TLC DXP-3800EC User Manual

ООО «ТЛК Трейд» | 196158, г.Санкт-Петербург, Пулковское шоссе, д.30, корп.4, оф. 213В (юр.) | ИНН 7810592830 КПП 781001001

р/с 40702810068000007550 | к/с 30101810200000000704 | Филиал ОПЕРУ ОАО Банк ВТБ в Санкт-Петербурге | БИК 044030704

ОКПО 66035862 | ОКАТО 40284565000 | ОГРН 1107847196060 | т.(812)6499888 | http://www.tlct.ru http://www.rftel.ru

ООО «ТЛК Трейд», Санкт

-

Петербург

[phone]

[e-mail]

DXP

DXPDXP

DXP

----

3800EC

3800EC3800EC

3800EC

User

Manual

Brighten Your Digital View!

8-Way MPEG-2 SD Encoder

ООО «ТЛК Трейд» | 196158, г.Санкт-Петербург, Пулковское шоссе, д.30, корп.4, оф. 213В (юр.) | ИНН 7810592830 КПП 781001001

р/с 40702810068000007550 | к/с 30101810200000000704 | Филиал ОПЕРУ ОАО Банк ВТБ в Санкт-Петербурге | БИК 044030704

ОКПО 66035862 | ОКАТО 40284565000 | ОГРН 1107847196060 | т.(812)6499888 | http://www.tlct.ru http://www.rftel.ru

ООО «ТЛК Трейд», Санкт

-

Петербург

[phone]

[e-mail]

01 Notice

03 Before Using the Device

04 1 Overview

04 2 Features

05 3 Technical Specifications

06 4 Block Diagram

06 5 Front panel and rear panel instructions

06 5.1 Front panel

07 5.2 Rear panel

08 6 Control with Front Panel

08 6.1 Overview of the Menu

08 6.2 Description of menu

08 6.2.1 Status

09 6.2.2 Configuration

14 6.2.3 System

15 7 Control with Web Server

15 7.1 Status

16 7.2 Encoder

18 7.3 TS/IP

22 7.4 MUX

Contents

ООО «ТЛК Трейд» | 196158, г.Санкт-Петербург, Пулковское шоссе, д.30, корп.4, оф. 213В (юр.) | ИНН 7810592830 КПП 781001001

р/с 40702810068000007550 | к/с 30101810200000000704 | Филиал ОПЕРУ ОАО Банк ВТБ в Санкт-Петербурге | БИК 044030704

ОКПО 66035862 | ОКАТО 40284565000 | ОГРН 1107847196060 | т.(812)6499888 | http://www.tlct.ru http://www.rftel.ru

ООО «ТЛК Трейд», Санкт

-

Петербург

[phone]

[e-mail]

Notices

COPYRIGHT (Copyright © 2014 Beijing Jaeger Communication Electronic Technology Co., Ltd.)
Not to be copied, used or translated in part or whole without Beijing Jaeger prior consent in writing

except approval of ownership of copyright and copyright law.

WARRANTY

This warranty does not cover parts which may become defective due to misuse of the information
contained in this manual.

Read this manual carefully and make sure you understand the instructions provided. For your
safety, be aware of the following precautions.

WARNING! IMPORTATNT SAFETY INSTRUCTIONS
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE

COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.

WARNING

• To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture.

• To avoid explosion danger, do not dispose of batteries in an open fire.

CE MARK FOR EUROPEAN HARMONISED STANDARDS

The CE mark which is attached to these products means it conforms to EMC Directive
(89/336/EEC) and Low Voltage Directive (73/23/EEC).

IMPORTANT INFORMATION

Please retain the original packaging, should it be necessary at some stage to return the device.

Disposal of Old Electrical and Electronic Equipment (Applicable in the European Union and
other European countries with separate collection systems)

This symbol on the product or on its packaging indicates that this product shall not be
treated as household waste. Instead it shall be handed over to the applicable collection
point for the recycling of electrical and electronic equipment. By ensuring this product is
disposed of correctly, you will help prevent potential negative consequences for the
environment and human health, which could otherwise be caused by inappropriate waste
handling of this product. The recycling of materials will help to conserve natural resources.

ООО «ТЛК Трейд» | 196158, г.Санкт-Петербург, Пулковское шоссе, д.30, корп.4, оф. 213В (юр.) | ИНН 7810592830 КПП 781001001

р/с 40702810068000007550 | к/с 30101810200000000704 | Филиал ОПЕРУ ОАО Банк ВТБ в Санкт-Петербурге | БИК 044030704

ОКПО 66035862 | ОКАТО 40284565000 | ОГРН 1107847196060 | т.(812)6499888 | http://www.tlct.ru http://www.rftel.ru

ООО «ТЛК Трейд», Санкт

-

Петербург

[phone]

[e-mail]

For more detailed information about recycling of this product, please contact your local
Civic Office, your household waste disposal service, or the shop where you purchased the
product.

COPYRIGHTS

Television programs, movies, video tapes, discs, and other materials may be copyrighted.
Unauthorized recording of copyrighted material may be against the copyright laws in your region.
Also, use of this product with cable television transmissions may require authorization from the
cable television operator or transmitter/owner.

VENTILATION

• Do not expose the product to high temperatures, such as placing it on top of other product that
produce heat or in places exposed to direct sunlight or spot lights.

• The ventilation slots on top of the product must be left uncovered to allow proper airflow into the
device.

• Do not stand the product on soft furnishings or carpets.

• Do not stack electronic equipment on top of the product.

• Do not place the product in a location subject to extreme changes in temperature. The temperature
gradient should be less than 10 degrees C/hour.

• Place the product in a location with adequate ventilation to prevent the build-up of heat inside the
product. The minimum ventilation space around the device should be 7 cm. The ventilation should
not be impeded by covering the ventilation openings with items, such as newspapers, table cloth,
curtains, etc.

POWER SOURCES

• The product is not disconnected from the AC power source (mains) as long as it is connected to the
power outlet or wall socket, even if the product is turned off.

• If the product will not be used for a long period of time, disconnect it from the AC power outlet or wall
socket.

ООО «ТЛК Трейд» | 196158, г.Санкт-Петербург, Пулковское шоссе, д.30, корп.4, оф. 213В (юр.) | ИНН 7810592830 КПП 781001001

р/с 40702810068000007550 | к/с 30101810200000000704 | Филиал ОПЕРУ ОАО Банк ВТБ в Санкт-Петербурге | БИК 044030704

ОКПО 66035862 | ОКАТО 40284565000 | ОГРН 1107847196060 | т.(812)6499888 | http://www.tlct.ru http://www.rftel.ru

ООО «ТЛК Трейд», Санкт

-

Петербург

[phone]

[e-mail]

Before Using the Device

Thank you for purchasing the DXP-3800EC 8-Way MPEG-2 SD Encoder. This User Manual is
written for operators/users of the DXP-3800EC to assist in installation and operation. Please read
this user manual carefully before installation and use of the device.

