Toastmaster TG21W User Manual

Cool-Edge Griddle

with Backstop

USE AND CARE GUIDE

MODELS TG21W, TG21WL AND TG21WCAN

READ AND SAVE
THESE INSTRUCTIONS

WARNING: A risk of fire and electrical shock exists in all electrical
appliances and may cause personal injury or death. Please follow all
safety instructions.

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should
always be followed, including the following:

◆ Read all instructions before using appliance.

◆ Do not touch hot surfaces. Use handles or knobs.

◆ To protect against electric shock, do not immerse probe, cord or

plug in water or other liquid. See instructions for cleaning.

◆ This appliance is not for use by children.

◆ Close supervision is necessary when this appliance is used near

children.

◆ Unplug from outlet when not in use and before cleaning. Allow to

cool before putting on or taking off parts, and before cleaning the
appliance.

◆ Do not operate any damaged appliance. Do not operate with a

damaged cord or plug, or after the appliance malfunctions, or has
been dropped or damaged in any manner. Contact Consumer
Service for return authorization, examination, repair or
adjustment.

◆ The use of accessory attachments not recommended by

Toastmaster Inc. may cause injuries.

◆ Do not use outdoors or while standing in a damp area.

◆ Do not let cord hang over edge of table or counter, or touch hot

surfaces.

◆ Do not place on or near a hot gas or electric burner, or in a heated

oven.

◆ Extreme caution must be used when moving an appliance

containing hot oil or other hot liquids.

◆ Always attach probe to appliance first, then plug cord into the wall

outlet. To disconnect, turn the temperature control knob to
minimum setting, then remove plug from wall outlet.

◆ When using this appliance, provide 4 to 6 inches air space on all

sides for air circulation. Do not use on surfaces where heat may
cause a problem.

1.

◆ Do not use appliance unattended.

◆ Use extreme caution when disposing of hot grease.

◆ Do not place drip tray on top of hot griddle surface.

◆ CAUTION: Hot surfaces.

◆ Do not use appliance for other than intended use.

SAVE THESE INSTRUCTIONS

CAUTION: A short power supply cord is provided to reduce the risk of
personal injury resulting from becoming entangled in or tripping over a
longer cord. Extension cords are available from local hardware stores
and may be used if care is exercised in their use. If an extension cord is
required, special care and caution are necessary. The cord must be: (1)
the marked electrical rating of the cord set or extension cord should be
at least as great as the electrical rating of the appliance (2) if the
appliance is of the grounded type, the extension cord should be a
grounding 3-wire cord, and (3) the cord must be arranged so that it will
not drape over the countertop or tabletop where it can be pulled on by
children or tripped over accidentally.

POLARIZED PLUG: Some models have a 2-prong polarized plug, (one
blade is wider than the other). As a safety feature to reduce the risk of
electrical shock, this plug is intended to fit in a polarized outlet only one
way. If the plug does not fit fully in the outlet, reverse the plug. If it still
does not fit, contact a qualified electrician. Do not attempt to defeat this
safety feature.

GROUNDED-TYPE PLUG: Some models have a 3-prong grounded­type plug. This plug will only fit into an electrical outlet made for a
3-prong plug. This is a safety feature. If the plug should fail to fit the
outlet, contact a qualified electrician. Do not attempt to defeat this
safety feature.

ELECTRIC POWER: If electric circuit is overloaded with other
appliances, your appliance may not operate properly. It should be
operated on a separate electric circuit from other appliances.

This product is for household use only.

Temperature Control Probe: Use only the Temperature Control
Probe Model 1244 supplied with this product. Using any other
Te mperature Control Probe may cause fire, electric shock or injury.

Cool-Edge Griddle with Backstop Use and Care Guide

2.

L

ow

est

settin

g

Lowest

setting

L

o

w

e

s

t

s

e

ttin

g

A.

Figure 1

B.

C.

G.

F.

E.

D.

A. Drip Tray (P/N 21701TM)
B. Warming Drawer

(P/N 21732TM)

C. Temperature Control Probe

(P/N 21731TM)

Figure 2

D. Non-Skid Rubber Feet

(P/N 21700TM)
E. Cool-Touch Surround
F. Non-stick Cooking Surface
G. Backstop

Figure 3

3.

