Engine Breakdown Catalogue for SS49
QJ1E40QMB-4 (1010208.04101)
1 气缸总成 CYLINDER HEAD ASSY
NO QJ CODE DESCRIPTION QTY
1 30701B01F00A HEAD，CYLINDER 1
2 30507B01F000 GASKET，CYLINDER HEAD 1
3 201204.013000 SPARK PLUG 1
4 27101B01F00A CYLINDER 1
5
204204.001000
6 26107B01F910 STUD BOLT 4
304290700062
7
2 曲轴箱分总成 CRANKCASE ASSY
NO QJ CODE DESCRIPTION QTY
1
206200.045000
2 26108G02F000 BUSH,ENGINE MOUNTING 1
3 B12016600300 BEARING 6003-2RS 2
4 26211B09F001 CRANKCASE,RH 1
5 26142G02F000 BRAKE SHOE 1
6 26123G02F000 DOWEL PIN 12X16 2
7 301310603565 PAN HEAD SCREW M6X35 6
8 26109B09F000 AXLE,engine mount 1
9 B08010001700 CIRCLIP 17 2
10 B04070812553 NUT M8 1
11 26214B09F000 BEARING HOLDER 1
12 B02000601262 PAN HEAD SCREW M6X12 2
13
14222J01F000
GASKET，CYLINDER 1
NUT 4
CRANKCASE,LH 1
O-RING 1
RMK
BR8HSA
RMK
14 26123G02F000 DOWEL PIN 12X16 2
15
214201.004000
GASKET，GEAR BOX 1
16 18101B09F000 COVER, GEAR BOX 1
17
206407.004081
OIL PLUG 1
Black
18 26102G02F000 O RING 1
19
301310801605
FLANGE BOLT M8X16 1
chrome
20 18105H03F000 PLATE WASHER 8 1
21 26214G02F910 OIL SEAL HOLDER 1
22 301310601263 PAN HEAD SCREW M6X12 1
23
206321.001000
GASKET 1
24 301310805565 SCREW M8Χ55 2
25 301310805065 SCREW M8Χ50 5
207234.001000
26
bush 1
color zinc
chrome
chrome
3 侧盖分总成 SIDECOVER ASSY
序号 代码 数量 备注
NO QJ CODE DESCRIPTION QTY
RMK
1 207208.017000 GASKET,L CRANKCASE 1
2
207200.001082
L CRANKCASE COVER 1
3 26128G02F000 IDLE GEAR 1
4 26208J01F000 DOWEL PIN 2
5 301310602565 PAN HEAD SCREW M6X25 8
6 301310603565 PAN HEAD SCREW M6X35 1
7 301310606565 PAN HEAD SCREW M6X65 1
8 302460601265 PAN HEAD SCREW 2
chrome
chrome
chrome
chrome
4 活塞连杆曲轴分总成 PISTON CRANKSHAFT CONNECTING ROD ASSY
序号 代码 数量 备注
NO QJ CODE DESCRIPTION QTY
RMK
1 208100.022000 CRANKSHAFT，ASSY 1
2 15100B01F000 PISTON ASSY 1
Europe I
3 15105B16F000 PISTON PIN 1
4 15103B01F000 PISTON RING ASSY 2
AVL
5 15111G02F000 CIRCLIP 2
6
15110B16F000
NEEDLE BEARING 1
TPI
7 15101B01F000 WOODRUFF KEY 1
8 B12016620453
BALL BEARING
TPI
2
9 15213G02F000 OIL SEAL 1
10 26215G02F000 OIL SEAL ASSY 1
11 15214G02F000 COLLAR 1
12 17308G02F000 CIRCLIP 1
5 机油泵分总成 OIL PUMP ASSY
序号 代码 数量 备注
NO QJ CODE DESCRIPTION QTY
1 219101.008000 OIL PUMP ASSY 1
RMK
Mark 502
2 B02000501463 SCREW 2
3 15211G02F000 PUMP DRIVE GEAR 1
4 B090103014C0 PIN 1
5 15106G02F910 CIRCLIP 2
6 221405.100000
7 19213G02F00A HOSE CLIP 2
8 221405.101000
9 19217G02F00A HOSE CLIP 2
HOSE,OIL INLET
HOSE,OIL OUTLET
1
chrome
1
chrome
6 导风罩分总成 AIR COOLING SYSTEM
序号 代 码 数量 备注
NO QJ CODE DESCRIPTION QTY
RMK
1 20301B01F000 COWLING,cylinder 1
2 20303G02F000 GROMMET 2
3 20201B09F000 COELING,fan 1
4 20208G02F000 BEADING (RUBBER) 1
AVL
110
5 222103.009000 COVER ASSY (FAN) 1
6 20401B01F000 FAN ASSY 1
7 20402G02F000 RUBBER RING 70X3.1 1
8 B02000601663 SCREW M6X16 3
9 B07000000600 SPRING WASHER φ6 3
10 B07030000600 WASHER φ6 3
11 20102G02F000 DUST COVER (RUBBER) 1
12 20206G02F000 BEADING (RUBBER) 1
220
13 20208B09F000 COLLOR 3
14 222304.102000 COVER 1
15 302210403564 SCREW M4X35 3
7 起动分总成 KICK STARTER ASSY
序号 代码 数量 备注
NO QJ CODE DESCRIPTION QTY
RMK
1 34120G02F000 START GEAR ASSY 1