FOR YOUR SAFETY

This equipment is provided with a protective earthing ground incorporated in the power cord. The
main plug shall only be inserted in a socket outlet provided with a protective earth contact. Any
interruption of the protective conductor, inside or outside the device, is likely to make the device
dangerous. Do not remove the covers of this equipment. Hazardous voltages are present within
this equipment and may be exposed if the covers are removed. Only Beijing Jaeger trained and
approved service engineers are permitted to service this equipment.

The supplied AC power cable must be used to power the device. If the power cord becomes
damaged it must be replaced. No operator serviceable parts inside. Refer servicing to Beijing
Jaeger trained and approved service engineers. For the correct and safe use of the device, it is
essential that both operating and servicing personnel follow generally accepted safety procedures
in addition to the safety precautions specified in this manual. Whenever it is likely that safety
protection is impaired, the device must be made in-operative and secured against unintended
operation. The appropriate servicing authority must be informed. For example, safety is likely to be
impaired if the device fails to perform the intended measurements or shows visible damage.

WARNINGS

• The mounting environment should be relatively dust free, free of excessive vibration and the ambient
temperature between 0C° to 40C°. Relative humidity of 20% to 80% (non-condensed) is
recommended.

ООО «ТЛК Трейд» | 196158, г.Санкт-Петербург, Пулковское шоссе, д.30, корп.4, оф. 213В (юр.) | ИНН 7810592830 КПП 781001001

р/с 40702810068000007550 | к/с 30101810200000000704 | Филиал ОПЕРУ ОАО Банк ВТБ в Санкт-Петербурге | БИК 044030704

ОКПО 66035862 | ОКАТО 40284565000 | ОГРН 1107847196060 | т.(812)6499888 | http://www.tlct.ru http://www.rftel.ru

ООО «ТЛК Трейд», Санкт

-

Петербург

[phone]

[e-mail]

• Avoid direct contact with water.

• Never place the equipment in direct sunlight.

• The outside of the equipment may be cleaned using a lightly dampened cloth. Do not use any
cleaning liquids containing alcohol, methylated spirit or ammonia etc.

• For continued protection against fire hazard, replace line fused only with same type.

• Air intake for cooling is achieved via holes at the side of the device and the fans inside. The air flow
should not be obstructed. Therefore, the device has to be placed on a flat surface, leaving some
space at the sides of the device.

• When in operation, the internal temperature should not exceed the limit of 70C°.

DXP-3800EC Series

8-Way MPEG-2 SD Encoder

1 Overview

DXP-3800EC is an integrated 8-way high density MPEG-2 Encoder. Eight ways of Standard Definition
(SD) base band real time A/V programs could be encoded simultaneously. These streams encoded
could be re-multiplexed with the stream from its ASI input port. The final re-multiplexed Transport
Stream (TS) is available at its Gigabit TSoverIP port and ASI output port. The series provide two TS/IP
operation modes. The first is “Full Duplex”, which allows one MPTS or SPTS inputted over 1
multicast/unicast to make up a new MPTS with local encoders, then sends out the new one over 1
multicast/unicast. In the second mode “Multiple output” which delivers up to 9 streams over IP. There
are 8 un-stuffed SPTS (lower bit rate but less PCR accurate than normal SPTS, from local encoders)
and 1 MPTS (from internal reMultiplexer) over the IP with different Unicast or Multicast IP addresses.
DXP-3800EC allows user to configure, monitoring and manage over the informative front panel and
keypad, or Web interface, or SNMP based management software from 3rd party. This Encoder family
presents brilliant picture quality, high density design, high stability system architecture, and the hot­swappable power supply.

2 Features

 Compile with MPEG-1(ISO/IEC11172), MPEG-2 MP@ML(ISO/IEC13818)
 Video resolution 576i (PAL, SECAM) & 480i (NTSC)
 MPEG1 Layer I/II audio compression
 8-way real time encoder with re-multiplexed integrated
 Built-in re-Mux accepts up to 10 SPTS/MPTS (8 from local encoders, 2 from external input over IP and ASI)

ООО «ТЛК Трейд» | 196158, г.Санкт-Петербург, Пулковское шоссе, д.30, корп.4, оф. 213В (юр.) | ИНН 7810592830 КПП 781001001

р/с 40702810068000007550 | к/с 30101810200000000704 | Филиал ОПЕРУ ОАО Банк ВТБ в Санкт-Петербурге | БИК 044030704

ОКПО 66035862 | ОКАТО 40284565000 | ОГРН 1107847196060 | т.(812)6499888 | http://www.tlct.ru http://www.rftel.ru

ООО «ТЛК Трейд», Санкт

-

Петербург

[phone]

[e-mail]

 1 ASI input (for daisy chain) & Redundant ASI output
 Full duplex Gigabit TS over IP I/O (under Full duplex operation mode)
 Up to 9 multicast/unicast output (under Multiple-channel operation mode)
 SNMP & HTTP WEB
 Redundant Power Supplies



19” x 1 U EIA standard chassis

3 Technical Specifications

Video input & Encode

Number of input ports CVBS x 8
Encoding Standard MPEG-2 MP@ML
Chrominance Format 4:2:0
Compression Bit Rate 1.7Mbps~20Mbps
Video Resolutions &
Recommended

Compression Bit Rates

480i（720×480）@29.97Hz:SMPTE656M: 3~6Mb/s
576i（720×576）@25Hz: SMPTE656M: 3~6Mb/s

Audio Input & Encode

Number of input ports 8 pairs of Stereo Audios

MPEG1 Layer I

Compression Standard

MPEG1 Layer II

Sampling Rate 48KSym/s

MPEG1 Layer I: 64~256Kb/s

Compression Bit Rate

MPEG1 Layer II: 32~384Kb/s

DVB-ASI Input

Interface BNC Female, 75Ω
Maximum Input Bit rate 100 Mb/s
Data Transfer type Byte
Packet Length 188 or 204 Bytes
Signal Level 200 ~ 880mVp-p

DVB-ASI Output

Interface BNC Female, 75Ω
Effective Data Rate

1.5 Mb/s ～70 Mb/s

ООО «ТЛК Трейд» | 196158, г.Санкт-Петербург, Пулковское шоссе, д.30, корп.4, оф. 213В (юр.) | ИНН 7810592830 КПП 781001001

р/с 40702810068000007550 | к/с 30101810200000000704 | Филиал ОПЕРУ ОАО Банк ВТБ в Санкт-Петербурге | БИК 044030704

ОКПО 66035862 | ОКАТО 40284565000 | ОГРН 1107847196060 | т.(812)6499888 | http://www.tlct.ru http://www.rftel.ru

ООО «ТЛК Трейд», Санкт

-

Петербург

[phone]

[e-mail]

