Automatic Drip
Coffeemaker
USE AND CARE GUIDE
MODEL TCM10PWF
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should
always be followed, including the following:
◆ Read all instructions.
◆ Do not touch hot surfaces. Use handles or knobs.
◆ To protect against electric shock, do not place cords, plugs or
appliance in water or other liquid.
◆ Close supervision is necessary when any appliance is used by or
near children.
◆ Unplug from outlet when not in use and before cleaning. Allow to
cool before putting on or taking off parts, and before cleaning the
appliance.
◆ Do not operate any appliance with a damaged cord or plug or after
the appliance malfunctions, or has been damaged in any manner.
Contact Consumer Service for examination, repair or adjustment.
◆ The use of an accessory not evaluated for use with this appliance
may cause injuries.
◆ Do not use outdoors.
◆ Do not let cord hang over edge of table or counter, or touch hot
surfaces.
◆ Do not place on or near a hot gas or electric burner, or in a heated
oven.
◆ To disconnect, turn Power Switch to “off”, then remove plug from
wall outlet.
◆ Do not use appliance for other than intended use.
◆ Be certain Lids are securely in place before operating appliance.
◆ Scalding may occur if the lid is removed during the brewing cycles.
◆ The carafe is designed for use with this appliance. It must never be
used on a range top.
◆ Do not set a hot carafe on a wet or cold surface.
◆ Do not use a cracked Carafe or a Carafe having a loose or
weakened handle.
◆ Do not clean carafe with cleansers, steel wool pads, or other
abrasive material.
SAVE THESE INSTRUCTIONS
For Household Use Only
1.
ADDITIONAL IMPORTANT
SAFEGUARDS
WARNING: This appliance generates heat and escaping steam during
use. Proper precautions must be taken to prevent the risk of burns,
fires, or other injury to persons or damage to property.
◆ All users of this appliance must read and understand this Use and
Care Guide before operating or cleaning this appliance.
◆ The cord to this appliance should be plugged into a 120 V AC
electrical outlet only.
◆ Use water only in this appliance! Do not put any other liquids or
food products in this appliance. Do not mix or add anything to the
water placed in this appliance, except as instructed in the User
Maintenance Instructions to clean the appliance.
◆ DO NOT attempt to move an appliance containing hot liquids.
Allow appliance to cool completely before moving.
◆ Keep appliance at least 4 inches away from walls or other objects
during operation. Do not place any objects on top of appliance while
it is operating. Place the appliance on a surface that is resistant to
heat.
◆ If this appliance begins to malfunction during use, immediately
unplug the cord. Do not use or attempt to repair the malfunctioning
appliance.
◆ If this appliance falls or accidentally becomes immersed in water or any
other liquid, unplug it immediately. Do not reach into the water! Do not
use this appliance after it has fallen into or has become immersed in
water. Contact Consumer Service for examination and repair.
◆ Do not leave this appliance unattended during use.
◆ The appliance must be left to cool down sufficiently before adding
more water to avoid splattering.
◆ Always use fresh, cool water in your appliance. Warm water or other
liquids, except as listed in cleaning section, may cause damage to the
appliance.
◆ DO NOT put carafe into a microwave.
◆ DO NOT leave empty Carafe on Warming Plate when appliance is
turned ON, as the Carafe may crack or become otherwise damaged.
◆ CAUTION: To prevent injury when utilizing Pause and Pour
(drip-stop) feature, replace Carafe within 30 seconds of removing
during brewing process.
Automatic Drip Coffeemaker Use and Care Guide
2.
Polarized Plug
This appliance has a polarized plug (one blade is wider than the other). To
reduce the risk of electric shock, this plug is intended to fit into a polarized
outlet only one way. If the plug does not fit fully in the outlet, reverse the
plug. If it still does not fit, contact a qualified electrician. Do not attempt to
modify the plug in any way.
Short Cord Instructions
A short power-supply cord is provided to reduce the risk resulting
from becoming entangled in or tripping over a longer cord.
Do not use an extension cord with this product.
Electric Power
If the electric circuit is overloaded with other appliances, your
appliance may not operate properly. It should be operated on a
separate electrical circuit from other appliances.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC
SHOCK, DO NOT REMOVE THE BOTTOM COVER. NO USERSERVICEABLE PARTS INSIDE. REPAIR SHOULD BE DONE BY
AUTHORIZED SERVICE PERSONNEL ONLY.
