Toastmaster TMCKM2S User Manual

USE AND CARE GUIDE

MODEL TMCKM2S

Cordless Cookie Press

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should always be followed including the following:

◆ Read all instructions.

◆ To protect against risk of electrical shock, do not put cord, plug or

appliance in water or other liquid.

◆ Close supervision is necessary when any appliance is used by or near children.

◆ Unplug from outlet when not in use, before putting on or taking off

parts and before cleaning.

◆ Avoid contacting moving parts.

◆ Do not operate any appliance with a damaged cord or plug or after

the appliance malfunctions, or is dropped or damaged in any manner. Contact Consumer Service for examination, repair or electrical or mechanical adjustment.

◆ The use of attachments not recommended or sold by the manufacturer may cause fire, electric shock or injury.

◆ Do not use outdoors.

◆ Do not let cord hang over edge of table or counter.

◆ Do not let cord contact hot surface, including the stove.

◆ Do not use an extension cord. Plug Battery Adaptor directly into an

electric outlet.

◆ Use only with the Battery Adaptor provided with the appliance. Do not attempt to use this Battery Adaptor with any other product. Likewise, do not attempt to charge this appliance with any other Battery Adaptor.

◆ Do not incinerate this appliance even if it is severely damaged. The batteries can explode in a fire.

◆ Keep hands, hair, clothing as well as utensils away from moving parts and Discs while processing to prevent the risk of severe injury to persons, or damage to the Cookie Press. Handle Discs and Tips carefully when removing, inserting or cleaning.

◆ Be certain Tube and Tube Cover is securely locked in place before operating appliance. Do not attempt to remove the Tube or Cover while operating.

◆ Before using, check that Tube has no presence of foreign objects.

SAVE THESE INSTRUCTIONS FOR HOUSEHOLD USE ONLY

Cordless Cookie Press Use and Care Guide

ADDITIONAL IMPORTANT SAFEGUARDS

◆ All users of this appliance must read and understand this Use and Care Guide before operating or cleaning this appliance.

◆ The cord to this appliance should be plugged into a 120V AC electrical outlet only.

◆ Do not leave this appliance unattended during use.

◆ If this appliance begins to malfunction during use, immediately

release the ON/OFF Button. The Cookie Press will stop when the ON/OFF Button is released. Unplug the cord. Do not use or attempt to repair the malfunctioning appliance.

◆ If this appliance falls or accidentally becomes immersed in water, unplug it immediately. Do not reach into the water! Do not use this appliance after it has fallen into or becomes immersed in water.

◆ To reduce the risk of injury to persons or property, never use this appliance in an unstable position.

◆ Do not use this appliance for other than its intended use.

◆ Do not use an extension cord with this product.

Electric Power

If the electrical circuit is overloaded with other appliances, your appliance may not operate properly. It should be operated on a separate electrical circuit from other appliances.

Introduction

Congratulations on your purchase of the Toastmaster® Cordless Cookie Press. Cordless means effortless; ease of operation, maneuverability and newfound cookie-baking freedom. No more rolling dough to change shapes! Simply change the disc and the batter for a dozen new designs and cookies. Push button operation means each and every cookie will be fashioned to perfection, quickly and easily.

The Cordless Electric Cookie Press comes packed in its convenient Storage Box with Handle, complete with a wide selection of interchangeable Cookie Discs, 1 Filler Tip, 8 Decorator Tips, and 2 Cannoli Shell Forms.

Make bakery style cookies in your own home...change from a Cookie Disc to a Decorator Tip and you're ready to add the final flourishes to pastries, cakes and candies. Use the Filler Tip to fill cupcakes and pastries. Wrap dough around the Cannoli Shell Forms for frying. Create your own fresh, delicious filling to prepare professional looking and great-tasting cannoli for family and friends.

Before Using for the First Time

1. Carefully unpack the Cookie Press in its Storage Box. Slide the box out to reveal the Cookie Maker and all accessories conveniently packed inside.

2. After unpacking, wash the Cookie Discs, Filler Tip, Filler Tip/ Decorator Tip Adaptor, Decorator Tips, Cannoli Shell Forms, Tube Cover, Tube, Cam Disc, Press Disc and Cam Shaft with warm, soapy water. Rinse and dry thoroughly.

3. Never immerse the Motor Body, Plug, Battery Adaptor or Battery Adaptor Connector in water or any other liquid.

4. Make sure the Battery Adaptor is unplugged and then wipe all surfaces with a slightly moistened, soft cloth and dry thoroughly.