Data Transfer type Byte
Packet Length 188 or 204 Bytes
Signal Level 800±80mV

Gigabit TS_over_IP

Standard IEEE 802.3, 10/100/1000 Base-T, Full Duplex
Maximum Effective Bit

Rate

80Mb/s

Data Protocol UDP or RTP, SPTS or MPTS
Control Protocol ICMP, ARP, IGMPv2

Interfaces on Rear Panel

ASI In 1 x BNC Female, 75Ω
CVBS In 8 x BNC Female, 75Ω
AUDIO In 8 x BNC Female, 75Ω
ASI Out 2×BNC Female, 75Ω(1 Backup)

Interfaces on Front Panel

Control 1×RJ-45, 10/100 Base-T
TS/IP 1× IP (GbE), RJ-45, 10/100/1000 Base-T, Full Duplex
Display 2 x 20 LCD Display

Others

Power Supply AC90~260V 50/60Hz
Operating Temperature

0 ~ 45℃

Storage Temperature

-10 ~ 60℃

Operation Humidity 10 ~ 90%, (Non-condensed)

4 Block Diagram

ООО «ТЛК Трейд» | 196158, г.Санкт-Петербург, Пулковское шоссе, д.30, корп.4, оф. 213В (юр.) | ИНН 7810592830 КПП 781001001

р/с 40702810068000007550 | к/с 30101810200000000704 | Филиал ОПЕРУ ОАО Банк ВТБ в Санкт-Петербурге | БИК 044030704

ОКПО 66035862 | ОКАТО 40284565000 | ОГРН 1107847196060 | т.(812)6499888 | http://www.tlct.ru http://www.rftel.ru

ООО «ТЛК Трейд», Санкт

-

Петербург

[phone]

[e-mail]

A3 A4

5 Front panel and rear panel instructions

5.1 Front panel

A5

A7

A6

A2 A1

ООО «ТЛК Трейд» | 196158, г.Санкт-Петербург, Пулковское шоссе, д.30, корп.4, оф. 213В (юр.) | ИНН 7810592830 КПП 781001001

р/с 40702810068000007550 | к/с 30101810200000000704 | Филиал ОПЕРУ ОАО Банк ВТБ в Санкт-Петербурге | БИК 044030704

ОКПО 66035862 | ОКАТО 40284565000 | ОГРН 1107847196060 | т.(812)6499888 | http://www.tlct.ru http://www.rftel.ru

ООО «ТЛК Трейд», Санкт

-

Петербург

[phone]

[e-mail]

B1

B2

B3

B3 B4

B5

B6

A1 Status LEDs Power: green when power is on, red when one of the power supply unit

malfunction

Warning: red when function faulty

Alarm: red when function critical

A2 Encoder Status Encoder 1~8 working status, green light indicates the corresponding encoder

module is under working, red when the corresponding encoder module
malfunction or stop or input is invalid

A3 VFD Panel

A4 Keypad 6 keys for local control

A5 USB Used to upgrade software version of this device

A6 Management Ethernet (10/100 LAN) control port

A7 TS/IP TS over IP I/O port

5.2 Rear panel of DXP-3800EC

B1 ASI IN ASI input interface

B2 ASI OUT 2 ASI output interface (output in mirror)

B3 Audio Video IN SDI/HDMI input interface

B4 RS232 Reserved for factory use

B5 Alarm Alarm relay interface

ООО «ТЛК Трейд» | 196158, г.Санкт-Петербург, Пулковское шоссе, д.30, корп.4, оф. 213В (юр.) | ИНН 7810592830 КПП 781001001

р/с 40702810068000007550 | к/с 30101810200000000704 | Филиал ОПЕРУ ОАО Банк ВТБ в Санкт-Петербурге | БИК 044030704

ОКПО 66035862 | ОКАТО 40284565000 | ОГРН 1107847196060 | т.(812)6499888 | http://www.tlct.ru http://www.rftel.ru

ООО «ТЛК Трейд», Санкт

-

Петербург

[phone]

[e-mail]

B6 Power Socket AC Power Input

6 Control with Front Panel

With the keypad and display panel on the front panel, user can configure the device locally.

6.1 Overview of the Menu

Power on the device and wait for initialization complete, the Local IP address will be displayed on the VFD panel.
Press〔ENTER〕to get into the main menu.

Main Menu

Status

Configuration

System

Input Bit Rate

TS/IP Status
(Full Duplex/

Multiple
Output)

Encoder

Remux

TS/IP

(Mode:

Multiple

Output/ Full

Duplex)

ООО «ТЛК Трейд» | 196158, г.Санкт-Петербург, Пулковское шоссе, д.30, корп.4, оф. 213В (юр.) | ИНН 7810592830 КПП 781001001

р/с 40702810068000007550 | к/с 30101810200000000704 | Филиал ОПЕРУ ОАО Банк ВТБ в Санкт-Петербурге | БИК 044030704

ОКПО 66035862 | ОКАТО 40284565000 | ОГРН 1107847196060 | т.(812)6499888 | http://www.tlct.ru http://www.rftel.ru

ООО «ТЛК Трейд», Санкт

-

Петербург

[phone]

[e-mail]

(1) Status: show the status of the device
(2) Configuration: Configure and monitor parameters of encoding/transcoding
(3) System: Configure the local settings of the device

6.2 Description of menu

The main menu items can be selected with the keypad. By pressing the [Enter], the user navigates to the sub­menus, which are selected in the same manner.

6.2.1 Status

Sub-Menu

Sub-menu
Parameter

Description Factory Default Value

Encoder 1 Bit Rate Display encoder 1 bit rate
Encoder 2 Bit Rate Display encoder 2 bit rate
Encoder 3 Bit Rate Display encoder 3 bit rate
Encoder 4 Bit Rate Display encoder 4 bit rate
Encoder 5 Bit Rate Display encoder 5 bit rate
Encoder 6 Bit Rate Display encoder 6 bit rate
Encoder 7 Bit Rate Display encoder 7 bit rate
Encoder 8 Bit Rate Display encoder 8 bit rate
ASI Input Bit rate Display the input ASI signal bit rate

Input Bit Rate

TS/IP Input Bit Rate

Display the TSoverIP input bit rate (Valid under Fully
Duplex mode only)

Link Status Display IP link status:10M/100M/1000M

Display IP out UDP packet/s
Display IP out column FEC packet/s

Gigabit Output Status

Display IP out row FEC packet/s
Display IP in lock status and lock bitrate
Display IP in protocol

TS/IP Status
(Full Duplex)

Gigabit In Status

Display IP in mode of column FEC and row FEC

ООО «ТЛК Трейд» | 196158, г.Санкт-Петербург, Пулковское шоссе, д.30, корп.4, оф. 213В (юр.) | ИНН 7810592830 КПП 781001001

р/с 40702810068000007550 | к/с 30101810200000000704 | Филиал ОПЕРУ ОАО Банк ВТБ в Санкт-Петербурге | БИК 044030704

ОКПО 66035862 | ОКАТО 40284565000 | ОГРН 1107847196060 | т.(812)6499888 | http://www.tlct.ru http://www.rftel.ru

