LAMINATED
MOLDED
Bumpers, Wheel Chocks & Track Guards
Save-T LAMINATED RUBBER BUMPERS
Laminated Bumpers are constructed of recycled truck tire pads
compressed between steel angles and secured with 3/4" steel
tie rods. Laminated bumpers, the most common style, protect
both trucks and docks. Our complete line includes all sizes from
4-1/2" to 12" thick in horizontal, vertical, extra-length, and extra-thick styles.
Gussets for lower loading docks and special sizes are also available.
Save-T STEEL FACED BUMPERS
Steel Faced Bumpers with a 3/8" thick steel front plate should be used where
maximum protection is desired. They will absorb more shock and abrasion than
STEEL
FAC ED
standard laminated bumpers, and absorb the constant height adjustment of air
ride trailers. Standard sizes are 4-1/4" to 12-3/4" thick in standard design and
sizes. Gussets for lower loading docks and special sizes are also available.
Steel Faced Bumpers last as much as 5 times longer than standard laminated
bumpers, offering the lowest cost of ownership.
Save-T MOLDED RUBBER BUMPERS
Molded Dock Bumpers are manufactured using reinforced rubber in a variety of
shapes and sizes. These solid, durable, one piece bumpers are smooth, attractive, and will not harden or be affected by weather. The most popular models are
the "T", "L", and "R" styles. We carry a full line of standard sizes.
See Back Cover
for Product
Model Numbers
WHEEL CHOCKS
EXTRUDED
Save-T EXTRUDED BUMPERS
When wall protection from forklifts and other loading dock equipment is needed,
Extruded Bumpers are the ideal solution. This type of bumper is also great for
indoor parking areas and marinas. They are available in any length up to ten feet
and can have holes pre-drilled at the factory. Common styles include the "D" and
"E" shapes.
Save-T WHEEL CHOCKS
TMI, LLC carries an entire line of wheel chocks, including laminated rubber, molded
rubber, urethane, and aluminum. Wheel chocks can be purchased with standard
chain lengths of 10’, 12’, and 15’. Safety security signs are also available.
OSHA Regulation 1910.78(M) - Wheel chocks must be used in addition
to a trailer stand while trailer is docked.
Save-T OVERHEAD DOOR TRACK GUARDS
Made of heavy-duty 7 gauge steel, they absorb impact from forklifts and
other vehicles. Track guards bolt to the floor and the wall for firm attachment.
Wraps around door track without interfering with door operation
•
45 degree angle flange adds strength and protects from side impact
•
1/4" thick floor plate drilled for three 1/2'' anchors
•
3/16" thick wall flange drilled for three 1/2'' anchors
•
7-1/4" projection
•
Stocked in 36" (DTG 36), and 48" (DTG 48) sections
•
2
Page 3
Dock Lights
Save-T LED DOCK LIGHT HEADS
This new LED light outlasts up to 25 incandescent lights, and eliminates high maintenance costs associated with repair and replacement of traditional dock lights.
LED Dock Lights are made using a PAR 38 LED bulb with a choice of single or
double strut arms. This light also comes in an Ultra Heavy-Duty model. Optional
fans and secure wire guards are available.
Head Diameter: 8".
DL-40-PLED
Save-T POLYMER DOCKLITE®HEADS
The Polymer Docklite Head has a cool-to-the-touch head that deflects and dissipates heat and prevents denting.
Head Diameter: 8"; Compatible with standard Phoenix arms.
Save-T FLUORESCENT DOCKLITE®HEADS -
The self-ballasted compact fluorescent light head allows for up to 75% energy
savings each year. The cool-to-the-touch light head is also impact resistant.
Energy savings rebates may be available!
Head Diameter: 8"; Compatible with standard Phoenix arms.
