850921 User Manual

HDMI 1.4 Signal Manager

850921 HDMI Signal Manager

TLS electronics GmbH Contact: [e-mail]

Thank you for purchasing this product. For optimum performance and safety, please read these
instructions carefully before connecting, operating or adjusting this product. Please keep this manual for
future reference.

SURGE PROTECTION DEVICE RECOMMENDED

This product contains sensitive electrical components that may be damaged by electrical spikes, surges,
electric shock, lightning strikes, etc. Use of surge protection systems is highly recommended in order to
protect and extend the life of your equipment.

850921 HDMI Signal Manager

TLS electronics GmbH Contact: [e-mail]

Table of Contents

1. Introduction.........................................................................................4

2. Features...............................................................................................4

3. Panel Descriptions.................................................................................5

4. Appl i cation Diag r a m ...... . ....... ....... . . ...... . . ...... . . ....... ........ ....... . . .....7

5. Specifications.......................................................................................7

6. Package Contents................................................................................7

7. Maintenance.......................................................................................8

8. Warranty Policy.................................................................................8

9. Limitations of Warranty............................................................................8

10. Exclusive Remedies......... ...................................................................9

11. RMA Policy…………….…………………………............................................................... ..9

850921 HDMI Signal Manager

TLS electronics GmbH Contact: [e-mail]

Introduction

TLS HDMI 1.4 Signal Manager can work in two modes, one mode for extracting the audio via Coaxial and
stereo outputs from HDMI source, and the other mode for removing the original audio of HDMI source and
embedding auxiliary audio via L/R input to the HDMI output. It also features embedded pre-set EDID’s as
testing device in the video signal chain.

Features

 HDMI amplifier
 Extract audio from the HDMI video
 Extract audio with or without an actual display connected
 Provides both digital and analog audio outputs
 Can remove the audio from the HDMI input signal and embed auxiliary stereo audio to HDMI output

signal

 Support 3D Video & 4K
 HDCP compatible

850921 HDMI Signal Manager

TLS electronics GmbH Contact: [e-mail]

Panel Descriptions

Front Panel

1. L/R In--- Analog stereo auxiliary audio input

2. HDMI Input---Connect to HDMI source device

3. DC 5V--- Connect to 5V/1A power supply

4. LED indicator for HDMI input---Lit when detecting HDMI signal

5. LED indicator for power---Lit when getting power

Rear panel

1. Coaxial Out—Extract the audio from HDMI input

2. HDMI Output---Connect to HDMI sink device

3. L/R Out--- Extract the audio from HDMI input and convert to 2CH if source Audio is PCM

4. LED indicator for HDMI Output---Lit when detecting HDMI signal

850921 HDMI Signal Manager

TLS electronics GmbH Contact: [e-mail]

Side panel

1. DIP switcher--- EDID management
3 2 1 0

Combination of DIP positions

EDID type

0 0 0 0 Copy EDID from output1
0 0 0 1 1080P 2.0CH
0 0 1 0 1080P 5.1CH
0 0 1 1 1080P 7.1CH
0 1 0 0 1080i 2.0CH
0 1 0 1 1080i 5.1CH
0 1 1 0 1080i 7.1CH
0 1 1 1 3D 2.0CH
1 0 0 0 3D 5.1CH
1 0 0 1 3D 7.1CH
1 0 1 0 4K 2.0CH
1 0 1 1 4K 5.1CH
1 1 0 0 4K 7.1CH
1 1 0 1 DVI 1280x1024
1 1 1 0 DVI 1920x1080
1 1 1 1 DVI 1920x1200

2. Mode selection DIP switch

Position 1=0: Input HPD depends on Output HPD
Position 1=1: Input HPD forced high
Position 0=0: HDMI extractor mode
Position 0=1: HDMI embedder mode, remove the audio from HDMI input signal and embed the
L/R input to HDMI input signal

850921 HDMI Signal Manager

TLS electronics GmbH Contact: [e-mail]

Application Diagram

Specifications

Bandwidth 2.97Gbps per color
Video Input Connectors 1x HDMI Type A, 19-pin, female
Audio Input Connectors 1x 3.5mm stereo jack (L/R)
Video Output Connectors 1x HDMI Type A, 19-pin, female
Audio Output Connectors 1x RCA(SPDIF), 1x 3.5mm stereo jack (L/R)
EDID 4-PIN DIP Switch
Mode 2-PIN DIP Switch
Dimensions(W x D x H) 55mm x 60mm x 23mm, without feet
Shipping Weight 0.15KG
Operating Temperature 32°F to 104°F (0°C to 40°C)
Storage Temperature - 4°F to 140°F (- 20°C to 60°C)
Power Supply 5V/1A DC

850921 HDMI Signal Manager

TLS electronics GmbH Contact: [e-mail]

Package Contents

1. 1x 850921 HDMI 1.4 Signal Manager

2. 1x 5V/1A Power Supply

Maintenance

Clean this unit with a soft, dry cloth. Never use alcohol, paint thinner or benzene to clean this unit.