ООО «ТЛК Трейд», Санкт

-

Петербург

[phone]

[e-mail]

Display IP in packets per UDP frame
Display IP in received TS frames

Display IP in fixed RTP frames
TS/IP Status
(Multiple

Output)

Link Status

Display IP link Status:

10M/100M/1000M/Disconnect

6.2.2 Configuration

Sub-Menu

Sub-menu
Parameter

Description

Factory Default
Value

Encoder Select

Encoder Select:
Encoder 1: the encoder 1 is active for configuration
Encoder 2: the encoder 2 is active for configuration
Encoder 3: the encoder 3 is active for configuration
Encoder 4: the encoder 4 is active for configuration
Encoder 5: the encoder 5 is active for configuration
Encoder 6: the encoder 6 is active for configuration
Encoder 7: the encoder 7 is active for configuration
Encoder 8: the encoder 8 is active for configuration

Encoder

Video Settings

Mode:
PAL/NTSC/SECAM: set the video mode

Resolution: set the resolution of the output video
D1 / HD1 / SIF / QSIF / Sliced Screen / 2/3D1 /

3/4D1

GOP Structure: set the structure of GOP
IBBPBBPBB/IIIIIIIII/IPPPPPPPP/IBIPBPBPB

GOP Size: 0-63. Set the GOP size, valid range from

0-63. Note the bigger the value, better the
compression ratio (for video) but longer the latency of
encoding.

Saturation Control: set the saturation of the picture,

Mode: PAL

Resolution: D1

GOP Structure:
IBBPBBPBB

GOP Size: 61

ООО «ТЛК Трейд» | 196158, г.Санкт-Петербург, Пулковское шоссе, д.30, корп.4, оф. 213В (юр.) | ИНН 7810592830 КПП 781001001

р/с 40702810068000007550 | к/с 30101810200000000704 | Филиал ОПЕРУ ОАО Банк ВТБ в Санкт-Петербурге | БИК 044030704

ОКПО 66035862 | ОКАТО 40284565000 | ОГРН 1107847196060 | т.(812)6499888 | http://www.tlct.ru http://www.rftel.ru

ООО «ТЛК Трейд», Санкт

-

Петербург

[phone]

[e-mail]

Hue Control: set the hue of the picture, valid range
0~255

Brightness Control: set the brightness of the
picture, valid range 0~255

Contrast Control: set the contrast of the picture,
valid range 0~255

Aspect Ratio:
4:3: set video aspect ratio to 4:3
16:9: set video aspect ratio to 16:9

Hue Control: 0

Brightness Control: 135

Contrast Control: 123

Aspect Ratio: 4:3

Audio Settings

Audio Format:
MPEG1 Layer2: set the audio compression format

MPEG-1 Layer I or MPEG-1 Layer II

Sample: 48K/32K/44.1K

Set the audio sampling rate

Audio Bit Rate: 32k bps /64k bps /128k bps /192k
bps /256k bps /384k bps

Set the audio bitrate

Audio Channel Mode: Stereo / Joint Stereo / Dual
Channel / Single Channel

Set the audio channel mode.

Audio Level: Mute/+6dB~-17dB

Set the gain of output volume

Audio Format: MPEG1
Layer I

Sample: 48K

Audio Bit Rate: 192 Kbps

Audio Channel Mode:
Stereo

Audio Level: 0dB

Encoder Bit Rate

Encoder Bit Rate: 1.7M~20MKbps. set the output bit
rate of the selected encoder.

Note: Encoder bit rate must greater than the sum of
video bit rate + audio bit rate + PSI (150Kbps) +
buffering (100Kbps) + encoder error (150Kbps)

Encoder Bit Rate:
5000Kb/s

Encoder

Advanced Settings

PMT PID: set PMT PID, valid range from 32 to 8190
decimal

Output PMT PID: 43

ООО «ТЛК Трейд» | 196158, г.Санкт-Петербург, Пулковское шоссе, д.30, корп.4, оф. 213В (юр.) | ИНН 7810592830 КПП 781001001

р/с 40702810068000007550 | к/с 30101810200000000704 | Филиал ОПЕРУ ОАО Банк ВТБ в Санкт-Петербурге | БИК 044030704

ОКПО 66035862 | ОКАТО 40284565000 | ОГРН 1107847196060 | т.(812)6499888 | http://www.tlct.ru http://www.rftel.ru

ООО «ТЛК Трейд», Санкт

-

Петербург

[phone]

[e-mail]

Video PID: set Video PID, valid range from 32 to
8190 decimal

Output Video PID: 4001

Audio PID: set audio PID, valid range from 32 to
8190 decimal

Output AudioPID:4002

PCR PID: set PCR PID, valid range from 32 to 8190
decimal

Output PCR PID:8004

Service PID: set Service PID, valid from 32 to 8190
decimal

Output Service PID:4000

Service Name: set the service name

Output Service Name:
Encoder Video

Program List

Program List: select the programs to remux. Click
on Enter to select, double click to cancel. (The
program(s) will be marked with an asterisk (*) once
be selected)

Encoder 1: select the SPTS from encoder 1
Encoder 2: select the SPTS from encoder 2
Encoder 3: select the SPTS from encoder 3
Encoder 4: select the SPTS from encoder 4
Encoder 5: select the SPTS from encoder 5
Encoder 6: select the SPTS from encoder 6
Encoder 7: select the SPTS from encoder 7
Encoder 8: select the SPTS from encoder 8
ASI Input: select the program(s) inputted via ASI

input port.
IP Input: select the program(s) inputted via IP input

port. (Note: this sub-menu is displayed only when the
Gigabit I/O is configured as full-duplex mode.)

Bit Rate

Output Bit Rate: set the bit rate of the newly
generated MPTS, valid range from 100~216000 Kb/s

Output Bit Rate:
38015Kb/s

Packet Size

188 Byte / 204 Byte

188 Byte

TS ID

TS ID: key in the TSID of the newly generated MPTS,
valid range from 0 to 65535 decimal

TS ID:00008

Remove CA

ON: remove the CA descriptors that are carried
within the inputted TS over ASI or IP

OFF: keep the CA descriptors

OFF

Insert EIT

ON: insert EIT into the output stream, EIT data may
come from ASI or IP input port

OFF: don’t insert EIT into the output stream.

OFF

Remux

Output Program Display the program list of the remux

ООО «ТЛК Трейд» | 196158, г.Санкт-Петербург, Пулковское шоссе, д.30, корп.4, оф. 213В (юр.) | ИНН 7810592830 КПП 781001001

р/с 40702810068000007550 | к/с 30101810200000000704 | Филиал ОПЕРУ ОАО Банк ВТБ в Санкт-Петербурге | БИК 044030704

ОКПО 66035862 | ОКАТО 40284565000 | ОГРН 1107847196060 | т.(812)6499888 | http://www.tlct.ru http://www.rftel.ru

ООО «ТЛК Трейд», Санкт

-

Петербург

[phone]

[e-mail]

Channel 1~8
(the streaming

comes from Encoder
1~8
correspondingly.)

