Toa DA-1000F Operating Instructions Manual
OPERATING INSTRUCTIONS
MULTICHANNEL POWER AMPLIFIER
DA-1000F
1.
IMPORTANT SAFETY INSTRUCTIONS
........................................................................................ 2
2.
SAFETY PRECAUTIONS
................................................................................................................. 2
3. GENERAL DESCRIPTION . ...............................................................................................................
5
4.
NOMENCLATURE AND FUNCTIONS
............................................................................................. 5
5.
CONNECTIONS
............................................................................................................................... 7
6.
SYSTEM CONNECTION CASES
..................................................................................................... 8
7.
THERMAL DISSIPATION
................................................................................................................ 9
8. POWER LEVEL ADJUSTMENT .......................................................................................................10
9.
TROUBLESHOOTING
.....................................................................................................................11
10.
SPECIFICATIONS
............................................................................................................................12
11.
DIMENSIONAL DIAGRAM
...............................................................................................................12
TABLE OF CONTENTS
Thank you for purchasing TOA's Multichannel Power Amplifier.
Please carefully follow the instructions in this manual to ensure long, trouble-free use of your equipment.
1. IMPORTANT SAFETY INSTRUCTIONS
Read these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.
Do not use this apparatus near water.
Clean only with dry cloth.
Do not block any ventilation openings. Install in accordance with the manufacturer's
instructions.
Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus(including amplifiers) that produce heat.
Do not defeat the safety purpose of the polarized or grounding-type plug. A grounding
type plug has two blades and a third grounding prong. If the provided plug does not fit into
your outlet, consult an electrician for replacement of the obsolete outlet.
Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles, and the point where they exit from the apparatus.
Only use attachments/accessories specified by the manufacturer.
Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or
sold with the apparatus. When a cart is used, use caution when
moving the
cart/apparatus combination to avoid injury from tip-over.
Unplug this apparatus during lightning storms or when unused
for long periods of time.
Refer all servicing to qualified service personnel. Servicing is
damaged in
any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does
not operat
e normally, or has been dropped.
Servicing is required when the apparatus has been
2. SAFETY PRECAUTIONS
Before installation or use, be sure to carefully read all the instructions in this section for
correct and safeoperation.
Be sure to follow all the precautionary instructions in this section, which contain important
warnings and/or cautions regarding safety.
After reading, keep this manual handy for future reference.
Safety Symbol and Message Conventions
Safety symbols and messages described below are used in this manual to prevent bodily injury
and property damage which could result from mishandling. Before operating your product,
read this manual first and
understand the safety symbols and messages so you are thoroughly
The exclamation point within an equilateral triangle is intended to alert the user to
the presence of important operation and maintenance (servicing) instruction in
the literature accompanying the appliance.
aware of the potential safety hazards.
Indicates a potentially hazardous situation which, if
mishandled, could result in death or serious personal
WARNING
injury.
2
When Installing the Unit
Do not expose the unit to rain or an environment where it may be splashed by water or other
liquids, as doing so may result in fire or electric shock.
Use the unit only with the voltage specified on the unit. Using a voltage higher than that which
is specified
may result in fire or electric shock.
Do not cut, kink, otherwise damage nor modify the power supply cord. In addition, avoid using
the power
cord in close proximity to heaters, and never place heavy objects -- including the unit
itself -- on the power cord, as doing so may result in fire or electric shock.
Avoid installing or mounting the unit in unstable locations, such as on a rickety table or a
slanted surface. Doing so may result in the unit falling down and causing personal injury and/or
External wiring connected to the terminals marked with requires installation by an instructed
The apparatus shall be connected to a mains socket outlet with a protective earthing connection.
The socket-outlet shall be installed near the equipment and the plug (disconnecting device) shall
be easily accessible.
When the Unit is in Use
Should the following irregularity be found during use, immediately switch off the power, disconnect
the powersupply plug from the AC outlet and contact your nearest
TOA dealer. Make no further
attempt to operate the unit in this condition as this may cause fire or electric shock.
