myTouch Q

™

User Manual

Contents

1 Read Before Proceeding .......................................................1

1.1 Safety Precautions............................................................. .......... 1

1.2 Personal Information and Data Security ...................................... 2

1.3 Legal Notice.................................................. ............................... 3

2 Getting Started.......................................................................6

2.1 Phone at a Glance....................................................................... 6

2.2 Key Functions at Your Fingertips................................................. 7

2.3 Installing the SIM Card ................................................... ............. 7

2.4 (Optional) Installing the microSD Card ........................................ 8

2.5 Installing the Battery .................................................................... 8

2.6 Charging the Battery .................................................................... 9

2.7 Important Information About the Battery.................................... 10

2.8 Power Saving Tips .................................................................... 10

2.9 Power On or Off Your Mobile Phone .................... ..................... 11

2.10 Using the Touchscreen ............................................... ............. 12

2.11 Locking and Unlocking the Screen .......................................... 12

2.12 Home Screen ........................................................................... 13

2.13 Using a microSD Card ............................................................. 18

3 Calling..................................................................................18

3.1 Making a Call ............................................................................. 19

3.2 Answering or Rejecting a Call.................................................... 20

3.3 Other Operations During a Call .................... ............................. 21

3.4 Using the Call log.... ................................................................... 21

3.5 TTY Operation .......................................................................... 22

3.6 Setting Hearing Aid Compatibility .............................................. 22

3.7 Using Airplane Mode .............. ................................................... 23

4 Contacts...............................................................................23

4.1 Opening the Contacts Application ............................................. 23

4.2 Importing Contacts from a SIM Card .............................. ........... 23

4.3 Adding a Contact ....................................................................... 24

4.4 Adding a Contact to Your Favorites ........................................... 24

4.5 Searching for a Contact .................................................. ........... 24

4.6 Editing a Contact ....................................................................... 25

4.7 Communicating with Your Contacts ........................................... 25

4.8 Deleting a Contact ..................................................................... 26

4.9 Backing Up and Synchronizing Contacts................................... 26

4.10 Managing Groups .................................................................... 27

4.11 Joining and Separating Contacts..................... ........................ 28

4.12 Sending Contacts .............. ................................................. ..... 28

5 Using the Onscreen Keyboard.............................................29

5.1 Displaying the Keyboard .................................................... ........ 29

5.2 Customizing Keyboard Settings................................................. 31

6 Messages ............................................................................32

6.1 SMS and MMS........................................................................... 32

6.2 Email..................................................... ..................................... 34

7 Getting Connected...............................................................36

7.1 Mobile Networks ........................................... ............................. 36

7.2 Wi-Fi .......................................................................................... 37

7.3 Sharing Your Phone’s Data Connection.................................... 38

7.4 Browser...................................................................................... 39

7.5 Bluetooth.............. ...................................................................... 41

8 Entertainment ......................................................................42

8.1 Taking Photos and Recording Videos ....................................... 42

8.2 Using the Gallery ....................................................................... 44

8.3 Enjoying Music........................................................................... 45

8.4 Listening to the FM Radio ............................................. ............. 47

9 Google Services ..................................................................47

9.1 Creating a Google Account........................................................ 48

9.2 Gmail ....................................................................................... .. 48

9.3 Talk ......................................... ................................................. .. 50

9.4 Maps ....................................... ................................................... 51

9.5 YouTube .................................................................................... 52

9.6 Play Store .................................................................................. 53

10 Synchronizing Information .................................................54

10.1 Managing Your Accounts ............................................ ............. 54

10.2 Customizing Your Account Synchronization......... ................... 56

11 Using Other Applications...................................................57

11.1 Calendar .................................................................................. 57

11.2 File Manager ............................................................................ 59

11.3 Clock................................................... ..................................... 61

11.4 Calculator......................................................... ........................ 62

11.5 Notepad ................................................................................... 62

11.6 Weather ........................................ ........................................... 62

11.7 Genius Button .................................................. ........................ 63

12 Managing Your Mobile Phone ...........................................64

12.1 Setting the Date and Time....................................................... 64

12.2 Setting the Display ........................................................ ........... 64

12.3 Setting Ringers ........................................................................ 65

12.4 Setting Phone Services ........................................................... 66

12.5 Configuring Text-to-Speech..................................................... 66

12.6 Protecting Your Mobile Phone......... ........................................ 67

12.7 Managing Applications............................................................. 68

12.8 Resetting Your Mobile Phone ....................................... ........... 70

13 Appendix............................................................................70

13.1 FAQs.................. ...................................................................... 70

iii

1 Read Before Proceeding

1.1 Safety Precautions

Please read the safety precautions carefully to ensure the correct use of your mobile phone.

Do not crash, throw, or puncture your mobile phone. Avoid the falling, squeezing, and bending of your mobile phone.

Do not use your mobile phone in a moist environment, such as the bathroom. Prevent your mobile phone from being soaked or washed in liquid.

Do not switch on your mobile phone when it is prohibited to use phones or when the phone may cause interference or danger.

Do not use your mobile phone while driving.

Follow any rules or regulations in hospitals and health care facilities. Switch off your mobile phone near medical apparatus.

Switch off your mobile phone in aircraft. The phone may cause interference to control equipment of the aircraft.

Switch off your mobile phone near high-precision electronic devices. The phone may affect the performance of these devices.

Do not attempt to disassemble your mobile phone or its accessories. Only qualified personnel are allowed to service or repair the phone.

Do not place your mobile phone or its accessories in containers with a strong electromagnetic field.

Do not place magnetic storage media near your mobile phone. Radiation from the phone may erase the information stored on them.

Do not put your mobile phone in a high-temperature place or use it in a place with flammable gas such as a gas station.

Keep your mobile phone and its accessories away from children. Do not allow children to use your mobile phone without guidance.

Use only approved batteries and chargers to avoid the risk of explosions.

Observe any laws or regulations on the use of wireless devices. Respect others’ privacy and legal rights when using your wireless device.

Strictly follow the relevant instructions of this manual while using the USB cable. Otherwise your mobile phone or PC may be damaged.

1.2 Personal Information and Data Security

The use of some functions or third-party applications on your device could result in your personal information and data being lost or becoming accessible to others. Several measures are recommended to help you protect personal and confidential information.

• Place your device in a safe area to prevent it from unauthorized use.

• Set your device screen to lock and create a password or unlock pattern to open it.

• Periodically back up personal information kept on your SIM/USIM/ISIM card, memory card, or stored in your device memory. If you change to a different device, be sure to move or delete any personal information on your old device.

• If you are worried about viruses when you receive messages or emails from a stranger, you can delete them without opening them.

• If you use your device to browse the Internet, avoid websites that might pose a security risk to avoid theft of your personal information.

• If you use services such as Wi-Fi tether or Bluetooth, set passwords for these services to prevent unauthorized access. When these services are not in use, turn them off.

• Install or upgrade device security software and regularly scan for viruses.

• Be sure to obtain third-party applications from a legitimate source. Downloaded third-party applications should be scanned for viruses.

• Install security software or patches released by Huawei or third-party application providers.

• Some applications require and transmit location information. As a result, a thirdparty may be able to share your location information.

• Your device may provide detection and diagnostic information to third-party application providers. Third party vendors use this information to improve their products and services.

• If you have concerns about the security of your personal information and data, please contact mobile@huawei.com.

1.3 Legal Notice

Copyright © Huawei Technologies Co., Ltd. 2012. All rights reserved.

No part of this document may be reproduced or transmitted in any form or by any means without prior written consent of Huawei Technologies Co., Ltd. The product described in this manual may include copyrighted software of Huawei Technologies Co., Ltd. and possible licensors. Customers shall not in any manner reproduce, distribute, modify, decompile, disassemble, decrypt, extract, reverse engineer, lease, assign, or sublicense the said software, unless such restrictions are prohibited by applicable laws or such actions are approved by respective copyright holders.

Trademarks and Permissions

, , and are trademarks or registered trademarks of Huawei Technologies Co., Ltd. Android is a trademark of Google Inc. Other trademarks, product, service and company names mentioned are the property of their respective owners.

Notice

Some features of the product and its accessories described herein rely on the software installed, capacities and settings of local network, and therefore may not be activated or may be limited by local network operators or network service providers. Thus the descriptions herein may not match exactly the product or its accessories you purchase. Huawei Technologies Co., Ltd. reserves the right to change or modify any information or specifications contained in this manual without prior notice and without any liability.

Third-Party Software Statement

Huawei Technologies Co., Ltd. does not own the intellectual property of the third-party software and applications that are delivered with this product. Therefore, Huawei Technologies Co., Ltd. will not provide any warranty of any kind for these third-party software and applications. Neither will Huawei Technologies Co., Ltd. provide support to customers who use these third-party software and applications, nor be responsible or liable for the functions of these third-party software and applications. Third-party software and applications services may be interrupted or terminated at any time. Huawei Technologies Co., Ltd. does not guarantee that any content or service would be maintained for any period during its availability. Third-party service providers provide content and services through network or transmission tools outside of the control of Huawei Technologies Co., Ltd. To the greatest extent permitted by applicable law, it is explicitly stated that Huawei Technologies Co., Ltd. shall not compensate or be liable for services provided by third-party service providers, or the interruption or termination of third-party contents or services. Huawei Technologies Co., Ltd. shall not be responsible for the legality, quality, or any other aspects of any software installed on this product, or for any uploaded or downloaded third-party works, such as texts, images, videos, or software. Customers shall bear the risk for any and all effects, including incompatibility between the software and this product, which result from installing software or uploading or downloading the third-party works.

This product uses the open-source Android™ platform. Huawei Technologies Co., Ltd. has made necessary changes to the platform. Therefore, this product may not support all the functions that are supported by the standard Android platform or may be incompatible with third-party software. Huawei Technologies Co., Ltd. shall not be liable for any of such situation.

DISCLAIMER OF WARRANTIES

THE CONTENTS OF THIS MANUAL ARE PROVIDED “AS IS”. EXCEPT AS REQUIRED BY APPLICABLE LAWS, NO WARRANTIES OF ANY KIND , EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LI MITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE ACCURACY, RELIABILITY OR CONTENTS OF THIS MANUAL.

LIMITATIONS OF LIABILITY

TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT SHALL HUAWEI TECHNOLOGIES CO., LTD. BE LIABLE FOR ANY SPECIAL, INCIDENTAL, INDIRECT, OR CONSEQUENTIAL DAMAGES, OR LOST PROFITS, BUSINESS, REVENUE, DATA, GOODWILL OR ANTICIPATED SAVINGS. THE MAXIMUM LIABILITY (THIS LIMITATION SHALL NOT APPLY TO LIABILI TY FOR PERSONAL INJURY TO THE EXTENT APPLICABLE L AW PROHIBITS SUCH A LIMITATION) OF HUAWEI TECHNOLOGIES CO., LTD. ARISING FROM THE USE OF THE PRODUCT DESCRIBED IN THIS DOCU MENT SHALL BE LIMITED TO THE AMOUNT PAID BY CUSTOMERS FOR THE PURCHASE OF THIS PRODUCT.