Using Your Griddle

T

his griddle includes a warming drawer. The warming drawer allows
your food to be kept warm under the griddle for short periods of
time while additional foods are prepared on top of the griddle.

1. Before

and Use of Non-Stick Surface.

2. Insert warming drawer and drip tray into rails under griddle,
see Figure 2.

3. Turn Temperature Control Knob on probe to
setting

4. Condition the non-stick surface with vegetable shortening
before heating. If necessary, remove excess oil with paper
towel. Plug into 120V ~ 60 Hz outlet. Align temperature
control knob with pointer. The unit is preheated when the
light on the probe goes off. The light will cycle during use
indicating the proper temperature is being maintained.

5. When finished cooking, turn Temperature Control Knob on probe
to
cleaning.

CAUTION: Because some countertop finishes are more affected
by heat than others, use care not to place griddle on surfaces
where heat may cause a problem.
CAUTION: Griddle surfaces are hot during use.

first use, see Cleaning Instructions and Hints For Care

minimum

position and attach securely in place, see Figure 3.

minimum setting

, unplug from outlet and cool before

User Maintenance Instructions

This appliance requires little maintenance. It contains no user
serviceable parts. Do not try to repair it yourself. Contact a qualified
appliance repair technician if the product requires servicing.

Cleaning Instructions

NOTE: No parts should be placed in an automatic dishwasher.

1. Unplug and allow to cool before cleaning or moving.

2. Remove probe (DO NOT IMMERSE PROBE IN WATER), wipe
with a damp cloth and dry thoroughly.

3. Remove drip tray; empty contents. Wash griddle, warming
drawer, and drip tray in soapy water; rinse and dry thoroughly.

Cool-Edge Griddle with Backstop Use and Care Guide

4.

A plastic pad with mild abrasive cleaner may be used to clean
underside of griddle.
C

AUTION: Probe and probe receptacle must always be completely

dry before use.

Hints For Care and Use of Non-Stick Surface

◆ To avoid scratching the non-stick surface, do not stack objects on

griddle.

◆ Use medium to low heat for best cooking results. Very high

temperatures can cause discoloration and shorten the life span
of any non-stick surface. If higher temperatures are necessary,
preheat on medium for a few minutes.

◆ Use only nylon, plastic, or wooden utensils with care to avoid

scratching the non-stick surface. Never cut food on the griddle.

◆ Remove stubborn stains with a plastic scouring pad and mild

dish washing liquid; DO NOT USE STEEL WOOL.

Time and Temperature

Food Temperature Time Directions

(Preheat) (Minutes)

Bacon 325° 8-16 DO NOT PREHEAT. Turn often.
Sausage 325° 20-35 DO NOT PREHEAT. Turn often.
French Toast 350° 6-12 Turn halfway into cooking time.
Ham Slices 350° 15-20 Turn halfway into cooking time.
Sandwiches 350° 6-10 Butter outside and brown both sides.
Pork Chops 350° 20-35 Brown both sides then reduce

temperature to 325°. Turn halfway
into cooking time.

Pancakes 375° 4-8 Pour batter onto griddle. When

bubbles appear on top side, turn.

Steaks 400° rare 6-11 Turn halfway into cooking time.

400° medium 9-16 Turn halfway into cooking time.

400° well 15-22 Turn halfway into cooking time.

Hamburger 400° 6-18 Turn halfway into cooking time.

5.

LIMITED ONE YEAR WARRANTY

Warranty: This Toastmaster®product is warranted to be free from defects in materials or workmanship for a period of

(1) year from the original purchase date. This product warranty covers only the original consumer purchaser of the
product.

Warranty Coverage: This warranty is void if the product has been damaged by accident in shipment, unreasonable
use, misuse, neglect, improper service, commercial use, repairs by unauthorized personnel, normal wear and tear,
improper assembly, installation or maintenance abuse or other causes not arising out of defects in materials or
workmanship. This warranty is effective only if the product is purchased and operated in the USA, and does not extend
to any units which have been used in violation of written instructions furnished with the product or to units which have
been altered or modified or to damage to products or parts thereof which have had the serial number removed,
altered, defaced or rendered illegible.

