Page 1
MODULAR® DISPENSING
SYSTEMS
Page 2
MODULAR® DISPENSING SYSTEMS
with the Modular
So Many Cup Sizes...
One Indispensable Dispenser
Modular® quality, now value priced.
The Simpli-Flex® 2000 makes cup dispensing easier than ever.
One self-adjusting dispenser fits any size paper, plastic or foam cup up
to 44 oz. (130 cl). Choose from wall or stand mount,
in-counter or cabinet mount and surface mount styles.
The Simpli-Flex 2000 is built with the Modular
durability and reliability you expect.
Look for this symbol
It means there’s a
Simpli-Flex 2000
cup dispenser inside!
Modular® dispensers feature the exclusive patented Simpli-Flex® gasket.
A better gasket makes a better dispenser –
here’s why:
• Totally self-adjusting.
• Accurately dispenses paper, plastic or foam cups
up to 64 oz. (189 cl).
• One-at-a-time dispensing, every time.
• Seals cups from contamination.
• Constructed of NSF- and FDA-approved materials.
• Molded of tear-resistant silicone.
• Easy to install – it just slips on the dispenser!
• One-year warranty.
#7 Series Gaskets Designed to Dispense Soft Foam Cups
Are soft foam cups giving you a dispensing headache? Our #7 Series Gaskets are specifically
designed to gently dispense soft foam cups. These gaskets will fit on any SF2000, SF1005,
CSF1005 and ESF1005 cup dispenser and are designed to dispense cups from
8 to 44 oz. (24 to 130 cl.). Conversion kit (#1420169) includes three gaskets
and is shipped with easy to follow instructions.
Page 3
.5/.2
.5/.2
www.tomlinsonind.com
The Simpli-Flex® 2000 Cup Dispenser
The Simpli-Flex® 2000 self-adjusting cup dispenser is shipped with
three Simpli-Flex gaskets to fit any size paper, plastic or foam cup up to
44 oz. (130 cl.) or cups with a 2-1/4" – 4-5/8" (57 - 117 mm) lip diameter.
Available for in-counter/cabinet mounting or under-counter/wall mounting.
Mounting Specifications for SF2000 Cup Dispenser
23-1/32˝
(585 mm)
5-1/4˝
(133 mm)
Model # Description Dimensions
L x Dia inches (mm)
1015023 SF2000 Cup Dispenser (for in-counter/cabinet mounting) 23 x 5 (584 x 127)
1015470 ESF2000 Cup Dispenser (for under-counter/wall mounting) 23 x 5 (584 x 127)
Optional Stainless Steel Clamp Ring Case Qty. Ship Wt. (lbs./kgs.)
1019380 Stainless Steel Clamp Ring Assembly 1 .5/.2
Standard Spares
1415173 Gasket Kit (includes 5A, 5B and 5E gaskets) 1 .5/.2
1908522 5A Gasket
1915130 5B Gasket
1910110 5E Gasket
1415174 Screw Packet (for optional dispenser mounting) 1 .5/.2
1905844 Black Clamp Ring 1 .5/.2
6-3/4˝
(172 mm)
5-1/2˝
(140 mm)
MOUNTING HOLE
DIAMETER
Model # 1019380
The Simpli-Flex® 2000 Portion Cup Dispenser
The Simpli-Flex® 2000 Portion Cup Dispenser is shipped complete with three Simpli-Flex
gaskets to dispense portion cups with 1-9/16" – 2-1/3" (40 - 59 mm) lip diameter.
Dispenser available for in-counter/cabinet mounting or for under-counter/wall mounting.
Shipped 12 per case; approximate ship weight is 15 lbs. (7 kgs.).
Model # Description Dimensions
L x Dia inches (mm)
1015572 SFP2000 Portion Cup Dispenser 14 x 3 (356 x 76)
(for in-counter/cabinet mounting)
1015751 ESFP2000 Portion Cup Dispenser 14 x 3 (356 x 76)
(for under-counter/wall mounting)
Standard Spares Case Qty. Ship Wt. (lbs./kgs.)
1915669 7S Gasket 1 .5/.2
1915581 7M Gasket 1 .5/.2
1915592 7L Gasket 1 .5/.2
2
Page 4
MODULAR® DISPENSING SYSTEMS
Model # 1020609Model # 1020609
Combination Cabinet Dispensers
A popular item in convenience stores and where counter space is limited, these cabinet
dispensers combine cup, lid, domed lid and straw dispensing into one area, keeping
counters clutter free and organized. Each cabinet is shipped with Simpli-Flex®
cup dispensers for one-at-a-time dispensing of paper, plastic or foam cups up to
44 oz. (130 cl.). Cabinets can be customized to fit your needs.
