Tomberlin Anvil Operator's Manual
TOMBERLIN®CONSUMERDISCLAIMER
Tomberlin®reservestherighttochangethesuggestionsgainedinthisconsumersupportsite.Itis
intendedprimarilyforeducationalpurposesonly.Someexperiencedconsumersprefertodothe
maintenanceandservicethemselves,forthe"DoItYourself"owners,Tomberlinstronglyencourages
interactionwithyourlocaldealerfirstandtoneverattemptaprocedureyouareunfamiliarwithsafely
performing.Anelectricvehiclehasasignificantvoltagethatcanresultinshock,fireandinjuryifnot
performedbyaprofessional.Damagetothevehiclecanalsooccur.Someproceduresrequirespecific
torquesettingsthatwhennotfollowedcanresultindangerous,possiblylifethreateningsituations.
Manyerrorswillnotsurfaceimmediately.Theinformationhereinhasgenerallyproventoenhancethe
lifecycle,safetyandoverallownershipexperiencewhenproperlyfollowed.Tomberlinassumesno
liabilityforthecontentprovidedinthisconsumereducationalsectionanditispossiblethatanerror
withregardtospelling,grammar,nomenclature,andtranslationispresent.Notethattheinformation
providedshouldbetreatedaslivedocumentsmeaningtheyarealwaysinastateofrefinement,
correctionandimprovement.Checkbackoftenandifprinted,checkbackpriortoreliancetoassurethey
remaincurrent.Neverattempttomanipulatethevehicletoexceedthespeedasrequiredby
regulations.ThehighestspeedrangeforTomberlin®E‐Merge™PTV'sandLSV'sarefactorysetat15‐19
mphasaPTVor22‐25mphasanLSV.Consumersshouldalwaysexerciseprudentcommonsense
measures,usepropersafetygearwithtoolsdesignedspecificallyforthetask.Alwaysutilizeinsulated
toolsaroundelectricalconnections.Neverexceedyourcomfortlevelandwhenindoubt,stopandcall
yourlocaldealer.TomberlinAuthorizedDealersarealwaysyourbestresource.Ifyounoticeanerroror
haveanideathatwillimproveoureffortshere,pleaseemailyourideatoinfo@tomberlin.net.
Anvil Operator’s Manual Page 1
A N V I L
OPERATOR’S MANUAL
Electric Low-speed
Vehicle
(LSV)
Anvil Operator’s Manual Page 2
WARNING
z THE TOMBERLIN ANVIL IS EQUIPPED TO OPERATE AT A TOP SPEED OF 25MPH
(40 KPH) AND IS INTENDED FOR USE AS A LOW-SPEED-VEHICLE.
WARNING
WHEN OPERATING VEHICLE ON PUBLIC ROADS
THIS VEHICLE OFFERS MUCH LESS CRASH PROTECTION THAN A NORMAL
PASSENGER CAR, VAN, OR TRUCK. THIS MEANS A HIGHER RISK OF INJURY OR
DEATH ON COLLISIONS, EVEN AT LOW SPEEDS. THE HIGHER THE SPEED OF THE
TRAFFIC AROUND YOU, THE HIGHER THE RISK OF INJURY MAY OCCUR.
To reduce these risks:
z Obey all traffic regulations.
z Avoid roads with regular traffic, even if the speed limit is low.
z Whenever possible, stay on roads and lanes limited to low speed vehicle.
z All passengers should wear safety belts at all times.
z Avoid operating vehicle at night if possible, because your vehicle may be hard for others
to see.
z To reduce the chance of the vehicle tipping over, reduce speed when turning and
maneuvering through curves and hills.
z Never drink and drive. Not only is drinking and driving unsafe, but doing so may violate
state and local laws.
WARNING
THIS PRODUCT CONTAINS OR EMITS CHEMICALS OR SUBSTANCES THAT HAVE
BEEN DETERMINED BY THE STATE OF CALIFORNIA TO CAUSE CANCER AND
BIRTH DEFECTS OR OTHER REPRODUCTIVE HARM.