Phoenix Modular Dock Light Heads
Product No. Description
DL-INC-LH Incandescent Light Head
DL-50HPS-LH 50 Watt High Pressure Sodium (Available up to 100 Watts)
DL-50MH-LH 50 Watt Metal Halide (Available up to 100 Watts)
DL-500QH-LH 500 Watt Quartz Halogen
Phoenix Modular Dock Light Arms
Product No. Description
DL-24-ARM Single Strut 24'' Arm
DL-42-ARM Single Strut 42'' Arm
DL-60-ARM Single Strut 60'' Arm
Product No. Description
DL-42-ARM-DS Double Strut 42'' Arm
DL-60-ARM-DS Double Strut 60'' Arm
DL-42-ARM-SP Spring Arm 42''
Energy Savings
DLP-INC-LH
DLP-40SBFL-LH
DL40-P
Fans, Explosion Proof, Weather Tight, and Impact Resistant Lights Available – Call 800-888-9750
Save-T POLYCARBONATE DOCK LIGHTS
The Tri-Lite DL40-P has a 40'' Double Strut Arm. This cool-to-the-touch head is
very durable and very affordable. Single strut arm and metal head available.
Save-T STOP & GO COMMUNICATION LIGHTS
Tri-Lite Stop & Go Lights alert personnel that a truck has been safely docked.
These are available in Incandescent, LED, and Low Voltage light types.
SG10/20/30
3
3
Page 4
Trailer Stands
TMI’s Save-T Trailer Stands are essential for loading dock safety. All three
Trailer Stands provide secondary support should a trailer’s landing gear
collapse. The Ratchet-Riser will also help reposition a trailer after an accident
with 40,000 lbs. of lifting capacity. Each stand is ergonomically designed and
offers best-in-class safety and simplicity.
EZ-RISER
Save-T EZ-RISER TRAILER STANDS
Exclusive gas-activated leveling system with security pin
•
100,000 lbs static load capacity
•
Height adjustable from 36" to 48"
•
5" x 30" support pad
•
Extra large 17" x 18.5" base
•
Large 16" pneumatic rubber tires
•
Only one required per trailer
•
Weight - 200 lbs.
•
One year limited warranty
•
AUTO-RISER
Save-T AUTO-RISER TRAILER STANDS
Exclusive gas-activated leveling system with security pin
•
100,000 lbs static load capacity
•
Height adjustable from 42" to 52.5"
•
5" x 30" support pad
•
Extra large 17" x 18.5" base
•
10" semi-pneumatic rubber tires
•
Only one required per trailer
•
Weight - 150 lbs.
•
One year limited warranty
•
Save-T RATCHET-RISER TRAILER STANDS
38" ratcheting/positioning handle
•
100,000 lbs static load capacity
•
40,000 lbs lifting capacity
•
Height adjustable from 39.5" to 51"
•
Large circular base
•
10" semi-pneumatic rubber tires
•
Two recommended per trailer
•
Weight - 105 lbs.
•
One year limited warranty
•
OSHA regulations suggest that trailer stands may prevent the upending of
trailers during loading or unloading when the trailer is not attached to a
RATCHET-RISER
4
tractor or converter dolly.
Page 5
Parking Blocks, Speed Bumps & Post Guards
Save-T PARKING BLOCKS and SPEED BUMPS
Save-T Parking Blocks are made of rugged, high density polyethylene. They
are flexible, light weight, affordable, and will never need to be painted. They
feature a non-skid surface, weather and chemical resistant, and are load tested
to 20,000 lbs. per pneumatic tire. Mounting hardware is included.
Product No. Description Wt.
T1790Y HDPE Parking Block - 4''H x 8''W x 72''L 15 lbs.
Yellow, Gray, Blue, Black
T1792 HDPE Speed Bump - Cable Guard - Yellow - 6' Long 15 lbs.
T1793 HDPE Speed Bump - Cable Guard - Yellow - 9' Long 25 lbs.
T1790KIT HDPE Anchor Kit for Parking Stops (3 Anchors) 3 lbs.
T1792KIT HDPE Anchor Kit for Speed Bumps (6 Anchors) 8 lbs.
Save-T SOLID RECYCLED PLASTIC PARKING BLOCK
and SPEED BUMPS
These solid parking blocks are virtually indestructible and maintenance free.
They carry a lifetime warranty against breakage, chipping or cracking.
Product No. Description Wt.
SPB-4-6-72 Solid Standard Parking Block - 4''H x 6''W x 72''L 30 lbs.