Import and Export Regulations

Customers shall comply with all applicable export or import laws and regulations and be responsible to obtain all necessary governmental permits and licenses in order to export, re-export or import the product mentioned in this manual including the software and technical data therein.

2 Getting Started

Earpiece

Headset jack Front camera

Back camera

Charger/Data

port

Volume

keys

Camera key

Touchscreen

Flash

Speaker

Microphone

All the pictures in this guide are for your reference only. Your phone’s actual display features may be different to those described here, depending on its software version.

2.1 Phone at a Glance

Alternate

Shift

ReturnSpace

Delete

2.2 Key Functions at Your Fingertips

• Press and hold to power on your mobile phone.

• Press and hold to open the

• Press to lock the screen when your mobile phone is active.

• Touch to return to the previous screen or exit the application you are running.

• Touch to hide the keyboard.

Touch to open the menu on an active screen.

• Touch to return to the Home screen.

• Touch and hold to show the most recently used applications.

Press to open the Genius.

Phone options

menu.

2.3 Installing the SIM Card

There are two steps to install the SIM card:

1 2

1. Remove the battery cover.

2. Insert the SIM card.

2.4 (Optional) Installing the microSD Card

1 2

Your mobile phone is already equipped with a large-volume built-in embedded MultiMediaCard (eMMC). If you want to expand your phone memory, you can also insert a microSD card.

1. Remove the battery cover.

2. Insert the microSD card into the card slot as shown in the diagram.

2.5 Installing the Battery

1. Angle the edge labeled a (with the contacts) into the bottom end of the battery compartment.

2. Push the edge labeled b into the compartment until the battery clicks firmly into place.

2.6 Charging the Battery

Before charging the battery, ensure that it has been properly installed on your phone.

1. Connect the USB cable that came with your mobile phone to the charger.

2. Connect the other end of the USB cable to your mobile phone. Then, to start charging, plug the charger into an electrical outlet.

If you charge your mobile phone while it is powered on, the battery icon on the

notification bar indicates the charging status. When the battery icon changes to , your mobile phone is fully charged.

2.6.1 Status Indicator

The color of the status indicator tells you the status of your mobile phone’s battery.

Status Indicator

Green: Fully charged (when connected to charger).

Orange: Charging in progress (when connected to charger).

Red: Battery low.

2.7 Important Information About the

Battery

• If the battery has not been used for a long time, you may not be able to power on your mobile phone immediately after you begin charging the battery. Allow the battery to charge for a few minutes with the phone powered off before attempting to power the phone on.

• As it ages, the battery’s performance will degrade, in particular it will not hold charge as it did when it was new. When the battery life becomes noticeably shorter than usual after being charged properly, replace the battery with a new one of the same type.

• Using data services increases the power consumption of the phone and will therefore reduce the length of time that the phone can be used between battery charges.

• The time required to fully charge the battery depends on the ambient temperature and the age of the battery.

• When the battery power is low, the phone will alert you and display a message. When the battery power is almost exhausted, your phone will power off automatically.

2.8 Power Saving Tips

The longevity of battery power depends on the network to which you connect, and how you use your mobile phone. Try the following to conserve battery power:

• When your mobile phone is not in use, turn off the screen backlight.

• Reduce the time it takes for your screen backlight to turn off when your phone is idle.

• Lower the screen brightness.

• Turn off Bluetooth when you are not using it. Only make your phone visible to other Bluetooth devices when you need to establish a Bluetooth connection.

• Turn off Wi-Fi when you are not using it.

• Turn off your phone’s GPS receiver when you are not using it.

• Lower the volume.

• Close power-draining programs, when you do not need them.

• Turn off the data service.

2.9 Power On or Off Your Mobile Phone

2.9.1 Powering On Your Mobile Phone

Press and hold . The first time you power on your phone, you will be asked to sign in to your account and set up your mobile phone.

If personal identification number (PIN) protection is enabled on your mobile phone, you must enter your PIN before using the mobile phone.

2.9.2 Setting Up Your Mobile Phone

The first time you power on your mobile phone, the phone displays a setup wizard to help you set up the phone. The setup wizard helps you:

• Learn about your mobile phone

• Create or sign in to your account

• Make some initial decisions about how you want to use your mobile phone

2.9.3 Turning On Fast Boot

1. Touch >

2. Select the

2.9.4 Powering Off Your Mobile Phone

1. Press and hold to open the

2. Touch

Settings

Fast boot

Do not turn on

Power off

Fast boot

is disabled, touch OK to shut down the phone.

Applications

check box.

Fast boot

is enabled, the phone will enter the deep sleep mode. If

while on an airplane.

Phone options

menu.

Fast boot

2.9.5 Restarting Your Mobile Phone

1. Press and hold to open the

2. Touch

Restart

3. Touch OK.

Phone options

menu.

2.10 Using the Touchscreen

2.10.1 Touchscreen Actions

•

Touch

: Tap the screen with your finger to select an item, confirm a selection, or

start an application.

•

Touch and hold

mobile phone responds. For example, to open the options menu for the active screen, touch and hold the screen until the menu appears.

•

Flick

•

Drag

item to any part of the screen. You can drag an icon to move or delete it.

: Touch an item with your finger and do not release it until the

: Move your finger either vertically or horizontally across the screen.

: Touch and hold the desired item with your finger. To move an item, drag the

2.10.2 Rotating Your Mobile Phone Screen

The orientation of most screens will change to landscape or portrait view when you rotate your phone sideways.

On the Home screen, touch > to disable this function.

Settings

Display

Auto-rotate screen

2.11 Locking and Unlocking the Screen

2.11.1 Locking the Screen

• When your phone is on, press to lock the screen. When the screen is locked, you can still receive messages and calls.

• If your phone is idle for a while, the screen will lock automatically.

2.11.2 Unlocking the Screen

1. Press to wake up the screen.

2. Drag the lock icon from up to down to unlock the screen.

10:23

If you have set up a screen unlock pattern, you will be prompted to draw the pattern on the screen to unlock it.

2.12 Home Screen

10:23

Notification bar: Displays reminders and phone status icons. Flick down to open the notification panel.

Display area: Main display area of the phone.

Home screen and extension indicator

Touch to view all your applications.

Shortcuts Touch to open the Phone application.

Touch and hold a shortcut until the mobile phone vibrates, you can then drag it to your desired location or move it to the trash. You can also drag an icon from another area of the screen to the shortcut position.

2.12.1 Notification and Status Icons

Signal strength No signal

Connected to GPRS mobile network

Connected to EDGE mobile network

Connected to 4G mobile network

Roaming Airplane mode

Bluetooth on

Speakerphone on Alarm enabled

Vibration mode Ringer silenced

Call muted Charging battery

Battery full Battery extremely low

Call in progress Missed call

Call in progress with a Bluetooth headset used

GPRS in use

EDGE in use

4G in use

Receiving location data from GPS

New mail from Gmail

New text or multimedia message

New chat message New email

New voicemail Connected to a PC

Open Wi-Fi network available

Uploading Downloading

Phone storage space is getting low

Preparing the mircoSD card

Synchronizing data Synchronization failed

Portable Wi-Fi hotspot on USB tethering on

Connected to a VPN Disconnected from a VPN

Problem with text or multimedia message delivery

Upcoming event

Sign-in or synchronizati on problem

More undisplayed notifications

2.12.2 Notification Panel

Your mobile phone will notify you when you receive a new message or there is an upcoming event. The notification panel also informs you of alarms and settings. Open the notification panel to see your network operator or to view a message, reminder, or event notification.

Opening the Notification Panel

1. When a new notification icon appears on the notification bar, place your finger on the notification bar and flick down to open the notification panel.

You can also open the notification panel from the Home screen: Touch >

Notifications

to open the panel.

2. On the panel, you can:

• Touch a notification to open the related application.

• Touch

Clear

to clear all notifications.

Closing the Notification Panel

Touch and hold the bottom of the panel. Then flick up to close it.

2.12.3 Viewing Other Parts of the Home Screen

10:23

Flick your finger left or right across the Home screen.

2.12.4 Customizing the Home Screen

Adding a New Home Screen Item

1. Touch and hold a blank area on the Home screen until the menu is displayed.

You can also touch >

Home screen

2. Select an item to add it to the Home screen.

Moving a Home Screen Item

1. Touch and hold an item on the Home screen until the item expands in size and the mobile phone vibrates.

2. Without lifting your finger, drag the item to the desired position on the screen, and then release it.

Removing a Home Screen Item

1. Touch and hold an item on the Home screen until the item expands and the mobile phone vibrates.

2. Without lifting your finger, drag the item to the trash can. When the item and the trash can turn red, the item is ready to be removed.

3. Release the item to remove it from the Home screen.

menu.

Add

on the Home screen to display the

Add to Home screen

Add to

2.12.5 Service Shortcuts

1. Open the notification bar.

2. Touch , , or at the top of the screen to turn Wi-Fi, Bluetooth, GPS and Auto-rotate on or off.

2.12.6 Changing the Wallpaper

1. On the Home screen, touch >

2. Touch the following menu items to select a picture and set it as the wallpaper:

•

Gallery

•

Live wallpapers

•

Wallpapers

Wallpaper

2.13 Using a microSD Card

2.13.1 Using the microSD Card as a USB Mass Storage

To transfer all your favorite music and pictures from your PC to your mobile phone’s microSD card, set the microSD card as a USB mass storage.

1. Connect your mobile phone to your PC with the USB cable provided. Your PC will detect the microSD card as a removable storage device.

2. Open the notification bar, and then touch

3. Touch

Turn on USB storage

to transfer files.

You can now transfer files from your PC to your mobile phone’s microSD card.

When your microSD card acts as a USB mass storage, your mobile phone will not use this memory space. Ensure that you follow the correct procedures to disconnect the USB mass storage device (your mobile phone) from the PC when you have finished transferring files.

USB connected

in the dialog box that opens to confirm that you want

2.13.2 Removing the microSD Card

1. On the Home screen, touch >

2. Scroll down the screen, and then touch

3. Carefully remove the microSD card.

Settings

Storage

Unmount SD card

3 Calling

To make a phone call, you can dial a number using the keypad or touch a number saved in your contact list, on a webpage, or in other places. When you are in a call, you can answer other incoming calls or redirect them to your voicemail. You can also set up conference calls with several participants.

3.1 Making a Call

To make a call, you can use the or

Call log

When you are in a call, you can touch to use other functions. To return to the call screen, flick the notification bar down and touch

Be careful not to block the microphone at the bottom of your phone if you want your voice heard by the other parties in a call.

3.1.1 Making a Call with the Dialer Application

Your mobile phone supports the SmartDial function, that is, when you touch numbers on the dialer, the phone automatically searches among your contacts and lists the matching results ordered according to the accuracy of the match. If no contacts match the information entered, the phone will not display any result.