Implied Warranties: ANY IMPLIED WARRANTIES WHICH THE PURCHASER MAY HAVE ARE LIMITED IN DURATION
TO ONE (1) YEAR FROM THE DATE OF PURCHASE. Some states do not allow limitations on how long an implied
warranty lasts, so the above limitation may not apply to you.

Warranty Performance: During the above one-year warranty period, a product with a defect will be either repaired or
replaced with a reconditioned comparable model (at our option) when the product is returned to the Repair Center, or
the purchase price refunded. The repaired or replacement product will be in warranty for the balance of the one-year
warranty period and an additional one-month period. No charge will be made for such repair or replacement.

Service and Repair: Should the appliance malfunction, you should first call toll-free 1 [phone] between the hours
of 9:00 am and 5:00 pm Central Standard Time and ask for CONSUMER SERVICE stating that you are a consumer with
a problem. Please refer to model number TG21W, TG21WL or TG21WCAN when you call.

In-Warranty Service (USA): For an appliance covered under the warranty period, no charge is made for service or
postage. Call for return authorization (1 800 947-3744).

Out-of Warranty Service: A flat rate charge by model is made for out-of-warranty service. Include $12.00 (U.S.) for
return shipping and handling. We will notify you by mail of the amount of the charge for service and require you to pay
in advance for the repair or replacement.

For Products Purchased in the USA, but Used in Canada: You may return the product insured, packaged with
sufficient protection, and postage and insurance prepaid to the USA address listed below. Please note that all customs
duty / brokerage fees, if any, must be paid by you and we will require you to pay the cost of customs duty /
brokerage fees to us in advance of our performing any service.

Risk During Shipment: We cannot assume responsibility for loss or damage during incoming shipment. For your
protection, carefully package the product for shipment and insure it with the carrier. Be sure to enclose the following
items with your appliance: any accessories related to your problem, your full return address and daytime phone
number, a note describing the problem you experienced, a copy of your sales receipt or other proof of purchase to
determine warranty status. C.O.D. shipments cannot be accepted.

To return the appliance, ship to:

Salton Inc.
Attn: Repair Center
708 South Missouri Street
Macon, MO 63552

Email: [e-mail]
www.Toastmaster.com

Limitation of Remedies: No representative or person is authorized to assume for us any other liability in connection
with the sale of our products. There shall be no claims for defects or failure of performance or product failure under
any theory of tort, contract or commercial law including, but not limited to negligence, gross negligence, strict liability,
breach of warranty and breach of contract. Repair, replacement or refund shall be the sole remedy of the purchaser
under this warranty, and in no event shall we be liable for any incidental or consequential damages, losses or
expenses. Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above
limitation or exclusion may not apply to you.

Legal Rights: This warranty gives you specific legal rights, and you may also have other rights which vary from state
to state.

To contact us,please write to or call:

Salton Inc.
P. O. Box 6916
Columbia, MO 65205-6916

© 2003 Toastmaster Inc. P/N 61004Rev03/03
All Rights Reserved Printed in China

Cool-Edge Griddle with Backstop Use and Care Guide

6.

Keep Dated Sales Receipt for Warranty Service.

Keep this booklet. Record the following for reference:

Date purchased _______________________________________________

Model number _______________________________________________

Date code (stamped on bottom)________________________________

EVERYBODY EATS. It’s a fact of life.

But sometimes preparing

meals can become a chore.

That’s why TOASTMASTER has been invited

into millions of kitchens just like yours

so we can HELP YOU MASTER your

mixing, baking, grilling, toasting,

brewing, heating and serving

tasks WITH EASE AND STYLE.

The TOASTMASTER name stands for a

CELEBRATION of INNOVATION designed

to serve your life and keep you

COOKIN’ IN STYLE.

7.

?

• 20.5” non-stick cooking surface

• Cool-touch surround

•Immersible with probe removed

• Backstop for easy food removal

• Infinitely adjustable thermostat

Questions

Call toll free 1-800-947-3744
Monday– Friday, 8:00 a.m. -5:30 p.m. CST
www.toastmaster.com

TG21W, TG21WL AND TG21WCAN
