positions in
relati
on to the area that you
wis
h to stimulate.
Page 25
USER
MANUAL T-ONE Medi/Medi-Pro MNPG06-
03 Pag. 25
F
09 • Muscle recovery.
C
an be used for all sports, after competitions or the most demanding training se
ssions, i
n
particular after long and intense exertion. To be used
immedi
ately after exertion. Helps
drainage and winding down, improving mu
scl
e oxygenation and helping to d
ischar
ge synthetic
subs
tances produced during exertion. Program
duration: 15 minutes. Stimulation intensity:
medium-low (15÷25mA), increas
ed during the last 5 minutes.
Position of electrodes: see photos 01 to 20 in the manual of positions in relation to the area
that you
wis
h to stimulate.
F
10 •
Agonist
/
Antagonist
.
T
he electronic stimulator produces contractions alternated between 4 channels: during the f
irs
t
phase of wa
rm-
up the 4 channels work
simul
taneou
sly
, during the second work phase (20
mi
nutes) mu
scle c
ontractions are alternated between Channel 1 and 2 (agonist mu
scles)
and
C
hannel 3 and 4 (antagonist mu
scles). T
he program is designed to restore mu
scl
e tone to the
quad
riceps
and its antagonist the leg biceps, or the biceps brachii and the t
riceps
. The work
a
ims
at developing strength. With this program, mu
scle relaxati
on is obtained by
simul
taneous
stimulati
on from 4 channels during the last 10 minutes.
Stimulati
on intensity during the contraction: enough to produce good mu
scle c
ontraction +
vol
untary contraction to reduce the sense of d
iscomfor
t and reach higher intensities. Intensity
mus
t be increased gradua
lly tr
eatment by treatment, without overstraining the mu
scles
. In the
event of mu
scl
e ache after stimulation, use the “F09 Recove
ry” program
.
F10Agonist/ Antagonis
t
Phase1 Phase
2
Phase
3
F
11 • Lipolysis.
These specific drai
nage program increase
microcirculati
on within and around the mu
scl
e fibres
treated and create rhyth
mic c
ontractions, fa
cili
tating the d
ischar
ge of algogenic substances
and promoting
lym
phatic act
ivity
. It can also be applied to older people to improve blood and
lym
phatic
circulati
on.
T
he program produces sequential tonic contractions (before CH1 and CH2 after CH3 and
CH4), repr
oducing the typical effect of electronic
lym
phatic drainage.
Ther
e are no real
limits
of app
licati
on for this program, which can be practiced until the de
sir
ed
resul
t has been achieved.
Stimulati
on intensity must be suff
ici
ent to produce good mu
scle c
ontractions during the
treatment but not enough to cause any soreness. Duration 30 minutes.
T
he f
irst results c
an usua
lly
be seen after 3/4 weeks pract
ici
ng 4/5 se
ssions
a week.
Page 26
Pag
. 26 USER
MANUAL T-ONE Medi/Medi-Pro cod. do
c. MNPG06-03
F11Lipolysi
s
Upper
muscles
Lower
muscles
Phase1 Phase
2
Phase
3
F
12 • Drain up
.
Thes
e programs have specific draining purpouse, increasing the
microcirculati
on inside and
around treatened muscular fibers, also creating rhyth
mic c
ontractions, to fa
cili
tate the flow of
algogene substances and
lym
phatic act
ivity. This program c
an be useful for elde
rly
people, to
aid blood
circulati
on and
lym
phatic
circulati
on.
O
n phase 2 and 3, the programs produce sequential tonic contractions able to produce the
typical effect of electronic
lym
phatic massage. However, un
lik
e of lipo
lysis program, i
n drain up
program the contraction are sequential: start on CH1, then CH2, CH3, CH4.
Ther
e are no real app
licative limits
for the use of these programs, so they can be used t
ill
the
achievement of de
sir
ed result.
T
he intensity of stimulation has to be strong enough to assure good muscular contractions
during treatment, but not so strong to generate stiffness (20÷30mA).
Normally
, the results appear after 3/4 weeks, with 4/5 treatment a week.
F12Drainu
p
Muscles:
Phase1 Phase
2
Phase
3
Phase
4
F
13 • Microlifting
.