Model # Description Dimensions Case Qty. Ship Wt.
D x H x W inches (mm) lbs./kgs.
1019580 Stainless Steel High-Volume Cabinet; 24-7/8 x 33-1/2 x 14-1/2 1 60/30
5 cup dispensers; (632 x 851 x 368)
4 lid and 2 straw organizers
1020384 Stainless Steel Cup/Lid/Straw Cabinet 22-1/4 x 27-3/4 x 14-1/2 1 50/25
with 4 cup dispensers on left side; (565 x 705 x 368)
Model # 1020396
lid, straw organizers on right
1020396 Stainless Steel Cup/Lid/Straw Cabinet 22-1/4 x 27-3/4 x 14-1/2 1 50/25
with 4 cup dispensers on right side; (565 x 705 x 368)
lid, straw organizers on left
1020470 Stainless Steel Cup/Straw/ 28 x 35-5/8 x 13 1 50/25
Domed Lid Cabinet with 4 cup dispensers, (711 x 905 x 330)
3 domed lid dispensers and 1 straw dispenser
1019768 Stainless Steel Lid/Straw 8 x 28 x 8 1 30/15
Cabinet; 3 lid holders, 1 straw holder (203 x 711 x 203)
Model # 1019768
Aluminum combination cabinet dispenser painted black with two CSF1004 cup
dispensers and lower lid and condiment dispenser. Ideal for coffee service stations.
1020609 Black Painted Aluminum Cabinet 20 x 22 x 7 1 25/11
(508 x 559 x 178)
Model # 1020609
Countertop cabinets featuring two Simpli-Flex® 2000 cup dispensers and built-in top
condiment and lid organizer. Black painted aluminum or stainless steel construction.
1021894 Black Painted Aluminum Cabinet 23 x 20 x 8 1 25/11
(584 x 508 x 203)
1023524 Stainless Steel Cabinet 23 x 20 x 8 1 25/11
(584 x 508 x 203)
3
Model # 1021894
Page 5
www.tomlinsonind.com
hip Wt.hip Wt.
lbs./kgs.lbs./kgs.
33/15
4/2
The Simpli-Flex® 2100 Molded Cabinet
The Simpli-Flex® 2100 Molded Cabinet includes one Simpli-Flex 2000
cup dispenser. This unit is durable – molded of heavy-duty high-impact plastic.
This stackable cabinet is great for multiple dispensing applications. Optional top
condiment and lid organizer is sold separately, complete with five compartments
and four adjustable spacers.
D x H x W inches (mm) Qty. lbs./kgs.
1015385 SF2100 Molded Cabinet 22 x 9 x 8 (559 x 229 x 203) 4 33/15
1015560 Top Condiment and 21 x 4 x 7 (533 x 102 x 178) 1 4/2
Lid Organizer
Model # Description Dimensions Case Ship Wt.
The Simpli-Flex® 2100 Series Cabinets
The Simpli-Flex® 2100 Series Cabinet Dispensers are shipped complete with
Simpli-Flex 2000 cup dispensers. These beige or black painted aluminum cabinets
have a stainless steel faceplate and are available with one, two, three or four cup
dispensers. Stainless steel cabinets are also available.
Model # Description Dimensions Case Qty. Ship Wt.
D x H x W inches (mm) lbs./kgs.
Painted Aluminum Cabinets:
1015600 SF2101 Cabinet, beige - 1 hole 25 x 7 x 8 (635 x 178 x 203) 1 12/5
1015599 SF2102 Cabinet, beige - 2 holes 25 x 14 x 8 (635 x 356 x 203) 1 17/8
1015598 SF2103 Cabinet, beige - 3 holes 25 x 21 x 8 (635 x 533 x 203) 1 22/10
1015393 SF2104 Cabinet, beige - 4 holes 25 x 28 x 8 (635 x 711 x 203) 1 25/11
1017024 SF2101 Cabinet, black – 1 hole 25 x 7 x 8 (635 x 178 x 203) 1 12/5
1016022 SF2102 Cabinet, black – 2 holes 25 x 14 x 8 (635 x 356 x 203) 1 17/8
1015778 SF2103 Cabinet, black – 3 holes 25 x 21 x 8 (635 x 533 x 203) 1 22/10
1015765 SF2104 Cabinet, black – 4 holes 25 x 28 x 8 (635 x 711 x 203) 1 25/11
Stainless Steel Cabinets:
1015936 SF2101 Cabinet, SS – 1 hole 25 x 7 x 8 (635 x 178 x 203) 1 12/5
1015909 SF2102 Cabinet, SS – 2 holes 25 x 14 x 8 (635 x 356 x 203) 1 17/8
1015904 SF2103 Cabinet, SS – 3 holes 25 x 21 x 8 (635 x 533 x 203) 1 22/10
1015935 SF2104 Cabinet, SS – 4 holes 25 x 28 x 8 (635 x 711 x 203) 1 25/11
Model # 1015778
Optional painted colors are red, white and gray.
