Toastmaster UB-328 User Manual

Wrist Digital Blood Pressure Monitor

WM

+

PD4000913

Model UB-328

Instruction Manual

Manuel d’instructions

Manual de Instrucciones

Manuale di Istruzioni

ENGLISH

Dear Customers

Congratulations. You have purchased an A&D blood pressure monitor, one of the most technologically advanced, yet
easy to use products available in the marketplace today.
We strongly recommend you read this instruction manual carefully prior to using it the first time.

General Information

This device conforms to the European Community Directive 93/42/EEC for Medical Products. This is evidenced by the
CE mark of conformity accompanied by the reference number of a designated authority.
This device is designed for monitoring your blood pressure and pulse rate at home. Therefore, intended use of this
device is limited to monitoring blood pressure and pulse for the general public, except newborns and infants.

Note:

1.This device is designed for personal use and not for public use.

2.This device is not designed for measuring newborns or infants. Using this device on newborns and infants could
cause injury to the child. DO NOT USE on newborns or infants.

Precautions

1. Precision components were used in the construction of this device. Extremes in
temperature, humidity, direct sunlight, shock or dust should be avoided.

2. Clean the device with a dry, soft cloth. Never use thinner, alcohol, benzine, or wet cloths.

3. Avoid folding the cuff tightly or storing the hose tightly twisted for long periods, as such
treatment may shorten the life of the components.

4. The device and cuff are not water resistant. Protect the device and cuff from rain, sweat and water.

5. Measurements may be impaired if the device is used close to televisions, microwave
ovens, cellular telephones, X-ray or other devices with strong electrical fields.

6. Used equipment, parts and batteries are not treated as ordinary household waste, and must be disposed of
according to applicable regulations.

ENGLISH 1

Parts Identification

ENGLISH 2

Symbols

Symbols Function / Meaning Treatment

SN

Turns the device on and off.
Guide to install battery
Direct current
Serial number

Date of manufacture
Type BF: Device, cuff and tubing are designed to

provide special protection against electrical shocks.
Appears when measurement is in progress and

flashes when the pulse is detected.
Irregular Heartbeat indicator. (I.H.B.)

The indicator that detects irregular heartbeats or any
excessive body movement during the measurement.

Previous measurement stored in MEMORY
Appears when the battery voltage is too low for

the device to work properly.
Appears if the pressure value is unstable due to

movement during the measurement.

___________
___________
___________
___________

___________
___________

Measurement is in progress – remain still.

___________

___________

Replace all batteries with new ones.

Try the measurement again.

Appears if the pressure value is unstable due to
movement during the measurement.

Appears when inflation is not sufficient.
Appears when the cuff is not fastened correctly. Fasten the cuff correctly, and try the measurement again.

Appears when the pulse is not detected correctly. Fasten the cuff correctly, and try the measurement again.

ENGLISH 3

Remain very still during the measurement.
If your systolic reading exceeds 150 mmHg, read “For those

whose systolic pressure is over 150 mmHg” on page 7.

Systolic blood pressure in mmHg

___________

Diastolic blood pressure in mmHg
Pulse beats per minute

The EC directive medical device label

Using the Monitor

1. Installing the batteries

1. Remove the battery holder cover.

2. Place two batteries (LR03 or AAA) in the holder, with positive (+) and negative (-)
terminals matching those indicated in the holder.

3. Replace the battery holder cover until it is locked.

• Insert the batteries as shown in the battery holder or the device will not work.

___________
___________

___________

• When    (LOW BATTERY mark) appears in the display, replace all batteries with

new ones at the same time. Do not mix old and new batteries. It may shorten the battery
life, or cause the device to malfunction.

•    (LOW BATTERY mark) does not appear when the batteries are drained.

• Battery life varies with the ambient temperature and may be shorter at low temperatures.

• Remove the batteries if the device is not to be used for a long period of time. The batteries may leak and cause a malfunction.

• Use the specified batteries only. The batteries provided with the device are for testing monitor performance and may

have a shorter life.

ENGLISH 4