3.
10
12
10
8
8
6
6
4
4
2
2
Getting To Know Your Toastmaster
Coffeemaker
Product may vary slightly from Illustration.
9.
8.
1.
2.
3.
4.
FIGURE 1
1. Water Window
2. Carafe Lid Only
(P/N 30899)
3. Glass Carafe (P/N 30790)
4. Power Switch
5. Warming Plate
7.
6.
5.
6. Swing-out Filter Holder
7. Removable Filter Basket
w/ Drip Stop (P/N 30952)
8. Water Chamber Cover
9. Permanent Filter
(P/N 31127)
Automatic Drip Coffeemaker Use and Care Guide
4.
Before You Use Your Coffeemaker
Before preparing coffee in your new coffeemaker, thoroughly clean
the carafe, carafe lid and removable filter holder and permanent
filter in hot, sudsy water. Rinse and dry. Replace disassembled parts.
Clean the inside of the coffeemaker by brewing two full carafes of tap
water (see "Brewing Instructions" below). Do not place coffee in filter
holder for this initial cleaning.
Note: At the end of first cycle, turn coffeemaker off and wait ten
minutes. Turn unit on and brew second carafe of water.
Brewing Instructions
1. Plug coffeemaker into any 120 Volt, AC electrical outlet.
2. Fill carafe with cold tap water and pour into water chamber.
Markings on the carafe indicate level of water required to brew
desired number of cups. No less than two cups is recommended.
Note: The amount of brewed coffee will always be less than the
amount of water placed into coffeemaker, since about 10% is
absorbed by coffee grounds and filter.
3. Measure one level tablespoon of drip or regular grind coffee for
each cup of coffee desired. For stronger or milder coffee, adjust
amount of coffee to suit your taste. Add coffee to permanent filter
and place filter into filter holder.
4. Return filter holder to closed position.
5. Place carafe on warming plate.
6. Switch control to on.
7. If you wish to serve a cup of coffee before brew cycle is
completed, simply remove carafe from warming plate. Dripping
will automatically cease. Return carafe to position on warming
plate within a few seconds; dripping will resume.
5.
Brewing Instructions (Cont.)
8. Upon completion of the brew cycle, wait about one minute until
the brew dripping from the filter holder into the carafe has
stopped. Carafe lid should be kept in place to facilitate safe
serving and help keep coffee at proper serving temperature.
9. To keep coffee hot, return carafe to the warming plate after
serving. The warming plate will automatically cycle to maintain
ideal serving temperature as long as the coffeemaker is on.
10. Switch coffeemaker to off when carafe is empty or when unit is
not in use.
11. To brew another carafe of coffee, turn unit off and wait
10 minutes to allow heating element to cool. Important: If unit is
not allowed to cool before immediate repeated use, water placed
in water chamber may become overheated and a spray of steam
could be released from opening, creating a risk of burns.
Brewing A Second Pot Of Coffee
As mentioned above, it is recommended that the coffeemaker should
be in off position for 10 minutes between cycles, in order to allow
unit to cool. While unit is in off position, rinse carafe and permanent
filter and holder in water. Repeat brewing procedure.
Hints for Great Tasting Coffee
A clean coffeemaker is essential for making great tasting coffee.
Regular cleaning, as specified in "Care and Cleaning of your
Coffeemaker" on page 7 is highly recommended.
Always use fresh, cold water in your coffeemaker.
Finer grinds, such as drip and ADC coffee, promote fuller
extraction and provide rich, full-bodied coffee. Regular grind will
require slightly more coffee per cup to provide the strength of a
finer grind.
Automatic Drip Coffeemaker Use and Care Guide
6.
Hints for Great Tasting Coffee
Store coffee in a cool, dry place. Once coffee has been opened,
keep it tightly sealed in the refrigerator to maintain freshness.
For optimum coffee, buy whole beans and grind them finely just
before brewing.
Do not re-use coffee grounds since this will greatly impair coffee
flavor.
Reheating coffee is not recommended. Coffee is at its peak flavor
immediately after brewing.