Contact factory for availability and lead times.
Minimum order or setup charge may apply.
See page 12 for more
information regarding
condiment dispensers for
these cabinets.
Stainless steel cup dispensers are available for these cabinets.
4
Page 6
MODULAR® DISPENSING SYSTEMS
Simpli-Flex® Gasket Reference Chart
GASKET (Part #) SF2000 CSF1003 CSF1004 CSF1005 CSF1006
Cup Lip Diameter For 3.5-44 oz. cups For portion cups For 3.5-22 oz. cups For 16-44 oz. cups For jumbo cups
#1 (1905841)
#1 GASKET #3 GASKET
#3E GASKET #5A GASKET
#5B GASKET #5E GASKET
#5 GASKET
1-7/16"-2-3/8"
37mm-60mm
#3 (1904359)
2-3/8"-3-13/16"
60mm-97mm
#3E (1910115)
3-1/2"-3-11/16"
89mm-94mm
#5A (1908522)
3-1/2"-4-7/16"
89mm-113mm
#5B (1915130)
2-1/4"-3-1/2"
57mm-89mm
#5E (1910110)
4-1/4"-4-5/8"
108mm-117mm
#5 (1907797)
3-11/16"-5-1/2"
94mm-140mm
= Included with dispenser O= Optional
Simpli-Flex® Cup Dispensers for in-counter and
cabinet mounting
Self-adjusting spring loaded in-counter/cabinet mount cup dispensers.
Dispenser tube is made of stainless steel. Deluxe CSF1004 and Deluxe CSF1005
dispensers shipped with two Simpli-Flex® self-adjusting gaskets to dispense cups
from 3.5 oz. (10 cl.) – 44 oz. (130 cl.).
Model # Description Dimensions Case Qty. Ship Wt.
L x Dia inches (mm) lbs./kgs.
1007699 CSF1003 24 x 3 (610 x 76) 12 36/16
for extra small/portion cups
1015202 Deluxe CSF1004 24 x 4 (610 x 102) 6 22/10
for medium cups
Standard Spares
1904359 #3 Gasket 1 .5/.2
1910115 #3E Gasket 1 .5/.2
1905840 Black Clamp Ring 1 .5/.2
1015201 Deluxe CSF1005 24 x 5 (610 x 127) 6 26/12
for large cups
Standard Spares
1908522 #5A Gasket 1 .5/.2
1910110 #5E Gasket 1 .5/.2
1905844 Black Clamp Ring 1 .5/.2
5
1009959 CSF1006 24 x 6 (610 x 152) 6 32/15
for jumbo cups
See page 6 for mounting specifications.
Page 7
www.tomlinsonind.com
SIMPLI-FLEX® CUP DISPENSER MOUNTING CHART
CSF1003 CSF1004 CSF1005 CSF1006
4-21/32" (118 mm) 5-17/32" (141 mm) 6-23/32" (171 mm) 7-25/32" (198 mm)
A
22-1/2" (572 mm) 22-1/2" (572 mm) 22-1/2" (572 mm) 22-1/2" (572 mm)
B
3-3/32" (79 mm) 4" (102 mm) 5" (127 mm) 6-5/32" (156 mm)
C
D
3-1/2" (89 mm) 4-3/8" (111 mm) 5-1/2" (140 mm) 6-9/16" (167 mm)
Simpli-Flex® Cup Dispensers for under-counter or
surface mounting
Self-adjusting spring-loaded cup dispensers for under-counter or surface mounting. Dispenser
tube is made of stainless steel. Deluxe ESF1004 and Deluxe ESF1005 dispensers shipped with
two Simpli-Flex® self-adjusting gaskets to dispense cups from 3.5 oz. (10 cl.) – 44 oz. (130 cl.).
