Tommee Tippee 0423708 Instruction Manual

closer to nature perfect prep machine
IMPORTANT WARNINGS - Keep this instruction sheet for future reference as it includes important information.
• Do not immerse in water.
• This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with this appliance. Cleaning and user maintenance shall not be made by children without supervision.
• Keep the appliance cord out of reach of children.
WARNING LIGHTS ACTION BUTTONS
CHANGE
FILTER
WATER TANK
HOT
WATER LEVEL
LOW
DECALC/
DESCALE
CLEANING
MODE
INSTRUCTIONS FOR USE
CLEANING
MODE
FILTER
VOLUME
RESET
DECALC/
DESCALE
WATER
HOPPER
WATER
FILTER
START / STOP
BUTTON
SETTING
DIAL
DISPENSER
DISPENSER
OUTLET
OUTLET
LIGHTS
ACTION
BUTTONS
WATER
TANK
FOR DOMESTIC USE ONLY - NOT INTENDED FOR COMMERCIAL USE
BOTTLE
STAND
1. SET UP AND CLEANING
Before first use you need to run a cleaning cycle – which should take approximately 10 minutes. You should
clean your unit as part of the set up and again whenever you replace your filter. For hygiene and safety
reasons you should always clean your unit if it has been unused or in storage for longer than 2 weeks.
1
Place a container under the dispenser outlet to capture the water used to clean the system (at least 1 litre capacity).
2 3 4
Plug in the unit, the tank empty warning light will illuminate.
With the water hopper in place (but not the filter) fill the hopper with 1 litre of freshly boiled water - HOT
WATER -
5 6 7 8
Wait for the tank empty warning light to go out. The water tank hot light will illuminate.
Press the cleaning mode button and hold for 2 seconds. The cleaning mode light will illuminate.
Wait whilst the boiled water is emptied from the tank, through the dispenser, into the container that you placed under the outlet in step 1.
The tank empty warning light will illuminate once the water has flushed through the system.
Discard the water captured in your container and replace it under the dispenser.
9a 9b 10 11
*Handling the filter cartridge by the top only:
• Remove the filter cartridge from packaging
• Remove sticker from the top of filter
• Fill a bowl with potable (drinking) water
• Fully submerge the cartridge in the water
• Gently agitate until the bubbles cease
12
Remove the water hopper and fit the filter*. Replace in the water tank.
13 14
Fill the hopper with COLD WATER. Wait for the tank empty warning
light to go out.
15
Press the start/stop button. A red light will flash.
The appliance will dispense an amount of hot water.
Press the start/stop button again. A green light will flash and an amount of water will be dispensed to finish the cycle.
FILTER
VOLUME
RESET
Press the filter volume reset button for 2 seconds to clear the memory. Discard dispensed water.
Your system is now ready to use.