1. On the Home screen, touch >

If you are already working with

2. Touch the appropriate number keys to enter the phone number.

3. Touch to initiate the call.

During a call, touch

3.1.2 Making a Call from Contacts

1. On the Home screen, touch >

If you are already working with

2. In the list, touch the contact you want to call.

3. Touch to dial the phone number.

3.1.3 Making a Call from Call log

1. On the Home screen, touch >

If you are already working with

2. Touch to the right of the log entry to dial.

If you touch and hold a log entry, the options menu will open.

Dialer

application, or select a number from

Current call

Dialer

to display the dialer.

Contacts

Call log

Dialpad

to enter other numbers on the dialpad.

Contacts

to display the contact list.

Dialer

Call log

to display the call log.

Contacts

Dialer

, touch the

Dialer

Contacts

Call log

Contacts

tab.

3.2 Answering or Rejecting a Call

3.2.1 Answering an Incoming Call

When you receive a phone call, the incoming call screen opens. If you have previously saved the caller’s number in displayed. If the caller’s number is not saved in displayed.

Drag to the right to answer the call.

3.2.2 Ending a Call

During a call, touch

End

to hang up.

3.2.3 Rejecting an Incoming Call

Drag to the left to reject the call.

Contacts

, the caller's name and number are

Contacts

, the caller’s number is

You can also drag up the bar at the bottom of the screen to reject a call and send the caller a message.

3.3 Other Operations During a Call

3.3.1 Making a Conference Call

If you receive a new call while you are already in a call, you can add the second call to the call you are in. This feature is known as conference calling. You can also set up a conference call with multiple callers.

Contact your network operator to ask if conference calls are supported and, if yes, how many parties can participate.

1. To initiate a conference call, dial the number of the first participant. After you have connected to the first participant, keep the connection open, touch

2. Enter the phone number of the next person you want to invite for the conversation

and touch , or select someone from your participant is automatically placed on hold while you do this.

3. Once you have connected to the second person, touch conference call.

4. To end the conference call and disconnect from everyone, touch

Call log

Contacts

Merge calls

Add call

. The first

to begin the

End

3.3.2 Switching Between Calls

If you receive a new call while you are already in a call, you can switch between the two calls.

1. While you are in the first call and the second call comes in, answer the incoming call, and then touch

2. The current call is placed on hold and you are connected to the first call.

Swap

3.4 Using the Call log

The

Call log

contains a list of calls that you have dialed, received, and missed. You can use the call log to find a recently called number quickly or add a number from the call log to your contact list.

3.4.1 Adding an Entry to Contacts

1. If you are already working with

2. Touch and hold the entry you want to add to your

3. Touch

Add to contacts

4. Touch

Create contact

contact name.

Dialer

Contacts

, touch the

Call log

in the options menu.

Contacts

or scroll through the contact list and touch an existing

tab.

3.5 TTY Operation

3.5.1 Using the TTY Device

The Teletypewriter (TTY) is a typewriting device. By connecting the phone to the TTY device, you can use the TTY functions to send/receive messages. When you use the TTY function, do as follows:

1. Connect the TTY device to the headset jack of the phone and set the phone to the

TTY mode.

2. Make or answer calls as normal.

3. When the call is put through, use the TTY device to send or receive the letters.

4. Touch

End

to end the call.

3.5.2 Setting the TTY Mode

1. touch >

2. Select one TTY mode.

Settings

Call settings

TTY mode

•

TTY Off

: The standard voice speaking mode and the listening mode.

•

TTY Full

: Transmit and receive the TTY characters.

•

TTY HCO

: Transmit TTY characters but receive by listening to the earpiece.

•

TTY VCO

: Receive TTY characters but transmit by speaking into the

microphone.

3.6 Setting Hearing Aid Compatibility

Touch > compatible with a hearing aid.

Settings

Call settings

Hearing aids

to set your phone to be

3.7 Using Airplane Mode

Some locations may require you to turn off your phone’s wireless connections. Rather than powering off your phone, you can place it in

1. Press and hold .

2. Touch

Airplane mode

in the options menu.

Airplane mode

4 Contacts

The

Contacts

phone numbers and addresses of your contacts. After you save contact information on your mobile phone, you have easy access to the people with whom you want to communicate.

4.1 Opening the Contacts Application

If you have not yet added any contacts to your mobile phone, message with hints on how to start adding contacts information.

On the Home screen, touch > All of your contacts are displayed alphabetically in a list that you can scroll through.

4.2 Importing Contacts from a SIM Card

1. In the contact list, touch >

2. Touch

3. Wait for the SIM card contents to be loaded. Select the contacts you want to import

4. Touch

5. If you have more than one account on your phone, touch the account into which

application enables you to save and manage information such as

Contacts

to open the

Copy from SIM card

or touch

Select All

to select all contacts.

Copy

you want to import the contacts.

Manage contacts

Contacts

displays a

application.

4.3 Adding a Contact

1. In the contact list, touch >

2. Touch

MobileLife Contacts

account type.

If you need to set the default account type, please first select the

for this action

3. If you have more than one account with contacts, touch the account to which you

want to add the contact.

4. Enter the contact's name, and then add detailed information such as phone

number and address.

Some fields may not be available when you're adding contacts to your SIM card.

5. When you are finished, touch

Create contact

tab to select the account type or set the default

check box, then touch the account you want to set.

Save

to save the contact information.

Use by default

4.4 Adding a Contact to Your Favorites

• Touch and hold the contact you want to add to

Favorites

• Touch a contact, and then touch the star to the right of the contact’s name. The star

turns gold.

Favorites

. Then touch

Add to

4.5 Searching for a Contact

1. In the contact list, touch >

2. Enter the name of the contact you wish to search for. As you type, contacts with

matching names appear below the search box.

On the contact list screen, you can touch a letter on the right to display contacts starting with the touched letter.

4.6 Editing a Contact

You can make changes to the information you have stored for a contact at any time.

1. In the contacts list, touch and hold the contact whose details you want to edit, and

then touch

Edit contact

2. Touch the category of contact information you wish to change: name, phone

number, email address, or any other information you recorded earlier.

3. Make the desired changes to the contact information, and then touch

cancel all of your changes, touch

in the options menu.

Cancel

Save

. To

4.7 Communicating with Your Contacts

From the

Contacts

Favorites

multimedia (MMS) message to a contact’s default phone number. You can also open details to view a list of all the ways you can communicate with that contact. This section describes how to communicate with a contact when you view your contacts list.

4.7.1 Using Quick Contact for Android

1. Touch the contact's picture or picture frame (if you have not assigned a picture to

the contact) to open Quick Contact for Android.

2. Touch the icon for the way you want to communicate with the contact.

The icons available depend on the information you have entered for the contact, the applications installed on your phone, and the accounts you have.

4.7.2 Communicating with a Contact

1. In the contacts list, touch the contact that you want to communicate with.

2. On the contact’s details screen, touch the icon to the right of the number to call or

send messages.

tab, you can quickly call or send a text (SMS) or

4.8 Deleting a Contact

1. In the contacts list, touch and hold the contact that you want to delete, and then

touch

Delete contact

2. Touch OK to confirm that you want to delete the contact.

in the options menu.

4.9 Backing Up and Synchronizing Contacts

You can back up contacts from your phone to a microSD card, or synchronize phone contacts with a server using your Google account.

4.9.1 Using a microSD Card to Back Up Contacts

Backing Up Contact s

1. In the contact list, touch >

2. Touch

Backup to SD card

3. Touch OK to export your phone contact's information to the installed microSD card.

You can copy the .vcf files backed up on the microSD card to your computer. The files are stored in the microSD card's

Restoring Contacts

1. In the contact list, touch >

2. Touch

Restore from SD card

type for the imported contacts.

If there is more than one .vcf files saved on the microSD card, you can choose to restore one, multiple, or all the of them.

4.9.2 Using a Google Account to Synchronize Contacts

You can synchronize contacts using your Google account. For details, see Changing an Account’s Synchronization Settings.

Manage contacts

in the displayed menu.

Contact

Manage contacts

in the displayed menu, and then select the account

folder.

4.10 Managing Groups

4.10.1 Creating a Group

1. On the Home screen, touch >

touch

Groups

2. In the groups list, touch , and then touch

3. Enter the name and picture you want to assign to the group, and then set a ringtone

for it.

4. Touch >

5. Select the contacts to be added to the group, and then touch OK.

6. When you are finished, touch

Add members

You can only add contacts saved in the phone memory to a group.

4.10.2 Editing a Group

You can always make changes to the information you have saved for a group.

1. In the groups list, touch and hold the group whose details you want to edit, and then

touch

Edit group

2. Make the desired changes to the group information, and then touch

cancel all changes you made to the group information, touch

in the options menu.

4.10.3 Adding a Contact to Your Groups

To add a contact to your groups, you can do any of the following:

• Touch and hold the contact you want to add to

groups

• When editing a group, touch , and then touch

contacts you want to add to group.

You can add contacts in phone memory rather than in SIM/USIM/ISIM card to a group.

Contacts

. Then flick the tab bar to the left and

Create group

to add members to the group.

Save

to save the group information.

Groups

. Then touch

Add members

Cancel

Save

. To

Add to

to select the

4.11 Joining and Separating Contacts

You may have duplicate contacts if you import contacts by:

• Adding an account, such as a Gmail account.

• Using other methods, such as exchanging emails.

To avoid duplication, join two or more contacts together to form a single contact.

4.11.1 Joining Contacts

1. On the Home screen, touch >

2. Touch a duplicated contact.

3. Touch

Joined Contacts

4. Select the contact to be joined to combine two duplicate contacts.

Two contacts will be joined together and displayed as one contact. Touch the contact to view the joined information. You can see that the contact is joined together by two contacts. You can also combine more than two contacts.

Contacts

, and then touch

Add contact

4.11.2 Separating Contacts

If contact information from different sources was joined together in error, you can separate the contacts.

1. On the Home screen, touch >

2. Touch the joint contact to be separated.

3. Touch the option for separating a contact.

4. Select the contact to be separated from the joint contact.

The joint contact is then separated into two contacts displayed separately in

Contacts

4.12 Sending Contacts

You can send contacts as a .vcf file via Bluetooth or Email.

1. In the contacts list, touch , and then touch .

2. Select contacts that you want to send.

3. Touch

Send

4. Select the way you prefer to send the contacts you have selected, for example

q w e r t y u i o p

a s d f g h j k

z x c v b n m

?123

Touch once to capitalize the next letter you type. Touch twice to capitalize all letters to be entered.

Touch to change from the text mode to the symbol/number mode.

Touch to enter text by voice.

Touch to insert a space.

Touch to delete a character to the left of the cursor. Touch and hold to delete all characters to the left of the cursor.

......

Touch to select or set input method.

:-)

...

