Contents
Brief Introductions………...……...…………………………..…..................1
1. What’s Included………………..……………………….…………......….…....1
2. About Tokio Wireless………..………………………………...........…..……...1
Before Use……………….……………………………………..............……..2
1. Overview……………..…………………………………………................…2-3
2. Charging Tokio Wireless…………..…………………………………..........3-4
Getting Started……..……….…………………………………..............……4
1. Turning On/Off Tokio Wireless……………...…………………...........….......4
2. Pairing Tokio Wireless With Bluetooth Devices………….……......……..4-9
1) How to enter pairing mode…………………….………........…………….4
2) Pairing Tokio Wireless with a Bluetooth cell phone via NFC…….........4-6
3) Pairing Tokio Wireless with a Bluetooth cell phone via Bluetooth……..7
4) Pairing Tokio Wireless with a Bluetooth transmitter via Bluetooth……..8
5) Pairing Tokio Wireless with Multi-devices via Bluetooth..................…8-9
3. Re-connecting With a Bluetooth Device......…………….………........……....9
4. Making Calls With Tokio Wireless……………………………........……10-12
5. Playing Music…………………………….…............…………………….12-13
6. LED Indicator…………………….……………............……………………..13
7. Indication Tone……………………………………………………………….14
8. Factory Reset………………….…………………............………………..….14
Important maintenances precautions………............………..………..14
FAQs……………………….…………………...……...............……………..15
Specifications…………………………………...………..............………..…16
Brief Introductions
1. What’s Included
The following components are included with your purchased product:
Tokio Wireless
3.5mm Cable
USB Cable
User Manual
2. About Tokio Wireless
Tokio Wireless is a Bluetooth stereo headset. Foldable and retractable design is
very easy to take with you. It supports the following Bluetooth profiles:
HSP —— Headset Profile
HFP —— Hands-free Profile
A2DP—— Advanced Audio Distribution Profile
AVRCP——Audio/Video Remote Control Profile
You can enjoy music wirelessly by using Tokio Wirelss. It has the following
features:
1) Supporting NFC(Near Field Communication) function, it can quickly
connect with Bluetooth cell phone which supports NFC function.
2) Pairing with a Bluetooth cell phone or PDA which supports HFP profile.
Answer a call, end a call and reject a call
Redial last number
Voice dial
Adjust the volume
Call transfer between the Tokio Wireless and your Bluetooth cell phone
Microphone mute
3) Pairing with a Bluetooth cell phone or Bluetooth transmitter supporting A2DP
profile.
1
Enjoy music wirelessly
Adjust the volume
Remote control pause/play
Remote control previous/next track
4) Easy to switch between the call and music, you will not miss the incoming calls
when listening to music.
5) Every time your Tokio Wireless is turned on, it will connect to last connected
device automatically.
Note: In order to achieve above function, the Bluetooth profiles of paired device
must be same as your Tokio Wireless. And even though the paired device and
Tokio Wireless support the same Bluetooth profiles, functions may vary due to
specification differences of the paired devices.
Before use
1. Overview
2
1
Built-in Microphone
7
LED indicator
2
Multi-function button(MFB)
8
Charging jack
3
Next song
9
Volume down
4
Pause/play
10
Volume up
5
Last song
11
Right speaker
6
Line-in jack
12
Left speaker
2. Charging Tokio Wireless
Your Tokio Wireless comes with a built-in rechargeable battery, prior to use it, it is
recommended to charge the battery fully for the first time.
When your Tokio Wireless is with low power, it emits three “Dong” tones every 5
minutes and the red LED flashes, please recharge it in time.
The way of charging is as following:
Using USB cable
1. Plug USB charging cable into the USB port of computer
2. Plug another side of USB cable to your Tokio Wireless
Red light on: Charging
Blue light on: Finish charging
3. It will takes about 3 hours to finish charging
3
Remarks:
1) The battery is recyclable.
2) Batteries (battery pack or batteries installed) shall not be exposed to excessive
heat place, such as sunshine, fire or the like.
Getting started
1. Turning on/off Tokio Wireless
Functions
Operation
LED indicator
Turning on
Press and hold MFB button for
3~4 seconds until blue LED
flashes
Blue light flashes for
one second
Turning off
Press and hold MFB button for
3~4 seconds until red LED
flashes
Red light flashes for
one second
Remark: In order to save power, your Tokio Wireless will turn off automatically
if no devices can be connected after 5 minutes.
2. Pairing Tokio Wireless with Bluetooth devices
1) How to enter pairing mode
Functions
Operation
LED indicator
Enter pairing
mode
Ensure Tokio Wireles is off, and
then press and hold MFB button
for 5~6 seconds until red and blue
LED flash alternately
Red and blue LED
flash alternately
Remark: Pairing mode will last 2 minutes. If no devices can be connected after 2
minutes, it will return to standby mode automatically.
