t&mSystems 120MP, 240MP User Manual
OPERATION MANUAL
PROJECT120MP
PROJECT240MP
PROJECT120MP
USB
MIC 1
MP3 PLAYER
PREV
PLAY
MIC 1 MIC 2 MIC 3 AUX 1 AUX2 BASS
MP3 VOL
RPT
NEXT
-5
PROT
TEMP
OUTPUT LEVEL
4 6
10
8
2
TREBLE
0
0
+5
-5
12
MASTER
+5
POWER
Please follow the instructions in this manual to obtain the optimum results from this unit.
We also recommend that you keep this manual handy for future reference.
TABLE OF CONTENTS
1. GENERAL DESCRIPTION ....................................................................................5
2. FEATURES ...............................................................................................................5
3. NOMENCLATURE AND FUNCTIONS
3.1 Front Panel .............................................................................................................6
3.2 Rear Panel..............................................................................................................7
4. OPERATION METHOD
4.1 Operation Method....................................................................................................8
4.2 Mute function.......................................................................................................... 8
4.3 Warnings ............................................................................................................... 8
5. CONNECTING METHOD........................................................................................ 8
6. FAULT REMOVAL ...................................................................................................9
APPLICATIONS
7. ................................................................................................... .10
BLOCK DIAGRAM
8. ................................................................................................ 11
SPECIFICATIONS
9. ................................................................................................ 12
DIMENSIONAL DIAGRAMS
10. ............................................................................ 13
2
SAFETY PRECAUTIONS
Be sure to read the instructions in this section carefully before use.
Make sure to observe the instructions in this manual as the conventions of safety symbols and messages
regarded as very important precautions are included.
We also recommend you keep this instruction manual handy for future reference.
Safety Symbol and Message Conventions
Safety symbols and messages described below are used in this manual to prevent bodily injury and property
damage which could result from mishandling. Before operating your product, read this manual first and
understand the safety symbols and messages so you are thoroughly aware of the potential safety
Indicates a potentially hazardous situation which, if mishandled, could
result in death or serious personal injury.
Indicates a potentially hazardous situation which, if mishandled, could
result in moderate or minor personal injury, and/or property damage.
When Installing the Unit
Do not expose the unit to rain or an environment
where it may be splashed by water or other liquids,
as doing so may result in fire or electric shock.
Use the unit only with the voltage specified on the
unit. Using a voltage higher than that which is
specified may result in fire or electric shock.
Do not cut, kink, otherwise damage nor modify the
power supply cord. In addition, avoid using the
power cord in close proximity to heaters, and never
place heavy objects -- including the unit itself -- on
the power cord, as doing so may result in fire or
electric shock.
Be sure to replace the unit's terminal cover after
connection completion. Because high voltage is
applied to the speaker terminals, never touch these
terminals to avoid electric shock.
Be sure to ground to the safety ground (earth)
terminal to avoid electric shock. Never ground to a
gas pipe as a catastrophic disaster may result.
When the Unit is in Use
Should the following irregularity be found during
use, immediately switch off the power, disconnect
the power supply plug from the AC outlet and
contact your nearest dealer.Make no further attempt
to operate the unit in this condition as this may cause
fire or electric shock.
If you detect smoke or a strange smell coming
from the unit.
If water or any metallic object gets into the unit
If the unit falls, or the unit case breaks
If the power supply cord is damaged (exposure of
the core, disconnection, etc.)
If it is malfunctioning (no tone sounds.)
To prevent a fire or electric shock, never open nor
remove the unit case as there are high voltage
components inside the unit. Refer all servicing to
your nearest dealer.
Do not place cups, bowls, or other containers of
liquid or metallic objects on top of the unit. If they
accidentally spill into the unit, this may cause a fire
or electric shock.
Avoid installing or mounting the unit in unstable
locations, such as on a rickety table or a slanted
surface. Doing so may result in the unit falling
down, causing personal injury and/or property
damage.
Do not insert nor drop metallic objects or
flammable materials in the ventilation slots of the
unit's cover, as this may result in fire or electric
shock.
3
SAFETY PRECAUTIONS
When Installing the Unit
Never plug in nor remove the power supply plug
with wet hands, as doing so may cause electric
shock.
When unplugging the power supply cord, be sure
to grasp the power supply plug; never pull on the
cord itself. Operating the unit with a damaged
power supply cord may cause a fire or electric
shock.
When moving the unit, be sure to remove its power
supply cord from the wall outlet. Moving the unit
with the power cord connected to the outlet may
cause damage to the power cord, resulting in fire or
electric shock. When removing the power cord, be
sure to hold its plug to pull.
Do not block the ventilation slots in the unit's cover.
Doing so may cause heat to build up inside the unit
and result in fire.
Avoid installing the unit in humid or dusty locations,
in locations exposed to the direct sunlight, near the
heaters, or in locations generating sooty smoke or
steam as doing otherwise may result in fire or
electric shock.
When the Unit is in Use
Do not place heavy objects on the unit as this may
cause it to fall or break which may result in
personal injury and/or property damage. In
addition, the object itself may fall off and cause
injury and/or damage.
Make sure that the volume control is set to
minimum position before power is switched on.
Loud noise produced at high volume when power is
switched on can impair hearing.
Do not operate the unit for an extended period of
time with the sound distorting. This is an indication
of a malfunction, which in turn can cause heat to
generate and result in a fire.
Contact your dealer as to the cleaning. If dust is
allowed to accumulate in the unit over a long
period of time , a fire or damage to the unit may
result.
If dust accumulates on the power supply plug or in
the wall AC outlet, a fire may result. Clean it
periodically. In addition, insert the plug in the wall
outlet securely.
Switch off the power, and unplug the power supply
plug from the AC outlet for safety purposes when
cleaning or leaving the unit unused for 10 days or
more. Doing otherwise may cause a fire or electric
shock.
An all-pole mains switch with a contact separation of at least 3 mm in each pole shall be incorporated in
the electrical installation of the building.
4
1. GENERAL DESCRIPTION
The USB mixer power rated from 60W to 240W. They are featured of 3 balanced microphone
inputs, 2 aux inputs and 2 EMC inputs. Priority muting is achieved via EMC1-2 for overriding other
inputs except Mic1 on front panel. Individual gain controls are provided for Mic 1-3 and Aux 1-2, bass
and treble controls and master volume control are provided for overall tone control.70V, 100V and low
mpedance 4-16ohms speaker outputs are provided. Extensive protection from short-circuit, overload
and high temp.
2. FEATURES
1. The power rating of each channel is from 60W to 240W.
2. Protection of short-circuit, overload and overheating.
3. The priority function of the channel: MIC1>EMC IN>MIC2,MIC3,AUX1,AUX2,MIC2 LINE IN,MIC3 LINE IN.
4. With master volume control and treble & bass controls.
5. With USB interface, the playing tracks can be displayed on the panel with 4 common function keys:
PREV/PLAY/NEXT/RPT.
6. USB can be controled by the remote, on which there are common function keys: EQ/VOL-/VOL+/MUTE
and so on.
7. Built-in level indicator, overloading and protection indicators.
5