Bluetooth or Email.

You can send one contact by another way. Touch and hold a contact, touch

Send contact

, and then select the way you prefer to send.

5 Using the Onscreen Keyboard

5.1 Displaying the Keyboard

To enter text, use the onscreen keyboard. Some applications open the keyboard automatically. In others, touch a text field to open the keyboard.

Touch to hide the keyboard.

Touch and hold a text field to open the

5.1.1 Choosing an Input Method

1. Touch and hold a text field until the

2. Touch

Select input method

3. Select the input method.

5.1.2 Using the Android Keyboard

Edit text

menu.

Edit text

menu is displayed.

Touch once to capitalize the next letter you type. Touch twice for all caps.

Touch and hold to open settings.

Touch to change from text mode to symbol/number mode.

Touch to insert a space.

Touch to delete a character to the left of the cursor. Touch and hold to delete all characters to the left of the cursor.

q w e

(

890

:;”

)

r t y u i o p

a s d f g h j k

z x c v b n m

’

+!=

123

q w e

(

890

:;”

)

r t y u i o p

a s d f g h j k

z x c v b n m

’

+!=

123

q w e

(

890

:;”

)

r t y u i o p

a s d f g h j k

z x c v b n m

’

+!=

123

bay

To enter a word, just drag your finger over the letters in the word.

I’ll

To capitalize, go above the keypad. To enter apostrophes in common words drag through the ‘n’. To enter double letters, circle the letter.

The keyboard layout may vary slightly depending on the field where you are entering text. The previous figure is provided for your reference only.

On the Home screen, touch >

Android keyboard

Voice input

Settings

Language & keyboard

to turn on or turn off voice input.

5.1.3 Using the Swype Keyboard

The keyboard layout may vary slightly depending on the field where you are entering text. The previous figure is provided for your reference only.

5.1.4 Using the Landscape Keyboard

If you find the keyboard inconvenient or difficult to use, turn your mobile phone sideways. The screen will display the keyboard in landscape orientation, providing you with a wider keyboard layout.

5.1.5 Using the Phone Keypad

Press and to switch between input modes. In different input modes, the cursor is displayed in different forms, as described in the following table.

Cursor: To enter the character printed at the top of a key,

Cursor:

press first and then the desired key.

To enter only the characters printed at the top of keys,

press twice before typing. Press again to switch back to the main characters printed on keys.

To enter one uppercase letter, press first and then the desired key.

To enter only uppercase letters, press twice

before typing. Press again to input lowercase letters.

To delete a character, press . Press and hold the key to delete more characters quickly.

To start a new line, press .

5.2 Customizing Keyboard Settings

1. On the Home screen, touch >

2. In

Keyboard settings

Settings

, select an input met hod to customize the keyboard set tings.

Language & keyboard

6 Messages

The

Messages

multimedia messages (MMS) with anyone using an SMS-or-MMS-capable phone. With the

6.1 SMS and MMS

6.1.1 Opening Messages

Touch >

6.1.2 Creating and Sending a Text Message

1. Touch >

2. Enter a phone number or a contact's name in the To field, or touch to select a

3. Touch the composition text box to start entering your message.

4. When you are ready to send the message, touch

Sent and received messages will be displayed in a message thread, grouping together the messages in a conversation.

6.1.3 Creating and Sending a Multimedia Message

You can use multimedia messages to make everyday communications very special. You can record a message and send it as an audio file, sing 'Happy Birthday' and send it to friend, or send a slideshow of photographs of a special event. The possibilities are endless.

1. Touch >

2. Enter a phone number in the To field, or touch to select a contact from

application allows you to exchange text messages (SMS) and

application you can read and send emails.

Messages

New message

contact from

Contacts

Groups

As you enter the phone number or the contact's name, the phone displays possible matches from your contacts. Select a contact from the list of possible matches or continue entering.

After you select a contact or finish entering a number, add a comma and you can enter another recipient. You can also touch a previously entered contact again to edit or delete it.

Messages

New message

Contacts

Groups

Send

3. Touch the composition text box to start entering your message.

4. Touch to display the options panel.

• Touch

Add subject

multimedia message mode.

• Touch

5. When the message is ready to be sent, touch

to add the message subject. Your mobile phone is now in

Add

to add a picture, music, or video file.

Send

On the message editing screen, you can also touch , and then select your desired files to add.

You can select a media file (music, video or picture) and send it as an attachment in a multimedia message. In touch

Messages

File Manager

, touch and hold a media file, and then

Adding a Slideshow

If you want to attach more than one file to your message, use the

Slideshow

1. On the message editing screen, touch to display the options panel.

2. Touch

Add

Slideshow

, and then select a slide to start editing it.

3. Touch and then touch

4. Touch

Done

to finish composing your message and return to the multimedia

message screen.

5. To alter your multimedia message, touch the slideshow on the multimedia

message screen. When the message is ready to be sent, touch

Add slide

to add more slides.

Send

6.1.4 Opening and Viewing a Multimedia Message

1. In the message list, touch the message thread you wish to view.

2. Touch the multimedia message to view the message.

6.1.5 Replying to a Message

1. In the message list, touch a text or multimedia message thread to open it.

2. Touch the text box to compose your message. Once finished, touch

You can also do the following to reply to a message: Touch > select one or more message threads, and touch

Send

option.

Multiselect

6.1.6 Copying a Text Message to Notepad or Calendar

1. In the message list, touch a text message thread to open it.

2. Touch and hold one of the messages, and then touch

3. Touch

Notepad

Calendar

For information about how to use this guide.

to save it as a no te or an event.

Notepad

Copy message to

Calendar

, see the relevant sections of

6.1.7 Customizing Message Settings

In the message list, touch , and then touch settings.

Settings

to customize the message

6.2 Email

Your mobile phone also puts email at your fingertips. With your phone’s application, you can use your email account with Yahoo!, AOL, or other popular email services on your phone.

6.2.1 Adding an Email Account

When using the account. The Email setup wizard helps you to configure your account. A number of popular email systems are supported. You can work with the same email service that you use on your PC or you can select another email service.

1. On the Home screen, touch >

2. In the email system list, select a system, or select

3. To customize your email settings, follow the onscreen instructions, and then touch

4. Enter the account name and the name you want other people to see when they

receive an email from you.

5. Touch

application for the first time, you must configure an email

Done

Others

Adding Other Email Accounts

1. After creating your initial email account, touch on the

touch

Accounts

to access the account s screen.

2. Touch on the accounts screen, and then touch

another email account.

When adding an additional email account, you have the option to use the new account to send all outgoing messages.

Inbox

Add account

screen, and then

to create

6.2.2 Viewing an Email Message

1. On the accounts screen, touch the email account you want to use.

2. Access a folder, and then touch the message that you want to view.

6.2.3 Saving an Email Attachment

1. On the accounts screen, touch the email account you want to use.

2. Touch the email message you want to view.

3. Touch

Save

4. Select a path for saving the attachment and touch

next to the attachment in the email.

Save

6.2.4 Creating and Sending an Email Message

1. On the accounts screen, touch the email account you want to use.

2. On the

Inbox

3. In the To field, enter the recipients’ name or email address.

4. Enter the subject of your message and compose the message.

5. When you are finished, touch

screen, touch , and then touch

To send an attachment with the message, touch , and then touch

attachment

If you are not ready to send the message, touch save the message as a draft.

Send

Compose

Save as draft

in the options panel.

or touch to

Add

6.2.5 Replying to an Email Message

1. On the accounts screen, touch the email account you want to use.

2. Touch the email message to which you want to reply.

3. Touch

Reply all

to reply to the email message.

6.2.6 Deleting an Email Account

1. On the accounts screen, touch and hold the email account you want to delete.

2. Touch

Remove account

3. Touch OK.

6.2.7 Changing Email Account Settings

You can change a number of account settings, including how often you check for emails, how you are notified of a new mail, and details about the servers the account uses to send and receive mails.

Your account’s incoming and outgoing settings depend on the kind of email service you are using. You can enter the necessary details manually, although you may need to contact your email service provider to obtain the correct information.

1. Touch >

2. On the accounts screen, touch and hold the email account you want to change.

3. Touch

4. Change

Account settings

General settings, Notification settings

, or

Server settings

7 Getting Connected

7.1 Mobile Networks

Your mobile phone will be automatically configured to use your network operator’s 2G/3G service (if available) when you turn on the phone for the first time. Note that the SIM/USIM/ISIM card must be inserted (some CDMA mobile phones have an integrated USIM/ISIM card and do not need a separate USIM/ISIM card)

7.1.1 Checking the Network Connection

1. Touch >

2. Touch

3. Touch

connection.

Settings

Wireless & networks

Network operators

Do not change the access point parameters; otherwise, you might not be able to access network resources.

Mobile networks

Access Point Names

to check the network

7.1.2 Turning on the Data Service

1. Touch >

2. Touch

3. Select the

Settings

Data enabled

check box to turn on the data connection.

Wireless & networks

Mobile networks

7.2 Wi-Fi

Wi-Fi gives you wireless access to broadband Internet. To use Wi-Fi on your mobile phone, you must have an access to wireless access points (hotspots). Obstacles that block the Wi-Fi signal will reduce its strength.

7.2.1 Turning On Wi-Fi

1. Touch >

2. Touch

7.2.2 Connecting to a Wireless Network

1. After turning on Wi-Fi, touch >

2. Touch

networks in the

3. Touch a Wi-Fi network to connect to it.

Settings

Wireless & networks

• If you select an open network, you will be automatically connected to the network.

• If you select a network that is secured with Wired Equivalent Privacy (WEP) and connect to it for the first time, enter the password as prompted, and then

Wi-Fi networks

, and then select the

Settings

Wi-Fi settings

section.

Wi-Fi

check box to turn on Wi-Fi.

. You will see a list of detected Wi-Fi

touch

Connect

already used, you will not be prompted to enter the password again unless you have reset your mobile phone to its default settings.

On the network.

. If you connect to a secured wireless network that you have

Wi-Fi settings

screen, touch

Add Wi-Fi network

to add a new Wi-Fi

7.3 Sharing Your Phone’s Data Connection

Tethering and WiFi Hotspot may include a separate charge. Please contact your carrier for more information. You can share your mobile phone's data connection with a single computer via a USB cable: USB tethering. You can share your mobile phone's data connection with a number of devices at the same time, by turning your phone into a portable Wi-Fi hotspot.

7.3.1 Installing the USB tethering Driver

If your computer is running Windows 7 or a recent distribution of some flavors of Linux (such as Ubuntu), you typically do not need to prepare your computer for tethering. But if you are running an earlier version of Windows or another operating system, you may need to prepare your computer to establish a network connection via USB. Install the

USB tethering

1. Connect a USB cable to a computer. The computer will automatically recognize the phone.

2. Choose

Start

3. Open the Double-click the link

4. Download and install

5. After the installation, you are able to use USB tethering.

7.3.2 Sharing Your Phone’s Data Connection via USB

To use USB tethering in different operating systems, you may need to prepare your computer to establish a network connection via USB.

driver in the following steps:

My Computer

drivers

folder and then open the

DownloadActiveSync.url

ActiveSync 4.5

, and then double-click

usbnet_driver_win2k_xp

or a later version.

