HX

Compact Array Speaker System

New innovations in sound reinforcement.

-

5 Series

15 degrees

30 degrees

45 degrees

60 degrees

HX Series

TOA,s new HX-5 Series Speaker

System fills an important need

for versatile public address

—

Full area coverage

equipment that can provide

high quality reinforcement for

a wide range of venues.

Available in black and white

finishes to complement a venue,s

interior color scheme, the HX-5 Series is

ideal for a wide range of medium size

venues of all different shapes that often

pose problems for sound reinforcement.

These include auditoriums, places of

worship, banquet halls, community centres

as well as dance halls, sports bars,

shopping malls, boardrooms, gyms, health

clubs and many others.

HX-5B /HX-5B-WP

Design background

The HX-5 is an innovative modular speaker design that
incorporates the best characteristics of the traditional,
cumbersome woofer enclosure combined with a CD
horn-loaded high frequency driver and the full-range
compact speaker enclosure without the drawbacks
associated with each type.
The traditional speaker system was able to provide
well-controlled sound coverage but posed various
difficulties for correct installation and also presented
an old-fashioned appearance as well that impacts on
the venue,s appearance. The full-range compact
speaker enclosure is easy to install, but the design,s
sound coverage is hard to control.
The HX-5 features remarkably easy to control
coverage characteristics including problematic low
frequencies and can be installed in a multitude of ways
while maintaining
a modern,
unobstrusive
appearance.

Directivity

changeable

speaker

Large-scale

CD horn