Anvil Operator’s Manual Page 3
WARNING
• This vehicle is not designed to be used in conjunction with child safety seats
• Do not use or install child safety seat in any seat or position in the vehicle
• Always obey and follow laws and regulations regarding the transportation of
children
• Children that require the use of a child safety seat in a regular type automobile
should not be transported in this vehicle
Anvil Operator’s Manual Page 4
Foreword
Thank you for the purchase of your Tomberlin Anvil. Your satisfaction with your new
vehicle is important to all of us at Tomberlin.
Please take the time to review this Operator’s manual and abide by all safety and
operation warnings before allowing anyone to operate your new Anvil. Familiarizing
yourself with the Operator’s Manual and warnings will help avoid possible personal
injury and property loss.
We hope that you will consider this manual as an indispensable part of the vehicle.
The information contained in this document is subject to change without notice.
Tomberlin reserves the right to make design changes to vehicle without obligation to
make these changes on units previously sold.
IMPORTANT OPERATING NOTES:
z ALWAYS OPERATE YOUR ANVIL IN COMPLIANCE WITH YOUR STATE AND
LOCAL VEHICLE REGULATIONS INCLUDING REGISTRATION, TITLING,
INSURANCE, SEAT BELT USAGE, AND OPERATOR’S LICENSING.
z SWITCH VEHICLE TO OFF POSITION, REMOVE KEY AND SET PARKING BRAKE
PRIOR TO EXITING DRIVER’S SEAT.
z ALWAYS FASTEN YOUR SEAT BELTS!
z TO EXTEND THE LIFE OF YOUR BATTERIES:
° KEEP BATTERIES FULLY CHARGED WHENEVER POSSIBLE.
° AVOID DEEP DISCHARGING OF BATTERIES WHENEVER POSSIBLE
° USING THE BATTERY WATERING SYSTEM, ADD DISTILLED WATER AS
NECESSARY.
° ALWAYS WEAR SAFETY GOGGLES OR EYE PROTECTION, RUBBER GLOVES,
AND A MASK BEFORE HANDLING BATTERIES.
° KEEP YOUR ANVIL PLUGGED INTO THE CHARGER EVEN DURING LONG
ABSENCES. THE CHARGER IS COMPUTER CONTROLLED AND WILL MONITOR
AND MAINTAIN YOUR BATTERIES PEAK CONDITION.
° WHEN NEW（FIRST 4 WEEKS）AND UNDER HEA VY USE CHECK ELECTROLYTE
BY REMOVING THE BATTERY CAPS TO INSURE THAT THE WATERING
FREQUENCY RATE IS MAINTAINING THE PROPER ELECTROLYTE LEVEL.
Anvil Operator’s Manual Page 5
CONTENTS
Precautions ------------------------------------------------------------------6
Safety Regulations---------------------------------------------------------6
General Warnings-----------------------------------------------------------6
Appearance of Control-----------------------------------------------------8
Controls And Operation---------------------------------------------------9
Pre-operation Inspection-------------------------------------------------14
Driving Instructions--------------------------------------------------------15
Towing--------------------------------------------------------------------------16
Storage-------------------------------------------------------------------------16
Maintenance------------------------------------------------------------------17
- Scheduled Maintenance----------------------------------------------18
- Battery Pack--------------------------------------------------------------21
Charger-------------------------------------------------------------------------23
Cleaning -----------------------------------------------------------------------26
Vehicle Specifications-----------------------------------------------------27
Warranty------------------------------------------------------------------------28
Anvil Operator’s Manual Page 6
PRECAUTION
The Anvil is designed and manufactured as a Low-Speed-Vehicle (LSV). It is important that
every Operator become familiar with safe operation of the vehicle as described in this
Operating Manual and also with all applicable State, Local, and Community regulations
governing the use of an LSV.
SAFETY REGULATIONS
It is required to read the Owner’s manual completely before operating the vehicle or
attempting repair work. Any violations of instructions in the manual may lead to property l oss,
serious injury, or even death.
Pay special attention to important statements with the words such as “Danger”, “Warning”,
“Caution”, “Attention” etc…
If any of the operation/warning decals are damaged, defaced, destroyed, or illegible it is
important that they be replaced with new decals. Please contact the manufacturer or your
dealer to obtain new decals.
DANGER
DANGER indicates an immediate hazard that if ignored, will result in severe personal
injury or death.