Model # Description Dimensions Case Qty. Ship Wt.
L x Dia inches (mm) lbs./kgs.
1003855 ESF1003 24 x 3 (610 x 76) 12 27/12
for extra small/portion cups
1007614 Deluxe ESF1004 24 x 4 (610 x 102) 12 41/19
for medium cups
1008494 Deluxe ESF1005 24 x 5 (610 x 127) 12 48/22
for large cups
1008707 ESF1006 24 x 6 (610 x 152) 6 32/15
for jumbo cups
Simpli-Flex® Cup Dispensers for
wall and stand mounting
Self-adjusting pull type cup dispensers for wall and stand mounting. Dispenser tube is
made of stainless steel. Deluxe SF1004 and Deluxe SF1005 dispensers shipped with two
Simpli-Flex® self-adjusting gaskets to dispense cups from 3.5 oz. (10 cl) – 44 oz. (130 cl).
Model # Description Dimensions Case Qty. Ship Wt.
L x Dia inches (mm) lbs./kgs.
1007516 SF1003 16 x 3-1/8 (406 x 79) 12 23/10
for extra small/portion cups
1007664 Deluxe SF1004 24 x 4 (610 x 102) 12 37/17
for medium cups
1008188 Deluxe SF1005 24 x 5 (610 x 127) 12 44/20
for large cups
1008702 SF1006 24 x 6 (610 x 152) 6 30/14
for jumbo cups
See pages 7 - 8 for mounting stands and accessories.
6
Page 8
MODULAR® DISPENSING SYSTEMS
SIMPLI-FLEX® CONE DISPENSER SELECTION CHART
CONE LIP DIAMETER DISPENSER MODEL
MIN. MAX. 1015P 1002
1015P
Model # 1905841
1002
Model # 1905842
1-3/8" (35 mm) 2-1/4" (57 mm) CAKE
1-1/2" (38 mm) 2" (51 mm) SUGAR
1-1/2" (38 mm) 2" (51 mm) WAFFLE
2-3/16" (56 mm) 3-1/16" (78 mm) CAKE
3-1/4" (83 mm) 3-3/8" (86 mm) DOUBLE
2-1/2" (64 mm) 3-5/16" (84 mm) WAFFLE
Simpli-Flex® Ice Cream Cone Dispensers
Prevent breakage, protect from contamination and keep ice cream cones fresher
with the Simpli-Flex® cone dispensers for cake, waffle and sugar cones with a
1-3/8" – 3-3/8" (35 - 86 mm) cone lip diameter. Simpli-Flex cone dispensers are
completely self-adjusting, ensuring one-at-a-time dispensing. Simpli-Flex cone
dispensers are available in heavy-duty, polished stainless steel or tough, gray tinted
plastic. Dispenser mount options include wall, stand, in-counter or under-counter.
Model # Description Dimensions Case Qty. Ship Wt.
L x Dia lbs./kgs.
inches (mm)
1003854 ESF1002 spring loaded 24 x 4 12 41/19
for medium to large cones 610 x 102
(uses gasket # 1905842)
1003846 SF1002 stainless steel tube 24 x 4 12 37/17
for medium to large cones 610 x 102
(uses gasket # 1905842)
1003848 SF1002P plastic tube 31 x 4 12 40/18
for medium to large cones 787 x 102
(uses gasket # 1905842)
1003850 SF1015P plastic tube 19 x 3-1/8 12 30/14
for small cones 483 x 79
(uses gasket # 1905841)
1007710 SF1015P-30" plastic tube 31 x 3-1/8 12 32/15
30" long tube, for small cones 787 x 79
(uses gasket # 1905841)
7
Rotary Stands
Countertop rotating stands for cup, tubular lid and ice cream cone dispensers.
Dispensers sold separately.
Model # Description Dimensions Case Qty. Ship Wt.
D x H x W inches (mm) lbs./kgs.
1003860 1007-024; 4-sided stand 13 x 42 x 13 (330 x 1067 x 330) 1 7/3
1003863 1007-624; 6-sided stand 13 x 42 x 13 (330 x 1067 x 330) 1 7/3
1009646 1007-400; 13 x 2 x 13 (330 x 51 x 330) 1 4/2
condiment caddy
w/four 1-quart inserts
Page 9
www.tomlinsonind.com
Z-Stands
Countertop Z-stands for cup, lid and ice cream cone dispensers. Made of stainless steel,
painted gray. Dispensers sold separately.