Small oil droplets on the surface of brewed, black coffee is due to the
extraction of oil from the coffee grounds. Oiliness may occur more
frequently if heavily roasted coffees are used. Over extraction may
also cause oiliness, indicating a need to clean your coffeemaker.
User Maintenance Instructions
This appliance requires little maintenance. It contains no user
serviceable parts. Do not try to repair it yourself. Refer it to a
qualified appliance repair technician if servicing is needed.
Care And Cleaning
Always make sure coffeemaker is unplugged and warming plate is
cool before attempting to clean. After daily use, the filter holder,
permanent filter and carafe should be washed in hot, sudsy water.
Wipe exterior with a damp cloth to remove superficial stains. For
stubborn stains, use a nylon or plastic pad with a non- abrasive
cleanser, such as Bon Ami®or Arm & Hammer®. Do not use metal
scouring pads or abrasive cleansers.
Special cleaning of your coffeemaker is recommended at least once a
month, depending on frequency of use and quality of water used in
the unit. If water in your area is especially hard, the following
cleaning procedure should be performed every two weeks, since
minerals in water can detract from the flavor of the coffee and
possibly lengthen brew time.
7.
Care And Cleaning (Cont.)
1. Fill carafe with one part white vinegar to three parts cold water.
Pour water and vinegar solution into the water chamber.
2. Place the permanent filter in the filter holder and swing to closed
position. Place carafe on warming plate. Switch control to on. During
cleaning, more steam will occur than during normal brewing.
3. KEEP THE COFFEEMAKER ON UNTIL CARAFE IS HALF FULL.
Switch control to off. When liquid stops dripping from filter holder
into the carafe, remove the holder and carafe and allow liquid to
cool in the carafe for 10 minutes. When cooled, pour liquid back
into the water chamber.
4. Replace holder and return carafe to warming plate.
5. Switch control to on. Repeat procedure, allowing all the cleaning
solution to empty into the carafe. After dripping has stopped,
discard contents of carafe.
6. After allowing coffeemaker to cool for 10 minutes, rinse it out by
brewing a carafe full of cold water.
7. At end of brew cycle, switch control to off. Discard water in the
carafe. Remove permanent filter and wash carafe and filter holder
in hot sudsy water. Dry parts.
8. When coffeemaker has cooled, wipe exterior with a dry cloth.
Automatic Drip Coffeemaker Use and Care Guide
8.
LIMITED ONE YEAR WARRANTY
Warranty: This Toastmaster®product is warranted to be free from defects in materials or workmanship for a period of
(1) year from the original purchase date. This product warranty covers only the original consumer purchaser of the
product.
Warranty Coverage: This warranty is void if the product has been damaged by accident in shipment, unreasonable
use, misuse, neglect, improper service, commercial use, repairs by unauthorized personnel, normal wear and tear,
improper assembly, installation or maintenance abuse or other causes not arising out of defects in materials or
workmanship. This warranty is effective only if the product is purchased and operated in the USA, and does not extend
to any units which have been used in violation of written instructions furnished with the product or to units which have
been altered or modified or to damage to products or parts thereof which have had the serial number removed,
altered, defaced or rendered illegible.
Implied Warranties: ANY IMPLIED WARRANTIES WHICH THE PURCHASER MAY HAVE ARE LIMITED IN DURATION
TO ONE (1) YEAR FROM THE DATE OF PURCHASE. Some states do not allow limitations on how long an implied
warranty lasts, so the above limitation may not apply to you.
Warranty Performance: During the above one-year warranty period, a product with a defect will be either repaired or
replaced with a reconditioned comparable model (at our option) when the product is returned to the Repair Center, or
the purchase price refunded. The repaired or replacement product will be in warranty for the balance of the one-year
warranty period and an additional one-month period. No charge will be made for such repair or replacement.
Service and Repair: Should the appliance malfunction, you should first call toll-free 1 (800) 947-3744 between the hours
of 9:00 am and 5:00 pm Central Standard Time and ask for CONSUMER SERVICE stating that you are a consumer with
a problem. Please refer to model number TCM10PWF when you call.
In-Warranty Service (USA): For an appliance covered under the warranty period, no charge is made for service or
postage. Call for return authorization (1 800 947-3744).
