Page 1
ESTABLISHED 1923
Calvin
Calvin
Calvin
Features
16” diameter reflector provides excellent coverage and uniformity, suitable
for general and localized lighting
Choice of LED or incandescent source
Smooth dimming without any color shift
Surge suppressor protects the internal components
Quality components combined with the most current technology for high
efficiency and reduced lighting costs
Applications
Calvin is ideal for illuminating indoor spaces where the quality of light, subtle
style and economy are important. It is suitable for a variety of commercial
applications.
Ceiling Canopy
Construction
Aluminum construction with stainless steel mounting hardware; 16” (406 mm)
diameter reflector and canopy, with a drop cord and aircraft cable mount.
Lamping
Integrated 15W Cree™ LED light source, CCT 3500K, CRI 80, 120-277V, or
60W incandescent.
Note: A medium base lamp socket (E26) is installed for incandescent
systems. LED modules are wired directly to the integral driver, and do not
require a lamp socket.
Only integrated LED sources are supplied, not lamps.
LED Driver
The LED source is controlled by an advanced electronic driver that delivers
consistent power.
Surge Suppressor
Luminaire components are protected by a 6kV surge suppressor.
Dimming
0-10V, current-sinking type, with pulse width modulation (PWM).
Note: Use a current-sinking dimming system (by others) for LED dimming.
Compatibility of this product is not guaranteed with all control systems.
Finish
The TMS fire red powder-coat finish is applied to the reflector and ceiling
canopy. A white powder coat is applied to the inner reflector.
Mounting
Mount to the ceiling, directly to a standard 4” electrical junction box. The
adjustable drop cord and aircraft cable mount (120” / 3.048 m max.) provide
support for the luminaire.
Follow the installation instructions, and adhere to the local electrical code.
Compliances
QPS-C/US, or UL-C/US certified to UL1598 standards. Rated IP20 for dry,
indoor locations.
IP20
Page 2
Calvin
ESTABLISHED 1923
Calvin
Calvin
Dimensions
Specifications are subject to change without notice.
TMS Lighting Inc.
247A Summerlea Road,
Brampton, Ontario,
Canada. L6T 4E1
Web Site:
tmslighting.com
North America: (905) 793-1174
Toll-free: (866) 793-1174
Fax: (905) 793-1175
UK & Europe: 44-1474-250-654