DLP-4.5-6-72 Solid Deluxe Parking Block - 4.5''H x 6''W x 72''L 36 lbs.
TPB-7-10-96 Solid Truck Parking Block - 7''H x 10''W x 96''L 80 lbs.
SSB-2-10-72 Solid Standard Speed Bump - 2''H x 10''W x 72''L 25 lbs.
Available colors: yellow, gray, blue,
and black with yellow stripes.
Mounting hardware
included
Mounting hardware
included
Save-T BOLLARD POSTS and MACHINE GUARDS
Save-T Bollard Posts prevent damage to doorways, racking, or corners. Post
caps can be removed for filling. TMI's Save-T Machine Guards provide protection
for equipment and machinery and can create barriers between traffic areas.
Product
No. Description
T1742 4'' Dia. Bollard Post -
T1743 4'' Dia. Bollard Post - 36''H
T1744 4'' Dia. Bollard Post - 42''H
T1749 4'' Dia. Post Cap
T1755 5'' Dia. Bollard Post -
T1756 5'' Dia. Bollard Post - 36''H
T1757 5'' Dia. Bollard Post - 42''H
T1758 5'' Dia. Post Cap
T1752 5'' Sq. Bollard Post -
T1753 5'' Sq. Bollard Post - 36''H
T1754 5'' Sq. Bollard Post - 42'H
24''H
24''H
24''H
Product
No. Description
T1759 5'' Sq. Post Cap
T1763 6'' Dia. Bollard Post -
T1764 6'' Dia. Bollard Post - 42''H
T1769 6'' Dia. Post Cap
T1746 4'' Machine Guard-
T1770 4'' Machine Guard-24''H x 48''W
T1774 4'' Machine Guard-36''H x 36''W
T1775 4'' Machine Guard-36''H x 48''W
T1771 4'' Machine Guard-42''H x 36''W
T1747 4'' Machine Guard-42''H x 48''W
36''H
24''H x 36''W
Save-T BOLLARD POST SLEEVES
Save-T Post Sleeves make old bollards look new. These sleeves eliminate costly
repairs due to chipping, rusting, cracking, or discoloration. Sleeves are 56" long
and can be trimmed to fit existing posts. Yellow is standard, additional colors available.
Product No. Description Wt.
T1732 Sleeve for 4'' Round Bumper Post - Yellow Ribbed 4 lbs.
T1732BASE Base for 4'' Round Bumper Post Sleeve 2 lbs.
T1730 Sleeve for 6'' Round Bumper Post - Yellow Ribbed 6 lbs.
T1730BASE Base for 4'' Round Bumper Post Sleeve 2 lbs.
T1735 Sleeve for 4'' Round Bumper Post - Yellow Smooth 4 lbs.
T1736 Sleeve for 6'' Round Bumper Post - Yellow Smooth 6 lbs.
T1737 Sleeve for 8'' Round Bumper Post - Yellow Smooth 8 lbs.
BOLLARDS
• 1/2" thick steel on a 3/8" steel plate
• Powder-coated with lead-free paint
MACHINE GUARDS
• Made of heavy-duty steel
BOLLARD POST SLEEVES
• Ribbed and smooth outside surface
• Fits 4'', 6'', and 8'' posts
3
5
Page 6
Protection Devices & Dock Plates
Save-T COLUMN PROTECTORS
Save-T Column Protectors are the perfect solution for protecting
warehouse and factory columns, posts, and beams. These high density polyethylene protectors absorb impact and prevent damage and
repair charges to columns, forklifts, equipment, and personnel. They
can be installed in just seconds. Two halves attach together with
easy-to-use Velcro straps and require no tools. Each column protector is maintenance free, light weight, and UV protected. Other highvisibility colors are available.
T1706
Product No. Description Wt.
T1704 Narrow Protector for 4''- 6'' Column 16 lbs.
T1706 Protector for 6'' Column 40 lbs.
T1708 Protector for 8'' Column 40 lbs.
T1710 Protector for 10'' Column 40 lbs.
T1712 Protector for 12'' Column 40 lbs.
T1726
T1720
Save-T WALL PROTECTORS
Save-T Wall Protectors are a simple solution for preventing damage
to walls in areas with forklift, hand truck, or drum traffic. Each high
density polyethylene protector is impact resistant, light weight, and
resistant to cracking and chipping. (Anchors not provided).