Uni/Multi IP Address: set the uni/multicast IP
address for the IP output 1~8

Uni/Multi UDP Port: set the port number, valid range
from 1~65535

Target MAC Address:

set the destination port number MAC Address
Gigabit Out Switch: ON/OFF: to switch on/off the

current channel

Uni/Multi IP Address:

238.069.070.001
Uni/Multi UDP Port:
01234
Target MAC Address:
00:00:24:56:12:67
Gigabit Out Switch: ON

Channel 9
(the streaming

comes from the
built-in Remux or
ASI input.)

Uni/Multi IP Address: set the uni/multicast IP
address for the IP output channel 9

Uni/Multi UDP Port: set the port number, valid range
from 1~65535

Target MAC Address:

set the destination port number MAC Address
Gigabit Out Switch: ON/OFF: to switch on/off the

current channel

MUX/ASI Out: set the source for IP output
channel 9

Uni/Multi IP Address:

238.069.070.001
Uni/Multi UDP Port:
01234
Target MAC Address:
00:00:24:56:12:67
Gigabit Out Switch: ON

MUX/ASI Out: ASI

Gigabit Address: set the IP address of the IP port

IP Board IP
Address:10.10.80.60

Gigabit Subnet Mask: set the net mask of the IP
port

IP Board Net
Mask:255.255.255.0

Gigabit Gateway: set the gateway of the IP port

IP Board
Gateway:10.10.80.1

Gigabit MAC Address: display the MAC address of
the IP port

IP Board MAC Address:

Protocol:
UDP: set UDP protocol to IP output
RTP: set RTP protocol to IP output

Protocol: UDP

TS Pkts Per UDP: set the number of TS packets that
can be carried by each UDP packet, valid range from
1~7

TS Pkts Per UDP: 7

Time To Live: set TTL to the output IP packets, valid
range from 1~255

Time To Live: 255

Type Of Service: Min Delay/Max Reliability/Max
Throughput/Min Monetary Cost/Normal

Type Of Service: Min
Delay

TS/IP(Gigabit
Mode:
Multiple
Output)

Gigabit Local

Gateway MAC Address: set the MAC address of the
gateway under which the device is connected

Gateway MAC Address:
ff:ff:ff:ff:ff:ff

ООО «ТЛК Трейд» | 196158, г.Санкт-Петербург, Пулковское шоссе, д.30, корп.4, оф. 213В (юр.) | ИНН 7810592830 КПП 781001001

р/с 40702810068000007550 | к/с 30101810200000000704 | Филиал ОПЕРУ ОАО Банк ВТБ в Санкт-Петербурге | БИК 044030704

ОКПО 66035862 | ОКАТО 40284565000 | ОГРН 1107847196060 | т.(812)6499888 | http://www.tlct.ru http://www.rftel.ru

ООО «ТЛК Трейд», Санкт

-

Петербург

[phone]

[e-mail]

Gigabit Out Switch: Enable/Disable

Gigabit Out Switch: ON

Protocol:
UDP: set UDP protocol to IP output
RTP: set RTP protocol to IP output

Protocol: UDP

TS Pkts Per UDP: set the number of TS packets that
can be carried by each UDP packet, valid range from
1~7

TS Pkts Per UDP: 7

Time To Live: set TTL to the output IP packets, valid
range from 1~255

Time To Live: 1~255

Type Of Service: Min Delay/Max Reliability/Max
Throughput/Min Monetary Cost/Normal

Type Of Service: Min
Delay

Uni/Multi IP Address: set the destination IP address

Uni/Multi Address:

238.069.070.001

Uni/Multi UDP Port: set the destination port number,
valid range from 1~65535

Uni/Multi UDP Port:
01234

ProMPEG FEC Switch: Enable/Disable

ProMPEG FEC Switch:
Disable

ProMPEG FEC Mode:
1D,5x5/1D,5x20/1D,10x10/2D,5x5/2D,5x20/2D,10x10

ProMPEG FEC Mode :
1D,5x5

Gigabit Output

FEC Alignment:

Annex A/Annex B

FEC Alignment:

Annex A

Gigabit Address: set the IP address of the IP port

Gigabit Adress:

010.010.080.060

Gigabit Subnet Mask: set the net mask of the IP
port

Gigabit Subnet Mask:

255.255.255.000

Gigabit MAC Address: display the MAC address of
the IP port

Gigabit Gateway: set the gateway of the IP port

Gigabit IP Gateway:

010.010.080.001

Gigabit Local

Gateway MAC Address: set the MAC address of the
gateway under which the device is connected

Gateway MAC Address:
ff:ff:ff:ff:ff:ff:ff

Uni/Multi Address: set the uni/multicast target
address of the IP input

Uni/Multi
Addres:238.069.070.002

TS/IP
(Gigabit
Mode: Full
Duplex)

Gigabit Input

Uni/Multi UDP Port: set the target port number of
the uni/multicast IP input, valid range from 1~65535

Uni/Multi UDP Port:
01234

ООО «ТЛК Трейд» | 196158, г.Санкт-Петербург, Пулковское шоссе, д.30, корп.4, оф. 213В (юр.) | ИНН 7810592830 КПП 781001001

р/с 40702810068000007550 | к/с 30101810200000000704 | Филиал ОПЕРУ ОАО Банк ВТБ в Санкт-Петербурге | БИК 044030704

ОКПО 66035862 | ОКАТО 40284565000 | ОГРН 1107847196060 | т.(812)6499888 | http://www.tlct.ru http://www.rftel.ru

ООО «ТЛК Трейд», Санкт

-

Петербург

[phone]

[e-mail]

TS Clock Recovery:
Auto: it is suggested to set Auto when there is

accurate PCR carried by the inputted TS/IP
Fixed Rate: when fixed rate is selected, user has to

configure a bit rate to regenerate the TS clock. The
configured fixed bit rate has to be a little bit higher
than the bit rate of the inputted TS/IP.

TS Clock Recovery: Auto

6.2.3 System

IP Address: set the IP address of the device, valid range from

0.0.0.0~255.255.255.255

IP Address:

10.10.70.48

Subnet Mask: set the net mask of the device, valid range from

0.0.0.0~ 255.255.255.255

Net Mask:

255.255.255.0

Gateway: set the gateway of the device, valid range from

0.0.0.0~255.255.255.255

Gateway: 10.10.70.1

Network Setting

MAC Address: to display the MAC address

Remote Setting

Trap IP Address: set the IP address of the SNMP Trap server, valid
range from 0.0.0.0~255.255.255.255

Trap IP Address:

10.10.70.25

Device Label

Device Label: user allows to rename the device, press Enter and key
in the name of the device, then press Enter to confirm the setting or
press Exit to cancel.