2) Pairing Tokio Wireless with a Bluetooth cell phone via NFC
Your Tokio Wireless supports NFC function, it can quickly connect with Bluetooth
cell phone via NFC, hereby take Samsung S3 (Not included) for example.
4
The general pairing procedures are as follows:
1) Please activate the Bluetooth and NFC function of cell phone;
Please refer to following pictures：
Touch Setting button to enter into setting interface, activate Bluetooth function,
then go to More settings interface to activate NFC function.
2) Pairing and connecting with cell phone
Please refer to following pictures:
Make the NFC chip of cell phone and NFC logo on your Tokio Wireless within 1
centimeter, Tokio Wireless will turn on and enter pairing mode automatically,
there will be a request and prompt tone on cell phone “Pair the Bluetooth device”,
according to prompt tone, click “Yes” to confirm. Now, Tokio Wireless has
already paired and connected with cell phone.
5
Remarks:
The screen of cellphone must be in unlocked mode during pairing via NFC
The NFC chip of cell phone and NFC logo on your Tokio Wireless must be in 1
centimeter during pairing
You can pair your Tokio Wireless with cell phone via NFC even if it is under
the states of turn off, standby mode(not connect with device) or pairing mode.
6
3) Pairing the Tokio Wireless with a Bluetooth cell phone via Bluetooth
Prior to use Tokio Wireless for the first time, you have to pair it with a
Bluetooth-enabled cell phone. The pairing procedures are subject to different
models of cell phones. Please refer to your cell phone user’s manual for further
information. The general pairing procedures are as follows:
1) Keep your Tokio Wireless and phone within 1 meter when pairing;
2) Make the Tokio Wireless enter pairing mode (please refer to “How to enter
pairing mode);
3) Activate your cell phone’s Bluetooth function and set your cell phone to search
for Bluetooth devices within range, and select “Tokio Wireless” from the list of
devices shown;
4) According to the indication, enter password or PIN No: “0000”(If the mobile
phone supports Bluetooth V2.1, password is not required.);
5) If prompted by your cell phone to connect, select “Yes” (this will vary among
cell phone models);
6) After successful connecting, blue LED of Tokio Wireless flashes twice every 4
seconds.
Remarks:
If pairing is failed, please turn off Tokio Wireless first and then re-pair
according to steps 1～6 mentioned above.
After pairing is successful, Tokio Wireless and the cell phone will remember
each other, they will no need to re-pair next time. Tokio Wireless can
remember 8 paired devices, when the number of paired devices exceeds 8, the
first one will be replaced.
Every time Tokio Wireless is turned on, it will connect to last connected device
automatically. If you want to pair it with other devices, please turn off the
Bluetooth function of last connected devices first and pair your Tokio Wireless
with the new device according to steps 1～6 mentioned above.
7
4) Pairing Tokio Wireless with a Bluetooth transmitter via Bluetooth
You can connect the Tokio Wireless to a Bluetooth transmitter to enjoy music
wirelessly. For example(Bluetooth transmitter not included), the pairing steps are
as follows:
1) Keep your Tokio Wireless and transmitter
within 1 meter when pairing;
2) Make your Tokio Wireless enter pairing
mode (Please refer to “How to enter pairing
mode);
3) Turn on the Bluetooth transmitter and make
it enter paring mode. It will search for Bluetooth devices automatically and
send a pairing request;
4) When Tokio Wireless requests to enter a PIN No., the transmitter will response
“0000” automatically;
5) After successful pairing and connecting, blue LED of the Tokio Wireless
flashes twice every 4 seconds.
Remarks:
The defaulted pairing password of Tokio Wireless is “0000”. So, Tokio
Wireless can only pair with a Bluetooth transmitter whose pairing password is
“0000”.
If pairing still fails after several tries, please refer to the Bluetooth transmitter’s
user’s manual for further information.
5) Pairing Tokio Wireless with Multi-devices via Bluetooth
Your Tokio Wireless has been defaulted with multi-pair function Off, the steps of
turn on/off the multi-pair function are as follows:
Turn on multi-pair function: when Tokio Wireless is in standby mode, not
connect with any Bluetooth devices, press on MFB and volume up button
simultaneously for 3~5 seconds and release it until hear a prompt tone.
Turn off multi-pair function: when Tokio Wireless is in standby mode, not
connect with any Bluetooth devices, press on MFB and volume down button
simultaneously for 3~5 seconds and release it until hear a prompt tone.