Product No. Description Wt.
T1726 6'' Wall Protector (Set of 2) 8 lbs.
T1728 10'' Wall Protector (Set of 2) 14 lbs.
Save-T CORNER PROTECTORS
Save-T Corner Protectors deflect impact and protect plant areas
prone to damage by forklift, hand truck, or personnel traffic. They
can be mounted to protect racks or overhead door frames. Each
lightweight corner protector is UV stabilized.
Product No. Description Wt.
T1720 21'' Corner Protector (Set of 2) 10 lbs.
T1725 42'' Corner Protector (Set of 2) 20 lbs.
Save-T PORTABLE POLY DOCK PLATE (Not Shown)
The Save-T Portable Poly Dock Plate is designed for use with two
and four wheeled dollies, hand trucks, and carts. Its light, durable
ergonomic design and raised non-slip surface makes it easy to
handle and use. Maximum load capacity is 750 lbs.
Product No. Description Wt.
T1795 Portable Poly Dock Plate - 35'' W x 36''L x 5''H 30 lbs.
T1795CR Shipping Container Ramp - 35'' W x 36''L x 6''H 25 lbs.
Save-T PORTABLE POLY CURB RAMP
TMI’s Save-T Curb Ramp is primarily used with hand trucks or carts.
Its lightweight, durable design makes this the perfect product for
delivery trucks. Maximum load capacity is 1000 lbs.
T1794
6
Product No. Description Wt.
T1794 Poly Curb Ramp - 27'' W x 27''L x 4''H 9 lbs.
Page 7
Guard Security Gates and Cabinets
Save-T GUARD SECURITY GATES
These gates increase protection at loading docks, warehouses, shipping
& receiving doors, personnel entrances and retail stores. They protect from
theft, pilfering and trespassing while allowing fresh air to circulate in
secured areas, creating a comfortable work environment. Gates can be
mounted in-the-jamb or on the face of the outside wall. Extension brackets
are available for mounting around an existing garage door.
Heavy-Duty Construction
• 14 gauge steel with gray polyurethane finish
• 11/2'' x 11/2'' x 1/8'' steel uprights with steel casters and drop pins
• Single and double gate models available
Product No. Gate Style Max. Width Bracket Height Ship Wt.
SG-66-60* Single 66'' 60'' 50 lbs.
SG-66-78 Single 66'' 78'' 65 lbs.
SG-66-96 Single 66'' 96'' 75 lbs.
SG-78-78 Single 78'' 78'' 65 lbs.
SG-78-96 Single 78'' 96'' 80 lbs.
SG-90-78 Single 90'' 78'' 70 lbs.
SG-90-96 Single 90'' 96'' 85 lbs.
DG-96-78* Double 96'' 78'' 85 lbs.
DG-96-96 Double 96'' 96'' 100 lbs.
DG-120-78* Double 120'' 78'' 100 lbs.
DG-120-96* Double 120'' 96'' 120 lbs.
DG-144-78* Double 144'' 78'' 115 lbs.
DG-144-96 Double 144'' 96'' 140 lbs.
DG-168-78* Double 168'' 78'' 130 lbs.
DG-168-96* Double 168'' 96'' 160 lbs.
DG-192-78* Double 192'' 78'' 135 lbs.
DG-192-96* Double 192'' 96'' 170 lbs.
* Quick-Ship item - Ships within 1-2 days
Double Gate
Drop Pin
“L” Bracket
Bottom Pin
Save-T STORAGE CABINETS
Save-T Storage Cabinets are the perfect solution for storing flammables,
acids, pesticides, chemicals, and other liquids. Safety Cabinets are made of
18 gauge steel and are designed to protect contained flammable liquids for
a period of 10 minutes, giving employees time to exit a building in case of a
fire. Each cabinet has adjustable shelves to accommodate various container
sizes. Save-T Storage Cabinets meet NFPA Code 30 and OSHA specifica-
tions. Additional sizes are available.
Product No. Description Wt.
T1930 1 Door, Sliding Self Closing Storage Cabinet - 30 Gallons 253 lbs.