Software Version

Software Version: display the software version

Factory Default

Factory Default:
Enter = Yes: press Enter to recall the factory default settings.
Exit = No: press Exit to cancel

Note: the network
settings will not reset to
the factory setting!

MAC Address: to Modify the MAC address
S/N: display the serial number of the device

Gigabit MAC Address: to Modify the Gigabit MAC address

Machine Type

Detail Version: Display the detail version of MCU,FPGA,LINUX OS

WEB Login ID

Edit Login ID: press Enter and key in the login ID for WEB
management

Default Login ID: root

WEB Login Password

Edit Login Password: press Enter and key in the password for WEB
management

Default Login
Password: 12345

Gigabit Mode: Gigabit Mode

Multiple Output: the Gigabit I/O is configured as multiple

uni/multicast output mode, which delivers up to 10 streams over IP.

Gigabit Mode: Multiple
Output

ООО «ТЛК Трейд» | 196158, г.Санкт-Петербург, Пулковское шоссе, д.30, корп.4, оф. 213В (юр.) | ИНН 7810592830 КПП 781001001

р/с 40702810068000007550 | к/с 30101810200000000704 | Филиал ОПЕРУ ОАО Банк ВТБ в Санкт-Петербурге | БИК 044030704

ОКПО 66035862 | ОКАТО 40284565000 | ОГРН 1107847196060 | т.(812)6499888 | http://www.tlct.ru http://www.rftel.ru

ООО «ТЛК Трейд», Санкт

-

Петербург

[phone]

[e-mail]

There are 8 stuffed or un-stuffed SPTS (lower bit rate but less PCR
accurate than normal SPTS, from local encoders) and two MPTS
from built-in remultiplexer and ASI input over the IP with different
Unicast or Multicast IP addresses.

Full Duplex: the IP I/O is configured as full duplex mode, which
allows only one MPTS or SPTS over IP input and output in
uni/multicast at the same time.

7. Control with Web Server

DXP-3800EC has an integrated web server. This web server allows the configuration and status requests with a
standard web browser. To operate a DXP-3800EC, first make sure the Ethernet control port is well connected in
the network and could be pinged by the host PC, and then enter the IP address of the DXP3800EC into the
browser, there will be a pop-up showed asking for login user and password. After login the device can be
operated. The default user name and password are respectively “root” and “12345”. The username and password
can be changed by user via front panel or via submenu under the system page. If the username and password
are forgotten, user have to set a new one via front panel.

7.1 Status

Via the status page, user can have an overview of the current input and output status of the connected DXP­3800EC.

ООО «ТЛК Трейд» | 196158, г.Санкт-Петербург, Пулковское шоссе, д.30, корп.4, оф. 213В (юр.) | ИНН 7810592830 КПП 781001001

р/с 40702810068000007550 | к/с 30101810200000000704 | Филиал ОПЕРУ ОАО Банк ВТБ в Санкт-Петербурге | БИК 044030704

ОКПО 66035862 | ОКАТО 40284565000 | ОГРН 1107847196060 | т.(812)6499888 | http://www.tlct.ru http://www.rftel.ru

ООО «ТЛК Трейд», Санкт

-

Петербург

[phone]

[e-mail]

Input Status

Output Status

TS/IP Status

7.2 Encoder

There are eight encoders integrated on one DXP-3800EC, each encoder can work independently. Click on the

to configure the encoder 1, the same for the rests.

ООО «ТЛК Трейд» | 196158, г.Санкт-Петербург, Пулковское шоссе, д.30, корп.4, оф. 213В (юр.) | ИНН 7810592830 КПП 781001001

р/с 40702810068000007550 | к/с 30101810200000000704 | Филиал ОПЕРУ ОАО Банк ВТБ в Санкт-Петербурге | БИК 044030704

ОКПО 66035862 | ОКАТО 40284565000 | ОГРН 1107847196060 | т.(812)6499888 | http://www.tlct.ru http://www.rftel.ru

ООО «ТЛК Трейд», Санкт

-

Петербург

[phone]

[e-mail]

Video Setup

Mode: PAL/NTSC/SECAM: set the video mode
Resolution: set the resolution of the output video
D1 / HD1 / SIF / QSIF / Sliced Screen / 2/3D1 / 3/4D1

GOP Structure: set the structure of GOP
IBBPBBPBB/IIIIIIIII/IPPPPPPPP/IBIPBPBPB

GOP Size: 0-63. Set the GOP size, valid range from 0-63. Note the bigger
the value, better the compression ratio (for video) but longer the

ООО «ТЛК Трейд» | 196158, г.Санкт-Петербург, Пулковское шоссе, д.30, корп.4, оф. 213В (юр.) | ИНН 7810592830 КПП 781001001

р/с 40702810068000007550 | к/с 30101810200000000704 | Филиал ОПЕРУ ОАО Банк ВТБ в Санкт-Петербурге | БИК 044030704

ОКПО 66035862 | ОКАТО 40284565000 | ОГРН 1107847196060 | т.(812)6499888 | http://www.tlct.ru http://www.rftel.ru

ООО «ТЛК Трейд», Санкт

-

Петербург

[phone]

[e-mail]

latency of encoding.
Saturation Control: set the saturation of the picture, valid range 0~255

Hue Control: set the hue of the picture, valid range 0~255

Brightness Control: set the brightness of the picture, valid range 0~255

Contrast Control: set the contrast of the picture, valid range 0~255

Aspect Ratio:
4:3: set video aspect ratio to 4:3
16:9: set video aspect ratio to 16:9

Audio Settings

Audio Format: set the audio compression format MPEG-1 Layer I or
MPEG-1 Layer II

Sample: Set the audio sampling rate, available options: 48K/32K/44.1K

Audio Bit Rate: Set the audio bitrate, available options: 32k bps /64k
bps /128k bps /192k bps /256k bps /384k bps

Audio Channel Mode: Set the audio channel mode, available mode:
Stereo / Joint Stereo / Dual Channel / Single Channel

ООО «ТЛК Трейд» | 196158, г.Санкт-Петербург, Пулковское шоссе, д.30, корп.4, оф. 213В (юр.) | ИНН 7810592830 КПП 781001001

р/с 40702810068000007550 | к/с 30101810200000000704 | Филиал ОПЕРУ ОАО Банк ВТБ в Санкт-Петербурге | БИК 044030704

ОКПО 66035862 | ОКАТО 40284565000 | ОГРН 1107847196060 | т.(812)6499888 | http://www.tlct.ru http://www.rftel.ru

ООО «ТЛК Трейд», Санкт

-

Петербург

[phone]

[e-mail]

Audio Level: Set the gain of output volume from +6dB to -17dB, or shut
off the audio by select Mute.

7.3 TS/IP

All models provide two TS/IP operation modes. The first is “Full Duplex”, which allows one MPTS or SPTS
inputted to make up a new MPTS with local encoders, then sends the new one over IP & ASI_out. In the second
mode “Multiple output” which delivers up to five streams over IP. There are four stuffed or un-stuffed SPTS and
one MPTS (from internal reMultiplexer) over the IP with different Unicast or Multicast IP addresses. The
management webpage will be different following the change of the operation mode.

