CPU-52A
Functions and
Operating Instructions
TOA ELECTRIC C O. , LTD.
KOBE, JAPAN
Master Station
Keyboard Allocation
Keyboa r d Functions
Standard Functions
Optional Functions
Conference
Personal number c a l l
and single-digit
number programming
MIC-Off
Paging
Paging response,
priority, executive
priority
Clear entry
Single-digit dialing
Conversation over
Regardless of the station keyboard, the following functions are included as standard.
Automatic Line Release
When, in dialing, all of the numbers are not dialed within 5 seconds, the station is automatically disconnected
from the speech path and dialing cannot be completed. In this instance, the dialing process will have to be
repeated from the beginning.
This function has been adopted to speed up traffic processing and to improve the availability of speech paths.
Camp-On-Busy
When the party you are calling is on another line, by simply waiting you automatically "Camp-On" the line.
(Busy tone sounds continuously.) As soon as the line is freed, you will be automatically connected.
Camp-On-Privacy
When the party you are calling has his station on Privacy mode, by simply waiting you will automatically
"Camp-On" the line. (Busy tone sounds countinuously.) As soon as the Privacy mode is released, yo u will be
automatically connected.
— 1 —
STANDARD FUNCTIONS
Name of function
Description of function
Operation
Privacy
When a party does not wish to accept incoming calls, this function may be employed to
refuse them. With the Privacy switch in the
ON position, a continuous privacy tone will
be sounded in the station making the call,
and at the same tim e, a brief Pri vacy ton e wil l
sound in the station called, indicating a call
attempt is being made.
Shift Privacy Switch to ON.
PRIVACY
ON
To restore a station in the "Privacy" mode to
a normal condition, and thus ready to receive
or make calls.
Shift Privacy Switch back to the left.
PRIVACY
ON
Note 1:
A call received while the station is in the
Privacy mode may be accepted if the Privacy
function is immediately cancelled, (see CampOn Privacy)
Note 2:
With a station that incorporates the Secretary
Transfer function, the Privacy switch is used
to activate the Secretary Transfer function,
(see Secretary Transfer)
Note 3:
During the above "Privacy" mode, while
the calling station has the PTT bar depressed,
the privacy tone stops and the caller can
transmit a one way message.
When the PTT bar is released, the normal
"Privacy" mode t o be resumed.
Mic Off
This function is used when for one reason or
another it is desirable to stop a conversation
temporarily. With this function in use, a holding tone is transmitted to both the calling and
the called station while the conversation is
interrupted.
Touch dialing of
during a conversation
turns off that station's microphone, and a
holding tone is heard at both stations involved.
When it is desirable to resume the conversation interrupted with the Mic-Off function,
the function may be cancelled by the Party
who operate the Mic-O ff.
Touch dialing
again cancels the Mic-Off
function, and the conversation can be resumed.
— 2 —