Model # Description Dimensions Case Qty. Ship Wt.
D x H x W inches (mm) lbs./kgs.
1008213 1008-20Z 24 x 29 x 11 1 6/3
for any 2 cup or lid dispensers (610 x 737 x 279)
1003865 1008-30Z 24 x 29 x 11 1 6/3
for any 3 cup or lid dispensers (610 x 737 x 279)
1009316 1008-40Z 24 x 29 x 11 1 7/3
for any 4 cup or lid dispensers (610 x 737 x 279)
1003870 1008-50Z 24 x 29 x 12 1 7/3
for any 5 cup or lid dispensers (610 x 737 x 305)
1404429 22-1008-AB suction mounting kit 1 1/.5
(Not recommended for 1008-50Z)
1003871 1009 High Volume stand 23 x 33 x 11 1 16/7
for any 8 cup or lid dispensers (584 x 838 x 279)
Grab-N-Go Cup Dispenser Kit
Designed for use at checkout registers to maximize and drive beverage sales at time of
check out. Grab-N-Go Cup Dispenser Kits include a cup dispenser and mounting hardware
to support four mounting options for attaching to walls, poles and counters. Installation
instructions are included. Cup Dispensers and Poles are sold separately.
Model # 1003865
Model # 1003871
Model # Description Dimensions Case Qty. Ship Wt.
L x Dia inches (mm) lbs./kgs.
Cup Dispensers:
1022589 SF1005 with fountain drink decal 24 x 5 (610 x 127) 1 4/2
1022590 SF1005 with coffee decal 24 x 5 (610 x 127) 1 4/2
Mounting Stands/Poles:
1021984 Stand/Pole, painted red 30" L (762) 1 4/2
1022086 Stand/Pole, painted blue 30" L (762) 1 4/2
Pull-Type Cup Dispensers
Adjustable stainless steel pull-type cup dispensers for wall or stand mounting.
Model # Description Dimensions Case Qty. Ship Wt.
L x Dia inches (mm) lbs./kgs.
1008783 1013 (small cups) 15-1/2 x 3 (394 x 76) 12 27/12
1003700 1001 (medium cups) 23-1/8 x 3-5/8 (587 x 92) 12 27/12
1003713 1002 (medium cups) 23-1/8 x 4 (587 x 102) 12 32/15
1003721 1017 (large cups) 23-1/8 x 4-3/8 (587 x 111) 12 37/17
1003725 1018 (large cups) 23-1/8 x 5 (587 x 127) 12 40/18
1003730 1020 (extra large cups) 23-1/8 x 5-13/32 (587 x 137) 6 24/11
1003692 1010 stainless 15-1/2 x 2-11/16 (394 x 68) 12 30/14
water cup dispenser
1003696 1015 stainless 15-1/2 x 3 (394 x 76) 12 30/14
water cup dispenser
1011721 WCP1003AL 15-1/2 x 3 (394 x 76) 24 30/14
plastic water cup dispenser
clear tube w/almond head
1011720 WCP1003W 15-1/2 x 3 (394 x 76) 24 30/14
plastic water cup dispenser
clear tube w/white head
See page 7 and above for optional mounting stands.
ADJUSTABLE CUP DISPENSERS
SELECTION CHART FOR
Specifications subject to change without notice.
All dimensions are for reference only.
Model # 1003713
Model # 1011720
Dispenser Cup Lip Diameter
Model # Inches (mm)
1013 2-5/16 - 2-15/16 (59 - 75)
1010 2-5/16 - 2-11/16 (59 - 68)
1015 2-1/2 - 2-15/16 (64 - 75)
1001 2-3/4 - 3-3/8 (70 - 86)
1002 3-1/4 - 3-5/8 (83 - 92)
1017 3-1/2 - 4-1/16 (89 - 103)
1018 4 - 4-3/4 (102 - 121)
1020 4-1/2 - 5-1/16 (114 - 129)
8
Page 10
MODULAR® DISPENSING SYSTEMS
ELC Cup Dispensers
Spring-loaded ELC cup dispensers with stainless steel mounting collar for counter or
cabinet mounting. Tube and collar are made of FDA-grade stainless steel.
Model # Description Dimensions Case Qty. Ship Wt.
L x Dia inches (mm) lbs./kgs.