Multiple Output Mode

The pages below are displayed under Multiple Output mode. To change the TS/IP operation mode, please refer
to chapter 7.5 System-Device.

ООО «ТЛК Трейд» | 196158, г.Санкт-Петербург, Пулковское шоссе, д.30, корп.4, оф. 213В (юр.) | ИНН 7810592830 КПП 781001001

р/с 40702810068000007550 | к/с 30101810200000000704 | Филиал ОПЕРУ ОАО Банк ВТБ в Санкт-Петербурге | БИК 044030704

ОКПО 66035862 | ОКАТО 40284565000 | ОГРН 1107847196060 | т.(812)6499888 | http://www.tlct.ru http://www.rftel.ru

ООО «ТЛК Трейд», Санкт

-

Петербург

[phone]

[e-mail]

Gigabit Output

Under multiple output operation mode, user can set output uni/multicast IP addresses and port number for each
encoder, the built-in remux, and ASI input. Each IP output channel can be switched ON/OFF independently. The
source for TS/IP output 1-8 is forced to link to the encoder 1-8 respectively and cannot be changed. The source
for the 9th uni/multicast output channel can be the built-in remux or ASI input.

(Note: the page below is displayed only when the TS/IP operation mode is Multiple Output mode. To change the
TS/IP operation mode, please refer to chapter 7.5 System-Device.)

ООО «ТЛК Трейд» | 196158, г.Санкт-Петербург, Пулковское шоссе, д.30, корп.4, оф. 213В (юр.) | ИНН 7810592830 КПП 781001001

р/с 40702810068000007550 | к/с 30101810200000000704 | Филиал ОПЕРУ ОАО Банк ВТБ в Санкт-Петербурге | БИК 044030704

ОКПО 66035862 | ОКАТО 40284565000 | ОГРН 1107847196060 | т.(812)6499888 | http://www.tlct.ru http://www.rftel.ru

ООО «ТЛК Трейд», Санкт

-

Петербург

[phone]

[e-mail]

Gigabit Input

Under Multiple output mode, the Gigabit Input is not available.

Local Settings

Set the parameters for the TS/IP output port.

Gigabit Address: set the IP address of the IP port

Gigabit Subnet Mask: set the net mask of the IP port

Gigabit MAC Address: display the MAC address of the IP port, cannot be modified by user

Gigabit Gateway: set the gateway address under which the IP port is connected

Gateway MAC Address: set the MAC address of the gateway under which the device is connected, this is

necessary when the IP streaming is needed to pass through the gateways

Full-duplex Output Mode

The pages below are displayed under Full-duplex mode. To change the TS/IP operation mode, please refer to

chapter 7.5 System-Device.

Gigabit Input

ООО «ТЛК Трейд» | 196158, г.Санкт-Петербург, Пулковское шоссе, д.30, корп.4, оф. 213В (юр.) | ИНН 7810592830 КПП 781001001

р/с 40702810068000007550 | к/с 30101810200000000704 | Филиал ОПЕРУ ОАО Банк ВТБ в Санкт-Петербурге | БИК 044030704

ОКПО 66035862 | ОКАТО 40284565000 | ОГРН 1107847196060 | т.(812)6499888 | http://www.tlct.ru http://www.rftel.ru

ООО «ТЛК Трейд», Санкт

-

Петербург

[phone]

[e-mail]

Under full-duplex operation mode, the device supports single uni/multicast reception. Set the uni/multicast target
IP address and port number in the page.

Uni/Multicast IP Address: set the multicast address for the incoming IP streaming. To receive a unicast
streaming, the submenu can be ignored.

Uni/Multicast UDP Port: set the port number for the incoming IP streaming.

TS Clock Recover:

Auto: it is suggested to set Auto when there is accurate PCR carried by the inputted TS/IP

Fixed Rate: when fixed rate is selected, user has to configure a bit rate to regenerate the TS clock. The

configured fixed bit rate has to be a higher than the bit rate of the inputted TS/IP.

Gigabit Output

Under full-duplex operation mode, the device supports single uni/multicast output. The default source for TS/IP
output is the built-in remux.

(Note: the page below is displayed only when the TS/IP operation mode is Full-duplex mode. To change the
TS/IP operation mode, please refer to chapter 7.5 System-Device.)

ООО «ТЛК Трейд» | 196158, г.Санкт-Петербург, Пулковское шоссе, д.30, корп.4, оф. 213В (юр.) | ИНН 7810592830 КПП 781001001

р/с 40702810068000007550 | к/с 30101810200000000704 | Филиал ОПЕРУ ОАО Банк ВТБ в Санкт-Петербурге | БИК 044030704

ОКПО 66035862 | ОКАТО 40284565000 | ОГРН 1107847196060 | т.(812)6499888 | http://www.tlct.ru http://www.rftel.ru

ООО «ТЛК Трейд», Санкт

-

Петербург

[phone]

[e-mail]

IP Out Switch: Enable or Disable the IP output

Source: select the source for the IP output in the dropdown list

Protocol: select UDP or RTP protocol for the IP output

TS Pkts Per UDP: select the number of TS packets that can be carried by each UDP packet

Time To Live: set TTL to the output IP packets

Type of Service: select the service type for the outputted IP streaming

Uni/Multi IP Address: set the unicast or multicast IP address for the output IP streaming

Uni/Multi UDP Port: set the port number, valid range from 1~65535

ProMPEG FEC Switch: Enable or Disable the ProMPEG FEC

(Note: the submenus below are available only when the ProMPEG FEC is switched on and has be applied)

ООО «ТЛК Трейд» | 196158, г.Санкт-Петербург, Пулковское шоссе, д.30, корп.4, оф. 213В (юр.) | ИНН 7810592830 КПП 781001001

р/с 40702810068000007550 | к/с 30101810200000000704 | Филиал ОПЕРУ ОАО Банк ВТБ в Санкт-Петербурге | БИК 044030704

ОКПО 66035862 | ОКАТО 40284565000 | ОГРН 1107847196060 | т.(812)6499888 | http://www.tlct.ru http://www.rftel.ru

ООО «ТЛК Трейд», Санкт

-

Петербург

[phone]

[e-mail]

ProMPEG FEC Mode: select the mode of ProMPEG FEC from the dropdown list

Column FEC UDP Port: set the port number for column FEC

Row FEC UDP Port: set the port number for row FEC

FEC Alignment: set the alignment for FEC
Test Drop Packets: set the test drop packets

Local Settings

Set the local network parameters for the TS/IP port.