T1947 2 Door, Manual Close Storage Cabinet - 45 Gallons 342 lbs.
T3010 2 Door, Self Closing Storage Cabinet - 30 Gallons 257 lbs.
T4510 2 Door, Self Closing Storage Cabinet - 45 Gallons 353 lbs.
T1915 Manual Shelf for 15, 30, 45 Gallon Cabinets 12 lbs.
All steel cabinets meet NFPA Code 30 and OSHA specifications.
Self-closing models meet Uniform Fire Code and NFPA Code One requirements.
T1947
3
7
Page 8
Laminated Rubber Bumpers
DRAWING 4
T
7
⁄ 8" Holes)
DRAWING 3
W
A
C
B
H
B
C
T
R
C
B
H
D
B
C
H – Overall Height
W – Overall Width
T – Overall Thickness
R – Width of Rubber Surface
DRAWING 1
W
A
C
B
H
C
R
A – Horizontal Anchor Holes - Center to Center (
B – Vertical Anchor Holes - Center to Center
C – Center of Anchor Hole to Top/Bottom Edge
DRAWING 2
T
C
B
H
B
C
W
A
R
• Structural Steel Angles and Plates - 3/8'' Thick • Add-On for Galvanized Angles - Consult Factory
W
A
T
R
MODEL NO. No. H W T R A B C D Wt.(lbs.)
Drawing
B410-12 1 10" 14" 41⁄ 2" 8" 12" 5" 21⁄2"– 27
B410-14 1 10" 16" 4
1
⁄ 2" 10" 14" 5" 21⁄ 2"– 31
B410-24 1 10" 26" 41⁄ 2" 20" 24" 5" 21⁄ 2"– 48
B410-36 1 10" 38" 41⁄ 2" 32" 36" 5" 21⁄ 2"– 72
B412-12 1 12" 14" 41⁄ 2" 8" 12" 7" 21⁄ 2"– 32
B412-14 1 12" 16" 41⁄ 2" 10" 14" 7" 21⁄ 2"– 36
1
B412-24 1 12" 26" 4
⁄ 2" 20" 24" 7" 21⁄ 2"– 58
B412-36 1 12" 38" 41⁄ 2" 32" 36" 7" 21⁄ 2"– 9
VB420-11 2 20" 13" 41⁄ 2" 7" 11" 71⁄2"21⁄ 2"– 50
VB424-11 3 24" 13" 4
B610-12 1 10" 14" 6" 8" 12" 5" 2
1
⁄ 2" 7" 11" 91⁄2"21⁄ 2"– 59
1
⁄ 2"– 37
B610-14 1 10" 16" 6" 10" 14" 5" 21⁄ 2"– 4
B610-24 1 10" 26" 6" 20" 24" 5" 21⁄ 2"– 74
B610-36 1 10" 38" 6" 32" 36" 5" 2
1
⁄ 2" – 111
B612-12 1 12" 14" 6" 8" 12" 7" 21⁄ 2"– 45
B612-14 1 12" 16" 6" 10" 14" 7" 2
B612-24 1 12" 26" 6" 20" 24" 7" 2
B612-36 1 12" 38" 6" 32" 36" 7" 2
VB620-11 2 20" 13" 6" 7" 11" 7
1
⁄ 2"21⁄ 2"– 71
1
⁄ 2"– 52
1
⁄ 2"– 84
1
⁄ 2" – 133
VB624-11 3 24" 13" 6" 7" 11" 91⁄ 2"21⁄ 2"– 8
VB636-11 4 36" 13" 6" 7" 11" 9
1
⁄2"21⁄ 2" 12" 122
Extra-Thick & Extra Length Laminated Rubber Bumpers are available.
Other Products
Strip Doors
Managing Environments™
Enclosures
5350 Campbells Run Road • Pittsburgh, PA 15205-9738
Air Curtains Bug Screen
800-888-9750
Tel: 412-787-9750 Fax: 412-787-3665
Web: www.tmi-pvc.com
E-Mail: customer-service@tmi-pvc.com
Impact Doors
Copyright © 2010
Catalog Number LDA-08-10
Loading...