· If you detect smoke or a strange smell coming from the unit
· If water or any metallic object gets into the unit
· If the unit falls, or the unit case breaks
· If the power supply cord is damaged (exposure of the core, disconnection, etc.)
· If it is malfunctioning (no tone sounds.)
components inside the unit. Refer all servicing to your nearest TOA dealer.
property damage.
person.
To prevent a fire or electric shock, never open or remove the unit case as there are high voltage
Do not place cups, bowls, or other containers of liquid or metallic objects on top of the
unit. If they accidentally spill into the unit, this may cause a fire or electric shock.
Do not insert nor drop metallic objects or flammable materials in the ventilation slots of the
unit's cover, as this may result in fire or electric shock.
When Installing the Unit
Never plug in or remove the power supply plug with wet hands, as doing so may cause electric
shock.
When unplugging the power supply cord, be sure to grasp the power supply plug; never pull
on the cord itself. Operating the unit with a damaged power supply cord may cause a fire or
When moving the unit, be sure to remove its power supply cord from the wall outlet. Moving the unit
with the power cord connected to the outlet may cause damage to the power cord, resulting in fire
or electric shock. When removing the power cord, be sure to hold its plug to pull.
Indicates a potentially hazardous situation which, if mishandled
,
could result in moderate or minor personal injury, and/or property
CAUTION
damage.
electric shock.
3
Do not block the ventilation slots in the unit's cover. Doing so may cause heat to build up
inside the unit and result in fire.
Avoid installing the unitinhumid or dustylocations, inlocations exposed to the directsunlight,
near theheaters,
or in locations generatingsooty smoke or steam as doing otherwise may
resultinfire or
electricshock.
To avoid electric shocks, be sure to unplug the unit's power supply cord when connecting
speakers.
Be sure to follow the instructions below when rack-mounting the unit. Failure to do so may
cause a fire or personal injury.
· Install the equipment rack on a stable, hard floor. Fix it with anchor bolts or take other
arrangements to prevent it from falling down.
· When connecting the unit's power cord to an AC outlet, use the AC outlet with current
capacity allowable to the unit.
· No rack-mounting screws are supplied with the unit. Separately prepare the appropriate
screws for the rack.
When the Unit is in Use
Do not place heavy objects on the unit as this may cause it to fall or break which may
result in personal injury and/or property damage. In addition, the object itself may fall off and
cause injury and/or damage.
Make sure that the volume control is set to minimum position before power is switched on.
Loud noise produced at high volume when power is switched on can impair hearing.
Do not operate the unit for an extended period of time with the sound distorting. This is an
indication of a malfunction, which in turn can cause heat to generate and result in a fire.
If dust accumulates on the power supply plug or in the wall AC outlet, a fire may result. Clean
it periodically.In addition, insert the plug in the wall outlet securely.
Switch off the power, and unplug the power supply plug from the AC outlet for safety
purposes when cleaning or leaving the unit unused for 10 days or more. Doing otherwise may
cause a fire or electric shock.
Clean the unit regularly
Contact your TOA dealer as to the cleaning. If dust is allowed to accumulate in the unit
over a long period of time, a fire or damage to the unit may result.
Clean the power supply plug
If dust accumulates on the power supply plug or in the wall AC outlet, a fire may result.
Clean it periodically. In addition, insert the plug in the wall outlet securely.
During maintenance or leaving the unit unused
Turn off this unit's power switch, and unplug the power su
pply plug from the AC outlet for
safety purposes when cleaning or leaving the unit unused for 10 days or more. Doing
otherwise may cause a fire or electric shock.
The lighting flash with arrowhead symbol, within an equilateral triangle, is intended
to alert the user
to the presence of uninsulated "dangerous voltage" within the
product's enclosure that may be of
sufficient magnitude to constitute a risk of
electric shock to persons.
4