5. Thoroughly dry all parts so that no water enters the Motor Body.

Getting To Know Your Toastmaster

Cordless Cookie Press

Cordless Cookie Press Use and Care Guide

10.

Before using your Cordless Electric Cookie Press for the first time, you must become familiar with all of the parts. Read all instructions and safeguards carefully.

12.

14.

13.

1. Motor Body

2. ON/OFF Button

3. Cam Disc (P/N 70701B)

4. Connector Inlet

5. Cam Shaft (P/N 70702B)

6. Press Disc (P/N 70703B)

7. Tube (P/N 70704)

8. Cookie Disc

9. Tube Cover (P/N 70706B)

10. 2 Cannoli Shell Forms (P/N 71158, 1 piece)

11. 10mm Filler Tip (P/N 71159)

12. Filler/Decorator Tip Adaptor (P/N 70705B)

13. Decorator Tip

14. Filler Tip/Decorator Tip Cover (P/N 70707B)

15. Battery Adaptor Connector

16. Battery Adaptor (P/N 71171)

Filler Tip/Decorator Tip

Assembly

Cookie Disc

Assembly

11.

16.

15.

Figure 1

Product may vary slightly from Illustration.

Cookie Press Discs & Decorator Tips

10.

11.

12.

Storage Box: (P/N 71172 )

12 Cookie Discs

1. 2.

3. 4.

5. 6.

7. 8.

Figure 3

Decorator Tips Set (P/N 70709-SET) Individual Tips (P/N 70709-1, 70709-2,

70709-3, 70709-4, 70709-5, 70709-6, 70709-7, 70709-8)

8 Decorator Tips

Figure 2

Individual Discs: (P/N 70708-1) (P/N 70708-2) (P/N 70708-3) (P/N 70708-4) (P/N 70708-5) (P/N 70708-6)

(P/N 70708-7) (P/N 70708-8) (P/N 70708-9) (P/N 70708-10) (P/N 70708-11) (P/N 70708-12)

Cookie Discs Set (P/N 70708-SET)

Cordless Cookie Press Use and Care Guide

Recharging The Battery For Cordless Use

IMPORTANT: For the first use you must charge the unit for at least 24 hours to ensure that the batteries are fully charged.

1. The normal recharge time is 6 hours for a full charge. When fully charged, your Cookie Press can be used to prepare 10 to 15 Tubes full of cookie batter/filling.

2. To recharge, insert the Battery Adaptor Connector into the Connector Inlet located at the top backside of the Motor Body Handle. (See Figure 3). Then plug the Adaptor into a standard 120V AC outlet. Unplug Adaptor from unit and wall before cordless use.

Direct Drive By Adaptor For Corded Use

1. The unit can be used as direct-drive with the Adaptor supplied with the unit when the batteries are not charged. Use only the Adaptor (P/N 71171) supplied with this unit.

2. Insert the Battery Adaptor Connector into the Connector Inlet located at the top backside of the Motor Body Handle. (See Figure

3). Then plug the Adaptor into a standard 120V AC outlet for direct corded use.

Figure 3

Assembly Instructions

1. Unplug from outlet before assembly or disassembly of parts. Attach Cam Shaft to the Press Disc by inserting stem of the Shaft into the Press Disc’s center hole. Press firmly. You will hear a click as the Shaft snaps in place. (See Figure 4.)

2. Line the Tabs on the Motor Body up with the slots on the Cam Disc. Insert Cam Disc into the Motor Body. Using the two Grips on the Cam Disc, turn slightly clockwise until the Disc clicks into position. (See Figure 5.)

3. Fit the Shaft all the way inside the unit, the outside contours of the 2 Discs will line up. (See Figure 6.)

NOTE: Tu rn Cam Disc one click counterclockwise if Shaft is difficult to insert into Motor Body.

4. Select a Disc and place it inside the Tube Cover. Then place the Tube into the Tube Cover, turning clockwise until locked. (See Figure 7.)

5. If a Filler Tip or Decorator Tip is to be used, fit the desired Tip over the Filler Tip/Decorator Tip Adapter and secure it with the Filler Tip/Decorator Tip Cover. Place the Filler Tip Assembly inside the Tube Cover. Then place the Tube into the Tube Cover, turning clockwise until locked. (See Figures 8A and 8B.)

Figure 4

Figure 7

Figure 8A

Filler Tip

Cookie Disc

Filler Tip/ Decorator Tip Cover

Tube Cover

Tube with Filler Tip Assembly

Tube with Disc Assembly

Figure 5

Filler Tip/ Decorator Tip Adapter

Tabs

Slots

Cam Disc

Grips

Press Disc

Cam Shaft

Figure 6