Mobile Partner

folder.

You cannot share your mobile phone’s data connection and access its microSD card via USB at the same time.

1. Touch >

2. Touch

3. Select the

Settings

USB tethering

check box to share your data connection.

Wireless & networks

Tethering and Mobile HotSpot

7.3.3 Sharing Your Phone’s Data Connection as a Portable

Wi-Fi Hotspot

1. Touch >

2. Touch

3. Select the

When change its network name or secure it.

Settings

Wireless & networks

Mobile HotSpot

Tethering and Mobile HotSpot

check box to share your data connection.

is selected, you can touch

Mobile HotSpot settings

7.4 Browser

Your mobile phone comes with an Internet browser pre-installed.

7.4.1 Opening the Browser

When known or open Wi-Fi networks and mobile data networks are available at the same time, your phone will preferably select a Wi-Fi network for Internet access.

Touch >

Touch to open the browser options menu and perform one of the following operations:

•

Browser

to open the home page.

New window

Bookmarks

Windows

another browser window or open a new one on this screen.

Refresh

Forward

selecting text, downloading, or setting options.

: Touch to open a new window.

: Touch to display bookmarks.

: Touch to view thumbnails of open browser windows. You can switch to

: Touch to refresh the current webpage.

: Touch to browse the next web page.

: Touch to open other menus and perform operations such as searching,

7.4.2 Opening a Webpage

1. In a browser window, touch the URL field at the top of the screen.

2. Use the keyboard to enter a webpage address. You can touch to enter the web page address by voice.

3. As you enter the address, matching webpage addresses will appear on the screen. If you see the address you want, touch it and go directly to that webpage or complete entering your desired webpage.

7.4.3 Setting a Home Page

1. In a browser window, touch .

2. Touch

Settings

3. Enter the address of the desired home page, and then touch OK.

Set home page

7.4.4 Managing Bookmarks

You can store as many bookmarks as you want on your mobile phone.

Adding a Bookmark

1. In a browser window, go to the webpage you want to save as a bookmark.

2. Touch , and then touch

3. Edit the bookmark name and then touch OK.

Opening a Bookmark

On the

Bookmarks

or touch the

Most visited

1. In a browser window, touch , and then touch

2. Touch the bookmark of the website you want to open.

Bookmarks

Add

screen, touch the

History

tab to view the pages you have visited most frequently.

tab to view the pages you have visited,

Bookmarks

7.4.5 Customizing Browser Settings

Customize the browser to suit your browsing style. Use

privacy, and security preferences. In a browser window, touch , and then touch

Settings

Browser

to set page content,

7.5 Bluetooth

Your mobile phone has Bluetooth, which allows you to create a wireless connection with other Bluetooth devices so you can share files with your friends, talk hands-free with a Bluetooth headset, or even transfer photos from your phone to your PC. If you are using Bluetooth, remember to stay within 10 meters (33 feet) of the other Bluetooth devices to which you want to connect. Be aware that obstacles like walls or other electronic equipment may interfere with your Bluetooth connection.

7.5.1 Turning On Bluetooth

1. Touch >

2. Touch Bluetooth. When Bluetooth is turned on, the Bluetooth icon appears in the notification bar.

3. Touch mobile phone visible to other Bluetooth devices.

7.5.2 Pairing with and Connecting to a Bluetooth Device

Your mobile Bluetooth lets you do the following:

• Hands Free Profile (HFP): allows you to use a hands-free Bluetooth device.

• Headset Profile (HSP): allows you to use a mono Bluetooth headset.

• Object Push Profile (OPP): allows you to transfer files over a Bluetooth connection.

• Advanced Audio Distribution Profile (A2DP): allows you to use a stereo Bluetooth headset.

• A/V Remote Control Profile (AVRCP): allows you to control audio playing using a Bluetooth headset remotely.

Before you use Bluetooth, pair your mobile phone with another Bluetooth device as follows:

1. Ensure that the Bluetooth function on your mobile phone is enabled.

2. On the Home screen, touch >

settings

3. Touch the device you want to pair your mobile phone with.

4. If required, enter the pairing password to complete the connection.

Settings

Wireless & networks

Bluetooth settings

. Your mobile phone will then scan for Bluetooth devices in range.

, and then select the

Settings

Bluetooth

check box to turn on

Discoverable

Wireless & networks

to make your

Bluetooth

7.5.3 Sending Files via Bluetooth

With Bluetooth, you can share pictures, videos, or music files with your family and friends. To send files via Bluetooth:

1. Touch and hold the file to be sent in your mobile phone or SD card. The active options menu is displayed.

2. Touch

, then

Bluetooth

to select a paired device.

7.5.4 Disconnecting from or Unpairing with a Bluetooth Device

1. Touch >

2. Navigate to the which you are connected.

3. Touch

Settings

Wireless & networks

Bluetooth devices

Unpair

to disconnect from the device.

section, and then touch and hold the device to

Bluetooth settings

8 Entertainment

In addition to being a communication device and personal assistant, your mobile phone also provides you with a multitude of entertainment possibilities. You can take photos, create videos and audio clips, and download and listen to music.

8.1 Taking Photos and Recording Videos

The camera is a combination of camera and camcorder that you can use to shoot and share pictures and videos.

8.1.1 Opening Your Camera

• Touch > mode, ready to take a picture or record a video.

• Touch to close the camera.

Camera

to open the camera. The camera opens in landscape

Capture Screen

Touch to customize the camera settings.

Thumbnail of the last photo. Touch to preview the photos or videos.

Touch to take a photo.

Settings

Flash

Back

Camera

Touch to switch between

camera and video modes.

In camera mode, slide left or right the zoom bar to zoom in or out.

Touch to switch

the camera light

on or off.

Touch to switch between

front camera and

back camera.

8.1.2 Taking a Photo

1. Open your camera application and switch it to camera mode.

2. If necessary, change the camera settings. The preview changes as you change the settings.

3. Frame your photo within the photo capture screen.

4. Touch to take your photo.

Photos taken are displayed for a moment. You can take another photo or review your photos.

8.1.3 Viewing Your Photos

1. After taking a photo, a thumbnail of the photo you have just taken is shown in the lower right corner of the capture screen. Touch the thumbnail to view it.

2. Touch the onscreen button to do any of the following:

• Touch

Delete

• Touch

to share the photo with others.

to delete the photo.

Set as

to set the photo as a contact icon or the wallpaper.

8.1.4 Recording a Video

1. Open the camera application, and then switch it to camcorder mode.

2. If necessary, change the camcorder settings.

3. Frame the scene with which you want to start your video.

4. Touch to start recording a video.

5. Touch to stop recording.

8.1.5 Viewing Your Videos

1. After recording a video, a thumbnail of the video you have just recorded is shown in the lower right corner of the capture screen. Touch the thumbnail to view it.

2. Touch the onscreen buttons to do any of the following:

• Touch

On the video playback screen, touch the controls to fast-forward or rewind or to play or pause the video.

3. If you want to view more videos, flick your finger left or right across the screen.

to share the video with others.

Delete

to delete the video.

8.2 Using the Gallery

Your

Gallery

application can automatically search for pictures and videos on your mobile phone and microSD card. Use view and edit pictures, watch videos, and set a picture as wallpaper or as a photo for a contact.

8.2.1 Opening the Gallery

On the Home screen, touch > The

Gallery

application categorizes your pictures and videos by storage location and

displays these files in folders. Touch a folder to view the pictures or videos inside.

Gallery

to sort photos and videos into folders,

Gallery

8.2.2 Viewing a Picture

1. In

Gallery

, touch the folder that contains the pictures you want to view.

2. Touch the picture to view it in full-screen mode.

3. Touch the screen. Then the zoom panel appears. You can zoom in or zoom out on

the picture.

The picture viewer supports the automatic rotation function. When you rotate your mobile phone, the picture adjusts itself to the rotation.

8.2.3 Rotating a Picture

1. When viewing a picture, touch to display the operations panel.

2. Touch

orientation.

Rotate Left

Rotate Right

. The picture is saved with the new

3. Select either

8.2.4 Cropping a Picture

1. When viewing a picture, touch to display the operation panel, and then touch

Crop

2. Use the cropping tool to select the portion of the picture to crop.

3. Touch

• Drag from the inside of the cropping tool to move it.

• Drag an edge of the cropping tool to resize the image.

• Drag a corner of the cropping tool to resize the image without changing its length to width ra tio.

Save

to save the cropped picture. Touch

Discard

to discard the changes.

8.3 Enjoying Music

You can download music files to your PC or insert a CD and copy the files to your microSD card so you can listen to music on your mobile phone.

8.3.1 Copying Music to the microSD Card

1. Connect the phone to your computer with a USB cable and mount the microSD card.

2. On the PC, navigate to the USB drive and open it.

3. Create a folder in the root directory of the microSD card (for example,

4. Copy the music from your computer to the folder you have created.

5. After copying music, unmount or eject the drive as required by your PC’s operating system to safely remove the mobile phone.

6. Disconnect the mobile phone from the PC.

Play Music

8.3.2 Opening the Media Library

Touch > The six tabs:

Play Music

RECENT, ARTISTS, ALBUMS, SONGS, PLAYLISTS

to display the media library.

application organizes your music files by storage location. It contains

and

GENRES

8.3.3 Playing Music

1. Touch a category on the music library screen.

2. Touch the song you want to play.

When you are listening to music, touch , to use another application. Your music continues to play. To return to the music controls, open the notification panel and then touch the song.

8.3.4 Adding Music to a Playlist

1. Touch a category on the music library screen.

2. In the list that appears, select the song you want to add to the playlist.

3. Touch and hold the song, and then touch

• Touch an existing playlist to add the song to an existing playlist.

• Touch

New playlist

to create a playlist and add the song to it.

Add to playlist

in the options menu.

8.3.5 Playing a Playlist

1. Touch the

PLAYLISTS

2. Touch and hold the playlist you want to play.

3. Touch

Play

tab on the music library screen.

to play the playlist.

8.4 Listening to the FM Radio

The FM radio lets you listen to FM radio programs on your mobile phone. Since the FM radio uses the provided wired stereo headset as its antenna, before opening the application, connect the headset to your phone’s the audio jack.

8.4.1 Opening the FM Radio

1. On the Home screen, touch >

2. The first time you open FM radio, touch available FM channels, saves them as presets, and plays the first FM channel found.

FM Radio

Auto tuning

to open the application.

, which automatically scans for

8.4.2 Tuning the FM Radio

Open the

FM Radio

application, and then do the following:

• Touch or to tune the radio to the previous or next channel.