Gigabit Address: set the IP address of the TS/IP port

Gigabit Subnet Mask: set the net mask of the TS/IP port

Gigabit MAC Address: display the MAC address of the TS/IP port, cannot be modified by user

Gigabit Gateway: set the gateway address under which the TS/IP port is connected

ООО «ТЛК Трейд» | 196158, г.Санкт-Петербург, Пулковское шоссе, д.30, корп.4, оф. 213В (юр.) | ИНН 7810592830 КПП 781001001

р/с 40702810068000007550 | к/с 30101810200000000704 | Филиал ОПЕРУ ОАО Банк ВТБ в Санкт-Петербурге | БИК 044030704

ОКПО 66035862 | ОКАТО 40284565000 | ОГРН 1107847196060 | т.(812)6499888 | http://www.tlct.ru http://www.rftel.ru

ООО «ТЛК Трейд», Санкт

-

Петербург

[phone]

[e-mail]

Gateway MAC Address: set the MAC address of the gateway under which the device is connected, this is
necessary when the IP streaming is needed to pass through the gateways

7.4 MUX

The device supports remux the 8 SPTS generated locally with the service(s) carried by the transport stream
inputted via ASI In or TS/IP In (available only under full duplex mode).

The “Output Bit Rate” is the bit rate of the remux output, the value has to be equal or greater than the total bit rate
of the selected services.

Packet Size: set the packet length of the new 188 or 204 Byte

Max Bit Rate (Kbps): Set the bitrate for the new generated MPTS, valid range from 100~216000 Kb/s. The

bitrate should be at least bigger than the total bitrate of selected programs, otherwise, packets may dropout.

TS ID: Set the TSID of the new generated transport stream, valid range from 0 to 65535 decimal

Insert EIT: ON: insert EIT into the output stream, EIT data may come from ASI or IP input port

ООО «ТЛК Трейд» | 196158, г.Санкт-Петербург, Пулковское шоссе, д.30, корп.4, оф. 213В (юр.) | ИНН 7810592830 КПП 781001001

р/с 40702810068000007550 | к/с 30101810200000000704 | Филиал ОПЕРУ ОАО Банк ВТБ в Санкт-Петербурге | БИК 044030704

ОКПО 66035862 | ОКАТО 40284565000 | ОГРН 1107847196060 | т.(812)6499888 | http://www.tlct.ru http://www.rftel.ru

ООО «ТЛК Трейд», Санкт

-

Петербург

[phone]

[e-mail]

OFF: EIT will not be inserted into the output stream.

Remove CA: ON: remove the CA descriptors that are carried within the inputted TS over ASI or IP

OFF: keep the CA descriptors

7.5 System

The system page gives all information of this device including device name, serial number, software version, and
so on. User can implement the alarm switch configuration, network settings, TS/IP operation mode and software
upgrade under system page.

Device

Device Label: Check the name and the serial number of this device. User can resign this product name at will,

the device name should be less than 24 characters. The serial number is read-only.

Serial Number: show the serial number for the device, cannot be modified by user.

WEB Auto Refresh Time: set the interval of webpage refresh.

Gigabit Mode: switch the TS/IP operation mode between “Multiple Output” and “Full duplex”. The device will

reboot after change.

IP Control

The network settings for the device can be found and configured under the page below.

ООО «ТЛК Трейд» | 196158, г.Санкт-Петербург, Пулковское шоссе, д.30, корп.4, оф. 213В (юр.) | ИНН 7810592830 КПП 781001001

р/с 40702810068000007550 | к/с 30101810200000000704 | Филиал ОПЕРУ ОАО Банк ВТБ в Санкт-Петербурге | БИК 044030704

ОКПО 66035862 | ОКАТО 40284565000 | ОГРН 1107847196060 | т.(812)6499888 | http://www.tlct.ru http://www.rftel.ru

ООО «ТЛК Трейд», Санкт

-

Петербург

[phone]

[e-mail]

IP Address: set the device’s IP address

Network Mask: set the net mask of the device

Gateway: set the gateway address of the device
MAC: display the MAC address of the device, cannot be modified by user

Version

User can check versions of various functional blocks of the device, as it shown in figure below.

Login

Set the login ID and password for the web management server of the device.

ООО «ТЛК Трейд» | 196158, г.Санкт-Петербург, Пулковское шоссе, д.30, корп.4, оф. 213В (юр.) | ИНН 7810592830 КПП 781001001

р/с 40702810068000007550 | к/с 30101810200000000704 | Филиал ОПЕРУ ОАО Банк ВТБ в Санкт-Петербурге | БИК 044030704

ОКПО 66035862 | ОКАТО 40284565000 | ОГРН 1107847196060 | т.(812)6499888 | http://www.tlct.ru http://www.rftel.ru

ООО «ТЛК Трейд», Санкт

-

Петербург

[phone]

[e-mail]

Factory Default

Click the button “Default” to restore the factory default settings to the device.

Note: the IP address of the device and the operation mode of the Gigabit board will not be restored.

System Reboot

User can reboot this device by clicking the button “Reboot”.

ООО «ТЛК Трейд» | 196158, г.Санкт-Петербург, Пулковское шоссе, д.30, корп.4, оф. 213В (юр.) | ИНН 7810592830 КПП 781001001

р/с 40702810068000007550 | к/с 30101810200000000704 | Филиал ОПЕРУ ОАО Банк ВТБ в Санкт-Петербурге | БИК 044030704

ОКПО 66035862 | ОКАТО 40284565000 | ОГРН 1107847196060 | т.(812)6499888 | http://www.tlct.ru http://www.rftel.ru

ООО «ТЛК Трейд», Санкт

-

Петербург

[phone]

[e-mail]

8 Installation

It is highly recommended to fix the DXP-3800EC be mounted in EIA standard 19” rack, any other mounting
method may lead to damage to the device.

 Open the box and take out the device with care. Inspect if there is any damage to the appearance of

the device.

 Fix the device into the standard EIA 19” rack.
 Connect the input and output cables. It is highly recommended to put the 75Ohm loader onto the ASI

output port that is not used.

 Plug the power cable into the AC Power input socket. The POWER Indicator LED (A4) should be green

and always light on during working. The DXP-3800EC needs about one minutes to boot up completely.

 Configure the network settings of the device via front panel.
 Make the settings of Encoder, Remux, and IP output step by step following the instruction written in the

user manual.

9 Accessories

CD-ROM 1PC

Certificate of quality /Guarantee card 1PC

RCA to BNC converter 24PCS

Power Cable 2PCS

ООО «ТЛК Трейд» | 196158, г.Санкт-Петербург, Пулковское шоссе, д.30, корп.4, оф. 213В (юр.) | ИНН 7810592830 КПП 781001001

р/с 40702810068000007550 | к/с 30101810200000000704 | Филиал ОПЕРУ ОАО Банк ВТБ в Санкт-Петербурге | БИК 044030704

ОКПО 66035862 | ОКАТО 40284565000 | ОГРН 1107847196060 | т.(812)6499888 | http://www.tlct.ru http://www.rftel.ru

ООО «ТЛК Трейд», Санкт

-

Петербург

[phone]

[e-mail]

75Ohm Loader 1PC