1003755 ELC1010R (xsm cups) 23-1/2 x 2-11/16 (597 x 68) 12 30/14
1003761 ELC1015R (sm cups) 23-1/2 x 3 (597 x 76) 12 32/15
1003767 ELC1001R (med cups) 23-1/2 x 3-5/8 (597 x 92) 12 39/18
1003782 ELC1002R (med cups) 23-1/2 x 4 (597 x 102) 12 42/19
1003799 ELC1017R (lrg cups) 23-1/2 x 4-3/8 (597 x 111) 6 23/10
1003807 ELC1018R (lrg cups) 23-1/2 x 5 (597 x 127) 6 28/13
1003818 ELC1020R (xlrg cups) 23-1/2 x 5-13/32 (597 x 137) 6 30/14
ELC CUP DISPENSER MOUNTING CHART
MOUNTING
HOLE
inches/mm
MODEL NUMBER
ELC 1010
ELC 1015
ELC 1001
ELC 1002
ELC 1010 ELC 1015 ELC 1001 ELC 1002 ELC 1017 ELC 1018 ELC 1020
5”
(127 mm)
4-3/8 (112)
5-1/2 (140)
5-7/8 (149)
22-3/4”
(578 mm)
23-1/2”
(597mm)
X X X X
ELC 1017
ELC 1018
ELC 1020
6-1/2”
(165 mm)
X X
Wire Cup Dispensers
This Wire Cup Dispenser is an affordable cup dispensing solution when counter
space is at a minimum. Dispense up to five different sized paper, plastic or foam
cups. Easy adjustment — simply twist side springs to adjust. Suction feet keep
dispenser firmly in place. A top lid organizer is available and sold separately.
Model # Description Dimensions Case Qty. Ship Wt.
D x H x W inches (mm) lbs./kgs.
1020857 Wire Cup Dispenser, 3 tier 18-1/4 x 19-1/4 x 5-7/8 1 5/2
(464 x 489 x 149)
1019971 Wire Cup Dispenser, 4 tier 18-1/4 x 23-3/4 x 5-7/8 1 6/3
(464 x 603 x 149)
1023374 Wire Cup Dispenser, 5 tier 18-1/4 x 29-1/2 x 5-7/8 1 7/3
(464 x 749 x 149)
1020372 Top Lid Organizer 21-11/16 (L) x 4-13/16 (W) 1 2/1
(551 x 122)
22-3/4”
(578 mm)
23-1/2”
(597mm)
X
9
Page 11
www.tomlinsonind.com
Air Pot Stations
A one-stop shop for your coffee or tea service setup. Vacuum-formed heavy-duty organizer keeps
air pots, condiments, stir sticks and more together for quick and easy service. Each air pot station
includes stainless steel drip trays and air pot risers. Available in double or single air pot size.
Model # Description Dimensions Case Qty. Ship Wt.
D x W lbs./kgs.
inches (mm)
1023361 Double Air Pot Station 12-1/2 x 25-1/4 1 8/4
(318 x 641)
1023359 Single Air Pot Station 12-1/2 x 16-1/2 1 5/2
(318 x 419)
Countertop Adjustable Lid Dispensers
Stainless steel countertop lid dispensers with adjustable dividers for several size lids.
Available in various widths and heights.
Model # Description Dimensions Case Qty. Ship Wt.
D x H x W lbs./kgs.
inches (mm)
1004054 L200-15 4-1/2 x 7 x 15-1/2 8 35/16
3 adjustable dividers (114 x 178 x 394)
1004063 L212-15 4-1/2 x 12-1/2 x 15-1/2 1 7/3
Like the L200-15, but (114 x 318 x 394)
12-1/2” (318 mm) tall
1004056 L200-19 4-1/2 x 7 x 19 6 37/17
4 adjustable dividers (114 x 178 x 483)
1004064 L212-19 4-1/2 x 12-1/2 x 19 1 9/4
Like the L200-19, but (114 x 318 x 483)
12-1/2” (318 mm) tall
1004061 L200-22 4-1/2 x 7 x 22 6 38/17
5 adjustable dividers (114 x 178 x 559)
1004065 L212-22 4-1/2 x 12-1/2 x 22 1 10/5
Like the L200-22, but (114 x 318 x 559)
12-1/2” (318 mm) tall
1004068 L200MB 1 2/1
Mounting Bracket Kit
to mount dispenser on
fountain head or wall
Model # 1004061
Model # 1004065
Tubular Adjustable Lid Dispensers
Stainless steel tubular lid dispensers with three adjustable dividers for several size lids.
Lid dispensers can be wall or stand mounted.
Model # Description Dimensions Case Qty. Ship Wt.