• Slide the knob left or right to perform precision tuning. When a channel is found,

touch , then select an empty channel to save the new channel to the channel list.

• Touch >

Save channel

Auto tuning

. Enter the channel name, touch OK, and then

to scan automatically for available FM channels.

9 Google Services

Availability of Google applications, services, and features may vary according to your country or carrier. Please follow local laws and regulations to use them.

When you turn on your mobile phone for the first time, touch a Google services such as

Talk, Gmail

, or

Play Store

account.

Ensure that your mobile phone has an active data connection (3G/GPRS) before you sign in to your Google account.

If you already have a Google account, touch password.

, and you will be prompted to sign in to your Google

and enter your username and

9.1 Creating a Google Account

If you do not have a Google account, you can create one:

1. After reading the setup information, touch

2. Touch

Create

3. Enter the first name, last name, and user name for your Google account, and then touch username is available. If the username you entered is already in use, you will be prompted to choose another one or select one from a list.

4. Enter and confirm your Google account password.

5. Select a security question from the drop-down menu, and then enter the answer.

6. Touch

7. When the

8. Enter the characters that appear on the screen, and then touch

To use another Google account, go to the touch

. The mobile phone will connect to a Google server to check whether the

Create

Google Terms of Service

Add account

to select which type of accounts you want to add.

screen appears, touch

Accounts & sync settings

I agree, Next

screen, and

9.2 Gmail

Gmail

is Google’s web-based email service. When you first set up your phone, you may have configured it to use an existing The first time you open the the messages from your

Gmail

9.2.1 Opening Gmail

On the Home screen, touch > you decide to keep on your mobile phone will go to your

9.2.2 Switching Between Accounts

1. In the mail list, touch , and then touch

2. Touch the account that contains the email you want to read.

Gmail

application on your phone, your

web account.

account or create a new account.

Gmail

. The

Inbox

mail list appears. Any emails

Accounts

Inbox

folder.

Inbox

will contain

9.2.3 Creating and Sending an Email

1. In the mail list, touch , and then touch

2. Enter the message recipient’s email address in the To field. If you are sending the

email to several recipients, separate the email addresses with commas. You can add as many message recipients as you want.

If you want to send a copy (Cc) or a blind copy (Bcc) of the email to other

recipients, touch , and then touch

3. Enter the email subject and write your email.

If you want to add a picture attachment, touch , and then touch select the picture you want to attach.

4. After writing your email, touch .

Compose

Add Cc/Bcc

Attach

9.2.4 Replying to or Forwarding an Email

1. In the mail list, touch the email that you want to reply to or forward.

2. Touch to reply. You can also touch , and then touch

Forward

3. Do one of the following:

• If you selected

• If you selected additional text you want to include in the forwarded message.

4. Touch to send, or touch to save as a draft.

Reply all

Forward

, enter your message.

, specify the message recipients and add any

Reply, Reply all

9.2.5 Searching for an Email

1. In the mail list, touch , and then touch

2. Enter the search keywords in the box, and then touch .

9.2.6 Customizing Your Gmail Settings

In the mail list, touch , and then touch

Gmail

Settings

to customizing your

, or

9.3 Talk

Talk

is Google’s instant messaging service. You can use it to communicate in real

time with other people using

9.3.1 Opening Talk

On the Home screen, touch >

Your

Talk

phone.

9.3.2 Adding a Friend

1. In the friends list, touch , and then touch

2. Enter the

Talk

3. Touch

Send invitation

9.3.3 Accepting an Invitation

1. If you have invited anyone to chat or if someone else has invited you to chat, this information will appear in the friends list.

2. Touch a pending invitation, and then touch

9.3.4 Starting a Chat

1. In the friends list, touch a friend's name in the friends list.

2. Use the onscreen keyboard to enter text and chat with your friend.

3. After entering your message, touch

Talk

on a phone or on the web.

Talk

to open the application.

account is based on the Google account you set up with your mobile

Add friend

instant messaging ID or Gmail address of the friend you want to add.

Send

9.3.5 Setting Notifications for New Instant Messages

Whenever you receive an instant message, your mobile phone can play a sound, vibrate, or display an icon. To set up one of these handy notifications, start in the

friends list, and then touch . Then touch following:

Settings

. Now choose from one of the

Notifications

Ringtone

Vibrate

Touch to choose whether you receive a notification on the notification bar when you receive an instant message.

Touch to choose the ringtone used for a new instant message. You will hear a short sample of the ringtone when you select it. To turn the ringtone of f, select

Touch to choose whether your mobile phone vibrate when you receive a new instant message.

Silent

9.3.6 Signing out of Talk

On the friends list screen, touch , and then touch

Sign out

to quit

Talk

9.4 Maps

Maps

lets you find your current location, view real-time traffic conditions (depending on availability in your locale), and get detailed directions to various destinations. You can view satellite images, traffic maps, or other kinds of maps of your current or other locations.

9.4.1 Enabling the Location Service

Before you open enable the location service.

1. On the Home screen, touch >

2. Touch

3. In the

GPS satellites

Maps

to find your location or search for places of interest, you must

Location & security

My Location

section, select the

check box, or both.

Settings

Use wireless networ ks

check box, the

Use

9.4.2 Opening Maps

On the Home screen, touch >

Maps

to open the application.

9.4.3 Searching for Places of Interest

1. On the map, touch , and then touch

2. Enter the place you want to search for in the search box, and then touch the Search

icon.

3. Your search results will then be displayed. Touch a place you are interested in and

the application will show where it is on the map.

9.4.4 Getting Directions

1. While viewing a map, touch , and then touch

2. Enter the starting point in the first text box, and then enter your destination in the

second text box.

3. Touch the icon for car, public transit, or walking directions.

4. Touch

Get directions

5. Touch a direction item on the list to show it on the map.

6. When you finish viewing or following the directions, touch , and then touch

Clear Map

. Your directions will appear in a list.

to reset the map.

Directions

9.5 YouTube

YouTube

is Google’s free online video streaming service for watching, searching for,

and uploading videos.

9.5.1 Opening YouTube

On the Home screen, touch >

9.5.2 Searching for a Video

1. On the

YouTube

2. Enter a search keyword, and then touch the Search icon.

3. You will see a number of search results displayed below the notification bar. Scroll

through the results and touch a video to watch it.

screen, touch , and then touch

YouTube

. You will then see the YouTube screen.

9.5.3 Sharing a Video

From the video list on the

YouTube

screen, select a video clip and touch .

9.6 Play Store

Android

Play Store

download and install on your phone.

9.6.1 Opening Play Store

1. On the Home screen, touch >

2. When you open

window will appear. Touch

9.6.2 Installing an Application

1. In the

download. On the application details screen, you can view more information about the selected application, such as its cost, overall rating, user comments, and similar applications in which you might be interested. You can also scroll down to view information about the application developer, including other applications from the same developer and a link to the developer's website. In addition, you can send the developer an email.

2. To install the application, touch

price (if it is not free), and confirm your download or purchase.

3. To check the progress of a download, open the notification panel. Most applications

are installed within seconds. To stop an application from downloading, touch the cross (×).

After the application has been downloaded and installed on your mobile phone, the content download icon appears in the notification bar.

If you want to install a non-Play Store application, touch >

Applications

installation of the non-Play Store application.

provides direct access to applications and games which you can

Play Store

for the first time, the

Play Store

, select a category, and then touch the application you want to

Download

, and then select the

Google Play Terms of Service

to continue.

(if it is free) or touch the button with its

Unknown sources

Settings

check box to allow

9.6.3 Uninstalling an Application

1. On the

Play Store

2. Touch the application you want to uninstall, and then touch

screen, touch >

3. When prompted, touch OK to remove the application from your mobile phone.

My Apps

Uninstall

10 Synchronizing Information

Some applications on your mobile phone give you access to the same personal information that you can add, view, and edit on your computer. If you add, change, or delete your information in any of these applications on the web, the updated information also appears on your mobile phone. This is made possible through over-the-air data synchronization. The process occurs in the background and does not interfere with use of your mobile phone. When your phone is synchronizing, a data synchronization icon will be shown in the notification bar.

10.1 Managing Your Accounts

You can synchronize contacts, email, and other information on your mobile phone with multiple Google accounts or other kinds of accounts, depending on the applications installed on your mobile phone. For example, you can start by adding your personal Google account, so your personal email, contacts, and calendar are always available. You could then add a work account, so your work-related emails and work contacts are handy. If you like, you may add multiple Google accounts or other accounts.

10.1.1 Adding an Account

When you add an account, the newly synchronized account with contacts from your existing mobile phone accounts and attempts to merge duplicates into a single entry in as a single contact entry, the contact data itself is not merged.

1. On the Home screen, touch >

displays your current synchronization settings and a list of your current accounts.

In some cases, you may need to obtain account details from IT support. For example, you may need to know the account’s domain or server address.

Contacts

application compares contacts from the

Contacts

Settings

Accounts & sync

. While it is presented

. The screen

2. Touch

Add account

3. Touch the kind of account to add.

4. Follow the onscreen steps to enter the required and optional information about the

account. Most accounts require a username and password, but the details depend on the kind of account and the configuration of the service to which you are connecting.

5. Configure the account. Depending on the kind of account, you may be asked to

configure what kind of data you want to synchronize to the mobile phone, to name the account, and for other details. When you are finished, the account is added to the list on the

Accounts & sync settings

screen.

10.1.2 Adding an Exchange Account

1. On the Home screen, touch >

2. Touch

Add account

3. Follow the instructions and enter the required information about the exchange

account you want to add. For details, contact the server administrator.

4. Touch

synchronization settings for this account.

5. Touch

synchronized properly, contact the server administrator.

to display the

to finish configuring the account settings. If emails are not

Settings

Corporate

Account options

Accounts & sync

screen. Configure the

10.1.3 Removing an Account

You can remove an account, deleting it and all information associated with it from your mobile phone, including email, contacts, settings, and so on. You cannot, however, remove some accounts, such as the first account you signed into on the mobile phone. If you attempt to remove certain accounts, all personal information associated with it will be deleted.

You can only remove the first Google Account by resetting the phone to factory defaults.

1. On the

Accounts & sync settings

2. Touch

Sign Out

3. Confirm that you want to remove the account.

screen, touch the account to be deleted.

10.2 Customizing Your Account Synchronization

You can configure background data use and synchronization options for all the applications on your phone. You can also configure what kind of data you synchronize for each account. For some accounts, synchronization is bi-directional; changes that you make to the information on your mobile phone are made to the copy of that information on the web. Some accounts support only one-way synchronization; the information on your mobile phone is read-only.

10.2.1 Configuring General Synchronization Settings

On the

Accounts & sync settings

• Select or clear the

and services can transmit data when you are not working with them directly (that is, when they are running in the background).

If you clear this option, synchronizing events, and so on, until you refresh them.

• Select or c lear the

information on the phone or on the web are automatically synchronized with each other.