T
he following program, with a duration of 15 minutes, is used to tone facial mu
scles usi
ng a
special impuls
e to improve both the appearance and the dyna
mism
of facial mu
scles
.
T
he position of the electrodes is shown in the manual of electrode positions (photo 24).
N.B
. a minimum distance of 3 cm. must be kept between the electrode and the eyeball.
IMPORTANT:
take care when adjusting the intensity as facial mu
scles
are particula
rly
sensitiv
e; intensity should be increased gradua
lly, starti
ng with a very low level of stimulation
(jus
t above perception) and increasing with extreme care until you reach a good level of
stimulati
on, represented by good mu
scl
e activation.
IMPORTANT: it is
not necessary to reach levels of intensity capable of causing d
iscomfor
t!
T
he equation “more pain = more gain” is completely
misl
eading and counterproductive.
Great and significant results are obtained through con
sis
tency and patience.
Page 27
USER
MANUAL T-ONE Medi/Medi-Pro MNPG06-
03 Pag. 27
13. T-ONE MEDI PRO:
programmable memories
.
Operative instructions reserved to medical pers
onn
el or
therapist
s.
1. Switc
h on T-ONE k
eeping pressed key for at least 1 second.
2. Select MEM on menu, pre
ssi
ng 3 times key .
3. Proc
eed on choosing the de
sire memory usi
ng keys .
4. Press key
to enter selected memory and change the stimulation parameters.
M
01/M02 • TENS memor
y 1/2
.
(Medical program)
.
Available programs to set Rapid tens, endorphinic tens, ma
ximum values, microcurr
ent.
Positi
on of electrodes: form a square on the painful area as shown in
illustrati
on 1.
• Use keys
to move through the menu and select the stimulation parameter, use
keys
to modify the values.
• S
et all stimulation parameters, position the cursor over OK
to store the program.
• To star
t the stored program, press key .
• A
three sound signal
will
ad
vis
e of the end of the program.
Page 28
Pag
. 28 USER
MANUAL T-ONE Medi/Medi-Pro cod. do
c. MNPG06-03
Settab
le values chart:
PARAMETER DESCRIPTION MIN MAX
Fr
equency 1 Hertz 120 Hertz
Impulse width 20
microsec
. 450
microsec
.
T
otal time 1 minute 60 minutes
M
03 • EMS 1 sec
ond
slope.
EMS
1 sec. slope: to set EMS program with 1 second impulse slope.
• Use keys
to move through the menu and select the stimulation parameter, use keys
to modify the values
• S
et all stimulation parameters, position the cursor over OK
to store the program
• To star
t the stored program, press key .
•
A
three sound signals
will
ad
vis
e of the end of the program.
Settab
le values chart:
PARAMETER DESCRIPTION MIN MAX
C
ontraction frequency 20 Hertz 120 Hertz
C
ontraction time 2 seconds 10 seconds
Recovery fr
equency 1 Hertz 12 Hertz
Recovery tim
e 2 seconds 20 seconds
Impulse width 60
microsec
onds 450
microsec
onds
T
otal time 1 minute 60 minutes
IMPORTANT:
using 1 second slope the contraction
will
be faster, while with 2/3
sec
onds slope we obtain more progre
ssive c
ontraction. Particula
rly
for memory 5, with 3
sec
onds slope, we obtain a “triangular” impulse where the impulse parameters are
c
ontinuou
sly vari
ed. This program is particula
rly sui
table for partia
lly
denervated mu
scles
.
Page 29
USER
MANUAL T-ONE Medi/Medi-Pro MNPG06-
03 Pag. 29
M
04 • EMS 2 sec
ond
s slope.
EMS
2 sec. slope: to set EMS program with 2 second impulse slope.
Settab
le values chart
PARAMETER DESCRIPTION MIN MAX
C
ontraction frequency 20 Hertz 120 Hertz
C
ontraction time 4 seconds 10 seconds
Recovery fr
equency 1 Hertz 12 Hertz
Recovery tim
e 2 seconds 20 seconds
Impulse width 60
microsec
onds 450
microsec
onds
T
otal time 1 minute 60 minutes
M
05 • EMS 3 sec
ond
s slope.
EMS
3 sec. slope.: to set EMS program with 3 second impulse slope.