2 34121G02F000 NEEDLE BEARING 1
3 34123G02F000 THRUST WASHER 1
4 34110G02F00A STARTER CLUTCH ASSY.COMP 1
5 34126G02F000
DRIVEN GEAR,STARTER
1
6 26128G02F000 IDLE GEAR SHAFT 1
7 34122G02F000 PLATE WASHER 1
8 34125G02F000 IDLE GEAR HOLDER 1
9 301310601062 SCREW 2
10 302040602065 SCREW 2
11
216100.004000
SHAFT, kick starter 1
12 17407G02F000 SPRING 1
13 216217.001000 BUSH 1
14
307991005552
WASHER ,kick starter 1
15 308090150003 CIRCLIP 1
16 17415G02F000 KICK PINION ASSY 1
17 17418G02F930 CLIP 1
18 218100.017472 STARTING MOTOR ASSY(460-470mm) 1
19 B190102120B0 O-RING 1
20 34130G02F000 PLATE WASHER 1
21
217100.100000
START CLUTCH ASSY, COMP. 1
22 34404G02F00A SPRING 3
23 34405G02F00A CAP 3
24 34402G02F00A ROLLER 3
8 传动机构总成 CLUTCH ASSY
序号 代码 数量 备注
NO QJ CODE DESCRIPTION QTY
1 24201B09F000
PRIMARY DRIVE SHAFT
RMK
1
2 18114G02F000 PLATE WASHER 1
3 B01090801263 PAN HEAD SCREW 1
4 B08010001700 CIRCLIP 1
5 B12016620300 BEARING 6203 1
6 24203B09F000 OIL SEAL 1
7 24301B01F000 CLUTCH ASSY,shoe 1
8 24245G02F000 ROLLER BEARING 1
9 24303G02F000 NUT 1
10 24700G02F000 CLUTCH DRUM 1
11 24305G02F940 NUT 1
12 24243G02F000 O-RING 1
13 24209G02F000 BEARING 638Z 1
14 24101G02F000 FACE,movable drive 1
15 213119.004000 ROLLER 6
4g
16 24103G02F000 PLATE,movable drive 1
17 24104G02F000 DAMPER 3
18 24105G02F000 COLLER 1
19 24106B01F000 WASHER 1
20 24107B01F000 V BELT，DRIVE 1
21 24108G02F000 FACE，FIXED DRIVE 1
22 24109G02F000 PLATE，WOODRUFF KEY 1
23
213203.001161
STARTING DISC 1
24 15112G02F010 WASHER，SPRING 1
25 B04031212553 NUT 1
26 24204G02F000 FACE，FIXED DRIVEN 1
27 24205G02F000 FACE，MOVABLE DRIVEN 1
28 24206G02F000 OIL SEAL 1
29 24207G02F000 O-RING 2
30 24308B01F000 SPRING 1
31 24309G02F930 SEAT，SPRING 1
32 24200B01F000 DRIVEN PULLY and CLUTCH ASSY 1
33 24100B09F000 DRIVE ASSY 1
34 213100.009000 SHIFT ASSY 1
35 24208G02F000 PIN，GUIDE 2
4g
9 变速系统分总成 TRANSMISSION SYSTEM ASSY52-4
序号 代码 数量 备注
NO CODE QTY
1 17800G16F000
SHAFT，IDLE
RMK
1
2 B12016620000 BEARING 6200 1
3 17802J01F000
4 17300G16F000
WASHER，PLANE
DRIVEN SHAFT(GEAR BOX)
1
1
5 B12016600400 NEEDLE BEARING 1
6 17317B09F000 OIL SEAL 1
7 B12016620200 NEEDLE BEARING 1
10 进气阀分总成 REED VALVE ASSY
序号 代码 数量 备注
NO QJ CODE DESCRIPTION QTY
RMK
1 32300G02F000 REED VALVE ASSY 1
2
202306.002000
3 302040602065 SCREW 4
VALVE SEAT GASKET 1
chrome
4 32200G02F000 PIPE, intake 1
202104.006000
5
CLIP 1
11 磁电机总成 MAGNETO ASSY
序号 代码 数量 备注
NO QJ CODE DESCRIPTION QTY
1 34310G02F000
COIL ASSY
2 223100.100000 MAGNETO ASSY 1
RMK
1
15°
3 34330G02F000 PULSE TRIGGER 1
4 34350G02F000 OIL SEAT 1
5 B02000502522 SCREW 2
6 B02000501262 SCREW 2
7 B02000400622 SCREW 1
8 B07000000400 SPRING WASHER 1
9
223101.019000
FLY WHEEL ASSY
15°
1
10 B07030001200 WASHER 1
11 15228H03F000 NUT 1
12 B01070601664 NUT 2
12 化油器分总成 CARBURETORASSY
序号 代码 数量 备注
NO CODE QTY
RMK
1 32510B01F000 NEEDLE, jet 1
2 32511B01F000 VALVE,PISTON 1
3 224202.100000 JET, main 1
4 32612B01F000
5 32619B01F000 PIN, float 1
6 32620B01F000 FLOAT 1
7 32701B01F000 GASKET 1
32609B01F000 JET, idle
8
9
224100.042000
10 32508B01F000 CLIPMM,V shape 1
ENRICH VALVE
CARBURETOR ASSY 1
70
1
1