For example, when this option is selected, changes that you make in on the phone are automatically made in Google Contacts on the web.

Background data

Auto-sync

10.2.2 Changing an Account’s Synchronization Settings

1. On the

Accounts & sync settings

sync

2. Touch the account for which you want to change the synchronization settings. The

data and synchronization screen opens, displaying a list of the kinds of information the account can synchronize.

3. Select the items you want to synchronize from the list. Your phone will automatically

synchronize the selected items.

screen, do the f ollowing:

check box to control whether applications

Gmail

stops receiving new mails,

check box to control whether changes you make to

screen, select

Calendar

Background data

and

stops

Contacts

Auto-

11 Using Other Applications

11.1 Calendar

Use

Calendar

Depending on your synchronization settings, the calendar on your phone can be synchronized with the internet-based calendar you use.

11.1.1 Opening Calendar

On the Home screen, touch > When you add a Google Account that includes a calendar service to your phone, you

can access Google calendar: Touch , and then touch

11.1.2 Creating an Event

1. In any calendar view, touch , and then touch

2. Enter the event name.

3. Enter the location of the event and a description.

4. Specify in

5. Touch

to create and manage events, meetings, and appointments.

Calendar

to open the application.

Calendars

New event

to open the

details

screen.

If you have more than one calendar, select the calendar where you want to save the event.

• If there is a time frame for the event, touch and end times of the event.

• If the event is a special occasion such as a birthday or a day-long activity, set the date for

From

and To, and then select the

Repetition

then set the time for your event reminder in

Done

To quickly create an event in the day, week, or month view, touch and hold an empty time slot, and then touch appear with the selected time slot and date in the

whether the event recurs and, if it does, how frequently, and

From

and To to set the beginning

All day

Reminders

New event

. A new event details screen will

From

check box.

and To fields.

Event

11.1.3 Setting an Event Reminder

1. In any calendar view, touch an event to view its details or an event summary.

2. Touch the

Add reminder

button to delete an existing reminder.

3. Touch the reminder time, and then, from the list displayed, touch the length of time before the event when you want to be reminded. When the time comes, you will receive a notification about the event.

button to add a reminder, or touch the reminder’s “-”

11.1.4 Setting Synchronization and Display

1. In any calendar view, touch . Then touch

The Calendars screen displays all the calendars you have added or subscribed to for each account that is configured to synchronize events to your phone, organized by account. (Calendars for accounts you have configured not to synchronize Calendar events are not included in the list.)

2. Touch the icon next to a calendar to change whether it is synchronized and whether it is displayed.

You remain subscribed to Calendars that you configure not to store on the phone and can still work with them with Google Calendar on the web, or using other calendar services.

3. Touch OK.

Calendars

11.1.5 Customizing Calendar Settings

In any calendar view, touch . Then touch following:

•

Hide declined events

invitations.

•

Set alerts & notifications

a notification, or to turn off event notifications on your mobile phone.

•

Select ringtone

reminder.

•

Vibrate

: Select to vibrate the mobile phone when you receive an event notification.

•

Default reminder time

reminders to occur.

: Select to hide events for which you have decline d

: Touch to set event reminders to alert you, to send you

: Touch to select the ringtone to sound when you receive an event

: Touch to select the default time before an event for event

Settings

and choose from the

11.2 File Manager

File Manager

organize, edit, and delete files and folders.

11.2.1 Opening File Manager

On the Home screen, touch >

11.2.2 Creating a Folder

1. On the

2. Touch to open the options panel, and then touch

3. Enter the name of the new folder in the text box.

4. Touch

11.2.3 Moving or Copying a File

1. On the

2. Touch the file or folder you want to move or copy. When a file or a folder is selected,

3. Touch

4. Select the path where you want the file to be copied or moved. Touch to open

11.2.4 Searching for a File

1. On the

2. Touch to open the options panel, and then touch

3. Write a key word of the name of your file in the search box.

4. Touch next to the search box. Your mobile phone will start the search.

is like having a pocket-sized personal assistant (PA), letting you

File Manager

new folder.

Save

File Manager

Multiselect

a check mark will appear.

To select or unselect all files, touch

Cut

the options panel, and then touch path.

File Manager

you want is located.

screen, access the directory in which you want to create a

screen, touch to show the options panel, and then touch

Copy

screen, touch a folder to access the directory where the file

File Manager

Paste

to open the application.

Select all

to move or copy the file to the selected

New folder

Unselect all

5. A list of search results will be displayed. Touch a file in the list to open it.

6. Touch

New search

manager screen.

for a new search or touch the back key to return to the file

11.2.5 Compressing or Extracting Files

Your phone supports compressing and extracting files.

You can only compress files and folders into .zip files, but can extract both .zip and .rar files.

Compressing Files

1. On the

File Manager

2. Select the files or folders you want to compress. When a file is selected, a check mark will appear.

To select or unselect all files, touch

3. Touch

Compress

4. Edit the save path and the name of the target file, and then touch OK to start compressing the files and folders.

Extracting a File

1. Touch and hold a compressed file.

2. Touch

Extract

3. Edit the save path for the extracted files.

4. Touch OK to start extracting.

screen, touch , and then touch

Select all

Unselect all

Multiselect

11.2.6 Viewing Your Memory Status

On the

File Manager

Memory Status

allows you to view the memory status and available memory on your mobile phone and microSD card.

screen, touch to open the options panel, and then touch

. The memory management screen will be displayed. This screen

11.3 Clock

In addition to displaying the date and time, the about the weather and your phone. You can also use phone into an alarm clock.

11.3.1 Opening the Clock

On the Home screen, touch >

Clock

opens with the date and time displayed on your Home screen wallpaper, along

with your local weather and other useful information.

11.3.2 Opening the Alarms

On the

Clock

screen, touch to open the

Adding an Alarm

1. On the alarm list screen, touch

2. Set the alarm, and then touch

Setting an Alarm

1. On the alarm list screen, touch one of the alarms on the screen.

2. Touch

Time

3. Touch

4. Touch

5. Select the

6. Touch

7. Touch

Customizing Alarm Settings

On the alarm list screen, touch , and then touch

to set the time of the alarm.

Repeat

to set the days when you want the alarm to sound.

Ringtone

to select a ringtone for the alarm.

Vibrate

the ringtone.

The alarm clock still works when the phone is powered off.

check box to enable the phone to vibrate, in addition to playing

Label

to enter a name for the alarm.

Done

Clock

to open the application.

Add alarm

Done

Clock

application displays information

Clock

to turn your mobile

Alarms

Settings

11.4 Calculator

Use

Calculator

solve more complex equations.

to solve simple arithmetic problems or use its advanced operators to

11.4.1 Opening Calculator

On the Home screen, touch >

Calculator

to open the application.

11.4.2 Switching Between Basic and Advanced panel

On the

Calculator

Advanced panel

screen, flick the screen to the right or left to switch between

and

Basic panel

11.5 Notepad

Notepad

features a simple text processor. In the note list, you can add, edit, and

delete notes.

1. On the Home screen, touch >

2. Touch , and then touch

3. Touch > OK to save the note.

Add note

Notepad

to open the application.

to create a note.

11.6 Weather

You can use

Weather

latest weather of any city in any time and to share weather information with others.

You need to turn on the GPS and data service on your phone before using weather clock.

11.6.1 Setting the Default City

1. On the Home screen, touch >

2. On the weather clock screen, touch >

3. Select the city you want to add.

In addition to your current city, you can add up to four more cities to the weather clock and get weather information for all of them at the same time.

to check the date and time of cities around the world, to get the

Weather

Add city

4. On the weather information screen, touch the name of the city to be set as the default city, and then confirm to complete the operation.

11.6.2 Updating Weather

You can update weather information on the weather clock either manually or

automatically. To update the current city's latest weather information, touch >

Refresh

on the weather clock screen.

You can also set your phone to update the weather information automatically.

1. On the weather clock screen, touch >

2. Select

Auto update

Update interval

to set the interval between automatic weather updates.

3. Touch

Settings

11.6.3 Changing a City

1. On the weather clock screen, touch >

2. Select a city from the the search field.

Hot city

Change city

list, or search for another city by entering its name in

11.6.4 Sharing Weather Information

1. On the weather clock screen, touch >

2. Enter a phone number or a contact's name in the To field, or touch to select a

Contacts

Groups

3. Touch

Send

to send weather information to the recipient.

Share weather

11.7 Genius Button

Touch to activate voice recognition to let you use your voice on your Contacts list and your Music library.

•

Call

: Say the name or number of the person you would like to call.

•

Send Text

: Say the name of the person to whom you would like to address the

message.

•

Search Web

: Say what you are searching for on the Web.

•

Navigate To

: Say the destination address.

12 Managing Your Mobile Phone

To configure your mobile phone, touch >

12.1 Setting the Date and Time

When your mobile phone is using the date and time settings provided automatically by the network, you cannot manually set the date, time, and time zone.

1. On the

Settings

2. Clear the

3. Touch month, and year, and then touch

4. Touch the list to view more time zones.

5. Touch minute. Touch

6. Select or clear the 12-hour formats.

7. Touch mobile phone.

screen, touch

Automatic

check box.

Set date

. On the set date screen, touch or to adjust the date,

Select time zone

Set time

Select date format

, and then select the desired time zone from the list. Scroll

. On the set time screen, touch or to adjust the hour and

Set

when the configuration is complete.

Use 24-hour format

to select how you want the date to display on your

12.2 Setting the Display

12.2.1 Adjusting the Screen Brightness

1. On the

Settings

If you want to adjust the screen brightness manually, first clear the

brightness

2. Drag the slider left to make the screen darker, or right to make it brighter.

3. Touch OK to save the adjustment.

screen, touch

checkbox.

Settings

Date & time

Set

when the configuration is complete.

check box to switch between 24-hour and

Display

Brightness

Automatic

12.2.2 Adjusting the Time Before the Screen Turns Off

If your mobile phone is idle for several minutes, it will turn off the screen to save battery power. To set a longer or shorter idle time:

1. On the

Settings

2. Select the duration you want the screen to be illuminated.

screen, touch

Display

Screen timeout

12.3 Setting Ringers

12.3.1 Turning On Silent Mode

1. On the

Settings

2. Select the and video media.

screen, touch

Silent mode

12.3.2 Adjusting the Volume

You can adjust the volume while on the Home screen or on most of the application screens (such as the screen displayed during a call or when playing music or videos). Press the Volume keys to adjust volume to the level you desire. You can also adjust the volume from the settings screen.

1. On the

Settings

2. Drag the slider left to make the volume lower, or right to make it higher.

3. Touch OK to save the adjustment.

screen, touch

12.3.3 Changing the Phone Ringtone

1. On the

Settings

2. In the displayed list, select an option:

•

3. Touch OK.

screen, touch

Ringtone

: Select a preinstalled ringtone. The ringtone plays when selected.

Music

: Select the music stored in the phone or on the microSD card. The

music plays when selected.