Settab
le values chart
PARAMETER DESCRIPTION MIN MAX
C
ontraction frequency 20 Hertz 120 Hertz
C
ontraction time 6 seconds 10 seconds
Recovery fr
equency 1 Hertz 12 Hertz
Recovery tim
e 2 seconds 20 seconds
Impulse width 60
microsec
onds 450
microsec
onds
T
otal time 1 minute 60 inutes
14. SET UP
S
electing the la
nguag
e and c
ontrast level on the display.
Turn T-ONE on using the button and
immedi
ately after keeping pressed the button
until the language
lis
t appears on the display. Release the button: now use the mouse to
mov
e the cursors and choose the de
sir
ed language or the level of contrast on the display.
Selec
t the chosen language by using the buttons.
Adjus
t the level of contrast on the display by using the buttons.
Press to conf
irm your selections
.
Page 30
Pag
. 30 USER
MANUAL T-ONE Medi/Medi-Pro cod. do
c. MNPG06-03
15. Self-adhesive electrodes.
T
he position of the electrodes is shown in the manual of electrode positions.
T
he electrodes supplied are top quality, pre-gelled and ready for use, they are particula
rly
sui
table for electrostimulation treatments.
They are very flexible maki
ng it easy to treat all areas. Remove the protective plastic from the
electrode before use, position it on the
ski
n as shown in the manual and replace the plastic
after use.
Electrode duration is dete
rmi
ned by the
skin’s pH val
ue; we recommend no more than 10/15
app
lications usi
ng the same electrode.
R
epeated use of the same electrodes can compro
mise stimulati
on safety, which is why
electrodes must not be used when they no longer st
ick
to the
ski
n; in fact it can cause
ski
n
r
edness that can last for many hours after stimulation. Consult a doctor if this occurs.
16. Technical specifications.
Risk class
:
Class
II in accordance with the 93/42/EEC directiv
e.
Insulation class: Interna
lly
powered de
vice wi
th type BF
applied parts, in accordance with
the CEI EN 60601-1 standard.
Classificati
on: IP30, based on the penetration of liquids and powder; equipment not
protected.
Housi
ng:
ABS
.
Power S
upply: 4 AA Alkali
ne batteries 1,5V, or 4 AA Ni/Mh batteries 1.2V.
Average
consumpti
on: 1 W.
L
imi
tations: equipment not suitable for use in en
vironm
ents with a high concentration
of oxygen and/or flammable liquids and/or flammable gas; do not use with
equipment for electrosurgery or short-wave or
microwav
e therapy.
Operati
on: equipment suitable for continuous operation.
O
utput channel: 4 channels, independent and galvanica
lly isol
ated.
O
utput current: peak to peak 218mA maximum
power, 31mA max
, effective per single
c
hannel with load from 200 ohm to 1Kohm.
Ty
pe of impulse: rectangular and compensated bipha
sic rec
tangular.
Fr
equency: operates with a range of impulses from 0,5 Hz to 1500 Hz.
Impulse amplitude: from 40µs
to 900µs (sum
of the two se
mi-impulses)
.
Display
:
reflectiv
e LCD display, 128x64 pixel.
C
ontrol keypad: 10-key soft-touch keypad.
Dimensions
: 125 x 76 x 34 mm
Wei
ght: 280 gr. including batteries.
B
attery charger: see charger instruction.
Mai
ntenance
and storage:
r
efer to the instructions in Chapter 8 “Maintenance and storage of T-ONE“.
Page 31
USER
MANUAL T-ONE Medi/Medi-Pro MNPG06-
03 Pag. 31
Warni
ng:
the equipment de
livers curr
ent in excess of 10mA
.
Manufactured in compliance with the 93/42/EEC directive concerni
ng
medical
de
vices
17. Assistance
Every intervention on de
vice mus
t be performed by manufacturer. For any a
ssis
tance
i
ntervention contact the National
Distri
butor or the manufacturer at the following address:
I.A.C.E.R. S.r.l.
Via S. Pertini, 24/a • 30030 Martellago (VE) - Italy
Tel. +
39 0415401356 • Fax +39 0415402684
www.iacer.it • [email protected]
t
Y
ou can get any technical documentation on spare parts but only prior business autho
rizati
on.
Page 32
Loading...