WARNING
WARNING indicates an immediate hazard that if ignored, could result in severe
personal injury or death.
CAUTION
CAUTION indicates a hazard or unsafe practice that if ignored, could result in minor
personal injury or product or property damage.
GENERAL WARNINGS
The following safety procedures should be followed during vehicle operation, maintenance
or repair. Other special warning signs are described in this manual.
DANGER
Anvil Operator’s Manual Page 7
The Anvil contains batteries which can emit quantities of explosive gases. Keep the
vehicle in a well ventilated area and away from sparks and open flames.
Ventilate when charging or operating the vehicle in enclosed areas.
Do not perform service or maintenance on batteries while vehicle is charging.
The Anvil does not offer protection from lightning, flying debris, or other storm
hazards. Upon indication of severe weather condition, seek appropriate shelter
immediately.
WARNING
Inspect battery terminals, cables and batteries before each use.
Always wear a full face shield, rubber gloves and rubber apron when working with or
in close proximity to batteries.
Turn the ignition switch to the off position Turn the ignition switch to the off position,
remove the key, set the park brake, unplug the charger and place the run/tow switch to
the two position before inspecting or performing any type of service on the vehicle.
Connections should be tight and free of corrosion.
Utiliz e insulated tools only when working with electrical connections.
The tightness of the battery terminal nut should be between 95-105 inch pounds of
torque. Do not over tighten. Loose and/or over tightened connections can cause battery
failure, explosion and or fire.
Do Not Overfill the Batteries and keep batteries clean and free of moisture.
If any high heat condition or burning smell is noticed immediately park the vehicle in a
safe location, place the ignition in the off position, move yourself and passengers away
quickly to a safe distance from the vehicle and contact your dealer for assistance and
repair. If fire or smoke is detected contact your local fire department immediately. Do not
store your vehicle inside if any of these conditions exist.
Only use recommended batteries of the correct size.
Only authorized mechanics should perform maintenance or repair on the Anvil. It is
required to abide by all regulations and safety decals on the vehicle while performing any
type of maintenance or repairs.
To carry out repair work: turn the run/tow switch to the “TOW” position. Turn the
vehicle off, remove the key and chock the tires. Set the direction selector to its Neutral
position.
Use only insulated tools to handle the battery pack and electrical components.
Remove all jewelry and loosen items before performing maintenance procedures.
Improper applic ation o r maintena nce will le ad to deterioration of vehicle performance
Anvil Operator’s Manual Page 8
and reduce the overall life of the vehicle.
Do not attempt to alter the vehicle in any manner which would affect stability, control,
or top speed. Such alterations may lead it serious injury or death, violate state and local
laws, and will void the manufacturer’s warranty.
APPEARANCE OF THE ANVIL CONTROLS
1. Headlight & turn signal stalk 15. Cup holder
2. Brake fluid reservoir 16. FWD/REV switch
3. Steering wheel 17. Emergency flasher switch
4. Speedometer/ Instrument Display 18. Key switch
5. Windshield wiper control and defroster switch 19. Heated Seat switch
6. CD player / Stereo (reference stereo manual ) 20. Parking brake handle
7. Defroster vent 21. Boost button
8.12V Power outlet (max 5 AMP rating) 22. High performance switch
9. Speaker
10. Charge indicator
Anvil Operator’s Manual Page 9
11. Brake pedal
12. Accelerator pedal
13. Front vent handle
14. Defroster
Key Switch
The key switch is located on the right side of steering wheel. The key can only be
removed in the OFF Position.
When you turn the key to this position, all the electrical power will be turned on.
WARNING
z Do not take out the key while driving your car as it will result in sudden power loss and
braking to occur.
z Do not leave the key in the car or leave children in the vehicle unattended.
Instrument Cluster
1. Amperage display 9. Parking brake indicator
2. Left turn signal indicator 10. Brake fluid low indicator
3. Trip odometer reset 11. High beam indicator
4. Speed display 12. Low beam indicator
5. Odometer display 13. Motor over temperature indicator
6. Right turn signal indicator
7. Battery Power gauge
8. Voltage display
CONTROLS AND OPERATION
WARNING