Sound

Volume

Phone ringtone

check box to silence all sounds except alarms, and music

12.3.4 Changing the Message Ringtone

1. On the Home screen, touch >

2. In the message list, touch >

3. In the displayed list, select an option:

•

Ringtone

: Select a preinstalled ringtone. The ringtone plays when selected.

•

Music

: Select the music stored in the phone or on the microSD card. The

music plays when selected.

4. Touch OK.

Messages

Settings

Select ringtone

12.4 Setting Phone Services

12.4.1 Customizing Call Settings

Mobile phone service providers offer different services such as call forwarding, call waiting, fixed dialing numbers, and voicemail. You can customize many of these services if they are part of your calling plan. On the

Settings

screen, touch

Call settings

to customize your call functions.

12.4.2 Turning on Data Roaming

1. On the

Settings

2. Select the

Accessing data services while roaming may incur additional charges. Ask your wireless service provider about data roaming fees.

screen, touch

Data roaming

Wireless & networks

check box.

Mobile networks

12.4.3 Switching off the Data Service

1. On the

Settings

2. Clear the

screen, touch

Data enabled

Wireless & networks

check box.

Mobile networks

12.5 Configuring Text-to-Speech

Use the Text-to-Speech settings to configure the Android text-to-speech synthesizer, for applications that can take advantage of this feature.

12.5.1 Installing Voice Data

1. On the

Settings

Install voice data

2. If your mobile phone does not have speech synthesizer data installed, connect to Android Play Store and let it guide you through the process of downloading and installing the data.

3. Follow the instructions to install the voice data.

screen, touch

Voice input & output

Text-to-speech settings

12.5.2 Adjusting the Speech Rate

1. On the

Settings

Speech rate

2. Select a speed at which the text is to be spoken.

screen, touch

Voice input & output

Text-to-speech settings

12.6 Protecting Your Mobile Phone

12.6.1 Turning on Your SIM Card PIN

1. On the

Settings

2. Select the

3. Use the keyboard to enter the PIN, and then touch OK.

4. To change the PIN at any time, touch

You can dial emergency numbers any time from your mobile phone.

screen, touch

Lock SIM card

12.6.2 Protecting Your Mobile Phone with a Screen Lock

To keep your data more secure, lock the screen and/or require a screen unlock pattern every time your mobile phone is turned on or wakes up from sleep mode.

1. On the

Settings

Pattern

2. Flick your finger vertically, horizontally or diagonally, connect at least four dots in any order you choose. Lift your finger from the screen when you are finished.

You must drag your finger between the dots on the screen to create the pattern, not simply touch individual dots.

3. Your mobile phone will record the pattern. Touch

screen, touch

Location & security

check box.

Change SIM PIN

Location & security

Set up SIM card lock

Set up screen lock

Continue

4. When prompted, draw the screen unlock pattern again, and then touch

To change your unlock screen pattern, touch

lock

Location & security

Confirm

Change screen

12.6.3 Protecting Your Mobile Phone with a Numeric PIN

You can set up a numeric PIN to lock your phone.

1. On the

Settings

Continue

screen, touch

2. Enter at least four characters.

3. Touch

4. Enter the same characters again and touch OK.

To change your PIN, touch

Location & security

Set up screen lock

Change screen lock

12.6.4 Unlocking Your Mobile Phone If You Forget the Screen

Lock Pattern

If you have already created a Google account, you can unlock your mobile phone using the following methods.

• After you have entered the wrong sequence five times, a will appear. Touch this button to enter the Google account interface. After you have entered your Google account password, you will be able to reset the unlock pattern.

• After you have entered the wrong pattern twenty times, you will be taken directly to the Google account interface. After you have entered your Google account password, you will be able to reset the unlock pattern.

Forgot pattern?

button

12.7 Managing Applications

12.7.1 Viewing an Installed Application

1. On the

Settings

2. In the applications list, do either of the following:

screen, touch

• Touch , and then touch details.

• Touch an application directly to view its details.

Applications

Sort by size

Manage applications

. Then touch an application to view its

12.7.2 Uninstalling an Application

You cannot uninstall the applications that are pre-installed on the system.

1. On the

Settings

2. Touch an application, and then touch

screen, touch

Applications

Uninstall

Manage applications

12.7.3 Moving an Application to the microSD Card

Some applications are designed to be stored on your phone’s USB storage or microSD card (depending on the model of your phone), rather than in its internal storage. Others are designed so you can change where they are stored. You may find it helpful to move large applications off your internal storage, to make more room for other applications that do not offer the option.

1. On the

Settings

2. Touch an application in the list. Then touch the application from the phone’s internal storage.

The memory used by the application. If the application can be moved, the

SD card

Touch storage.

screen, touch

Storage

section of the application’s details screen shows details about the

button is active.

Move to phone

Applications

to move the application back to the phone’s internal

Manage applications

Move to SD card

to move the bulk of

Move to

12.7.4 Ways to Free Up Your Mobile Phone Memory

• Move files and email attachments to the microSD card.

• In

Browser

, clear all temporary Internet files and Browser history information.

• Move applications to the microSD card.

• Uninstall any downloaded programs that you no longer use.

• Reset your mobile phone.

12.8 Resetting Your Mobile Phone

12.8.1 Backing Up My Data

You can use your Google account to back up your mobile phone’s settings to Google servers. If you replace your mobile phone, the settings you have backed up will be transferred to the new mobile phone the first time you sign in to your Google account.

1. On the

Settings

2. Select the

screen, touch

Back up my data

Privacy

check box.

12.8.2 Restoring Factory Data

If you reset your phone to its factory settings, all of your personal data stored on the phone, including information about your Google account, any other accounts that you have configured, your system and application settings, and any applications you have installed will be erased. Resetting the phone does not erase any system updates you have downloaded. Using the check box provided, you can also select to erase all the data stored on your SD card or on the phone’s internal SD card, which includes files that you have downloaded or copied there, such as music or photos.

1. On the

Settings

2. When prompted, touch mobile phone resets the settings to the original factory settings, and then restarts.

screen, touch

Privacy

Reset phone

Factory data reset

, and then touch

Erase everything

. The

13 Appendix

13.1 FAQs

How Can I Use a microSD Card to Import Contacts to My Phone from a

Different Mobile Phone?

Your mobile phone only supports contact files in the

Save the contacts you want to import to your mobile phone to a microSD card as a

.vcf

Insert the microSD card into your mobile phone and find the using

file.

File Manager

.vcf

format.

.vcf

file

Touch the

.vcf

file. The phone displays a message asking whether you

want to import the co ntacts.

Touch OK to import the contacts.

Compatibility problems may occur with phones and certain contact information may be lost after contacts are imported.

You can also use Bluetooth to share and import contacts.

.vcf

files created by different mobile

How Do I Prevent Automatic Change of Screen Orientation When Rotating My

Phone?

On the Home screen, touch > disable the function.

Settings

Display

Auto-rotate screen

How Do I Set an Unlock Pattern?

On the Home screen, touch >

lock

Pattern

Settings

Location & security

Set up screen

How Can I Change the Input Method?

Touch and hold the area where you write text and then select the input method you prefer.

How Do I Stop the Song Playing in the Background?

Touch the notification bar, flick downwards to open the notifications panel, touch the music playing notification to go to the music playing screen, and then stop playing the song.

How Do I Return to the Call Screen?

While in a call, if you’re on another screen, you can touch the notification bar, and flick downwards to open the notifications panel. Then touch the current call notification to return to the call screen.

How Do I Create an Application Shortcut on the Home Screen?

Touch and hold an application icon on the application screen until the Home screen is displayed. Then drag the icon to where you want to place it and release your finger.

How Do I Hide the Keyboard?

Touch to hide the keyboard.

How Do I Forward a Message?

Touch and hold a message, and then touch

How Do I Use Quick GPS?

On the Home screen, touch >

GPS

. Quick GPS downloads data to enhance the GPS satellite information and may therefore incur additional data charges.

Settings

Forward

in the menu that opens.

Location & security

Use Quick

V100R001_01

T-Mobile myTouch Q User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

1 Read Before Proceeding

1.1 Safety Precautions

1.2 Personal Information and Data Security

1.3 Legal Notice

Copyright © Huawei Technologies Co., Ltd. 2012. All rights reserved.

Trademarks and Permissions

Notice

Third-Party Software Statement

DISCLAIMER OF WARRANTIES

LIMITATIONS OF LIABILITY

Import and Export Regulations

2 Getting Started

2.1 Phone at a Glance

2.2 Key Functions at Your Fingertips

2.3 Installing the SIM Card

2.4 (Optional) Installing the microSD Card

2.5 Installing the Battery

2.6 Charging the Battery

2.6.1 Status Indicator

2.8 Power Saving Tips

2.9 Power On or Off Your Mobile Phone

2.9.1 Powering On Your Mobile Phone

2.9.2 Setting Up Your Mobile Phone

2.9.3 Turning On Fast Boot

2.9.4 Powering Off Your Mobile Phone

2.9.5 Restarting Your Mobile Phone

2.10 Using the Touchscreen

2.10.1 Touchscreen Actions

2.10.2 Rotating Your Mobile Phone Screen

2.11 Locking and Unlocking the Screen

2.11.1 Locking the Screen

2.11.2 Unlocking the Screen

2.12 Home Screen

2.12.1 Notification and Status Icons

2.12.2 Notification Panel

Opening the Notification Panel

Closing the Notification Panel

2.12.3 Viewing Other Parts of the Home Screen

2.12.4 Customizing the Home Screen

Adding a New Home Screen Item

Moving a Home Screen Item

Removing a Home Screen Item

2.12.5 Service Shortcuts

2.12.6 Changing the Wallpaper

2.13 Using a microSD Card

2.13.1 Using the microSD Card as a USB Mass Storage

2.13.2 Removing the microSD Card

3 Calling

3.1 Making a Call

3.1.1 Making a Call with the Dialer Application

3.1.2 Making a Call from Contacts

3.1.3 Making a Call from Call log

3.2 Answering or Rejecting a Call

3.2.1 Answering an Incoming Call

3.2.2 Ending a Call

3.2.3 Rejecting an Incoming Call

3.3 Other Operations During a Call

3.3.1 Making a Conference Call

3.3.2 Switching Between Calls

3.4 Using the Call log

3.4.1 Adding an Entry to Contacts

3.5 TTY Operation

3.5.1 Using the TTY Device

3.5.2 Setting the TTY Mode

3.6 Setting Hearing Aid Compatibility

3.7 Using Airplane Mode

4 Contacts

4.1 Opening the Contacts Application

4.2 Importing Contacts from a SIM Card

4.3 Adding a Contact

4.4 Adding a Contact to Your Favorites

4.5 Searching for a Contact

4.6 Editing a Contact

4.7 Communicating with Your Contacts

4.7.1 Using Quick Contact for Android

4.7.2 Communicating with a Contact