8
Your Tokio Wireless can connect with two Bluetooth devices at most. If you want
to finish the multi-pairing, please refer to the following steps:
1) Firstly, pair and connect Tokio Wireless with Bluetooth device one (refer to
“pairing Tokio Wireless with a Bluetooth cell phone”);
2) Turn off Tokio Wireless and make it enter paring mode again, pair and connect
with Bluetooth device two(refer to “pairing the Tokio Wireless with a
Bluetooth cell phone”);
3) Operate Bluetooth device one to connect with Tokio Wireless. Thus, Tokio
Wireless has already connected with Bluetooth device one and two, the Tokio
Wireless also can connect with these two devices automatically next time.
Remarks:
After successful multi-pairing, the paired devices will remember each other.
Tokio Wireless will connect with last connected two devices automatically
after turn on.
To improve the stabilization of Tokio Wireless, we suggest you turn off the
multi-pair function when you only connect with one cell phone.
3. Re-connecting with a Bluetooth device
1) Automatic connecting
Every time your Tokio Wireless is turned on, it will connect to last connected
device automatically.
2) Manual connecting
When your Tokio Wireless is in standby mode and not connect with device, short
press any button, it will try to connect to last connected device.
Remarks:
Before connecting to a Bluetooth device, please turn on the Bluetooth function
of Bluetooth device.
For some Bluetooth devices, for example, Nokia cell phones, you have to
allow automatic connecting in the cell phone’s settings. Please refer to your
cell phone’s manual for further information.
9
4. Making a call with Tokio Wireless
1) Basic operation
Functions
Status of Device
Operation
Cancel a call
Calling
Short press MFB once
Answer a call
Incoming ringing
Short press MFB once
Reject a call
Incoming ringing
Long press MFB for 2 seconds
and release it until listen a tone
End a call
During a call
Short press MFB once
Volume up
During a call
Short or long press + button
Volume down
During a call
Short or long press — button
Transfer
conversation
to mobile
phone
During a call
Long press MFB for 2 seconds
Transfer
conversation
to Tokio
Wireless
During a call
Long press MFB for 2 seconds
Microphone
mute
During a call
Double click MFB
Cancel mute
During a call
(microphone mute)
Double click MFB
Voice dial
Standby mode
(connected device)
Long press button for 2
seconds
Redial the last
number
Standby mode
(connected device)
Double click MFB
10
2) Three-ways call operation
Functions
Status of device
Operation
Answer new call and
end current call
There are second
incoming call
Short press once
Answer new call and
retain current call
There are second
incoming call
Long press for 2
seconds
Reject new call and
keep current call
There are second
incoming call
Double click button
Switch calls
Keep conversation
Long press for 2
seconds
End current call and
switch retain call
Keep conversation
Short press once
End retain call and
keep current call
Keep conversation
Double click button
Warning: excessive sound pressure from earphones and headphones can
cause hearing loss.
Remarks:
Not all the mobile phones support all the functions listed above. Please refer to
your mobile phone user’s manual.
Different function and prompt tone according to different mobile phones.
When the volume of Tokio Wireless has been adjusted to max or min, you will
hear one prompt tone.
When pressing the answer button on some mobile phones, the call will be
transferred to the mobile phone. You can switch the call to the Tokio Wireless
by using the conversation switch button or through operating on the mobile
phone. Please refer to your mobile phone user manual for further information.
11
3) Connecting with two cell phones to make a call
Functions
Status of Device
Operation
Retain phone call #1
and answer phone call
#2
During phone call #1, phone
2 has incoming call
Long press
for 2 seconds
End phone call #1 and
answer phone call #2
During phone call #1, phone
2 has incoming call
Short press
once
Reject phone call #2
and keep current
phone call
During phone call #1, phone
2 has incoming call
Double click
button
Switch call
During call, one of phone
call is retained
Long press
for 2 seconds
End current call, back
to retain phone call
During call, one of phone
call is retained
Short press
once
End retain phone call
During call, one of phone
call is retained
Double click
button
5. Playing music
When your Tokio Wireless connects to a mobile phone or Bluetooth transmitter
which supports A2DP, you can enjoy music wirelessly through Tokio Wireless.
12
Functions
Status of Headset
Operation
Volume up
Playing music
Short press “+” button
Volume down
Playing music
Short press “―” button
Last song
Playing music
Short press ◄ button once
Next song
Playing music
Short press ► button once
Fast forward
Playing music
Long press ► button once
Fast rewind
Playing music
Long press ◄ button once
Pause
Playing music
Short press button once
Play
Pausing
Short press button once
Line in input
Turned off
It can playing music through
3.5mm audio line
USB function
Turned off or turned
on
Connect Tokio Wiress with PC via
USB cable, you can enjoy music
from PC. If Tokio Wireless is
turned on, you can control
previous/next song, fast forward
/fast rewind of Tokio Wireless.
Remarks:
When play music on some mobile phones, the music will be transmitted to the
mobile phone’s speaker instead of Tokio Wireless. You have to select “transmit
the sound via Bluetooth” in the settings menu and then choose “Tokio
Wireless” as speaker device. The music will be transmitted to Tokio Wireless.