Out-of Warranty Service: A flat rate charge by model is made for out-of-warranty service. Include $ 8.00 (U.S.) for
return shipping and handling. We will notify you by mail of the amount of the charge for service and require you to pay
in advance for the repair or replacement.
For Products Purchased in the USA, but Used in Canada: You may return the product insured, packaged with
sufficient protection, and postage and insurance prepaid to the USA address listed below. Please note that all customs
duty / brokerage fees, if any, must be paid by you and we will require you to pay the cost of customs duty /
brokerage fees to us in advance of our performing any service.
Risk During Shipment: We cannot assume responsibility for loss or damage during incoming shipment. For your
protection, carefully package the product for shipment and insure it with the carrier. Be sure to enclose the following
items with your appliance: any accessories related to your problem, your full return address and daytime phone
number, a note describing the problem you experienced, a copy of your sales receipt or other proof of purchase to
determine warranty status. C.O.D. shipments cannot be accepted.
To return the appliance, ship to:
Attn: Repair Center
Toastmaster Inc.
708 South Missouri Street
Macon, MO 63552
Email: consumer_relations@toastmaster.com
www.toastmaster.com
Limitation of Remedies: No representative or person is authorized to assume for us any other liability in connection
with the sale of our products. There shall be no claims for defects or failure of performance or product failure under
any theory of tort, contract or commercial law including, but not limited to negligence, gross negligence, strict liability,
breach of warranty and breach of contract. Repair, replacement or refund shall be the sole remedy of the purchaser
under this warranty, and in no event shall we be liable for any incidental or consequential damages, losses or
expenses. Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above
limitation or exclusion may not apply to you.
Legal Rights: This warranty gives you specific legal rights, and you may also have other rights which vary from state to
state.
To contact us, please write to or call:
Toastmaster Inc.
P. O. Box 6916
Columbia, MO 65205-6916
1 (800) 947-3744
© 2004 Toastmaster Inc. P/N 61460
All Rights Reserved Printed in China
9.
Keep Dated Sales Receipts for Warranty Service.
Keep this booklet. Record the following for reference:
Date purchased _______________________________________________
Model number _______________________________________________
Date code (stamped on bottom)________________________________
EVERYBODY EATS. It’s a fact of life.
But sometimes preparing
meals can become a chore.
That’s why TOASTMASTER has been invited
into millions of kitchens just like yours
so we can HELP YOU MASTER your
mixing, baking, grilling, toasting,
brewing, heating and serving
tasks WITH EASE AND STYLE.
The TOASTMASTER name stands for a
CELEBRATION of INNOVATION designed
to serve your life and keep you
Automatic Drip Coffeemaker Use and Care Guide
10.
COOKIN’ IN STYLE.
Contact Information
Coordonnées :
Contacte a:
National Service Center
708 South Missouri Street
Macon, Mo 63552
In USA and Canada call:
Consumer Service: 1-800-947-3744
Consumer Parts: 1-800-947-3745
consumer_relations@toastmaster.com
Hours: 8:00
Aux USA et au Canada, appeler les numéros suivants :
Service Consommateurs : 1-800-947-3744
Pièces Consommateurs : 1-800-947-3745
consumer_relations@toastmaster.com
Horaires : De 8h00 à 17h30, heure GMT - 6
En México:
Toastmaster de México, S.A. de C.V.
Cerrada de Recursos
Hidráulicos Número 6
La Loma Industrial
Tlalnepantla de Baz, C.P. 54060
Estado de México
52-5-397-2848
Horario: 8:00 a.m. hasta 5:30 p.m., hora del Centro
A.M.- 5:30 P.M. CST
© 2004 Toastmaster Inc.
A Subsidiary of Salton, Inc.
Subsidiaire de Salton, Inc.
A una Subsidiaria de Salton, Inc.
11.
Automatic Drip Coffeemaker Use and Care Guide
12.
?
• Swing-out Cone Filter Holder
•Water Level Indicator
• Power Light
• Non-stick Warming Plate
Questions
Call toll free 1-800-947-3744
Monday– Friday, 8:00 a.m.- 5:30 p.m. CST
www.toastmaster.com
TCM10PWF
Loading...