L x Dia lbs./kgs.
inches (mm)
1011795 LO24 23-1/8 x 4-1/4 6 12/5
Maximum lid diameter (587 x 108)
is 4" (102 mm)
1011796 LO46 23-1/8 x 5-13/32 6 21/10
Maximum lid diameter (587 x 137)
is 5-1/4" (133 mm)
1012030 LO64 23-1/8 x 6-1/8 6 22/10
Maximum lid diameter (587 x 156)
is 5-7/8" (149 mm)
10
Page 12
MODULAR
®
DISPENSING SYSTEMS
Domed Lid Organizer
Organizes beverage cup lids used for slushies, frozen drinks, etc. One-inch
stainless steel base with rubber feet. Holds up to 200 domed lids. For on-counter
or in-counter mounting.
Model # Description Dimensions Case Qty. Ship Wt.
D x H x W
inches (mm)
1019467 Domed Lid Organizer 6-1/2 x 11-1/4 x 21-3/4 1 4/2
(165 x 286 x 552)
Straw Dispensers
Wrapped straw dispensers help reduce waste and organize space.
Stainless steel dispensers.
Model # Description Dimensions Case Qty. Ship Wt.
inches (mm)
1003989 ELC5006 5-1/2 (140) 1 2/1
for counter mount, large mounting hole
1003990 ELC9006 4-3/8 (111) 1 1/.5
for counter mount, small mounting hole
Model # 1004005
5500 Dairy Creamer Dispensers
An insulated dispenser for chilled dairy creamer packets. Refreezable cold packs
keep the creamer under 40ºF (4ºC) for up to eight hours. Available in brushed
stainless steel or beige polyurethane finish. Holds approximately 300 creamer
packets. Optional top coffee service organizer with two compartments for
organizing sugar, sweetener, powdered creamer and stir sticks is available.
Model # Description Dimensions Case Qty. Ship Wt.
D x H x W inches (mm) lbs./kgs.
1004005 5500-SS Dairy Creamer 15 x 11-5/8 x 6-5/8 1 7/3
Stainless steel w/ 2 cold packs (381 x 295 x 168)
1004002 5500 Dairy Creamer 15 x 11-5/8 x 6-5/8 1 7/3
Painted beige w/ 2 cold packs (381 x 295 x 168)
1004008 5600 10 x 4-1/2 x 6-5/8 4 8/4
Top Coffee Service Organizer (254 x 114 x 168)
1904516 17-2500 3 x 3-1/2 x 6-1/2 6 1/.5
White plastic stir stick insert (76 x 89 x 165)
1904890 Refreezable Cold Pack 12 29/13
11
Model #1004002
with 1004008
Page 13
www.tomlinsonind.com
1200 High-Volume Condiment Dispenser
Four-compartment gravity-fed condiment dispenser for high-volume use. Holds up
to 1500 condiment packets. Top-loading feature ensures product rotation. Simple
to load and clean. Painted gray aluminum construction.
Model # Description Dimensions Case Qty. Ship Wt.
D x H x W inches (mm) lbs./kgs.
1003993 1200 High-Volume 24 x 26 x 8 1 22/10
Condiment Dispenser (610 x 660 x 203)
6000 Condiment Dispensers
Four compartment condiment dispenser tray will mount on top of SF2100 Series Cabinets.
Model # Description Dimensions Case Qty. Ship Wt.
D x H x W inches (mm) lbs./kgs.
1004012 6000 Condiment Dispenser 24 x 6 x 8 6 21/10
in Aluminum (610 x 152 x 203)
1010072 6000 Condiment Dispenser 24 x 6 x 8 6 21/10
in Stainless Steel (610 x 152 x 203)
1904508 White plastic quart insert 5-5/8 x 3 x 6 12 2/1
(142 x 76 x 150)
1904516 White plastic stir stick insert 3 x 3-1/2 x 6-1/2 6 1/.5
(76 x 89 x 165)
9000 Condiment Dispenser
The 9000 Condiment Dispenser features nine 1-pint inserts inside a stainless
steel body. Additional pint inserts are available. Ideal for organizing multiple
condiment and coffee service packets.
Model # Description Dimensions Case Qty. Ship Wt.