Please refer to your mobile phone’s user’s manual for further information.
When the volume has been adjusted to max or min, you will hear one prompt
tone.
If you want to remote control last/next song, pause/play, it needs your
Bluetooth mobile phone or Bluetooth transmitter paired with the Tokio
Wireless to support AVRCP profile, please refer to the user’s manual of your
mobile phone or Bluetooth transmitter for further information.
Only the paired Bluetooth devices(phone or transmitter) support “fast
forward/fast rewind” function, and Tokio Wireless can use this function. Please
refer to your Bluetooth devices’(phone or transmitter) user’s manual for
further information
The Bluetooth will disconnect between Tokio Wireless and mobile phone
automatically if you plug 3.5mm audio input, and the Line in is available in
this time, but the other functions of Tokio Wireless is not available.
6. LED indicator
1) Charging
LED indicator
Status of Device
Red LED on
Charging
Blue LED on
Finish charging
2) Pairing with Bluetooth device
LED indicator
Status of Device
Red and blue LED flashes
alternately
Pairing mode
Blue LED flashes once quickly
every 2 seconds
Not connect with Bluetooth device
Blue LED flashes twice quickly
every 4 seconds
Have already connect with Bluetooth
device
Blue LED flashes slowly
continuously
Calling/incoming call
Blue LED flashes once quickly
every 2 seconds
During a call
Red LED flashes instead of blue
LED
Low battery
13
7. Indication Tone
Indication tone
Status of the Device
Continuous two prompt tone every
10 seconds
Conversation mode and microphone
mute
Three “dong” warning tone every 5
minutes
Low battery
8. Factory Reset
In the status of standby mode and not connect with Bluetooth device, long press
MFB and button for 3~4 seconds simultaneously and release it until the red
and blue LED on simultaneously.
Remarks:
For factory reset, you should press MFB button first, then press button or
press MFB and button simultaneously.
After factory reset, the paired list of Tokio Wireless will be deleted, when you
turn on Tokio Wireless again, it will enter paired mode automatically, but it
won’t connect with device automatically, you should re-pair and connect with
devices.
Important maintenances precautions
In order to offer your Tokio Wireless good maintenances, please always follow the
below basic precautions:
Keep it dry and don’t put it in the dump place to avoid the product’s internal
circuit being affected.
Keep the product away from direct sunlight or hot places. High temperatures
will shorten the life of electronic devices, destroy the battery or distort certain
plastic parts.
Don’t use this product during sport to avoid the sweat into product so that
damage the product. This product is not water-resistant.
Don’t expose the product to cold areas. It may damage the internal circuit
board.
Don’t try to disassemble the product as it may get damaged if you are not
professional.
Don’t let it fall down onto the floor or other hard surfaces. The internal circuit
might get damaged.
Don’t use intensive chemical products or detergent to clean the product.
Don’t scratch the surface with sharp things.
14
FAQs
1. What does it mean if all the LED indicator turns red?
Battery is low power, need to be recharged.
2. Why is the red LED off when charging?
a) Please make sure the charging device connect with Tokio Wireless Well;
b) You didn’t use Tokio Wireless for a long time, the battery may dry up. At this
time, you have to charge the battery for 30 minutes, and then the red LED will
be ON.
3. How far is the effective rang between Tokio Wireless and mobile phone?
According to the Bluetooth standard, the max available range of ClassII headset is
10 meters. But this also varies under different environment.
4. Why my mobile phone can not search and find Tokio Wireless?
The mobile phone will not find Tokio Wireless if Tokio Wireless and mobile
phone are not under the pairing mode. Make sure Tokio Wireless is under the
pairing mode and in the effective working range, and then Tokio Wireless can be
paired and connected.
5. Why I can not hear the voice from Tokio Wireless?
a) Make sure Tokio Wireless has been switched on;
b) Make sure the volume is not too low or muted;
c) Make sure Tokio Wireless connects with the mobile phone correctly;
d) Make sure the distance between Tokio Wireless and the cell phone is in the
available Bluetooth range.
6. Why I can not hear the voice clearly from Tokio Wireless during phone
conversation?
a) Make sure the mobile phone is in the strong signal area;
b) Make sure Tokio Wireless is in the available range of this product.
7. Why can’t control pause, play, last song and next song when playing
music?
This function needs your Bluetooth device supports AVRCP (Audio/Video
Remote Control profile)
15
Specifications
Bluetooth version
Bluetooth V4.0
Bluetooth profiles
Headset, Hands free, A2DP, AVRCP
Operating distance
10 meters
Working time
Music up to 17 hours
Standby time
Approx 400 hours
Charging input
DC5.0V 500mA
Charging time
About 3 hours
Dimension
176*165*32mm
Weight
Approx 173g
Battery capacity
430mAH
16
Loading...