Warranty Policy

TLS electronics products are warranted against defects in material and workmanship for three years
from the date of shipment. During the warranty period, TLS electronics will, at its option, repair or replace
products that prove to be defective. Repairs are warranted for the remainder of the original warranty or a
90 day extended warranty, whichever is longer.

For equipment under warranty, the owner is responsible for freight to TLS electronics and all related
customs, taxes, tariffs, insurance, etc. TLS electronics is responsible for the freight charges only for
return of the equipment from the factory to the owner. TLS electronics will return the equipment by the
same method as the equipment was sent to TLS electronics.

All equipment returned for warranty repair must have a valid RMA number issued prior to return and be
marked clearly on the return packaging. TLS electronics strongly recommends all equipment be
returned in its original packaging.

TLS electronics obligations under this warranty are limited to repair or replacement of failed parts, and
the return shipment to the buyer of the repaired or replaced parts.

850921 HDMI Signal Manager

TLS electronics GmbH Contact: [e-mail]

Limitations of Warranty

The warranty does not apply to any part of a product that has been installed, altered, repaired, or
misused in any way that, in the opinion of TLS electronics, would affect the reliability or detracts from the
performance of any part of the product, or is damaged as the result of use in a way or with equipment
that had not been previously approved by TLS electronics.

The warranty does not apply to any product or parts thereof where the serial number or the serial
number of any of its parts has been altered, defaced, or removed.

The warranty does not cover damage or loss incurred in transportation of the product.

The warranty does not cover replacement or repair necessitated by loss or damage from any cause
beyond the control of TLS electronics, such as lightning or other natural and weather related events or
wartime environments.

The warranty does not cover any labor involved in the removal and or reinstallation of warranted
equipment or parts on site, or any labor required to diagnose the necessity for repair or replacement.
The warranty excludes any responsibility by TLS electronics for incidental or consequential damages
arising from the use of the equipment or products, or for any inability to use them either separate from or
in combination with any other equipment or products.

A fixed charge established for each product will be imposed for all equipment returned for warranty
repair where TLS electronics cannot identify the cause of the reported failure.

Exclusive Remedies

TLS electronics’s warranty, as stated is in lieu of all other warranties, expressed, implied, or statutory,
including those of merchantability and fitness for a particular purpose. The buyer shall pass on to any
purchaser, lessee, or other user of TLS electronics products, the aforementioned warranty, and shall
indemnify and hold harmless TLS electronics from any claims or liability of such purchaser, lessee, or
user based upon allegations that the buyer, its agents, or employees have made additional warranties or
representations as to product preference or use.

The remedies provided herein are the buyer’s sole and exclusive remedies. TLS electronics shall not be
liable for any direct, indirect, special, incidental, or consequential damages, whether based on contract,
tort, or any other legal theory.

850921 HDMI Signal Manager

TLS electronics GmbH Contact: [e-mail]

RMA Policy

When returning product to TLS electronics for any reason, the customer should fill out the official RMA
form to obtain a RMA number. Without the permission or approval, TLS electronics will be no
responsible for any return. This can be initiated by emailing or calling your related sales. All requests are
processed within 48 hours.

Standard Replacement

For customers that agree to return defective product to TLS electronics first, a Standard Replacement
option is available.

An RMA number must first be issued by sales. This RMA number will need to be referenced on the
outside of the return shipment.

Upon receipt of the defective product, TLS electronics will, at its discretion, either repair or replace the
product and ship it out in the most expeditious manner possible. Subject to availability, the replacement
product will be shipped on the business day following receipt of the defective product.

In the event the product returned to TLS electronics has been discontinued (i.e. the product is no longer
being manufactured by TLS electronics but is still under warranty), TLS electronics will, at its discretion,
either repair or replace with recertified product.

Once you have obtained an RMA number

After obtaining an RMA number from TLS electronics, you must send the product - freight prepaid - to
TLS electronics. The TLS electronics RMA number must be prominently displayed on the outside of your
package. If you send your product to TLS electronics without the RMA number prominently displayed on
the outside of the package, it will be returned to you unopened.

Please use a shipping company that can demonstrate proof of delivery. TLS electronics does not accept
responsibility for any lost shipments unless proof of delivery to TLS electronics is provided.

850921 HDMI Signal Manager

TLS electronics GmbH Contact: [e-mail]

Please note:

Product shipped to TLS electronics must be properly packaged to prevent loss or damage in transit.

Shipping your RMA to TLS electronics using regular mailing envelopes is not acceptable, as they do not
protect the product from damage during shipping.

TLS electronics will not repair or replace a module that is shipped in such a way that the product is not
properly protected.

TLS electronics will not accept any product that has been damaged as a result of accident, abuse,
misuse, natural or personal disaster, or any unauthorized disassemble, repair or modification.