D x H x W lbs./kgs.
inches (mm)
1004017 9000 19 x 5-5/8 x 12 1 7/3
Condiment Dispenser (483 x 143 x 305)
1904512 52-1016 3 x 3 x 5-5/8 12 1/.5
White plastic pint insert (76 x 76 x 143)
for 9000 dispenser
Fits 2.7" x 5.3"
(69 x 139 mm)
mounting hole
Pint Insert #1904512
12
Page 14
MODULAR® DISPENSING SYSTEMS
In-Counter/Counter Mount
Napkin Dispensers
Model # 1010593
(in-counter)
Stainless steel spring-loaded dispensers with latched faceplate for easy and secure
closing. Mounts horizontally, vertically or diagonally in a counter or cabinet.
Dispenses one napkin at a time and accommodates 250 - 500 napkins.
Model # 1003980
(countertop)
Model # Description Dimensions Case Qty. Ship Wt.
D x H x W inches (mm) lbs./kgs.
1003971 4000-C10 6-1/2 x 10-1/2 x 8-1/4 4 19/9
Holds 250 napkins (165 x 267 x 210)
1010593 4000-C10N 6-1/2 x 10-1/2 x 8-1/4 4 19/9
Holds 250 napkins (165 x 267 x 210)
1012066 4000-C24 6-1/2 x 25 x 8-1/4 1 7/3
Holds 500 napkins (165 x 635 x 210)
1007462 4000-TC7 11 x 7-1/2 x 9 4 27/12
Countertop model (279 x 191 x 229)
Holds 250 napkins
1003980 4000-SD9 11 x 9 x 9 4 27/12
Countertop model (279 x 229 x 229)
Holds 250 napkins
w/top straw holder
Stainless Steel Trash Chutes
Designed for in-counter applications, these one-piece trash chutes are
manufactured of 22 gage, T-304 stainless steel with a highly polished lip flange.
Available in 4", 6" and 9" diameter sizes.
Model # Description Dimensions Case Qty. Ship Wt.
inches (mm) lbs./kgs.
1920105 4" Trash Chute 4-1/2 H (114) 1 1/.5
Hole Cutout:
4-3/16 - 4-7/32 (106 - 107)
1920106 6" Trash Chute 5 H (127) 1 1/.5
Hole Cutout:
5-17/32 - 5-9/16 (140 - 141)
1920107 9" Trash Chute 2-1/4 H (57) 1 1/.5
Hole Cutout:
9-1/16 - 9-3/32 (230 - 231)
13
Page 15
www.tomlinsonind.com
INDEX
Simpli-Flex® Gasket & Dispensing System ................Pg. 1
Simpli-Flex
®
2000 Products ........................................ Pg. 2
Combination Cabinet Dispensers .............................Pg. 3
Simpli-Flex
®
Cabinets & Cup Dispensers............... Pgs.4-6
Ice Cream Cone Dispensers........................................ Pg. 7
Mounting Stands................................................... Pgs. 7-8
Grab-N-Go Cup Dispenser Kit ...................................Pg. 8
Adjustable Cup Dispensers .................................. Pgs. 8-9
Wire Cup Dispensers ...................................................Pg.9
Air Pot Stations .........................................................Pg.10
Lid, Straw, Creamer & Condiment Dispensers ... Pgs. 10-12
Napkin Dispensers ....................................................Pg.13
Stainless Steel Trash Chutes ....................................Pg.13
Tomlinson Industries is
a recipient of the
President’s E-Star Award
for exporting excellence.
LIMITED WARRANTY
We guarantee to the original purchaser of each Tomlinson product that any part thereof which proves to be defective in
material or workmanship within one year – unless otherwise specified – of the date of shipment will be repaired or a
replacement part furnished F.O.B. our factory. Warranty will not apply if our examination shows product to be defective as
the result of negligence, abuse, misapplication or alteration by other than ourselves.
Tomlinson will not be responsible for unauthorized field service. Contact factory for instructions.
TERMS: Net 30 days, F.O.B. plant, Cleveland, Ohio U.S.A. Minimum order requirement is $100.00 net.
RETURNS: Return of merchandise requires an RMA number. Authorized returns are subject to handling and re-stocking charges
of 15%. Items returned to factory must have transportation charges prepaid. Custom items are not returnable.
FOR RESALE ONLY: Prices and specifications subject to change without notice. We reserve the right to correct printing errors.
Most Tomlinson
products have
been certified by
NSF International.
Page 16
13700 Broadway
Cleveland, OH 44125-1992
Phone: 216-587-3400, Ext. 224
FAX: 216-587-6192
www.tomlinsonind.com
World Class, Worldwide
© 2005 Tomlinson Industries Printed in U.S.A.Rev. 9/10
Loading...
